7/8" ROTARY HAMMER
Model 0611221539
INDUSTRIAL
January 1998 11221DVS
S-B Power Tool Company Chicago IL 60646-5999
pos. 832
disassembly alignment
(depress button 49 fully)
49
720
123
ø43mm
122
121
M8
120
21/1
21/3
85 821
2
94
D
B
AC
10
9
808
1
35
49
83
832
76
88
34 87
39 89 40 82
833
85 38 85 80
22
90
Torx
T
-20
70 60
61 43 96
819
Y
33
126 113
108
130
5
6
7
5/1
4
95
B
C
102
92
91
17
45
67
823
63
64
830
62
824
844
Y
48
865 65/1
65/2
42
77
72
81
820
M
12
CORD
Z
27 73
29
26
41
86
75
71
28
74 37
85
21/3
21/1
821
Z
V
653
connects to
1 618 190 006,
dust extractor
628
V
729
729/5
729/3
729/1
729/6
X
119 761
connects to vacuum cleaner
X
651
14118 115
109
3/6
13
803
811
101
D
101
93
A
16
125
107
131
119
847
X
865

89 1 903 230 013 Ball 7mm 86
90 1 613 410 004 Screw {4} 89
91 2 910 611 082 Screw 89
92 2 910 611 020 Screw {4} 89
93 2 910 611 006 Screw {4} 89
94 2 603 435 015 Screw {2} 89
95 2 603 410 001 Screw {2} 89
96 2 910 611 018 Screw 89
101 1 614 448 017 Cable 60mm {2} 10
102 2 604 448 005 Cable 130mm {2} 10
107 1 615 190 042 Fan Housing 73
108 1 615 190 044 Intermediate Plate 38
109 1 615 190 043 Air Deflector 24
113 1 611 038 017 Locking Plate 65
115 1 616 610 074 Dust Fan 23
118 2 916 130 027 Gasket 79
119 1 610 210 045 O-Ring {2} 78
120 1 612 025 019 Auxiliary Handle 9
121 1 618 040 048 Clamp Holder 80
122 1 613 490 002 T-Bolt 80
123 1 611 316 006 Clamping Band 43mm 80
125 2 910 001 168 Screw {4} 89
126 1 613 435 005 Screw {4} 89
130 1 611 110 640 Label "Caution" 9
131 1 611 015 039 Gasket 79
628 1 610 712 042 Dust Extractor Hose 9
651 1 615 703 010 Hose Coupling 9
653 1 610 591 008 Dust Port Plug 9
720 1 612 025 032 Auxiliary Handle Assy. 9
w/pos. 120, 121, 122, 123
729 2 605 411 044 Dust Bag Assembly 9
w/pos. 729/1-729/6
729/1 1 615 190 046 Bag Support 9
729/3 1 612 386 001 Bag Clip 9
729/5 1 619 200 409 Bag Retainer Ring 9
729/6 1 610 121 001 Gasket 9
761 1 610 793 002 Vacuum Hose 9
803 1 614 010 200 Armature w/Fan 120V AW
w/pos. 3/6, 13, 14, 109,
115, 118
808 1 611 104 999 Nameplate 9
811 1 617 014 127 Brush Set 26
819 1 615 806 093 Gear Cover Assembly 70
w/pos. 43, 60, 61, 70, 96
820 1 617 000 981 Gear Housing Assembly 72
w/pos. 42,65/1,65/2,72,77,865
821 1 616 490 061 Guide Tube Assembly 43
w/pos. 21/1, 21/3, 85
823 1 616 328 042 Gear w/pos. 63 34
824 1 613 060 021 Pinion Gear w/pos. 67 54
830 1 615 819 018 Eccentric Cam w/pos. 62 53
832 1 612 026 037 Selector Knob Assembly 64
w/pos. 49, 76, 83
833 1 617 000 163 Bit Retaining Assembly 86
w/pos. 33,34,39,40,82,87,89
844 1 615 820 092 Shift Fork w/pos. 45 63
847 1 617 000 348 Guide Bushing Assembly 49
865 1 610 591 016 Bushing Assy. w/pos. 81 82
1 1 615 108 061 Motor Housing 71
2 2 604 220 439 Field 120V 22
3/6 1 616 610 073 Fan 23
4 1 617 200 052 Switch VS 17
5 3 604 460 555 Cord 120V 18/2 11
5/1 1 900 452 012 Terminal Sleeve {2} 11
6 2 600 703 018 Strain Relief 11
7 2 601 035 001 Cord Clamp 89
9 2 610 906 839 Label "11221DVS" 9
10 2 610 906 857 Label "Caution" 9
13 2 600 905 032 Ball Bearing 60
14 1 610 905 006 Ball Bearing 61
16 1 614 336 025 Brush Holder w/Spring {2} 25
17 1 615 132 054 Handle Cover 74
21/1 1 613 100 019 Pin {3} 66
21/3 1 610 190 022 Clutch Disc 67
22 1 616 317 602 Gear 32
26 1 618 700 062 Piston 47
27 1 618 710 057 Striker 44
28 1 613 124 040 Impact Bolt 45
29 1 613 105 012 Wrist Pin 47
33 1 610 499 012 Plastic Sleeve 92
34 1 610 508 008 Dust Shield 92
35 1 610 206 021 Rubber Bearing Sleeve 82
37 1 610 390 017 Damping Bushing 49
38 1 610 102 026 Washer 67
39 1 610 102 025 Thrust Ring 86
40 1 610 190 011 Holding Plate 86
41 1 610 101 011 Washer {2} 47
42 1 610 202 015 Bushing 51
43 1 611 098 005 Locking Plate 65
45 1 614 651 014 Spring Clip 63
48 1 611 016 003 Holding Fork 62
49 1 612 026 035 Button 64
60 1 610 910 073 Needle Bearing 51
61 2 600 910 006 Needle Bearing 56
62 1 610 910 074 Needle Bearing 56
63 2 600 914 010 Needle Bearing 56
64 1 610 913 010 Needle Bearing 56
65/1 1 610 590 007 Bushing 82
65/2 1 610 109 016 Gasket 79
67 1 610 905 016 Ball Bearing 56
70 1 610 283 019 Seal 77
71 1 610 290 029 Scraper 49
72 1 610 210 068 O-Ring 78
73 1 610 210 119 O-Ring 44
74 1 610 210 104 O-Ring 78
75 1 610 210 105 O-Ring 78
76 1 610 210 046 O-Ring 78
77 1 610 210 106 Gasket 79
80 1 614 634 005 Clutch Spring 67
81 1 614 611 009 Spring 27
82 1 614 643 003 Spring 86
83 1 614 611 006 Spring 27
85 1 614 601 011 Spring Ring {3} 89
86 1 614 601 012 Spring Ring 89
87 2 916 540 012 Spring Ring 86
88 1 613 200 007 Pin {3} 66
+ = Not Illustrated * = As Required F/C = Failure Code AW = Refer to AW Labor Time Chart
F/CPos. Part Number Description {Qty} Pos. Part Number Description {Qty}
11221DVS 7/8" ROTARY HAMMER
