[en] Instruction manual Free standing cooker
Free standing cooker
HKQ38A150M

en
3
Table of contents
[en]I ns t r uc t i on manual Fr ee st andi ng cooker
8Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
(Important safety information . . . . . . . . . . . . . . . 4
Halogen lamp. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
]Causes of damage . . . . . . . . . . . . . . . . . . . . . . . . 6
Hob . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Damage to the oven. . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Damage to the plinth drawer . . . . . . . . . . . . . . . . . . . . 7
7Environmental protection . . . . . . . . . . . . . . . . . . 7
Saving energy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Saving energy with the hob . . . . . . . . . . . . . . . . . . . . . 8
Environmentally-friendly disposal . . . . . . . . . . . . . . . . . 8
5Installation and connection. . . . . . . . . . . . . . . . . 9
Electrical connection . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Levelling the cooker . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Adjacent units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Wall fixing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Measures to be noted during transport . . . . . . . . . . . . 9
*Getting to know your appliance . . . . . . . . . . . . 10
General information . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Cooking area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Cooking compartment . . . . . . . . . . . . . . . . . . . . . . . . 12
_Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Accessories included . . . . . . . . . . . . . . . . . . . . . . . . . 13
Inserting accessories . . . . . . . . . . . . . . . . . . . . . . . . . 13
Optional accessories . . . . . . . . . . . . . . . . . . . . . . . . . 13
KBefore using for the first time. . . . . . . . . . . . . . 14
Initial use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Cleaning the cooking compartment and accessories 14
1Setting the cooking time . . . . . . . . . . . . . . . . . 15
Setting procedure. . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Large dual-circuit hotplate . . . . . . . . . . . . . . . . . . . . . 15
Table of cooking times. . . . . . . . . . . . . . . . . . . . . . . . 15
1Operating the appliance . . . . . . . . . . . . . . . . . . 16
Switching the appliance on and off . . . . . . . . . . . . . . 16
Setting the heating function and temperature . . . . . . 16
Rapid heating. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
OTime-setting options . . . . . . . . . . . . . . . . . . . . . 17
Setting the cooking time . . . . . . . . . . . . . . . . . . . . . . 17
Setting the end time . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Setting the timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Setting the time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
AChildproof lock. . . . . . . . . . . . . . . . . . . . . . . . . . 19
Activating and deactivating. . . . . . . . . . . . . . . . . . . . .19
DCleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Cleaning agents . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Surfaces in the cooking compartment . . . . . . . . . . . .21
Keeping the appliance clean . . . . . . . . . . . . . . . . . . .22
pRails. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Detaching and refitting the rails . . . . . . . . . . . . . . . . .23
qAppliance door . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Detaching and attaching the oven door . . . . . . . . . . .24
Removing and refitting the door panels . . . . . . . . . . .24
Additional door safety. . . . . . . . . . . . . . . . . . . . . . . . .25
3Trouble shooting . . . . . . . . . . . . . . . . . . . . . . . . 25
Rectifying faults yourself . . . . . . . . . . . . . . . . . . . . . . .25
Replacing the bulb in the top of the cooking
compartment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
4Customer service . . . . . . . . . . . . . . . . . . . . . . . . 26
E number and FD number . . . . . . . . . . . . . . . . . . . . .26
JTested for you in our cooking studio. . . . . . . . 27
General information . . . . . . . . . . . . . . . . . . . . . . . . . .27
Cakes and pastries. . . . . . . . . . . . . . . . . . . . . . . . . . .28
Bakes and gratins . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Poultry, meat and fish . . . . . . . . . . . . . . . . . . . . . . . . .31
Vegetables and side dishes . . . . . . . . . . . . . . . . . . . .34
Yoghurt. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
Acrylamide in foodstuffs . . . . . . . . . . . . . . . . . . . . . . .34
Drying . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
Prove dough . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
Defrosting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Produktinfo
Additional information on products, accessories,
replacement parts and services can be found at
www.bosch-home.com and in the online shop
www.bosch-eshop.com

en Intended use
4
8Intended use
Intended use Read these instructions carefully. Only then
will you be able to operate your appliance
safely and correctly. Retain the instruction
manual and installation instructions for future
use or for subsequent owners.
The images shown in these instructions are for
guidance only.
Check the appliance for damage after
unpacking it. Do not connect the appliance if it
has been damaged in transport.
Only a licensed professional may connect
appliances without plugs. Damage caused by
incorrect connection is not covered under
warranty.
This appliance is intended for private domestic
use and the household environment only. The
appliance must only be used for the
preparation of food and beverages. The
cooking process must be supervised. A short
cooking process must be supervised without
interruption. Only use the appliance in
enclosed spaces.
This appliance is intended for use up to a
maximum height of 4000 metres above sea
level.
This appliance is not designed for operation
with an external timer or by remote control.
Do not use inappropriate child safety shields
or hob guards. These can cause accidents.
This appliance may be used by children over
the age of 8 years old and by persons with
reduced physical, sensory or mental
capabilities or by persons with a lack of
experience or knowledge if they are
supervised or are instructed by a person
responsible for their safety how to use the
appliance safely and have understood the
associated hazards.
Children must not play with, on, or around the
appliance. Children must not clean the
appliance or carry out general maintenance
unless they are at least 15 years old and are
being supervised.
Keep children below the age of 8 years old at
a safe distance from the appliance and power
cable.
Always slide accessories into the cooking
compartment the right way round.
~"Accessories" on page 13
(Important safety
information
Impor t ant saf et y informat i on :Warning – Risk of fire!
■Combustible items stored in the cooking
compartment may catch fire. Never store
combustible items in the cooking
compartment. Never open the appliance
door if there is smoke inside. Switch off the
appliance and unplug it from the mains or
switch off the circuit breaker in the fuse box.
Risk of fire!
■A draught is created when the appliance
door is opened. Greaseproof paper may
come into contact with the heating element
and catch fire. Do not place greaseproof
paper loosely over accessories during
preheating. Always weight down the
greaseproof paper with a dish or a baking
tin. Only cover the surface required with
greaseproof paper. Greaseproof paper
must not protrude over the accessories.
Risk of fire!
■Hot oil and fat can ignite very quickly. Never
leave hot fat or oil unattended. Never use
water to put out burning oil or fat. Switch off
the hotplate. Extinguish flames carefully
using a lid, fire blanket or something similar.
Risk of fire!
■The hotplates become very hot. Never
place combustible items on the hob. Never
place objects on the hob.
Risk of fire!
■The appliance becomes very hot, and
flammable materials can easily catch fire.
Do not store or use any flammable objects
(e.g. aerosol cans, cleaning agents) under
or in the vicinity of the oven. Do not store
any flammable objects inside or on top of
the oven.
Risk of fire!
■The surfaces of the plinth drawer may
become very hot. Only store oven
accessories in the drawer. Flammable and
combustible objects must not be stored in
the plinth drawer.
:Warning – Risk of burns!
■The appliance becomes very hot. Never
touch the interior surfaces of the cooking
compartment or the heating elements.
Always allow the appliance to cool down.
Keep children at a safe distance.
Risk of serious burns!
■Accessories and ovenware become very
hot. Always use oven gloves to remove
accessories or ovenware from the cooking
compartment.
Risk of burns!

Important safety information en
5
■Alcoholic vapours may catch fire in the hot
cooking compartment. Never prepare food
containing large quantities of drinks with a
high alcohol content. Only use small
quantities of drinks with a high alcohol
content. Open the appliance door with care.
Risk of burns!
■The hotplates and surrounding area
(particularly the hob surround, if fitted)
become very hot. Never touch the hot
surfaces. Keep children at a safe distance.
Risk of burns!
■During operation, the surfaces of the
appliance become hot. Do not touch the
surfaces when they are hot. Keep children
away from the appliance.
Risk of burns!
■The hotplate heats up but the display does
not work. Switch off the circuit breaker in
the fuse box. Contact the after-sales
service.
Risk of burns!
■The appliance becomes hot during
operation. Allow the appliance to cool down
before cleaning.
:Warning – Risk of scalding!
■The accessible parts become hot during
operation. Never touch the hot parts. Keep
children at a safe distance.
Risk of scalding!
■When you open the appliance door, hot
steam can escape. Steam may not be
visible, depending on its temperature. When
opening, do not stand too close to the
appliance. Open the appliance door
carefully. Keep children away.
Risk of scalding!
■Water in a hot cooking compartment may
create hot steam. Never pour water into the
cooking compartment when the cooking
compartment is hot.
:Warning – Risk of injury!
■Scratched glass in the appliance door may
develop into a crack. Do not use a glass
scraper, sharp or abrasive cleaning aids or
detergents.
Risk of injury!
■Saucepans may suddenly jump due to
liquid between the pan base and the
hotplate. Always keep the hotplate and
saucepan bases dry.
Risk of injury!
■If the appliance is placed on a base and is
not secured, it may slide off the base. The
appliance must be fixed to the base.
Risk of injury!
■The hinges on the appliance door move
when opening and closing the door, and
you may be trapped. Keep your hands away
from the hinges.
Risk of injury!
■If you leave the appliance door open,
people may bump into it, resulting in injury.
The appliance door must be kept closed
both while the appliance is in operation and
when it has finished.
:Warning – Risk of tipping!
Warning: In order to prevent tipping of the
appliance, this stabilizing means must be
installed. Refer to the instructions for
installation.
:Warning – Risk of electric shock!
■Incorrect repairs are dangerous. Repairs
may only be carried out by one of our
trained after-sales engineers. If the
appliance is faulty, unplug the mains plug or
switch off the fuse in the fuse box. Contact
the after-sales service.
Risk of electric shock and serious injury!
■The cable insulation on electrical
appliances may melt when touching hot
parts of the appliance. Never bring
electrical appliance cables into contact with
hot parts of the appliance.
Risk of electric shock!
■Do not use any high-pressure cleaners or
steam cleaners, which can result in an
electric shock.
Risk of electric shock!
■A defective appliance may cause electric
shock. Never switch on a defective
appliance. Unplug the appliance from the
mains or switch off the circuit breaker in the
fuse box. Contact the after-sales service.
Risk of electric shock!
■Cracks or fractures in the glass ceramic
may cause electric shocks. Switch off the
circuit breaker in the fuse box. Contact the
after-sales service.
Halogen lamp
:Warning – Risk of burns!
The bulbs in the cooking compartment
become very hot. There is still a risk of burning
your skin for some time after they have been
switched off. Do not touch the glass cover.
Avoid contact with your skin when cleaning.

en Causes of damage
6
:Warning – Risk of electric shock!
When replacing the cooking compartment
bulb, the bulb socket contacts are live. Before
replacing the bulb, unplug the appliance from
the mains or switch off the circuit breaker in
the fuse box.
]Causes of damage
Ca u s e s of damage Hob
Caution!
■Rough pot and pan bases scratch the ceramic.
■Avoid boiling pots dry. This may cause damage.
■Never place hot pots or pans on the control panel,
the display area or the surround. This may cause
damage.
■Damage can occur if hard or pointed objects fall on
the hob.
■Aluminium foil and plastic containers melt on hot
hotplates. Oven protective foil is not suitable for your
hob.
Overview
The following table provides an overview of the most
frequent kinds of damage:
Damage to the oven
Caution!
■Accessories, foil, greaseproof paper or ovenware on
the cooking compartment floor: do not place
accessories on the cooking compartment floor. Do
not cover the cooking compartment floor with any
sort of foil or greaseproof paper. Do not place
ovenware on the cooking compartment floor if a
temperature of over 50 ºC has been set. This will
cause heat to accumulate. The baking and roasting
times will no longer be correct and the enamel will
be damaged.
■Aluminium foil: Aluminium foil in the cooking
compartment must not come into contact with the
door glass. This could cause permanent
discolouration of the door glass.
■Water in a hot cooking compartment: do not pour
water into the cooking compartment when it is hot.
This will cause steam. The temperature change can
cause damage to the enamel.
■Moisture in the cooking compartment: Over an
extended period of time, moisture in the cooking
compartment may lead to corrosion. Allow the
cooking compartment to dry after use. Do not keep
moist food in the closed cooking compartment for
extended periods of time. Do not store food in the
cooking compartment.
■Cooling with the appliance door open: Following
operation at high temperatures, only allow the
cooking compartment to cool down with the door
closed. Do not trap anything in the appliance door.
Even if the door is only left open a crack, the front of
nearby furniture may become damaged over time.
Only leave the cooking compartment to dry with the
door open if a lot of moisture was produced whilst
the oven was operating.
■Fruit juice: when baking particularly juicy fruit pies,
do not pack the baking tray too generously. Fruit
juice dripping from the baking tray leaves stains that
cannot be removed. If possible, use the deeper
universal pan.
■Extremely dirty seal: If the seal is very dirty, the
appliance door will no longer close properly during
operation. The fronts of adjacent units could be
damaged. Always keep the seal clean. Never
operate the appliance if the seal is damaged or
missing. ~"Cleaning" on page 20
■Appliance door as a seat, shelf or worktop: Do not
sit on the appliance door, or place or hang anything
on it. Do not place any cookware or accessories on
the appliance door.
■Inserting accessories: depending on the appliance
model, accessories can scratch the door panel
when closing the appliance door. Always insert the
accessories into the cooking compartment as far as
they will go.
Damage Cause Action
Stains Food spills Remove spills immediately with a glass scraper.
Unsuitable cleaning agents Only use cleaning agents which are suitable for ceramic
Scratches Salt, sugar and sand Do not use the hob as a work surface or storage space.
Rough pot and pan bases scratch the
ceramic.
Check your cookware.
Discolouration Unsuitable cleaning agents Only use cleaning agents which are suitable for ceramic
Pan abrasion (e.g. aluminium) Lift the pots and pans when moving them.
Blisters Sugar, food with a high sugar content Remove spills immediately with a glass scraper.

Environmental protection en
7
■Carrying the appliance: do not carry or hold the
appliance by the door handle. The door handle
cannot support the weight of the appliance and
could break.
■Grilling: do not insert the baking tray or universal pan
higher than level 3 when grilling. The high heat
distorts it and the enamel may be damaged when it
is removed. At level 4 and 5, only grill directly on the
wire rack.
Damage to the plinth drawer
Caution!
Do not place hot objects in the plinth drawer. It could be
damaged.
7Environmental protection
En v i r o n ment al pr ot ect i on Your new appliance is particularly energy-efficient.
Here you can find tips on how to save even more
energy when using the appliance, and how to dispose
of your appliance properly.
Saving energy
■Only preheat the appliance if this is specified in the
recipe or in the tables in the operating instructions.
■Leave frozen food to defrost before placing it in the
cooking compartment.
■Use baking tins that are dark-coloured, painted black
or have an enamel coating. These absorb the heat
particularly well.
■Remove any unnecessary accessories from the
cooking compartment.
■Open the appliance door as infrequently as possible
when the appliance is in use.

en Environmental protection
8
■It is best to bake several cakes one after the other.
The cooking compartment stays warm. This reduces
the baking time for the second cake. You can place
two cake tins next to each other in the cooking
compartment.
■For longer cooking times, you can switch the
appliance off 10 minutes before the end of the
cooking time and use the residual heat to finish
cooking.
Saving energy with the hob
■Use pots and pans with thick, even bases. Uneven
bases increase energy consumption.
■The diameter of pan bases should be the same size
as the hotplate. In particular, small saucepans on the
hotplate cause energy losses. Note that cookware
manufacturers often indicate the upper diameter of
the saucepan. This is usually bigger than the
diameter of the base of the pan.
■Use a small saucepan for small quantities. A larger,
less full saucepan requires a lot of energy.
■Always place suitable lids on saucepans. When
cooking without a lid, four times the energy is
required.
■Cook with only a little water. This will save energy.
Vitamins and minerals in vegetables are preserved.
■Switch to a lower heat setting in good time.
■Use the residual heat. For longer cooking times, you
can switch the hotplate off 5-10 minutes before the
end of the cooking time.
Environmentally-friendly disposal
Dispose of packaging in an environmentally-friendly
manner.
This appliance is labelled in accordance with
European Directive 2012/19/EU concerning
used electrical and electronic appliances
(waste electrical and electronic equipment -
WEEE). The guideline determines the
framework for the return and recycling of used
appliances as applicable throughout the EU.

Installation and connection en
9
5Installation and connection
Instal l ati on and c onnect i on Do not install the appliance behind a decorative door
or the door of a kitchen unit, as this may cause the
appliance to overheat.
Electrical connection
Only licensed specialists may connect the appliance.It
is important that you comply with the requirements of
your electricity supplier.
Any damage arising from the appliance being
connected incorrectly will invalidate the warranty.
Caution!
If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
:Warning – Danger of death!
There is a risk of electric shock if you touch live
components.
■Always make sure your hands are dry when you
touch or hold the mains plug.
■Only pull out the mains cable by taking hold of the
plug and removing the plug; never pull it out by the
mains cable itself, as this could damage it.
■Never unplug the mains plug when the appliance is
in operation.
Please note the following information and ensure that:
Notes
■The mains plug fits the socket.
■The cable cross section is adequate.
■The earthing system is properly installed.
■The mains cable is only replaced by a qualified
electrician (if this is necessary).Spare mains cables
can be ordered from our after-sales service.
■No power strips/multi-way connectors or extension
cables are used.
■If using a residual current device, only use one that
bears the mark z.
The presence of this mark is the only way to be sure
that it fulfils all the applicable regulations.
■The mains plug can be accessed at all times.
■The mains cable is not kinked, crushed, modified or
severed.
■The mains cable does not come into contact with
heat sources.
For the installer
■An all-pole isolating switch with a contact gap of at
least 3 mm must be present in the installation circuit.
This is not necessary if the appliance is connected
by a plug that is accessible to the user.
■Electrical safety: The cooker corresponds to safety
class I and may only be used in conjunction with a
safety earth terminal.
■A type H 05 VV-F or equally rated lead must be used
to connect the appliance.
Levelling the cooker
Always place the cooker directly on the floor.
1. Pull out the plinth drawer and lift it up and out.
There are adjustable feet at the front and rear on the
inside of the plinth.
2. Use an Allen key to raise or lower the adjustable feet
as necessary until the cooker is level (picture A).
3. Push the plinth drawer back in (picture B).
Adjacent units
Any adjacent units must not be made of flammable
materials. The fronts of any adjacent units must be heat-
resistant up to at least 90 °C.
Wall fixing
To prevent the cooker from tipping over, you must fix it
to the wall using the enclosed bracket. Please observe
the installation instructions for fixing the oven to the
wall.
Measures to be noted during transport
Secure all mobile parts in and on the appliance using
an adhesive tape that can be removed without leaving
any traces. Push all accessories (e.g. baking tray) into
the corresponding slots with cardboard at the edges, in
order to avoid damaging the appliance. Place
cardboard or similar between the front and rear side to
prevent knocks against the inside of the glass door.
Secure the door and, if available, the top cover to the
appliance sides using adhesive tape.
Keep the original appliance packaging. Only transport
the appliance in the original packaging. Observe the
transport arrows on the packaging.
If the original packaging is no longer available
pack the appliance in protective packaging to
guarantee sufficient protection against any transport
damage.
Transport the appliance in an upright position. Do not
hold the appliance by the door handle or the
connections on the rear, as these could be damaged.
Do not place any heavy objects on the appliance.
%$

en Getting to know your appliance
10
*Getting to know your
appliance
Get t i ng to know your appl i ance In this section, we will explain the indicators and
controls. You will also find out about the various
functions of your appliance.
Note: Depending on the appliance model, individual
details and colours may differ.
General information
The design depends on the respective appliance
model. Cooking area
Here is an overview of the control panel. The design
depends on the respective appliance model.
Residual heat indicator
The hob has a residual heat indicator for each hotplate.
It shows which hotplates are still hot. Even if the hob is
switched off, the display remains lit until the hotplate
has cooled down sufficiently.
You can save energy by using the residual heat to keep
a small dish warm, for example.
Explanations
1 Hob**
2Control panel**
3* Cooling fan
4 Oven door**
5* Plinth drawer**
* Optional (available for some appliances)
** Details may vary depending on the appliance
model.






Explanations
1 Hotplate 18 cm
2 Hotplate 14.5 cm
3 Hotplate 18 cm
4 Two-ring cooking zone 21 and 12 cm
5 Residual heat indicator





Getting to know your appliance en
11
Control panel
Details may vary depending on the appliance model.
Control knobs
The control knobs can be pushed in and remain
pressed down when they are in the "out" position. Press
down on the control knob again to release it back up.
Buttons and display
You can use the buttons to set various additional
functions on your appliance. You will be able to see the
values for these on the display.
--------
Buttons
The sensors are located under the individual buttons.
They must not be pressed too firmly. Only touch the
corresponding symbol.
Display
The value that can be set at the present time or that is
elapsing will be shown in large digits on the display.
To use the individual time-setting options, tap the
vbutton several times. The symbol that lights up
corresponds to the value currently shown in large digits
on the display.
Types of heating and functions
Use the function selector to set the types of heating and
other functions.
To make sure you always use the right type of heating
to cook your food, we have explained the differences
and applications below.
--------
Other functions
Your new oven has yet more functions; see below for a
brief description of these.
--------
Symbol Meaning
\Time-setting options Tap the symbol repeatedly to select
the timer Q, duration x, end
time yand time.
Childproof lock Lock and unlock the oven functions
on the control panel by pressing and
holding the button for approx. 4 sec-
onds.
A
@
Minus
Plus
Reduce setting values.
Increase setting values.
Type of heating Use
<3D hot air For baking and roasting on one or more levels.
The fan distributes the heat from the ring heating element in the back panel evenly around
the cooking compartment.
6Gentle hot air For gently cooking selected types of food on one level without preheating.
The fan distributes the heat from the ring-shaped heating element in the back panel
around the cooking compartment.
This heating function is used to measure both the energy consumption in air recirculation
mode and the energy efficiency class.
(Grill, large area For grilling flat items, such as steaks or sausages, for making toast, and for browning
food.
The whole area below the grill element becomes hot.
7Circulated air grilling For roasting poultry, whole fish and larger pieces of meat.
The grill element and the fan switch on and off alternately. The fan circulates the hot air
around the food.
%Top/bottom heating For traditional baking and roasting on one level. Especially suitable for cakes with moist
toppings.
Heat is emitted evenly from above and below.
This heating function is used to measure the energy consumption in the conventional
mode.
BDefrosting For defrosting meat, poultry, bread and cakes.
The fan circulates the hot air around the food.
Function Use
FRapid heating Preheats the cooking compartment rapidly without accessories.

en Getting to know your appliance
12
Temperature
Use the temperature selector to set the temperature in
the cooking compartment. You can also use it to select
the settings for other functions.
For temperature settings above 250 °C, the appliance
reduces the temperature to approx. 240 °C after
approx. 10 minutes. If your appliance has the top/
bottom heating or bottom heating types, this reduction
does not take place.
--------
Temperature display
When the appliance is heating, the psymbol will be lit
on the display. It goes out during pauses in the heating.
When you are preheating the appliance, the optimal
time to place your food in the cooking compartment is
when the symbol first goes out.
Note: Due to thermal inertia, the temperature displayed
may be slightly different to the actual temperature inside
the oven.
Hotplate controls
You can use the four hotplate controls to control the
heat output provided by each hotplate.
When you switch on a hotplate, the indicator lamp lights
up.
Cooking compartment
Various functions in the cooking compartment make
your appliance easier to use. For example, the cooking
compartment is well lit and a cooling fan prevents the
appliance from overheating.
Opening the appliance door
If you open the appliance door when the appliance is in
operation, the appliance will continue to operate as
before.
Interior lighting
With most heating functions and other functions, the
interior lighting in the cooking compartment will remain
lit while the oven is in operation. When the function
selector is turned to bring operation to an end, the
lighting will go out.
Cooling fan
The cooling fan switches on and off as required. The
hot air escapes above the door.
Caution!
Do not cover the ventilation slots. Otherwise, the
appliance may overheat.
So that the cooking compartment cools down more
quickly after operation, the cooling fan continues to run
for a certain period afterwards.
Position Meaning
Ú"Off" position The appliance is not heating.
50-275 Temperature range The temperature that can be set
in the cooking compartment in °C.
1, 2, 3
or
I, II, III
Grill settings The configurable settings for the
grill, large area (and small
area *(depending on the appli-
ance model).
Setting 1 = low
Setting 2 = medium
Setting 3 = high
Setting Meaning
ýOff position The hotplate is switched off.
1-9 Heat settings 1 = lowest output
9 = highest output
ðActivation Switches on the large dual-circuit hot-
plate

Accessories en
13
_Accessories
Accessor i es Your appliance is accompanied by a range of
accessories. Here, you can find an overview of the
accessories included and information on how to use
them correctly.
Accessories included
Your appliance is equipped with the following
accessories:
--------
Only use genuine accessories. They are specially
adapted for your appliance.
You can buy accessories from the after-sales service,
from specialist retailers or online.
Note: The accessories may become deformed when
they become hot. This does not affect their function.
Once they cool down again, they regain their original
shape.
Inserting accessories
The cooking compartment has five shelf positions. The
shelf positions are counted from the bottom up.
In some appliances, the highest shelf position is
marked on the cooking compartment by the grill
symbol.
Always insert accessories between the two guide rods
for the shelf position.
Accessories can be pulled out approximately halfway
without tipping.
When sliding accessories into the cooking
compartment, ensure that the kink in the side rail is at
the back. Only then will they lock in place.
Notes
■Hold the baking tray securely at the sides with both
hands and slide it into the shelf supports, keeping it
parallel. Do not move the baking tray from side to
side as you slide it in, otherwise it will not go in easily
and the enamelled surfaces may be damaged.
■Make sure that you always insert the accessories
into the cooking compartment the right way round.
■Always insert the accessories fully into the cooking
compartment so that they do not touch the appliance
door.
■Take any accessories that you will not be using out
of the cooking compartment.
Optional accessories
You can buy optional accessories from our after-sales
service, from specialist retailers or online. You will find a
comprehensive range of products for your appliance in
our brochures and online.
Their availability and whether it is possible to order
them online varies from country to country. See your
sales brochures for more details.
Note: Not all optional accessories are suitable for every
appliance. When purchasing, always quote the exact
product number (E no.) of your appliance.
~"Customer service" on page 26
Wire rack
For ovenware, cake tins and ovenproof
dishes.
For roasts, grilled items and frozen
meals.
Universal pan
For moist cakes, pastries, frozen meals
and large roasts.
It can be used to catch dripping fat when
you are grilling directly on the wire rack.
Baking tray
For tray bakes and small baked prod-
ucts.





Optional accessories
Wire rack
For cookware, cake tins and ovenproof dishes, and for roasts and
grilled food.
Baking tray
For tray bakes and small baked items.
Universal pan
For moist cakes, baked items, frozen food and large roasts.
It can be used to catch dripping fat when you are grilling directly on
the wire rack.
Wire insert
For meat, poultry and fish.
For inserting into the universal pan to catch dripping fat and meat
juices.
Professional pan
For preparing large quantities of food. Also ideal for moussaka, for
example.

en Before using for the first time
14
--------
KBefore using for the first
time
Be f o r e usi ng for the first time Before you can use your new appliance, you must
make some settings. You must also clean the cooking
compartment and accessories.
Initial use
The time will appear on the display once the appliance
is connected to the power supply. Set the current time.
Setting the time
Make sure that the function selector is set to the "Off"
position.
The time starts at "12:00".
1. Use the Aor @button to set the time.
2. Touch the vbutton to confirm.
The current time will be shown on the display.
Cleaning the cooking compartment and
accessories
Before using the appliance to prepare food for the first
time, you must clean the cooking compartment and
accessories.
Cleaning the cooking compartment
To eliminate the new-appliance smell, heat up the
cooking compartment when it is empty and with the
oven door closed.
Make sure that there is no leftover packaging, such as
polystyrene pellets, in the cooking compartment and
remove the adhesive tape that is in or on the appliance.
Before heating the appliance, wipe the smooth surfaces
in the cooking compartment with a soft, damp cloth.
Keep the kitchen ventilated while the appliance is
heating.
Apply the settings indicated below. You can find out
how to set the heating function and the temperature in
the next section. ~"Operating the appliance"
on page 16
Switch off the appliance after the time indicated.
Once the cooking compartment has cooled down,
clean the smooth surfaces with soapy water and a dish
cloth.
Cleaning the accessories
Clean the accessories thoroughly using soapy water
and a dish cloth or soft brush.
Lid for the professional pan
The lid turns the professional pan into a professional roasting dish.
Pizza tray
For pizzas and large round cakes.
Grill tray
Use for grilling in place of the wire rack or as a splatter guard. Use in
the universal pan only.
Baking stone
For home-made bread, bread rolls and pizzas that you wish to have a
crispy base.
The baking stone must be preheated to the recommended tempera-
ture.
Glass roasting dish
For stews and bakes.
Glass pan
For bakes, vegetable dishes and baked items.
Pull-out system, one level
Fitting pull-out rails at position 2 will allow you to pull accessories out
further without them tipping.
Pull-out system, two levels
Fitting pull-out rails at positions 2 and 3 will allow you to pull accesso-
ries out further without them tipping.
Pull-out system, three levels
Fitting pull-out rails at positions 1, 2 and 3 will allow you to pull acces-
sories out further without them tipping.
Settings
Heating function 3D Hotair :
Temperature maximum
Time 1 hour

Setting the cooking time en
15
1Setting the cooking time
Setti ng the cooki ng ti me This chapter explains how to set a hotplate. The table
shows heat settings and cooking times for various
meals.
Setting procedure
Adjust the heat setting of the individual hotplates using
the hotplate controls.
Position 0 = off
Position 1 = lowest heat setting
Position 9 = highest heat setting
When you switch on a hotplate, the indicator lamp lights
up.
Large dual-circuit hotplate
You can change the size of this hotplate.
Switching on the large area
Turn the hotplate control to position 9 - where you will
feel a slight resistance - then continue turning to the
ðsymbol = large dual-circuit hotplate
Then immediately turn it back to the desired heat
setting.
Switching back to the small area
Turn the hotplate control to 0 and make new settings.
The small dual-circuit hotplate is particularly good for
heating small amounts.
Caution!
Never turn the hotplate control beyond the ðsymbol to
0.
Table of cooking times
The following table provides some examples.
Cooking times and heat settings may vary depending
on the type of food, its weight and quality. Deviations
are therefore possible.
When heating thick liquids, stir regularly.
For bringing liquids to the boil, use heat setting 9.
Ongoing cooking
setting
Ongoing cooking
time in minutes
Melting
Chocolate, cooking chocolate, gelatine
Butter
1
1-2
-
-
Heating and keeping warm
Stew (e.g. lentil stew)
Milk**
1-2
1-2
-
-
Poaching, simmering
Dumplings
Fish
White sauces, e.g. béchamel sauce
4*
3*
1
20-30 mins
10-15 mins
3-6 mins
Boiling, steaming, stewing
Rice (with double the quantity of water)
Unpeeled boiled potatoes
Boiled potatoes
Pasta, noodles
Stew, soups
Vegetables
Vegetables, frozen
Cooking in a pressure cooker
3
3-4
3-4
5*
3-4
3-4
3-4
3-4
15-30 mins
25-30 mins
15-25 mins
6-10 mins
15-60 mins
10-20 mins
10-20 mins
-
* Continue cooking without a lid
** Without lid

en Operating the appliance
16
1Operating the appliance
Oper at i ng the appl i ance You have already learnt about the controls and how
they work. Now we will explain how to apply settings on
your appliance.
Switching the appliance on and off
Use the function selector to switch the appliance on or
off. Turning the function selector to any position other
than the "Off" position switches on the appliance. To
switch off the appliance, always turn the function
selector to the "Off" position.
Setting the heating function and temperature
The function selector and temperature selector make it
very easy to apply the settings you require to your
appliance. To find out which heating function is best for
which type of food, please refer to the beginning of the
instruction manual. ~"Getting to know your
appliance" on page 10
Example in the picture: Top/bottom heating %at
190 °C.
1. Use the function selector to set the heating function.
2. Use the temperature selector to set the temperature
or grill setting.
The appliance will start heating after a few seconds.
Once your food is cooked, turn the function selector to
the "Off" position to switch the appliance off.
Note: You can set both a cooking time and an end time
on the appliance. ~"Time-setting options" on page 17
Changing
The heating function and temperature can be changed
at any time using the relevant selector.
Braising
Roulades
Pot roasts
Goulash
3-4
3-4
3-4
50-60 mins
60-100 mins
50-60 mins
Frying**
Escalope, plain or breaded
Escalope, frozen
Steak (3 cm thick)
Fish and fish fillet, plain
Fish and fish fillet, breaded
Fish and fish fillet, breaded and frozen, e.g. fish fingers
Stir fry, frozen
Pancakes
6-7
6-7
7-8
4-5
4-5
6-7
6-7
5-6
6-10 mins
8-12 mins
8-12 mins
8-20 mins
8-20 mins
8-12 mins
6-10 mins
continuous
Ongoing cooking
setting
Ongoing cooking
time in minutes
* Continue cooking without a lid
** Without lid

&

Time-setting options en
17
Rapid heating
With Rapid heating, you can shorten the heat-up time.
Then, for best results, use:
■<3D hot air
■%Top/bottom heating
Only use Rapid heating when a temperature of over
100 °C has been selected.
To achieve an even cooking result, do not place your
food into the cooking compartment until Rapid heating
is complete.
1. Set the function selector to F.
2. Use the temperature selector to set the temperature.
The oven will start heating after a few seconds.
Once Rapid heating is complete, an audible signal will
sound. Place your food in the cooking compartment.
OTime-setting options
Ti me- s et t i ng opt i ons Your appliance has different time-setting options.
Before you can call up the cooking time using the
vbutton, you will need to set a heating function. Once
you have set a cooking time, the end time can be called
up.
An audible signal will sound once the cooking time or
timer duration has elapsed. You can cancel the audible
signal early by touching the vbutton.
Setting the cooking time
You can set the cooking time for your food on the
appliance. This prevents the food from accidentally
being cooked for too long, and means that you do not
have to stop what you are doing to switch off the oven.
The maximum time that can be set is 23 hours and 59
minutes. The cooking time can be set in 1-minute
increments up to one hour, and then in 5-minute
increments.
The cooking time will start at a different default value
depending on which button you touch first:
10 minutes if you touch the Abutton and 30 minutes if
you touch the @button.
Example in the picture: Cooking time of 45 minutes.
Details in the diagram may differ from what you see on
your appliance.
1. Set the type of heating and temperature or setting.
2. Touch the vbutton twice.
The cooking time xwill be highlighted on the
display.
Time-setting option Use
xCooking time Once the set cooking time has elapsed, the
appliance will automatically stop heating.
yEnd time Enter a cooking time and the required end
time. The appliance will start up automatically
so that it finishes cooking at the required time.
QTimer The timer functions like an egg timer. It runs
independently of the appliance when it is
heating and does not affect the appliance.
vTime When no other function is running in the fore-
ground, the appliance will show you the time
of day on the display.
[

en Time-setting options
18
3. Use the Aor @button to set the cooking time.
The appliance will start heating after a few seconds. The
remaining time will count down on the display.
The cooking time has elapsed
An audible signal will sound. The appliance will stop
heating. The cooking time will be zero on the display.
Once the signal stops, you can touch the @button to
set a new cooking time.
Once your food is cooked, turn the function selector to
the "Off" position to switch the appliance off.
Changing and cancelling
You can use the Aor @button to change the cooking
time at any time.After a few seconds, the change will be
applied.
To cancel, use the Abutton to reset the cooking time all
the way to zero. The appliance will continue heating
without a cooking time.
Setting the end time
You can delay the time at which cooking is due to
finish. You can, for example, put your food in the
cooking compartment in the morning and set the
cooking time so that it is ready at lunch time.
Notes
■Make sure that food is not left in the cooking
compartment for too long as it may spoil.
■Do not adjust the end time once the appliance is
already in operation. Otherwise the cooking result
may no longer be satisfactory.
■The end time cannot be set for types of heating with
grill function.
The end of the cooking time can be delayed by up to
23 hours and 59 minutes.
Example in the picture: The time is 10.30 a.m., a
cooking time of 45 minutes has been set and you want
the food to be ready at 12.30 p.m.
1. Set the type of heating and temperature or setting.
2. Touch the vbutton twice and use the Aor @button
to set the cooking time.
3. Touch the vbutton again.
The end time ywill be highlighted on the display.
4. Use the @or Abutton to delay the end time.
The appliance will apply the settings after a few
seconds. The end time will be shown on the display.
Once the appliance starts, the time will begin counting
down.
The cooking time has elapsed
An audible signal will sound. The appliance will stop
heating. The cooking time will be zero on the display.
Once the signal stops, you can touch the @button to
set a new cooking time.
Once your food is cooked, turn the function selector to
the "Off" position to switch the appliance off.
Changing and cancelling
You can use the Aor @button to change the end time.
After a few seconds, the change will be applied. The
end time cannot be changed once the cooking time has
already started to count down. Otherwise the cooking
result would no longer be satisfactory.
To cancel, use the Abutton to set the end time all the
way back to the current time plus the cooking time. The
appliance will start to heat and the cooking time will
start to count down.
Setting the timer
You can use the timer whether or not the appliance
itself is in use. However, it is not possible to set a
cooking time or end time.
The maximum time that can be set is 23 hours and 59
minutes. Up to 10 minutes, the timer duration can be
set in 30-second increments. Above 10 minutes, the
time increments become longer the higher the value.
The timer duration will start at a different default value,
depending on which button you touch first:
5 minutes if you touch the Abutton and 10 minutes if
you touch the @button.

Childproof lock en
19
1. Touch the vbutton until the timer symbol Qis
highlighted.
2. Use the Aor @button to set the timer duration.
After a few seconds, the timer duration will start to
count down.
Tip: If the set timer duration is the duration for which
you wish to cook your food, use the cooking time. The
appliance will then switch off automatically when it has
finished cooking.
The timer duration has elapsed
An audible signal will sound. The timer duration will be
zero on the display.
Touch any button to switch off the timer.
Changing and cancelling
You can use the Aor @button to change the timer
duration at any time. After a few seconds, the change
will be applied.
To cancel, use the Abutton to reset the timer duration
all the way to zero. The timer is now switched off.
Setting the time
Once the appliance has been connected to the mains
or following a power failure, the clock will flash on the
display. Set the time.
The function selector must be set to the "Off" position.
1. Use the Aor @button to set the time.
The time will stop flashing.
2. Confirm by pressing the vbutton.
The appliance will apply the time you have set.
Changing the time
You can change the time again when you need to, e.g.
from summer to winter time.
To do this, when the appliance is switched off, touch the
vbutton until the time flashes, and use the Aor
@button to change the time.
AChildproof lock
Ch i l d p r o o f lock Your appliance is equipped with a childproof lock so
that children cannot switch it on accidentally or change
any settings.
Notes
■If a hob is connected, it will not be affected by the
childproof lock on the oven.
■After a power cut, the childproof lock will no longer
be active.
Activating and deactivating
To activate the childproof lock, the function selector
must be set to the "Off" position.
Press and hold the Dbutton for approx. 4 seconds.
†‘”“ appears in the display. This activates the
childproof lock.
Note: If a timer duration Qhas been set, this will
continue to count down. While the childproof lock is
active, the timer duration cannot be changed.
To deactivate the childproof lock, press and hold the
Dbutton again for approx. 4 seconds until †‘”“
goes out on the display.

en Cleaning
20
DCleaning
Cl eani ng With good care and cleaning, your appliance will retain
its appearance and remain fully functioning for a long
time to come. We will explain here how you should
correctly care for and clean your appliance.
Cleaning agents
Damage to the various different surfaces caused by
using the wrong cleaning agent can be avoided by
observing the following instructions.
When cleaning the hob do not use
■undiluted washing-up liquid or dishwasher detergent,
■scouring pads,
■abrasive cleaning agents such as oven cleaner or
stain remover,
■high-pressure cleaners or steam jets.
■Do not clean individual parts in the dishwasher.
When cleaning the oven do not use
■sharp or abrasive cleaning agents,
■cleaning agent with a high alcohol content,
■scouring pads,
■high-pressure cleaners or steam jets.
■Do not clean individual parts in the dishwasher.
Wash new sponges thoroughly before first use.
:Warning – Risk of burns!
The appliance becomes very hot. Never touch the
interior surfaces of the cooking compartment or the
heating elements. Always allow the appliance to cool
down. Keep children at a safe distance.
Zone Cleaning agent
Stainless steel sur-
faces*
(depending on appli-
ance model)
Hot soapy water:
Clean with a dish cloth and dry with a soft
cloth. On stainless steel surfaces, always wipe
parallel to the natural grain. Otherwise, you
may scratch the surface. Remove patches and
splashes of limescale, grease, starch and albu-
min (e.g. egg white) immediately. Corrosion
can form under such patches and splashes.
Special care products suitable for hot stainless
steel surfaces are available from our after-
sales service and from specialist retailers.
Apply a thin layer of care product with a soft
cloth.
Enamel, painted, plas-
tic and screen-printed
surfaces*
(depending on appli-
ance model)
Hot soapy water:
Clean with a dish cloth and dry with a soft
cloth. Do not use glass cleaner or glass scrap-
ers for cleaning.
Control panel Hot soapy water:
Clean with a dish cloth and dry with a soft
cloth. Do not use glass cleaner or glass scrap-
ers for cleaning.
* Optional (available for some appliances, depending on the appliance
model)
Upper glass cover*
(depending on appli-
ance model)
Glass cleaner:
Clean with a soft cloth.
You can remove the upper glass cover for
cleaning. To find out how to do this, please
refer to the section Upper glass cover.
Rotary knobs
Do not remove.
Hot soapy water:
Clean with a dish cloth and dry with a soft
cloth.
Hob surround Hot soapy water:
Do not clean with a glass scraper, lemon juice
or vinegar.
Gas hob and pan sup-
ports*
(depending on appli-
ance model)
Hot soapy water.
Use very little water. Water must not be
allowed to enter the appliance through the
base of the burners.
Clean off boiled-over liquids and spilt food
immediately.
You can remove the pan supports.
Cast iron pan supports*:
Do not clean in the dishwasher.
Gas burners*
(depending on appli-
ance model)
Remove the burner head and cap and clean
with hot soapy water.
Do not clean in the dishwasher.
The gas outlet openings must remain unob-
structed at all times.
Ignition plugs: Small, soft brush.
The gas burners only work properly when the
ignition plugs are dry. Dry all parts thoroughly.
Ensure that they are refitted correctly.
The burner caps are coated in black enamel.
The colour may change over time. This does
not impair their performance.
Electric hotplate*
(depending on appli-
ance model)
Abrasive materials or sponges:
Briefly heat up the hotplate afterwards, so that
it dries. Hotplates can rust over time if they
remain wet. Apply care product to finish.
Clean off boiled-over liquids and spilt food
immediately.
Hotplate ring*
(depending on appli-
ance model)
Remove yellow to blue iridescent discoloura-
tion from the hotplate ring with a steel care
product.
Do not use any abrasive materials that may
scratch surfaces.
Ceramic hob*
(depending on appli-
ance model)
Care: Protective/care products for ceramics
Cleaning: Cleaning agents suitable for ceram-
ics.
Follow the cleaning instructions on the packag-
ing.
:Glass scraper for stubborn dirt:
Remove the protective cover and clean using
the blade only. Caution: The blade is very
sharp. Risk of injury.
Cover the blade again after cleaning. Replace
damaged blades immediately.
Zone Cleaning agent
* Optional (available for some appliances, depending on the appliance
model)
