Bosch KDN43VL2E8 User manual

en Instructions for use Fridge-freezer 3
Fridge-freezer
KDN..

en Table of contents
Safety and warning information ........... 3
Information concerning disposal ......... 6
Scope of delivery ................................... 6
Installation location ................................ 7
Fitting the wall spacer ........................... 7
Aligning the appliance .......................... 7
Observe ambient temperature
and ventilation ........................................ 7
Connecting the appliance .................... 8
Getting to know your appliance .......... 9
Switching on the appliance .................. 9
Setting the temperature ...................... 10
Alarm functions .................................... 10
Usable capacity .................................... 11
Refrigerator compartment .................. 11
Freezer compartment .......................... 12
Freezing capacity ................................. 12
Freezing and storing food .................. 12
Freezing fresh food ............................. 13
Super freezing ...................................... 14
Thawing frozen food ............................ 14
Interior fittings ....................................... 14
Switching off and disconnecting
the appliance ........................................ 15
Cleaning the appliance ....................... 16
Light (LED) ............................................ 16
Tips for saving energy ........................ 17
Operating noises ................................. 17
Eliminating minor faults yourself ....... 18
Customer service ................................. 20

en
3
enTable of contents enInstructions for useFridge-freezer
Safety and warning
information
Before you switch ON the
appliance
Please read the operating and
installation instructions carefully!
They contain important
information on how to install,
use and maintain the appliance.
The manufacturer is not liable if
you fail to comply with the
instructions and warnings.
Retain all documents for
subsequent use or for the next
owner.
Technical safety
Fire hazard
The tubes of the
refrigeration circuit convey a
small quantity of an
environmentally friendly but
flammable refrigerant (R600a). It
does not damage the ozone
layer and does not increase the
greenhouse effect. If refrigerant
escapes, it may injure your eyes
or ignite.
If damage has occurred
■Keep naked flames and/or
ignition sources away from the
appliance,
■thoroughly ventilate the room
for several minutes,
■switch off the appliance and
pull out the mains plug,
■inform customer service.
The more refrigerant an
appliance contains, the larger
the room must be in which the
appliance is situated. Leaking
refrigerant can form a
flammable gas-air mixture in
rooms which are too small.
The room must be at least 1 m³
per 8 g of refrigerant. The
amount of refrigerant in your
appliance is indicated on the
rating plate inside the appliance.
When installing the appliance,
ensure that the mains cable is
not trapped or damaged.
If the power cord of this
appliance is damaged, it must
be replaced by the
manufacturer, Customer Service
or a similarly qualified person.
Improper installations and
repairs may put the user at
considerable risk.
Repairs may be performed by
the manufacturer, customer
service or a similarly qualified
person only.
Only original parts supplied by
the manufacturer may be used.
The manufacturer guarantees
that only these parts satisfy the
safety requirements.
Do not use multiple sockets,
extension leads or adapters.

en
4
Fire hazard
Portable multiple outlets or
power supplies may overheat,
causing a fire.
Never leave portable multiple
outlets or portable power
supplies behind the appliance.
Important information when
using the appliance
■Never use electrical
appliances inside the
appliance (e.g. heaters,
electric ice makers, etc.). Risk
of explosion!
■Never defrost or clean the
appliance with a steam
cleaner! The steam may
penetrate electrical parts and
cause a short-circuit. Risk of
electric shock!
■Do not use additional means
to accelerate the defrosting
process other than those
recommended by the
manufacturer. Risk of
explosion!
■Do not use pointed or sharp-
edged implements to remove
frost or layers of ice. You
might damage the refrigerant
tubes.Leaking refrigerant may
cause eye injuries or ignite.
■Do not store products which
contain flammable propellant
(e.g. spray cans) or explosive
substances in the appliance.
Risk of explosion!
■Do not stand on or lean
heavily against the base of the
appliance, drawers, doors,
etc.
■For defrosting and cleaning,
pull out the mains plug or
switch off the fuse. Do not pull
out the mains plug by tugging
on the power cord.
■Store high-percentage alcohol
tightly sealed and in an
upright position.
■Keep plastic parts and the
door seal free of oil and
grease. Otherwise, plastic
parts and the door seal will
become porous.
■Never cover or block the
ventilation openings of the
appliance.
■Do not store bottled or
canned liquids (especially
carbonated drinks) in the
freezer compartment.Bottles
and cans may burst!
■Never put frozen food straight
from the freezer compartment
in your mouth.
Risk of low-temperature burns!
■Avoid prolonged touching of
frozen food, ice or the
evaporator pipes, etc.
Risk of low-temperature burns!

en
5
■Avoiding placing children
and vulnerable people at
risk:
At risk here are children,
people who have limited
physical, mental or sensory
abilities, as well as people
who have inadequate
knowledge concerning safe
operation of the appliance.
Check that children and
vulnerable people have
understood the hazards.
A person responsible for
safety must supervise or
instruct children and
vulnerable people who are
using the appliance.
Only children aged 8 years
and above may use the
appliance.
Supervise children while the
appliance is being cleaned or
maintained.
Never allow children to play
with the appliance.
Children in the household
■Keep children away from
packaging and its parts.
Danger of suffocation from
folding cartons and plastic
film!
■Do not allow children to play
with the appliance!
■If the appliance features a
lock:
keep the key out of the reach
of children!
General regulations
The appliance is suitable
■for refrigerating and freezing
food,
■for making ice.
This appliance is intended for
use in the home and the home
environment.
The refrigeration circuit has
been checked for leaks.
This appliance complies with the
relevant safety regulations for
electrical appliances and is
fitted with noise suppression.
This appliance is intended for
use up to a maximum height of
2000 metres above sea level.

en
6
Information concerning
disposal
*Disposal of packaging
The packaging protects your appliance
from damage during transit. All utilised
materials are environmentally safe and
recyclable. Please help us by disposing
of the packaging in an environmentally
friendly manner.
Please ask your dealer or inquire at your
local authority about current means of
disposal.
*Disposal of your old
appliance
Old appliances are not worthless
rubbish! Valuable raw materials can be
reclaimed by recycling old appliances.
m Warning
Redundant appliances
1. Pull out the mains plug.
2. Cut off the power cord and discard
with the mains plug.
3. Do not take out the trays and
receptacles: children are therefore
prevented from climbing in!
4. Do not allow children to play with the
appliance once it has spent its useful
life. Danger of suffocation!
Refrigerators contain refrigerant and
gases in the insulation. Refrigerant and
gases must be disposed of
professionally. Ensure that tubing of the
refrigerant circuit is not damaged prior to
proper disposal.
Scope of delivery
After unpacking all parts, check for any
damage in transit.
If you have any complaints, please
contact the dealer from whom you
purchased the appliance or our
customer service.
The delivery consists of the following
parts:
■Free-standing appliance
■Interior fittings (depending on model)
■Bag containing installation materials
■Operating instructions
■Installation manual
■Customer service booklet
■Warranty enclosure
■Information on the energy
consumption and noises
This appliance is labelled in
accordance with European
Directive 2012/19/EU concerning
used electrical and electronic
appliances (waste electrical and
electronic equipment - WEEE).
The guideline determines the
framework for the return and
recycling of used appliances as
applicable throughout the EU.


en
7
Installation location
A dry, well ventilated room is suitable as
an installation location. The installation
location should not be exposed to direct
sunlight and not placed near a heat
source, e.g. a cooker, radiator, etc. If
installation next to a heat source is
unavoidable, use a suitable insulating
plate or observe the following minimum
distances from the heat source:
■3 cm to electric or gas cookers.
■30 cm to an oil or coal-fired cooker.
The floor of the installation location must
not give way; if required, reinforce floor. If
the floor is uneven, compensate with
supports.
Distance from wall
When installing the appliance, ensure
that the door can be opened by 90°.
Fitting the wall spacer
Fit wall spacers to obtain the indicated
energy rating of the appliance.
A reduced wall gap will not restrict the
function of the appliance. The energy
rating may then increase slightly.
Distance to the back wall
The distance of 75 mm must not be
exceeded.
Aligning the appliance
Place the appliance in the designated
location and align.The appliance must be
level and stand securely on the floor. If
the floor is uneven, use the front height-
adjustable feet. Adjust the height-
adjustable feet with a spanner.
Note
The appliance must be vertical. Please
align it with a spirit level.
Observe ambient
temperature
and ventilation
Ambient temperature
The appliance is designed for a specific
climate class. Depending on the climate
class, the appliance can be operated at
the following temperatures.
The climate class can be found on the
rating plate. Fig. )
Note
The appliance is fully functional within
the room temperature limits of the
indicated climatic class. If an appliance
of climatic class SN is operated at colder
room temperatures, the appliance
will not be damaged up to a temperature
of +5 °C.
Climate class Permitted ambient
temperature
SN +10 °C to 32 °C
N+16 °C to 32 °C
ST +16 °C to 38 °C
T+16 °C to 43 °C

en
8
Ventilation
Fig. $
The air on the rear panel and on the side
panels of the appliance heats up.
Conduction of the heated air must
not be obstructed. Otherwise,
the refrigerating unit must work harder.
This increases power consumption.
Therefore: Never cover or block
the ventilation openings!
Connecting
the appliance
After installing the appliance, wait at least
1 hour until the appliance is switched on.
During transportation the oil in
the compressor may have flowed into
the refrigeration system.
Before switching on the appliance for the
first time, clean the interior of the
appliance (see chapter “Cleaning
the appliance”).
Electrical connection
The socket must be near the appliance
and also freely accessible following
installation of the appliance.
m Warning
Risk of electric shock!
If the length of the mains cable is
inadequate, never use multiple sockets
or extension leads. Instead, please
contact Customer Service for
alternatives.
The appliance complies with protection
class I. Connect the appliance to 220–
240 V/50 Hz alternating current via a
correctly installed socket with protective
conductor. The socket must be protected
by a 10 A to 16 A fuse.
For appliances operated in non-
European countries, check whether the
indicated voltage and current type match
the values of your electricity supply. This
information can be found on the rating
plate, Fig. ).
m Warning
Never connect the appliance
to electronic energy saver plugs.
Our appliances can be used with mains
and sine-controlled inverters. Mains-
controlled inverters are used
for photovoltaic systems which
are connected directly to the national
grid. Sine-controlled inverters must be
used for isolated applications (e.g. on
ships or in mountain lodges) which are
not connected directly to the national
grid.

en
9
Getting to know your
appliance
Please fold out the illustrated last page.
These operating instructions refer
to several models.
The features of the models may vary.
The diagrams may differ.
Fig. !
* Not all models.
Controls
Fig. $
Switching on the
appliance
Fig. $
1. Insert the plug in the socket.
2. A warning signal sounds. The
temperature display 1 flashes.
3. Press the temperature setting button
3. The warning signal switches off.
When the freezer compartment has
reached the set temperature, the
temperature display 1 is lit.
The factory recommends the following
settings:
■Refrigerator compartment: medium
setting
■Freezer compartment: -18°C
Store delicate foods in the refrigerator
compartment.
A Freezer compartment
B Refrigerator compartment
1–3 Controls
4* Door shelf
5* Shelf for small bottles
6 Shelf for large bottles
7 Light (LED)
8 Fast freezer compartment
9* Ice pack
10 Condensation channel
11 Temperature controller
12* Bottle shelf
13 Shelf in the refrigerator
compartment
14 Vegetable container
15 Height-adjustable feet
1Temperature display
Indicates the set temperature of
the freezer compartment.
2Display super freezing
Illuminates when super freezing is
on.
3Temperature selection button
The required temperature is set
with this button.

en
10
Operating tips
■When the appliance has been
switched on, it may take several hours
until the set temperatures have been
reached.
■The fully automatic NoFrost system
ensures that the freezer compartment
remains free of ice. Defrosting is no
longer required.
■The sides of the housing are
sometimes heated slightly. This
prevents condensation in the area of
the door seal.
■If the freezer compartment door
cannot be immediately re-opened after
it has been closed, wait until the
resulting low pressure has equalised.
Setting
the temperature
Refrigerator compartment
Turn temperature controller, Fig. !/11,
to the required setting.
We recommend the setting in line with
the marking.
Changing the setting clockwise will lower
temperatures in the refrigerator
compartment.
At a room temperature below 16°C,
slightly increase the temperature setting
in the appliance. At a room temperature
above 32°C, slightly reduce the
temperature setting in the appliance.
Select a very cold setting only
temporarily if:
■door is opened frequently,
■large quantities of food are placed in
the refrigerator compartment.
Freezer compartment
The temperature can be set from -16 °C
to -24 °C.
Keep pressing temperature setting
button 3 until the required freezer
compartment temperature is set.
The value last selected is saved. The set
temperature is indicated on temperature
display 1.
Alarm functions
Fig. $
Door alarm
The door alarm (continuous sound)
switches on if the appliance door is open
for longer than one minute. Close
the door to switch off the warning signal.
Temperature alarm
The temperature alarm switches on if the
freezer compartment is too warm and the
frozen food is at risk of thawing.
Temperature display, Fig. $/1, is
flashing.
The alarm may switch on without any risk
to the frozen food:
■when the appliance is switched on,
■when large quantities of fresh food are
placed in the appliance,
■if the freezer compartment door is
open too long.
Note
Do not refreeze thawing or thawed food.
Only ready meals (boiled or fried) may
be refrozen.
No longer store the frozen produce for
the max. storage period.

en
11
Switching off the alarm
Fig. $
Press the temperature setting button 3 to
switch off the warning signal.
Usable capacity
Information on the usable capacity can
be found inside your appliance on
the rating plate. Fig. )
Refrigerator
compartment
The refrigerator compartment is the ideal
storage location for meat, sausage, fish,
dairy products, eggs, ready meals
and pastries.
Note when storing food
Note
Optimum cooling capacity is attained
when the upper glass shelf remains in
position.
■Store fresh, unspoilt food. This will
then preserve quality and freshness
for longer.
■With ready-made products and bottled
goods, observe the best-before or
use-by date specified by the
manufacturer.
■To preserve aroma, colour and
freshness, pack or cover food well
before placing in the appliance. This
will prevent the transfer of flavours and
the discolouration of plastic parts in
the refrigerator section.
■Allow hot food and drinks to cool
down first before placing in the
appliance.
Note
Do not block air outlet openings with
food, otherwise the air circulation will be
impaired. Food which is stored directly
in front of the air outlet openings may be
frozen by the cold air flowing out.
Note
Avoid contact between food and rear
panel. Otherwise the air circulation will
be impaired.
Food or packaging could freeze to
the rear panel.
Note the chill zones in the
refrigerator section
The air circulation in the refrigerator
section creates different chill zones:
■The coldest zone is between the
vegetable container and the glass
shelf situated above and in front of the
air outlet openings.
Note
Store perishable food (e.g. fish,
sausage, meat) in the coldest zone.
■The warmest zone is at the very top of
the door.
Note
Store e.g. hard cheese and butter in
the warmest zone. The aroma of hard
cheese can then continue to develop
and butter remains spreadable.

en
12
Vegetable container
Fig. !/14
A high air humidity keeps leafy
vegetables fresh for longer. Vegetables
and fruit should be stored at a slightly
lower air humidity.
The air humidity in the vegetable drawer
depends on the amount of stored food.
Note
If the air humidity is too high, drips may
form and cause decay.
Freezer compartment
Use the freezer compartment
■To store deep-frozen food.
■To make ice cubes.
■To freeze food.
Note
Ensure that the freezer compartment
door has been closed properly. If
the door is open, the frozen food will
thaw. The freezer compartment will
become covered in thick ice. Also: waste
of energy due to high power
consumption!
Freezing capacity
Information on the freezing capacity can
be found on the rating plate. Fig. )
Freezing and storing
food
Purchasing frozen food
■Packaging must not be damaged.
■Use by the “use by” date.
■Temperature in the supermarket
freezer must be -18 °C or lower.
■If possible, transport deep-frozen food
in an insulated bag and place quickly
in the freezer compartment.
Note when loading products
Freeze large quantities of food in the fast
freezer compartment where food freezes
particularly quickly and therefore also
gently.
Food which is already frozen must not
come into contact with the food which is
to be frozen.

en
13
Freezing fresh food
Freeze fresh and undamaged food only.
To retain the best possible nutritional
value, flavour and colour, vegetables
should be blanched before freezing.
Aubergines, peppers, zucchini and
asparagus do not require blanching.
Literature on freezing and blanching
can be found in bookshops.
Note
Keep food which is to be frozen away
from food which is already frozen.
■The following foods are suitable for
freezing:
Cakes and pastries, fish and seafood,
meat, game, poultry, vegetables, fruit,
herbs, eggs without shells, dairy
products such as cheese, butter and
quark, ready meals and leftovers such
as soups, stews, cooked meat and
fish, potato dishes, soufflés and
desserts.
■The following foods are not suitable
for freezing:
Types of vegetables, which are usually
consumed raw, such as lettuce or
radishes, eggs in shells, grapes,
whole apples, pears and peaches,
hard-boiled eggs, yoghurt, soured
milk, sour cream, crème fraîche and
mayonnaise.
Packing frozen food
To prevent food from losing its flavour
or drying out, place in airtight containers.
1. Place food in packaging.
2. Remove air.
3. Seal the wrapping.
4. Label packaging with contents
and date of freezing.
Suitable packaging:
Cling wrap, tubular film made of
polyethylene, aluminium foil, freezer
containers.
These products are available from
specialist outlets.
Unsuitable packaging:
Wrapping paper, greaseproof paper,
cellophane, bin liners and used shopping
bags.
Items suitable for sealing packaged
food:
Rubber bands, plastic clips, string, cold-
resistant adhesive tape, etc.
Bags and tubular film made of
polyethylene (PE) can be sealed with a
film heat sealer.
Shelf life of frozen food
Storage duration depends on the type
of food.
At a temperature of -18 °C:
■Fish, sausage, ready meals and cakes
and pastries:
up to 6 months
■Cheese, poultry and meat:
up to 8 months
■Vegetables and fruit:
up to 12 months

en
14
Super freezing
Food should be frozen solid as quickly
as possible in order to retain vitamins,
nutritional value, appearance and flavour.
Several hours before placing fresh food
in the freezer compartment, switch on
super freezing to prevent an unwanted
temperature rise.
As a rule, 4–6 hours is adequate.
This appliance runs constantly
and the freezer compartment drops to
a very low temperature.
If the max. freezing capacity is to be
used, super freezing must be switched
on for 24 hours before the fresh produce
is placed in the freezer compartment.
Smaller quantities of food (up to 2 kg)
can be frozen without “super freezing”.
Note
When super freezing is switched on,
increased operating noises may occur.
Switching on and off
Fig. $
Keep pressing the temperature selection
button 3 until the Super display 2 is lit.
Super freezing automatically switches off
after approx. 2½ days.
Thawing frozen food
Depending on the type and application,
select one of the following options:
■at room temperature
■in the refrigerator
■in an electric oven, with/without fan
assisted hot-air
■in the microwave
m Caution
Do not refreeze thawing or thawed food.
Only ready meals (boiled or fried) may
be refrozen.
No longer store the frozen produce for
the max. storage period.
Interior fittings
You can reposition the shelves inside
the appliance and the door shelves as
required:
■Pull shelf forwards, lower and swing
out to the side. Fig. %
■Raise the door shelf and remove. Fig.
#
Special features
(not all models)
Ice pack
The ice pack can be removed to cool
food temporarily, e.g. in a cold bag.
If a power failure or malfunction occurs,
the ice pack can be used to slow down
the thawing process.

en
15
Ice cube tray
Fig. '
1. Fill the ice cube tray ¾ full of drinking
water and place in the freezer
compartment.
2. If the ice tray is stuck to the freezer
compartment, loosen with a blunt
implement only (spoon-handle).
3. To loosen the ice cubes, twist the ice
tray slightly or hold briefly under
flowing water.
Bottle shelf
Fig. (
Bottles can be stored securely on
the bottle shelf.
Vegetable container with humidity
controller
Fig. &
To create the optimum storage climate
for fruit and vegetables, you can set the
air humidity in the vegetable container
depending on the quantity stored:
■smaller quantities of fruit and
vegetables – high air humidity
■large quantities of fruit and vegetables
– low air humidity
Notes
■Fruit sensitive to cold (e.g. pineapple,
banana, papaya and citrus fruit) and
vegetables sensitive to cold (e.g.
aubergines, cucumbers, zucchini,
peppers, tomatoes and potatoes)
should be stored outside
the refrigerator at temperatures
of approx. +8 °C to +12 °C for
optimum preservation of quality and
flavour.
■Condensation may form in the
vegetable container depending on the
type and quantity of products stored.
Remove condensation with a dry cloth
and adjust air humidity in the
vegetable container with the humidity
controller.
Switching off and
disconnecting the
appliance
Switching off the appliance
Pull out mains plug or switch off fuse.
Refrigerating unit switches off.
Disconnecting the appliance
If you do not use the appliance for
a prolonged period:
1. Pull out the mains plug or switch off
the fuse.
2. Clean the appliance.
3. Leave appliance doors open.

en
16
Cleaning the appliance
m Caution
■Never clean the appliance with large
volumes of water (e.g. from the water
hose).
Water may run into the appliance and
damage the electrical components.
■Do not use sand-, chloride- or acid-
based cleaning agents or solvents.
■Do not use scouring or abrasive
sponges.
The metallic surfaces could corrode.
■Never clean shelves or containers in
the dishwasher.
The parts may become deformed!
The cleaning water must not get into
the following areas:
■Controls
■Illumination
■Ventilation openings
■Openings in the separating plate
Proceed as follows:
1. Pull out the mains plug or switch off
the fuse.
2. Take out the frozen food and store
in a cool location. Place ice pack (if
available) on the food.
3. The rinsing water must not drip into
the controls, lighting, ventilation
openings or the openings in the
partition!
Clean the appliance with a soft cloth,
lukewarm water and a little pH-neutral
washing-up liquid.
4. Wipe the door seal with clear water
only and then wipe dry thoroughly.
5. After cleaning reconnect the
appliance.
6. Put the frozen food back into
the appliance.
Interior fittings
All variable parts of the appliance
can be taken out for cleaning.
Take out shelves in the door
Fig. #
Lift shelves upwards and take out.
Take out glass shelves
Pull the glass shelves forwards and take
out.
Light (LED)
Your appliance features a maintenance-
free LED light.
These lights may be repaired
by customer service or authorised
technicians only.

en
17
Tips for saving energy
■Install the appliance in a dry, well
ventilated room! The appliance should
not be installed in direct sunlight
or near a heat source (e.g. radiator,
cooker).
If required, use an insulating plate.
■Allow warm food and drinks to cool
down before placing in the appliance.
■Thaw frozen food in the refrigerator
compartment and use the low
temperature of the frozen food to cool
refrigerated food.
■Open the appliance as briefly as
possible.
■To achieve the lowest energy
consumption, leave a small wall gap
at the side.
■Do not remove or relocate the upper
glass shelf.
■Do not block the ventilation openings
in the appliance.
■To avoid increased power
consumption, occasionally clean the
back of the appliance.
■The ice packs slow down the thawing
process of the frozen food in the event
of a power failure or malfunction.
Place the ice packs directly on
the food in the top compartment.
Operating noises
Quite normal noises
Note
When super freezing is switched on,
increased operating noises may occur.
Droning
Motors are running (e.g. refrigerating
units, fan).
Bubbling, humming or gurgling noises
Refrigerant is flowing through the tubing.
Clicking
Motor, switches or solenoid valves are
switching on/off.
Cracking
Automatic defrosting is running.
Sizzling
The NoFrost system defrosts, water
droplets evaporate.
Preventing noises
The appliance is not level
Please align the appliance with a spirit
level. Use the height-adjustable feet
or place packing underneath them.
The appliance is not free-standing
Please move the appliance away
from adjacent units or appliances.
Containers or storage areas wobble
or stick
Please check the removable parts
and re-insert them correctly if required.
Bottles or receptacles are touching
each other
Move the bottles or receptacles slightly
away from each other.

en
18
Eliminating minor faults yourself
Before you call customer service:
Please check whether you can eliminate the fault yourself based on the following
information.
Customer service will charge you for advice – even if the appliance is still under
guarantee!
Fault Possible cause Remedial action
Temperature differs greatly
from the set value.
In some cases it is adequate to switch off
the appliance for 5 minutes.
If the temperature is too high wait a few hours
and check whether the temperature has
approached the set value.
If the temperature is too low check
the temperature again the next day.
Appliance has no
refrigeration capacity.
The light does not work.
The display does not
illuminate.
Power failure. Check whether the power is on.
The fuse has been switched
off.
Check the fuse.
The mains plug has not been
inserted properly.
Check whether the mains plug is secure.
Warning signal is emitted. Appliance is open. Close the appliance.
The temperature display
flashes.Fig. $/1
Fault - the freezer
compartment is too warm.
Frozen food is at risk.
To stop the temperature display flashing, press
temperature setting button. Press Fig. $/3.
The temperature display will also stop flashing
when the freezer section is cold enough again.
Ventilation openings are
covered up.
Ensure that there is adequate ventilation.
Too much food was placed in
the freezer at once.
Do not exceed the freezing capacity.
The temperature in the
freezer section is too warm.
Appliance opened
frequently.
Do not open the appliance unnecessarily.
The ventilation openings
have been covered.
Remove obstructions.
Large quantities of fresh
food are being frozen.
Do not exceed the freezing capacity.

en
19
Fault Possible cause Remedial action
The light does not function. The LED light is defective. See chapter “Light (LED)” section.
Appliance was open too
long.
Light is switched off after
approx. 10 min.
When the appliance is closed and opened,
the light is on again.
Controls have reduced
luminosity.
When the appliance is not
used for some time,
the display on the fascia
switches to energy saving
mode.
As soon as the appliance is again used, e.g.
the door is opened, the display switches back
to normal illumination.
Appliance is not cooling,
temperature display and light
are lit.
Showroom mode is
switched on.
Hold down temperature selection button
fig. $/3 for 10 seconds until
an acknowledgement signal sounds.
After a short time check whether your
appliance is cooling.
Freezer compartment door
was open for a long time;
temperature is no longer
reached.
The evaporator (refrigeration
generator) in the NoFrost
system is covered in thick ice
and can no longer be
defrosted fully automatically.
To defrost the evaporator, remove the frozen
food with the compartments, insulate well
and store in a cool location.
Switch off the appliance and move it away
from the wall. Leave the appliance door open.
After approx. 20 min. the condensation begins
to run into the evaporation pan,
at the rear of the appliance. Fig. *
To prevent the evaporation pan
from overflowing in this case,
mop up the condensation with a sponge.
The evaporator is defrosted when the water
stops running into the evaporation pan. Clean
the interior. Switch the appliance
back on again.
The appliance has no
refrigeration capacity.
The lighting does not work.
The display does not
illuminate.
Power failure Check whether the power is on. In the event of
a longer power failure, condensation will
collect in the condensation channel. Wipe up
the condensation water with a soft cloth.
The fuse has been switched
off.
Check mains fuse.
The mains plug has not been
inserted properly.
Check whether the mains plug is securely
inserted.

en
20
Customer service
Your local customer service can be
found in the telephone directory or in the
customer service index. Please give
customer service the product number
(E-Nr.), the production number (FD) and
the consecutive numbering (Z-Nr.) of the
appliance.
This information can be found on the
rating plate.Image )
This way you will help to prevent
unnecessary callouts and save the
associated additional costs.
Repair order and advice
on faults
Contact information for all countries can
be found on the enclosed customer
service list.
Fault Possible cause Remedial action
Condensation accumulates
on the surface of the
appliance and on the shelves
inside.
The effect is reinforced if
ambient temperatures are
warm and humid.
Wipe away the water with a soft, dry cloth.
■Open the appliance as briefly as possible
■Make sure that the appliance is always
closed properly.
GB 0344 892 8979 Calls charged at
local or mobile rate.
IE 01450 2655 0.03 € per minute
at peak. Off peak
0.0088 € per
minute.
US 800 944 2904 toll-free
