Bose F1 Model 812 Passive Installation and operating manual

F1 Flexible Array Loudspeaker System
F1 Model 812 Passive Loudspeaker
Installation and Safety Guidelines
Instrucciones de Instalacion y de Seguridad
Installation et Instructions de Sécurité
Installations- und Sicherheitshinweise

Important Safety Instructions2 English
This product is intended for installation by professional installers only! This document is intended to provide professional installers with
basic installation and safety guidelines for this product in typical fixed-installation systems. Please read this document before attempting
installation.
Solo un instalador profesional deberá montar este producto! Este documento ofrece a los instaladores profesionales instrucciones
básicas de instalación y seguridad para este producto en sistemas típicos de instalación fija. Lea este documento antes de intentar la
instalación.
WARNINGS:
• All Bose®products must be used in accordance with local, state, federal and industry regulations. It is the installer’s responsibility to
ensure installation of the loudspeakers and mounting system is performed in accordance with all applicable codes, including local
building codes and regulations. Consult the local authority having jurisdiction before installing this product.
• Unsafe mounting or overhead suspension of any heavy load can result in serious injury and equipment damage. It is the responsibility
of the installer to evaluate the reliability of any mounting method used for their application. Only professional installers with the
knowledge of proper hardware and safe mounting techniques should attempt to install any loudspeaker overhead.
• Do not use the F1 Model 812 Passive speaker with a tripod/stand that is unstable. The speaker is only designed for use on a 35 mm
post, and the tripod/stand must be capable of supporting a speaker with a minimum weight of 47 lbs (21.4 kg) and an overall size of
26.2” x 13.1” x 14.8” inches (665 mm x 334 mm x 375 mm). Using a tripod/stand that is not designed to support the size and mass of
the F1 Model 812 Passive speaker may lead to an unstable and hazardous condition that could result in injury.
ADVERTENCIA:
• Todos los productos Bose®deben utilizarse de acuerdo con las normas locales, estatales, federales e industriales. Será responsabilidad
del instalador asegurarse de que la instalación de los altavoces y del sistema de montaje se realiza de acuerdo con todos los códigos
aplicables, incluidos los códigos y normativas de construcción locales. Consulte a las autoridades locales pertinentes antes de instalar
este producto.
• El montaje no seguro o la suspensión de cualquier carga pesada puede producir heridas graves y daños al equipo. Será
responsabilidad del instalador evaluar la fiabilidad de cualquier método de montaje empleado en su aplicación. Sólo los instaladores
profesionales con conocimiento de los accesorios adecuados y las técnicas de montaje seguro deberán intentar instalar cualquier
altavoz en suspensión.
• No utilice el altavoz F1 Model 812 Passive con un trípode que no sea estable. Este altavoz ha sido diseñado para utilizarse
exclusivamente en un poste de 35 mm. El trípode debe poder soportar un altavoz con un peso mínimo de 21,4 kg y un tamaño total
de 665 mm x 334 mm x 375 mm (alto x ancho x fondo). El uso de un trípode que no haya sido diseñado para soportar el peso y el
volumen del altavoz F1 Model 812 Passive puede constituir una situación de peligro e inestabilidad que podría ocasionar lesiones.
WARNING: This product contains magnetic material. Contact your physician if you have any questions on whether this might
aect the operation of your implantable medical device.
ADVERTENCIA: Este producto contiene material magnético. Consulte a su médico si tiene alguna duda acerca de los efectos
que esto pudiera tener en el funcionamiento de un dispositivo médico implantado.
CAUTION: Do not make unauthorized alterations to this product; doing so may compromise safety, regulatory compliance, system
performance, and may void the warranty.
PRECAUCIÓN: No realice modificaciones no autorizadas del producto; en caso contrario puede poner en riesgo la seguridad, el
cumplimiento normativo, el rendimiento del sistema y anular la garantía.
WARNING: Do not place naked flame sources, such as lighted candles, on or near the product.
ADVERTENCIA: No coloque llamas vivas, por ejemplo, velas, encima o cerca del aparato.
Important Safety Instructions pro.Bose.com
Instrucciones de Seguridad Importantes
Please read this owner’s guide carefully and save it for future reference.
Lea atentamente esta guía del usuario y guárdela para consultarla en el futuro.

Instructions Importantes Relatives à la Sécurité
pro.Bose.com
English 3Important Safety Instructions
L’installation de ce produit est réservée à un technicien professionnel! Ce document à l’intention des installateurs professionnels
contient les directives de pose et de sécurité relatives pour ce produit en installation fixe. Lisezattentivement ce document avant
l’installation.
ATTENTION:
• Tous les produits Bose®doivent être utilisés en respectant les réglementations locales et nationales. L’installateur est responsable
du respect de tous les codes et règlements locaux et nationaux en vigueur applicables à l’installation et au montage des enceintes.
Consultez les autorités locales compétentes avant d’installer ce produit.
• Tout montage non sécurisé d’une lourde charge peut provoquer des dégâts matériels et des blessures graves. Il en va de la
responsabilité de l’installateur d’évaluer la fiabilité de toute méthode de montage utilisée pour cette application. Seul un installateur
professionnel connaissant le matériel et les techniques de montage adaptées est qualifié pour installer des enceintes suspendues.
• N’utilisez pas l’enceinteF1 modèle812 Passive avec un trépied instable. L’enceinte est conçue pour accueillir un tube de
35mm uniquement, et le trépied doit pouvoir supporter une enceinte d’au moins 21,4kg et aux dimensions suivantes:
665mmx334mmx375mm (HxLxP). L’utilisation d’un trépied non conçu pour supporter le poids d’une enceinteF1 modèle812
Passive aux dimensions précitées est dangereuse en raison de son instabilité.
ATTENTION: Ce produit contient des composants magnétiques. Contactez votre médecin pour toute question relative à
l’eet de ces composants sur le fonctionnement d’un appareil médical implanté.
AVERTISSEMENT: Toute modification non autorisée peut compromettre votre sécurité, le respect des réglementations et le bon
fonctionnement de l’appareil, et en invalidera la garantie.
ATTENTION: Ne placez aucune source de flamme nue, comme une bougie allumée, sur ou près de l’appareil.
Wichtige Sicherheitshinweise
Dieses Produkt darf nur von fachkundigen Monteuren installiert werden! Dieses Dokument soll fachkundigen Monteuren grundlegende
Installations- und Sicherheitsrichtlinie für dieses Produkt in typischen Festinstallationssystemen bieten. Bitte lesen Sie dieses Dokument
vor der Installation durch.
WARNUNG:
• Alle Bose®-Produkte müssen gemäß den örtlichen und staatlichen Vorschriften sowie gemäß allen Branchenbestimmungen verwendet
werden. Der Monteur ist dafür verantwortlich, sicherzustellen, dass die Installation der Lautsprecher und der Halterung gemäß allen
geltenden Vorschriften durchgeführt wird, einschließlich örtlicher Bauvorschriften und Bestimmungen. Wenden Sie sich vor der
Installation dieses Produkts an die zuständige Rechtsbehörde.
• Unsichere Befestigung oder ein Aufhängen über Kopf schwerer Lasten kann zu schweren Verletzungen und Sachschäden führen.
Der Monteur ist dafür verantwortlich, die Zuverlässigkeit der für die Anwendung verwendeten Befestigungsmethoden zu prüfen.
Nur fachkundige Monteure mit Wissen über ordnungsgemäße Befestigungselemente und sichere Befestigungstechniken sollten
Lautsprecher über Kopf installieren.
• Verwenden Sie den F1 Model 812 Passive Lautsprecher nicht mit einem instabilen Stativ. Der Lautsprecher ist nur für die Verwendung
mit einem 35-mm-Sockel ausgelegt, und das Stativ muss einen Lautsprecher mit einem Mindestgewicht von 21,4 kg und einer
Gesamtgröße von 665 mm H x 334 mm B x 375 mm T) tragen können. Bei Verwendung eines Stativs, das nicht auf die Größe und
Masse des F1 Model 812 Passive Lautsprechers ausgelegtes, kann es zu instabilen und gefährlichen Situationen kommen, die zu
Verletzungen führen können.
WARNUNG: Dieses Produkt enthält magnetische Materialien. Bitte wenden Sie sich an Ihren Arzt, wenn Sie wissen möchten,
ob dies den Betrieb Ihres implantierten medizinischen Geräts beeinflussen kann.
ACHTUNG: Keine nicht autorisierten Veränderungen am Produkt vornehmen. Diese können die Sicherheit, die Einhaltung von Richtlinien
und die Systemleistung beeinträchtigen. In diesem Fall kann die Garantie ungültig werden.
WARNUNG: Stellen Sie keine brennenden Kerzen oder ähnliches auf das Gerät oder in die Nähe des Geräts.
Consultez attentivement cette notice d’utilisation et conservez-la pour toute référence future.
Bitte lesen Sie diese Bedienungsanleitung sorgfältig durch und bewahren Sie sie zum späteren Nachschlagen
auf.

Introduction
Product Overview ............................................................................................................................................................................... 5
Features ........................................................................................................................................................................................... 5
Parts List ................................................................................................................................................................................................. 5
Using the Flexible Array ................................................................................................................................................................... 6
Loudspeaker Dimensions................................................................................................................................................................. 6
Flexible Array Coverage Patterns................................................................................................................................................. 7
Installation
U-Bracket Mounting Kit .................................................................................................................................................................... 8
U-Bracket Coverage Patterns ................................................................................................................................................. 9
Yoke Mounting Kit............................................................................................................................................................................... 10
Yoke Mounting Kit Coverage Patterns ................................................................................................................................ 10
Pan-and-Tilt Bracket........................................................................................................................................................................... 11
Pan-and-Tilt Bracket Coverage Patterns ............................................................................................................................ 11
Using the F1 Model 812 Passive on a Tripod Stand................................................................................................................ 12
Tripod Stand Coverage Patterns ........................................................................................................................................... 13
Operation
Recommended Amplifier ................................................................................................................................................................. 14
Example Compatible Bose®Amplifiers............................................................................................................................... 14
Recommended Signal Processing................................................................................................................................................ 14
Recommended Active EQ Settings ............................................................................................................................................. 15
Technical Information
Technical Specifications.................................................................................................................................................................... 16
Limited Warranty and Registration.............................................................................................................................................. 16
Additional Resources
Contact Information........................................................................................................................................................................... 17
Importer Information.................................................................................................................................................................. 17
4 English Installation Guide
Contents pro.Bose.com

Installation Guide English 5
Introduction
pro.Bose.com
Product Overview
The Bose® F1 Model 812 Passive Flexible Array loudspeaker is a small-format, full range sound reinforcement
loudspeaker with FLEX array technology, featuring four field-selectable sound coverage patterns: Straight,
C, J, and Reverse-J. The flexible array shape is easily snapped into place on site, allowing installers to direct
sound energy to listeners and away from wall and ceiling surfaces. This improved directivity means less
reverberation and more SPL in the audience area, which is especially helpful in live music applications. For
installers, mounting is easier because the loudspeaker is more adaptable to the venue, with less compromise
on mounting location or visual appearance.
The F1 Model 812 Passive loudspeaker features a nine-transducer full-range design, including a flexible mid/
high array using eight 2.25-inch drivers, a 100-degree horizontal waveguide, and one high-excursion 12-inch
woofer. Loudspeaker EQ is required and available using the presets provided by any Bose ControlSpace®
processor or PowerMatch® amplifier.
Features
• FLEX array technology - Bose exclusive flexible bae can be configured into four unique shapes, allowing
you to choose the best possible coverage pattern for the application
• 8-driver mid/high line array - Eight drivers, each mounted on a custom waveguide, help deliver wide,
consistent coverage
• 12-inch LF driver - High performance woofer provides strong low frequency output
• Full-range response - Reduces the need for subwoofers for moderate full-range music levels
• Mounting accessories - Built with six M8 threaded insert points that can be combined with a full suite
of optional mounting accessories. Choose from a Pan-and-Tilt Bracket, U-Bracket, and Yoke Bracket, all
available separately from Bose
• Passive design - Optimized for indoor installations and distributed systems
• Rugged enclosure - Rugged but professional looking design, great for permanent installations as well as
portable set-ups
• Integrated pole mount - For use with standard 35 mm tripod speaker stands
Parts List
Each F1 Model 812 Passive Flexible Array loudspeaker carton contains the following parts:
• F1 Model 812 Passive Flexible Array loudspeaker
• Installation guide

6 English Installation Guide
Introduction pro.Bose.com
Loudspeaker Dimensions
Using the Flexible Array
Shape the coverage pattern by moving the position of the top and bottom array.
Pulling the array outPushing the array in

Introduction
pro.Bose.com
Installation Guide English 7
Straight Pattern
Reverse-J Pattern
J Pattern
C Pattern
Flexible Array Coverage Patterns

U-Bracket Mounting Kit
The U-Bracket Mounting Kit available from Bose allows for ±115 degrees of rotation to adjust the coverage
angle for wall and ceiling-mounted installations. When the F1 Model 812 Passive loudspeaker is mounted
horizontally, use the flexible array to adjust the horizontal coverage pattern for each loudspeaker by up to 40
degrees, and the U-bracket to adjust the vertical mounting angle and direct the loudspeaker’s 100 degrees
of vertical coverage. This vertical and horizontal flexibility maximizes coverage with each loudspeaker and
supports asymmetrical configurations to reduce side wall reflections and improve clarity.
For complete safety and installation instructions, see the U-Bracket Mounting Kit Installation Guide included
with the mounting kit (Product Code 736453-0110).
8 English Installation Guide
Installation pro.Bose.com
U-Bracket Ranges
Speaker
Orientation
Pan/Yaw
Degrees
Tilt/Pitch
Degrees
Horizontal -±115°
Vertical ±115° -
The Bose® logo on the loudspeaker can be adjusted
for horizontal mounting. Pull the logo away from the
loudspeaker grille and rotate it 90 degrees in either
direction. Once repositioned, push the logo back in
toward the loudspeaker so it is flush with the grille.
Horizontal Mount
±115°
Side View: Horizontal Ceiling Mount Side View: Horizontal Wall Mount
±115°
You can also mount the F1 Model 812 Passive loudspeaker vertically, using
the flexible array to adjust the vertical coverage pattern and the U-bracket
to adjust the horizontal mounting angle.
Vertical Mount

U-Bracket Coverage Patterns
Top View: Reverse-J, C, and J Patterns
Asymmetrical array configuration to reduce side wall reflections and improve clarity
Top View: C Patterns
Directed 100° vertical coverage and symmetrical horizontal coverage
Side View
±115° mounting angle adjustment, directed 100° vertical coverage
Installation Guide English 9
Installation
pro.Bose.com

Yoke Mounting Kit
The Yoke Mounting Kit available from Bose allows for adjustment of the pitch (up/down angle) and yaw
(right/left angle) of the loudspeaker in ceiling-mounted installations. Use the flexible array to futher refine the
vertical coverage pattern by up to 40 degrees. The yoke mounting bracket is suitable for standard and high
ceiling installations.
For complete safety and installation instructions, see the Yoke Mounting Kit Installation Guide included with
the mounting kit (Product Code 736451-0110).
Pitch and Yaw Ranges - Ceiling Mounted
Pitch Degrees Yaw Degrees
±45° ±7.5°
Yoke Mounting Kit Coverage Patterns
10 English Installation Guide
Installation pro.Bose.com
Side View: J Pattern
Side View: C Pattern
Standard Ceiling
Standard Ceiling High Ceiling
High Ceiling

Installation Guide English 11
Installation
pro.Bose.com
Pan-and-Tilt Bracket
The Pan-and-Tilt Bracket available from Bose allows both pan/yaw (right/left angle) and tilt/pitch (up/down
angle) adjustment for the wall-mounted F1 Model 812 Passive loudspeaker. Use the flexible array to further
refine the vertical coverage pattern by up to 40 degrees.
For complete safety and installation instructions, see the RMUBRKT1 Pan-and-Tilt Bracket Installation Guide
included with the bracket accessory kit (Product Code 738453-0110).
Pan-and-Tilt Bracket Coverage Patterns
Side View: J Pattern
Achieve your intended coverage without tilting the loudspeaker
Side View: C Pattern
Pan-and-Tilt Ranges - Wall Mounted
Speaker
Orientation
Pan/Yaw
Degrees
Tilt/Pitch
Degrees
Horizontal ±15° 0° to 30°
Vertical ±45° 0° to 15°
Pan-and-Tilt Bracket Coverage Patterns
Side View: J Pattern
Achieve your intended coverage without tilting the loudspeaker
Side View: C Pattern
Pan-and-Tilt Ranges - Wall Mounted
Speaker
Orientation
Pan/Yaw
Degrees
Tilt/Pitch
Degrees
Horizontal ±15° 0° to 30°
Vertical ±45° 0° to 15°

Using the F1 Model 812 Passive on a Tripod Stand
The bottom of the F1 Model 812 Passive loudspeaker includes pole cup for mounting the loudspeaker on a
tripod speaker stand. The pole cup fits a standard 35 mm post.
WARNING: The F1 Subwoofer speaker stand is not compatible with the F1 Model 812 Passive loudspeaker. The
bottom of the F1 Model 812 Passive is designed to be used only with a standard 35 mm pole mount.
WARNING: Do not use the F1 Model 812 Passive loudspeaker with a tripod stand that is unstable. The
loudspeaker is only designed for use on a 35 mm pole, and the tripod stand must be capable of supporting
a loudspeaker with a minimum weight of 21.31 kg (47 lb) and an overall size of 665 mm H x 334 mm W x 375
mm D (26.2” H x 13.1” W x 14.8” D). Using a tripod stand that is not designed to support the size and mass of
the F1 Model 812 Passive loudspeaker may lead to an unstable and hazardous condition that could result in
injury.
Installation pro.Bose.com
12 English Installation Guide
Pole cup fits a
standard 35 mm
tripod stand

Installation
pro.Bose.com
Installation Guide English 13
Tripod Stand Coverage Patterns
Side View: Straight Pattern
Side View: Reverse-J Pattern
Side View: J Pattern
Side View: C Pattern

Recommended Amplifier
Selecting the proper amplifier size for a given loudspeaker requires analysis of the transducer long-term (or
RMS) power rating, dynamic range of the input-source material (crest factor), desired sound pressure levels,
and other factors. As a general guideline, the following table provides recommended power amplifier ranges.
Model Nominal Impedance Required Channels Amp Power Rating
F1 Model 812 Passive 8 Ω 1 300 - 1200 W
CAUTION: Failure to follow these guidelines may result in damage to the loudspeaker.
The Bose® PowerMatch configurable power amplifiers oer optimal amplification, amplifier limiting, digital
signal processing (DSP), and DSP presets for use with the F1 Model 812 Passive Flexible Array loudspeaker.
Please refer to the specifications listed on the pro.bose.com website for amplifiers and compare with the
table above to determine which model is best for your particular system design.
Recommended Signal Processing
Digital signal processing (DSP) is required for infrasonic bandpass protection, amplifier power limiting, and
active equalization to the F1 Model 812 Passive loudspeaker. Bose PowerMatch amplifiers provide all required
DSP functions, including amplifier limiting functions, as well as presets that automatically set all DSP values
for the loudspeaker in each of the four flexible array positions.
Bose ControlSpace® DSP hardware, including the ESP-880, ESP-1600, ESP-1240, ESP-4120, and ESP-00, can
also be used to provide active equalization and bandpass protection.
The latest Control Space Designer software for PowerMatch and DSP hardware, which contains the latest F1
preset files, can be found in the Software section of pro.Bose.com.
The following table lists the required infrasonic bandpass protection and amplifier limiter settings for the F1
Model 812 Passive loudspeaker when used without additional subwoofers.
Bandpass Limiter
High Pass Low Pass V Peak V RMS
Speaker Type Freq. Type Freq. Threshold Attack Release Threshold Attack Release
F1 Model
812 Passive
BW24 40 BW24 20000 100 1.5 ms 100 ms 50 1 s 2 s
Technical Information pro.Bose.com
14 English Installation Guide

Installation Guide English 15
Technical Information
pro.Bose.com
The following table lists recommended Active EQ raw values for the F1 Model 812 Passive loudspeaker when
used without additional subwoofers. For EQs with fewer than 9 bands, subtract bands 9, 8, and 7, in that
order.
Straight Coverage Pattern
Band 1 Band 2 Band 3 Band 4 Band 5 Band 6 Band 7 Band 8 Band 9
Frequency 60 115 400 485 570 1000 3000 6800 12000
Gain 9.0 3.1 -2.0 -5.0 2.0 -2.0 -4.5 1.0 2.0
Bandwidth 0.500 0.800 0.330 0.750 0.300 0.333 1.752 0.800 0.500
(Q) 2.871 1.780 4.320 1.902 4.800 4.323 0.775 1.780 2.871
C Coverage Pattern
Band 1 Band 2 Band 3 Band 4 Band 5 Band 6 Band 7 Band 8 Band 9
Frequency 60 115 400 485 570 1000 2500 3000 9500
Gain 9.0 3.1 -2.0 -5.0 2.0 -2.0 -5.2 6.5 1.0
Bandwidth 0.500 0.800 0.330 0.750 0.300 0.333 1.550 High Shelf 1.300
(Q) 2.871 1.780 4.320 1.902 4.800 4.323 0.887 High Shelf 1.073
J and Reverse-J Coverage Patterns
Band 1 Band 2 Band 3 Band 4 Band 5 Band 6 Band 7 Band 8 Band 9
Frequency 60 115 400 485 570 1000 3000 3500 6850
Gain 9.0 3.1 -2.0 -5.0 2.0 -2.0 -4.5 2.0 1.5
Bandwidth 0.500 0.800 0.330 0.750 0.300 0.333 1.950 High Shelf 1.000
(Q) 2.871 1.780 4.320 1.902 4.800 4.323 0.686 High Shelf 1.414
Recommended Subwoofers
The F1 Model 812 Passive loudspeaker can be used without a subwoofer. However, it can also be used with a
subwoofer, in which case Bose recommends the MB12 passive subwoofer for indoor installed applications.
The F1 Subwoofer can be used with the F1 Model 812 Passive loudspeaker. However, the F1 Subwoofer is an
active subwoofer and may not be suitable in system setups that include the F1 Model 812 Passive loudspeaker.
WARNING: The F1 Subwoofer speaker stand is not compatible with the F1 Model 812 Passive loudspeaker. The
bottom of the F1 Model 812 Passive is designed to be used only with a standard 35 mm pole mount.

Physical Specifications
Connectors Two (2) parallel-wired NL4 NEUTRIK®speakON®connectors
Four-terminal barrier strip (for use with speaker wire up to 12 gauge)
Suspension/Mounting 6 x M8 threaded inserts, 1 x 1-3/8” (35 mm) pole mount
Enclosure High impact composite materials
Grille Powder-coated perforated steel grille
Dimensions (H x W x D), mm 665 mm x 334 mm x 375 mm
Dimensions (H x W x D), inches 26.2” x 13.2” x 14.8”
Net Weight 21.3 kg (47 lbs)
Environmental Rating Indoor
Technical specifications subject to change. See pro.Bose.com for the latest technical data sheet and for more information.
Limited Warranty
Your product is covered by a limited warranty, Visit pro.Bose.com for warranty details.
The warranty information provided with this product does not apply in Australian and New Zealand. See our
website at www.bose.com/au/warranty or www.bose.com/nz/warranty for details of the Australian and New
Zealand warranty.
NEUTRIK® and speakON® are registered trademarks of Neutrik AG.
16 English Installation Guide
Technical Information pro.Bose.com

Technical Information
pro.Bose.com
Installation Guide English 17
Visit us on the web at pro.Bose.com.
Americas
(USA, Canada, Mexico, Central America, South
America)
Bose Corporation
The Mountain
Framingham, MA 01701 USA
Corporate Center: 508-879-7330
Americas Professional Systems,
Technical Support: 800-994-2673
Australia
Bose Pty Limited
Unit 3/2 Holker Street
Newington NSW Australia
TEL [phone]
Belgium
Bose N.V. / S.A
Limesweg 2, 03700
Tongeren, Belgium
TEL [phone]
China
Bose Electronics (Shanghai) Co Ltd
36F West Gate Tower
1038 West Nanjing Road
Shanghai, P.R.C. 200041 China
TEL [phone]
France
Bose S.A.S
12 rue de Temara
78100 St. Germain en Laye, France
TEL [phone]
Germany
Bose GmbH
Max-Planck Strasse 36D 61381
Friedrichsdorf, Deutschland
TEL [phone]
Hong Kong
Bose Limited
Suites 2101-2105, Tower One, Times Square
1 Matheson Street, Causeway Bay, Hong Kong
TEL [phone]
India
Bose Corporation India Private Limited
Salcon Aurum, 3rd Floor
Plot No. 4, Jasola District Centre
New Delhi – 110025, India
TEL [phone]
Italy
Bose SpA
Centro Leoni A – Via G. Spadolini
5 20122 Milano, Italy
TEL [phone]
Japan
Bose Kabushiki Kaisha
Shibuya YT Building
28-3 Maruyama-sho
Shibuya-Ku, Tokyo, 150, Japan
TEL [phone]
www.bose.co.jp
The Netherlands
Bose BV
Nijverheidstraat 8 1135 GE
Edam, Nederland
TEL [phone]
United Kingdom
Bose House
Quayside Chatham Maritime
Chatham, Kent ME4 4QZ
TEL [phone]
See website for other countries
Contact Information
Importer Information
European Union
Bose GP, Castleblayney Road, Carrickmacross, County Monaghan, Ireland
China
Bose Electronics (Shanghai) Company Limited, Part C, Plan 9, No. 353 North Riying Road, China (Shanghai)
Pilot Free Trade Zone
Taiwan
Bose Taiwan Branch, 9F-A1, No. 10, Section 3, Minsheng East Road, Taipei City 104, Taiwan
Mexico
Bose de México, S. de R.L. de C.V., Paseo de las Palmas 405-204, Lomas de Chapultepec, 11000 México, D.F.

18 English Installation Guide
Additional Information pro.Bose.com

Installation Guide English 19
Additional Information
pro.Bose.com

©2016 Bose Corporation, The Mountain,
Framingham, MA 01701-9168 USA
AM740742 Rev. 01
