FlexiDome Cameras Quick Guide
FlexiDome I
Series
FlexiDome II
Series FlexiDomeVF FlexiDomeXT+ FlexiDomeXF FlexiDomeDN
Imaging Features Image sensor type 1/4” Interlaced CCD 1/4” Interlaced CCD 1/3” Interlaced CCD 1/3” Interlaced CCD 1/3” Interlaced CCD 1/3” Interlaced CCD
Color models Yes Yes Yes Yes Yes Yes
Monochrome models Yes Yes Yes Yes No No
Day/Night — NightSense No No Yes Yes Yes Yes
Day/Night — IR sensitive (removable IR filter) No No No No No Yes
XF-Dynamic - Extended dynamic range No No No No 32x range 32x range
SensUp - Enhanced sensitivity No No No No Yes Yes
Automatic gain control (AGC) Yes Yes Yes Yes Yes Yes
Backlight compensation (BLC) Yes Yes Yes Yes Yes (programmable area) Yes (programmable area)
Automatic white balance (color models) Auto/Hold Auto/Hold Auto/Hold Auto/Hold Auto/Hold/Manual Auto/Hold/Manual
AutoBlack No No Yes Yes Yes Yes
Dynamic Noise Reduction (DNR) No No No No Yes Yes
Video motion detection No No No No Yes (Multizone) Yes (Multizone)
Resolution Maximum resolution (color) 330 TVL 470 TVL 540 TVL 540 TVL 540 TVL 540 TVL
Maximum resolution (monochrome) 380 TVL 570 TVL 570 TVL 570 TVL 540 TVL 540 TVL
Sensitivity (lux) Color 2.0 (F2.0, 30 IRE) 2.0 (F2.0, 30 IRE) 0.44 * 0.44 * 0.16 (F1.0, 30 IRE) 0.32 *
Color w/NightSense or Day/Night N/A N/A 0.18 * 0.18 * 0.056 (F1.0, 30 IRE) 0.11 *
Color w/SensUp N/A N/A N/A N/A 0.016 (F1.0, 30 IRE) 0.032 *
Monochrome 0.3 (F2.0, 30 IRE) 0.3 (F2.0, 30 IRE) 0.09 (F1.4, 30 IRE) 0.09 (F1.4, 30 IRE) N/A N/A
Lenses Focal length/F-stop
2.1mm, f/2.0
3.0mm, f/2.0
6.0mm, f/2.0
2.1mm, f/2.0
3.0mm, f/2.0
6.0mm, f/2.0
2.6 - 6.0mm, f/1.4
4.0 - 9.0mm, f/1.6
2.6 - 6.0mm, f/1.4
3.7 - 12.0mm, f/1.6
3.0 - 9.5mm, f/1.0
3.7 - 12.0mm, f/1.6 3.0 - 9mm, f/1.4
Housing and Power Impact rating Low impact Low impact Low impact 100lbs. direct force 100lbs. direct force 100lbs. direct force
Ingress rating No No No IP66/NEMA 4X IP66/NEMA 4X IP66/NEMA 4X
Tamper-proof No No No Yes Yes Yes
Temperature range (operating) 14 – 113˚F 14 – 113˚F 14 – 113˚F -58 – 122˚F -58 – 122˚F -58 – 122˚F
Voltage range 12 to 28 VDC
12 to 28 VAC
12 to 28 VDC
12 to 28 VAC
10.8 to 39 VDC
12 to 28 VAC
10.8 to 39 VDC
12 to 28 VAC
10.8 to 39 VDC
12 to 28 VAC
10.8 to 39 VDC
12 to 28 VAC
Power consumption 2W for all voltages 2W for all voltages 4W for all voltages 6W for all voltages 6W for all voltages 6W for all voltages
Installation/Service Bilinx remote configuration tool No No Yes Yes Yes Yes
On-screen display No No Yes Yes Yes Yes
Focus aid No No Yes Yes Yes Yes
Lens focus wizard No No Yes Yes Yes Yes
Service monitor output No No Yes Yes Yes Yes
Warranty Coverage period 3 years 3 years 3 years 3 years 3 years 3 years
* (F1.4 Lens, 89% reflectance,30 IRE)

part # F01U500968D
FlexiDome Cameras Quick Guide
* For surface-mount kits, add an "S" to the end of the part number (example: VDC-445V04-20S)
** For PAL versions, change the -20 to -10 (example: VDC-455V04-10)
Dome Camera Type Resolution Lens Option
540 TVL
3.7-12.0mm f/1.6
3.7-12.0mm f/1.6
Day/Night
XF-Dynamic†
3.7-12.0mm f/1.6
Vandal-resistant
Color
2.1mm f/2.0
3.0mm f/2.0
570 TVL
380 TVL
6.0mm f/2.0
Monochrome
2.1mm f/2.0
3.0mm f/2.0
6.0mm f/2.0
2.1mm f/2.0
Low ImpactFixed Lens
3.0mm f/2.0
470 TVL
330 TVL
6.0mm f/2.0
2.1mm f/2.0
3.0mm f/2.0
6.0mm f/2.0
2.6-6.0mm f/1.4
570 TVL
Low Impact
4.0-9.0mm f/1.6
Monochrome
2.6-6.0mm f/1.4
2.6-6.0mm f/1.4
Monochrome
Color
3.0-9.5mm f/1.0
Color
XF-Dynamic†
Color 540 TVL
2.6-6.0mm f/1.4
4.0-9.0mm f/1.6
570 TVL
540 TVL
540 TVL
NTSC** P/N
VDM-355V04-20*
LTC-1311/20
LTC-1312/20
LTC-1313/20
LTC-1321/20
LTC-1322/20
LTC-1323/20
LTC-1411/20
LTC-1412/20
LTC-1413/20
LTC-1421/20
LTC-1422/20
LTC-1423/20
VDM-345V03-20*
VDM-345V04-20*
VDC-445V03-20*
VDC-445V04-20*
VDM-355V03-20*
VDC-455V03-20*
VDC-455V04-20*
VDC-485V03-20*
VDC-485V04-20*
VDN-495V03-20*3.0-9.0mm f/1.4
Varifocal Lens
Camera Selection Chart Optional Mounts
Pendant Wall Mount
VDA-445WMT
Pendant Pipe Mount
VDA-455PMT
Corner Wall Mount
VDA-455CMT
Hardware and Accessories
Power Supplies
TC1323 Input; 120 VAC. 60Hz, Single Output; 24
VAC, 10 VA
TC1334 Input; 120 VAC. 60Hz, Single Output; 24
VAC, 30 VA
Surface Mount Box
VDA-445SMB Surface mount box for FlexiDomeVF
VDA-455SMB High impact surface mount box for
FlexiDomeXT+, XF, DN
UTP Adapter
VDA-455UTP
Converts BNC/Coax to UTP for transmission
of composite video over Cat5/Cat5e/Cat6
UTP cabling
Service/Monitor Cable
S1460 1-meter 2.5mm connector to BNC
(FlexiDomeVF,XT+, XF, DN)
Bilinx Configuration Tool
VP-CFGSFT Setup and configure cameras over the video
cable (FlexiDomeVF,XT+, XF, DN)
† wide dynamic range
FlexiDome I & II
FlexiDomeVF
FlexiDomeXT+
FlexiDomeXF
FlexiDomeDN
