Boulevard LS60THF-1 DVLL60BP90N-1 Quick start guide

LOG SET FOR USE WITH
DIRECT VENT FIREPLACE
MODELS:
DVLL60BP90(N,P)-1
WARNING: If not installed, operated and maintained
in accordance with the manufacturer's instructions,
this product could expose you to substances in fuel
or from fuel combustion which can cause death or
serious illness.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future
reference.
GAS-FIRED
INSTALLATION INSTRUCTIONS
AND
OWNER’S MANUAL
EMPIRE
EMPIRE
Comfort Systems
LS60THF-1
LOGS AND ROCKS SET
WARNINGS
If the information in this manual is not followed ex-
actly, a re or explosion may result causing property
damage, personal injury or loss of life.
– Do not store or use gasoline or other ammable
vapors and liquids in the vicinity of this or any
other appliance.
– Installation and service must be performed by a
qualied installer, service agency or the gas sup-
plier.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any
phone in your building.
• Immediately call your gas supplier from neighbor’s
phone. Follow the gas supplier’s instructions.
• If you cannot reach your gas supplier, call the re
department.
This decorative media set includes an unusual assort-
ment of logs and rocks in varying textures and colors
to complement your linear replace - plus stainless
steel coils to add a unique air.
For ease of installation, unpack all pieces and lay out
so that any identifying letters are visible.
Page 1

35796-0-0815Page 2
TABLE OF CONTENTS
Important Installation Guidelines..............................................................................3
General Information .................................................................................................3
Log Identication ......................................................................................................4
Log Placement ..................................................................................................5 - 10
Master Parts Distributor List................................................................................... 11
How To Order Repair Parts ....................................................................................11
SECTION PAGE
HARDWARE PACK
R12061 (QUANTITY 12)
8-32 X 3/4”
PH PN HD SCREW
R8234 (QUANTITY 12)
1/4” OD X 9/16”SPACER

35796-0-0815 Page 3
Proper Log Placement
Log placement is critical to proper burner performance. Logs must
be correctly positioned. The photos in this manual show the proper
pinned position for logs and rocks on this set. Owners need to be
shown proper log placement and instructed not to move the logs.
Logs and rocks must t rmly onto the locating pins when positioned
as shown in the photos. Misformed logs, rocks, or logs with sloppy
pin holes must be replaced.
Proper Placement of Crushed Glass Media
This replace is designed to use crushed glass media on the burner.
The maximum amount of crushed glass media should not exceed
7-1/2 lbs. Spread out over the entire burner cover, burner screen,
and accent light glass panels.
It is recommended that the crushed glass media be added after the
log and rock set has been properly installed.
CAUTION: Do not place crushed glass around the pilot as-
sembly. Crushed glass is only to be placed on the burner
screen and burner cover. See notice on page 26.
Make Owners Aware of Proper Log Set Operation
Properly installed and properly maintained log sets do not deposit
soot on the logs. If users see soot appear on a log, call for service.
Do not continue to operate the log set.
Qualied Installing Agency
Installation and replacement of gas piping, gas utilization
equipment or accessories and repair and servicing of equip-
ment shall be performed only by a qualied agency. The term
"qualied agency" means any individual, rm, corporation,
or company that either in person or through a representa-
tive is engaged in and is responsible for (a) the installation,
testing, or replacement of gas piping or (b) the connection,
installation, testing, repair, or servicing of equipment; that is
experienced in such work; that is familiar with all precautions
required, and that has complied with all the requirements of
the authority having jurisdiction.
The installation must conform with local codes or, in the
absence of local codes, with the National Fuel Gas Code,
ANSI Z223.1/NFPA54.*
*Available from the American National Standards Institute, Inc. 11 West
42nd St., New York, N.Y. 10018.
IMPORTANT INSTALLATION GUIDELINES
GENERAL INFORMATION
State of Massachusetts: The installation must be made
by a licensed plumber or gas tter in the Commonwealth
of Massachusetts.
Sellers of unvented propane or natural gas-red supple-
mental room heaters shall provide to each purchaser a
copy of 527 CMR 30 upon sale of the unit.
Appliance Certication
This logset is design certied in accordance with American National
Standard/CSA Standard ANSI Z21.88/CSA 2.33 and by Underwrit-
ers Laboratories for use with a Direct Vent Gas Fireplace Heater
and shall be installed according to these instructions.

35796-0-0815Page 4
ROCK IDENTIFICATION
TOP VIEW FRONT VIEW PART NUMBER &
DESCRIPTION
35777
ROCK A
35778
ROCK B
35779
ROCK C
35780
ROCK D
35781
ROCK E
35782
ROCK F
35783
ROCK G
35784
ROCK H
35785
ROCK I
35786
ROCK J
35787
ROCK K
TOP VIEW FRONT VIEW PART NUMBER &
DESCRIPTION

35796-0-0815 Page 5
LOG IDENTIFICATION
TOP VIEW FRONT VIEW PART NUMBER &
DESCRIPTION
35788
LOG L
35789
LOG M
35790
LOG N
35791
LOG O
35792
LOG P
35793
LOG Q
35794
LOG R

35796-0-0815Page 6
Tools Needed:
Protective Gloves
Phillips Screw Driver or Power Drill with Philips Drive
Before you begin: Do not, handle these logs with your bare hands!
Always wear gloves to prevent skin irritation. After handling logs,
wash your hands gently with soap and water.
All Logs
The positioning of the logs is critical to the safe and clean operation
of this heater. Sooting and other problems may result if the logs are
not properly and rmly positioned in the appliance.
Refer to Figure 1 for the following warning.
Warning: Failure to position the parts in accordance with this
diagram or failure to use only parts specically approved with
this appliance may result in property damage or personal injury.
F
Q
L
M
NR
P
O
A
BC
G
DI
E
H
K
J
Log Placement - Figure 1
LOG PLACEMENT
Attention: Refer to Pages 4 and 5 Parts List and Parts View to
order logs or rocks.
NOTE: Once the installation is complete with the logs, rocks, and
crushed glass media in place, operate the replace to verify ame
appearance. If there are ames directly impinging a log, turn off
replace, then remove the crushed glass media directly below where
the ame impingement occurred. This should eliminate sooting on
the log, and provide a more pleasing ame appearance.
Installation of the Pins for Log and Rock Placement
The LS60THF Log and Rock kit includes twelve 8-32x3/4" long
self-threading screws, and twelve 9/16" long spacers that will
need to be installed prior to the log and rock placement.
Note: It is highly recommended that the replace liner be installed
prior to installling the log and rock spacers so interference with
the locator pins is avoided.
Use a standard Philips screwdriver or power drill with a philips
drive to install the screws through a spacer at each of the twelve
pilot hole locations provided in the burner cover. See Figure 2.
These will be the locator pins for the logs and rocks.

35796-0-0815 Page 7
BURNER PIN LOCATIONS - Figure ____
12345678
910
11
12
ACCENT LIGHT GLASS PANELS
1. Place "Rock D" onto Burner Pin #6. Do not allow the rock to rest on the pilot or igniter probes.
LOG PLACEMENT
TOP VIEW
FRONT VIEW
D

35796-0-0815Page 8
2. Place "Rock H" on the burner cover and accent glass panel. Position the rock with the locater pin up and to the left. The top pro-
truding rectangle must be to the right side. This rock may be adjusted later to align with "Log R".
LOG PLACEMENT
BURNER PIN LOCATIONS
12345678
910
11
12
ACCENT LIGHT GLASS PANELS
TOP VIEW
FRONT VIEW
H

35796-0-0815 Page 9
3. Place "Rock C" on Burner Pin #4. The pin must be positioned slightly to the right. This rock may be adjusted later to align with "Log
N".
LOG PLACEMENT
TOP VIEW
FRONT VIEW
C

35796-0-0815Page 10
4. Place "Rock A" onto Burner Pin #2 and #3.
LOG PLACEMENT
BURNER PIN LOCATIONS
12345678
910
11
12
ACCENT LIGHT GLASS PANELS
TOP VIEW
FRONT VIEW
A

35796-0-0815 Page 11
5. Place "Rock F" on the Accent Light Glass panel so the pin is approximately 11 inches from the left side liner. This rock may be
adjusted later to position "Log Q".
LOG PLACEMENT
TOP VIEW
FRONT VIEW
11”
F

35796-0-0815Page 12
6. Place "Rock J" onto Burner Pin #12. The rectangle projection on the rock must be on the right side. This rock may be adjusted later
to posistion "Rock K".
LOG PLACEMENT
BURNER PIN LOCATIONS
12345678
910
11
12
ACCENT LIGHT GLASS PANELS
TOP VIEW
FRONT VIEW
J

35796-0-0815 Page 13
7. Place "Rock E" on Burner Pin #7. The pin on the rock must be on the right side.
LOG PLACEMENT
TOP VIEW
FRONT VIEW
E

35796-0-0815Page 14
8. Place "Rock K" onto the projection on "Rock J". These two rocks must be placed so they are away from the burner as shown.
LOG PLACEMENT
BURNER PIN LOCATIONS
12345678
910
11
12
ACCENT LIGHT GLASS PANELS
TOP VIEW
FRONT VIEW
K

35796-0-0815 Page 15
9. Place "Rock G" onto Burner Pin #10. The rock must be placed away from the burner and on top of the Accent Light Glass Panel.
LOG PLACEMENT
TOP VIEW
FRONT VIEW
G

35796-0-0815Page 16
10. Place "Rock I" on the rectangular protrusion on "Rock H".
LOG PLACEMENT
BURNER PIN LOCATIONS
12345678
910
11
12
ACCENT LIGHT GLASS PANELS
TOP VIEW
FRONT VIEW
I

35796-0-0815 Page 17
11. Place "Rock B" onto the pin on the left side of "Rock C".
LOG PLACEMENT
TOP VIEW
FRONT VIEW
B

35796-0-0815Page 18
12. Place "LOG O" onto Burner Pin #8 and the pin on "Rock E".
LOG PLACEMENT
BURNER PIN LOCATIONS
12345678
910
11
12
ACCENT LIGHT GLASS PANELS
O
TOP VIEW
FRONT VIEW

35796-0-0815 Page 19
13. Place "LOG P" onto the pin on "LOG O". Angle the log to the right so that it rests on the Accent Light Glass Panel.
LOG PLACEMENT
P
TOP VIEW
FRONT VIEW

35796-0-0815Page 20
14. Place "LOG N" onto Burner Pin #5 and the pin on "ROCK C".
LOG PLACEMENT
BURNER PIN LOCATIONS
12345678
910
11
12
ACCENT LIGHT GLASS PANELS
N
TOP VIEW
FRONT VIEW
