Bosch PIE6 R1 Series User manual

[en] Instruction manual
PIE6..R1..
Hob

2Ø = cm
ÚTable of contents [en]Instructionmanual
Safety precautions..................................................................... 2
Elements that may damage the appliance ....................................4
Protecting the environment ...................................................... 5
Environmentally-friendly disposal of waste products ...................5
Energy-saving advice .........................................................................5
Induction cooking...................................................................... 5
Advantages of induction cooking ....................................................5
Suitable pans.......................................................................................5
Familiarise yourself with the appliance ................................... 6
The control panel................................................................................6
The hotplates .......................................................................................7
Residual heat indicator ......................................................................7
Programming the hob................................................................ 7
Switching the hotplate on and off....................................................7
Set the hotplate ...................................................................................7
Cooking guidelines table...................................................................8
Childproof lock........................................................................... 9
Turning on and off the childproof lock. ..........................................9
Activating and deactivating the childproof lock............................9
Powerboost function ..................................................................9
Restrictions when using .................................................................... 9
To activate............................................................................................ 9
To deactivate ....................................................................................... 9
Time program function.............................................................10
How to program............................................................................... 10
Automatic time limitation.........................................................10
Basic settings ...........................................................................10
To access the basic settings......................................................... 11
Care and cleaning.....................................................................11
Hob..................................................................................................... 11
Hob frame ......................................................................................... 12
Fixing malfunctions..................................................................12
Normal noise while the appliance is working ............................ 12
After-sales service....................................................................13
Produktinfo
Additional information on products, accessories, replacement
parts and services can be found at www.bosch-home.com and
in the online shop www.bosch-eshop.com
ã=Safety precautions
Please read this manual carefully.
Please keep the instruction and
installation manual as well as the
appliance certificate in a safe place
for later use or for subsequent
owners.
Check the appliance after removing
it from the packaging. If it has
suffered any damage in transport,
do not connect the appliance,
contact the Technical Assistance
Service and provide written
notification of the damage caused,
otherwise you will lose your right to
any type of compensation.
This appliance must be installed
according to the installation
instructions included.
3,(5





3
This appliance is intended for
domestic use only. The appliance
must only be used for the
preparation of food and drink. The
appliance must be supervised
during operation. Only use this
appliance indoors.
This appliance is not intended for
operation with an external clock
timer or a remote control.
This appliance may be used by
children over the age of 8 years old
and by persons with reduced
physical, sensory or mental
capacity or by persons with a lack
of experience or knowledge if they
are supervised or are instructed by
a person responsible for their
safety how to use the appliance
safely and have understood the
associated hazards.
Children must not play with the
appliance. Children must not clean
the appliance or carry out general
maintenance unless they are at
least 8 years old and are being
supervised.
Keep children below the age of
8 years old at a safe distance from
the appliance and power cable.
Risk of fire!
■Hot oil and fat can ignite very
quickly. Never leave hot fat or oil
unattended. Never use water to
put out burning oil or fat. Switch
off the hotplate. Extinguish flames
carefully using a lid, fire blanket or
something similar.
Risk of fi re!
■The hotplates become very hot.
Never place combustible items on
the hob. Never place objects on
the hob.
Risk of fi re!
■The appliance gets hot. Do not
keep combustible objects or
aerosol cans in drawers directly
underneath the hob.
Risk of fir e!
■The hob switches off automatically
and can no longer be operated. It
may switch on unintentionally at a
later point. Switch off the circuit
breaker in the fuse box. Contact
the after-sales service.
Risk of burning!
■The hotplates and the area around
them get very hot. Never touch the
hot surfaces. Keep children away.
Risk of burns !
■The hotplate heats up but the
display does not work. Switch off
the circuit breaker in the fuse box.
Contact the after-sales service.
Risk of burns !
■Metal objects on the hob quickly
become very hot. Never place
metal objects (such as knives,
forks, spoons and lids) on the
hob.
Risk of fir e!!
■After each use, always turn off the
hob at the main switch. Do not
wait until the hob turns off
automatically after the pan is
removed.
Risk of electric shock!
■Incorrect repairs are dangerous.
Repairs may only be carried out
and damaged power cables
replaced by one of our trained
after-sales technicians. If the
appliance is defective, unplug the
appliance from the mains or
switch off the circuit breaker in the
fuse box. Contact the after-sales
service.
Risk of e lectric shock.!

4
■Penetrating moisture may cause
an electric shock. Do not use any
high-pressure cleaners or steam
cleaners.
Ris k of elect ric shoc k!
■A defective appliance may cause
electric shock. Never switch on a
defective appliance. Unplug the
appliance from the mains or
switch off the circuit breaker in the
fuse box. Contact the after-sales
service.
Ris k of elect ric shoc k!
■Cracks or fractures in the glass
ceramic may cause electric
shocks. Switch off the circuit
breaker in the fuse box. Contact
the after-sales service.
Electromagnetic hazards!
This appliance complies with safety
and electromagnetic compatibility
standards. However, people with
pacemakers or insulin pumps must
refrain from using this appliance. It
is impossible to ensure that all of
these devices available on the
market comply with current
electromagnetic compatibility
standards, and that interference
which may prevent the device from
working correctly will not occur. It is
also possible that people with other
types of devices, such as a hearing
aids, could experience some
discomfort.
Malfunction risk!
The hob is equipped with a fan in
the lower section. If there is a
drawer under the hob it should not
be used to store small objects or
paper, since they could damage
the fan or interfere with the cooling
if they are sucked into it.
There should be a minimum of
2 cm between the contents of the
drawer and fan intake.
Risk of injury!
■When cooking in a bain marie, the
hob and cooking container could
shatter due to overheating. The
cooking container in the bain
marie must not directly touch the
bottom of the water-filled pot. Only
use heat-resistant cookware.
Risk o f i njury!
■Saucepans may suddenly jump
due to liquid between the pan
base and the hotplate. Always
keep the hotplate and saucepan
bases dry.
Elements that may damage the appliance
Caution!
■Rough pan bases may scratch the hob.
■Avoid leaving empty pots and pans on the hotplate. Doing so
may cause damage.
■Do not place hot pans on the control panel, the indicator
area, or the hob frame. Doing so may cause damage.
■Hard or pointed objects dropped on the hob may damage it.
■Aluminium foil and plastic containers will melt if placed on the
hotplate while it is hot. The use of laminated sheeting is not
recommended on the hob.

5
Overview
The following table presents the most common damage
caused:
Protecting the environment
Unpack the appliance and dispose of its packaging in such a
way that no damage is caused to the environment.
Environmentally-friendly disposal of waste
products
Energy-saving advice
■Always place the correct lid on cookware. Cooking with an
uncovered pan will result in a four-fold increase in energy
use. Use a glass lid to provide visibility and avoid having to
lift the lid.
■Use cookware equipped with a solid, flat bottom. Curved pan
bases increase energy consumption.
■The diameter of the pan base must match the size of the
hotplate. If not, energy may be wasted. Note: The
manufacturer normally indicates the pan's upper diameter.
This is normally greater than the diameter of the pan's base.
■Choose cookware of a size suited to the amount of food you
are going to cook. A large pan that is only half full will use a
lot of energy.
■Use a small amount of water when cooking. This saves
energy, and vegetables retain their vitamins and minerals.
■Select a lower power level.
Induction cooking
Advantages of induction cooking
Induction cooking represents a radical change from the
traditional method of heating; the heat is generated directly in
the pan. It therefore offers a number of advantages:
■Time savings for cooking and frying; since the pan is heated
directly.
■Energy is saved.
■Care and cleaning are simpler. Foods that have spilt do not
burn as quickly.
■Heat and safety control; the hob supplies or cuts off power
immediately when the control knob is turned on. The
induction hotplate stops supplying heat if the pan is removed
without having previously switched it off.
Suitable pans
Ferromagnetic pans
Only ferromagnetic pans are suitable for induction cooking,
these may be made from:
■enamelled steel
■cast iron
■special cutlery for stainless steel induction pan
To determine whether a pan is suitable, check to see if a
magnet will stick to it.
Damage Cause Measure
Stains Food spillage Immediately remove spilt food using a glass scraper.
Unsuitable cleaning products Only use cleaning products specifically designed for glass-ceramic hobs.
Scratches Salt, sugar and sand Do not use the hob as a tray or working surface.
Pans with rough bottoms may scratch
the glass ceramic Check pans.
Fading Unsuitable cleaning products Only use cleaning products specifically produced for glass-ceramic hobs.
Contact with pans Lift pots and pans before moving them around.
Chips Sugar, substances with a high sugar
content Immediately remove spilt food using a glass scraper.
This appliance conforms to the Waste Electrical and
Electronic Equipment Directive WEEE 2002/96/EC.
This directive defines the framework for recycling used
appliances within European territory

6
Other suitable cookware for induction
There are other types of cookware especially made for
induction whose base is not entirely ferromagnetic.
Unsuitable pans
Never use pans made from:
■common thin steel
■glass
■earthenware
■copper
■aluminium
Characteristics of the pan base
The characteristics of the pan base may affect the uniformity of
the cooking results. Pans made from materials which help
diffuse heat, such as stainless steel sandwich pans, distribute
heat uniformly, saving time and energy.
Absence of pan or unsuitable size
If no pan is placed on the selected hotplate, or if it is made of
unsuitable material or is not the correct size, the power level
displayed on the hotplate indicator will flash. Place a suitable
pan on the hotplate to stop the flashing. If this takes more than
90 seconds, the hotplate will switch off automatically.
Empty pans or those with a thin base
Do not heat empty pans, nor use pans with a thin base. The
hob is equipped with an internal safety system. However, an
empty pan may heat up so quickly that the "automatic switch
off" function may not have time to react and the pan may reach
very high temperatures. The base of the pan could melt and
damage the glass on the hob. In this case, do not touch the
pan and switch the hotplate off. If it fails to work after it has
cooled down, please contact the Technical Assistance Service.
Pan detection
Each hotplate has a minimum limit for detecting pans, which
varies depending on the material of the pan being used. You
should therefore use the hotplate that is most suitable for the
diameter of your pan.
Familiarise yourself with the appliance
These instructions for use are applicable to other hobs. On
page 2 an overview of the models is provided, along with
information on measurements.
The control panel
When using large cookware on a
smaller ferromagnetic zone, only
the ferromagnetic zone heats up,
so heat might not be uniformly
distributed.
Cookware with aluminium on the
base reduce the ferromagnetic
zone, so less heat may be sup-
plied or be difficult to detect.
For good cooking results, the
diameter of the cookware's ferro-
magnetic area should match the
size of the hotplate. If cookware
is not detected on a hotplate, try
it on the next smaller hotplate
down.
,QGLFDWLRQVIRU
SRZHUOHYHO³É
IXQFWLRQDOLW\¯
UHVLGXDOKHDW
SRZHUERRVWIXQFWLRQ°
&RQWUROSDQHO
IRU
PDLQVZLWFK
&RQWUROSDQHO
IRU
VHOHFWLQJ
DKRWSODWH
&RQWUROSDQHOVIRU
UWLPHSURJUDPIXQFWLRQ
,QGLFDWRUVIRU
UWLPHSURJUDPIXQFWLRQ
&RQWUROSDQHO
IRU
VHOHFWLQJWKHSRZHUOHYHO
&RQWUROSDQHO
IRU
'FKLOGORF 

7
Control surfaces
Pressing a symbol activates its corresponding function.
Notes
■The settings will not change if several symbols are pressed at
the same time. This enables the programming zone to be
cleaned when food is spilt.
■Always keep the control surfaces dry. Moisture can affect
proper functioning.
The hotplates
Residual heat indicator
The hob has a residual heat indicator •on each hotplate,
which lights up when they are hot. Avoid touching them when
this indicator is lit.
The •light will remain on while the hotplate is hot, even after
the hob has been turned off.
If the pan is removed before the hotplate is switched off, the •
will appear and alternate with the selected power level.
Programming the hob
This section will show you how to program the hotplates. The
table contains power levels and cooking times for several
dishes.
Switching the hotplate on and off
The range is turned on and off using the main switch.
To switch on: press the %symbol. The indicator next to the
main switch and the ‹indicators light up. The range is ready
for use.
To switch off: press the %symbol until the indicators go out. All
hotplates are turned off. The residual heat indicator will remain
lit until the hotplates have cooled down sufficiently.
Note: The range switches off automatically when all the
hotplates have been turned off for more than 20 seconds.
Set the hotplate
Select the required power level with the +and -symbols.
Power level 1 = minimum power.
Power level 9 = maximum power.
Each power level has an intermediate setting. This is marked
with a dot.
Setting the power level
The range should be switched on.
1. Press the §symbol several times until the ‹indicator of the
required hotplate lights up.
2. Within the next 5 seconds, press the +or -symbol.The basic
setting appears:
+symbol, power level 1.
-symbol, power level 9.
3. To change the power level: select the hotplate and press the
+or -symbol until the required power level appears.
To switch off the hotplate
Select the hotplate and then press the +or -symbol until ‹
symbol appears.
The hotplate turns off and the residual heat indicator appears.
Note: If no pan has been placed on the induction hotplate, the
selected power level flashes. After a certain time, the hotplate
switches off.
Hotplate Turning on and off
$Single hotplate Always use cookware of a suitable size.
æBroiler This zone is switched on automatically when using cookware with a base the
same size as the outer zone.
Use only cookware suitable for induction cooking; see the section on suitable cookware.
 

8
Cooking guidelines table
The table below contains some examples.
Cooking times depend on the power level, type, weight and
quality of the food. As such they are approximate.
Power levels affect cooking results.
When heating purées, creams and thick sauces, stir
occasionally.
Use power level 9 to begin cooking.
Power level Cooking time
(minutes)
Melt
Chocolate, chocolate coating, butter, honey 1-1. -
Gelatine 1-1. -
Heating and keeping warm
Stew (e.g., lentils) 1-2 -
Milk** 1.-2. -
Sausages heated in water** 3-4 -
Defrosting and heating
Frozen spinach 2.-3. 5-15 min
Frozen goulash 2.-3. 20-30 min
Slow cooking, simmering
Potato dumplings 4.-5.* 20-30 min
Fish 4-5* 10-15 min
White sauces (e.g., bechamel) 1-2 3-6 min
Whipped sauces (e.g., Bearnaise, Hollandaise) 3-4 8-12 min
Boiling, steaming, sautéing
Rice (with a double amount of water) 2-3 15-30 min
Rice pudding 2-3 25-35 min
Unpeeled potatoes 4-5 25-30 min
Peeled potatoes with salt 4-5 15-25 min
Pasta 6-7* 6-10 min
Soups 3.-4. 15-60 min
Vegetables 2.-3. 10-20 min
Greens, frozen foods 3.-4. 7-20 min
Cooked in a pressure cooker 4.-5. -
Stewing
Meat roll 4-5 50-60 min
Stew 4-5 60-100 min
Goulash 3.-4. 50-60 min
Bake / Fry with a little oil**
Steaks, plain or breaded 6-7 6-10 min
Frozen steaks 6-7 8-12 min
Chops, plain or breaded 6-7 8-12 min
Beefsteak (3 cm thick) 7-8 8-12 min
Chicken breast (2 cm thick) 5-6 10-20 min
Frozen chicken breast 5-6 10-30 min
Plain fish and fish fillet 5-6 8-20 min
Breaded fish and fish fillet 6-7 8-20 min
Frozen breaded fish (e.g., fish fingers) 6-7 8-12 min
Prawns and shrimps 7-8 4-10 min
Frozen meals (e.g., stir-fries) 6-7 6-10 min
Pancakes 6-7 fry individually
Omelette 3.-4. fry individually
Fried eggs 5-6 3-6 min
* Uncovered cooking
** Uncovered

9
Childproof lock
The hob can be protected against being accidentally turned on,
to ensure that children do not switch on the hotplates.
Turning on and off the childproof lock.
The range should be turned off.
To turn on: press the Dsymbol for approx. 4 seconds. The
indicator next to the D symbol lights up for 10 seconds. The
range is locked.
To turn off: press the D symbol for approx. 4 seconds. The
range is unlocked.
Note: The childproof lock can be accidentally activated by the
presence of water spilled while cleaning, food that has spilled
over or objects resting on the Dsymbol.
Activating and deactivating the childproof
lock
With this function, the childproof lock automatically activates
when a hob is switched off.
Activating and deactivating
See the “Basic Settings" section.
Powerboost function
The Powerboost function can be used to heat large amounts of
water more quickly than the power level Š.
Restrictions when using
This function is available for all hotplates, provided that the
other zone of the same group is not operating (see image).
Otherwise, in the visual display of the selected hotplate ›and
Šwill flash; then the power level will automatically set
itself to Š.
To activate
1. Select the power level Š.
2. Press the +symbol. On the hotplate, the ›indicator will
appear.
The function has been activated.
To deactivate
1. Select a hotplate.
2. Press the -symbol. The › symbol will disappear and the
hotplate will return to the Špower level.
The Powerboost function has been deactivated.
Note: In certain circumstances, the Powerboost function may
turn off automatically in order to protect the electronic
components inside the hob.
Frying** (150-200 g per serving with 1-2 l. of oil)
Frozen foods (e.g., French fries, chicken nuggets) 8-9 fry one portion at a
time
Frozen croquettes 7-8
Meatballs 7-8
Meat (e.g., chicken pieces) 6-7
Fish, in breadcrumbs or batter 6-7
Greens, mushrooms, in breadcrumbs or batter (e.g., baby mushrooms) 6-7
Confectionary products (e.g., fritters, fruit in batter) 4-5
Power level Cooking time
(minutes)
* Uncovered cooking
** Uncovered
*URXS









*URXS
*URXS
*URXS

10
Time program function
This function allows the selected hotplate to be switched off
automatically after a preset time by inserting the cooking time.
How to program
This function allows the selected hotplate to be switched off
automatically after a preset time. The hotplate will switch off
once this time has elapsed.
The range should be switched on.
1.Select the required hotplate and power level.
Then press the rsymbol until the ‹‹ indicator is displayed.
The indicator lights up on the selected hotplate.
2.Set the time using the +or -symbols.
+= 30 minutes
-= 10 minutes
After a few seconds, the timer will start to count down.
Once the time has elapsed
The hotplate turns off, there is a warning sound and the ‹
indicator lights up. Press the rsymbol. The indicators go out
and the sound stops.
To cancel or change the time
Select the hotplate with the §symbol. Press the rsymbol
and change the cooking time using the + or -symbols, or set
to ‹‹.
Note: Any cooking time can be programmed up to 99 minutes.
Automatic time limitation
If the hotplate remains in use for a long time and no changes
are made in the settings, the automatic time limitation function
is triggered.
The hotplate stops heating. On the hotplate display, ”and ‰
flash alternately.
The indicator goes out when any symbol is pressed. The
hotplate can now be reset.
When the automatic time function is used, it is governed by the
selected power level (from 1 to 10 hours).
Basic settings
The device has several basic settings. These settings may be
adapted to the user's individual needs.
 
Indicator Function
™‚ Childproof lock
‹Deactivated.*
‚Activated.
™ƒ Sound signals
‹ Confirmation beep and error signal deactivated.
‚Only confirmation beep deactivated.
ƒAll signals activated.*
™† Automatic time limitation.
‹ Basic setting: switch off after 1-10 hours.*
‚The basic setting is halved: switch off after 0.5 - 5 hours.
ƒThe basic setting is quartered: switch off after 0.25 - 2.5 hours.
*Factory settings
