Dear Bosch Range Owner:
Thank you and congratulations on the purchase of your Bosch Electric Range, Whether
you are an expert chef or an aspiring cook, we know that your new range will exceed
your expectations, Decades of knowledge and experience are built into this range
making it among the highest quality, most versatile and most efficient available,
We ask that you read this manual thoroughly before using your new range. Please pay
particular attention to the safety precautions printed at the front of this book and the
numerous safety hints and cautions placed throughout, Also, be sure to familiarize
yourself with the proper operation of the range and its cleaning and maintenance
procedures, Adherence to these instructions and procedures will assure that you realize
the full potential of your new Bosch range as well as maintain it for years of dependable
use,
Thank you and good cooking,
BSH Home Appliances Corporation
When properly cared for, your new Bosch range has
been designed to be a safe, reliable appliance. Read all
instructions carefully before using this range. These
precautions will reduce the risk of burns, electric shock,
fire, and injury to persons. Do not operate the oven or
cooktop controls if the glass is broken. Food splatter or
cleaning solution may penetrate a broken control panel
and create a risk of electric shock. Contact a qualified
technician immediately should your glass control panel
become broken. When using kitchen appliances, basic
safety precautions must be followed, including those in
the following pages.
J
IMFK}RTANT SAFETY NOTICE
The California Safe Drinking and Toxic
Enforcement Act requires the Governor of
California to publish a list of substances known
to the state to cause cancer, birth defects or
other reproductive harm, and requires
businesses to warn customers of potential
exposure to such substances.
The elimination of soil during self-cleaning
generates some by-products which are on the
list.
The fiberglass insulation in self-clean ovens
gives off very small amounts of formaldehyde
during the first several cleaning cycles.
Exposure to these substances can be
minimized by:
L Providing good ventilation when cooking
with gas
2. Providing good ventilation during and
immediately after self cleaning the oven.
3. Operating the unit according to the
instructions in this manual.
J
The Bosch range referred to thoughout this manual is manufactured by BSH Home Appliance Corp.

Impo_ant $afeW Instructions .............................................................................. !
Getting Familiar with Your Range .......................................................................... 3
Setting UpYour Range
Setting and Changing the Clock .............................................................................. 5
Setting the Functions ............................................................................................ 6
Accessing and Using the Select Functions Menu ................................................ 6
Volume ......................................................................................................... 7
Change Temperature Scale ............................................................................. 7
LockKeys ..................................................................................................... 7
Time Format ................................................................................................. 7
Language Option ........................................................................................... 7
Clock Display ................................................................................................. 8
Oven Temperature Offset ............................................................................... 8
Demo Mode .................................................................................................. 8
ResetDefaults............................................................................................... 8
Sabbath Feature ............................................................................................ 8
The Cooktop
Cooktop Features.................................................................................................9
OperatingtheMechanicalCooktop ......................................................................... 10
The Oven
Oven Features .................................................................................................... 11
Oven Modes -Bake and ConvectionBake ................................................................12
Oven Modes =Broil ............................................................................................... 13
Oven Modes =Convection Roast ............................................................................. 14
Selecting the Mode ............................................................................................... !5
Using the Timer (s) .............................................................................................. 16
Using Timed Cook ................................................................................................ 17
Care and Cleaning
Cooktop .............................................................................................................. !8
Oven ................................................................................................................... 20
Guides, Self Helpand Maintenance
Cookware Selection Guide ..................................................................................... 23
Maintenance
Removing the Oven Door ................................................................................ 2zt
Replacing the Oven Light ................................................................................ 24
Self Help
Cooktop ........................................................................................................ 25
Oven ............................................................................................................ 26
Customer Sen,ice and Warranty ............................................................................ 27

Please read aH instructions before using this appliance°
APPLIANCE SAFETY
•Thisappliancemust be properlyinstalledand grounded by
a qualifiedtechnician,Connectonlyto properlygrounded
outlet,Referto InstallationInstructionsfordetails.
This appliance should be serviced only by a qualified service
technician. Contact the nearest authorized service center
for examination, repair or adjustment.
• Do not repair or replace any part of the range unless
specifically recommended. Refer service to an authorized
servicer.
Do not operate this appliance if it is not working properly
or if it has been damaged, until an authorized servicer has
examined it.
Use this appliance only for its intended use as described in
this manual If you have any questions, contact the
manufacturer.
Do not cover or block any openings on this appliance.
Donot use oorrosNe chemicals, vapors, or nonfood products
in this appliance. This type of range isspecifically designed
to heat or cook. It isnot designed for industrial or laboratory
use. The use of corrosive chemicals in heating or cleaning
will damage the appliance.
In the event that personal clothing or hair catches fire,
DROP AND ROLL IMMEDIATELY to extinguish flames,
• Do not allow children to use this appliance unless closely
supervised by an adult. Children and pets should not be left
alone or unattended in the area where the appliance is in
use. They should never be allowed to sit or stand on any
part of the appliance.
A
To reduce the risk of injury to persons, in the event of a
grease fire, observe the following:
In the event of a greasefire SMOTHERFLAMESwith a close-
ff_tinglid, cookie sheet, or other metal tray,then turn off the
elements. BECAREFULTO PREVENTBURNS.If the flames do
not go out immediately, EVACUATEAND CALLTHE FIRE
DEPARTMENT.
Donot use water,including wet dishcloths or towels on grease
fires. A violent steam explosion may result.
SMOTHERFLAMESfrom other types of food fires w_thbaking
soda. NEVERusewater on cooking fires.
NEVERPICK UPA FLAMINGPAN.You may be burned.
ALWAYShavea working SMOKEDETECTORnear the kitchen.
LEAVETHE HOODVENTILATORON when fiamb_ing food.
®Use an extinguisher ONLY IF:
Youknow you havea ClassABCextinguisher,andyou already
know how to operate it.
The fire is small and contained in the area where it started.
The fire department is being called.
You can fight the fire with your back to an exit.
RANGE SAFETY
Tielonghairso thatitdoes not hang loose.
The heating elements may be hot even though they are not
red in color. Interior surfaces of an oven become hot enough
to cause burns.
• Do not touch heating elements or interior surfaces of oven
during operation.
• During and after use, do not touch or let clothing or other
flammable materials contact the heating elements or the
interior surfaces of the oven until they have had sufficient
time to cool.
The trim on the sides of the oven door may become hot
enough to cause burns.
Use care when opening the door. Open the door slightly to
let hot air or steam escape before removing or repladng
food.
Do not heat unopened food containers. Build=up of pressure
may cause the container to burst and cause injury.
Always place oven racks in desired location while oven is
cool. If a rack must be moved while oven is hot, do not let
potholder contact the hot heating elements.
Use only dry potholders. Moist or damp potholders on hot
surfaces may result in burns from steam. Do not let potholder
touch hot heating elements. Do not use a towel or other
bulk'i cloth.
Keep the oven free from grease build up.
Do not place food direotly on oven bottom.
When using cooking or roasting bags in the oven, follow the
manufacturer's directions.
Do not use aluminum foil to line oven bottoms, except as
suggested inthis manual. Improper installation of aluminum
foil many result in a risk of electric shock or fire.
Toavoid electric shock, do not operate the oven without the
light bud cover in place.
COOKTOP SAFETY
Do not cook on a cooktop in which the glass top has broken.
If the cooktop glass should break, do not use it or attempt
to clean or fix it. Cleaning solutions and spillovers may
penetrate the broken cooktop and create a risk of electric
shock. Turn off electric circuit to the cooktop and call an
authorized service agency immediately.
When using the cooktop, DO NOT TOUCH THE HOT
COOKING AREA ORTHE IMMEDIATE SURROUNDING
AREA, Even though dark incolor, these areas may be hot.
Areas adjacent to the elements may become hot enough to
cause burns. Never let clothing, potholders, or other
flammable materials come in contact with a cooking area
until it has cooled.
Usehigh heat settings on the cooktop only when necessary Use
low to medium settings to heat oil slowly.
Never move a pan of hot oil,especiallyadeep fat fryer. Wait until
it iscool,
Page i

Please read aH instructions before using this applianceo
COOKTOP SAFETY (cont'd}
Never leavethe cooktop unattended, Boiloverscan causesmoke
and possiblydamage thecooktop,
Holdthehandleofthepan topreventmovement oftheutensil
when stirringorturningfood,
Otherthantheuseofmetalpans,onlycertaintypesofglass,
heatproof glass ceramic, ceramic, earthenware, or other glazed
utensilsare suitable for cooktop use,Other types of utensilsmay"
break w_thsudden temperature changes. Use only on low or
medium heat settings according to the utensil manufacturer's
direction&
OVEN SAFETY
To reduce the risk of fire;
Do not store flammable materials in or near the oven,
Do not use water on a grease fire, Smother fire or use a
dry chemical or foam-type extinguisher,
Have an appropriate fire extinguisher available and highly
visible near any cooking appliance,
Do not use the cavity for storage purposes, Do not leave
paper products, cooking utensils or food in the cavity when
not being used,
If materials inside the oven should ignite, keep oven door
closed, Turn off oven and disconnect the circuit at the
circuit breaker box,
Do not block any vent openings,
Never use the oven to warm or heat a room, This can
damage the oven parts,
Never wear loose-fitting or hanging garments while using
the appliance, Be careful when reaching for items stored
over the range, Flammable material could be ignited if
brought in contact with hot surface units or heating elements
and may cause severe burns,
Do not allow anyone to climb, stand or hang on the oven
door, warming drawer door, storage drawer or cooktop,
This can damage the range and even tip it over, causing
severe personal injury,
Have the installer show the location of the circuit breaker
or fuse, Mark it for easy reference,
SELF-CLEANING SAFETY
Confirm that the door locks and will not open once the
door lock indicator icon appears, If the door does not lock,
touch OFF and do not run Self-Clean. Phone
800/944=2904 for service.
Note; During a normal Self-Clean cycle, the door will not
lock until the oven reaches 450 ° F. In a Delayed Self-Clean
cycle, the door locks immediately.
Do not clean the oven gasket. It isessential for agood seal.
Care should be taken notto rub, damage, move or remove
the oven gasket.
• Donot usecommercial oven cleaners or oven liner protective
coatings of any kind in or around any part of the oven.
Clean only oven parts listed in this manual.
Before self-cleaning the oven, remove the broiler pan,
oven racks, oven probe, other utensils and wipe out
excess soft spillage,
REGARDING PET BIRDS;
Birds have very sensitive respiratory systems, Keep pet birds
out of the kitchen or other rooms where kitchen fumes could
reach them. During self dean, fumes are released that may
be harmful to birds. Other kitchen fumes such asoverheating
margarines and cooking oils may also be harmful.
Items of interest to children should
not be stored in cabinets above a
range or on the backsplash of a range.
Children climbing on the range to
reach items could be seriously injured.
Page 2

Parts Included with Your
Electric Range:
1, Use & Care Manual
2, Installation Instructions
3, AHAM Anti-TipBrochure
4, Oven Vent
5. AntFTip Bracket
6. Screws for AntFTip Bracket
7. Ceran Cooktop Scraper
8. Cooktop Cleaning Solution (not visible)
9. Registration Card
10, Incandescent Light (not visible)
11. Oven Control
t2, Paneland Knob
13. Broil Element (not visible)
14. Convection Fanand Element (not visible)
15. RackPositions
16. Door Gasket
17. Model & Serial # Hate
18, Bake E_ement(not visible)
19, Door Lock (not visible)
20. Oven RackBack
21, Oven RackFront
22. Broiler Pan
23. Broiler PanRacks(not shown)
24. Storage Drawer
19
17
4
OVEN RACK
/2O COOKTOP
SCRAPER
7
BROIL PAN ANTI-TIP
BRACKETS
AND SCREWS
5&6
Actual parts are larger than depicted in above graphics.
Page 3

Time
Clock
The Oven Control Panel
Light
HR:MIN:SEC
TIMER
Off Oven
Ternperatu re
Preheat
Temperature
O Cooking Mode
C
F
Temperature
Start
Start Contro_ Knob
Dispmay Window Features
CLOCK= Shows the time of day with a !2=hour or 24=hour
clock option.
COOKING MODE - Touch pad to display cooking mode.
COOKING ORTIMED MODE- Shows the number of hours
and minutes the oven will be"on." Cooking Mode Icon is also
displayed when cooking mode is seleceted.
CONTROL KNOB -Used to set the clock, timers, select
cooking mode and temperature. Turn clockwise to increase
and turn counterclockwise to decrease.
ELEMENTS - Displays which element(s) are active during a
cooking mode.
LIGHT - Touch pad to turn oven light on or offi
DOOR LOCK INDICATOR - Icon is displayed during the
self- dean mode when the door is locked. DO NOT attempt
to open the door until the lock symbol is no longer present.
OFF - Touch pad to turn off oven and/or warming drawer.
OVEN TEMPERATURE - Shows the oven temperature
selected.
PREHEAT - Displays temperature of oven during preheat
mode. Also displays internal temperature of meat when probe
is in use.
START -Touch pad to complete an entry.
TEMPERATURE -Touch pad to select cooking temperature.
TIMER-There are two timers- TIMER :[ AND TIMER 2; Each
counts down the time in hours and minutes. With less than
60 minutes remaining, the timer also displays seconds.
Other Indicators and Features
BEEP o Signals that more information must be entered or
confirms the receipt of an entry. A Beep also signals the
end of a program or an oven error.
DEFAULT SETTINGS o The cooking modes automatically
select the default temperature. These can be changed
when a different one is needed.
FLASHING SYMBOL OR NUMBER °Signals an
incomplete setting and calls for another step or STARTto
be touched.
F NUMBER CODES oThese codes are displayed when
there is a problem with the signal sent to the electronic
control board.
CONVECTION FAN oThe convection fan operates during
any convection mode. When the oven is operating in the
convection mode, the fan will turn off automatically when
the door is opened except when in the dehydrate mode.
The convection fan will also run during the preheat time
for specific modes.
Page 4

Setting the Clock (after power to the range has been off)
Always set the clock after installation or after a power failure. Once power returns to the oven, the clock defaults to 12:00 am,
The time of day is displayed in hours and minutes,
The clock time will appear during all oven operations except when the timer or a timed cooking operation is running.
The oven is preset to a 12=hour clock and indicates AN and PN.
Note: To switch to a 24 hr, clock, see "Select Function" section.
!, CLOCK will be displayed and the hour digits will flash,
2,
3,
4,
Turn knob to select hour and AM or PM. Turning to the right
increases by 1 hour increments; turning to the left decreases
by 1 hour increments.
Touch TIME. CLOCK wil! still be displayed and the
minute digits will flash,
Turn knob. Set minutes,
Touch TIME and the clock is now set.
Changing the Clock Time
1. Touch TIME, TIMER 1 will flash in display.
2. Turn knob to select CLOCK.
3. Touch TIME again and hour digits wil! flash.
4. Turn knob to change hours.
E Touch TIME again and minute digits wil! flash.
6. Turn knob clockwise or counter-clockwise to change minutes.
7. Touch TIME again and the clock is set,
Page 5

SELECT FUNCTIONS is the section of the menu where you can set or change the following features on your range:
VOLUME (decrease or increase loudness
of control beeps)
G
TEMPERATURE FORMAT (switch temperature
scale to Fahrenheit or Celsius)
TIHE FORMAT (!2 hr or 24 hr)
LOCK KEYS (oven control pad lockout )
ABC
@
DEHO
©
LANGUAGE OPTION (for display;selectEnglish,
Spanish, or French)
CLOCK DISPLAY (yes or no)
OVEN TEHPERATURE OFFSET (used to
calibrate the oven temperature)
DEMO MODE (used by appliance stores)
RESET DEFAULTS (change ai/function settings
back to original factory settings)
SABBATH FFJ_TURE(for religiousfaiths with"no
work" requirements on the Sabbath)
NOTE: In the event of a power failure, the functions return
to the factory settings and will need to be reset.
Accessing and Using the Select Functions
Menu
To access the SELECT FUNCTIONS menu, touch and hold
COOKING RODE touch pad forfive(5)seconds.
SELECT FUNCTION is displayed.
!. Turn knob to desired feature.
2. Press START to choose any function, and turn knob
to choose any sub-functions.
3. After selecting feature, touch OFF.
4. Touch OFF again to exit the select functions menu.
Page 6

_BEEP VOLUME
Thevolume ofthe control beepcanbechanged from LOW
(softest) to HIGH (loudest).
The control default for beep volume isMedium.
Changingthe beep vomume
1. Access SELECT FUNCTION Menu.
2. Turn knob clockwise slowl\z until VOLUME isdisplayed.
3. Touch START.
4. Turn knob to select volume level Low, Medium or High.
5. Touch START,
o
o
CHANGE TEMPERATURE
The oven has been preset to the Fahrenheittemperature
scale.
The feature allows you to switch between Fahrenheitand
Celsiustemperature.
Changing the Temperature Scale
!. Access SELECT FUNCTTON Menu.
2. Turn knob dockwise slowly/untiL SELECT TEHP F-C is
displayed.
3,Touch START.
4. Turn knob to select Fahrenheit (F) or Celsius(C).
5. Touch STARTto accept new selection.
LOCK KEYS
The keypad can be locked for safety"purposes.
This feature canbe usedto prevent changesto the oven
function.
T][HE FORMAT
The clock can be set to a !2=hr or 24=hr
format.
The oven default for clock format is !2=hr.
Changing the TTHE FORHAT
!. Access SELECT FUNCTION Menu.
2. Turn knob clockwise slowl_ until TTHE FORHAT is
displayed.
3. Touch START.
4. Turn knob to select12 hror 24 hrformat.
5. Touch START to accept new selection.
Locking or UnlocMng the Oven Control Panem
1. Access SELECT FUNCTTON Menu.
2. Turn knob dockwise slowly until LOCK KEYS is
flashing.
3. Touch START, KEY PAD LOCKED isdisplayed. The
displaywill beepifa keyispressedto indicatethatthe keypad
is locked.
¢ To unlock keypads,touch COOKING MODE and hold for
5 seconds. Displaywill read UNL(>CK%NG KL"_KPAD,
5, When unlocked,the clockwill again appear in the display.
Note: This function DOF._ NOT lock oven door.
ASC LANGUAGF DISPLAY
Language choicesare English,Spanish, and French.
Englishisthe default language.
Changing the Language Display
1. Aoce_5 SELECT FUNCTTON Menu.
2. Turn hob dockwiseslow_!untildesiredlanguageisdispiayed.
3, Touch START.
4. Turn knob clockwiseto select a different language
5. Touch START to accept a language change.
Page 7

_._#:CLOCK DISPLAY(ON or OFF)
Clock time display can be turned off.
The default display is on,
Turning the Clock Display ON or OFF
!, Access SELECT FUNCTION Menu.
2. Turn knob clockwiseslowl_zuntilCLOCK DISPLAY is
displayed.
3. Touch START.
4. Turn knob once and ON or OFF will appear in display.
5. Touch START to accept new selection.
RESET DEFAULTS
• ThisfeatureisusedtochangeaHthe"SelectFunctions"
settingsbackto theoriginalfactory"settings(or
defaults),
Resetting the factorysettings.
i. Access SELECT FUNCTTONS Menu,
2. Turn knob clockwise slowl_ until RESET DEFAULTS
isdisplayed.
3. Touch START. DisplayFeadsSELECTFUNCTIONS.
_OVEN TEMPERJ_TURE OFFSET
Changing the Oven Temp Offset
i. Access SELECT FUNCTION Menu.
2. Turn knob clockwiseslowlyuntilOVEN TEivIPOFFSET
isdisplayed,
3. Touch START. 0° F is displayed.
4. Turn the knob to the right to increase temperature
+25°F and to the left to decrease =25° temperature.
5. Touch START to accepta temperature change.
Dt_) DEMO MODE
The demo mode is for appliance store use only'.
o
FEATURE
Theovenwillbakefor 48 hoursbeforeautomaticallyturning
off.
Oven or warming drawer cannot be o_erating to set the
Sabbath Feature.
Setting the Sabbath Feature
!. Access SELECT FUNCTIONS Menu.
2. Turn knob clockwise until SABBATH OPTION
appears.
3. Touch START. BAKE will show in display and
temperature will flash.
4. Turn knob to set oven temperature.
5. Turn oven light on if desired (touch LIGHT).
Note: The light cannot be changed after this point. It will
stay on or off, as selected, during the entire Sabbath
mode.
6. Touch START. Oven starts after 5 seconds.
Note: The probe CANNOT be used during the Sabbath
mode.
While baking in Sabbath mode, the display will show SABBATH
and the BAKE icon will be displayed. The clock will be off and
no temperature will show in the display.
During the Sabbath mode, only the Off key will operate.
Press OFF at any time during the Sabbath mode to
end the mode and turn off the oven.
At end of 48 hours, the oven will turn off automatically and
the display will show SABBATH END. Touch OFF to return
to time of day.
Page 8

Before Using the ¢ooktop
Remove all packing materials and labels from the cooktop
surface.
While cool, wipe with a clean, damp sponge and dry.
Apply the Cooktop Cleaning Creme packaged with the
range. Buff with a clean cloth. See Care and Cleaning
Section.
There may be a slight odor during the first several uses;
this is normal and will disappear.
Optimum cooking results depend on the proper cookware
being selected and used.
The cooking surface will hold the heat and remain hot up
to 30 minutes after the elements have been turned off.
Read and understand all safety precautions and Use and
Care Manual information pdor to operating.
Precautions for Long Life and Good
Appearance of the Surface
Regular, daily care using the Cooktop Cleaning Creme will
protect the surface and make it easier to remove food soil
and water spots.
The ceramic glass cooking surface is a durable material
resistant to impact but not unbreakable if a pan or other
object is dropped on it.
Never cook food directly on the glass.
Avoid placing a wok support ring, trivet or other metal
stand on the glass surface.
Do not use the glass surface as a cutting board.
Do not slide cookware across the cooking surface; it may
scratch the glass.
Do not place wet pans on the glass surface.
Retained Heat
The glass cooking surface retains heat and stays hot after
the element(s) have been turned off. The retained heat may
be used to hold foods at serving temperatures for a short
time. If a hot surface light is on, use caution when working
or cleaning around the cooktop as the cooktop is still hot.
Temperature Limiters
Each radiant heating element has its own sensor to protect
the glass cooking surface from extreme high temperatures.
The limiters will operate automatically by cycling the element
off regardless of the cook setting.
Although cycling is normal, any one of the following conditions
can activate the limiter and cause it to cycle on and off more
than usuah
The base of the pan is not making full contact with the
heating surface (due to a warped or uneven base).
The pan is too small for the size of the element.
The pan has boiled dry.
The material or shape of the pan is slow to transfer the
heat.
Radiant Elements
Bosch UltraSpeed TM radiant elements use a wire ribbon located
under the ceramic glass surface to provide the heat for cooking.
These radiant elements will cycle on and off by design (see
Temperature LimRersat left.) There are 9heat setting positions
from 9 (high) to 1 (low) and a special setting for keep warm.
Dual Element
The dual element consists of two radiant ribbon elements
within the same heating area. Either the small inner element
or both the inner and outer elements may be selected for use,
depending on the size of cookware.
Use this chart as a guide for heat settings"
Uses Heat
Settings
Bringing water to boil 9
High
Pan frying, sauteing, 6-8
browning meat, deep Med-High
fat frying
Most frying, eggs, 4-5
pancakes, slow boil IVied
Simmering, finish cooking 2-3
covered foods, steaming Med Low
Melting butter and 1
chocolate, keeping food warm Low
A range of heat settings are listed because the actual
setting depends on:
!) type and quality of pan (See"Selecting Cookware" on
page 23)
2) type, quantity and temperature of the food
3) element used
4) the cook's preference.
208/240 Volt Connection; The Heat Settings
recommended on this page are based on a 240 volt
power source. If your cooktop is connected to 208 volts,
the same heat settings apply but foods may take a little
longer to finish cooking.
Page 9

YourMechanicalCooktophas3singleelements(small,mediumandlarge)andone(1)doubleelement,The4controlknobs
locatedatthefrontoftherangeallowyouto adjusttheheatsettingsofthecooktopelements.
T'5
NO, _PE&SIZE
1 Dual 5"/9"
2. Single 7"
3. Single 8"
4 Single 6"
5. Hot Surface
Indicator Light
Control Knobs
DualElement Knob Single Element Knob
OFF® OFF•
5_ 5 3_ "7
linnetElement Only
n°°r,:OmO22 o:nt
The controls on the cooktop are marked to show which element
they control. All controls are marked from 1-9, with 1 being
the lowest heat setting and 9 the highest setting. There are
an infinite number of heat settings between the 1-9 positions.
Single Element
To turn on a single element, push in on the control knob and
turn in either direction to the desired heat setting.
Dual Element
To turn ON the small, inner element, push in on the control
knob and turn it counter=clockwise. Set to desired heat level.
To turn ON both the inner and outer elements together, push
in on the control knob and turn it clockwise. Turn the knob
clockwise to the desired setting. Toturn off the dual element,
turn the knob to the OFF position.
CAUTION
Foods packaged in aluminu_ foil should not be
placed directly on the glass ceramic surface for cooking;
aluminum foil can melt and cause permanent damage
to the surface.
Plastic, paper and cloth can melt or burn when in
contact with a hot surface. Do not let these items come
in contact with the hot glass ceramic surface.
Do not allow pans to boil dry. This can permanently
damage the pan, the element and the cooktop glass.
750/2200
1500
1900
1200
Hot Surface Indicator Light
Each element features a hot indicator light to show when the
cooking surface is too hot to touch. The signal light will turn
on automatically in the area marked CAUTION oHOT at the
center front. The light remains on until the cooking area has
cooled to a safe=to=touch temperature.
Caution oHot
Page !0

Oven Racks
Your oven has three fiat racks. They are designed with a stop
so they will stop before coming completely out and not tilt.
_'_, CAUT][ON: TO AVOID POSSIBLE BURNS, PLACE
OVEN RACKS IN DESIRED POSITIONS BEFORE
TURNING THE OVEN ON. ALWAYS USE OVEN HITTS
WHEN THE OVEN IS WARH,
Removing from oven: Grasp rack firmly on both sides and
pull rack toward you. When the stop is reached, tilt rack up
and pull the rest of the way out.
Replacing in oven: Grasp rack firmly on both sides. Tilt
rack up to allow stop into rack holder. Bring rackto a horizontal
position and push the rest of the way in. Rack should be
straight and flat, not crooked.
Rack Position
(see graphic at right for further details)
RACK 6 (highest position) - Use for melting cheese, broiling
thin foods
RACK S - Use for broiling most meats, toasting bread
RACK 4 - Use for broiling thicker meats
RACK 3- Use for most baked goods when baking on one
rack, such as on a cookie sheet or baking pan, cakes, frozen
convenience foods, biscuits, brownies, muffins
RACK 2 - Used for pies, casseroles, breads, bundt or pound
cakes, small roasts or poultry,
RACK 1 (lowest position) - Use for angel food cake, large
roasts, turkey.
Multipme Rack Cooking
When using multiple racks, follow the placement
recommendations below.
Two rack: Use rack positions ! and 5.
To allow for best baking results for cakes, place items on back
of upper rack and front of lower rack (see graphic at right).
Three rack: (for convection bake): Use positions 1, 3 and 5.
The rack in position 3 can be telescopic if desired.
Preheating
Preheat the oven if the recipe recommends it.
Preheating is necessary for good results when baking cakes,
cookies, pastry and breads. When using the probe preheating
is not recommended. Setting a higher temperature does not
shorten preheat time. Place oven racks in proper position
before preheating. A beep will confirm that the oven is
preheated and the selected oven temperatu re will be displayed.
Pan Pmacement
Baking results are better if pans are placed in the center of the
oven. If baking more than one pan on a rack, allow at least
:["to ! 1/2"of air space around the pan. When baking four cake
layers at the same time, place pans on two racks so that one
pan is not directly above the other. Do not place food directly
on oven bottom.
Baking Pans
Glass baking dishes absorb heat, therefore reduce oven
temperature 25°F when baking in glass.
Shiny, smooth metal reflects heat resulting in lighter, more
delicate browning.
Dark, rough or dull pans will absorb heat resulting in browner,
crisper crust. Some manufacturers recommended reducing
temperature 25° F when using this type of pan. Follow
manufacturer recommendations. Use glass OFdark metal pans
for pies.
Insulated baking pans may increase the length of the
recommended baking time.
Rack Position
Hultiple Rack Cooking °Pan Placement
One Rack
Two Racks
Page 11

BAKE and WARH
Baking is cooking with dry, heated air. Both the upper and
lower element cycle to maintain the oven temperature:
The Bake mode can be used to prepare a variety of food
items, from pastries to casseroles. It can also be used to roast
meats.
In the Warming mode, the oven uses the upper and lower
element to maintain a low temperature to keep food at serving
temperature.
, Use the Warming setting on the oven to keep foods hot
until ready to serve.
o The Warming mode temperatures are !40 ° - 220° R The
default temperature is !70°R
o Foods that need to be kept moist should be cpvered with
a lid or aluminum foil.
Convection Baking is similar to Baking. In this case, heat
also comes from the top and bottom elements. The main
difference in convection baking is that the heat is circulated
throughout the oven by the convection fan:
The Convection Bake mode is well-suited for baking large
quantities of food on multiple racks. It can be used to prepare
cookies, pies, cupcakes, pastries, breads, snack foods and
appetizers among other items.
The benefits of Convection Baking include:
o Slight decrease in cooking time
o Better results for three rack cooking (more even browning)
o Higher Volume (yeast items rise higher)
Cook more items at once
For Best Results:
Reduce recipe temperature by 25° F Refer to the
Convection Baking chart for examples.
• Place food in low-sided, uncovered pans such as cookie
sheets without sides.
Center baking pans side to side on the oven rack.
Convection BakeChart
Cake
Cupcakes
Bundt Cake
Angel Food
Pie
2 crust, fresh, 9"
2 crust, frozen fruit, 9"
Cookies
Sugar
Chocolate Chip
Brownies
Breads
Yeast bread, loaf, 9x5
Yeast rolls
Quick Bread, loaf,
8x4
Biscuits
Muffins
3 325
2 325
1 325
2 350-400
2 350
3 325 _350
3 325-350
3 325
2 350
3 350_375
2 325 _350
17-19
37-43
35-39
45-55
68_78
6oll
8o13
29 _36
18_22
12_15
45_55
3 350_375 11-15
3 400 15_19
Pizza
Frozen 3 375_425 23_26
Fresh 3 400_425 12_15
Page !2

BROIL
Broiling uses intense heat radiated from the upper element:
The Broil mode is best suited to cooking thin, tender cuts of
meat (!" or less), poultry and fish. It can also be used to
brown breads, casseroles and other foods.
The benefits of Broiling include:
Fast and efficient cooking
o Cooking without the addition of fats or liquids
o Browning as the food cooks
For Best Results:
, Preheat oven 3-4 minutes
o Steaks and Chops should be at least 3/4"thick
o Brush fish and poultry" with butter or oil to prevent sticking
, Use the broil pan and grid included with your range
, Do not cover the broiler grid with foil. Tt iS designed to
drain fats and oils away from the cooking surface to
prevent smoking and spattering
o Turn meats once halfway through the recommended
cooking time (see Broil Chart for examples).
When top browning casseroles, use only metal or glass
ceramic dishes such as Comingware®.
Never use heat-proof glass (Pyrex®); they cannot tolerate
the high temperature.
ALWAYS BROIL WTTH THE DOOR CLOSED
BroilChart
Beef
Steak (3/4" - 1 ")
Medium Rare 5 High* 145 7-8
Medium 5 High 160 8-9
Well 5 High 170 9-11
Hamburgers
(3/4" - 1")
Well 4 High 160 12-15
PouJtry
Breast (boneqn) 4 Low* 170 18-20
6-7
6-9
7-10
7-8
18-19
Pork
Pork Chops (1") 4 High 160 9-10 8-9
Sausage - fresh 3 High 160 8-10 7-9
Ham Slice (1/2") 5 High 160 3-4 2-3
6-7
Seafood Cook
Fish Filets, 1" 4 Low until
Buttered opaque
& flakes
easily
with fork
Lamb
Chops (1")
Medium Rare 5 High 145
Medium 5 High 160
Well 5 High 170
5-7
8-9
9-11
Bread
Garlic Bread, 1"
slices 2-4
High
DO
NOT
TURN
6-7
6-8
8-9
Page !3

CONVECTION ROAST
Convection Roast uses heat from the top and bottom
elements as well as heat circulated by the convection fan:
The Convection Roast mode is well suited to preparing tender
cuts of meat and poultry.
The benefits of Convection Roasting, include:
o As much as 25% faster cooking than standard Roasting/
Baking
, Rich, golden browning
For Best Results:
Use the same temperature as indicated in the recipe.
Check doneness early as roasting time may decrease by
as much as 25%. Refer to Convection Roast Chart for
examples.
o Do not cover meat or use cooking bags
, Use the broil pan and grid provided with the range for
roasting. A low-sided, uncovered pan can also be used.
, Use the probe (some models) or a meat thermometer to
determine the internal temperature of the meat.
If the meat is browned to your liking, but is not yet done,
a small strip of foil can be placed over the breast to
prevent overbrowning.
, Let meat stand covered with foil !0-!5 minutes after
removing from the oven.
iBeef
Convection Roast Chart
iiiiiii! to!iiiili !i
.........................................................................
Rib Roast 4-6 325 25-32 145(med/ra_)
28-32 160(medium)
Rib Eye Roast, 4 - 6 325 24-32 145 (med/rare)
(boneless) 27-32 160 (medium)
Rump, Eye, 3 - 6 325 25-30 145 (med/rare)
_p, Sirloin 28-32 160 (medium)
(boneless)
Tenderloin 2 - 3 425 15-25 145 (med/rare)
Roast
Pork
Loin Roast
(boneless or
bone-in)
5-8 350 15-25 160
Shoulder 3- 6 350 20-30 160
Pouffry
Chicken - 3 - 4 375 14-20 180
whole
Turke_ 12-15 325 10-14 180
unstuffed**
Turke_ 16-20 325 9-13 180
unstuffed**
Turke_ 21-25 325 6-10 180
unstuffed**
Turkey Breast 3 - 8 325 20-25 170
i Cornish Hen 1 - 1 ½ 350 45-75 (total 180
time)
Lamb
Half Leg 3 - 4 325 30-35 160 (medium)
25-30 170 (well)
Whote Leg 6 - 8 325 25-30 160 (medium)
30-35 170 (well)
Page !4

Se ing the Cooking Mode
i, Touch COOKING MODE,
2. BAKE vviI{flashinthe display.
Ifno furthersettingismade within5 seconds,contro{will
beep and flash.Ifthisoccurs,pressSTART.
3. To change the cooking mode, turn knob.
4. Push START.
The selected mode will appear in the display, along with
the default temperature for that mode, which will be
blinking.
5. To select a different temperature, turn knob to the
right or left (in 5° increments) to desired temperature.
6. Touch START. If START is not touched, oven will
automatically turn on in 5 seconds.
7. The display alternates between the cooking mode and
preheat.
The preheated temperature is also displayed, starting at
:[00oR The actual temperature increases until set
temperature is reached, at which point the oven will
beep,
8. To change temperature during cooking, simply touch
TEMPERa_TURE. Turn the knob to select new
Temperature and press START.
9. Once cooking has been completed, touch OF[=to
turn off oven.
Note: After the oven has been turned off, HOT appears in the
display where the cooking mode was. This is to indicate that
the oven is off but still hot. When the oven temperature drops
below :[76° F, HOT is no longer seen in the display.
Oven Operation Time
The oven will automatically shut off after :[2 hours (24 hours
if the time format isset for 24 hour in the SELECT FUNCTION
section).
Oven Vent
The oven vent is located below the display above the rear left
cooktop element.
It is normal to see steam escaping from the vent and
condensation may collect on the backgaurd and cooktop.
This area may become hot when the oven is in use.
Do not block the vent as it is important for air circulation.
Page :[5

Setting the Timer/s
1, Touch TIME and TIMER 1 will be displayed. Clearing the Timer/s
i, Touch TIME once_
2_ Turn knob toselectthe appropriatetimer Touch TIME.
3, Turn knob once inclockwisedirectionand CLEAR TIMER
will flash in display.
4, Push TIME,
2. Turn counterclockwise and TIMER 2 will be displayed. Select
TINIER 1 or 2, then push TIN!E, SET TINIER 1 (2) appears
in display. Minutes flash.
3. Turn knob to the right to increase by iminute increments or
left to decrease by 1 minute increments. Continue to rotate knob
until desired minutes are displayed.
If setting only minutes, press START. Otherwise, continue to
step 4.
4. Touch TINIE again and the hours will flash.
5_ Touch TINIE pad.TINIER 1 (2) will flash in display.
6. Turn knob to clear TINIER 1 (2).
7. To clear TINIER 1 (2), push TIN!E.
8. If TINIE pad is not touched, oven will beep and display wil!
continue flashing.
When the specified time has elapsed, the control beeps. TINIER 1
(2) END flashes in the display.
1. Touch TINIE to return to main screen.
5. Turn knob to the right to increase by 1 hour increments or
left to decrease by 1 hour increments until desired hours are
displayed.
6, Touch TTNIE again, The TINIER is now set,
7. If TINIE or START is not touched, oven will begin beeping and
timer display wil! begin flashing.
Changing the "limer/s
1. Touch TIN!E. TINIER 1 will appear in display. Selecteither TINIER
lor2o
2, Push TINIE, RESET TINIER I (2) appears in the display,
Minute digits flash,
3, Turn knob clockwise or counteroclockwise to change minutes,
4. Touch TINIE again and hour digits will flash,
5, Turn knob clockwise or counteroclockwise to change hours.
6. Touch TINIE and new time is set.
Page !6

TheTIMEDCOOK feature sets the oven to a cooking mode for a set period of time and then turns it off, The TIMED COOK
feature is available for each of the following oven modes: Bake, Convection Bake and Convection Roast.
Be sure that the time-of-day dock displays the correct
time before beginning, See "Changing the Clock Time"
to adjust the time,
Setting a Timed Mode
!. Touch COOKING HOD£.
2. BAKEwillbedisplayed. Toselectadifferentcookingmode, turn
the knob.
3. TouchSTART.
4. Turn knob to select desiredtemperature.
Note: time required for the oven to reach temperature must be
included in theset cooking tLme.
5. Touch TIME. T£MEB BAKE appears in the display.
6. Touch TIME, set BAKE TIME appears in the display and
minutes flash. Set min_s, Touch TIME.
7. Hours Flash. Set hours, Touch START.
8. TIMED BAKE appearsindisphyand the c_,enbeginsto preheat.
After cooking is complete, display flashesTIME COOK END.
iiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiii!iiiiiiiiiiiii!i i!iiiii iiiiiiiiiiiiiiiiiiiiilliiiiiiiiiiiiiii!!!!!!!!!!!!i
Delaying the Start of a Timed Mode
!. Follow steps 1 through S above.
2. Turn knob until DELAYEB BAKE appears in display.
3. Touch TIME. SET BAKE T£ME appears in the display and
minutes flash. Set minutes, Touch TIME,
4. Hours Flash. Set hours, Touch START.
5. SET BAKE END appears in the display. Touch TIME.
6. Use knob to enter the time of day the oven will stop
cooking or turn off,
Set hours. Touch TIME.
Set minutes, Touch START.
The clock automatically calculates the time of day at
which the cooking mode starts and stops. The displayed
cooking time counts down by the minute.
7. At the end of the programmed cookingtime, the oven will
automatically turn off. Display will show the mode and
TIME COOK END and the oven will beep. Reminder
beeps will sound for up to fifteen minutes until
any pad is touched.
Note; Remove food from oven immediately after cycle
has finished to prevent overcooking. Food left in the oven will
continue to cook even after the cycle is complete.
To check the cooking time and stop time after a delay has
been set, touch TIME. Turn knob to BAKE END or
DEU_.YED BAKE. Touch TIME.
Page !7
