Bowers & Wilkins CWM 5 User manual

CWM 5
Wall Mount Monitor
Product Summary
●The B&W CWM 5 is the compact solution for in-wall speakers. It is completely versatile -
demanding little wall space - and is easy to accommodate in virtually any home or
commercial application.
●Benefiting from B&W's in-house technology throughout, the CWM 5 makes few sonic
compromises. The sound quality easily exceeds most competitively priced conventional
loudspeakers.
B&W Loudspeakers Ltd reserves the right to amend details of the specifications without notice in line with technical developments. E & OE. All trademarks acknowledged.
www.bwspeakers.com
Drive Units
Frequency Response
Sensitivity
Nominal Impedance
Power Handling
1 x 125mm (5in) polypropylene
bass/midrange
1 x 25mm (1in) polymer diaphragm -
tweeter
75Hz - 20kHz ± 3dB on reference axis
87dB spl (2.83V 1m)
8 ohms
20 - 70W into 8 ohms on unclipped
programme
Dimensions
Finish
Height: 227mm Width: 160mm
Min depth req: 75mm (3in) from wall
surface.
Semi-matt white suitable for
customising or pre-painting
