Bosch WQG233DMFG Operating and maintenance instructions

Clothes dryer
WQG233DMFG
[NL] User manual and
installation instructions
Translated from Dutch to English - www.onlinedoctranslator.com

NL
Refer to the Digital User's Guide for more
information.
Table of contents
1 Safety................................................ 4
1.1 General instructions .................. 4
9 Programs ................................ 24
9.1 Automatic programs ..... 24
9.2 Time programs................................ 251.2 Destination of the device
rate .................................. 4
1.3 Restriction of users ...... 4
1.4 Safe installation................................. 5
1.5 Safer use ................................... 7
10 Accessories................................ 27
11 Laundry................................... 27
11.1 Preparing the laundry.......... 27
1.6 Safe cleaning and maintenance
hold .................................. 10 12 The Ministry at its core................. 28
12.1 Switching on the device .... 28
12.2 Set program ................ 28
2 Avoiding material damage ...... 11
3 Environmental protection and saving
ring................................................. 11
12.3 Filling the drum with detergent
good .................................. 28
3.1 Disposing of the packaging .... 11
3.2 Saving energy ....................... 11
3.3 Energy Saving Mode ........ 12
12.4 Starting the program ... 28
12.5 Adding laundry .................. 28
12.6 Program cancel .................. 29
12.7 Taking out the laundry .................. 29
12.8 Switching off the device ........... 29
12.9 Fluff filter ............................. 29
4 Set up and connection .................. 12
4.1 Unpacking the device .................. 12
4.2 Scope of delivery ..................... 12 12.10 Filter system of the bottom
unit ......................... 31
4.3 Installation site
requirements ................................... 13 12.11 Condensate tank ........ 32
4.4 Adjusting the device .......... 13
4.5 Connecting the appliance
electrically................................................. 14
13 Child Lock ................................ 33
13.1 Activating child lock ........... 33
13.2 Deactivating the child lock.......... 33
5 Getting to know your device.................. 15
5.1 Device ................................... 15
5.2 Control panel..................... 16
14 Basic Settings .................. 33
15 Cleaning and maintenance .......... 34
6 Display ................................... 17
7 Buttons .................................. 20
15.1 Tips for cleaning and
maintenance................................ 34
15.2 Base unit ................................ 34
15.3 Humidity sensor ............... 37
8 Drying target ................................... 23
8.1 Changing dryness target................ 23
8.2 Adjust drying target................ 23
2

NL
16 Troubleshooting .................. 38
17 Transporting, Storing and
drain.................................. 42
17.1 Preparing the device for
transport ................................... 42
17.2 Disposal of your old
appliance ....................................... 42
18 Customer Service............................ 43
18.1 Product number (E no.) and
production number (FD) ........... 43
19 Consumption values .................. 44
20 Technical data.............. 45
3

NL Safety
1 Safety
Observe the following safety instructions.
1.1 General instructions
s Read this manual carefully.s Keep the operating instructions and
product information for future reference.
for use or for subsequent owners.
s Do not connect the device in case of transport damage.
1.2 Destination of the device
Only use the device:s to use dryer-safe and water-washed textiles
dry and refresh.
s for domestic use and in enclosed spaces within the
sly environment.
s to an altitude of 4000 m above sea level.
1.3 Restriction of users
This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and/or knowledge if they have been given
supervision or instruction concerning use of the appliance in a safe
way and understand the resulting hazards. understood. Children must
not play with the appliance.
Cleaning and user maintenance shall not be made by children
unless they are supervised.
Make sure that children up to 3 years old and pets cannot reach the
device.
4

Safety NL
1.4 Secure installation
Observe the safety regulations when installing the device.
WARNING ‒ Risk of electric shock!
Improper installations are dangerous.
▶
Only connect and use the device in accordance with the
information on the type plate.
▶
Only connect the device to a mains supply with alternating
current via a properly installed earthing socket.
▶
The protective earth system of the electrical house installation must be
installed in accordance with the electrical engineering regulations. The
installation must have a sufficiently large conductor diameter.
▶
When using an earth leakage circuit breaker, only use a type
marked with .
▶
Never power the device via an external switching device, e.g. a
time switch or remote control.
▶
Never connect the appliance to a circuit that is regularly turned
on and off by the utility.
▶
When the device is installed, the mains plug of the mains
connection cable must be freely accessible or, if free access is not
possible, an all-pole disconnecting device must be installed in the
permanently installed electrical system in accordance with the
installation instructions.
▶
When setting up the device, make sure that the power cord is
not pinched or damaged.
Damaged power cord insulation is dangerous.
▶
Never bring the connecting cable into contact with hot
appliance parts or heat sources.
▶
Never bring the power cord into contact with sharp points or
edges.
▶
Never kink, pinch or alter the power cord.
5

NL Safety
WARNING ‒ Risk of fire!
Using an extended power cord and unauthorized adapters is
dangerous.
▶
Do not use extension cords or multiple sockets.
▶
If the power cord is too short, contact customer service.
▶
Only use adapters approved by the manufacturer.
WARNING ‒ Risk of injury!
The heavy weight of the device can cause injuries when lifted.
▶
Do not lift the device alone.
If this appliance is installed incorrectly in a washer-dryer column,
the installed appliance may fall.
▶
Stack the dryer on top of a washing machine only with the dryer
manufacturer's connection kit. No other method of installation is
allowed.
▶
Do not install the appliance in a washer-dryer column if the dryer
manufacturer does not offer a suitable connection set.
▶
Do not install appliances from different manufacturers and with
different depths and widths in a washer-dryer column.
▶
Do not set up a washer-dryer column on a platform, the
devices can tilt.
WARNING ‒ Risk of suffocation!
Children can pull packing material over their head and become
entangled and suffocate.
▶
Keep packaging material away from children.
▶
Do not let children play with packaging material.
CAUTION ‒ Risk of injury!
The device may vibrate or move during operation.
▶
Set up the device on a clean, flat and solid surface.
▶
Level the appliance using the appliance feet and a spirit level.
6

Safety NL
There is a tripping hazard with incorrectly laid hoses and mains
connection cables.
▶
Lay the hoses and connection cables in such a way that they cannot
be tripped over.
If the appliance is moved by protruding parts, such as the loading
door, the parts can break off.
▶
Do not move the appliance by protruding parts.
CAUTION ‒ Risk of cutting!
Sharp edges on the device can cause cuts if touched.
▶
Do not touch the device on sharp edges.
▶
Use protective gloves when installing and transporting the
device.
1.5 Safer use
WARNING ‒ Risk of electric shock!
A damaged appliance or power cord is dangerous.
▶
Never use a damaged device.
▶
Never pull on the power cord to disconnect the device from the
power supply. Always pull the plug on the power cord.
▶
If the appliance or the mains cable is damaged, immediately
unplug the mains cable from the socket or switch off the fuse in
the fuse box.
▶
Contact customer service. → Page 43
Penetrating moisture can cause an electric shock.
▶
Only use the device in closed rooms.
▶
Never expose the device to excessive heat and humidity.
▶
Do not use a steam cleaner, pressure washer, hoses or nozzles
to clean the appliance.
7

NL Safety
WARNING ‒ Risk of health hazard!
Children can lock themselves in the appliance and endanger
their lives.
▶
Do not install the appliance behind a door that blocks or
prevents the opening of the appliance door.
▶
In the case of discarded appliances, remove the plug of the
mains cable from the socket, then cut the mains cable and
damage the lock of the appliance door so that the appliance door
no longer closes.
WARNING ‒ Risk of suffocation!
Children can inhale or swallow small parts and choke.
▶
Keep small parts away from children.
▶
Do not allow children to play with small parts.
WARNING ‒ Risk of explosion!
Coal dust or flour in the vicinity of the device can cause explosions.
▶
Keep the area around the device clean during use.
WARNING ‒ Risk of poisoning!
The condensed water from this appliance is not drinking water and may be
contaminated with fluff.
▶
Do not drink or continue to use the condensed water from the
device.
Detergents and care products can lead to poisoning if ingested.
▶
In case of accidental ingestion, seek medical advice.
▶
Keep detergents and care products out of the reach of children.
8

Safety NL
WARNING ‒ Risk of fire!
The refrigerant R290 in this appliance is environmentally friendly
but flammable and can ignite on contact with open flames or
ignition sources.
▶
Open flames and other ignition sources away from the
hold device.
WARNING ‒ Risk of explosion!
Residues in the fluff filter can ignite during drying.
▶
Clean the fluff filter regularly.
Highly flammable items, such as lighters or matches, can ignite
during drying.
▶
Before drying, remove all easily flammable objects from the
pockets of the laundry.
If unwashed laundry has come into contact with solvents, oil, wax,
wax remover, paint, grease or stain remover, it can ignite during
drying.
▶
Do not dry unwashed laundry in this appliance.
▶
Rinse the laundry thoroughly with hot water and detergent
before drying.
▶
Do not use the appliance if the laundry is previously cleaned
with industrial chemicals.
WARNING ‒ Risk of fire!
The laundry was not cooled sufficiently if drying was interrupted
prematurely and could ignite.
▶
Do not interrupt the drying program prematurely.
▶
Remove and spread out the laundry immediately if drying is
interrupted prematurely.
CAUTION ‒ Risk of injury!
The cover plate may break when climbing or clambering on the
device.
▶
Do not climb or scramble on the device.
9

NL Safety
The appliance may tip over when sitting or leaning on the open
door.
▶
Do not sit or lean on the appliance door.
▶
Do not place any objects on the appliance door.
Reaching into the rotating drum can cause injury to hands.
▶
Wait for the drum to come to a complete stop before reaching inside the
drum with your hand.
1.6 Safe cleaning and maintenance
Observe the safety instructions when cleaning and maintaining the
device.
WARNING ‒ Risk of electric shock!
Improper repairs are dangerous.
▶
Only trained specialist personnel may carry out repairs on the
device.
▶
Only original spare parts may be used to repair the device.
▶
If the power cord of this appliance is damaged, it must be
replaced by the manufacturer, its service agent or a similarly
qualified person in order to avoid a hazard. Penetrating
moisture can cause a shock.
▶
Do not use a steam cleaner, pressure washer, hoses or nozzles
to clean the appliance.
WARNING ‒ Risk of injury!
The use of non-original spare parts and non-original accessories
is dangerous.
▶
Only use original spare parts and original accessories from the
manufacturer.
WARNING ‒ Risk of poisoning!
Toxic fumes can be generated when using solvent-based cleaning
agents.
▶
Do not use solvent-based cleaning agents.
10

Avoid material damage NL
m2
avoid material damage Foam or foam rubber may deform
or melt when dried.
▶ Do not dry foam or foam rubber
laundry.
Unsuitable cleaning agents can
damage the surfaces of the device.
▶ Do not use sharp or abrasive
cleaning agents.
▶ Do not use strong alcohol-based
cleaning agents.
▶ Do not use hard scouring or
dishwashing sponges.
▶ Clean the device only with water
and a soft, damp cloth.
▶ Remove all detergent residues,
spray mist or residues immediately
upon contact with the appliance.
Material damage
avoid
mhuh
avoid material damage
use this instruction to
avoid damage and damage to the
device.
PAY ATTENTION!
Incorrect dosage of fabric softeners,
detergents, care products and
cleaning agents can affect the
functioning of the appliance.
▶ Follow the manufacturer's dosing
recommendations.
Exceeding the maximum load
quantity affects the operation of the
appliance.
▶ Observe and do not exceed the
maximum load for each
programme.
→ "Programs", Page 24
Overheating of the device can affect
the operation of the device.
▶ Keep the air inlet of the device
clear during operation.
▶ Provide adequate ventilation in
the room.
Light objects, such as hair and fluff,
can be drawn into the air inlet of the
device during operation and affect the
function of the device.
▶ Keep the environment clean while
using the device.
▶ Keep light objects away from the
device.
Operation with a missing, incomplete
or defective fluff guard (depending on
the device equipment, e.g. fluff filter,
fluff container, filter mat) can lead to
damage to the device.
▶ Do not use the appliance with a
missing, incomplete or defective
fluff guard.
m3 Environmental protection and
savings
environmental protection and savings
Environmental protection and saving
3.1 Disposal of the packaging
The packaging materials are
environmentally friendly and can be
reused.
▶ Dispose of the individual components
separately according to type.
3.2 Saving energy
If you follow these directions, your
device will use less power.
Use the device in a well-ventilated
area and keep the air inlet of the
device clear.
a A hindered air exchange
extends the program duration and
increases energy consumption.
11

NL Set up and connect
Before drying, spin the laundry in
the washing machine. O4
set up and connect
Set up and connect
a Wetter laundry extends the
program duration and increases
energy consumption.
Set up and connect
4.1 Unpacking the device
PAY ATTENTION!
Objects that remain in the drum and
that are not intended for use with the
device can lead to material and device
damage.
▶ Before use, remove all these items
and the supplied accessories from
the drum.
Observe the maximum load for the
programmes.
→ "Programs", Page 24
a Exceeding the maximum
male load quantity extends the
program duration and increases
energy consumption.
Clean the fluff filter after drying →
Page 29 .1. Completely remove packaging
material and protection from the
device.
a A contaminated fluff filter
reduces the airflow in the
appliance, extends the program
duration and increases energy
consumption.
→ "Disposal of the packaging",
Page 11 .
2. Check the device for visible
damage.
After cleaning the filters in the filter
system of the bottom unit
→ Page 31 dry well.
3. Open the appliance door.
→ "The Ministry in essence",
Page 28
a Wetter filters extend the
program duration and increase
energy consumption.
4. Remove the accessories from the
drum.
5. Close the appliance door.
3.3 Energy Saving Mode 4.2 Scope of delivery
If you do not operate the device for a
longer period of time, the device
automatically switches to energy-
saving mode. All clues disappear and
Start/Refill flashes. The energy saving
mode is exited when you operate the
device again.
After unpacking, check all parts for
transport damage and the
completeness of the delivery.
PAY ATTENTION!
Use with incomplete or defective
accessories may impair the operation
of the device or cause material
damage and damage to the device.
▶ Do not use the device with
incomplete or defective accessories.
▶ Replace the accessories before
using the device.
→ "Accessories", Page 27
12

Set up and connect NL
delivery amount
catch
Description installation site To demand
in a laundry
drying column
The device al-
borrow with the
original connection
set of the drug
ger manufacturer in
a washer-dryer
to set up a column.
This device al-
borrow a washing
machine from the-
same manufacturer
place. The
depth and width
use of this
appliance with
the measurements
of the washing machine
china match
man.
The washer-dryer column
do not place on
a platform.
Clothes dryer
Accompanying
documents
4.3 Installation site
requirements
PAY ATTENTION!
If the device is tilted more than 40°,
residual water can run out of the
device and cause material damage.
▶ Carefully tilt the device.
▶ Transport the device upright.
Freezing residual water in the device
can damage the device.
▶ Do not place and use the device in
frost-sensitive places or outdoors.
If the device is used immediately after
transport, the refrigerant in the
device may cause damage to the
device.
▶ Let the device rest for two hours
immediately after transport before
using it for the first time.
4.4 Adjusting the device
To reduce noise and vibration, level
the device.
▶ To adjust the appliance, turn the
appliance feet. Check the horizontal
adjustment of the appliance with a
spirit level.
installation site
On the floor
To demand
The device on
a clean, ef-
fen and fixed on
place surface.
The device
set
→ Page 13 .
All appliance feet must be firmly
planted on the floor.
13

NL Set up and connect
4.5 Connecting the appliance
electrically
1. Insert the mains plug of the
appliance's connecting cable into
a socket in the vicinity of the
appliance.
The connection data of the device
can be found in the technical data
→ Page 45 .
2. Check the mains plug for tightness.
14

Getting to know your device NL
YOU5 Getting to know your device
get to know your device
Getting to know your device
5.1 Device
Here you will find an overview of the components of your device.
6
5
4
3
2
1
Depending on the device type, details in the image may differ, e.g. color and
shape.
1
2
Air intake 4
5
Door
Service valve of the
bottom unit → Page 34
Condensate tank
→ Page 32
3Fluff filter →
Page 29
6Control panel
→ Page 16
15

NL Getting to know your device
5.2 Control panel
You can set all functions of your device and obtain information about the
operating status via the control panel.
2 3
1 1
4
1
2
Programs → Page 24
Program selector
→ Page 28
3
4
Display → Page 17
Buttons → Page 20
16

Display NL
d6
isplay
Display
dO
isplay
p the display shows the current
setting values, options or instruction
texts.
Example display indication
Indication
0:40 1
name Description
Program duration /
remaining time of
the program
Approximate expected program duration
or remaining time of the program.
1:25 Time program Time program is set.
→ "Time programs", page 25
8.0kg1Recommended load Maximum load for the set program in kg.
0:45 1Ready in time
Child lock
→ "Buttons", Page 22
s lights up: the child lock is activated.s
flashes: the child lock is activated
and the device was operated.
→ "Deactivate child lock", page 33
Start / Pause Start, cancel or pauses lights up: the
program is running and can
be aborted or paused.
s flashes: the program can be
started or resumed.
1 Example
17

NL Display
Indication name Description
Drying purpose iron
dry
The drying target is activated.
→ "Buttons", Page 21
Drying purpose cabinet-
dry
The drying target is activated.
→ "Buttons", Page 21
Drying purpose cabinet-
dry Plus
The drying target is activated.
→ "Buttons", Page 20
+ 1
+ 2
+ 3
Drying target set
suits
The custom drying target is activated.
→ "Buttons", Page 20
→ "Buttons", Page 21
→ "Buttons", Page 21
Anti-crease function The anti-crease function is activated.
→ "Buttons", Page 21
Gentle drying Gentle drying for sensitive textiles is
activated.
→ "Buttons", Page 22
4kg half load
amount of
Half the load quantity is activated.
→ "Buttons", Page 22
Silent drying Silent drying without beeps is activated.
→ "Buttons", Page 22
Condensate tank
server
Emptying the condensed water container
→ Page 32 .
Push in the condensed water container
→ Page 33 .
fluff filter Cleaning the fluff filter →
Page 29 .
Filter system from
the bottom unit
Cleaning the filter system of the bottom
unit → Page 31 .
hot cooling process The laundry is cooled with a rotating drum
to avoid damage to the laundry. The
process can be interrupted by opening the
door.
Remark: Do not change the program.
Program status
Program status
To dry
Drying purpose iron
dry
1 Example
18

Display NL
Indication name Description
Program statusDrying purpose cabinet-
dry
Anti wrinkle
Pause
Program end
Program status
Program status
Program statusend
1 Example
19

NL Buttons
k7
studs
Buttons
khuh
studs
Here you will find an overview of the buttons and their setting options.
Knob
Start/Refill
Choise Description
s start
s Cancel
s pause
Start program, an-
zero or pause.
3 sec. s activate
s deactivate
Activate or deactivate
the child lock.
The control panels
secure against accidental
operation.
If the childproof lock has been
activated and the appliance
has been switched off, the
childproof lock remains
activated.
→ "Child lock",
Page 33
Cupboard dry plus s Cupboard dry plus
+1
+2
+3
s With the selection Cabinet-
dry plus the drying
target is activated
spring.
Laying the drying target
determine how damp or dry
the laundry is at the end of
the programme
is.
→ "drying target",
Page 23
s With the selection +1, +2
or +3 the drying target
is adjusted.
→ "Dry target adjust-
sen", Page 23
20
