Bosch LC4-UC06E Installation and operation manual

Ceiling Loudspeakers
LC4-UC06E, LC4-UC12E and LC4-UC24E
en Installation Note

Installation
Fig. 1 Fig. 2
162 mm / 6.37"
00++
Fig. 3 Fig. 4
Fig. 5 Fig. 6
1
Ceiling Loudspeakers Installation | en 3
Bosch Security Systems B.V. Installation Note 2014.01 | V1.31 |

Fig. 7 Fig. 8
1/8
1/4
1/2
1/8
1/4
1/2
70V
1
100V
8
1
Fig. 9 Fig. 10
Fig. 11 Fig. 12
4en | Installation Ceiling Loudspeakers
2014.01 | V1.31 | Installation Note Bosch Security Systems B.V.

Fig. 13 Fig. 14
LC4‑CBB
click
00++
Fig. 15 Fig. 16
Next steps: fig 5‑12
Fig. 17 Fig. 18
LC4‑MFB
Ceiling Loudspeakers Installation | en 5
Bosch Security Systems B.V. Installation Note 2014.01 | V1.31 |

Fig. 19 Fig. 20
178 mm / 7.00"
Fig. 21 Fig. 22
Fig. 23 Fig. 24
Optional
6en | Installation Ceiling Loudspeakers
2014.01 | V1.31 | Installation Note Bosch Security Systems B.V.

CLICK!
1
2
Fig. 25 Fig. 26
00++
Fig. 27 Fig. 28
Fig. 29 Fig. 30
Ceiling Loudspeakers Installation | en 7
Bosch Security Systems B.V. Installation Note 2014.01 | V1.31 |

Fig. 31 Fig. 32
Next steps: fig. 9‑12
8en | Installation Ceiling Loudspeakers
2014.01 | V1.31 | Installation Note Bosch Security Systems B.V.

2 x 20.5 mm / 0.80"
95 mm / 3.74"
70 mm / 2.75"
17 mm / 0.66"
162 mm / 6.37"
200 mm / 7.87"
2 x 20.5 mm / 0.80"
2 x 11.5 mm / 0.45"
Dimensions
+
0
0
1/8
1/81/4
11/2
1/41/2
1
100V 70V
88
+
8
Circuit diagram
6 0
7 0
8 0
9 0
10 0
110
10 10 0 100 0 10 00 0 10 0 00 0
Freque ncy
dB SPL
BOSCH
Frequency response
Ceiling Loudspeakers Installation | en 9
Bosch Security Systems B.V. Installation Note 2014.01 | V1.31 |

Technical specifications
Electrical *
LC4‑UC06E LC4‑UC12E
Description Ceiling loudspeaker
Maximum power 9 W 18 W
Rated power 6 W (6/3/1.5/0.75W) 12 W (12/6/3/1.5W)
Sound pressure level
at 6 W power / 1 W
(1 kHz, 1 m)
95 dB / 87 dB (SPL) 98 dB / 87 dB (SPL)
Opening angle
at 1 kHz / 4kHz (-6 dB)
180° / 180° 180° / 180°
Effective frequency range
(-10 dB)
65 Hz to 20 kHz 65 Hz to 20 kHz
Rated voltage 6.93 / 70 / 100 V 9.8 / 70 / 100 V
Rated impedance 8 / 835 / 1667 Ohm 8 / 418 / 833 Ohm
Electrical connection 4‑way screw terminal block
Acceptable wire gauge 0.5 – 3 mm2
LC4‑UC24E
Description Ceiling loudspeaker
Maximum power 36 W
Rated power 24 W (24/12/6/3 W)
Sound pressure level
at 6 W power / 1 W
(1 kHz, 1 m)
101 dB / 87 dB (SPL)
Opening angle
at 1 kHz / 4kHz (-6 dB)
180° / 180°
Effective frequency range
(-10 dB)
65 Hz to 20 kHz
Rated voltage 13.9 / 70 / 100 V
Rated impedance 8 / 208 / 417 Ohm
Electrical connection 4-way screw terminal block
Acceptable wire gauge 0.5 – 3 mm2
* Technical performance according to IEC 60268‑5
2
10 en | Technical specifications Ceiling Loudspeakers
2014.01 | V1.31 | Installation Note Bosch Security Systems B.V.

Mechanical
LC4‑UC06E LC4‑UC12E LC4‑UC24E
Description Ceiling Loudspeaker
Diameter 200 mm (7.87 in)
Mounting cut‑out 162 mm (6.38 in)
Min./Max. ceiling
thickness
5 to 50 mm (0.19 to 1.97 in)
Maximum depth 70 mm (2.75 in)
Material
(Loudspeaker unit)
ABS (V 0)
Material (front grille) Steel mesh with ABS (V 0) rim
Weight 800 g (1.77 lb) 840 g (1.86 lb) 990 g (2.18 lb)
Color
(loudspeaker unit)
Black (RAL 9011)
Color (front grille) White (RAL 9003)
LC4‑CBB LC4‑MFD
Description Back‑Box Metal Fire‑dome
Diameter 160 mm (6.29 in) 197 / 175 mm (7.75 / 6.88 in)
Maximum depth 78 mm (3.07 in) 156 mm (6.14 in)
Mounting cut‑out n.a. 178 mm (7.00 in)
Min./Max. ceiling
thickness
n.a. 5 to 50 mm (0.19 to 1.97 in)
Material ABS (V 0) Steel
Weight 160 g (0.35 lb) 998 g (2.20 lb)
Color Black
(RAL 9011)
Flame red (RAL 3000)
Environmental
Operating temperature -25 ºC to +55 ºC (-13 ºF to +131 ºF)
Storage temperature -40 ºC to +70 ºC (-40 ºF to +158 ºF)
Relative humidity <95%
Ceiling Loudspeakers Technical specifications | en 11
Bosch Security Systems B.V. Installation Note 2014.01 | V1.31 |

Certification and Approvals
Safety According to EN 60065
Water and dust protected* According to EN 60529 IP 21
Emergency* Compliant to BS 5839 part 8
According to EN 54‑24
* With LC4‑CBB Back‑box or LC4‑MFD
Fire‑dome
1000 2000 4000 8000
-30
-25
-20
-15
-10
-5
0
5
0
10
20
30
40
50
60
70
80
90
100
110
120
130
140
150
160
170190
200
210
220
230
240
250
260
270
280
290
300
310
320
330
340
350
-30
-25
-20
-15
-10
-5
0
5
0
10
20
30
40
50
60
70
80
90
100
110
120
130
140
150
160
170
180
190
200
210
220
230
240
250
260
270
280
290
300
310
320
330
340
350
125 250 500 1000
Horizontal/Vertical polar diagram.
Normalized at 0‑degrees axis.
Horizontal/Vertical polar diagram.
Normalized at 0‑degrees axis.
Bosch Security Systems BV
Torenallee 49, 5617BA Eindhoven, The Netherlands
10
1438-CPD-0321
EN 54-24:2008
Loudspeaker for voice alarm systems
for fire detection and fire alarm systems for buildings
Ceiling loudspeaker 6 W, 12 W, 24 W and accessories
LC4-UC06E, LC4-UC12E, LC4-UC24E, LC4-CBB, LC4-MFD
Type A
12 en | Technical specifications Ceiling Loudspeakers
2014.01 | V1.31 | Installation Note Bosch Security Systems B.V.
