Bosch AN traffic 4000 IR User manual

en User Manual
AN trafc 4000 IR
960H IR License Plate Bullet Camera

Bosch Security Systems User Manual 2012.11
2 en | Table of Contents 960H IR License Plate Bullet Camera
Table of Contents
1 Cautions
2 Important safety instruction
3Features
4Components
5Camera parts
6Installation
6.1 Mounting position
6.2 Monitor connection
7 Installation guideline
7.1 Camera height
7.2 Camera angles
7.3 Capture zone
7.4 Lane width
7.5 Speed
8Camera conguration
9 OSD menu structure
10 Specication
10.1 Dimensions

Bosch Security Systems User Manual 2012.11
960H IR License Plate Bullet Camera Cautions | en 3
1 CAUTIONS
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions;
1. This device may not cause harmful interference.
2. This device must accept any interference received,
including interference that may cause undesired operation.
Note!
This equipment has been tested and found to comply with the limits
for a Class A digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area
is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.”
WARNING
This is a class A product. In a domestic environment this product may
cause radio interference in which case the user may be required to
take adequate measures.
CAUTION!
Any changes or modications in construction of this devies which are
not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
CAUTION!
1. A regulated DC12V 500mA power supply is recommended for use with
this camera for the best picture and the most stable operation.
An unregulated power supply can cause damage to the camera.
When unregulated power supply is applied, product warranty will be
out of subject.
2. It is recommended that the camera is used with a monitor that has a
CCTV quality 75 video impedance level. If your monitor is switched to high
impedance then please adjust accordingly.
3. Do not attempt to disassemble the camera to gain access to the internal
components. Refer servicing to your dealer.
4. Never face the camera towards the sun or any bright or reective light,
which may cause smear on the picture and possible damage to the CCD.
5. Do not remove the serial sticker for the warranty service.
6. Do not expose the camera to rain or other types of liquid.
7. The apparatus must be connected to a mains socket-outlet with a
protective earthing connection.

Bosch Security Systems User Manual 2012.11
4 en | Cautions 960H IR License Plate Bullet Camera
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European countries with
separate collection systems)
This marking shown on the product or its literature, indicate that
it should not be disposed with other household wastes at the end
of its working life. To prevent possible harm to the environment or
human health from uncontrolled waste disposal, please separate this
from other types of wastes and recycle it responsibly to promote the
sustainable reuse of material resources.
This product should not be mixed with other commercial wastes
purchased this product, or their local government ofce, for details of
where and how they can take item for environmentally safe recycling.
Business users should contact their supplier and check the terms and
conditions of the purchase contract.
Household users should contact either the retailer where they for
disposal.
CAUTION
RISK OF ELECTRIC SHOCK DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER(OR BACK). NO USER. SERVICING
TO QUALIFED SERVICE PERSONNEL.
This symbol is intended to alert the user to the presence of
uninsulated “dangerous voltage” within the product’s enclosure
that may be of sufcient mangnitude to constitute a risk of
electric shock to persons.
This symbol is intended to alert the user to the presence of
important operating and maintenance(servicing) instruction in
the literature accompanying the appliance.
CAUTION!
These servicing instructions are for use by qualied service personnel
only. To reduce the risk of electric shock do not perform any servicing
other than that contained in the operating instructions unless you are
qualied to do so.
Use Class 2 Power Supply Only

Bosch Security Systems User Manual 2012.11
960H IR License Plate Bullet Camera Important safety instructions | en 5
2 Important safety instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with
the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including ampliers) that
produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-
type plug. A polarized plug has two blades with one wider than
the other. A grounding type plug has two blades and a third
grounding prong. The wide blade or the third prong are provided
for your safety. If the provided plug does not t into your outlet,
consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
11. Only use attachments/accessories specied by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specied
by the manufacturer, or sold with the apparatus. When a cart is
used, use caution when moving the cart/apparatus combination
to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for
long periods of time.
14. Refer all servicing to qualied service personnel. Servicing is
required when the apparatus has been damaged in any way, such
as power-supply cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has
been dropped.

Bosch Security Systems User Manual 2012.11
6 en | Features/Components 960H IR License Plate Bullet Camera
3Features
The camera has the following features:
•
•
•
•
•
•
•
•
•
1/3" 960H SONY EXview HAD CCD ll
720 TV Lines Horizontal Sensor Resolution.
Adjustable high power IR beam in combination with special light lter
technology for reliable license plate capturing in all lighting and weather
conditions.
5~50mm varifocal lens providing variable capture range of 4.8 to 27
meters. (16 to 91 feet)
Multi language On Screen Display (OSD) with joystick control.
Plate capture up to 120 km/h (75 mph)External lens adjustment.
Cable managed bracket for secure and clean installation.
Vandal resistant (IK08)
Outdoor rated (IP66)
NOTICE! This product works only in countries where license plates have a reective
coating. License plates without a reective coating will not be visible.
Capture range, speed and quality depends on the character font and size
used on the license plate. Performance may be degraded by license plates
with a poor coating/printing or dirt. Vibration or shaking of the camera will
also degrade the performance, especially with a long capture distance. Make
sure the camera is mounted with suitable mounting materials on a stable
surface, and shorten the capture distance where possible.
4 Components
Qty Description Qty Description
1
VLR-4075-V5x1
camera with
integrated
mounting bracket
1Wrench
(M6 hex)
1Video Output
Test Cable 1 Guide Pattern
4
Screws
(PH/1(SUS)
5x30)
1User Manual
(this booklet)

Bosch Security Systems User Manual 2012.11
960H IR License Plate Bullet Camera Camera parts | en 7
5 Camera parts
1
2
3
4
5
Sunshield Fixing Bolt
Sunshield
Housing Front
Housing Body
Housing Back
6
7
8
9
Mounting Bracket
Lens Knob
LED
Lens
➊
➍➌ ➎
➐ ➒➑
➋ ➏
OSD joystick
Service cable connector
After lens adjustment, fasten the zoom and focus knob tightly
to prevent water ingress.
After using the OSD joystick or Service cable connector,
check rubber seal is in place on the protection cap, close and
rmly tighten it to prevent water ingress.

Bosch Security Systems User Manual 2012.11
8 en | Installation 960H IR License Plate Bullet Camera
6 Installation
6.1 Monitor connection
To prevent injury, this apparatus must be securely attached to
the oor/wall in accordance with the installation instructions.
NOTICE! The image sensors in modern cameras are highly sensitive and require special
care for proper performance and extended lifetime. Follow the guidelines for
optimum results with your camera:
– Do not expose to direct sunlight or bright spotlights in operating and
nonoperating conditions.
– Avoid bright lights in the eld of view of the camera. Bright lights cause
a “smearing” effect, which is visible as white lines above and below the
highlight. Prolonged exposure to bright lights may cause bleaching of the
sensor's color lters. This will be visible as colored spots in the picture
and is irreversible.
WARNING! The mounting surface, mounting screws/plugs, and junction box must be
stable and capable of supporting a maximum load of 10kg (22 pounds).
Mounting to an improper surface or using improper mounting material can
cause camera malfunction and is a potential safety hazard.
WARNING! Make sure that appropriate mounting screws and anchors are used for the
surface to which the camera is mounted. The supplied universal mounting
screws can be used with most plastic anchors, please conrm compatibility
before mounting the camera.
CAUTION! To prevent humidity problems, the camera must be installed in dry conditions,
and the cable leads should be sealed after they are connected.
* 3rd Axis
360°
* 1st Axis
360°
90°
* 2nd Axis

Bosch Security Systems User Manual 2012.11
960H IR License Plate Bullet Camera Installation | en 9
6 Installation
6.2 Monitor connection
6.3 Camera adjustment
CAUTION! To prevent humidity problems, the camera must be installed in
dry conditions. The lens knobs (located on the bottom of the camera)
and protection cap (located on the rear of the camera) provide protection
against water ingress when fully tightened. Therefore never remove or keep
them loosened after installation. Doing so could cause water ingress and/or
condensation on the inside of the camera window
1.
2.
3.
4.
5.
6.
7.
8.
Open the protection cap on the rear of the camera (only needed to access
service monitor connection and OSD control)
Connect service monitor (optional)
Loosen the zoom and focus knob
Adjust zoom and focus
Fasten the zoom and focus knob tightly
Adjust OSD settings (refer to Camera Conguration section)
Disconnect service monitor cable (optional)
Check rubber seal is in place on the protection cap. Close and rmly tighten
the protection cap on the rear of the camera.
DUAL(DC12V/AC24V) Regulated Power Supply
DUAL (DC12V/AC24V)
*Sold separately
Video In
TV Monitor
Camera
Female
BNC connector
Ground contact
Signal contact
Terminal block
Terminal block connector
Screw
Terminal
"+","-" Indication
 2.6x3.2
(0.1x0.12)
10.16
(0.4)
5.08(0.2)
15.4(0.6)
18.2(0.71)
mm
(in.)

Bosch Security Systems User Manual 2012.11
960H IR License Plate Bullet Camera Installation guideline | en 10
7 Installation guideline
7.1 Camera height
• The camera has a 5~50mm varifocal lens providing variable capture
range of 4.8 to 27 meters (16 to 91 feet)
• The camera height (the height where the camera is mounted) must
be considered when determining capture distance.
Below table illustrates how the camera height inuences the capture distance
(camera height and horizontal distance are examples).
Camera height (m/ft) Horizontal Distance (m/ft) Capture Distance (m/ft)
1 / 3.3 4 / 13.1 4.1 / 13.5
1.5 / 4.9 4 / 13.1 4.3 / 14.1
2 / 6.6 4 / 13.1 4.5 / 14.8
2.5 / 8.2 4 / 13.1 4.7 / 15.4
3 / 9.8 4 / 13.1 5 / 16.4
7.2 Camera angles
• It is advised to mount the camera at a horizontal and vertical angle of less than
30 degrees. A greater angle will distort the characters of the license plate and will
reduce the capture performance. If the mounting position is xed, the capture angle
can be reduced by increasing the capture distance.
H-angle less than 30˚V-angle less than 30˚

Bosch Security Systems User Manual 2012.11
11 en | Installation guideline 960H IR License Plate Bullet Camera
7 Installation guideline
Below table illustrates how the camera height inuences the capture distance
(camera height and horizontal distance are examples).
Camera height (m/ft) Horizontal Distance (m/ft) V-angle (º)
1 / 3.3 4 / 13.1 14
1.5 / 4.9 4 / 13.1 21
2 / 6.6 4 / 13.1 27
2.5 / 8.2 4 / 13.1 32 (exceeds the advised
mounting angle)
3 / 9.8 4 / 13.1 37(exceeds the advised
mounting angle)
7.3 Capture zone
- Wide angle provides shorter capture distance and increased capture angle,
but could result in the better image quality and stability.
- Tele angle provides longer capture distance and reduced capture angle,
but could result in reduced image quality and stability.
- While a license plate can still be read by human eye, license plate
capture software might not be able to recognize it.
License plate readable
by human eye
WIDE END -66.5 @ f=5mm
TELE END -7.4 @ f=50mm
WIDE SETTING -66.5 @ f=5mm
TELE SETTING -7.4 @ f=50mm
o
o
What will be the plate look like on screen?
(All scenes taken with high-beam)
Position "A" with WIDE SETTING
Position "B" with TELE SETTING
License plate readable by
license plate
capture software
Position "B" with WIDE SETTING
Position "C" with TELE SETTING
5M 10M 15M 20M 25M 30M

Bosch Security Systems User Manual 2012.11
960H IR License Plate Bullet Camera Installation guideline | en 12
7.4 Lane width
• Narrow lanes = less variation in plate location.
• Wider lanes = more variation in plate location.
• Lens should cover entire width of the lane.
• Ensure horizontal eld of view is wide enough.
7.5 Speed
• Camera can capture moving vehicles up to 120 km/h (75 mph).
• Keep camera as low as possible.
• Minimize horizontal angle.
• Zoom in the lens as close as possible.
Up to 75 mph

Bosch Security Systems User Manual 2012.11
13 en | OSD menu structure 960H IR License Plate Bullet Camera
8Camera conguration
After the camera is properly installed, the focus and zoom should be adjusted,
and OSD menu should be congured to optimize the camera's performance. To
enter the OSD menu, press the OSD joystick located on the rear of the camera.
Step1: The rst time the camera is turned on, the camera is in installation mode. In this mode,
the camera will display the complete monochrome picture (not only the license plate).
This will help to correctly aim and focus the camera on the target object. If the camera
is not in installation mode, change MODE from LICENSE-PLATE to INSTALLATION in the
OSD menu.
Step2: Adjust the zoom and focus (and camera position if needed) to the target object.
Step3: Change the camera mode from INSTALLATION to LICENSE-PLATE in the OSD menu. In
this mode, the camera will only display reective objects such as the license plate.
Step4: Adjust the SHUTTER value (= shutter speed) in order to prevent over- or underexposure
of the license plate. In applications with short capture distance, the IR intensity may be
reduced by lowering the LED level in the OSD menu to further prevent overexposure.
Note that if the camera is installed outdoors, the license plate image may be slightly
different during daytime and nighttime. This effect will increase when lowering the LED
level, or when using a long capture distance.
Step5: If required, the image may be inverted by turning on NEGATIVE in the OSD menu.
In negative mode, light areas in the image will appear dark and vice versa. In some
applications this may improve the readability of the license plate.
Step6: Exit the OSD menu.
9 OSD menu structure
MAIN MENU 1st Sub
MODE INSTALLATION
LICENSE-PLATE
SHUTTER
---- (INSTALL MODE)
1/250, 1/500,
1/1000~1/10000 (adjusted 1/500sec measure)
1/30K,1/50K,1/70K,
1/90K, 1/100K
NEGATIVE OFF
ON
LED LEVEL 0~10
LANGUAGE English, Russian, Spanish, German, French, Portuguese
EXIT
* SHUTTER: adjusted when LICENSE-PLATE MODE is performed.

Bosch Security Systems User Manual 2012.11
14 en | Specication 960H IR License Plate Bullet Camera
10 Specication
Model VLR-4075-V521(NTSC) VLR-4075-V511(PAL)
Image Device 1/3" 960H SONY EXview HAD CCD ll
Scanning System 2 : 1 Interlace
Scanning Frequency 15.734 KHz(H),59.94 Hz(V) 15.625 KHz(H), 50 Hz(V)
H. Sensor Res. 720TVL
Actual H. Res. 620TVL
Total Pixels 1028(H) x 508(V) 1028(H) x 596(V)
Effective Pixels 976(H) x 494(V) 976(H) x 582(V)
S/N Ratio More than 50dB (AGC Off)
Min. Illumination 0 Lux (IR LED On)
Sync. System Internal
Gamma r = 0.45
Video Output 1.0 Vp-p Composite (75Ω)
Lens Varifocal Auto IRIS & DC Lens Built-in
Lens focal length 5~50mm
Aperture F1.4~360
Lens adjustment External
Electronic Shutter 1/250 ~ 1/100,000
Function Installation Mode, License Plate Mode, Shutter speed
Changeable, Focus Adjust Mode, Negative Image
Language English, Russian, Spanish,
German, French, Portuguese
OSD Built-in
OSD Control External
IR LED 850 nm, up to 28 m
IP Rating IP66 (Water resistant)
Operating Temperature -30 ºC to +50 ºC (-22 ºF to +122 ºF)
Storage Temperature -20˚C to +60˚C (-4˚F to +140˚F)
Power Consumption Dual : DC12V(±10%), Max. 600 mA /
AC24V(±10%), Max. 7.7 W
Cable
Management Bracket Yes
Video interface 1 standard BNC connector for analog output
Weight Approx. 1.9kg(including bracket)
Housing material Casted/machined Aluminium
Paint color White RAL9003
Vandal resistant Yes (IK08)
Outdoor rated Yes (IP66)

Bosch Security Systems User Manual 2012.11
960H IR License Plate Bullet Camera Dimensions | en 15
10-1 Dimensions
160(6.29)
173(6.85)
150(5.9)
mm
(in.)
Ø110(4.33)
Ø95(3.74)
4-Ø6.0(0.23)
Approx. 310(12.2)

Bosch Security Systems
www.boschsecurity.com
(c) Bosch Security Systems, 2013
