Service Manual
SoundTouchTM Wireless Adapter
(Airplay and non-Airplay versions)

2
CONTENTS
CAUTION: The Bose®SoundTouchTM Wireless Adapter contains no user-serviceable
parts. To prevent warranty infractions, refer servicing to warranty service stations or
factory service.
PROPRIETARY INFORMATION
THIS DOCUMENT CONTAINS PROPRIETARY INFORMATION OF
BOSE CORPORATION WHICH IS BEING FURNISHED ONLY FOR
THE PURPOSE OF SERVICING THE IDENTIFIED BOSE PRODUCT
BYAN AUTHORIZED BOSE SERVICE CENTER OR OWNER OF
THE BOSE PRODUCT, AND SHALL NOT BE REPRODUCED OR
USED FOR ANY OTHER PURPOSE.
The Bose SoundTouch Wireless Adapter is covered by a 1-year limited warranty. Warranty is
2 years in Europe.
WARRANTY
Product Description .........................................................................................................................3
Part List Notes ..................................................................................................................................3
Packaging Part List, SoundTouchTM Wireless Adapter (refer to Figure 1)..................................4
Figure 1. Packaging View .................................................................................................................4
Main Part List, SoundTouch Wireless Adapter (refer to Figure 2) ..............................................5
Figure 2. Exploded View ...................................................................................................................5
Electrical Part Lists .................................................................................................................... 6-28
Wi-Fi Module PCB Assembly...................................................................................................... 6-24
Input / Output PCB Assembly .................................................................................................. 24-28
Disassembly Procedures ...............................................................................................................29
TAP Command Setup......................................................................................................................30
Wi-Fi Test Procedure......................................................................................................................31
Test Procedures ....................................................................................................................... 32-35
Service Manual Revision History .................................................................................................36

3
PRODUCT DESCRIPTION
The Bose®SoundTouchTM Wireless Adapter is sold as part of the SoundTouch Stereo JC Wi-Fi
music system, the SA-4 amplifier system (both use the Airplay version of the wireless adapter), and
the Lifestyle and VideoWave SoundTouch compatible systems (they use the non-Airplay version).
The wireless adapter connects to these
systems via the Bose link connector located
on these products. The adapter derives
power from the SoundTouch product and
contains the Wi-Fi circuitry that allows
connection to the customer’s wireless
network. The non-Airplay version of the
wireless adapter also has a USB connec-
tion which connects to the system’s media
center.
SoundTouch Features
• SoundTouch wireless adapter enables
Wi-Fi access to your home network.
• An Ethernet connector enables wired access to your home network.
• Stream your music viaAirPlay from yourApple devices.
• USB connectors for network setup.*
* The USB connectors on the back of the system (SETUP A and SETUP B) are for setup only.
The connectors are not designed to charge smartphones, tablets, or similar devices.
With SoundTouch, you can stream Internet radio, music services, and your musiclibrary. If you
have Wi-Fi at home, you’re ready to enjoy your favorite music in any room or outdoor space that
you want.
Key Benefits
• Enjoy wireless access to Internet radio, music services, and your music library.
• Stream your favorite music easily with personalized presets.
• Works with your existing home Wi-Fi network.
• Free SoundTouch app for your computer, smartphone, or tablet provides more
powerful control.
• Simply add additional systems at any time for a multi-room listening experience.
• Wide selection of Bose®audio systems lets you choose the right solution for any
room or outdoor space.
PART LIST NOTES
1. The individual parts located on the PCBs are listed in the Electrical Part List.
2. This part is referenced for informational purposes only. It is not stocked as a repair part.
Refer to the next higher assembly for a replacement part.
3. This part is critical for safety purposes. Failure to use a substitute replacement with
the same safety characteristics as the recommended replacement part might create shock,
fire and/or other hazards.
4. When replacing the programmed Wi-Fi module, the serial number and country code must be
set on the replacement board before returning the unit to the customer. Refer to pages 33
and 34 for procedures.

4
PACKAGING PART LIST
SoundTouchTM WirelessAdapter (refer to Figure 1)
Figure 1. Packaging View
Item
Number Description Part Number Qty Note
1 BAG,FOAM-FILM,5.00X13.00X0.03 363682-0010 1
2 CARTON,DC,175 E,9.50X3.50X1.94 363681-0010 1


5
MAIN PART LIST
SoundTouchTM WirelessAdapter (refer to Figure 2)
Important Note: When replacing the programmed Wi-Fi module PCB (item 5 above), the serial
number and country code MUST be set on the replacement board before returning the unit to the
customer. Refer to pages 33 and 34 for procedures.
Figure 2. Exploded View
123
4
5
6
Item
Number Description Part Numbe
r
Qty Note
1 CABLE ASSY, FFC, STRAIGHT, 31 POS, 80mm 370236-0080 1
2 CABLE, FFC, 40 POS, 65mm 355832-0065 1
3 PCB ASSY, SOUNDTOUCH, I/O, SVC 355647-001S 1 1
4 TOP ENCLOSURE SUBASSY, SVCE
(INCLUDES BOSE LINK CABLE) 625539-001S 1
5 WI-FI MODULE, PROG, SVC (AIRPLAY) 625125-041S or
625125-071S 1 1
WI-FI MODULE, PROG, SVC (NON-AIRPLAY) 625125-012S or
625125-052S
6 BOTTOM ENCLOSURE SUBASSY, SVCE
(INCLUDES FEET) 625538-001S 1
- SCRIM, CONN, LRG 361216-0010 1
- SCREW, TAPP, 4-16X.44, PAN, TORX 343757-007 3
SCREW, TAPP, 4-16X.75, PAN, TORX 343757-012 3
- SCRIM, RESET BUTTON 374284-0010 1
Note: The Airplay version Wi-Fi module (item 5) is used in the SoundTouch wireless adapter that
ships with the SA-4 amplifier and the SoundTouch Stereo JC music system.


6
ELECTRICAL PART LIST
Wi-Fi Module PCB Assembly
Resistors
Reference
Designator Description Part Number Note
R13 51 OHM, 0402 ARRAY, 4 5%, 0.063W 354737-510J4
R14 51 OHM, 0402 ARRAY, 4 5%, 0.063W 354737-510J4
R15 0 OHM, JUMPER, 0402 280043
R16 0 OHM, JUMPER, 0402 280043
R27 220 OHM, 0402 ARRAY, 4 5%, 0.063W 354737-221J4
R123 121 Ohm, 0402, 63mw, 1% 268361-121R
R124 30.1 OHMS, 0402, 0.063W, 1% 268361-30R1
R125 5.76K, 0402, 63MW, 1% 268361-5761
R126 5.76K, 0402, 63MW, 1% 268361-5761
R127 5.76K, 0402, 63MW, 1% 268361-5761
R128 187 OHMS, 0402, 63mw, 1% 268361-187R
R129 187 OHMS, 0402, 63mw, 1% 268361-187R
R132 392 OHM, 0402, 63MW, 1% 268361-392R
R133 51 OHMS, 0402, 0.063W, 1% 268361-51R0
R134 100 OHM, 0402, 63MW, 1% 268361-1000
R135 100 OHM, 0402, 63MW, 1% 268361-1000
R136 100 OHM, 0402, 63MW, 1% 268361-1000
R137 100 OHM, 0402, 63MW, 1% 268361-1000
R138 0 OHM, JUMPER, 0402 280043
R139 0 OHM, JUMPER, 0402 280043
R140 100 OHM, 0402, 63MW, 1% 268361-1000
R141 3.01K, 0402, 63MW, 1% 268361-3011
R142 10.0K, 0402, 63MW, 1% 268361-1002
R143 10.0K, 0402, 63MW, 1% 268361-1002
R144 10.0K, 0402, 63MW, 1% 268361-1002
R146 JUMPER, CHIP, 0603 196042
R147 JUMPER, CHIP, 0603 196042
R200 10.0K, 0402, 63MW, 1% 268361-1002
R201 13.0K, 0402, 63MW, 1% 268361-1302
R202 6.04K, 0402, 63MW, 1% 268361-6041
R203 10.0K, 0402, 63MW, 1% 268361-1002
R204 10.0K, 0402, 63MW, 1% 268361-1002
R205 2.74K, 0402, 63MW, 1% 268361-2741
R206 100 OHM, 0402, 63MW, 1% 268361-1000
R207 1.50K, 0402, 63MW, 1% 268361-1501
R208 10.0K, 0402, 63MW, 1% 268361-1002
R209 10.0K, 0402, 63MW, 1% 268361-1002
R210 10.0K, 0402, 63MW, 1% 268361-1002
R211 10.0K, 0402, 63MW, 1% 268361-1002
R212 0 OHM, JUMPER, 0402 280043
R213 0 OHM, JUMPER, 0402 280043
R214 10.0K, 0402, 63MW, 1% 268361-1002
R215 100 OHM, 0402, 63MW, 1% 268361-1000
R216 100 OHM, 0402, 63MW, 1% 268361-1000
R217 10.0K, 0402, 63MW, 1% 268361-1002
R218 10.0K, 0402, 63MW, 1% 268361-1002
R219 4.75K, 0402, 0.063W, 1% 268361-4751


7
ELECTRICAL PART LIST
Wi-Fi Module PCB Assembly
Resistors (continued)
Reference
Designator Description Part Number Note
R220 10.0K, 0402, 63MW, 1% 268361-1002
R221 4.75K, 0402, 0.063W, 1% 268361-4751
R225 100 OHM, 0402, 63MW, 1% 268361-1000
R229 100 OHM, 0402, 63MW, 1% 268361-1000
R240 10.0K, 0402, 63MW, 1% 268361-1002
R242 10.0K, 0402, 63MW, 1% 268361-1002
R243 10.0K, 0402, 63MW, 1% 268361-1002
R244 10.0K, 0402, 63MW, 1% 268361-1002
R245 10.0K, 0402, 63MW, 1% 268361-1002
R246 0 OHM, JUMPER, 0402 280043
R247 33 OHM, 0402, 1/16W, 1% 268361-33R0
R276 10.0K, 0402, 63MW, 1% 268361-1002
R279 0 OHM, JUMPER, 0402 280043
R280 0 OHM, 0402 ARRAY, 4CONVEX, 0.5A 357537-0020
R281 0 OHM, 0402 ARRAY, 4CONVEX, 0.5A 357537-0020
R282 0 OHM, 0402 ARRAY, 4CONVEX, 0.5
A
357537-0020
R283 0 OHM, 0402 ARRAY, 4CONVEX, 0.5A 357537-0020
R284 0 OHM, 0402 ARRAY, 4CONVEX, 0.5A 357537-0020
R285 0 OHM, 0402 ARRAY, 4CONVEX, 0.5A 357537-0020
R286 0 OHM, 0402 ARRAY, 4CONVEX, 0.5
A
357537-0020
R287 0 OHM, 0402 ARRAY, 4CONVEX, 0.5A 357537-0020
R288 0 OHM, 0402 ARRAY, 4CONVEX, 0.5A 357537-0020
R289 0 OHM, 0402 ARRAY, 4CONVEX, 0.5
A
357537-0020
R290 0 OHM, 0402 ARRAY, 4CONVEX, 0.5
A
357537-0020
R300 100 OHM, 0402, 63MW, 1% 268361-1000
R302 1.00K, 0402, 63MW, 1% 268361-1001
R304 100 OHM, 0402, 63MW, 1% 268361-1000
R305 100 OHM, 0402, 63MW, 1% 268361-1000
R307 10.0K, 0402, 63MW, 1% 268361-1002
R308 10.0K, 0402, 63MW, 1% 268361-1002
R309 10.0K, 0402, 63MW, 1% 268361-1002
R311 100 OHM, 0402, 63MW, 1% 268361-1000
R400 51 OHMS, 0402, 0.063W, 1% 268361-51R0
R401 51 OHMS, 0402, 0.063W, 1% 268361-51R0
R402 243 OHMS, 0402, 63MW, 1% 268361-2430
R403 10.0K, 0402, 63MW, 1% 268361-1002
R404 10.0K, 0402, 63MW, 1% 268361-1002
R406 49.9 OHM, 0402, 63MW, 1% 268361-49R9
R407 51 OHMS, 0402, 0.063W, 1% 268361-51R0
R408 100 OHM, 0402, 63MW, 1% 268361-1000
R409 10.0K, 0402, 63MW, 1% 268361-1002
R413 806 OHM, 0402, 63mw, 1% 268361-806R
R414 1.00K, 0402, 63MW, 1% 268361-1001
R415 33 OHM, 0402, 1/16W, 1% 268361-33R0
R421 51 OHM, 0402 ARRAY, 4 5%, 0.063W 354737-510J4
R422 51 OHM, 0402 ARRAY, 4 5%, 0.063W 354737-510J4
R423 51 OHM, 0402 ARRAY, 4 5%, 0.063W 354737-510J4


8
Wi-Fi Module PCB Assembly
Resistors (continued)
ELECTRICAL PART LIST
Reference
Designator Description Part Number Note
R424 51 OHM, 0402 ARRAY, 4 5%, 0.063W 354737-510J4
R425 51 OHM, 0402 ARRAY, 4 5%, 0.063W 354737-510J4
R426 51 OHM, 0402 ARRAY, 4 5%, 0.063W 354737-510J4
R500 100 OHM, 0402, 63MW, 1% 268361-1000
R501 100 OHM, 0402, 63MW, 1% 268361-1000
R502 100 OHM, 0402, 63MW, 1% 268361-1000
R503 10.0K, 0402, 63MW, 1% 268361-1002
R504 100 OHM, 0402, 63MW, 1% 268361-1000
R505 100 OHM, 0402, 63MW, 1% 268361-1000
R506 10.0K, 0402, 63MW, 1% 268361-1002
R507 5.76K, 0402, 63MW, 1% 268361-5761
R508 4.75K, 0402, 0.063W, 1% 268361-4751
R509 100 OHM, 0402, 63MW, 1% 268361-1000
R510 100 OHM, 0402, 63MW, 1% 268361-1000
R511 4.53K, 0402, 0.063W, 1% 268361-4531
R513 10.0K, 0402, 63MW, 1% 268361-1002
R514 10.0K, 0402, 63MW, 1% 268361-1002
R515 10.0K, 0402, 63MW, 1% 268361-1002
R516 100 OHM, 0402, 63MW, 1% 268361-1000
R517 10.0K, 0402, 63MW, 1% 268361-1002
R518 100 OHM, 0402, 63MW, 1% 268361-1000
R519 100 OHM, 0402, 63MW, 1% 268361-1000
R520 100 OHM, 0402, 63MW, 1% 268361-1000
R521 100 OHM, 0402, 63MW, 1% 268361-1000
R522 56.2K, 0402, 63MW, 1% 268361-5622
R523 100 OHM, 0402, 63MW, 1% 268361-1000
R524 1.00K, 0402, 63MW, 1% 268361-1001
R525 10.0K, 0402, 63MW, 1% 268361-1002
R527 10.0K, 0402, 63MW, 1% 268361-1002
R528 100 OHM, 0402, 63MW, 1% 268361-1000
R529 10.0K, 0402, 63MW, 1% 268361-1002
R530 100 OHM, 0402, 63MW, 1% 268361-1000
R531 100 OHM, 0402, 63MW, 1% 268361-1000
R532 100 OHM, 0402, 63MW, 1% 268361-1000
R533 10.0K, 0402, 63MW, 1% 268361-1002
R534 10.0K, 0402, 63MW, 1% 268361-1002
R535 1.00K, 0402, 63MW, 1% 268361-1001
R537 100 OHM, 0402, 63MW, 1% 268361-1000
R538 10.0K, 0402, 63MW, 1% 268361-1002
R539 10.0K, 0402, 63MW, 1% 268361-1002
R540 301 OHM, 0402, 63MW, 1% 268361-3010
R541 301 OHM, 0402, 63MW, 1% 268361-3010
R544 100 OHM, 0402, 63MW, 1% 268361-1000
R546 100 OHM, 0402, 63MW, 1% 268361-1000
R547 100 OHM, 0402, 63MW, 1% 268361-1000
R548 100 OHM, 0402, 63MW, 1% 268361-1000
R549 56.2K, 0402, 63MW, 1% 268361-5622


9
Wi-Fi Module PCB Assembly
Resistors (continued)
ELECTRICAL PART LIST
Reference
Designator Description Part Number Note
R550 56.2K, 0402, 63MW, 1% 268361-5622
R551 100 OHM, 0402, 63MW, 1% 268361-1000
R552 100 OHM, 0402, 63MW, 1% 268361-1000
R553 56.2K, 0402, 63MW, 1% 268361-5622
R554 56.2K, 0402, 63MW, 1% 268361-5622
R555 1.50K, 0402, 63MW, 1% 268361-1501
R560 56.2K, 0402, 63MW, 1% 268361-5622
R561 56.2K, 0402, 63MW, 1% 268361-5622
R562 100 OHM, 0402, 63MW, 1% 268361-1000
R564 100 OHM, 0402, 63MW, 1% 268361-1000
R565 100 OHM, 0402, 63MW, 1% 268361-1000
R566 100 OHM, 0402, 63MW, 1% 268361-1000
R600 4.53K, 0402, 0.063W, 1% 268361-4531
R602 4.53K, 0402, 0.063W, 1% 268361-4531
R606 100 OHM, 0402, 63MW, 1% 268361-1000
R607 10.0K, 0402, 63MW, 1% 268361-1002
R608 10.0K, 0402, 63MW, 1% 268361-1002
R609 10.0K, 0402, 63MW, 1% 268361-1002
R610 10.0K, 0402, 63MW, 1% 268361-1002
R611 100 OHM, 0402, 63MW, 1% 268361-1000
R612 100 OHM, 0402, 63MW, 1% 268361-1000
R613 100 OHM, 0402, 63MW, 1% 268361-1000
R614 100 OHM, 0402, 63MW, 1% 268361-1000
R615 10.0K, 0402, 63MW, 1% 268361-1002
R616 100 OHM, 0402, 63MW, 1% 268361-1000
R617 100 OHM, 0402, 63MW, 1% 268361-1000
R618 1.00K, 0402, 63MW, 1% 268361-1001
R619 10.0K, 0402, 63MW, 1% 268361-1002
R620 10.0K, 0402, 63MW, 1% 268361-1002
R621 10.0K, 0402, 63MW, 1% 268361-1002
R622 100 OHM, 0402, 63MW, 1% 268361-1000
R623 10.0K, 0402, 63MW, 1% 268361-1002
R657 100 OHM, 0402, 63MW, 1% 268361-1000
R661 3.32K, 0402, 63MW, 1% 268361-3321
R662 3.32K, 0402, 63MW, 1% 268361-3321
R665 10.0K, 0402, 63MW, 1% 268361-1002
R667 10.0K, 0402, 63MW, 1% 268361-1002
R668 100 OHM, 0402, 63MW, 1% 268361-1000
R669 100 OHM, 0402, 63MW, 1% 268361-1000
R674 100 OHM, 0402, 63MW, 1% 268361-1000
R675 100 OHM, 0402, 63MW, 1% 268361-1000
R676 100 OHM, 0402, 63MW, 1% 268361-1000
R688 100 OHM, 0402, 63MW, 1% 268361-1000
R700 10.0K, 0402, 63MW, 1% 268361-1002
R701 10.0K, 0402, 63MW, 1% 268361-1002
R702 10.0K, 0402, 63MW, 1% 268361-1002
R800 10.0K, 0402, 63MW, 1% 268361-1002


10
Wi-Fi Module PCB Assembly
ELECTRICAL PART LIST
Resistors (continued)
Reference
Designator Description Part Number Note
R801 10.0K, 0402, 63MW, 1% 268361-1002
R802 10.0K, 0402, 63MW, 1% 268361-1002
R1000 3.32K, 0402, 63MW, 1% 268361-3321
R1001 3.32K, 0402, 63MW, 1% 268361-3321
R1002 49.9 OHM, 0402, 63MW, 1% 268361-49R9
R1003 56.2K, 0402, 63MW, 1% 268361-5622
R1004 100 OHM, 0402, 63MW, 1% 268361-1000
R1005 100 OHM, 0402, 63MW, 1% 268361-1000
R1006 100 OHM, 0402, 63MW, 1% 268361-1000
R1007 100 OHM, 0402, 63MW, 1% 268361-1000
R1008 100 OHM, 0402, 63MW, 1% 268361-1000
R1009 100 OHM, 0402, 63MW, 1% 268361-1000
R1010 100 OHM, 0402, 63MW, 1% 268361-1000
R1011 100 OHM, 0402, 63MW, 1% 268361-1000
R1014 100 OHM, 0402, 63MW, 1% 268361-1000
R1015 100 OHM, 0402, 63MW, 1% 268361-1000
R1016 100 OHM, 0402, 63MW, 1% 268361-1000
R1100 3.32K, 0402, 63MW, 1% 268361-3321
R1101 3.32K, 0402, 63MW, 1% 268361-3321
R1102 100K, 0402, 63MW, 1% 268361-1003
R1103 100K, 0402, 63MW, 1% 268361-1003
R1104 1.0M, 0402, 63MW, 1% 268361-1004
R1105 1.0M, 0402, 63MW, 1% 268361-1004
R1106 1.0M, 0402, 63MW, 1% 268361-1004
R1107 100K, 0402, 63MW, 1% 268361-1003
R1108 100K, 0402, 63MW, 1% 268361-1003
R1111 4.7 OHMS, 0402, 0.063W, 1% 268361-4R70
R1112 1.00K, 0805, 1/10W, 5% 133626-1025
R1113 499 OHMS, 0805, .125W, 1% 133625-4990
R1114 4.7 OHMS, 0402, 0.063W, 1% 268361-4R70
R1115 4.7 OHMS, 0402, 0.063W, 1% 268361-4R70
R1201 100 OHM, 0402, 63MW, 1% 268361-1000
R1202 100 OHM, 0402, 63MW, 1% 268361-1000
R1206 100 OHM, 0402, 63MW, 1% 268361-1000
R1207 100 OHM, 0402, 63MW, 1% 268361-1000
R1208 100 OHM, 0402, 63MW, 1% 268361-1000
R1210 100 OHM, 0402, 63MW, 1% 268361-1000
R1300 10.0K, 0402, 63MW, 1% 268361-1002
R1301 0 OHM, JUMPER, 0402 280043
R1303 100K, 0402, 63MW, 1% 268361-1003
R1304 100K, 0402, 63MW, 1% 268361-1003
R1306 215K, 0402, 0.063W, 1% 268361-2153
R1307 100K, 0402, 63MW, 1% 268361-1003
R1308 23.7K, 0402, 63MW, 1% 268361-2372
R1309 10.0K, 0402, 63MW, 1% 268361-1002
R1310 10.0 OHM, 0402, 63MW, 1% 268361-10R0
R1313 100K, 0402, 63MW, 1% 268361-1003


11
Wi-Fi Module PCB Assembly
ELECTRICAL PART LIST
Resistors (continued)
Reference
Designator Description Part Number Note
R1314 100K, 0402, 63MW, 1% 268361-1003
R1315 348K, 0402, 63MW, 1% 268361-3483
R1316 100K, 0402, 63MW, 1% 268361-1003
R1317 1 OHM, 0402, 0.063W, 1% 268361-1R00
R1318 8.25K, 0402, 0.063W, 1% 268361-8251
R1500 1.50K, 0402, 63MW, 1% 268361-1501
R1501 51 OHMS, 0402, 0.063W, 1% 268361-51R0
R1502 51 OHMS, 0402, 0.063W, 1% 268361-51R0
R1503 1.50K, 0402, 63MW, 1% 268361-1501
R1504 49.9 OHM, 0805, .125W, 1% 133625-49R9
R1505 51 OHMS, 0402, 0.063W, 1% 268361-51R0
R1506 49.9 OHM, 0805, .125W, 1% 133625-49R9
R1507 274 OHMS, 0402, 63MW, 1% 268361-2740
R1508 274 OHM, 0402, 63MW, 1% 268361-2740
R1509 75 OHM, 0402, 63MW, 1% 268361-75R0
R1510 75 OHM, 0402, 63MW, 1% 268361-75R0
R1539 100 OHM, 0402, 63MW, 1% 268361-1000
R1540 100 OHM, 0402, 63MW, 1% 268361-1000
R1541 100 OHM, 0402, 63MW, 1% 268361-1000
R1542 100 OHM, 0402, 63MW, 1% 268361-1000
R1548 100 OHM, 0402, 63MW, 1% 268361-1000
R1549 100 OHM, 0402, 63MW, 1% 268361-1000
R1550 100 OHM, 0402, 63MW, 1% 268361-1000
R1553 12.1K, 0402, 63MW, 1% 268361-1212
R1555 100 OHM, 0402, 63MW, 1% 268361-1000
R1556 4.75K, 0402, 0.063W, 1% 268361-4751
R1557 4.75K, 0402, 0.063W, 1% 268361-4751
R1558 49.9 OHM, 0805, .125W, 1% 133625-49R9
R1559 49.9 OHM, 0805, .125W, 1% 133625-49R9
R1561 4.75K, 0402, 0.063W, 1% 268361-4751
R1562 4.75K, 0402, 0.063W, 1% 268361-4751
R1564 4.75K, 0402, 0.063W, 1% 268361-4751
R1566 4.75K, 0402, 0.063W, 1% 268361-4751
R6100 100 OHM, 0402, 63MW, 1% 268361-1000
R6102 100 OHM, 0402, 63MW, 1% 268361-1000
R6103 100 OHM, 0402, 63MW, 1% 268361-1000
R6111 249K, 0402, 0.063W, 1% 268361-2493
W503 0 OHM, JUMPER, 0402 280043
W700 0 OHM, JUMPER, 0402 280043
W900 0 OHM, JUMPER, 0402 280043
W901 0 OHM, JUMPER, 0402 280043
W1000 0 OHM, JUMPER, 0402 280043
W1001 0 OHM, JUMPER, 0402 280043
W1003 0 OHM, JUMPER, 0402 280043
W1004 0 OHM, JUMPER, 0402 280043
W1103 0 OHM, JUMPER, 0402 280043
W1104 0 OHM, JUMPER, 0402 280043


12
Wi-Fi Module PCB Assembly
ELECTRICAL PART LIST
Resistors (continued)
Capacitors
Reference
Designator Description Part Number Note
W1105 0 OHM, JUMPER, 0402 280043
W1300 0 OHM, JUMPER, 0402 280043
W1301 0 OHM, JUMPER, 0402 280043
W1302 0 OHM, JUMPER, 0402 280043
W1303 0 OHM, JUMPER, 0402 280043
W1304 0 OHM, JUMPER, 0402 280043
W1305 0 OHM, JUMPER, 0402 280043
W1306 0 OHM, JUMPER, 0402 280043
W1307 0 OHM, JUMPER, 0402 280043
W1308 0 OHM, JUMPER, 0402 280043
W1309 0 OHM, JUMPER, 0402 280043
W1310 0 OHM, JUMPER, 0402 280043
W1312 0 OHM, JUMPER, 0402 280043
W1313 0 OHM, JUMPER, 0402 280043
W1315 0 OHM, JUMPER, 0402 280043
W1316 JUMPER, CHIP, 0603 196042
W1317 JUMPER, CHIP, 0603 196042
W1319 0 OHM, JUMPER, 0402 280043
W1320 0 OHM, JUMPER, 0402 280043
W1321 0 OHM, JUMPER, 0402 280043
W1322 0 OHM, JUMPER, 0402 280043
W1500 0 OHM, JUMPER, 0402 280043

Reference
Designator Description Part Number Note
C138 10pF, COG, 0402, 5%, 50V 268364-100
C139 10
p
F, COG, 0402, 5%, 50V 268364-100
C147 10uF, X5R, 0805, 10V, 10% 354809-106K
C148 0.1uF, X5R, 0402, 16V, 10% 313771-104C
C149 100pF, COG, 0402, 5%, 50V 268364-101
C150 0.22uF, X5R, 0402, 10V, 10% 342199-224
C151 470pF, COG, 0402, 5%, 50V 268364-471
C152 10uF, X5R, 0805, 10V, 10% 354809-106K
C153 10uF, X5R, 0805, 10V, 10% 354809-106K
C154 10uF, X5R, 0805, 10V, 10% 354809-106K
C155 10uF, X5R, 0805, 10V, 10% 354809-106K
C156 0.1uF, X5R, 0402, 16V, 10% 313771-104C
C157 100
p
F, COG, 0402, 5%, 50V 268364-101
C160 6800pF, X7R, 0402, 16V, 10% 293702-682
C161 6800pF, X7R, 0402, 16V, 10% 293702-682
C162 6800pF, X7R, 0402, 16V, 10% 293702-682
C164 470pF, COG, 0402, 5%, 50V 268364-471
C165 0.22uF, X5R, 0402, 10V, 10% 342199-224
C167 0.22uF, X5R, 0402, 10V, 10% 342199-224
C168 10uF, X5R, 0805, 10V, 10% 354809-106K
C169 0.22uF, X5R, 0402, 10V, 10% 342199-224


13
Wi-Fi Module PCB Assembly
ELECTRICAL PART LIST
Capacitors (continued)
Reference
Designator Description Part Numbe
r
Note
C170 100pF, COG, 0402, 5%, 50V 268364-101
C171 100pF, COG, 0402, 5%, 50V 268364-101
C172 0.22uF, X5R, 0402, 10V, 10% 342199-224
C173 0.22uF, X5R, 0402, 10V, 10% 342199-224
C174 6800pF, X7R, 0402, 16V, 10% 293702-682
C175 6800pF, X7R, 0402, 16V, 10% 293702-682
C177 6800pF, X7R, 0402, 16V, 10% 293702-682
C178 6800pF, X7R, 0402, 16V, 10% 293702-682
C181 6800pF, X7R, 0402, 16V, 10% 293702-682
C182 6800pF, X7R, 0402, 16V, 10% 293702-682
C183 6800pF, X7R, 0402, 16V, 10% 293702-682
C184 6800pF, X7R, 0402, 16V, 10% 293702-682
C185 6800pF, X7R, 0402, 16V, 10% 293702-682
C186 6800pF, X7R, 0402, 16V, 10% 293702-682
C187 3.3pF, C0G, 0402, 50V, 0.25pF 317398-3R3CH
C188 22pF, COG, 0402, 50V, 5% 268364-220
C189 47pF, COG, 0402, 50V, 5% 268364-470
C190 1.8pF, 0.1pF, COG, 0402, 50V 317398-1R8BH
C191 10pF, COG, 0402, 5%, 50V 268364-100
C192 1000pF, X7R, 0402, 16V, 10% 293702-102
C193 1000pF, X7R, 0402, 16V, 10% 293702-102
C194 47pF, COG, 0402, 50V, 5% 268364-470
C195 18pF, COG, 0402, 5%, 50V 268364-180
C196 15pF, COG, 0402, 5%, 50V 268364-150
C197 15pF, COG, 0402, 5%, 50V 268364-150
C198 0.01uF, X7R, 0402, 16V, 10% 293702-103
C199 47pF, COG, 0402, 50V, 5% 268364-470
C200 0.1uF, X7R, 0402, 16V, 10% 293702-104
C201 0.01uF, X7R, 0402, 16V, 10% 293702-103
C202 0.1uF, X7R, 0402, 16V, 10% 293702-104
C203 0.1uF, X7R, 0402, 16V, 10% 293702-104
C204 0.1uF, X7R, 0402, 16V, 10% 293702-104
C205 0.1uF, X7R, 0402, 16V, 10% 293702-104
C206 0.1uF, X7R, 0402, 16V, 10% 293702-104
C207 0.1uF, X7R, 0402, 16V, 10% 293702-104
C208 0.1uF, X7R, 0402, 16V, 10% 293702-104
C209 0.1uF, X7R, 0402, 16V, 10% 293702-104
C210 0.1uF, X7R, 0402, 16V, 10% 293702-104
C211 0.01uF, X7R, 0402, 16V, 10% 293702-103
C212 0.1uF, X7R, 0402, 16V, 10% 293702-104
C213 0.01uF, X7R, 0402, 16V, 10% 293702-103
C215 0.1uF, X7R, 0603, 16V, 10% 257154-104K16
C220 0.1uF, X7R, 0402, 16V, 10% 293702-104
C222 0.01uF, X7R, 0402, 16V, 10% 293702-103
C223 0.01uF, X7R, 0402, 16V, 10% 293702-103
C224 0.01uF, X7R, 0402, 16V, 10% 293702-103
C225 0.01uF, X7R, 0402, 16V, 10% 293702-103


14
Wi-Fi Module PCB Assembly
ELECTRICAL PART LIST
Capacitors (continued)
Reference
Designator Description Part Number Note
C226 0.1uF, X7R, 0402, 16V, 10% 293702-104
C227 0.01uF, X7R, 0402, 16V, 10% 293702-103
C233 0.22uF, X5R, 0402, 10V, 10% 342199-224
C300 10uF, X5R, 0603, 6.3V, 20% 313766-106J
C301 0.1uF, X7R, 0603, 16V, 10% 257154-104K16
C302 10uF, X5R, 0603, 6.3V, 20% 313766-106J
C303 10uF, X5R, 0603, 6.3V, 20% 313766-106J
C304 0.1uF, X7R, 0603, 10%, 50V 191470-104
C305 0.1uF, X7R, 0603, 10%, 50V 191470-104
C307 470pF, X7R, 0402, 50V, 5% 268366-471
C308 10uF, X5R, 0603, 6.3V, 20% 313766-106J
C309 470pF, X7R, 0402, 50V, 5% 268366-471
C310 0.1uF, X7R, 0402, 16V, 10% 293702-104
C311 1uF, X7R, 0603, 16V, 10% 257154-105K16
C312 470pF, X7R, 0402, 50V, 5% 268366-471
C314 1500pF, X7R, 0402, 16V, 10% 293702-152
C315 0.1uF, X7R, 0402, 16V, 10% 293702-104
C317 0.1uF, X7R, 0402, 16V, 10% 293702-104
C318 1500pF, X7R, 0402, 16V, 10% 293702-152
C319 22uF, X5R, 0805, 6.3V, 20% 273592-226JM
C320 0.1uF, X7R, 0402, 16V, 10% 293702-104
C321 22uF, X5R, 0805, 6.3V, 20% 273592-226JM
C323 1500pF, X7R, 0402, 16V, 10% 293702-152
C324 0.1uF, X7R, 0402, 16V, 10% 293702-104
C326 1500pF, X7R, 0402, 16V, 10% 293702-152
C328 1500pF, X7R, 0402, 16V, 10% 293702-152
C330 1500pF, X7R, 0402, 16V, 10% 293702-152
C332 1500pF, X7R, 0402, 16V, 10% 293702-152
C334 1500pF, X7R, 0402, 16V, 10% 293702-152
C335 0.1uF, X7R, 0402, 16V, 10% 293702-104
C338 1500pF, X7R, 0402, 16V, 10% 293702-152
C340 0.1uF, X7R, 0402, 16V, 10% 293702-104
C341 0.1uF, X7R, 0402, 16V, 10% 293702-104
C342 1500pF, X7R, 0402, 16V, 10% 293702-152
C343 0.1uF, X7R, 0402, 16V, 10% 293702-104
C344 1500pF, X7R, 0402, 16V, 10% 293702-152
C346 0.1uF, X7R, 0402, 16V, 10% 293702-104
C347 0.1uF, X7R, 0402, 16V, 10% 293702-104
C348 1500
p
F, X7R, 0402, 16V, 10% 293702-152
C349 1500pF, X7R, 0402, 16V, 10% 293702-152
C352 0.1uF, X7R, 0402, 16V, 10% 293702-104
C353 0.1uF, X7R, 0402, 16V, 10% 293702-104
C354 1500pF, X7R, 0402, 16V, 10% 293702-152
C355 1500pF, X7R, 0402, 16V, 10% 293702-152
C357 0.1uF, X7R, 0402, 16V, 10% 293702-104
C358 0.1uF, X7R, 0402, 16V, 10% 293702-104
C359 1500pF, X7R, 0402, 16V, 10% 293702-152


15
Wi-Fi Module PCB Assembly
ELECTRICAL PART LIST
Capacitors (continued)
Reference
Designator Description Part Number Note
C361 1500pF, X7R, 0402, 16V, 10% 293702-152
C363 1500
p
F, X7R, 0402, 16V, 10% 293702-152
C364 1500pF, X7R, 0402, 16V, 10% 293702-152
C367 1500pF, X7R, 0402, 16V, 10% 293702-152
C368 1500pF, X7R, 0402, 16V, 10% 293702-152
C370 1500pF, X7R, 0402, 16V, 10% 293702-152
C371 1500pF, X7R, 0402, 16V, 10% 293702-152
C373 0.1uF, X7R, 0402, 16V, 10% 293702-104
C374 0.1uF, X7R, 0402, 16V, 10% 293702-104
C376 470pF, X7R, 0402, 50V, 5% 268366-471
C377 10uF, X5R, 0603, 6.3V, 20% 313766-106J
C378 470pF, X7R, 0402, 50V, 5% 268366-471
C379 10uF, X5R, 0603, 6.3V, 20% 313766-106J
C380 0.1uF, X7R, 0603, 16V, 10% 257154-104K16
C381 10uF, X5R, 0603, 6.3V, 20% 313766-106J
C382 0.1uF, X7R, 0603, 16V, 10% 257154-104K16
C383 22uF, X5R, 0805, 6.3V, 20% 273592-226JM
C384 22uF, X5R, 0805, 6.3V, 20% 273592-226JM
C385 10uF, X5R, 0603, 6.3V, 20% 313766-106J
C386 0.1uF, X7R, 0603, 16V, 10% 257154-104K16
C400 0.1uF, X7R, 0402, 16V, 10% 293702-104
C401 0.01uF, X7R, 0402, 16V, 10% 293702-103
C402 0.1uF, X7R, 0402, 16V, 10% 293702-104
C403 0.01uF, X7R, 0402, 16V, 10% 293702-103
C404 0.1uF, X7R, 0402, 16V, 10% 293702-104
C405 0.01uF, X7R, 0402, 16V, 10% 293702-103
C406 0.1uF, X7R, 0402, 16V, 10% 293702-104
C407 0.01uF, X7R, 0402, 16V, 10% 293702-103
C408 0.1uF, X7R, 0402, 16V, 10% 293702-104
C409 0.01uF, X7R, 0402, 16V, 10% 293702-103
C410 0.1uF, X7R, 0402, 16V, 10% 293702-104
C411 0.01uF, X7R, 0402, 16V, 10% 293702-103
C412 0.1uF, X7R, 0402, 16V, 10% 293702-104
C413 0.01uF, X7R, 0402, 16V, 10% 293702-103
C414 0.1uF, X7R, 0402, 16V, 10% 293702-104
C415 0.01uF, X7R, 0402, 16V, 10% 293702-103
C416 0.1uF, X7R, 0402, 16V, 10% 293702-104
C417 0.01uF, X7R, 0402, 16V, 10% 293702-103
C418 0.01uF, X7R, 0402, 16V, 10% 293702-103
C419 0.01uF, X7R, 0402, 16V, 10% 293702-103
C420 0.01uF, X7R, 0402, 16V, 10% 293702-103
C421 0.01uF, X7R, 0402, 16V, 10% 293702-103
C422 0.1uF, X7R, 0402, 16V, 10% 293702-104
C423 0.1uF, X7R, 0402, 16V, 10% 293702-104
C424 0.1uF, X7R, 0402, 16V, 10% 293702-104
C425 0.1uF, X7R, 0402, 16V, 10% 293702-104
C426 0.1uF, X7R, 0402, 16V, 10% 293702-104


16
Wi-Fi Module PCB Assembly
ELECTRICAL PART LIST
Capacitors (continued)
Reference
Designator Description Part Number Note
C427 0.1uF, X7R, 0402, 16V, 10% 293702-104
C428 0.1uF, X7R, 0402, 16V, 10% 293702-104
C429 0.1uF, X7R, 0402, 16V, 10% 293702-104
C430 0.1uF, X7R, 0402, 16V, 10% 293702-104
C431 0.1uF, X7R, 0402, 16V, 10% 293702-104
C432 22uF, X5R, 0805, 6.3V, 20% 273592-226JM
C433 22uF, X5R, 0805, 6.3V, 20% 273592-226JM
C434 0.1uF, X7R, 0402, 16V, 10% 293702-104
C435 0.1uF, X7R, 0402, 16V, 10% 293702-104
C500 0.1uF, X7R, 0603, 10%, 50V 191470-104
C501 100pF, COG, 0402, 5%, 50V 268364-101
C502 100pF, COG, 0402, 5%, 50V 268364-101
C503 100
p
F, COG, 0402, 5%, 50V 268364-101
C504 0.1uF, X5R, 0402, 16V, 10% 313771-104C
C505 15pF, COG, 0402, 5%, 50V 268364-150
C506 0.1uF, X5R, 0402, 16V, 10% 313771-104C
C507 15nF, X7R, 0402, 16V, 5% 296732-153
C508 15nF, X7R, 0402, 16V, 5% 296732-153
C509 100pF, COG, 0402, 5%, 50V 268364-101
C510 10uF, X5R, 0603, 6.3V, 20% 313766-106J
C511 100pF, COG, 0402, 5%, 50V 268364-101
C512 100pF, COG, 0402, 5%, 50V 268364-101
C513 100pF, COG, 0402, 5%, 50V 268364-101
C514 15
p
F, COG, 0402, 5%, 50V 268364-150
C515 1000pF, COG, 0402, 5%, 50V 268364-102
C516 100pF, COG, 0402, 5%, 50V 268364-101
C517 100pF, COG, 0402, 5%, 50V 268364-101
C518 0.1uF, X5R, 0402, 16V, 10% 313771-104C
C519 0.1uF, X5R, 0402, 16V, 10% 313771-104C
C521 100pF, COG, 0402, 5%, 50V 268364-101
C601 10uF, X5R, 0603, 6.3V, 20% 313766-106J
C602 100pF, COG, 0402, 5%, 50V 268364-101
C604 100pF, COG, 0402, 5%, 50V 268364-101
C607 100pF, COG, 0402, 5%, 50V 268364-101
C700 0.1uF, X7R, 0402, 16V, 10% 293702-104
C701 0.1uF, X7R, 0402, 16V, 10% 293702-104
C702 10nF, X7R, 0402, 25V, 5% 268367-103
C703 10nF, X7R, 0402, 25V, 5% 268367-103
C704 10nF, X7R, 0402, 25V, 5% 268367-103
C705 10nF, X7R, 0402, 25V, 5% 268367-103
C706 100pF, COG, 0402, 5%, 50V 268364-101
C707 100pF, COG, 0402, 5%, 50V 268364-101
C708 0.1uF, X7R, 0402, 16V, 10% 293702-104
C709 0.1uF, X7R, 0402, 16V, 10% 293702-104
C710 0.1uF, X7R, 0402, 16V, 10% 293702-104
C711 0.1uF, X7R, 0402, 16V, 10% 293702-104
C712 0.1uF, X7R, 0402, 16V, 10% 293702-104


17
Wi-Fi Module PCB Assembly
ELECTRICAL PART LIST
Capacitors (continued)
Reference
Designator Description Part Number Note
C713 0.1uF, X7R, 0402, 16V, 10% 293702-104
C714 0.1uF, X7R, 0402, 16V, 10% 293702-104
C715 0.1uF, X7R, 0402, 16V, 10% 293702-104
C716 0.1uF, X7R, 0402, 16V, 10% 293702-104
C717 1000pF, COG, 0402, 5%, 50V 268364-102
C718 0.1uF, X7R, 0402, 16V, 10% 293702-104
C719 10uF, X5R, 0603, 6.3V, 20% 313766-106J
C720 10uF, X5R, 0603, 6.3V, 20% 313766-106J
C721 10uF, X5R, 0603, 6.3V, 20% 313766-106J
C746 0.01uF, X7R, 0402, 16V, 10% 293702-103
C748 10nF, X7R, 0402, 25V, 5% 268367-103
C749 10nF, X7R, 0402, 25V, 5% 268367-103
C750 10nF, X7R, 0402, 25V, 5% 268367-103
C751 10nF, X7R, 0402, 25V, 5% 268367-103
C752 0.01uF, X7R, 0402, 16V, 10% 293702-103
C768 10nF, X7R, 0402, 25V, 5% 268367-103
C769 10nF, X7R, 0402, 25V, 5% 268367-103
C771 10nF, X7R, 0402, 25V, 5% 268367-103
C772 0.01uF, X7R, 0402, 16V, 10% 293702-103
C773 10nF, X7R, 0402, 25V, 5% 268367-103
C774 10nF, X7R, 0402, 25V, 5% 268367-103
C775 10nF, X7R, 0402, 25V, 5% 268367-103
C776 10nF, X7R, 0402, 25V, 5% 268367-103
C777 10nF, X7R, 0402, 25V, 5% 268367-103
C778 0.01uF, X7R, 0402, 16V, 10% 293702-103
C779 10nF, X7R, 0402, 25V, 5% 268367-103
C780 10nF, X7R, 0402, 25V, 5% 268367-103
C781 10nF, X7R, 0402, 25V, 5% 268367-103
C782 10nF, X7R, 0402, 25V, 5% 268367-103
C783 0.01uF, X7R, 0402, 16V, 10% 293702-103
C784 10nF, X7R, 0402, 25V, 5% 268367-103
C785 10nF, X7R, 0402, 25V, 5% 268367-103
C786 10nF, X7R, 0402, 25V, 5% 268367-103
C787 0.01uF, X7R, 0402, 16V, 10% 293702-103
C788 10nF, X7R, 0402, 25V, 5% 268367-103
C789 10nF, X7R, 0402, 25V, 5% 268367-103
C790 10nF, X7R, 0402, 25V, 5% 268367-103
C791 10nF, X7R, 0402, 25V, 5% 268367-103
C792 10nF, X7R, 0402, 25V, 5% 268367-103
C793 10nF, X7R, 0402, 25V, 5% 268367-103
C794 10nF, X7R, 0402, 25V, 5% 268367-103
C795 10nF, X7R, 0402, 25V, 5% 268367-103
C796 10nF, X7R, 0402, 25V, 5% 268367-103
C797 10nF, X7R, 0402, 25V, 5% 268367-103
C798 10nF, X7R, 0402, 25V, 5% 268367-103
C799 10nF, X7R, 0402, 25V, 5% 268367-103
C900 0.01uF, X7R, 0402, 16V, 10% 293702-103


18
Wi-Fi Module PCB Assembly
ELECTRICAL PART LIST
Capacitors (continued)
Reference
Designator Description Part Number Note
C901 0.01uF, X7R, 0402, 16V, 10% 293702-103
C902 0.01uF, X7R, 0402, 16V, 10% 293702-103
C1003 10uF, X5R, 0603, 6.3V, 20% 313766-106J
C1006 3.3uF, X5R, 0603, 20%, 6.3V 313766-335J
C1007 3.3uF, X5R, 0603, 20%, 6.3V 313766-335J
C1009 10uF, X5R, 0603, 6.3V, 20% 313766-106J
C1011 10pF, COG, 0402, 5%, 50V 268364-100
C1012 10pF, COG, 0402, 5%, 50V 268364-100
C1013 10uF, X5R, 0603, 6.3V, 20% 313766-106J
C1014 220pF, COG, 0402, 5%, 50V 268364-221
C1015 10uF, X5R, 0603, 6.3V, 20% 313766-106J
C1016 0.1uF, X7R, 0402, 16V, 10% 293702-104
C1017 1000
p
F, X7R, 0402, 16V, 10% 293702-102
C1018 1000pF, X7R, 0402, 16V, 10% 293702-102
C1019 1000pF, X7R, 0402, 16V, 10% 293702-102
C1020 1000pF, X7R, 0402, 16V, 10% 293702-102
C1021 0.1uF, X7R, 0402, 16V, 10% 293702-104
C1022 220pF, COG, 0402, 5%, 50V 268364-221
C1023 220pF, COG, 0402, 5%, 50V 268364-221
C1024 0.1uF, X7R, 0402, 16V, 10% 293702-104
C1025 47pF, COG, 0402, 50V, 5% 268364-470
C1026 1uF, X5R, 0402, 10%, 10V 313771-105A
C1027 47pF, COG, 0402, 50V, 5% 268364-470
C1028 1000
p
F, COG, 0402, 5%, 50V 268364-102
C1029 100pF, COG, 0402, 5%, 50V 268364-101
C1030 100pF, COG, 0402, 5%, 50V 268364-101
C1031 100pF, COG, 0402, 5%, 50V 268364-101
C1032 100pF, COG, 0402, 5%, 50V 268364-101
C1100 3.3uF, X5R, 0603, 20%, 6.3V 313766-335J
C1101 470pF, X7R, 0402, 50V, 5% 268366-471
C1102 470pF, X7R, 0402, 50V, 5% 268366-471
C1103 22pF, COG, 0402, 50V, 5% 268364-220
C1104 150pF, X7R, 0402, 16V, 10% 293702-151
C1105 0.1uF, X7R, 0603, 10%, 50V 191470-104
C1107 150
p
F, X7R, 0402, 16V, 10% 293702-151
C1108 150pF, X7R, 0402, 16V, 10% 293702-151
C1109 10uF, X5R, 0603, 6.3V, 20% 313766-106J
C1110 150pF, X7R, 0402, 16V, 10% 293702-151
C1111 150
p
F, X7R, 0402, 16V, 10% 293702-151
C1112 0.1uF, X7R, 0603, 10%, 50V 191470-104
C1113 150pF, X7R, 0402, 16V, 10% 293702-151
C1114 10uF, X5R, 0603, 6.3V, 20% 313766-106J
C1115 100pF, COG, 0402, 5%, 50V 268364-101
C1116 100pF, COG, 0402, 5%, 50V 268364-101
C1117 3.3uF, X5R, 0603, 20%, 6.3V 313766-335J
C1200 100
p
F, COG, 0402, 5%, 50V 268364-101
C1201 1000pF, COG, 0402, 5%, 50V 268364-102


19
Wi-Fi Module PCB Assembly
ELECTRICAL PART LIST
Capacitors (continued)
Reference
Designator Description Part Numbe
r
Note
C1202 100pF, COG, 0402, 5%, 50V 268364-101
C1203 100pF, COG, 0402, 5%, 50V 268364-101
C1204 100pF, COG, 0402, 5%, 50V 268364-101
C1205 100pF, COG, 0402, 5%, 50V 268364-101
C1206 100pF, COG, 0402, 5%, 50V 268364-101
C1207 100pF, COG, 0402, 5%, 50V 268364-101
C1208 100pF, COG, 0402, 5%, 50V 268364-101
C1209 100pF, COG, 0402, 5%, 50V 268364-101
C1210 100pF, COG, 0402, 5%, 50V 268364-101
C1211 100pF, COG, 0402, 5%, 50V 268364-101
C1212 100pF, COG, 0402, 5%, 50V 268364-101
C1213 100pF, COG, 0402, 5%, 50V 268364-101
C1214 100pF, COG, 0402, 5%, 50V 268364-101
C1215 100pF, COG, 0402, 5%, 50V 268364-101
C1216 100pF, COG, 0402, 5%, 50V 268364-101
C1217 100pF, COG, 0402, 5%, 50V 268364-101
C1218 100pF, COG, 0402, 5%, 50V 268364-101
C1221 100pF, COG, 0402, 5%, 50V 268364-101
C1222 100pF, COG, 0402, 5%, 50V 268364-101
C1223 100pF, COG, 0402, 5%, 50V 268364-101
C1224 100pF, COG, 0402, 5%, 50V 268364-101
C1225 100pF, COG, 0402, 5%, 50V 268364-101
C1226 4.7uF, CER, 1210, X7R, 25V 291431-475
C1227 100pF, COG, 0402, 5%, 50V 268364-101
C1228 100pF, COG, 0402, 5%, 50V 268364-101
C1229 100pF, COG, 0402, 5%, 50V 268364-101
C1230 100pF, COG, 0402, 5%, 50V 268364-101
C1231 100pF, COG, 0402, 5%, 50V 268364-101
C1232 100pF, COG, 0402, 5%, 50V 268364-101
C1233 100pF, COG, 0402, 5%, 50V 268364-101
C1234 100pF, COG, 0402, 5%, 50V 268364-101
C1235 100pF, COG, 0402, 5%, 50V 268364-101
C1236 1000pF, COG, 0402, 5%, 50V 268364-102
C1237 1000pF, COG, 0402, 5%, 50V 268364-102
C1300 100nF, X7R, 0402, 16V, 5% 296732-104
C1301 10uF, X5R, 0603, 6.3V, 20% 313766-106J
C1302 2.2uF, X5R, 0402, 20%, 6.3V 313771-225JM
C1303 10uF, X5R, 0603, 6.3V, 20% 313766-106J
C1304 2.2uF, X5R, 0402, 20%, 6.3V 313771-225JM
C1305 10uF, X5R, 0603, 6.3V, 20% 313766-106J
C1306 2.2uF, X5R, 0402, 20%, 6.3V 313771-225JM
C1307 10uF, X5R, 0603, 6.3V, 20% 313766-106J
C1308 2.2uF, X5R, 0402, 20%, 6.3V 313771-225JM
C1309 10uF, X5R, 0603, 6.3V, 20% 313766-106J
C1310 2.2uF, X5R, 0402, 20%, 6.3V 313771-225JM
C1311 10uF, X5R, 0603, 6.3V, 20% 313766-106J
C1312 2.2uF, X5R, 0402, 20%, 6.3V 313771-225JM


20
Wi-Fi Module PCB Assembly
ELECTRICAL PART LIST
Capacitors (continued)
Reference
Designator Description Part Numbe
r
Note
C1313 2.2uF, X5R, 0402, 6.3V, 20% 313771-225JM
C1314 2.2uF, X5R, 0402, 6.3V, 20% 313771-225JM
C1315 2.2uF, X5R, 0402, 6.3V, 20% 313771-225JM
C1316 2.2uF, X5R, 0402, 6.3V, 20% 313771-225JM
C1317 2.2uF, X5R, 0402, 6.3V, 20% 313771-225JM
C1318 4.7uF, CER, 1210, X7R, 25V 291431-475
C1319 0.1uF, X7R, 0603, 10%, 50V 304991-104
C1320 10uF, X5R, 0603, 6.3V, 20% 313766-106J
C1321 2.2uF, X5R, 0402, 6.3V, 20% 313771-225JM
C1322 10uF, X5R, 0603, 6.3V, 20% 313766-106J
C1323 2.2uF, X5R, 0402, 6.3V, 20% 313771-225JM
C1324 10uF, X5R, 0603, 6.3V, 20% 313766-106J
C1325 10uF, X5R, 0603, 6.3V, 20% 313766-106J
C1326 2.2uF, X5R, 0402, 6.3V, 20% 313771-225JM
C1328 10uF, X5R, 0603, 6.3V, 20% 313766-106J
C1329 10uF, X5R, 0603, 6.3V, 20% 313766-106J
C1330 10uF, X5R, 0603, 6.3V, 20% 313766-106J
C1331 100nF, X7R, 0402, 16V, 5% 296732-104
C1332 100nF, X7R, 0402, 16V, 5% 296732-104
C1333 1uF, X5R, 0402, 10%, 10V 313771-105A
C1335 1000pF, X7R, 0402, 16V, 10% 293702-102
C1336 1000pF, X7R, 0402, 16V, 10% 293702-102
C1337 1000pF, X7R, 0402, 16V, 10% 293702-102
C1338 1000pF, X7R, 0402, 16V, 10% 293702-102
C1339 1000pF, X7R, 0402, 16V, 10% 293702-102
C1340 1000pF, X7R, 0402, 16V, 10% 293702-102
C1500 1000pF, COG, 0402, 5%, 50V 268364-102
C1501 1000pF, COG, 0402, 5%, 50V 268364-102
C1502 100pF, COG, 0402, 5%, 50V 268364-101
C1503 1000pF, COG, 0402, 5%, 50V 268364-102
C1508 0.1uF, X7R, 0603, 10%, 50V 191470-104
C1509 0.1uF, X7R, 0603, 10%, 50V 191470-104
C1510 470pF, X7R, 0402, 50V, 5% 268366-471
C1511 4.7uF, X5R, 0603, 10V, 20% 313766-475A
C1512 1uF, 0805, X7R, 10%, 25V 181264-105
C1513 0.1uF, X7R, 0603, 10%, 50V 191470-104
C1514 0.1uF, X7R, 0603, 10%, 50V 191470-104
C1515 1206, X7R, 10V, 10%, 10uF 260361-1062
C1516 0.1uF, X7R, 0603, 10%, 50V 191470-104
C1517 1.0nF, 0603, COG, SMD, 25V, 5% 268368-102
C1518 1.0nF, 0603, COG, SMD, 25V, 5% 268368-102
C1519 1000pF, X7R, 1206, 2000V, 20% 359294-102M
C7100 10nF, X7R, 0402, 25V, 5% 268367-103
C7101 10nF, X7R, 0402, 25V, 5% 268367-103
C7102 10nF, X7R, 0402, 25V, 5% 268367-103
C7103 10nF, X7R, 0402, 25V, 5% 268367-103
C7104 10nF, X7R, 0402, 25V, 5% 268367-103

