Introducing
Classic Series Speakers
Classic Boston Performance
Classic Boston Styling
Classic Boston Value

Classic Boston speakers,
Classic Boston value
Classic Series was designed to offer Boston’s legendary sound, classic look,
exceptional quality, and value. Classic loudspeakers provide an excellent
foundation for a multi-channel home theater system or a stereo-only
music system. The Classic Series includes a high performance floorstanding
loudspeaker, two small bookshelf loudspeakers, a center channel, a 100-watt
powered subwoofer, and a satellite/center loudspeaker package. All Classic
models are finished in Black Walnut or Cherry Vinyl - a classic look
that looks great anywhere.
Key features
• BostonKortec®softdometweetersforcrystallinehigh-frequencysound
• GraphiteinjectedpolymerwoofersutilizeDeepChannel®Design(DCD)
for more bass from less amplifier power
• Acousticallytunedportforimprovedbass
• MagnaGuard®magneticshieldingpreventsvideointerference
• 5-waygold-platedbindingpostsforhook-upexibilityand
the purest signal transfer
Classic speakers are available in Cherry and Black Walnut finishes.

CS 226
Dual 6½” 2-Way Floorstanding Speaker
US MAP $249.99 each
CS 225C
Dual 5¼” 2-Way Center Channel Speaker
US MAP $179.99 each
CS Sub10
100 Watt 10” Down-firing DCD Subwoofer
US MAP $249.99 each
CS 26 and 23
CS 26 2-Way 6½”Bookshelf Speaker
MAP $149.99 each
CS 23 2-Way 3½”Bookshelf Speaker
US MAP $119.99 each
CS 2310 System
(4) CS 23 2-Way 3½”Bookshelf Speakers
(1) CS 223C Dual 3½”2-Way Center Channel Speaker
(1) CS Sub10 100 Watt 10”Subwoofer
US MAP $849.99
Available now.

300 Jubilee Drive, Peabody, MA 01960 bostonacoustics.com
© 2008 All rights reserved. Boston, Boston Acoustics, and BassTrac are registered trademarks, and the B/A ellipse symbol and Play Smart are trademarks of Boston Acoustics, Inc.
300 Jubilee Drive, Peabody, MA 01960 bostonacoustics.com
© 2008 All rights reserved. Boston, Boston Acoustics, BassTrac, Deep Channel, Kortec, and MagnaGuard are registered trademarks, and the B/A ellipse symbol and Play Smart are trademarks of Boston Acoustics, Inc.
Specications CS 23 CS 26 CS 223C* CS 225C CS 226
Frequency Range (±3dB) 120Hz – 20kHz 52Hz – 25kHz 100Hz – 20kHz 80Hz – 25kHz 46Hz – 25kHz
Recommended Amplier 10 – 150 watts 10 – 150 watts 15 – 150 watts 15 – 175 watts 15 – 250 watts
Sensitivity 89dB [SPL/2.8V at 1m] 89dB [SPL/2.8V at 1m] 89dB [SPL/2.8V at 1m] 89dB [SPL/2.8V at 1m] 89dB [SPL/2.8V at 1m]
Nominal Impedance 8 ohms 8 ohms 8 ohms 8 ohms 8 ohms
Crossover Frequency 2,700Hz 2,400Hz 2,700Hz 2,400Hz 2,800Hz
Woofers 3
1/2”(89mm) DCD 61/2” (165mm) DCD Dual 31/2”(89mm) DCD Dual 51/4” (133mm) DCD
Dual 61/2”(165mm) DCD
Graphite injected Graphite injected Graphite injected Graphite injected Graphite injected
polymer woofer polymer woofer polymer woofer polymer woofer polymer woofer
Passive Radiators — — — — —
High-Frequency Driver 1”(25mm) Kortec®1”(25mm) Kortec 1”(25mm) Kortec 1”(25mm) Kortec 1”(25mm) Kortec
Soft Dome Soft Dome Soft Dome Soft Dome Soft Dome
Dimensions (H x W x D) 711/16 x 5 x 415/16” 121/4x 81/4” x 91/16” 51/2x 121/2x 41/3” 6 1/4x 165/8x 8” 3713/16 x 81/4x 103/8”
(195 x 127 x 124mm) (311 x 210 x 230mm) (141 x 318 x 112mm) (159 x 421 x 203mm) (960 x 210 x 263mm)
Weight: 4 lbs (1.8Kg) 12.5 lbs (5.7Kg) 7 lbs (3.2Kg) 15 lbs (6.8Kg) 33 lbs (15Kg)
* Only available in CS 2310
Specications CS Sub10
Frequency Range 32 – 150 Hz
Amplier Power 100 watts RMS; BassTrac® circuitry eliminates distortion
Bass Driver 10”(254mm) DCD
Dimensions (H x W x D) 15 x 15 x 15”
(381 x 381 x 381mm)
Weight: 32 lbs (14.5kg)
Boston Acoustics continually strives to update and improve its products.
The specifications and construction details are subject to change without notice.
Available nishes for all models
Cherry Vinyl
Black Walnut Vinyl
