en Installation Manual

AUTODOME IP 4000i Table of contents | en 3
Bosch Security Systems Installation Manual 2020-05 | 2.0 |
Table of contents
1Safety 4
1.1 About this manual 4
1.2 Legal information 4
1.3 Safety precautions 4
1.4 Connection in applications 5
1.5 Customer support and service 6
2Introduction 7
3Product Description 8
4Preparing Wiring 9
5Preparing the Camera 10
6Installing a microSD card (optional) 12
7Installing a Surface Mount and Camera 14
7.1 Tools Required 14
7.2 Installation Requirements 14
7.3 Preparing the Surface Mount for Installation 14
7.4 Installing the Surface Mount Adapter 14
8Installing an In-ceiling Camera in a Suspended Ceiling 17
8.1 Tools Required 17
8.2 Installation Requirements 17
8.3 Preparing the Suspension Ceiling for Installation 17
8.4 Securing the Camera to the Ceiling 19
9Installing an In-Ceiling Camera in a Drywall Ceiling 22
9.1 Tools Required 22
9.2 Installation Requirements 22
9.3 Preparing the Ceiling for Installation 22
9.4 Securing the Camera to the Ceiling 23
10 Installing a Camera Directly to an Indoor Wall 26
10.1 Installation Requirements 26
10.2 Preparing the Wall for Installation 26
10.3 Installing the Wall Mount 26
10.4 Attaching the Camera to the Pendant Interface Plate 26
11 Installing a Pipe Mount and Camera 30
11.1 Tools Required 30
11.2 Installation Requirements 30
11.3 Preparing the Ceiling for Installation 30
11.4 Installing the Pipe Mount 30
11.5 Attaching the Camera to the Pendant Interface Plate 31
12 Connection 34
13 Decommissioning 36

4en | Safety AUTODOME IP 4000i
2020-05 | 2.0 | Installation Manual Bosch Security Systems
1 Safety
1.1 About this manual
This manual has been compiled with great care and the information it contains has been
thoroughly verified. The text was complete and correct at the time of printing. Because of the
ongoing development of products, the content of the manual may change without notice.
Bosch Security Systems accepts no liability for damage resulting directly or indirectly from
faults, incompleteness, or discrepancies between the manual and the product described.
1.2 Legal information
Copyright
This manual is the intellectual property of Bosch Security Systems, Inc. and is protected by
copyright. All rights reserved.
Trademarks
All hardware and software product names used in this document are likely to be registered
trademarks and must be treated accordingly.
1.3 Safety precautions
In this manual, the following symbols and notations are used to draw attention to special
situations:
Danger!
High risk: This symbol indicates an imminently hazardous situation such as “Dangerous
Voltage” inside the product. If not avoided, this will result in an electrical shock, serious
bodily injury, or death.
!
Warning!
Medium risk: Indicates a potentially hazardous situation. If not avoided, this may result in
minor or moderate injury.
!
Caution!
Low risk: Indicates a potentially hazardous situation. If not avoided, this may result in
property damage or risk of damage to the unit.
Notice!
This symbol indicates information or a company policy that relates directly or indirectly to the
safety of personnel or protection of property.

AUTODOME IP 4000i Safety | en 5
Bosch Security Systems Installation Manual 2020-05 | 2.0 |
1.4 Connection in applications
24VAC power source: This unit is intended to operate with a limited power source. The unit
is intended to operate at 24VAC (if PoE+ is not available). User supplied wiring must be in
compliance with electrical codes (Class 2 power levels).
PoE: Use only approved PoE+ devices. Power-over-Ethernet can be connected at the same
time as a 24VAC power supply.
If auxiliary power (24VAC) and PoE+ are applied simultaneously, the camera selects auxiliary
input and shuts off PoE+.

6en | Safety AUTODOME IP 4000i
2020-05 | 2.0 | Installation Manual Bosch Security Systems
1.5 Customer support and service
If this unit needs service, contact the nearest Bosch Security Systems Service Center for
authorization to return and shipping instructions.
USA
Telephone: [phone]
Fax: [phone]
Email: [email protected]
Customer Service
Telephone: [phone]
Fax: [phone]
Email: [email protected]
Technical Support
Telephone: [phone]
Fax: [phone]
Email: [email protected]
Canada
Telephone: [phone]
Fax: [phone]
Europe, Middle East, Africa, and Asia Pacific Regions
Please contact your local distributor or Bosch sales office. Use this link:
https://www.boschsecurity.com/corporate/where-to-buy/index.html
More Information
For more information, please contact the nearest Bosch Security Systems location or visit
www.boschsecurity.com.

AUTODOME IP 4000i Introduction | en 7
Bosch Security Systems Installation Manual 2020-05 | 2.0 |
2 Introduction
– This equipment should be unpacked and handled with care. Check the exterior of the
packaging for visible damage. If an item appears to have been damaged in shipment,
notify the shipper immediately.
– Verify that all the parts listed in the Parts List below are included. If any items are
missing, notify your Sales or Customer Service Representative from Bosch Security
Systems.
– Do not use this product if any component appears to be damaged. Please contact Bosch
Security Systems in the event of damaged goods.
– The original packing carton (if undamaged) is the safest container in which to transport
the unit and must be used if returning the unit for service. Save it for possible future use.

8en | Product Description AUTODOME IP 4000i
2020-05 | 2.0 | Installation Manual Bosch Security Systems
3 Product Description
The AUTODOME IP 4000i is a compact, indoor PTZ dome camera with a high-resolution
1080p60 HD sensor and a 12x optical zoom that allows operators to monitor wide scenes
without losing any details. The camera’s aesthetic design and flexible mounting options allow
unobtrusive surveillance of large halls, reception areas, or waiting areas that would otherwise
require multiple cameras for effective surveillance.

AUTODOME IP 4000i Preparing Wiring | en 9
Bosch Security Systems Installation Manual 2020-05 | 2.0 |
4 Preparing Wiring
4Prepare and install all wiring for 24 VAC, PoE+ (Cat5e/Cat6), alarms, and audio as
necessary. For 24 VAC, follow the recommendations for maximum cable distance and
wire gage.
Maximum cable distance in meters (feet) per minimum cable diameter
The following table identifies the recommended transmission distance (maximum) in meters
(feet), based on the specified wattage, per the minimum cable diameter (in mm²), when the
cable diameter is fixed and the maximum permitted power consumption for 24 VAC is 10%.
For example, for a device of 20 W and a minimum cable diameter of 1.0 mm², the
recommended transmission distance is 42 m (141 feet) from the transformer.
Models Watts 1.0 mm² 1.5 mm² 2.5 mm² 4.0 mm²
Indoor
(ceiling)
20 42 m (141 ft) 68 m (225 ft) 109 m (358 ft) 275 m (905 ft)
Outdoor 30 28 m (94 ft) 45 m (150 ft) 72 m (238 ft) 183 m (603 ft)
Wire Gage
Note: Metric wire sizes are standard DIN sizes, ISO6722, mm².
Wire diameter (mm²) AWG
1.0 18
1.5 16
2.5 14
4.0 12

10 en | Preparing the Camera AUTODOME IP 4000i
2020-05 | 2.0 | Installation Manual Bosch Security Systems
5 Preparing the Camera
Note: For pendant models, use T15.
For in-ceiling models, use T10.
1. Loosen the three (3) Hex screws in the trim ring / bubble enclosure with the appropriate
Torx screwdriver.
2. Remove the trim ring / bubble enclosure.
2.
1.
3
T15

AUTODOME IP 4000i Preparing the Camera | en 11
Bosch Security Systems Installation Manual 2020-05 | 2.0 |
2.
1.
3
T10
3. Remove the foam insert that protects the camera block.
4. Remove the tape holding the plastic lens protector; remove the lens protector.

12 en | Installing a microSD card (optional) AUTODOME IP 4000i
2020-05 | 2.0 | Installation Manual Bosch Security Systems
6 Installing a microSD card (optional)
1. Push the camera block until you see the card slot (item 1 in the following figure).
2. Insert the card into the slot (item 2 in the following figure).
3. Push the camera block into its original position (item 3 in the following figure).
1.
2.
3.
1.
3.
2.
Note: The next two steps are for pendant models only.

AUTODOME IP 4000i Installing a microSD card (optional) | en 13
Bosch Security Systems Installation Manual 2020-05 | 2.0 |
1. Replace the trim ring / bubble enclosure.
2. Tighten the screws with the T15 Torx screwdriver.
1.
2.
3
T15

14 en | Installing a Surface Mount and Camera AUTODOME IP 4000i
2020-05 | 2.0 | Installation Manual Bosch Security Systems
7 Installing a Surface Mount and Camera
7.1 Tools Required
– Appropriate screwdriver (Phillips head)
– Appropriate tool for cutting a hole in drywall or ceiling tile (if applicable)
– One (1) ground
7.2 Installation Requirements
– The ceiling is thick enough to install the mounting screws.
– The ceiling can sustain at least eight (8) times the weight of the camera (1.88 kg (4.14
lb)): > 15 kg (33 lb).
7.3 Preparing the Surface Mount for Installation
1. Determine the side of the surface mount adapter (NEZ-A4-SMB) from which the external
cables are to be routed. Remove the plug from the appropriate hole in the side of the adapter.
2. Attach a ground wire (user-supplied) to the stand-off on the inside of the adapter with the
ground symbol with one M5 screw.
3. Attach the L-shaped end of the safety tether (supplied with the camera) to the stand-off on
the inside of the adapter with the other M5 screw.
NEZ-A4-SMB
M5
M5
7.4 Installing the Surface Mount Adapter
1. Determine a secure location for mounting the surface mount adapter (NEZ-A4-SMB) and
the camera.
2. Use the adapter as a template to mark on the mounting surface the locations of the four
holes in which to insert the screws for mounting the adapter.
3. Drill the four (4) holes in the installation location.
4. Attach the surface mount adapter to the surface using the four screws.

AUTODOME IP 4000i Installing a Surface Mount and Camera | en 15
Bosch Security Systems Installation Manual 2020-05 | 2.0 |
5. Attach conduit to the side of the adapter from which you removed the plug (the side from
which the external cables are to be routed).
Note: The conduit should have M20 or NPT ¾ inch threads.
M20 or NPT 3/4"
4×
4×
1. Route the external cables (24 VAC, CAT 5/CAT6, alarm and/or audio as needed) through
the conduit and into the surface mount adapter.
2. Attach the mounting plate (supplied with the camera) to the surface mount adapter with
the three (3) M4 – .7 x 8 Phillips pan head machine screws (supplied with the surface
mount adapter).

16 en | Installing a Surface Mount and Camera AUTODOME IP 4000i
2020-05 | 2.0 | Installation Manual Bosch Security Systems
3×
M4

AUTODOME IP 4000i Installing an In-ceiling Camera in a Suspended Ceiling | en 17
Bosch Security Systems Installation Manual 2020-05 | 2.0 |
8 Installing an In-ceiling Camera in a Suspended Ceiling
8.1 Tools Required
– Appropriate screwdriver (Phillips head)
– Appropriate tool for cutting a hole in drywall or ceiling tile (if applicable)
8.2 Installation Requirements
– The ceiling thickness ranges from 10 - 40 mm.
– The ceiling can sustain at least eight (8) times the weight of the camera (1.81 kg (4 lb)): >
14.5 kg (32 lb).
8.3 Preparing the Suspension Ceiling for Installation
You must use the VGA-IC-SP In-ceiling Support Kit to install the camera In-ceiling housing into
a suspended or drop ceiling. This kit requires a separate purchase.
1. Choose the desired location to mount the camera.
2. Remove an adjacent ceiling tile.
3. Loosen the four (4) securing screws, located in the corners of the Bracket Assembly,
enough to hold the suspension bars but still allowing adjustment during installation.
4. Place the Bracket Assembly over the ceiling tile, which is used to mount the camera.
5. Snap the Bar Clips of the bracket to the ceiling rails.
A
Figure8.1: Suspension Ceiling Bracket (Top View)
1 Suspension Bars 3 Securing Screw (4)
2 Base Plate 4 Bar Clips
1. Use the bracket Base Plate as a template or cut a hole-sized hole in the center of the
ceiling tile with a drywall utility saw or jig saw.

18 en | Installing an In-ceiling Camera in a Suspended Ceiling AUTODOME IP 4000i
2020-05 | 2.0 | Installation Manual Bosch Security Systems
Figure8.2: Cut Hole in Ceiling Tile
2. Tighten the four (4) securing screws to the Bracket Assembly.
Figure8.3: Tighten Bracket Securing Screw
3. Secure the Bracket Assembly to an overhead securing point with a safety wire.
Figure8.4: Secure Bracket Assembly

AUTODOME IP 4000i Installing an In-ceiling Camera in a Suspended Ceiling | en 19
Bosch Security Systems Installation Manual 2020-05 | 2.0 |
8.4 Securing the Camera to the Ceiling
1. Connect the cables from the ceiling to the cables on the camera. Refer to the chapter
Connection for more information.
2. Insert the camera (without the trim ring / bubble enclosure) into the hole in the ceiling.
Ensure not to pinch the cables.
3. Turn each fastening screw to secure the clamps in the ceiling.

20 en | Installing an In-ceiling Camera in a Suspended Ceiling AUTODOME IP 4000i
2020-05 | 2.0 | Installation Manual Bosch Security Systems
3×
4. Tighten the clamps using the Phillips screwdriver to secure the housing to the ceiling.
!
Warning!
Over torquing the ceiling clamps can damage the clamp or ceiling. Only tighten the clamp
until it contacts the ceiling and you start to feel some resistance. If using a power
screwdriver, set the torque level to the lowest setting.
5. Place the trim ring / bubble enclosure in position over the camera block, aligning the
three (3) screws. Tighten the screws firmly to secure the trim ring / bubble enclosure to
the in-ceiling bracket.
