Bosch KGN Series User manual

en User manual
Fridge-freezer
KGN..

en Table of Contents
Safety and warning information ............ 3
Information concerning disposal .......... 6
Scope of delivery .................................... 7
Installation location ................................. 7
Ambient temperature and ventilation .. 7
Connecting the appliance ..................... 8
Getting to know your appliance ........... 8
Switching the appliance on ................ 10
Setting the temperature ...................... 10
Special functions .................................. 11
Alarm function ...................................... 12
Usable capacity .................................... 12
Refrigerator compartment .................. 13
Super cooling ....................................... 14
Freezer compartment .......................... 15
Max. freezing capacity ........................ 15
Freezing and storing food .................. 15
Freezing fresh food ............................. 16
Super freezing ...................................... 17
Thawing frozen food ............................ 17
Interior fittings ....................................... 17
Sticker “OK” .......................................... 18
Switching off the appliance ................ 18
Cleaning the appliance ....................... 19
Light (LED) ............................................ 19
Tips for saving energy ........................ 20
Operating noises ................................. 20
Eliminating minor faults yourself ....... 21
Appliance self-test ............................... 22
Customer service ................................. 22

en
3
enTable of Contents enInstruction for Use
Safety and warning
information
Before you switch ON the
appliance
Please read the operating and
installation instructions carefully!
They contain important
information on how to install,
use and maintain the appliance.
The manufacturer is not liable if
you fail to comply with the
instructions and warnings.
Retain all documents for
subsequent use or for the next
owner.
Technical safety
The appliance contains a small
quantity of environmentally
friendly but flammable
refrigerant R600a. Ensure that
the tubing of the refrigerant
circuit is not damaged during
transportation and installation.
Leaking refrigerant may cause
eye injuries or ignite.
If damage has occurred
■Keep naked flames and/or
ignition sources away from the
appliance,
■thoroughly ventilate the room
for several minutes,
■switch off the appliance and
pull out the mains plug,
■inform customer service.
The more refrigerant an
appliance contains, the larger
the room must be in which the
appliance is situated. Leaking
refrigerant can form a
flammable gas-air mixture in
rooms which are too small.
The room must be at least 1 m³
per 8 g of refrigerant. The
amount of refrigerant in your
appliance is indicated on the
rating plate inside the appliance.
If the power cord of this
appliance is damaged, it must
be replaced by the
manufacturer, customer service
or a similarly qualified person.
Improper installations
and repairs may put the user
at considerable risk.

en
4
Repairs may be performed by
the manufacturer, customer
service or a similarly qualified
person only.
Only original parts supplied by
the manufacturer may be used.
The manufacturer guarantees
that only these parts satisfy the
safety requirements.
A extension cable may be
purchased from customer
service only.
Important information when
using the appliance
■Never use electrical
appliances inside the
appliance (e.g. heater, electric
ice maker, etc.). Explosion
hazard!
■Never defrost or clean the
appliance with a steam
cleaner! The steam may
penetrate electrical parts and
cause a short-circuit. Risk
of electric shock!
■Never cover or block the
ventilation openings of the
appliance!
■Do not use pointed or sharp-
edged implements to remove
frost or layers of ice. You
could damage the refrigerant
tubes. Leaking refrigerant may
cause eye injuries or ignite.
■Do not store products which
contain flammable propellants
(e.g. spray cans) or explosive
substances in the appliance.
Explosion hazard!
■Do not stand on or lean
heavily against base
of appliance, drawers
or doors, etc
■For defrosting and cleaning,
pull the mains plug out or
switch off the fuse. Do not pull
out the mains plug by tugging
on the power cord.
■Store high-percentage alcohol
tightly closed and standing up.
■Keep plastic parts and the
door seal free of oil and
grease. Otherwise, parts and
door seal will become
porous.

en
5
■Avoiding placing children
and vulnerable people at
risk:
At risk are children, people
who have limited physical,
mental or sensory abilities, as
well as people who have
inadequate knowledge
concerning safe operation of
the appliance.
Ensure that children and
vulnerable people have
understood the hazards.
A person responsible for
safety must supervise or
instruct children and
vulnerable people who are
using the appliance.
Only children from 8 years
and above may use the
appliance.
Supervise children who are
cleaning and maintaining the
appliance.
Never allow children to play
with the appliance.
■Do not store bottled or
canned drinks (especially
carbonated drinks) in the
freezer compartment. Bottles
and cans may burst!
■Never put frozen food straight
from the freezer compartment
into your mouth.
Risk of low-temperature burns!
■Avoid prolonged touching of
frozen food, ice or the
evaporator pipes, etc.
Risk of low-temperature burns!
Children in the household
■Keep children away from
packaging and its parts.
Danger of suffocation from
folding cartons and plastic
film!
■Do not allow children to play
with the appliance!
■If the appliance features a
lock:
keep the key out of the reach
of children!

en
6
General regulations
The appliance is suitable
■for refrigerating and freezing
food,
■for making ice.
This appliance is intended for
use in the home and the home
environment.
The appliance is suppressed
according to EU Directive 2004/
108/EC.
The refrigeration circuit has
been checked for leaks.
This product complies with
the relevant safety regulations
for electrical appliances
(EN 60335-2-24).
This appliance is intended for
use up to a maximum height of
2000 metres above sea level.
Information concerning
disposal
*Disposal of packaging
The packaging protects your appliance
from damage during transit. All utilised
materials are environmentally safe and
recyclable. Please help us by disposing
of the packaging in an environmentally
friendly manner.
Please ask your dealer or inquire at your
local authority about current means of
disposal.
*Disposal of your old
appliance
Old appliances are not worthless
rubbish! Valuable raw materials can be
reclaimed by recycling old appliances.
m Warning
Redundant appliances
1. Pull out the mains plug.
2. Cut off the power cord and discard
with the mains plug.
3. Do not take out the trays
and receptacles: children are
therefore prevented from climbing in!
4. Do not allow children to play with
the appliance once it has spent its
useful life. Danger of suffocation!
Refrigerators contain refrigerant
and gases in the insulation. Refrigerant
and gases must be disposed
of professionally. Ensure that tubing
of the refrigerant circuit is not damaged
prior to proper disposal.
This appliance is labelled in
accordance with European
Directive 2012/19/EU concerning
used electrical and electronic
appliances (waste electrical and
electronic equipment - WEEE).
The guideline determines the
framework for the return and
recycling of used appliances as
applicable throughout the EU.


en
7
Scope of delivery
After unpacking all parts, check for any
damage in transit.
If you have any complaints, please
contact the dealer from whom you
purchased the appliance or our
customer service.
The delivery consists of the following
parts:
■Free-standing appliance
■Interior fittings (depending on model)
■Bag containing installation materials
■Operating instructions
■Installation manual
■Customer service booklet
■Warranty enclosure
■Information on the energy
consumption and noises
Installation location
A dry, well ventilated room is suitable as
an installation location. The installation
location should not be exposed to direct
sunlight and not placed near a heat
source, e.g. a cooker, radiator, etc. If
installation next to a heat source is
unavoidable, use a suitable insulating
plate or observe the following minimum
distances from the heat source:
■3 cm to electric or gas cookers.
■30 cm to an oil or coal-fired cooker.
The floor of the installation location must
not give way; if required, reinforce floor. If
the floor is uneven, compensate with
supports.
Distance from wall
When installing the appliance, ensure
that the door can be opened by 90°.
Ambient temperature
and ventilation
Ambient temperature
The appliance is designed for a specific
climate class. Depending on the climate
class, the appliance can be operated at
the following temperatures.
The climate class can be found on
the rating plate. Fig. -
Note
The appliance is fully functional within
the room temperature limits
of the indicated climatic class. If
an appliance of climatic class SN
is operated at colder room temperatures,
the appliance will not be damaged up to
a temperature of +5 °C.
Ventilation
Fig. "
The air on the rear panel and on the side
panels of the appliance heats up.
Conduction of the heated air must
not be obstructed. Otherwise,
the refrigerating unit must work harder.
This increases power consumption.
Therefore: Never cover or block
the ventilation openings!
Climate class Permitted ambient
temperature
SN +10 °C to 32 °C
N+16 °C to 32 °C
ST +16 °C to 38 °C
T+16 °C to 43 °C

en
8
Connecting
the appliance
After installing the appliance, wait at least
1 hour until the appliance is switched on.
During transportation the oil in
the compressor may have flowed into
the refrigeration system.
Before switching on the appliance for
the first time, clean the interior of
the appliance (see chapter “Cleaning
the appliance”).
Electrical connection
The socket must be near the appliance
and also freely accessible following
installation of the appliance.
The appliance complies with the
protection class I. Connect the appliance
to 220–240 V/50 Hz alternating current
via a correctly installed socket with
protective conductor. The socket must
be fused with a 10 to 16 A fuse.
For appliances operated in non-
European countries, check whether the
stated voltage and current type match
the values of your mains supply. This
information can be found on the rating
plate. Fig. -
m Warning
Never connect the appliance
to electronic energy saver plugs.
Our appliances can be used with mains
and sine-controlled inverters. Mains-
controlled inverters are used
for photovoltaic systems which
are connected directly to the national
grid. Sine-controlled inverters must be
used for isolated applications (e.g. on
ships or in mountain lodges) which are
not connected directly to the national
grid.
Getting to know your
appliance
Please fold out the illustrated last page.
These operating instructions refer
to several models.
The features of the models may vary.
The diagrams may differ.
Fig. !
* Not all models.
A Refrigerator compartment
B Freezer compartment
1–15 Controls
16* Butter and cheese compartment
17 Shelf for small bottles
18 Shelf for large bottles
19 Light (LED)
20* Bottle shelf
21* Breakfast set
22 Cold storage compartment
23 Vegetable container with
humidity control
24* Frozen food container

en
9
Controls
Fig. $
1Temperature display freezer
compartment
The numbers correspond
to the set freezer compartment
temperatures in °C.
2Display – ALARM –
This lights up if the freezer
compartment is too warm.
3Display superfreeze
This lights up if super freezing is
in operation.
4Display freshness mode
This lights up when the freshness
mode is switched on.
5Eco mode indicator
This lights up when the eco mode
is switched on.
6Display – ALARM –
This lights up if the fridge
compartment becomes too warm.
7Temperature display refrigerator
compartment
The numbers correspond to the
set refrigerator compartment
temperatures in °C.
8Display supercool
This lights up if super cooling is in
operation.
9Display vacation mode
This lights up when the vacation
mode is switched on.
10 Button “lock” function
If this function is switched on, no
settings are possible via
the controls.
11 Button lock/alarm off
This button is used to
■switch off the audible warning
signal (see section "Alarm
function")
■Switch the button lock on and
off.
12 Setting buttons +/-
The buttons are used to set the
temperatures of the refrigerator
and freezer compartment.
13 °C button to select the room
Used to select a room. This is
necessary to change its
temperature or to switch on
certain special functions.
14 Super button
Used to switch on the functions
supercool (fridge compartment)
and superfreeze (freezer
compartment).
15 Button mode
Selecting the special functions.

en
10
Switching the
appliance on
1. First insert the plug into the
connection on the back of the
appliance. Check that the plug has
been inserted all the way.
2. Then insert the other end of the cable
into the socket.
The appliance is now switched on and a
warning signal sounds.
Press the alarm button to switch off the
warning signal.
Display “alarm” goes out when the
appliance has reached the set
temperature.
The preset temperatures are reached
after several hours. Do not put any food
in the appliance beforehand.
The factory has recommended
the following temperatures:
■Freezer compartment: -18 °C
■Refrigerator compartment: +4 °C
Operating tips
■When the appliance has been
switched on, it may take several hours
until the set temperatures have been
reached.
■The fully automatic NoFrost system
ensures that the freezer compartment
remains free of ice. Defrosting is no
longer required.
■The sides of the housing are
sometimes heated slightly. This
prevents condensation in the area of
the door seal.
■If the freezer compartment door
cannot be immediately re-opened after
it has been closed, wait until the
resulting low pressure has equalised.
Setting the
temperature
Fig. $
Refrigerator
The temperature can be set from
+2°C to +8°C.
1. Select the fridge compartment using
the °C button.
2. Keep pressing the +/- buttons until the
required temperature is indicated.
Perishable food should not be stored
above +4 °C.
Freezer compartment
The temperature can be set from
-16°C to -24°C.
1. Select the freezer compartment using
the °C button.
2. Keep pressing the +/- buttons until the
required temperature is indicated.

en
11
Special functions
Fig. $
Fresh mode
Fresh mode gives food an even longer
shelf life.
Switching on:
Press the mode button until thefreshness
mode indicator appears.
The appliance automatically sets
the following temperatures:
■refrigerator compartment: + 2 °C
■Freezer compartment: remains
unchanged
Switching off:
Press the mode button until thefreshness
mode indicator goes off.
Eco mode
The eco mode switches the appliance to
energy-saving operation.
Switching on:
Press the mode button until the "eco
mode" indicator appears.
The appliance automatically sets
the following temperatures:
■cooling compartment: +8°C
■freezer compartment: -16°C
Switching off:
Press the mode button until the "eco
mode" indicator goes off.
Holiday mode
If leaving the appliance for a long
period of time, you can switch
the appliance over to the energy-saving
holiday mode.
The temperature of the refrigerator
compartment is automatically switched
to +14 °C.
Do not store any food in the refrigerator
compartment during this time.
Switching on:
Press the mode button until the vacation
mode indicator appears.
The appliance automatically sets
the following temperatures:
■cooling compartment: +14°C
■freezer compartment: -16°C
Switching off:
Press the mode button until thevacation
mode indicator goes off.
Button lock function
To switch the button lock on and off,
press the lock/alarm off button for
5 seconds.
When the function is switched on, the D
display lights up.
The control panel is now protected
against unintentional operation.
Exception to the button lock:
Thelock/alarm off button can be pressed
to switch off the button lock or if an
audible warning signal sounds.

en
12
Alarm function
In the following cases an alarm may be
actuated.
Door alarm
The door alarm (continuous signal)
switches on,7 appears – ALARM – in the
temperature display of the fridge
compartment if the appliance is left open
for too long. Close the appliance to
switch the door alarm off again.
Temperature alarm
An interval tone sounds, – ALARM –
appears on the temperature display of
the freezer compartment 1.
The temperature alarm switches on if the
freezer compartment is too warm and the
frozen food is at risk of thawing.
The alarm may switch on without any risk
to the frozen food in the following
instances:
■when switching on the appliance for
initial use.
■when large quantities of fresh food are
placed in the appliance.
Note
Do not refreeze thawing or thawed food.
Only ready meals (boiled or fried) may
be refrozen.
No longer store the frozen produce for
the max. storage period.
The temperature display indicates for
5 seconds the warmest temperature
which was reached in the freezer
compartment. Then the set temperature
is displayed again.
Switching off the alarm
Press the lock/alarm off button to switch
off the audible warning signal.
Usable capacity
Information on the usable capacity can
be found inside your appliance on
the rating plate. Fig. -
Fully utilising the freezer
volume
To place the maximum amount of frozen
food in the freezer compartment, you can
remove the containers. You can then
stack the food directly on the shelf and
on the floor of the freezer compartment.
Note
Avoid contact between food and rear
panel. Otherwise the air circulation will
be impaired.
Food or packaging could freeze to
the rear panel.
Removing the fittings
Pull out the frozen food container all
the way, lift at the front and remove.
Fig. *

en
13
Refrigerator
compartment
The refrigerator compartment is the ideal
storage location for meat, sausage, fish,
dairy products, eggs, ready meals
and pastries.
Storing food
■Store fresh, undamaged food. The
quality and freshness will then
be retained for longer.
■In the case of ready-made products
and bottled goods, observe the best-
before date or use-by date specified
by the manufacturer.
■To retain aroma, colour
and freshness, pack or cover food
well before placing in the appliance.
This will prevent the transfer
of flavours and the discolouration
of plastic parts in the refrigerator
compartment.
■Allow warm food and drinks to cool
down before placing in the appliance.
Note
Do not block air outlet openings with
food, otherwise the air circulation will be
impaired. Food which is stored directly
in front of the air outlet openings may be
frozen by the cold air flowing out.
Note the chill zones in the
refrigerator compartment
The air circulation in the refrigerator
compartment creates different chill
zones:
■The coldest zones are in front of the
air outlet openings and in the chill
compartment, Fig. !/22.
Note
Store perishable food (e.g. fish,
sausage, meat) in the coldest zones.
■Warmest zone is at the very top of the
door.
Note
Store e.g. hard cheese and butter in
the warmest zone. The aroma of hard
cheese can then continue to develop
and butter remains spreadable.
Vegetable container with
humidity controller
Fig. (
To create the optimum storage climate
for fruit and vegetables, you can set the
air humidity in the vegetable container
depending on the quantity stored:
■smaller quantities of fruit and
vegetables – high air humidity
■large quantities of fruit and vegetables
– low air humidity

en
14
Notes
■Fruit sensitive to cold (e.g. pineapple,
banana, papaya and citrus fruit) and
vegetables sensitive to cold (e.g.
aubergines, cucumbers, zucchini,
peppers, tomatoes and potatoes)
should be stored outside
the refrigerator at temperatures
of approx. +8 °C to +12 °C for
optimum preservation of quality and
flavour.
■Condensation may form in the
vegetable container depending on the
type and quantity of products stored.
Remove condensation with a dry cloth
and adjust air humidity in the
vegetable container with the humidity
controller.
Cold storage compartment
Fig. )
The cold storage compartment has lower
temperatures than the refrigerator
compartment. Even temperatures below
0 °C may occur.
Ideal for storing fish, meat and sausage.
Not suitable for lettuce and vegetables
and produce sensitive to cold.
The temperature of the chill
compartments can be varied using the
ventilation opening. Push temperature
controller upwards to reduce the
temperature. Push temperature controller
downwards to increase the temperature.
Super cooling
Super cooling sets the refrigerator
temperature to the coldest temperature
setting for approx. 6 hours. Then
the appliance automatically switches
to the temperature set prior to super
cooling mode.
Switch on super cooling mode, e.g.
■before placing large quantities of food
in the refrigerator compartment.
■for the fast cooling of drinks.
Switching on and off
Fig. $
1. Select the cooling compartment using
the °C button.
2. Press the super button until the
supercool display lights up.
You do not need to switch off the super
cooling. After 6 hours, the previously set
temperature is automatically restored.

en
15
Freezer compartment
Use the freezer compartment
■To store deep-frozen food.
■To make ice cubes.
■To freeze food.
Note
Ensure that the freezer compartment
door has been closed properly. If
the door is open, the frozen food will
thaw. The freezer compartment will
become covered in thick ice. Also: waste
of energy due to high power
consumption!
Max. freezing capacity
Information about the max. freezing
capacity within 24 hours can be found
on the rating plate. Fig. -
Prerequisites for max. freezing
capacity
■Switch on super freezing before
placing fresh products
in the compartment (see chapter
entitled “Super freezing”).
■Remove containers; stack food
directly on the shelf and on the floor of
the freezer compartment.
■Freeze large quantities of food
preferably in the very top
compartment where food freezes
particularly quickly and therefore also
gently.
Freezing and storing
food
Purchasing frozen food
■Packaging must not be damaged.
■Use by the “use by” date.
■Temperature in the supermarket
freezer must be -18 °C or lower.
■If possible, transport deep-frozen food
in an insulated bag and place quickly
in the freezer compartment.
Note when loading products
■Preferably freeze large quantities
of food in the top compartment, where
food freezes particularly quickly
and therefore also gently.
■Place the food over the whole area
of the compartments or the frozen
food containers.
Note
Food which is already frozen must not
come into contact with the food which
is to be frozen. If required, move
the frozen food to other frozen food
containers.
Storing frozen food
Insert frozen food container all the way to
ensure unrestricted air circulation.

en
16
Freezing fresh food
Freeze fresh and undamaged food only.
To retain the best possible nutritional
value, flavour and colour, vegetables
should be blanched before freezing.
Aubergines, peppers, zucchini and
asparagus do not require blanching.
Literature on freezing and blanching
can be found in bookshops.
Note
Keep food which is to be frozen away
from food which is already frozen.
■The following foods are suitable for
freezing:
Cakes and pastries, fish and seafood,
meat, game, poultry, vegetables, fruit,
herbs, eggs without shells, dairy
products such as cheese, butter and
quark, ready meals and leftovers such
as soups, stews, cooked meat and
fish, potato dishes, soufflés and
desserts.
■The following foods are not suitable
for freezing:
Types of vegetables, which are usually
consumed raw, such as lettuce or
radishes, eggs in shells, grapes,
whole apples, pears and peaches,
hard-boiled eggs, yoghurt, soured
milk, sour cream, crème fraîche and
mayonnaise.
Packing frozen food
To prevent food from losing its flavour
or drying out, place in airtight containers.
1. Place food in packaging.
2. Remove air.
3. Seal the wrapping.
4. Label packaging with contents
and date of freezing.
Suitable packaging:
Plastic film, tubular film
made of polyethylene, aluminium foil,
freezer containers.
These products are available
from specialist outlets.
Unsuitable packaging:
Wrapping paper, greaseproof paper,
cellophane, bin liners and used
shopping bags.
Items suitable for sealing packaged
food:
Rubber bands, plastic clips, string, cold-
resistant adhesive tape, etc.
Bags and tubular film
made of polyethylene can be sealed
with a film heat sealer.
Shelf life of frozen food
Storage duration depends on the type
of food.
At a temperature of -18 °C:
■Fish, sausage, ready meals and cakes
and pastries:
up to 6 months
■Cheese, poultry and meat:
up to 8 months
■Vegetables and fruit:
up to 12 months

en
17
Super freezing
Food should be frozen solid as quickly
as possible in order to retain vitamins,
nutritional value, appearance and flavour.
Several hours before placing fresh food
in the freezer compartment, switch on
super freezing to prevent an unwanted
temperature rise.
As a rule, 4–6 hours is adequate.
This appliance runs constantly
and the freezer compartment drops to
a very low temperature.
If the max. freezing capacity is to be
used, super freezing must be switched
on for 24 hours before the fresh produce
is placed in the freezer compartment.
Smaller quantities of food (up to 2 kg)
can be frozen without “super freezing”.
Note
When super freezing is switched on,
increased operating noises may occur.
Switching on and off
Fig. $
1. Select the freezer compartment using
the °C button.
2. Press the super button until the
superfreeze display lights up.
3. Press the °C button again.
You do not need to switch off the super
freezing. After approx. 2 ½ days, the
previously set temperature is
automatically restored.
Thawing frozen food
Depending on the type and application,
select one of the following options:
■at room temperature
■in the refrigerator
■in an electric oven, with/without fan
assisted hot-air
■in the microwave
m Caution
Do not refreeze thawing or thawed food.
Only ready meals (boiled or fried) may
be refrozen.
No longer store the frozen produce for
the max. storage period.
Interior fittings
Shelves and containers
You can reposition the inner shelves
and the containers in the door as
required: pull shelf forwards, lower
and swivel out to the side. Lift
the container and remove.
Special features
(not all models)
Breakfast set
Fig. %
The containers for the breakfast set can
be taken out and filled individually.
You can take out the breakfast set for
loading and unloading. To do this, lift the
breakfast set and pull out. The container
holder can be moved.

en
18
Bottle shelf
Fig. &
Bottles can be stored securely on
the bottle shelf.
Ice cube tray
Fig. ,
1. Fill the ice cube tray ¾ full of drinking
water and place in the freezer
compartment.
2. If the ice tray is stuck to the freezer
compartment, loosen with a blunt
implement only (spoon-handle).
3. To loosen the ice cubes, twist the ice
tray slightly or hold briefly under
flowing water.
Freezer calendar
Fig. +
To prevent the quality of the frozen food
from deteriorating, do not exceed the
storage duration. The figures next
to the symbols indicate the permitted
storage period of the produce in months.
In the case of commercially available
frozen food observe the date
of manufacture or use-by date.
Ice block
If a power failure or malfunction occurs,
the ice blocks can be used to slow down
the thawing process. The longest
storage time is obtained by placing
the ice pack on the food in the top
compartment.
The ice blocks can also be used to cool
food temporarily , e. g. in a cold bag.
Sticker “OK”
(not all models)
The “OK” temperature monitor
can be used to determine temperatures
below +4 °C. Gradually reduce
the temperature if the sticker
does not indicate “OK”.
Note
When the appliance is switched on,
it may take 12 hours until
the temperature is reached.
Correct setting
Switching off the
appliance
Press "+" button for 10 seconds.
Refrigeration unit switches off.
Disconnecting the appliance
If you do not use the appliance for
a prolonged period:
1. Pull out the mains plug or switch off
the fuse.
2. Defrost the freezer compartment.
3. Clean the appliance.
4. Leave appliance doors open.

en
19
Cleaning the appliance
m Caution
■Do not use abrasive, chloride or acidic
cleaning agents or solvents.
■Do not use scouring or abrasive
sponges.
The metallic surfaces could corrode.
■Never clean shelves and containers
in the dishwasher.
The parts may become deformed!
The cleaning water must not get into
the following areas:
■Controls
■Illumination
■Ventilation openings
■Openings in the separating plate
Proceed as follows:
1. Pull out the mains plug or switch off
the fuse.
2. Take out the frozen food and store
in a cool location. Place ice pack (if
available) on the food.
3. Wait until the layer of frost has thawed.
4. Clean the appliance with a soft cloth,
lukewarm water and a little pH-neutral
washing-up liquid. The rinsing water
must not drip onto the controls or
light.
5. Wipe the door seal with clear water
only and then wipe dry thoroughly.
6. After cleaning reconnect the
appliance.
7. Put the frozen food back into
the appliance.
Interior fittings
All variable parts of the appliance
can be taken out for cleaning.
Take out shelves in the door
Fig. #
Lift shelves upwards and take out.
Take out glass shelves
Pull the glass shelves forwards and take
out.
Removing the container
Fig. )
Pull out the container all the way, lift at
the front and remove.
Taking out the frozen food container
Fig. *
Pull out the frozen food container all
the way, lift at the front and remove.
Light (LED)
Your appliance features a maintenance-
free LED light.
These lights may be repaired
by customer service or authorised
technicians only.

en
20
Tips for saving energy
■Install the appliance in a dry, well
ventilated room! The appliance should
not be installed in direct sunlight
or near a heat source (e.g. radiator,
cooker).
If required, use an insulating plate.
■Allow warm food and drinks to cool
down before placing in the appliance.
■Thaw frozen food in the refrigerator
compartment and use the low
temperature of the frozen food to cool
refrigerated food.
■Open the appliance as briefly as
possible.
■To achieve the lowest energy
consumption, leave a small wall gap
at the side.
■The arrangement of the fittings does
not affect the energy rating of the
appliance.
Operating noises
Quite normal noises
Droning
Motors are running (e.g. refrigerating
units, fan).
Bubbling, humming or gurgling noises
Refrigerant is flowing through the tubing.
Clicking
Motor, switches or solenoid valves are
switching on/off.
Cracking
Automatic defrosting is running.
Preventing noises
The appliance is not level
Please align the appliance with a spirit
level. Use the height-adjustable feet
or place packing underneath them.
The appliance is not free-standing
Please move the appliance away
from adjacent units or appliances.
Containers or storage areas wobble
or stick
Please check the removable parts
and re-insert them correctly if required.
Bottles or receptacles are touching
each other
Move the bottles or receptacles slightly
away from each other.
