Bosch Programme Table User manual

1 2 3 4 5 6
Emptying condensation
Empty container after each d rying operation!
1. Pull out condensation container keeping it h orizontal.
2. Pour out condensation.
3. Always push container in fully unti l it clicks into place.
If Container flashes in the display panel aWhat to do if..., Page 10.
Cleaning the fluff filter
Clean the fluff filter after each dry ing operation.
1. Open the door, remove fluff from door/door area.
2. Pull out and fold open the fluff filter.
3. Remove the fluff (by wiping the filter with your hand).
If the fluff filter is very dirty or blocked, rinse with wa rm water and dry
thoroughly.
4. Close and reinsert the fluff filter.
Switching off the dryer
Turn the programme selector to Off.
Do not leave laundry in the dryer.
Removing the laundry
The automatic anti-crease functio n causes the drum to m ove at specific intervals, th e washing remains
loose and fluffy for an hour (two hou rs if the additional Reduced Ironing function is also selected-
depending on model).
... and adapt to individual requirements
Never start the dryer if it is damaged!
Inform your after-sales service . Inspecting the
dryer
Sorting and loading laundry
Remove all items from pockets.
Check for cigarette light ers.
The drum must be em pty prior to loading.
See programme overview on page 7.
See also separate inst ructions for “Woollens basket ”
(depending on model)
Your new dryer
Congratulations - You have ch osen a modern, high-quality Bosch
domestic appliance.
The condensation dryer is distinguished by its eco nomical energy
consumption.
Every dryer which leaves our factory is carefully checked to ensure
that it functions correctly and is in perfect condition .
Should you have any questions, our after-sales service will be ple ased
to help.
Disposal in an environmentally-respons ible manner
Dispose of packaging in an environmentally-responsible m anner.
This appliance is labelled i n accordance with the European
guideline 2002/96/EG on waste electrical and ele ctronic
equipment - WEEE.
The guideline provides an EU-wide fram ework for the return and
recycling of old appliances.
For further information about our p roducts, accessories, spare parts
and services, please visit: www.bosch-home.com
Intended use Preparing for installation, see Page 8
Selecting and adjusting the programme
Drying
Condensation container
Control panel
ʋfor domestic use only,
ʋonly to be used for drying fabrics that have been
washed with water.
Do not leave children unsup ervised near the dryer.
Keep pets away from the dryer.
Select the drying programme ...
Press the Start/Stop button
1
2
3
Make sure your hands are dry.
Hold the plug only. Connecting the
mains plug
Drying
Information on laundry ...
Labelling of fabrics
Follow the manufacturer's care infor mation.
(Drying at normal temp erature.
'cDrying at low temperatu re aalso select &Low Heat .
)cDo not machine dry.
Observe safety instructions without f ail aPage 11!
Do not tumble-dry the follow ing fabrics for example:
– Impermeable fabrics (e.g. rubber-coate d fabrics).
– Delicate materials (silk or curtains m ade from synthetic materia l) athey may crease
– Laundry c ontaminated with oil.
Drying tips
– To ensure a con sistent result, sort the laundry by f abric type and drying programme.
– Always dry very small items (e .g. baby socks) together with large items of laundry (e.g. hand
towel).
– Close zips, hooks an d eyelets, and button up covers.
Tie fabric belts, apron strings, etc. toge ther
– Do not ove r-dry easy-care laundry arisk of crea sing!
Allow laundry to finish drying in th e air.
– Do not dry woolens in the dryer, onl y use to freshen them up aPage 7, Woollens finish
Programme (depending on m odel).
– Do not iron laundry immediately after drying, fold items up and leave for a while athe
remaining moisture will t hen be distributed evenly.
– Machi ne-knitted fabrics (e.g. T-shirts or jerseys) often shrink the fir st time they are dried a
do not use the Very Dry programm e.
– Starched laundry is not always suitable for dryers astarch leaves behind a c oating that
adversely affects the drying operation.
– Use the correc t dosage of fabric softener as per the m anufacturer's instructions when
washing the laundry to b e dried.
– Use the tim er programme for small loads athis i mproves the drying result.
Environmental protection/energy-saving tips
– Before drying, spin the laundry thoroughly in the was hing machine athe higher the spin
speed the shorter the drying time wi ll be (consumes less energy), also sp in easy-care
laundry.
– Put in, but do not exceed, th e maximum recommended quantity of laundry a
programme overview aPage 7.
– Make sure the room is well ventilated during drying.
– Do not obstruct or seal up the air inlet.
– Keep the air cooler clean apage 6 “Care a nd cleaning”.
Drum
All buttons are sensitive an d only
need to be touched lightly.
Only operate the dryer with
the fluff filter inserted!
Air inlet
Fluff filter
Drum interior light
(depending on model)
Maintenance
flap
Care and cleaning
Dryer housing, control panel, air cooler, moisture senso rs
– Wipe with a soft, damp cloth.
– Do not use h arsh cleaning agents and solvents.
– Remove detergent and cleaning age nt residue immediately.
Clean the air cooler 5 - 6 times a year
or if Filter flashes afte r cleaning the fluff filt er.
Air cooler
– Allow the dryer to co ol.
– Residual wate r may leak out, so p lace an absorbent towel
underneath the maintenance d oor.
1. Unlock the maintena nce door.
2. Open the maintena nce door fully.
3. Turn both locking levers towards each ano ther.
4. Pull out the air coole r.
Do not damage the air cooler.
Clean with warm water only. Do not use any hard or sharp-edged
objects.
5. Clean the air cooler thoroughl y,
Allow to drip dry.
6. Clean the seals.
7. Re-insert the air coo ler,
with the handle facing down.
8. Turn back both loc king levers.
9. Close the mainten ance door until the lock c licks into place.
Moisture sensors
The dryer is fitted w ith stainless steel moi sture sensors. The sensor s
measure the level of moisture in the laundry. After a long p eriod of
operation, a fine layer of limescale m ay form on the sensors.
1. Open the door and clean the m oisture sensors with a damp spon ge
which has a rough surface.
Do not use steel wool or abrasive materials.
Programme end on ce lights up in th e display.
Interrupt programme removing or adding laundry.
The drying cycle can be inte rrupted for a brief period so t hat laundry may be added or r emoved.
The programme selected must then be resumed and completed.
Never switch the dryer off before the drying process has ended.
Drum and door may b e hot!
1. Open door, the drying process is interrupted.
2. Load or remove laundry and close door.
3. If required, select a ne w programme and additional functions.
4. Press the Start/Stop button.
Contents Page
ʋPreparation . . . . . . . . . . . . . . . . . . . . . . 2
ʋSetting the programmes . . . . . . . . . . . . . 2
ʋDrying . . . . . . . . . . . . . . . . . . . . . . . . 3/4
ʋInformation on laundry . . . . . . . . . . . . . . 5
ʋCare and cleaning . . . . . . . . . . . . . . . . . 6
ʋProgramme overview . . . . . . . . . . . . . . . .7
ʋInstallation . . . . . . . . . . . . . . . . . . . . . . . . 8
ʋFrost protection / Transport . . . . . . . . . . . 8
ʋTechnical data . . . . . . . . . . . . . . . . . . . . 9
ʋOptional accessories . . . . . . . . . . . . . . . . 9
ʋWhat to do if... / After-sales servic e . . . . 10
ʋSafety instructions . . . . . . . . . . . . . . . . 11
Additional
functions
Programme selectorTime
remaining
Display panel
Service displays
Container
Filter Empty the condensation con tainer.
Clean the fluff filter and/or air cooler apage 4/6.
ˎh:min
End of programme in 1*-24 hours (Press button several times if required) (*depending on the selected programme, e. g. duration 1:54h a2 h. Can always be selected to the
next full hour.)
ʋ&Buzzer Select On/Off for a acoustic signal at end of programme.
ˎ&Low Heat Reduced temperature for delica te fabrics 'that require a longer drying time; e.g. for polyacryli cs, polyamide, elastane or acetate.
ˎcReduced
Ironing
Reduces creasing and extends the anti-creasing p hase once the program has ended.
Only when switched off!
Read these instructions b efore operating the dryer.
Observe the safety instructions on page 11.

7
Programme overview also see Page 5
After drying: laundry is to be ...
T-shirt
Shirts
Trousers
Skirts/dresses
Sportswear
Work clothing
Anoraks
Towelling
dressing gowns
Underwear
Socks
Bed linen
Table linen
Terry towels
Tea towels/
towels
c
ironed

lightly ironed dry
@c
not ironed
c
passed through a mangle
LFCottons max. 8 kg Forw hites and coloureds/cotton or linen.
Iron Dry ø@ è*è*è*è*è*è*è*è*
Cupboard Dry @è*è*è*è*è* Very Dry @*è*è*è*è*è*Easy-Care max. 3.5 kg For non-iron laundry made of synthetic f ibres and blended fabric, cotton.
Iron Dry cø@c è*è*è*è*è*è*
Cupboard Dry @è*è* Very Dry @è*è*è*/MIxed Load max. 3 kg For mixed items of laundry made of co tton ande asy-care fabrics.
Cupboard Dry
ZSportswear max. 1.5 kg For fabrics with membrane c oating, water-repellent fabrics, functional clothing, fleece fa brics (dry jackets/trousers with
removable internal lining separately).
Woollens finish max. 3 kg For woollen fabrics suitable fo r machine-washing. Fabrics become fluffier but not dry.
Remove fabrics once the progra mme has ended and allow to dry.
SuperQuick 40’ max. 2 kg
For laundry made of synthetic fibres, co tton or blended fabrics (for example) that needs to be dried quick ly. The values may differ from the those specified depending on the type of fabric, mixture o f laundry to be dried, residual moisture in the fabric and loading capacity.
Timed Programme warm 20‘ max. 3 kg For pre-dried, multi-layer ed, sensitive fabrics made of acrylic fibres, or separate small item s of laundry.
Also for subsequent drying.
0111 / 9000617182 *617182* Robert Bosch Hausgeräte GmbH
Carl-Wery-Str. 34
81739 München/Germany
WTE84309GB
8
Installation
– Delivery specification : dryer, instructions for insta llation and use, woollens ba sket
(depending on model).
– Check dryer for transpo rt damage.
– The dryer is very heavy. Do not attempt to lift it on your own.
– Be careful to avoid sharp edges.
– Do not lift the dryer by any of the protruding parts (e.g . the door) as they may break o ff.
– Do not set up in a roo m that is susceptible to frost.
Freezing water may cause damage.
– If in doubt, have the a ppliance connected by an exper t.
Setting up the dryer
– The appliance plug must always be accessible.
– Ensure that the appliance is instal led on a clean, level
and solid surface.
– Keep the coolin g grille at the front of the dryer
unobstructed.
– Keep the area ar ound the dryer clean.
– Make the dryer level using the th readed feet
and a spirit level.
Do not remove the threaded feet under any
circumstances.
Mains conn ection see safety instru ctions a Page 11.
– Connect to an AC e arthed socket. If in doubt have the socket checked by an e xpert.
– The mains volta ge and the voltage shown on the rating plate (
a Page 9) must correspond.
– The connected load and necessary fuse p rotection are specified on th e rating plate.
Frost protection / Transport
Preparation
1. Empty the condensation container
a page 4.
2. Select any p rogramme using the programme selector.
3. Press the Start/Stop button
a condensation is pumped in to the container.
4. Wait 5 min., and then empty the condensation containe r again.
5. Turn the programme selector to Off.
1.
Take all accessory parts
out of the drum.
The drum must be em pty.
Make sure that the air
inlet remains unobstru cted
Clean and level
2.
Do not operate the d ryer if
there is a danger of frost .
Do not set up the d ryer behind a door or sliding
door as this may obstruct or pr event the dryer door
from opening. This will prevent a potentially fatal
danger to children from locki ng themselves in.
9
Technical data
ʠDimensions (DxWxH) 60 x 60 x 85 cm (height adjustable)
Weight approximately 45 kg
Max. capacity 8 kg
Condensation container 4.2 l
Connection voltage
Connected load
Fuse protection see appliance rating plate
Ambient temperature
Product number/
Production number
You can find the rating plate on the back of the d ryer.
ʠConsumption ra tes These are guide values determ ined under standard
conditions. Fluctuations up to 10% a re possible.
Spin speed in rpm
(residual moisture)
Drying time
in min.**
Energy
consumption
in kWh**
LFCottons 8 kg 13 A 13 A
Cupboard Dry* 1400 (app rox. 50 %) 105 3.74
1000 (app rox. 60 %) 122 4.49
800 (approx. 70 %) 139 5.17
Iron Dry* 1400 (approx. 50 %) 83 2.24
1000 (app rox. 60 %) 100 3.44
800 (approx. 70 %) 117 3.86
Easy-Care 3.5 kg 1000 39 1.05
Cupboard Dry* 800 (approx. 40 %) 42 1.35
600 (approx. 50 %) 51 1.65
*Test program according to DIN EN 61121.
**The values may differ from the t hose specified depending on the type of fabric, mixture of
laundry to be dried, residual moist ure in the fabric and loading capac ity.
ʠDrum interior light (depending on model) (bulb E14, 25 W)
The drum is illuminated after the doo r is opened or closed, and also after th e programme is
started. It goes out automatically. Replac ing the bulb
a Page 10.
Optional accessories (or der from the after-sales service using the o rder number)
Connection fittings for condensation outlet
The condensation is convey ed directly via a hose.
Washer-dryer stack connec tion set
The dryer can be placed o n top of a suitable washin g machine with the same width a nd depth
to save space. This connect ion set must always be used to secure the dryer to the washing
machine. With pull-out worktop: WT Z 11300.
Installation underneath the worktop
Risk of electric shock!
Instead of the appliance covering plate, you must hav e a metal cover fitted by an ex pert.
WTZ
1110
WTZ
11310
WTZ
10290
10
What to do if ...
If you cannot rectif y a fault yourself, please contact our after-sale s service. We will alwa ys find
an appropriate solution and will av oid unnecessary visit s by engineers. Trust the expertise of
the manufacturer and rest assured that the repair wi ll be carried out by trained service
technicians using origina l spare parts. The contact det ails of your local after-sales serv ice can
be found in t he enclosed after-sales service directory, or by calling one of these numbers :
–GB 0844 8928979 (Calls from a BT landline will be charged at up to 3 pence pe r minute.
A call set-up fee of up to 6 penc e may apply.)
–IE 01450 2655
When contacting the af ter-sales service, please quot e the appliance's product nu mber (E no.)
and production nu mber (FD) (see the inside of the door) .
Set the programme sele ctor to Off and remove the appliance p lug from the socket.
ʠThe Start/Stop indicator
lamp does not light up.
Mains plug plugged in?
Programme selected?
ʠThe Container and Start/
Stop indicator lights are
flashing.
Empty the condensation container.
If featured, check hose for condensation outlet.
ʠThe Filter and Start/Stop
indicator lights are fla shing.
Clean the fluff filter and/or air cooler a Page 4/6.
ʠDryer does not start. Start/Sto p button selected?
Door closed?
Programme set?
Ambient temperature greater than 5 °C?
ʠWater is running out. A lign dryer horizontally.
Clean air cooler seal.
ʠThe door opens by itself. Push the door closed until you hear it engage.
ʠThe required degree of
dryness was not achieved or
the drying time was too long .
Clean the fluff filter and/or air cooler
a Page 4/6.
Empty condensation co ntainer
a Page 4.
Check water outlet (if feature d).
Ambient temperature highe r than 35 °C
a airing.
Air inlet may be blocked
a keep unobstructed.
Was an unsuitable pro gramme selected?
a Page 7.
Has the dryer been i nstalled with sufficient space on all
sides? Ensure tha t air can circulate.
Fine layer of scale on the mois ture sensors
a Clean the
moisture sensors
a page 6.
ʠLaundry damp. Use the next drying programme up or use the timer
programme as a supple ment
a Page 7.
Warm laundry feels damper than it really is!
ʠ
The moisture content oft heroom
has increased significantly.
Make sure the room is sufficien tly ventilated.
Air inlet blocked?
a keep unobstructed.
Ensure that the air cooler has been inserted.
ʠMains failure. Remove laundry from the dryer immediately and spread out.
This allows the heat to dissipate.
ʠOne or more indicator lights for
programme status are
flashing.
Clean filter and air co oler
a Page 4/6.
Check installation con ditions
a Page 8.
Switch off, leave to cool down, swi tch on again, restart
programme.
ʠThe interior light is not working
(depending on model).
Pull out the appliance plug, r emove the cover cap in the
interior above the door (use Torx 2 0 screw driver) and
replace the bulb. Close the cover cap.
Never operate the dryer witho ut a cover cap.
11
Safety instructions
Emergency – Pull the appliance plug out of the socket immedia tely or disconnect the fuse.
ONLY use the
dryer...
– In rooms inside the h ouse.
– To dry fabrics.
The dryer must
NEVER...
– Be used for other purposes than those described above.
– Be modified in terms of its techn ology or attributes.
Dangers – The dryer must not be used by children or person s who have not been
instructed in its use.
– Do not l eave children unsuper vised near the dr yer.
– Keep pets away f rom the dryer.
– Remove all objects f rom pockets.
Make especially sure that cigarette lighters are removed as they constitute an
a explosion hazard.
– Do no t lean or sit on the door
a risk of tipping.
Installation – Secure loose cables a tripping hazard.
– Do not operate the dryer if there is a risk of frost.
Mains
connection
– Connect the dryer according to specifications to an AC e arthed socket, as
otherwise it cannot be guaranteed that the appliance is completely safe.
– The cable cross-secti on must be sufficient.
– Only use earth-leakage circuit breakers with the following symbol:
– The appliance plug a nd socket must be compatible.
– Do not u se multiple plugs/cou plings and/or extension cables.
– Do no t hold the appliance plug with wet hands
a risk of electric shock.
– Never pull the appli ance plug out of the socket by its cable .
– Do no t damage the main s lead
a risk of electric shock.
Operation – Only load the drum with laundry.
Check the contents befo re you switch the dryer on.
– Do no t use the dryer if the laundry ha s been in contact with solvents, o il, wax,
grease or paint (e.g. hair setting spr ay, nail polish remover, stain remover,
cleaning solvent, etc.)
a fire/explosion hazard.
– Dust (e.g. coal dust, flour) poses a danger: do not use the dr yer
a explosion hazard.
– Do n ot put laundry containing foamed m aterial/rubber in the dryer
a elastic
material may be destroyed and th e dryer may be damaged due to p ossible
deformation of the foamed material.
– Switch off the dryer once the programme has ended.
– Condensation is not drinking water and m ay be contaminated wit h fluff.
Defect – Do not use the dryer if it is d efective or if you suspect it is.
Repairs must only be carrie d out by the after-sales service.
– Do not use the drye r if the mains cable is defective. T o avoid danger, only
have the defective mains cabl e replaced by the after-sales service.
– Always pull the mains plug out of the socket before chan ging the bulb for the
interior light
a risk of electric shock.
Spare parts – Only use genuine spare parts and accessories for safety reasons.
Disposal – Dryer: pull out the appliance plug, then cut off the mains c able from the
appliance.
Dispose of at municipal was te disposal facility.
– Packaging: do not lea ve children alone with packing parts
a risk of suffocation.
– All materials are en vironmentally sound and can be reused. Dispose of in an
environmentally-responsible mann er.
Dryer
en Instruction manual

1 2
a... and adapt to individual requirements
Never start the dryer if it is damaged!
Inform your after-sales service. Inspecting the
Sorting and loading laundry
Remove all items from pockets.
Check for cigarette lighters.
The drum must be empty prior to loading.
See programme overview on page 7.
See also separate instructions for “Woollens basket
(depending on model)
Your new dryer
Congratulations - You have chosen a modern, high-quality Bosch
domestic appliance.
The condensation dryer is distinguished by its economical energy
consumption.
Every dryer which leaves our factory is carefully checked to ensure
that it functions correctly and is in perfect condition.
Should you have any questions, our after-sales service will be pleased
to help.
Disposal in an environmentally-responsible manner
Dispose of packaging in an environmentally-responsible manner.
This appliance is labelled in accordance with the European
guideline 2002/96/EG on waste electrical and electronic
equipment - WEEE.
The guideline provides an EU-wide framework for the return and
recycling of old appliances.
For further information about our products, accessories, spare parts
and services, please visit: www.bosch-home.com
Intended use Preparing for installation, see Page 8
Selecting and adjusting the programme
ʋfor domestic use only,
ʋonly to be used for drying fabrics that have been
washed with water.
Do not leave children unsupervised near the dryer.
Keep pets away from the dryer.
Select the drying programme ...
Press the Make sure your hands are dry.
Hold the plug only. Connecting the
mains plug ('ca&)caaaaaaaaaaaa
All buttons are sensitive and only
need to be touched lightly.
Only operate the dryer with
the fluff filter inserted! 
Contents Page
ʋPreparation . . . . . . . . . . . . . . . . . . . . . . 2
ʋSetting the programmes . . . . . . . . . . . . . 2
ʋDrying . . . . . . . . . . . . . . . . . . . . . . . . 3/4
ʋInformation on laundry . . . . . . . . . . . . . . 5
ʋCare and cleaning . . . . . . . . . . . . . . . . . 6
ʋProgramme overview . . . . . . . . . . . . . . . . 7
ʋInstallation . . . . . . . . . . . . . . . . . . . . . . . . 8
ʋFrost protection / Transport. . . . . . . . . . . 8
ʋTechnical data . . . . . . . . . . . . . . . . . . . . 9
ʋOptional accessories . . . . . . . . . . . . . . . . 9
ʋWhat to do if... / After-sales service . . . . 10
ʋSafety instructions . . . . . . . . . . . . . . . .11
Additional
functions
Programme selectorTime
remaining
Display panel
Service displays
Container
Filter Empty the condensation container.
Clean the fluff filter and/or air cooler apage 4/6.
ˎh:min
End of programme in 1*-24 hours (Press button several times if required) (*depending on the selected programme, e.g. duration 1:54h a2h. Can always be selected to the
next full hour.)
ʋ&Buzzer Select On/Off for a acoustic signal at end of programme.
ˎ&Low Heat Reduced temperature for delicate fabrics 'that require a longer drying time; e.g. for polyacrylics, polyamide, elastane or acetate.
ˎcReduced
Ironing
Reduces creasing and extends the anti-creasing phase once the program has ended.
Read these instructions before operating the dryer.
Observe the safety instructions on page 11.

3 4
Emptying condensation
Empty container after each drying operation!
1. Pull out condensation container keeping it horizontal.
2. Pour out condensation.
3. Always push container in fully until it clicks into place.
If Container flashes in the display panel aWhat to do if..., Page 10.
Cleaning the fluff filter
Clean the fluff filter after each drying operation.
1. Open the door, remove fluff from door/door area.
2. Pull out and fold open the fluff filter.
3. Remove the fluff (by wiping the filter with your hand).
If the fluff filter is very dirty or blocked, rinse with warm water and dry
thoroughly.
4. Close and reinsert the fluff filter.
Switching off the dryer
Turn the programme selector to Off.
Do not leave laundry in the dryer.
Removing the laundry
The automatic anti-crease function causes the drum to move at specific intervals, the washing remains
loose and fluffy for an hour (two hours if the additional Reduced Ironing function is also selected-
depending on model).
... and adapt to individual requirements
Inspecting the
dryer
Sorting and loading laundry
See also separate instructions for “Woollens basket”
Selecting and adjusting the programme
Drying
Condensation container
Control panel
ʋʋ
Select the drying programme ...
Press the Start/Stop button
1
2
3
Connecting the
mains plug
Drying ('ca&)caaaaaaaaaaaa
Drum
All buttons are sensitive and only
need to be touched lightly.
Only operate the dryer with
the fluff filter inserted!
Air inlet
Fluff filter
Drum interior light
(depending on model)
Maintenance
flap Programme end once lights up in the display.
Interrupt programme removing or adding laundry.
The drying cycle can be interrupted for a brief period so that laundry may be added or removed.
The programme selected must then be resumed and completed.
Never switch the dryer off before the drying process has ended.
Drum and door may be hot!
1. Open door, the drying process is interrupted.
2. Load or remove laundry and close door.
3. If required, select a new programme and additional functions.
4. Press the Start/Stop button.
ʋʋʋʋʋʋʋʋʋʋʋʋaˎa2h. Can always be selected to the
ʋ&ˎ&'rylics, polyamide, elastane or acetate.
ˎc

56
a
ʋʋ
1
2
3
Information on laundry ...
Labelling of fabrics
Follow the manufacturer's care information.
(Drying at normal temperature.
'cDrying at low temperature aalso select &Low Heat .
)cDo not machine dry.
Observe safety instructions without fail aPage 11!
Do not tumble-dry the following fabrics for example:
– Impermeable fabrics (e.g. rubber-coated fabrics).
– Delicate materials (silk or curtains made from synthetic material) athey may crease
– Laundry contaminated with oil.
Drying tips
– To ensure a consistent result, sort the laundry by fabric type and drying programme.
– Always dry very small items (e.g. baby socks) together with large items of laundry (e.g. hand
towel).
– Close zips, hooks and eyelets, and button up covers.
Tie fabric belts, apron strings, etc. together
– Do not over-dry easy-care laundry arisk of creasing!
Allow laundry to finish drying in the air.
– Do not dry woolens in the dryer, only use to freshen them up aPage 7, Woollens finish
Programme (depending on model).
– Do not iron laundry immediately after drying, fold items up and leave for a while athe
remaining moisture will then be distributed evenly.
– Machine-knitted fabrics (e.g. T-shirts or jerseys) often shrink the first time they are dried a
do not use the Very Dry programme.
– Starched laundry is not always suitable for dryers astarch leaves behind a coating that
adversely affects the drying operation.
– Use the correct dosage of fabric softener as per the manufacturer's instructions when
washing the laundry to be dried.
– Use the timer programme for small loads athis improves the drying result.
Environmental protection/energy-saving tips
– Before drying, spin the laundry thoroughly in the washing machine athe higher the spin
speed the shorter the drying time will be (consumes less energy), also spin easy-care
laundry.
– Put in, but do not exceed, the maximum recommended quantity of laundry a
programme overview aPage 7.
– Make sure the room is well ventilated during drying.
– Do not obstruct or seal up the air inlet.
– Keep the air cooler clean apage 6 “Care and cleaning”.
Care and cleaning
Dryer housing, control panel, air cooler, moisture sensors
– Wipe with a soft, damp cloth.
– Do not use harsh cleaning agents and solvents.
– Remove detergent and cleaning agent residue immediately.
Clean the air cooler 5 - 6 times a year
or if Filter flashes after cleaning the fluff filter.
Air cooler
– Allow the dryer to cool.
– Residual water may leak out, so place an absorbent towel
underneath the maintenance door.
1. Unlock the maintenance door.
2. Open the maintenance door fully.
3. Turn both locking levers towards each another.
4. Pull out the air cooler.
Do not damage the air cooler.
Clean with warm water only. Do not use any hard or sharp-edged
objects.
5. Clean the air cooler thoroughly,
Allow to drip dry.
6. Clean the seals.
7. Re-insert the air cooler,
with the handle facing down.
8. Turn back both locking levers.
9. Close the maintenance door until the lock clicks into place.
Moisture sensors
The dryer is fitted with stainless steel moisture sensors. The sensors
measure the level of moisture in the laundry. After a long period of
operation, a fine layer of limescale may form on the sensors.
1. Open the door and clean the moisture sensors with a damp sponge
which has a rough surface.
Do not use steel wool or abrasive materials.

ʋʋʋʋʋʋʋʋʋʋʋʋaˎaʋ&ˎ&'ˎc Only when switched off!

7
Programme overview also see Page 5
After drying: laundry is to be ...
T-shirt
Shirts
Trousers
Skirts/dresses
Sportswear
Work clothing
Anoraks
Towelling
dressing gowns
Underwear
Socks
Bed linen
Table linen
Terry towels
Tea towels/
towels
c
ironed

lightly ironed dry
@c
not ironed
c
passed through a mangle
LFCottons max. 8 kg For whites and coloureds/cotton or linen.
Iron Dry ø@ è*è*è*è*è*è*è*è*
Cupboard Dry @è*è*è*è*è* Very Dry @*è*è*è*è*è*Easy-Care max. 3.5 kg For non-iron laundry made of synthetic fibres and blended fabric, cotton.
Iron Dry cø@c è*è*è*è*è*è*
Cupboard Dry @è*è* Very Dry @è*è*è*/MIxed Load max. 3 kg For mixed items of laundry made of cotton and easy-care fabrics.
Cupboard Dry
ZSportswear max. 1.5 kg For fabrics with membrane coating, water-repellent fabrics, functional clothing, fleece fabrics (dry jackets/trousers with
removable internal lining separately).
Woollens finish max. 3 kg For woollen fabrics suitable for machine-washing. Fabrics become fluffier but not dry.
Remove fabrics once the programme has ended and allow to dry.
SuperQuick 40’ max. 2 kg
For laundry made of synthetic fibres, cotton or blended fabrics (for example) that needs to be dried quickly. The values may differ from the those specified depending on the type of fabric, mixture of laundry to be dried, residual moisture in the fabric and loading capacity.
Timed Programme warm 20‘ max. 3 kg For pre-dried, multi-layered, sensitive fabrics made of acrylic fibres, or separate small items of laundry.
Also for subsequent drying.
0111 / 9000617182 *617182* Robert Bosch Hausgeräte GmbH
Carl-Wery-Str. 34
81739 München/Germany
WTE84309GB
8
Installation
– Delivery specification: dryer, instructions for installation and use, woollens basket
(depending on model).
– Check dryer for transport damage.
– The dryer is very heavy. Do not attempt to lift it on your own.
– Be careful to avoid sharp edges.
– Do not lift the dryer by any of the protruding parts (e.g. the door) as they may break off.
– Do not set up in a room that is susceptible to frost.
Freezing water may cause damage.
– If in doubt, have the appliance connected by an expert.
Setting up the dryer
– The appliance plug must always be accessible.
– Ensure that the appliance is installed on a clean, level
and solid surface.
– Keep the cooling grille at the front of the dryer
unobstructed.
– Keep the area around the dryer clean.
– Make the dryer level using the threaded feet
and a spirit level.
Do not remove the threaded feet under any
circumstances.
Mains connection see safety instructions a Page 11.
– Connect to an AC earthed socket. If in doubt have the socket checked by an expert.
– The mains voltage and the voltage shown on the rating plate ( a Page 9) must correspond.
– The connected load and necessary fuse protection are specified on the rating plate.
Frost protection / Transport
Preparation
1. Empty the condensation container a page 4.
2. Select any programme using the programme selector.
3. Press the Start/Stop button a condensation is pumped into the container.
4. Wait 5 min., and then empty the condensation container again.
5. Turn the programme selector to Off.
1.
Take all accessory parts
out of the drum.
The drum must be empty.
Make sure that the air
inlet remains unobstructed
Clean and level
2.
Do not operate the dryer if
there is a danger of frost.
Do not set up the dryer behind a door or sliding
door as this may obstruct or prevent the dryer door
from opening. This will prevent a potentially fatal
danger to children from locking themselves in.
ʠʠLFʠ
a
ʠʠʠ
a
ʠʠʠʠ
aaaaaaa
ʠ
a
ʠ
a
ʠʠ
aa
ʠ
aaaaaaaaaa

c@c c
LFø@ è*è*è*è*è*è*è*è*@è*è*è*è*è*@*è*è*è*è*è*cø@c è*è*è*è*è*è*@è*è*@è*è*è*/Z
aaa
 a
1.
2.
Do not operate the dryer if
9
Technical data
ʠDimensions (DxWxH) 60 x 60 x 85 cm (height adjustable)
Weight approximately 45 kg
Max. capacity 8 kg
Condensation container 4.2 l
Connection voltage
Connected load
Fuse protection see appliance rating plate
Ambient temperature
Product number/
Production number
You can find the rating plate on the back of the dryer.
ʠConsumption rates These are guide values determined under standard
conditions. Fluctuations up to 10% are possible.
Spin speed in rpm
(residual moisture)
Drying time
in min.**
Energy
consumption
in kWh**
LFCottons 8 kg 13 A 13 A
Cupboard Dry* 1400 (approx. 50 %) 105 3.74
1000 (approx. 60 %) 122 4.49
800 (approx. 70 %) 139 5.17
Iron Dry* 1400 (approx. 50 %) 83 2.24
1000 (approx. 60 %) 100 3.44
800 (approx. 70 %) 117 3.86
Easy-Care 3.5 kg 1000 39 1.05
Cupboard Dry* 800 (approx. 40 %) 42 1.35
600 (approx. 50 %) 51 1.65
*Test program according to DIN EN 61121.
**The values may differ from the those specified depending on the type of fabric, mixture of
laundry to be dried, residual moisture in the fabric and loading capacity.
ʠDrum interior light (depending on model) (bulb E14, 25 W)
The drum is illuminated after the door is opened or closed, and also after the programme is
started. It goes out automatically. Replacing the bulb a Page 10.
Optional accessories (order from the after-sales service using the order number)
Connection fittings for condensation outlet
The condensation is conveyed directly via a hose.
Washer-dryer stack connection set
The dryer can be placed on top of a suitable washing machine with the same width and depth
to save space. This connection set must always be used to secure the dryer to the washing
machine. With pull-out worktop: WTZ 11300.
Installation underneath the worktop
Risk of electric shock!
Instead of the appliance covering plate, you must have a metal cover fitted by an expert.
WTZ
1110
WTZ
11310
WTZ
10290
10
What to do if ...
If you cannot rectify a fault yourself, please contact our after-sales service. We will always find
an appropriate solution and will avoid unnecessary visits by engineers. Trust the expertise of
the manufacturer and rest assured that the repair will be carried out by trained service
technicians using original spare parts. The contact details of your local after-sales service can
be found in the enclosed after-sales service directory, or by calling one of these numbers:
–GB 0844 8928979 (Calls from a BT landline will be charged at up to 3 pence per minute.
A call set-up fee of up to 6 pence may apply.)
–IE 01450 2655
When contacting the after-sales service, please quote the appliance's product number (E no.)
and production number (FD) (see the inside of the door).
Set the programme selector to Off and remove the appliance plug from the socket.
ʠThe Start/Stop indicator
lamp does not light up.
Mains plug plugged in?
Programme selected?
ʠThe Container and Start/
Stop indicator lights are
flashing.
Empty the condensation container.
If featured, check hose for condensation outlet.
ʠThe Filter and Start/Stop
indicator lights are flashing.
Clean the fluff filter and/or air cooler a Page 4/6.
ʠDryer does not start. Start/Stop button selected?
Door closed?
Programme set?
Ambient temperature greater than 5 °C?
ʠWater is running out. Align dryer horizontally.
Clean air cooler seal.
ʠThe door opens by itself. Push the door closed until you hear it engage.
ʠThe required degree of
dryness was not achieved or
the drying time was too long.
Clean the fluff filter and/or air cooler a Page 4/6.
Empty condensation container a Page 4.
Check water outlet (if featured).
Ambient temperature higher than 35 °C a airing.
Air inlet may be blocked a keep unobstructed.
Was an unsuitable programme selected? a Page 7.
Has the dryer been installed with sufficient space on all
sides? Ensure that air can circulate.
Fine layer of scale on the moisture sensors a Clean the
moisture sensors a page 6.
ʠLaundry damp. Use the next drying programme up or use the timer
programme as a supplement a Page 7.
Warm laundry feels damper than it really is!
ʠ
The moisture content of the room
has increased significantly.
Make sure the room is sufficiently ventilated.
Air inlet blocked? a keep unobstructed.
Ensure that the air cooler has been inserted.
ʠMains failure. Remove laundry from the dryer immediately and spread out.
This allows the heat to dissipate.
ʠOne or more indicator lights for
programme status are
flashing.
Clean filter and air cooler
a Page 4/6.
Check installation conditions
a Page 8.
Switch off, leave to cool down, switch on again, restart
programme.
ʠThe interior light is not working
(depending on model).
Pull out the appliance plug, remove the cover cap in the
interior above the door (use Torx 20 screw driver) and
replace the bulb. Close the cover cap.
Never operate the dryer without a cover cap.
aaaaaaaaaa

c@c c
LFø@ è*è*è*è*è*è*è*è*@è*è*è*è*è*@*è*è*è*è*è*cø@c è*è*è*è*è*è*@è*è*@è*è*è*/Z
aaa
 a
1.
2.
Do not operate the dryer if
ʠʠLFʠ
a
ʠʠʠ
a
ʠʠʠʠ
aaaaaaa
ʠ
a
ʠ
a
ʠʠ
aa
ʠ
11
Safety instructions
Emergency – Pull the appliance plug out of the socket immediately or disconnect the fuse.
ONLY use the
dryer...
– In rooms inside the house.
– To dry fabrics.
The dryer must
NEVER...
– Be used for other purposes than those described above.
– Be modified in terms of its technology or attributes.
Dangers – The dryer must not be used by children or persons who have not been
instructed in its use.
– Do not leave children unsupervised near the dryer.
– Keep pets away from the dryer.
– Remove all objects from pockets.
Make especially sure that cigarette lighters are removed as they constitute an
a explosion hazard.
– Do not lean or sit on the door
a risk of tipping.
Installation – Secure loose cables a tripping hazard.
– Do not operate the dryer if there is a risk of frost.
Mains
connection
– Connect the dryer according to specifications to an AC earthed socket, as
otherwise it cannot be guaranteed that the appliance is completely safe.
– The cable cross-section must be sufficient.
– Only use earth-leakage circuit breakers with the following symbol:
– The appliance plug and socket must be compatible.
– Do not use multiple plugs/couplings and/or extension cables.
– Do not hold the appliance plug with wet hands
a risk of electric shock.
– Never pull the appliance plug out of the socket by its cable.
– Do not damage the mains lead a risk of electric shock.
Operation – Only load the drum with laundry.
Check the contents before you switch the dryer on.
– Do not use the dryer if the laundry has been in contact with solvents, oil, wax,
grease or paint (e.g. hair setting spray, nail polish remover, stain remover,
cleaning solvent, etc.) a fire/explosion hazard.
– Dust (e.g. coal dust, flour) poses a danger: do not use the dryer
a explosion hazard.
– Do not put laundry containing foamed material/rubber in the dryer a elastic
material may be destroyed and the dryer may be damaged due to possible
deformation of the foamed material.
– Switch off the dryer once the programme has ended.
– Condensation is not drinking water and may be contaminated with fluff.
Defect – Do not use the dryer if it is defective or if you suspect it is.
Repairs must only be carried out by the after-sales service.
– Do not use the dryer if the mains cable is defective. To avoid danger, only
have the defective mains cable replaced by the after-sales service.
– Always pull the mains plug out of the socket before changing the bulb for the
interior light
a risk of electric shock.
Spare parts – Only use genuine spare parts and accessories for safety reasons.
Disposal – Dryer: pull out the appliance plug, then cut off the mains cable from the
appliance.
Dispose of at municipal waste disposal facility.
– Packaging: do not leave children alone with packing parts
a risk of suffocation.
– All materials are environmentally sound and can be reused. Dispose of in an
environmentally-responsible manner.
Dryer
en Instruction manual
