IR Illuminator 5000
IIR-50850 | IIR-50940
en Installation Note
Available from A1 Security Cameras
www.a1securitycameras.com email: [email protected]

Available from A1 Security Cameras
www.a1securitycameras.com email: [email protected]

1
3 IR Illuminator 5000 Safety | en
Safety
Safety message explanation
!
Caution!
Indicates a hazardous situation which, if not avoided, could
result in minor or moderate injury.
Notice!
Indicates a situation which, if not avoided, could result in
damage to the equipment or environment, or data loss.
Safety precautions
!
Caution!
Risk Group 2 Caution: IR emitted from this product
Avoid eye exposure, use appropriate shielding or eye
protection.
!
Caution!
Installation should only be performed by qualified service
personnel in accordance with the National Electrical Code
(NEC 800 CEC Section 60) or applicable local codes.
!
Caution!
The Low Voltage power supply unit must comply with EN/UL
60950. The power supply must be a SELV-LPS unit or a SELV -
Class 2 unit (Safety Extra Low Voltage - Limited Power Source).
!
Caution!
These units must be properly and securely mounted to a
supporting structure capable of sustaining the unit weight. Use
care when selecting mounts for installation; the mounting
surface and unit's weight should be carefully considered.
Bosch Security Systems 2016.8 | 1.0 | AM18-Q0715
Available from A1 Security Cameras
www.a1securitycameras.com email: [email protected]

4 en | Safety IR Illuminator 5000
Important safety instructions
Read, follow, and retain for future reference all of the following
safety instructions. Follow all warnings before operating the
device.
– Clean only with a dry cloth. Do not use liquid cleaners or
aerosol cleaners.
– Do not install device near any heat sources such as
radiators, heaters, stoves, or other equipment (including
amplifiers) that produce heat.
– Never spill liquid of any kind on the device.
– Take precautions to protect the device from power and
lightning surges.
– Adjust only those controls specified in the operating
instructions.
– Operate the device only from the type of power source
indicated on the label.
– Unless qualified, do not attempt to service a damaged
device yourself. Refer all servicing to qualified service
personnel.
– Install in accordance with the manufacturer's instructions in
accordance with applicable local codes.
– Use only attachments/accessories specified by the
manufacturer.
– Permanently connected devices must have an external,
readily operable mains plug or all‑pole mains switch in
accordance with installation rules.
– Disconnect power supply and arrange for the device to be
serviced by qualified personnel if:
– The power cable/plug is damaged.
– Liquids or foreign bodies have entered the device.
– The device has been exposed to water or extreme
environmental conditions.
– The device is faulty despite correct installation/
operation.
2016.8 | 1.0 | AM18-Q0715 Bosch Security Systems
Available from A1 Security Cameras
www.a1securitycameras.com email: [email protected]

5 IR Illuminator 5000 Safety | en
– The device has fallen from a height, or the housing has
been damaged.
– The device performance is noticeably changed.
Notices
FCC & ICES Information
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following
measures:
– reorient or relocate the receiving antenna;
– increase the separation between the equipment and
receiver;
– connect the equipment into an outlet on a circuit different
from that to which the receiver is connected;
– consult the dealer or an experienced radio/TV technician
for help.
Intentional or unintentional modifications, not expressly
approved by the party responsible for compliance, shall not be
made. Any such modifications could void the user's authority to
operate the equipment. If necessary, the user should consult the
dealer or an experienced radio/television technician for
corrective action.
Bosch Security Systems 2016.8 | 1.0 | AM18-Q0715
Available from A1 Security Cameras
www.a1securitycameras.com email: [email protected]

6 en | Safety IR Illuminator 5000
The user may find the following booklet, prepared by the
Federal Communications Commission, helpful: How to Identify
and Resolve Radio-TV Interference Problems. This booklet is
available from the U.S. Government Printing Office, Washington,
DC 20402, Stock No. 004-000-00345-4.
Disposal - Your Bosch product was developed and
manufactured with high-quality material and components that
can be recycled and reused. This symbol means that
electronic and electrical appliances, which have reached the
end of their working life, must be collected and disposed of
separately from household waste material. Separate collecting
systems are usually in place for disused electronic and
electrical products. Please dispose of these units at an
environmentally compatible recycling facility, per European
Directive 2012/19/EU.
2016.8 | 1.0 | AM18-Q0715 Bosch Security Systems
Available from A1 Security Cameras
www.a1securitycameras.com email: [email protected]

2
7 IR Illuminator 5000 Installation | en
Installation
Mounting the bracket
x2
Connect the bracket to the illuminator as follows:
1. Ensure that the parts are mounted in the following order:
– Socket head screw
– Lock washer
– Washer
– Illuminator
– Bracket
2. Use the supplied socket wrench to secure the bracket on
both sides of the illuminator.
Bosch Security Systems 2016.8 | 1.0 | AM18-Q0715
Available from A1 Security Cameras
www.a1securitycameras.com email: [email protected]

8 en | Installation IR Illuminator 5000
Changing the beam-angle filter
Insert a beam-angle filter as follows:
1. Insert the supplied tool into the slot and twist. (Use the
thick end for the IIR-50xxx0-SR illuminator; use the tapered
end for all other illuminators.)
IIR-50xx0-SR
IIR-50xx0-MR/LR/XR
2. Remove the top cover.
3. Peel back the protective foil from the adhesive points.
4. Attach the selected beam-angle filter with the label side up
to the adhesive points.
“click”
5. Click the top cover back into place.
2016.8 | 1.0 | AM18-Q0715 Bosch Security Systems
Available from A1 Security Cameras
www.a1securitycameras.com email: [email protected]

3
9 IR Illuminator 5000 Connection | en
Connection
+
-
WH
YE
GN
BU
RD
BK
{
{
6
5
4
3
2
1
Power
– To power the illuminator connect a 12 to 32 VDC or a
24 VAC supply from a SELV class 2 power supply to wires
5 (+ red) and 6 (- black).
Illuminator masters the camera
To use the light sensor in the illuminator to switch the day/night
function of the camera:
1. Connect wires 1 (+ white) and 2 (- yellow) to the alarm
input of the camera.
2. If required, adjust the Photocell adjust control to
determine the switching points of the illuminator.
Camera masters the illuminator
To control illuminator switching from the camera:
1. Turn the Photocell adjust control fully counterclockwise.
2. Connect a relay output from the camera to wires 3 (–
green) and 4 (+ blue).
Bosch Security Systems 2016.8 | 1.0 | AM18-Q0715
Available from A1 Security Cameras
www.a1securitycameras.com email: [email protected]

10 en | Connection IR Illuminator 5000
Setting up
To achieve the best results set up at night and view the results
on a monitor.
1. Mount the illuminator and connect as described above.
2. Adjust the pan of the illuminator to match the camera’s
field of view.
3. Loosen the bolts on each side of the unit and adjust the
vertical alignment to maximize the results:
– Tilt the unit downwards until the near part of required
field of view is saturated with light as viewed on the
monitor.
– Slowly tilt the unit upwards until the furthest part of
the required field of view is illuminated correctly on
the monitor.
4. Re-tighten the bolts.
2016.8 | 1.0 | AM18-Q0715 Bosch Security Systems
