GE JD750SF User instructions

JD750SF
GE 30" Drop-In Electric Convection Range
Note: Cabinets installed adjacent to slide-in ranges must have an
adhesion spec of at least 194° temperature rating.
Note: To reduce possibility of scorching the side walls above the
countertop when no load is present on burners, it is recommended
that a minimum of 6" spacing from adjacent side wall be allowed for
possible extended, high-heat, element operation.
IMPORTANT: 30" DROP-IN RANGES ARE DESIGNED TO HANG
FROM THE COUNTERTOP. IT DOES NOT REST ON THE FLOOR.
FOR INSTALLATION ALTERNATIVES, REFER TO INSTALLATION
INSTRUCTIONS PACKED WITH PRODUCT.
Optional Kits For Drop-In Electric Ranges (Available At Additional Cost)
Installation information: Before installing,
consult installation instructions packed with
product for current dimensional data.
Accessory Backguards
(Attaches to the back of range
as a backguard when unit is installed
in 30" free-standing cutout)
JXS32SS (Stainless) - 4" High
JXS32WW (White) - 4" High
JXS32BB (Black) - 4" High
Rear Filler Strip
WB07T10680 - Black Filler Strip Assembly
Listed by
Underwriters
Laboratories
Dimensions and Installation Information (in inches)
KW Rating
240V 12.6
208V 9.5
Breaker Size
240V 40 Amps
208V 40 Amps
Above illustration intended for dimensional reference only.
Refer to photograph for actual product appearance.
For answers to your Monogram® or GE®
appliance questions, visit our website at
geappliances.com or call GE Answer Center®
service, 800.626.2000.
All GE ranges are equipped with
an Anti-Tip device. The installation
of this device is an important,
required step in the installation
of the range.
Acceptable Electrical Outlet
Area Also In Adjacent
Cabinet Or Under Floor
Conduit is 40" long
30" Min.
30" Min.
15" Min.
Recommended
6" Min.
from walls
2-7/8"
To Front Surface
of Countertop
30
27-1/2
25
23-3/16
If necessary,
build upsides
to 1-1/4" thick
to provide
countertop
support
27
20-5/8" Door
Clearance
From Front
Surface of
Countertop
24
31-1/4
30
4
Accessory
Backguard JXS32
25-3/4*
(excluding handle)
*Total depth from wall to
front of closed oven door
including handle is 28-1/2.
28-1/2
23-3/16
30
30
If you are NOT using the
Filler strip or Backguard:
If you are using the
Filler strip or Backguard:
25
DROP-IN ELECTRIC RANGE
Acceptable Electrical Outlet
Area Also In Adjacent
Cabinet Or Under Floor
Conduit is 40" long
30" Min.
30" Min.
15" Min.
Recommended
6" Min.
from walls
2-7/8"
To Front Surface
of Countertop
30
27-1/2
25
23-3/16
If necessary,
build upsides
to 1-1/4" thick
to provide
countertop
support
27
20-5/8" Door
Clearance
From Front
Surface of
Countertop
24
31-1/4
30
4
Accessory
Backguard JXS32
25-3/4*
(excluding handle)
*Total depth from wall to
front of closed oven door
including handle is 28-1/2.
28-1/2
23-3/16
30
30
If you are NOT using the
Filler strip or Backguard:
If you are using the
Filler strip or Backguard:
25
DROP-IN ELECTRIC RANGE
Acceptable Electrical Outlet
Area Also In Adjacent
Cabinet Or Under Floor
Conduit is 40" long
30" Min.
30" Min.
15" Min.
Recommended
6" Min.
from walls
2-7/8"
To Front Surface
of Countertop
30
27-1/2
25
23-3/16
If necessary,
build upsides
to 1-1/4" thick
to provide
countertop
support
27
20-5/8" Door
Clearance
From Front
Surface of
Countertop
24
31-1/4
30
4
Accessory
Backguard JXS32
25-3/4*
(excluding handle)
*Total depth from wall to
front of closed oven door
including handle is 28-1/2.
28-1/2
23-3/16
30
30
If you are NOT using the
Filler strip or Backguard:
If you are using the
Filler strip or Backguard:
25
DROP-IN ELECTRIC RANGE
Acceptable Electrical Outlet
Area Also In Adjacent
Cabinet Or Under Floor
Conduit is 40" long
30" Min.
30" Min.
15" Min.
Recommended
6" Min.
from walls
2-7/8"
To Front Surface
of Countertop
30
27-1/2
25
23-3/16
If necessary,
build upsides
to 1-1/4" thick
to provide
countertop
support
27
20-5/8" Door
Clearance
From Front
Surface of
Countertop
24
31-1/4
30
4
Accessory
Backguard JXS32
25-3/4*
(excluding handle)
*Total depth from wall to
front of closed oven door
including handle is 28-1/2.
28-1/2
23-3/16
30
30
If you are NOT using the
Filler strip or Backguard:
If you are using the
Filler strip or Backguard:
25
DROP-IN ELECTRIC RANGE
Specification Revised 9/14

JD750SF
GE 30" Drop-In Electric Convection Range
JD750SF
Features and Benefits
• True European Convection with Precise Air - Enjoy perfectly
even results without turning the pan
• 6"/9"/12" 3600W Power Boil - Pots and pans fit perfectly on
the flexible heating element
• Bridge zone - Cook griddle favorites from the convenience of
your range
• Fifth element warming zone - Provides low heat capability
for foods
• Self-clean heavy-duty oven racks - Conveniently clean your
oven and racks together
• Self-clean with Steam Clean Option - Clean your oven the
way you want
• Black gloss oven interior - Enjoy a clean and sleek
appearance
• Model JD750SFSS - Stainless steel
Specification Revised 9/14
