59 2 610 320 173 Screw 89
60 2 610 023 331 Washer 65
61 2 610 025 067 Washer 65
62 2 610 329 929 Screw 89
63 2 610 329 955 Screw {2} 89
64 2 610 341 365 Screw {3} 89
65 2 610 306 355 Lock Washer {2} 65
66 2 610 319 932 Hinge Pin 66
67 2 610 325 655 Locking Pin 81
68 2 610 353 799 Screw {4} 89
69 2 610 356 026 Lock Nut 89
70 2 610 044 639 O-Ring 78
71 2 610 027 002 Screw {5} 89
72 2 610 911 837 Bolt 89
73 2 610 004 459 Spring Washer 27
74 2 610 023 335 Expansion Chamber 79
75 2 610 025 245 Oil Seal 77
76 2 610 004 521 Spring Washer 65
77 2 610 017 016 Washer 65
78 2 610 329 927 Oil Seal 77
79 2 610 993 549 Screw {2} 89
80 2 610 328 924 Screw 89
81 2 610 329 950 Screw {2} 89
82 2 610 023 334 Gasket 79
83 2 610 350 005 Plug 9
84 2 610 318 324 Nut 89
86 2 610 329 953 Screw {4} 89
90 2 610 325 089 Bearing Cover 70
91 2 610 353 289 Screw {4} 89
92 2 610 992 206 Screw {2} 89
93 2 610 968 746 Nut {2} 89
107 2 610 911 889 Set Screw 89
109 2 610 911 491 Hook 9
110 2 610 911 492 Bracket 9
111 2 610 341 288 Bushing 82
112 2 610 911 493 Spring 27
113 2 610 020 387 Roll Pin 66
114 2 610 911 890 Screw {2} 89
651 2 610 000 266 Wrench 9
804 2 610 321 608 Switch 15
805 2 610 914 296 Cord w/pos. 41 11
810 2 610 912 980 Brush Set 26
819 2 610 996 624 Foot Assembly w/pos.107 88
834 2 610 357 524 Gear/Shaft Assembly 32
1 2 610 906 405 Motor Housing 71
2 2 610 907 821 Field 120V 22
3 2 610 329 931 Armature 120V AW
6 2 610 005 970 Strain Relief 11
7 2 610 320 492 Cord Clamp 89
8 2 610 911 457 Nameplate 9
13 2 610 993 520 Ball Bearing 60
14 2 610 024 748 Ball Bearing {2} 61
18 2 610 901 971 Screw 89
21 2 610 906 401 Gear Housing 33
22 2 610 911 489 Cover 92
23 2 610 352 118 Inner Flange 91
24 2 610 901 964 Outer Flange 91
25 2 610 023 384 Oil Plug 9
26 2 610 000 050 Blade Bolt 85
27 2 610 315 286 Stud 89
28 2 610 911 146 Lower Guard 92
30 2 610 911 147 Handle 74
31 2 610 017 875 Ball Bearing 60
32 2 610 015 726 O-Ring 78
33 2 610 911 148 Spring 27
35 2 610 319 494 Rubber Stop 9
36 2 610 341 359 Retaining Ring 89
37 2 610 023 394 Spring 27
38 2 610 911 149 Upper Guard 91
39 2 610 911 213 Lift Lever 64
40 2 610 911 490 Top Handle 74
41 2 610 316 596 Terminal {3} 10
42 2 610 352 115 Retaining Plate 65
43 2 610 352 091 Guard Plate 92
44 2 610 023 324 Bushing 66
45 2 610 023 336 Cover Plate 70
46 3 603 463 500 Brush Cap {2} 25
47 2 610 044 638 O-Ring 78
48 2 610 023 330 Collar 77
50 2 610 329 940 Brush Holder {2} 25
51 2 610 004 341 Washer 65
52 2 610 912 616 Washer {3} 65
53 2 610 968 747 Retaining Ring {2} 89
54 2 610 968 745 Locking Lever {2} 64
55 2 610 000 166 Ball Bearing 56
56 2 610 027 039 Set Screw {2} 89
57 2 610 315 299 Screw {4} 89
58 2 610 315 380 Screw {5} 89
Pos. Part Number Description {Qty.} F/C Pos. Part Number Description {Qty.} F/C
+ = Not Illustrated * = As Required F/C = Failure Code AW = Refer to AW Labor Time Chart
Service Notes:
1677M 7-1/4" CIRCULAR SAW
Pos. 84: Torque nut to 100 in/lbs. then back off 1/4 turn.
