Bosch KDN64VW20N User manual

en Operating and installation instructions
fr Notices d'utilisation et de montage
it Istruzioni per l'uso ed il montaggio
el Οδηγίες χρήσης και τοποθέτησης
tr Kullanma ve montaj kılavuzu
KDN64..

en Table of contents
Safety and warning information ............ 5
Directions for disposal ........................... 7
Scope of delivery .................................... 7
Installing the appliance .......................... 8
Connecting the appliance ..................... 9
Attaching handles ................................... 9
Getting to know the appliance .......... 10
Switching on the appliance ................ 11
Setting the temperature ...................... 11
Super cooling function ........................ 12
Button lock ............................................ 12
Alarm function ...................................... 12
Utilisable volume .................................. 12
Cooling compartment ......................... 13
Freezer compartment .......................... 13
Max. freezing capacity ........................ 13
Freezing and storing ........................... 14
Freezing fresh food ............................. 14
Defrosting frozen food ........................ 15
Features ................................................. 15
Switching the appliance off and
placing it out of operation .................. 16
Cleaning the appliance ....................... 16
Lighting (LED) ....................................... 17
Saving energy ....................................... 17
Operating noises ................................. 18
Rectifying minor faults yourself ......... 18
After-sales service ............................... 20
fr Notices d'utilisation et de montage
Consignes de sécurité ........................ 21
Consignes pour la mise au rebut ..... 23
Étendue des fournitures ..................... 24
Installation de l'appareil ...................... 24
Raccordement de l'appareil ............... 26
Montage des poignées ....................... 26
Présentation de l'appareil ................... 27
Mise en service de l'appareil ............. 28
Réglage de la température ................ 28
Super-réfrigération ............................... 29
Verrouillage des touches .................... 29
Fonction d'alarme ................................ 29
Contenance utile .................................. 29
Compartiment réfrigérateur ................ 30
Compartiment congélateur ................ 30
Capacité de congélation maximale .. 30
Congélation et rangement ................. 31
Congélation de produits frais ............ 31
Décongélation des produits .............. 32
Équipement ........................................... 32
Coupure et remisage de l'appareil ... 33
Nettoyage de l'appareil ....................... 34
Éclairage (LED) .................................... 34
Économies d'énergie .......................... 35
Bruits de fonctionnement ................... 35
Remédier soi-même aux petites
pannes ................................................... 36
Service aprèsvente ............................. 38

3
it Indice
Avvertenze di sicurezza e pericolo ... 39
Avvertenze per lo smaltimento .......... 41
Fornitura ................................................. 42
Predisposizione dell'apparecchio ..... 42
Allacciamento dell'apparecchio ........ 44
Montaggio maniglie ............................. 44
Imparare a conoscere l'apparecchio 45
Attivazione dell'apparecchio .............. 46
Impostazione della temperatura ........ 46
Raffreddamento super ........................ 47
Blocco dei tasti ..................................... 47
Funzione allarme .................................. 47
Volume utile ........................................... 47
Frigorifero .............................................. 48
Congelatore .......................................... 48
Capacità di congelamento max. ...... 48
Congelamento e conservazione ....... 49
Congelamento di alimenti freschi ..... 49
Scongelamento dei cibi congelati .... 50
Dotazione .............................................. 50
Attivazione e disattivazione
dell'apparecchio ................................... 51
Pulizia dell'apparecchio ...................... 51
Illuminazione (LED) .............................. 52
Risparmio energetico .......................... 52
Rumori di funzionamento ................... 53
Eliminazione di piccole anomalie ..... 53
Servizio di assistenza tecnica ........... 55
el Πίνακας περιεχομένων
Υποδείξεις ασφαλείας και
προειδοποιητικές υποδείξεις .............. 56
Υποδείξεις για την απόσυρση ............. 58
Υλικά παράδοσης ................................. 59
Τοποθέτηση της συσκευής ................. 59
Σύνδεση της συσκευής ....................... 61
Συναρμολόγηση των λαβών ................ 61
Γνωρίστε τη συσκευή ........................... 62
Ενεργοποίηση της συσκευής .............. 63
Ρύθμιση της θερμοκρασίας ................ 63
Υπέρψυξη ............................................... 64
Κλείδωμα των πλήκτρων ...................... 64
Λειτουργία συναγερμού ...................... 64
Ωφέλιμη χωρητικότητα ........................ 65
Χώρος ψύξης ......................................... 65
Χώρος κατάψυξης ................................ 65
Μέγιστη απόδοση κατάψυξης ............ 65
Κατάψυξη και αποθήκευση ................ 66
Κατάψυξη νωπών τροφίμων ............... 66
Απόψυξη κατεψυγμένων τροφίμων ... 67
Εξοπλισμός ............................................ 67
Απενεργοποίηση και ακινητοποίηση
της συσκευής ........................................ 68
Καθαρισμός της συσκευής ................ 69
Φωτισμός (LED) ................................... 69
Εξοικονόμηση ενέργειας .................... 70
Θόρυβοι λειτουργίας ........................... 70
Αποκατάσταση μικρών βλαβών από
σας τους ίδιους .................................... 71
Σέρβις πελατών .................................... 73

4
tr İçindekiler
Güvenlik bilgileri ve uyarılar ............... 74
Atıkların yok edilmesiyle ilgili uyarılar 75
Paket içeriği ........................................... 76
Cihazın kurulması................................. 76
Cihazın bağlantısı................................. 78
Tutamakların montajı........................... 78
Cihazıtanımak ...................................... 79
Cihazıçalıştırmak ................................. 80
Sıcaklığın ayarlanması......................... 80
Süper soğutma ..................................... 81
Tuşkilidi ................................................. 81
Alarm fonksiyonu .................................. 81
Kullanım kapasitesi .............................. 81
Soğutma bölmesi ................................. 82
Dondurucu ............................................. 82
Maks. dondurma kapasitesi .............. 82
Dondurma ve saklama ....................... 83
Taze yiyeceklerin dondurulması........ 83
Dondurulmuşgıdanın çözülmesi ...... 84
Donanım ................................................ 84
Cihazın kapatılmasıve
beklemeye alınması............................. 85
Cihazın temizlenmesi .......................... 85
Aydınlatma (LED) ................................. 86
Enerji tasarrufu ..................................... 86
Çalışma sesleri ..................................... 87
Küçük arızalarıkendi kendinize
giderme .................................................. 87
Müşteri hizmetleri ................................. 89

en
5
enTable of contents enInstructions for use
Safety and warning
information
Before you put the appliance
into operation
Carefully read through the instructions
for use and assembly instructions. They
contain important information on setting
up, using and maintaining the appliance.
The manufacturer is not liable for any
damage caused by users ignoring the
information and warnings contained in
the instructions for use. Retain all
documents for later use or for
subsequent owners.
Technical safety
The appliance contains a small quantity
of the environmentally-friendly, though
flammable, refrigerant R600a. Make sure
that the pipes of the refrigerant circuit are
not damaged during transport or
installation. If refrigerant shoots out, it
may ignite or cause eye injuries.
In the event of damage:
■Keep open flames or sources of
ignition away from the appliance,
■Ventilate the room well for a few
minutes,
■Switch off the appliance and unplug it
from the mains,
■Inform the after-sales service.
The more refrigerant an appliance
contains, the larger the room must be in
which it stands. If there is a leak and the
room is too small, a flammable gas-air
mixture may form.
The room must be at least 1 m³ in size
for each 8 g of refrigerant. The volume of
refrigerant in your appliance is listed on
the rating plate inside the appliance.
If the mains connection cable for this
appliance is damaged, it must be
replaced by the manufacturer, the after-
sales department or a similarly qualified
person. Incorrect installations and
repairs may put the user at considerable
risk.
Repairs must only be carried out by the
manufacturer, after-sales service, or a
similarly qualified person.
Only original parts from the manufacturer
must be used. The manufacturer can
only guarantee that the safety
requirements are met if these parts are
used.
A mains cable extension lead must only
be procured from the after-sales service.
During use
■Never use electrical appliances inside
the appliance (e.g. heaters, electric
ice makers, etc.). Risk of explosion!
■Never defrost or clean the appliance
with a steam-cleaning device. The
steam may reach electrical parts and
trigger a short circuit. Risk of electric
shock!
■Do not use pointed or sharp objects to
remove layers of ice and frost! You
could damage the refrigerant pipes. If
refrigerant shoots out, it may ignite or
cause eye injuries.

en
6
■Do not store products with flammable
propellant gases (e.g. spray cans) or
explosive substances inside the
appliance. Risk of explosion!
■Do not misuse the base, rails, doors,
etc. as a step or support.
■For defrosting and cleaning, unplug
the appliance from the mains or switch
off the fuse. Pull on the mains plug,
not on the connecting cable.
■Only store high-proof alcohol tightly
sealed and in an upright position.
■Do not contaminate plastic parts or
door seals with oil or grease.
Otherwise, the plastic parts and door
seals will become porous.
■Never cover or block ventilation
openings for the appliance.
■Children and people with impaired
physical, sensory, or mental abilities
or who lack knowledge of the
appliance must only use it if they are
supervised by a person who will take
responsibility for their safety or who
have learned how to use the appliance
by reading this manual.
■Do not store liquids in bottles or tins in
the freezer compartment (in particular
carbonated drinks). Bottles and tins
may burst.
■Never eat frozen foods immediately
after they have been taken out of the
freezer compartment.
Risk of freezer burn!
■Avoid prolonged hand contact with
frozen foods, ice, and the evaporator
tubes, etc.
Risk of freezer burn!
Children in the household
■Do not give packaging or packaging
parts to children.
Risk of suffocation from cardboard
boxes and films!
■The appliance is not a toy.
■For appliances with a door lock:
Keep the key out of the reach of
children!
General requirements
The appliance is suitable for the following
tasks:
■Chilling and freezing food,
■Making ice cubes
This appliance is intended for domestic
use in private households and for a
domestic environment.
The appliance is fitted with interference
suppression in accordance with EU
Directive 2004/108/EC.
The refrigeration circuit has been
checked for leak tightness.
This appliance corresponds to the
relevant safety requirements for electrical
appliances (EN 60335-2-24).

en
7
Directions for disposal
*Disposing of packaging
The packaging protects your appliance
from damage during transport. All the
materials used are environmentally
friendly and can be recycled. Please help
by Disposing of the packaging in an
environmentally-responsible manner.
You can obtain information about current
disposal methods from your specialist
dealer or local council.
*Disposing of your old
appliance
Old appliances are not useless waste.
Valuable raw materials can be recovered
through environmentally responsible
disposal.
m Warning
For worn-out appliances:
1. Unplug the mains plug.
2. Cut the power cord and remove it
along with the mains plug.
3. Do not remove the shelves and
containers. Leaving them intact makes
it more difficult for children to climb in.
4. Never let children play with a disused
appliance. Risk of asphyxiation!
Refrigerators contain refrigerant as well
as gases in the insulation material.
Refrigerant and gases must be disposed
of properly. Do not damage the
refrigerant circuit pipes before disposing
of them properly.
Scope of delivery
After unpacking the appliance, check all
parts for transport damage.
If you wish to make a complaint, please
contact the dealer from whom you
purchased the appliance or our after-
sales service.
The scope of delivery includes the
following parts:
■Free-standing appliance
■Features (vary depending on the
model)
■Instructions for use and assembly
instructions
■After-sales service booklet
■Guarantee slip
■Information on energy consumption
and noises
■Bag of assembly materials
This appliance is marked in
accordance with European
directive 2002/96/EC regarding
old electric and electronic
appliances (waste electrical and
electronic equipment - WEEE).
The directive provides a
framework for the collection and
recycling of old appliances, which
is valid across the EU.


en
8
Installing the appliance
Location
The ideal installation location is a dry,
well-ventilated room. The installation
location should not be subject to direct
sunlight or near a heat source, such as a
cooker, heating element, etc. If setting up
the appliance next to a heat source is
unavoidable, use a suitable insulating
plate or observe the following minimum
distances from the heat source:
■3 cm from an electric or gas cooker.
■30 cm from oil or solid fuel cookers.
Appliances with fixed handles require a
distance of at least 55 mm from the wall
on the hinged side so that the door can
be opened by 90°.
Note the room temperature and
ventilation
Ambient temperature
The appliance is designed for a certain
climate class. Depending on the climate
class, the appliance can be operated at
the following ambient temperatures.
The climate class is specified on the
rating plate. Figure *
Note
The appliance can function within the
ambient temperature limits of the
specified climate class. If an appliance in
the SN climate class is operated at lower
ambient temperatures, damage to the
appliance can be excluded up to a
temperature of +5 °C.
Ventilation
Figure $
The air on the appliance's back panel
and side panels heats up. The heated air
must be able to escape unimpeded.
Otherwise, the refrigerating unit has to
work harder, which increases the
appliance's power consumption.
Therefore: You must never cover or
block the ventilation openings!
The minimum distance to all sides must
be at least 5 cm.
Fitting spacers
Figure %
Use the screws to attach the spacers
provided to the relevant openings at the
rear of the appliance. This will maintain
the minimum distance from the wall, thus
providing adequate ventilation.
If the appliance is standing at an angle,
this may mean that the doors do not
close correctly.
Levelling the appliance
Figure &
To ensure that it functions properly, the
appliance must be set level using a spirit
level.
If the appliance is standing at an angle,
this may mean that the doors do not
close correctly.
Climate class Permissible ambient
temperature
SN +10 °C to 32 °C
N+16 °C to 32 °C
ST +16 °C to 38 °C
T+16 °C to 43 °C

en
9
1. Position the appliance in the intended
installation area.
2. Unscrew the two screws on the base
panel and inspect the base panel.
3. Screw the front feet out until they
stand firmly on the ground and align
the appliance at the front.
4. Use a spirit level to check that the
appliance is horizontal.
5. Position the base panel and secure it
in place using the screws.
Note
The front feet must stand firmly on the
ground so that the appliance does not
roll away.
Connecting the
appliance
After setting up the appliance, wait for at
least one hour before starting the
appliance up. The oil contained in the
compressor may have been displaced
into the refrigeration system during
transport.
Before starting the appliance up for the
first time, clean its interior (see section
“Cleaning the appliance”).
Electrical connection
The socket must be near to the
appliance and easily accessible after the
appliance has been installed.
The appliance conforms to protection
class I. Connect the appliance to a
220-240 V/50 Hz alternating current
supply using a socket with protective
earthing conductor which has been
correctly installed. The socket must be
protected by a fuse with a rating of 10 A
to 16 A.
In the case of appliances operated
outside of Europe, check whether the
voltage and type of current specified
conform to the values of your electricity
grid. You will find this information on the
rating plate. Figure *
m Warning
The appliance must never be connected
up to an electronic energy-saving socket.
Sinusoidal-commutated and line-
commutated inverters can be used with
our appliances. Line-commutated
inverters are used with photovoltaic
systems that are connected directly to
the national grid. Sinusoidal-
communicated inverters must be used
with standalone applications (e.g. on
ships or mountain huts) that do not have
a direct connection to the national grid.
Attaching handles
Figure '
Only attach the handles once the
appliance has been positioned in its
installation location and has been
aligned so that it is level.
1. Push the holders into the guides.
2. Position and tighten the screws.
3. Push the handles onto the holders and
slide them downwards. The "Top"
sticker must be facing upwards.
4. Position and tighten the screw.

en
10
Getting to know the
appliance
Fold out the last page that contains the
figures. These instructions for use apply
for several models.
The features of the models may vary.
Deviations between the figures are
possible.
Figure !
Control element
Figure "
1 Lighting
2 Shelf in the freezer compartment
3 Ice twister
4 Temperature controller
5 Light switch
6 Door shelf (2 star compartment)
for short-term storage of food and
ice cream
7 Door shelf
8 Control element
9 Light switch
10 Shelves in the cooling
compartment
11 Stay-fresh compartment
12 Fruit and vegetable container with
deodoriser
13 Door shelf for eggs, tubes and
small tins
14 Door shelf for large bottles
1"super" button
For switching the super cooling
function on and off.
2"lock" button
For switching the button lock on
and off.
3"alarm" button
For switching off the warning tone
4"fridge" button
For adjusting the temperature in
the fridge compartment.
5Display panel
Displays the set temperature for
the fridge compartment.
"lock"
The button lock is switched on.
"super"
Super cooling function is
switched on.
"alarm"
The alarm function is active.

en
11
Switching on the
appliance
The appliance starts to cool after it is
connected to the power supply. The
lighting is switched on when the door is
opened.
An acoustic warning tone sounds. The
"alarm" button can be used to switch off
the audible warning signal.
The factory has recommended and set
the following temperatures:
■Fridge compartment: +4 °C
■Freezer compartment: -18 °C.
Notes on using the appliance
■After switching on the appliance, it
may be several hours before the set
temperatures are reached.
■Thanks to the fully automatic no-frost
system, the freezer compartment
remains ice-free. There is no longer
any need to defrost it.
■The front side of the housing is slightly
heated. This prevents condensation
from forming around the door seal.
■If the freezer compartment drawer
cannot be opened again soon after
being closed, wait for a moment until
the negative pressure has cleared.
Setting the
temperature
Cooling compartment
Figure "/4
The temperature can be set from +2 °C
up to +8 °C.
Press the "fridge" button repeatedly until
the display panel shows that the required
fridge compartment temperature is set.
Do not store perishable foods at
temperatures higher than +4 °C.
Notes
■Do not store perishable foods at
temperatures higher than +4 °C.
■For short-term storage of food, a
higher temperature can be set
(energy-saving operation).
■When frequently opening the door and
placing large quantities of food in the
cooling compartment, a lower
temperature should be set.
Freezer compartment
Figure #
Turn the temperature controller to the
required setting.
At the medium setting, the temperature
reaches approx. -18 °C.
Min: higher temperature.
Max: lower temperature.
Once the ambient temperature has fallen
below +10 °C, turn the temperature
controller to "Max".

en
12
Super cooling function
With the super cooling function, the
cooling compartment is cooled to the
coldest temperature. Once the coldest
temperature is reached, it automatically
changes to the present temperature.
The super cooling function is
recommended in the following cases:
■Before putting a large amount of food
in the cooling compartment.
■To cool drinks quickly.
Switching on and off
Figure "/1
Press the 1 button.
If the super cooling function is switched
on, "super" is shown on the display
panel.
After approx. 40 minutes, or once the
temperature in the cooling compartment
is 2 °C lower than the set temperature,
the super cooling function automatically
switches off.
Button lock
When the button lock is switched on, all
of the buttons on the control element are
locked.
Exception: When the button lock is
switched on, the "alarm" button can be
used to switch off the audible warning
signal.
Switching on and off
Figure "/2
Press the 2 button.
If the button lock is switched on, "lock" is
shown on the display panel.
To switch the button lock off, press and
hold button 2 for approx. 3 seconds.
Alarm function
If an alarm is triggered, an audible
warning signal sounds and "alarm" is
shown on the display panel.
Press the "alarm" button to switch off the
audible warning signal. Figure "/3
Door alarm
The door alarm switches on if one of the
appliance doors remains open for longer
than 1 minute.
The alarm stops when the door is closed
again.
Temperature alarm
The temperature alarm switches on if it
becomes too warm in the cooling
compartment.
Note
If it has become too warm in the cooling
compartment, properly heat up any
chilled goods that have been warmed
before consumption.
In cases of doubt, do not use raw food.
Utilisable volume
You will find information regarding the
utilisable volume on the rating plate (see
section "After-sales service").

en
13
Cooling compartment
The cooling compartment is the ideal
place to keep prepared dishes, baked
goods, canned goods, condensed milk,
hard cheese, fruit and vegetables that
are sensitive to cold, and tropical fruits.
When arranging the food, note
the following
When arranging the food, bear in mind
the following:
■Arrange your food so that it is well-
packaged or covered. This ensures
that the aroma, colour and freshness
are not lost. This also prevents
flavours from mixing and the plastic
parts from becoming discoloured.
■Allow warm food and beverages to
cool before putting them into the
appliance.
■Do not block the cooling
compartment's air outlets with food.
Doing so impedes the air circulation.
Food that is stored directly in front of
the air outlets may become frozen by
the cold air that is discharged.
Freezer compartment
Use the freezer compartment
for the following
■Storing deep frozen food.
■Making ice cubes.
■Freezing food.
Note
Make sure that the freezer compartment
door is always closed. When the door is
open, the frozen foods defrost and the
freezer compartment ices up heavily.
Furthermore: Energy is wasted due to the
power consumption.
When you close the freezer compartment
door, there is negative pressure in the
freezer compartment. This causes a
sucking noise. Wait for two to three
minutes until the negative pressure has
cleared.
Max. freezing capacity
You will find information on the maximum
freezing capacity in 24 hours on the
rating plate (see section "After-sales
service").

en
14
Freezing and storing
Purchasing frozen foods
■Packaging must not be damaged.
■Observe the best before date.
■The temperature in the commercial
chest freezer must be -18 °C or
colder.
■As far as possible, frozen food must
be transported in an insulated
container and quickly placed in the
freezer compartment.
Storing frozen food
If lots of food is to be stored, you can
remove the ice twister and the shelf.
To ensure that there is no impact on the
air circulation in the appliance, do not
stack the food beyond the stacking limit.
Freezing fresh food
Only use fresh, undamaged food for
freezing.
In order to retain the nutritional value,
aroma and colour of the food as much
as possible, blanch vegetables before
they are frozen. Blanching is not required
for aubergines, peppers, courgettes and
asparagus.
You can find literature about freezing and
blanching in bookshops.
Note
Do not allow food that is to be frozen to
sit right next to food that has already
been frozen.
■The following are suitable for freezing:
Baked goods, fish and seafood, meat,
game, poultry, vegetables, fruit, herbs,
eggs without their shells, dairy
products such as cheese, butter and
curd cheese, prepared dishes and
leftovers such as soups, stews,
cooked meat and fish, potato dishes,
baked casseroles and sweet foods.
■The following are not suitable for
freezing:
Types of vegetables that are usually
eaten raw – such as green salad or
radishes, eggs in their shells, grapes,
whole apples, pears and peaches,
hard-boiled eggs, yoghurt, soured
milk, sour cream, crème fraîche and
mayonnaise.
Packaging frozen food
Pack food so that it is airtight to prevent
it from losing its flavour or drying out.
1. Store food in its packaging.
2. Press out any air.
3. Close the packaging tightly.
4. Label packaging with its contents and
date of freezing.
The following are suitable as
packaging:
Plastic film, polyethylene hose film,
aluminium foil, freezer bags.
You will find these products at your
specialist dealer.
The following are not suitable as
packaging:
Wrapping paper, greaseproof paper,
cellophane, rubbish bags and used
shopping bags.
The following are suitable for sealing
packaging:
Rubber bands, plastic clips, pack-twines,
cold-resistant scotch tape, or similar.

en
15
Polyethylene bags and hose film can be
fused closed using a bag sealer.
Storage life of frozen foods
Depending on the type of food.
At a temperature of -18 °C:
■Fish, sausages, prepared dishes,
baked goods:
Up to 6 months
■Cheese, poultry, meat
Up to 8 months:
■Vegetables, fruit
Up to 12 months:
Defrosting frozen food
You can decide between the following
options, depending on the type of food
and its intended use:
■at ambient temperature
■in the fridge
■in an electric oven, with/without hot air
convection
■In the microwave oven.
m Caution
Do not refreeze defrosted food. It can
only be refrozen after it has been made
into a ready-to-eat meal (cooked or
roasted).
Do not continue to use the complete
max. storage time for the frozen food.
Features
You can vary positioning of the interior
shelves and the door shelves depending
on your requirements:
■Lift the shelf and move it towards the
front.
■Lift the door shelf and remove it.
Stay-fresh compartment
The temperatures in the stay-fresh
compartment are lower than in the
cooling compartment. There may also be
temperatures lower than 0 °C.
Ideal for storing fish, meat and sausages.
Not suitable for salads, vegetables or
food that is sensitive to cold.
To ensure that the stay-fresh
compartment functions correctly, it must
be completely closed and the shelf must
rest on it correctly.
Odour filter
Unpleasant odours in the refrigerator
compartment are prevented by the odour
filter.
Tip: Despite this, strong-smelling foods
should still be stored in securely sealed
containers.
If the effect of the odour filter decreases,
it can easily be revitalised:
1. Remove the odour filter.
2. Dry the filter with a hair dryer.
3. Lay the odour filter in the sun in order
to eliminate any remaining unpleasant
odours (decomposition of the odour
compounds by ultraviolet light).
4. Place the odour filter back in the
appliance.

en
16
Vegetable container with
humidity controller
Figure (
To create the perfect storage climate for
vegetables, salad and fruit, depending
on the quantity of food in storage, the
humidity can be controlled in the
vegetable container.
Small quantities of food –
Move the controller to the left.
Large quantities of food –
Move the controller to the right.
Ice twister
Figure )
1. Remove the ice cube drawers, fill
these up with water until they are ¾
full and reinsert the drawers.
2. Once the ice cubes are frozen, turn
the turning handles on the ice cube
drawers to the right.
The ice cubes become loose and fall
into the container.
3. Pull out the container and remove the
ice cubes.
Switching the
appliance off and
placing it out of
operation
Switch off the appliance
Unplug the appliance from the mains or
switch off the childproof lock.
The temperature display goes blank and
the refrigerating unit switches off.
Putting the appliance out of
service
If you do not use the appliance for long
periods:
1. Unplug the appliance from the mains
or switch off the childproof lock.
2. Clean the appliance.
3. Leave the appliance door open.
Cleaning the appliance
m Caution
■Do not use gritty, acidic or chlorine-
based cleaning agents or solvents.
■Do not use any abrasive materials or
materials that may scratch surfaces.
This may lead to corrosion of the
metallic surfaces.
■Never clean the shelves or containers
in the dishwasher.
The parts may warp.
The cleaning water must not get into
■Opening slots in the front bottom area
of the freezer compartment,
■Operating controls
■Or any lighting.

en
17
Proceed as follows:
1. Before cleaning the appliance, unplug
the mains plug or disconnect the fuse.
2. Take out the frozen food and store it in
a cool place. Place an ice block (if you
have one) on the food.
3. Clean the appliance with a soft cloth,
lukewarm water, and a little pH-neutral
detergent. The water used for rinsing
must not get into the lighting.
4. Only wipe the door seal with clean
water and then rub it until it is dry.
5. After cleaning, reconnect the
appliance to the mains and switch it
on.
6. Put the frozen food back in.
Features
To clean the appliance, all of the variable
elements can be removed.
Removing shelves
Lift the shelf and move it towards the
front.
Removing the door shelves
Lift the door shelf and remove it.
Lighting (LED)
Your device is equipped with a
maintenance-free LED light.
Any repair work on the lighting must only
be carried out by the after-sales service
or authorised experts.
Saving energy
■Install the appliance in a dry,
ventilated room. The appliance must
be installed out of direct sunlight and
away from heat sources (e.g. heating
elements, cooker).
Use an insulating plate if necessary.
■Allow hot food and drinks to cool
before placing them in the appliance.
■Place frozen food that is to be
defrosted in your cooling
compartment. Use the low
temperature of the frozen food to cool
down food.
■Open the appliance door for as little
time as possible.
■Clean the rear side of the appliance
occasionally with a vacuum cleaner or
brush in order to avoid increased
power consumption.

en
18
Operating noises
Completely normal noises
Humming
Motors running (e.g. refrigeration units,
ventilator).
Bubbling, whirring or gurgling noises
Refrigerant is flowing through the pipes.
Clicking
Motors, switches or solenoid valves are
switching on/off.
Crackling
Automatic defrosting is taking place.
Preventing noises
If the appliance is positioned unevenly
Align the appliance using a spirit level.
Use the threaded feet for this, or place
something underneath the feet.
If the appliance is touching adjacent
units or appliances
Move the appliance away from adjacent
furniture or appliances.
Containers or shelves are wobbling or
sticking
Check the removable parts and reinsert
them if necessary.
If bottles or containers are touching
Move the bottles or containers apart
slightly.
Rectifying minor faults yourself
Before you call the after-sales service:
Check whether you can rectify the fault yourself by using the notes below.
You must bear the costs for consultation with the after-sales services yourself – even
during the warranty period.
Problem Possible cause Remedy
It is too cold in the
cooling compartment.
Colder freezer
compartment
temperatures may also
cause colder cooling
compartment
temperatures. This is
due to its cooling
properties.
Set the temperature in the cooling
compartment so that it is slightly
warmer.
If this is not sufficient, e.g. if the
room temperatures are too cold, you
can also set the temperature in the
freezer compartment temperature so
that it is warmer.

en
19
The temperature in the
freezer compartment
is too high.
The appliance door is
being opened
frequently.
Do not open the appliance door
unnecessarily.
The ventilation
openings are covered.
Remove any obstructions.
Freezing larger
quantities of fresh
food.
Do not exceed the max. freezing
capacity.
The temperature
deviates considerably
from the setting.
In some cases, it is sufficient to
switch off the appliance for
5 minutes.
If the temperature is too high, wait a
few hours and check whether the
temperature has aligned with the
setting.
If the temperature is too low, wait
until the next day and check the
temperature again.
The lighting is not
working.
The LED lighting is
faulty.
See section "Lighting (LED)".
The appliance door
was opened for too
long.
The lighting switches
off after approx.
10 minutes.
After closing and opening the
appliance door, the lighting is
switched on again.
The light switch is
jammed.
Check whether you can move the
light switch. Figure !/5
No display lights up. If the appliance is not
operated for some
time, the control panel
display switches to
energy-saving mode.
As soon as the appliance is used
again (e.g. the door is opened), the
display switches back to its normal
lighting.
Power failure;
the fuse has been
tripped; the mains
plug is not firmly
inserted.
Connect the mains plug. Check
whether there is power, check the
fuses.
Problem Possible cause Remedy

en
20
After-sales service
You can find an after-sales service point
near to you in the telephone directory or
in the list of after-sales service points.
When you call the after-sales service,
quote your product number (E no.) and
the production number (FD no.) of your
appliance.
You will find this information on the rating
plate. Figure *
Please help us to avoid unnecessary
journeys by quoting the appliance and
production number. This will save you
the additional associated costs.
Repair order and consultation
if faults occur
The attached after-sales service directory
contains the contact data for all
countries.
An audible warning
signal sounds and
"alarm" is shown on
the display panel.
Problem; It is too
warm in the cooling
compartment.
Press the "alarm" button to switch off
the audible warning signal.
Figure "/3
Note
If it has become too warm in the
cooling compartment, properly heat
up any chilled goods that have been
warmed before consumption.
In cases of doubt, do not use raw
food.
The appliance door is
open.
Close the appliance door.
The ventilation
openings are covered.
Remove any obstructions.
Too much food has
been inserted for
freezing at the same
time.
Do not exceed the max. freezing
capacity.
Problem Possible cause Remedy
GB 0844 8928979 Calls from a BT
landline will be
charged at up
to 3 pence per
minute. A call
set-up fee of up
to 6 pence may
apply.
IE 01450 2655
US 800 944 2904 toll-free
