Bose ControlSpace ESPLink User manual

ControlSpace®ESPLink Output Card
Turn off and unplug the ESP.1.
Detach the top cover by removing the 8 screws.2.
Remove a bracket from an empty slot from slots 5-8 by removing the 2 screws (save these screws). The ESPLink Output Card will replace this bracket.3.
Position the card in the chassis. Be sure to align the card’s LEDs with the holes in the front of the chassis, and make sure the connector on the side of the card is aligned4.
with the connector on the motherboard. Use the black guide on the bottom of the case to direct the card using the grooves. See Figure 1.
When the connector on the card is aligned above the connector on the motherboard, press gently to mate the connectors. See5. Figure 2.
Screw the card into place.6.
Reattach the top cover and fasten the 8 screws.7.
Plug in the power supply and turn on the ESP.8.
Figure 1 Figure 2
CAUTION: Installation should only be performed by trained service personnel.
CAUTION: Make no modification to the system or accessories. Unauthorized alterations may compromise safety, regulatory compliance and system performance.
CAUTION: ESD sensitive device. Handle with care.

©2010 Bose Corporation, The Mountain Framingham,
MA 01701-9168 USA
AM331291 Rev.00
pro.Bose.com
Use the ControlSpace9. ®Designer™ software to verify the card was inserted
correctly:
a) Press scan and confirm that the software detects the card.
b) If the card was installed correctly, right-clicking the ESP and displaying
its properties will show ESPLink in the correct slot in the ESP.
See Figure 3.
Figure 3
If an error message appears, or the software does not properly detect the10.
ESPLink Output Card, repeat the installation instructions. Be sure that the
card is completely pushed into the connector, and that the card is properly
aligned in the chassis.
