BougeRV 30 Quart User manual

For Portable Car RefrigeratorBougeRV 30 Quart / 23 Quart

1. Safety InstructionsPage12. Product FeaturesPage23. Product StructurePage24. Preparing Before UsePage35. Function and OperationPage36. Car Battery Protection Voitage ReferencePage57. Cleaning and StoragePage68. Troubleshooting and Error ProblemsPage69. Warranty and MaintenancePage910. Technical InformationPage10

①②③④⑤⑥⑦⑧Car Refrigerator Electrical SchematicPackage included: 12/24V DC power cord,
110~240V AC power cord, User Manual,
Removable Basket.
①Ventilation port
②12/24V power outlet
③Interior handle
④Control panel & Digital display
⑤⑥Seal rubber ring
⑦Refrigerator cabinet
⑧Removable divider(23Qt modle doesn’t have)
USB
Multiple Application Scenarios: you can use the fridge on various vehicles such as SUV, Truck, RV, Camper, Jeep, Van, Boat, etc. You can take it with you, during camping, tailgating, road trips， outdoor travels, off road, even at home.Freezer or Refrigerator: with temp range -4 ℉~50℉, you can use it as a freezer or refrigerator. Energy Efficiency: with ECO energy saving mode, the operating mode is less than 45W. It comsumes far less than 1kwh/day for its intelligent cycle work. Fast Cooling with Compressor Refrigeration: running on Max mode in empty condi-tion, the freezer could achieve 16 min fast cooling from 77℉ to 32℉ and 50 min from 77℉ to -4℉3-level battery protection mode: the battery monitor will shut off the fridge/freezer as soon as the supply voltage falls below the set level.45dB Low Noise: the fridge is designed low noise to make sure you a good sleep after a long driving.

Power Supply1. Unpackage and take out the accessories, let it stand 24 hours.2. Before using it for the first time, clean the inside and outside of the car refrigera-tor with a damp cloth and wait until it gets dry.3. Place your refrigerator at a proper position which depends on your use scenario （car, truck, RV, camper, Van, Jeep, SUV, boat, home, etc.）4. According to your use scenario, please choose the right power cord (AC cord or DC cord) for the right power supply. Please read the next part carefully for the details.Connect to 12/24V DC power( use in car, truck or power station)Conect to 110~240V AC power( use at home with ac adapter)4.Preparing Before Use5.Function and OperationDisplay Screen InitializationWhen the refrigerator is powered on, you will hear a beep, and the display will flash once, and then nothing will be displayed. （You need to start on)Turn on/offHold the 3~5 seconds to turn on the refrigerator.

Temperature SettingIn woring status, press or for tempreture setting, the setting will be saved automatically after stopping operating for 4 seconds. Keep holding the button, the tempreture will be adjusted fastly.(Note: the tempreture displayed is the current temperature of the compartment. it will take a while to reach the set temper-ture.)Temperature setting range: -20~+10℃（-4~50℉） The car refrigerator has a power-off memory function, and the working state (power on/off state and working mode) before the power off is automatically restored after the next power on, and there is no need to set it again.Temperature Unit SwitchIn woring status, press one time, the "MAX/ECO" will flash , then press again, you can switch MAX or ECO working mode. When you stop the operation for seconds, it will automatically confirm the final mode.ECO (green light): Energy Saving Mode, 45 watts. MAX (white light):Fasting Cooling Mode, 60 watts.MAX/ECO Mode SwitchingIn woring status, press and at the same time 3~5 seconds to switch Celseius(℃）/Fahrenheit(℉）. (Factory setting is ℉）.Battery Protection ModeIn woring status, long press until the "H" flash, then press in turn to choose HIGH, MEDIUM or LOW levels. We suggest to set high level of the fridge when connect with car battery. To set medium and low level when with other battery. (Factory setting is H）.UnlockingWhen the refrigerator does not operate for about 1 minute, the control panel will automatically lock and unable to operate. You need to long press the until the screen is unlocked, and then you make the setting.

The BougeRV fridge/freezer is equipped with a battery preservation monitor.It hasthree settings to monitor your battery to prevent a full discharge. The higher the setting the higher the cut-off voltage will be.When set to HIGH, the battery monitor will provide maximum protection for the battery running the fridge/freezer against excessive/full discharge. When set to LoW, the battery monitor will allow the fridge/freezer to use more of the battery energy.Recommended temperature for common food:The battery monitor will shut off the fridge/freezer as soon as the supply voltage-falls below the set level. The fridge/freezer will restart after 2 minutes once the cut-in voltage is reached.6.Car Battery Protection Voitage ReferenceVoltageNOTE:Factory default voltage protection level sets to H ModeCut-out is the input voltage in which the fridge/freezer will turn off at.Cut-in is the input voltage in which the fridge/freezer will turn on at.High mode12V DCCut out11.3V10.1V9.6V12.5V11.4V10.9V24.6V22.3V21.3V26.0V23.7V22.7VCut inCut outCut in24V DCMedium ModeLow mode

7.Cleaning and StorageIf an abnormal situation cannot be resolved through simple fault analysis, please contact professional customer service for assistance via [email protected]om.1. The order number.2. Where do you use it?3. What power sources do you use?4. What power cords do you use?5. Set at ECO mode or MAX mode?6. What is the set temperature？7. How much food is inside? Is it empty?8. Do you notice any errors on the display?Note: in order to resolve the issue, you had better attach more details as follows in your email.8.Troubleshooting and Error Problems

The car refrigerator does not workCheck whether if the power is connected correctly or not(If the plug is loose, positive and negative poles are reversed).Check whether the power switch on the operation panel is turned on.Check the cooling ventilation is normal.Check whether if the fuse is blown or not.check whether the door is closedThe door cover seal is damaged or deformed and the seal is not strict.Poor ventilation in the car refrigerator cooling.Improper temperature settings.Causes and solutionsNot cooling SufficientlySome noises are normalThe place of car refrigerator is not stable.Hit the wall or other items.Internal parts loose or fall off.Abnormal noiseTroubleswhen the ambient air humidity> 75%, the surface of the box will normally have slight condensation.The refrigerator surface condensationIt is normal for the temperature to float in a certain range, and it is normal in the range of ± 5 ℃.It is normal that the temperature measured by yourself is 3 ℃ higher than that of the display screen.If the temperature does not drop all the time, please adjust to the lowest temperature and stay for a longer time.Please touch the inner wall of the refrigerator with your hand. If you can feel the cold obviously, there is no problem with the refrigeration of the refriger-ator.Temperature fluctuation/ problems

The definition of the error code on the displayE3E4E2Fan ProblemCompressor turbine speed too low.E5Er1Controller chip overheatingNTC opening or short circuitE1Input voltage too low①Condition one: insert refrigerator power cord into car cigar lighter when it doesn't start. Solution: to connect the refrigerator later after the car starts.②Condition two: the input voltage of the adapter is too low. Solution: to adjust the battery protection level to middle or low level. If fridge still no start properly, pls use a new adapter.Please replace a new fan when you confirm the fan malfunction.Compressor turbine speed too low.The input voltage needs to be adjusted and reconnect the power.Controller chip overheating. It needs to shutdown the power of fridge for 5 minutes. After hat, to check whether if it is an overheating caused by the blockage around the vent of the compressor.①Condition one:E3 appears when use fridge in car, pls shutdown fridge 5 minutes and after that, it can work normally. If it still not works after restart, it is E1 fault, with reference to E1 Fault troubleshooting and solution.②Condition two:E3 appears when use fridge at home, to adjust battery protection level to middle or low level. If it still no works properly, pls use a new adapter.Compressor Start up frequently Input voltage fault.Error CodeError TypeSolutions8

WarrantyBougeRV PORTABLE CAR REFRIGERATOR comes with a 2-year warranty that commences from the date of purchase on BougeRV Amazon Store or BougeRV Official Website, except following situations:Customer ServiceIf there is any problem with the operation or use of the product, please feel free to contact us via:VIP Service & Extra 1-year WarrantyContrived damage.Damage caused by force majeure such as earthquake, conflagration, etc.Damage from inappropriate use or violating this instruction.Damage or malfunction caused by disassembling.24-month limited warrantyLifetime technical support[email protected]om+(86)18924140684+14084294149（U.S.）+(86)18924140684（China）1. Search "QR Code" on your FB2. Scan the QR Code beside3. Join "BougeRV Car Refrigerator Club"4. You become a VIP and get a 3-year warranty1. Search "BougeRV.com"2. Support--Warranty Registration3. Sign up and submit4. You become a VIP and get a 3-year warrantyOption 1Option 299.Warranty and Maintenance

30 QuartECO (Green light): Energy Saving Mode, 45 watts. AC: 110~240V28 L= 0.99cu. ft. 22 L= 0.78cu. ft. DC: 12V/24V-20~10℃(-4~50℉)MAX (white light): Fasting Cooling Mode, 60 watts.RefrigerantR-134a23 Quart1010.Technical Information
