Your Sound Solution™
Versatility
Whether you are building a home theater, upgrading your stereo
system, or adding sound to your favorite room, Boston CR has a speaker
that is perfect for you.A variety of sizes and finishes makes CR ideal for
your family room, bedroom, theater room or whole house music
system. Extremely versatile, Boston CR speakers are at home on a
bookshelf, a floor stand, or mounted to the wall.And, for added
placement flexibility, the CRC7 can be mounted horizontally and/or
vertically around a flat panel TV.All CR speakers have rotating logos
and built-in keyhole mounts for extreme placement flexibility.
For precise positioning, use the optional CRB mounting bracket.
Technology
Boston engineers employed Finite Element Analysis (FEA) and 3D
modeling to optimize the geometryof both the cone and the surround.
Boston CR speakers feature Kortec tweeters. Kortec is a material that
offers detailed high-frequency response—often limited to metal
domes—with the smoothness of a woven material, likesilk. Ferrofluid
and an extruded aluminum heat sink combine to improve the tweeter’s
power handling and reliability.
SPECIFICATIONS
FREQUENCY RESPONSE (±3dB)
RECOMMENDED AMPLIFIER POWER
NOMINAL IMPEDANCE
SENSITIVITY [1watt(2.83v) at 1m]
BASS UNIT
PASSIVE RADIATOR
TWEETER
CROSSOVER FREQUENCY
NET WEIGHT
DIMENSIONS
(HxWxD)
MAGNAGUARD SHIELDING*
CR77 /The largest Boston CR bookshelf
speaker,the CR77 is a two-way, full-range,
magnetically shielded system. Its 61⁄2-inch
woofer delivers deep,tight bass. It also
features a 1-inch Boston Kortec®tweeter.
CR67 /Ideal for stereo systems, home
theater surrounds, or as speakers for
whole-house music systems. The CR67
speaker features a 3⁄4-inch Kortec®tweeter
and 51⁄4-inch woofer.
CR57 /Don’tlet its size fool you.
The versatile CR57 fills a room with
rich, vibrant Boston Sound, making it a
great choice as main speakers or as
surrounds for a larger system. It offers
Boston’s3⁄4-inch Kortec®tweeter and a
41⁄2-inch woofer.
CRC7 /Unique mounting design enables
L/C/R use around an LCD or flat screen
monitor. The CRC7 features Boston’s
1-inch tweeter,a 41⁄2-inch woofer, 41⁄2-inch
passive radiator, and some very
intelligent engineering.
Kortec®soft dome tweeter and
internally-braced cabinet delivers
clean, pure sound
MagnaGuard®magnetic shielding
for video applications*
Woofer’s coaxial phase plug
draws heat away from the voice
coil, increasing power handling
Deep Channel™Design pole plate
enables the voice coil to travel
farther without bottoming out
Wide selection of CR sizes and
specifications to fit any
application, and anybudget
CRC7 CR77 CR67 CR57
80Hz-20kHz
10-75 watts
8ohms
89dB
41⁄2"(115mm)
N/A
3⁄4"(19mm) Kortec®
2600Hz
5.3 lbs(2.6 kgs)
91⁄4x5
5⁄8x 61⁄4"
235 x 142 x 159mm
no
62Hz-20kHz
15-100 watts
8ohms
89dB
51⁄4"(135mm)
N/A
3⁄4"(19mm) Kortec®
2600Hz
7.7 lbs(3.5 kgs)
101⁄8x6
3⁄8x 811⁄16"
257 x 162 x 220mm
yes
52Hz-20kHz
15-100 watts
8ohms
89dB
61⁄2"(115mm)
N/A
1"(25mm) Kortec®
2400Hz
13.5 lbs(6.2 kgs)
121⁄4x7
1⁄2x111⁄16"
311 x 191 x 281mm
yes
80Hz-20kHz
15-100 watts
8ohms
89dB
41⁄2"(115mm)
41⁄2"(115mm)
1"(25mm) Kortec®
2400Hz
11 lbs(5.0 kgs)
51⁄4x15
1⁄2x 63⁄16"
134 x 394 x 157mm
yes
Key hole mounts and rotating
logos for flexible placement
