Product Features
Bose® ControlCenter zone controllers provide three options for remote volume control and input
source selection:
Controller Function Compatible Products
CC-1 Volume control only FreeSpace® IZA 2120-LZ/HZ
FreeSpace ZA 2120-LZ/HZ
PowerShare PS602 & PS604
Any ControlSpace® engineered sound processor
CC-2 Volume control with A/B
source selection switch
FreeSpace IZA 250-LZ; IZA 190-HZ
FreeSpace IZA 2120-LZ/HZ
Any ControlSpace engineered sound processor
CC-3 Volume control with A/B/C/D
source selection switch
Any ControlSpace engineered sound processor
Each zone controller is available in white and black, and in North America, Japan, and EU
configurations. The North America zone controllers are sized for Decora® wall mounting, and
include two 1/2 inch #6-32 screws. The Japan zone controllers fit Wide 21 wall plates with a
face height of 1 mm above the thick wall plate cover; the controllers have approximately 3 mm
face height when used with other types of wall plate covers. Two 8 mm M4 screws are included.
Wall plate covers are not included with North America and Japan zone controllers. The EU zone
controllers come as a finished wall plate of size 86 mm x 86 mm, with 60 to 60.3 mm screw
spacing suitable for either vertical or horizontal mounting, and include two 18 mm M4 screws. All
models include a sheet of pre-printed color-matched labels, plus two blank labels for customized
applications.
Connecting a Single Zone Controller
Connect a single zone controller to a FreeSpace or PowerShare amplifier using a CAT 5 cable
with maximum length of 609 meters (2000 feet). Connect to a ControlSpace ESP using a CAT
5 cable with a maximum length of 152 meters (500 feet) for a shielded cable or 30 meters (100
feet) for an unshielded cable.
The cable must be terminated on one end with an RJ-45 connection using TIA/EIA 568B pinout,
and on the other end with an RJ-45 connector for PowerShare amplifiers, or the Euroblock
connector appropriate for the FreeSpace amplifier or ControlSpace engineered sound processor
(2-pin, 4-pin, or 6-pin).
Introduction pro.Bose.com
8 English

pro.Bose.com Introduction
Connecting Multiple Zone Controllers
Some amplifier models allow adjacent zone controllers to be ganged together directly. Each zone
controller can be independently configured to control any output, or combination of outputs, for
bi-amping.
Use a CAT 5 cable with RJ-45 connectors to connect zone controllers to each other, then create
a single home run from the last zone controller in the chain back to the amplifier. The maximum
total cable length (from the first zone conroller to the amplifier) is 609 meters (2000 feet). Use
standard CAT 5 cables and RJ-45 connectors as described in Connecting a Single Controller.
CV41 4-to-1 Converter
For PowerShare amplifier models, you can use the CV41 4-to-1 Converter to create a single home
run back to an amplifier from multiple zone controllers distributed throughout an installation.
Connect each zone controller to the CV41 converter using CAT 5 cables with RJ-45 connectors,
then run a single CAT 5 cable from the CV41 4-to-1 Converter to the amplifier. You can connect
up to two CC-1 zone controllers to a PS602 amplifier, and up to four CC-1 zone controllers to a
PS604 amplifier.
English 9
CAT 5 cable
609 m (2000 ft) max
CAT 5 cable
7.6 m (25 ft) max

Front View
38 mm
1. 5 in
105 mm
4.1 in
CC-1 Zone Controller - North America
Chain Main
Rear View Side View
34 mm
1. 3 in
DIPON
12345678
CC-1 Zone Controller
The CC-1 zone controller provides volume control only. It is compatible with FreeSpace® IZA
2120-LZ/HZ and ZA 2120-LZ/HZ amplifiers, PowerShare PS602 and PS604 amplifiers, and any
ControlSpace® engineered sound processor (ESP).
CC-1 Installation Guide pro.Bose.com
Front View
42 mm
1. 7 in
110 mm
4.3 in
CC-1 Zone Controller - Japan
Chain Main
Rear View Side View
36.2 mm
1. 4 in
DIPON
1234567 8
10 English

pro.Bose.com CC-1 Installation Guide
Pin-to-Remote Connections
Connections from the RJ-45 (TIA/EIA 568B wiring) connector on the CC-1 zone controller to
the REMOTE connector on the FreeSpace® amplifier or CONTROL INPUTS connector on the
ControlSpace® engineered sound processor (ESP).
Pin Color FreeSpace ControlSpace ESP
8 Brown
7 White/Brown
6 Green
5 White/Blue
4 Blue VOL 2
3 White/Green VOL 1 VOL 1
2 Orange PWR #2
1 White/Orange PWR #1 PWR #1
86 mm sq.
3.4 in sq.
CC-1 Zone Controller - EU
Front View Rear View
DIPON
12345678
34mm
1. 4 in
Side View
English 11

Connecting the CC-1 Zone Controller
Connect one CC-1 zone controller to FreeSpace® amplifier models IZA 2120-LZ/HZ or ZA 2120-
LZ/HZ, PowerShare amplifier models PS602 or PS604, or any ControlSpace® engineered sound
processor (ESP).
FreeSpace ZA 2120-LZ/HZ
Either RJ-45 on CC-1
Zone Controller
FreeSpace IZA 2120-LZ/HZ
Either RJ-45 on CC-1
Zone Controller
FreeSpace IZA 2120-LZ/HZ
FreeSpace ZA 2120-LZ/HZ
PowerShare PS602 or PS604
ControlSpace ESP (any)
FreeSpace and PowerShare:
609 m (2000 ft) max
ControlSpace:
152 m (500 ft) max shielded cable
30 m (100 ft) max unshielded cable
CC-1 Zone
Controller
CAT 5 cable
Use either RJ-45
connection
CC-1 Installation Guide pro.Bose.com
12 English
Pin-to-Remote Connection Diagrams
Any ControlSpace ESPEither RJ-45 on CC-1
Zone Controller

pro.Bose.com CC-1 Installation Guide
English 13
Configure the CC-1 zone controller using the following DIP switch settings:
1 2 3 4 5 6 7 8
FreeSpace 0 0 1 0 1 0 0 0
PowerShare* 0 0 1 0 * * * *
ControlSpace 0 0 1 0 1 0 0 0
* For the PowerShare PS602 and PS604 amplifiers, the CC-1 controls any outputs with corresponding DIP switches
in the ON position:
DIP 5 - OUTPUT 1
DIP 6 - OUTPUT 2
DIP 7 - OUTPUT 3 (PS604 only)
DIP 8 - OUTPUT 4 (PS604 only)

CC-1 Installation Guide pro.Bose.com
14 English
Connect two ganged CC-1 zone controllers to FreeSpace® amplifier models IZA 2120-HZ or ZA
2120-HZ, or PowerShare amplifier models PS602 or PS604.
FreeSpace IZA 2120-HZ
FreeSpace ZA 2120-HZ
CC-1 Zone
Controller #2
CC-1 Zone
Controller #1
CAT 5 cable
609 m (2000 ft)
max total length
RJ-45 #1 (Main) on
CC-1 Zone Controller #2 FreeSpace IZA 2120-HZ RJ-45 #1 (Main) on
CC-1 Zone Controller #2 FreeSpace ZA 2120-HZ
Pin-to-Remote Connection Diagrams

pro.Bose.com CC-1 Installation Guide
English 15
Configure the CC-1 zone controllers using the following DIP switch settings:
1 2 3 4 5 6 7 8
FreeSpace Controller #1 0 0 1 0 1 0 0 0
Controller #2 0 0 0 1 0 1 0 0
PowerShare* Controller #1 0 0 1 0 * * * *
Controller #2 0 0 1 0 * * * *
* For the PowerShare PS602 and PS604 amplifiers, the CC-1 controls any outputs with
corresponding DIP switches in the ON position:
DIP 5 - OUTPUT 1
DIP 6 - OUTPUT 2
DIP 7 - OUTPUT 3 (PS604 only)
DIP 8 - OUTPUT 4 (PS604 only)
DIPON
1 2 3 4 5 6 7 8
CC-1 Zone Controller #1
DIPON
1 2 3 4 5 6 7 8
CC-1 Zone Controller #2
PowerShare AmplifiersFreeSpace Amplifiers
DIPON
1 2 3 4 5 6 7 8
CC-1 Zone Controller #1
DIPON
1 2 3 4 5 6 7 8
CC-1 Zone Controller #2

CC-1 Installation Guide pro.Bose.com
16 English
Connect up to four ganged CC-1 zone controllers to the PowerShare amplifier model PS604.
PowerShare PS604
CC-1 Zone
Controller #4
CC-1 Zone
Controller #3
CC-1 Zone
Controller #2
CC-1 Zone
Controller #1
CAT 5 cable
609 m (2000 ft) max total length
Configure the CC-1 zone controllers using the following DIP switch settings:
1 2 3 4 5 6 7 8
Controller #1 0 0 1 0 1 0 0 0
Controller #2 0 0 1 0 0 1 0 0
Controller #3 0 0 1 0 0 0 1 0
Controller #4 0 0 1 0 0 0 0 1
DIPON
1 2 3 4 5 6 7 8
CC-1 Zone Controller #1
DIPON
1 2 3 4 5 6 7 8
CC-1 Zone Controller #3
DIPON
1 2 3 4 5 6 7 8
CC-1 Zone Controller #4
DIPON
1 2 3 4 5 6 7 8
CC-1 Zone Controller #2

Connect multiple CC-1 zone controllers to PowerShare amplifier models PS602 or PS604 using
the CV41 4-to-1 converter. Connect up to two CC-1 zone controllers to the PS602 amplifier or up
to four CC-1 zone controllers to the PS604 amplifier.
CAT 5 cable
609 m (2000 ft) max
CAT 5 cable
7.6 m (25 ft) max
pro.Bose.com CC-1 Installation Guide
English 17
DIPON
1 2 3 4 5 6 7 8
CC-1 Zone Controller #1
DIPON
1 2 3 4 5 6 7 8
CC-1 Zone Controller #2
Configure the CC-1 zone controllers using the following DIP switch settings:
1 2 3 4 5 6 7 8
Controller #1 0 0 1 0 1 0 0 0
Controller #2 0 0 1 0 0 1 0 0

CC-1 Installation Guide pro.Bose.com
18 English
CAT 5 cable
609 m (2000 ft) max
CAT 5 cable
7.6 m (25 ft) max
Configure the CC-1 zone controllers using the following DIP switch settings:
1 2 3 4 5 6 7 8
Controller #1 0 0 1 0 1 0 0 0
Controller #2 0 0 1 0 0 1 0 0
Controller #3 0 0 1 0 0 0 1 0
Controller #4 0 0 1 0 0 0 0 1
DIPON
1 2 3 4 5 6 7 8
CC-1 Zone Controller #1
DIPON
1 2 3 4 5 6 7 8
CC-1 Zone Controller #3
DIPON
1 2 3 4 5 6 7 8
CC-1 Zone Controller #4
DIPON
1 2 3 4 5 6 7 8
CC-1 Zone Controller #2
Connect up to four CC-1 zone controllers to the PowerShare PS604 amplifier using the CV41
4-to-1 converter.

CC-2 Zone Controller
The CC-2 zone controller provides volume control and A/B source selection. It is compatible
with FreeSpace® amplifier models IZA 250-LZ, IZA 190-HZ, and IZA 2120-LZ/HZ, and any
ControlSpace® engineered sound processor (ESP).
pro.Bose.com CC-2 Installation Guide
English 19
Front View
BA
42 mm
1. 7 in
110 mm
4.3 in
CC-2 Zone Controller - Japan
Chain Main
Rear View Side View
36.2 mm
1. 4 in
DIPON
12345678
Front View
BA
38 mm
1. 5 in
105 mm
4.1 in
CC-2 Zone Controller - North America
Chain Main
Rear View Side View
34 mm
1. 3 in
DIPON
12345678

CC-2 Installation Guide pro.Bose.com
20 English
Pin-to-Remote Connections
Connections from the RJ-45 (TIA/EIA 568B wiring) connector on the CC-2 zone controller to
REMOTE connector on the FreeSpace® amplifier or to CONTROL INPUTS connector on the
ControlSpace® engineered sound processor (ESP).
Pin Color FreeSpace IZA ControlSpace ESP
8 Brown
7 White/Brown A/B Select #2
6 Green A/B Select #1 A/B Select #1
5 White/Blue
4 Blue VOL 2
3 White/Green VOL 1 VOL 1
2 Orange PWR #2
1 White/Orange PWR #1 PWR #1
BA
86 mm sq.
3.4 in sq.
CC-2 Zone Controller - EU
Front View Rear View
DIPON
12345678
34mm
1. 4 in
Side View

pro.Bose.com CC-2 Installation Guide
Connecting the CC-2 Zone Controller
Connect one CC-2 zone controller to FreeSpace® amplifier models IZA 250-LZ, IZA 190-HZ, and
IZA 2120-LZ/HZ, and any ControlSpace® engineered sound processor (ESP).
BA
FreeSpace IZA 250-LZ
FreeSpace IZA 190-HZ
FreeSpace IZA 2120-LZ/HZ
ControlSpace ESP (any)
CAT-5 cable
FreeSpace and PowerShare:
609 m (2000 ft) max
ControlSpace:
152 m (500 ft) max shielded cable
30 m (100 ft) max unshielded cable
Either RJ-45 on CC-2
Zone Controller Any FreeSpace IZA
English 21
1 2 3 4 5 6 7 8
Controller 1 0 1 0 1 0 0 0
DIPON
1 2 3 4 5 6 7 8
CC-2 Zone Controller
Configure one CC-2 zone controller using the following DIP switch settings:
Pin-to-Remote Connection Diagrams
Any ControlSpace ESP
Either RJ-45 on CC-2
Zone Controller

CC-2 Installation Guide pro.Bose.com
22 English
Switch 1 2 3 4 5 6 7 8
Controller #1 1 0 1 0 1 0 0 0
Controller #2 0 1 0 1 0 1 0 0
Connect two ganged CC-2 zone controllers to FreeSpace® amplifier model IZA 2120-HZ.
BA FreeSpace IZA 2120-HZ BA
CC-2 Zone
Controller #1
CC-2 Zone
Controller #2
CAT 5 cable
609 m (2000 ft) max total length
RJ-45 #1 (Main) on
CC-2 Zone Controller #2
FreeSpace IZA 2120-HZ
DIPON
1 2 3 4 5 6 7 8
CC-2 Zone Controller #1
DIPON
1 2 3 4 5 6 7 8
CC-2 Zone Controller #2
Configure two ganged CC-2 zone controllers using the following DIP switch settings:
Pin-to-Remote Connection Diagrams

pro.Bose.com CC-3 Installation Guide
CC-3 Zone Controller
The CC-3 zone controller provides volume control and A/B/C/D source selection. It is compatible
with any ControlSpace® engineered sound processor (ESP).
English 23
Front View
BC
AD
42 mm
1 .7 in
110 mm
4.3 in
CC-3 Zone Controller - Japan
Main
Chain
Rear View Side View
36.2 mm
1. 4 in
Front View
BC
AD
38 mm
1. 5 in
105 mm
4.1 in
CC-3 Zone Controller - North America
Chain Main
Rear View Side View
34 mm
1. 3 in

CC-3 Installation Guide pro.Bose.com
24 English
Pin-to-Remote Connections
Connections from the RJ-45 (TIA/EIA 568B wiring) connector on the CC-3 zone controller to the
CONTROL INPUTS connector on the ESP.
Pin Color ControlSpace ESP
8 Brown COM
7 White/Brown A
6 Green B
5 White/Blue C
4 Blue D
3 White/Green VOL
2 Orange
1 White/Orange
86 mm sq.
3.4 in
BC
AD
CC-3 Zone Controller - EU
Front View Rear View
34mm
1. 4 in
Side View

Connecting the CC-3 Zone Controller
Connect one CC-3 zone controller to any ControlSpace® engineered sound processor (ESP).
Any ControlSpace ESP
RJ-45 on CC-3
pro.Bose.com CC-3 Installation Guide
English 25
B C
A D
Any ControlSpace ESP
152 m (500 ft) max length CAT 5 shielded cable
30 m (100 ft) max length unshielded CAT 5 cable
Terminated with RJ-45 (TIA/EIA 568 pinout) on one end
and 6-pin phoenix on the other end
Pin-to-Remote Connection Diagrams
