Bosch LC4-UC06E User manual

Ceiling loudspeaker
LC4‑UC06E, LC4‑UC12E, LC4‑UC24E
en Installation manual

Ceiling loudspeaker Installation | en 3
Bosch Security Systems B.V. Installation manual 2018.06 | V1.1 |
1 Installation
Fig. 1 Fig. 2
162 mm / 6.37"
00++
Fig. 3 Fig. 4
Fig. 5 Fig. 6

4en | Installation Ceiling loudspeaker
2018.06 | V1.1 | Installation manual Bosch Security Systems B.V.
Fig. 7 Fig. 8
1/8
1/4
1/2
1/8
1/4
1/2
70V
1
100V
8
1
Fig. 9 Fig. 10
Fig. 11 Fig. 12

Ceiling loudspeaker Installation | en 5
Bosch Security Systems B.V. Installation manual 2018.06 | V1.1 |
Fig. 13 Fig. 14
LC4‑CBB
click
00++
Fig. 15 Fig. 16
Next steps: fig 5‑12
Fig. 17 Fig. 18
LC4‑MFB

6en | Installation Ceiling loudspeaker
2018.06 | V1.1 | Installation manual Bosch Security Systems B.V.
Fig. 19 Fig. 20
178 mm / 7.00"
Fig. 21 Fig. 22
Fig. 23 Fig. 24
Optional

Ceiling loudspeaker Installation | en 7
Bosch Security Systems B.V. Installation manual 2018.06 | V1.1 |
CLICK!
1
2
Fig. 25 Fig. 26
00++
Fig. 27 Fig. 28
Fig. 29 Fig. 30

8en | Installation Ceiling loudspeaker
2018.06 | V1.1 | Installation manual Bosch Security Systems B.V.
Fig. 31 Fig. 32
Next steps: fig. 9‑12
2 x 20.5 mm / 0.80"
95 mm / 3.74"
70 mm / 2.75"
17 mm / 0.66"
162 mm / 6.37"
200 mm / 7.87"
2 x 20.5 mm / 0.80"
2 x 11.5 mm / 0.45"
Dimensions
+
0
0
1/8
1/81/4
11/2
1/41/2
1
100V 70V
88
+
8
Circuit diagram

Ceiling loudspeaker Installation | en 9
Bosch Security Systems B.V. Installation manual 2018.06 | V1.1 |
6 0
7 0
8 0
9 0
10 0
110
10 10 0 100 0 10 00 0 10 0 00 0
Freque ncy
dB SPL
BOSCH
Frequency response

10 en | Technical specifications Ceiling loudspeaker
2018.06 | V1.1 | Installation manual Bosch Security Systems B.V.
2 Technical specifications
Electrical*
LC4‑UC06E LC4‑UC12E
Description Ceiling loudspeaker
Rated power 6W (6/3/1.5/0.75W) 12W (12/6/3/1.5W)
Sound pressure level
at 6 W power / 1 W
(1 kHz, 1 m)
95dB/87dB(SPL) 98dB/87dB (SPL)
Sound pressure level at rated
power / 1W (1kHz, 4m)
(reference axis 0 degrees, free
field)
84dB/75dB (SPL) 86dB/75dB (SPL)
Opening angle
at 1 kHz / 4kHz (-6dB)
180° / 180° ** 180° / 180° **
Effective frequency range
(-10 dB)
65Hz to 20kHz 65Hz to 20kHz
Rated input voltage LC4‑UC06E 6.93V 70V 100V
Rated impedance LC4‑UC06E 6W 8 Ohm 835 Ohm 1667 Ohm
3W N/A 1667 Ohm 3333 Ohm
1.5W N/A 3333 Ohm 6667 Ohm
0.75W N/A 6667 Ohm 13333 Ohm
Rated input voltage LC4‑UC12E 9.8V 70V 100V
Rated impedance LC4‑UC12E 12W 8 Ohm 418 Ohm 833 Ohm
6W N/A 833 Ohm 1667 Ohm
3W N/A 1667 Ohm 3333 Ohm
1.5W N/A 3333 Ohm 6667 Ohm
Electrical connection 4‑way screw terminal block
Acceptable wire gauge 0.5 - 3mm2
LC4‑UC24E
Description Ceiling loudspeaker
Rated power 24W (24/12/6/3W)
Sound pressure level
at 6 W power / 1 W
(1 kHz, 1 m)
101dB/87dB(SPL)

Ceiling loudspeaker Technical specifications | en 11
Bosch Security Systems B.V. Installation manual 2018.06 | V1.1 |
Sound pressure level at rated
power / 1W (1kHz, 4m)
(reference axis 0 degrees, free
field)
88dB/75dB (SPL)
Opening angle
at 1 kHz / 4kHz (-6dB)
180° / 180° **
Effective frequency range
(-10 dB)
65Hz to 20kHz
Rated input voltage LC4‑UC24E 13.9V 70V 100V
Rated impedance LC4‑UC24E 24W 8 Ohm 208 Ohm 416 Ohm
12W N/A 416 Ohm 833 Ohm
6W N/A 833 Ohm 1667 Ohm
3W N/A 1667 Ohm 3333 Ohm
Electrical connection 4-way screw terminal block
Acceptable wire gauge 0.5 - 3mm2
* Technical performance according to IEC60268‑5
** With mounted LC4-CBB or LC4-MFD: 80° @4 kHz

12 en | Technical specifications Ceiling loudspeaker
2018.06 | V1.1 | Installation manual Bosch Security Systems B.V.
Mechanical
LC4‑UC06E LC4‑UC12E LC4‑UC24E
Description Ceiling Loudspeaker
Diameter 200mm (7.87in)
Mounting cut‑out 162mm (6.38in)
Min./Max. ceiling
thickness
5 to 50mm (0.19 to 1.97in)
Maximum depth 70mm (2.75in)
Material
(Loudspeaker unit)
ABS (V0)
Material (front grille) Steel mesh with ABS (V0) rim
Weight 800g (1.77lb) 840g (1.86lb) 990g (2.18lb)
Color
(loudspeaker unit)
Black (RAL9011)
Color (front grille) White (RAL9003)
LC4‑CBB LC4‑MFD
Description Back‑Box Metal Fire‑dome
Diameter 160mm (6.29in) 197 / 175mm (7.75 / 6.88in)
Maximum depth 78mm (3.07in) 156mm (6.14in)
Mounting cut‑out n.a. 178mm (7.00in)
Min./Max. ceiling
thickness
n.a. 5 to 50 mm (0.19 to 1.97in)
Material ABS (V0) Steel
Weight 160g (0.35lb) 998g (2.20lb)
Color Black
(RAL9011)
Flame red (RAL3000)
Environmental
Operating temperature -25ºC to +55ºC (-13ºF to +131ºF)
Storage and operating temperature -40ºC to +70ºC (-40ºF to +158ºF)
Relative humidity <95%
Note:
– The specification data is measured in an anechoic chamber, on a standard baffle
– The reference axis is perpendicular to the center point of the front grille
– The reference plane is perpendicular to the center of the reference axis
– The horizontal plane is perpendicular to the center of the reference plane

Ceiling loudspeaker Technical specifications | en 13
Bosch Security Systems B.V. Installation manual 2018.06 | V1.1 |
Certification and Approvals
Safety According to EN60065
Water and dust protected* According to EN60529 IP21
Emergency* Compliant to BS5839 part8
According to EN54‑24
* With LC4‑CBB Back‑box or LC4‑MFD
Fire‑dome
Model Voltage (Vrms) Tap (W) Sound pressure level dB (A) at
3.1 m (10 Ft)
LC-UC06E 70 6 85
70 3 82
70 1.5 79
70 0.75 76
LC-UC06E 100 6 85
100 3 82
100 1.5 79
100 0.75 77
LC-UC12E 70 12 88
70 6 85
70 3 82
70 1.5 79
LC-UC12E 100 12 87
100 6 85
100 3 83
100 1.5 80
LC-UC24E 70 24 90
70 12 87
70 6 84
70 3 82
LC-UC24E 100 24 90
100 12 87
100 6 84
100 3 82

14 en | Technical specifications Ceiling loudspeaker
2018.06 | V1.1 | Installation manual Bosch Security Systems B.V.
1000 2000 4000 8000
-30
-25
-20
-15
-10
-5
0
5
0
10
20
30
40
50
60
70
80
90
100
110
120
130
140
150
160
170190
200
210
220
230
240
250
260
270
280
290
300
310
320
330
340
350
-30
-25
-20
-15
-10
-5
0
5
0
10
20
30
40
50
60
70
80
90
100
110
120
130
140
150
160
170
180
190
200
210
220
230
240
250
260
270
280
290
300
310
320
330
340
350
125 250 500 1000
Horizontal/Vertical polar diagram.
Normalized at 0‑degrees axis.
Horizontal/Vertical polar diagram.
Normalized at 0‑degrees axis.
