B+B SmartWorx iMediaChassis/20 User manual

iMediaChassis Series
iMediaChassis 3, 6 and 20 slot
USER MANUAL

IMediaChassis Series
i
Advantech B+B SmartWorx - Americas
707 Dayton Road
Ottawa, IL 61350 USA
Phone (815) 433-5100
Fax (815) 433-5105
Advantech B+B SmartWorx - European Headquarters
Westlink Commercial Park
Oranmore, Co. Galway, Ireland
Phone +353 91-792444
Fax +353 91-792445
www.advantech-bb.com
B+B SMARTWORX TECHNICAL SUPPORT
USA/Canada: 1 (800) 346-3119 (Ottawa IL USA location)
Monday - Friday, 7:00 a.m. to 7:00 p.m. CST
Europe: +353 91 792444 (Ireland location)
Monday - Friday, 8 a.m. to 5:00 p.m. GMT
Email: support@advantech-bb.com
Web: www.advantech-bb.com

IMediaChassis Series
ii
CONTENTS
B+B SMARTWORX TECHNICAL SUPPORT…………………………… i
List of Figures………………………………………………………………. iv
FCC RADIO FREQUENCY INTERFERENCE STATEMENT…………. v
Class A...................................................................................................... vi
Class B...................................................................................................... vi
WARRANTY………………………………………………………………. viii
ABOUT THE IMEDIACHASSIS/20………………………………………..1
HARDWARE FEATURES…………………………………………………. 1
Alarm Reset, Last Gasp and Temperature Gauge.........................1
Alarm Reset Button.........................................................................2
Last Gasp Alarm .............................................................................2
Temperature Gauge........................................................................3
SNMP Write Lock............................................................................3
SNMP Management Module LEDs.................................................4
Installing the iMediaChassis/20.............................................................. 4
DC Power Supply Module Wiring Instructions................................5
Installing SNMP Management and Application (iMcV-) Modules ..... 6
Replacing Power Supply Modules......................................................... 7
User Replaceable Power Supplies.................................................7
Dual AC, Part Number 850-10960-2AC..........................................7
Dual DC, Part Number 850-10960-2DC.........................................8
Dual AC, Part Number 605-10144-2AC..........................................9
Dual DC, Part Number 605-10145-2DC.........................................9
iMediaChassis/20 Specifications…………………………………………10
About the iMediaChassis/6………………………………………………. 11
Hardware Features 12
Alarm Reset, Last Gasp, and Temperature Gauge......................12
Alarm Reset Button.......................................................................12
Last Gasp Alarm ...........................................................................12

IMediaChassis Series
iii
Temperature Gauge......................................................................12
SNMP Write Lock..........................................................................13
Installing the iMediaChassis/6.............................................................. 13
DC Power Wiring, Replacing Power Supply Modules and Fans..... 15
DC Power Supply Wiring Instruction
s.................................................15
User-Replaceable Power Supply Modules...................................15
Fans..............................................................................................16
Installing Management and Application (iMcV-)Modules................. 16
Installing Applications Modules.....................................................16
iMediaChassis/6 Specifications............................................................ 17
About the iMediaChassis/3……………………………………………… 18
Hardware Features……………………………………………………….. 18
Alarm Reset, Last Gasp, and Temperature Gauge......................18
Alarm Reset Button.......................................................................18
Last Gasp Alarm ...........................................................................19
Temperature Gauge......................................................................19
Installing the iMediaChassis/3.............................................................. 19
DC Power Wiring, Replacing Power Supply Modules and Fans..... 20
DC Power Supply Module Wiring Instructions..............................20
Power Supply Modules.................................................................21
Fans..............................................................................................21
Installing Management and Application Modules .................................... 21
Installing Applications Modules.....................................................22
SNMP Write Lock..........................................................................22
iMediaChassis/3 Specifications…………………………………………..23
Hardware Feature Matrix……………………………………………….. 24
ELECTROSTATIC DISCHARGE PRECAUTIONS…………………….25
CERTIFICATIONS……………………………………………………….. 26

IMediaChassis Series
iv
LIST OF FIGURES
Figure 1: iMediaChassis/20, all models........................................................... 2
Figure 2: SNMP Write Lock Switch....................................................................... 3
Figure 3: DC Wiring Scheme................................................................................. 5
Figure 4: 850-10960-2AC PS................................................................................. 7
Figure 5: 850-10960-2DC PS ................................................................................ 8
Figure 6: 605-10144-2AC PS................................................................................. 9
Figure 7: 605-10144-2DC PS ................................................................................ 9
Figure 8: iMediaChassis/6 PS ............................................................................. 11
Figure 9: DC Wiring Scheme for iMediaChassis/6.............................................. 15
Figure 10: SNMP Module location for iMediaChassis/6 .................................... 16
Figure 11: DC Wiring Scheme iMediaChassis/3 ................................................. 21
Figure 12: SNMP Module Slot on iMediaChassis/3............................................ 22

IMediaChassis Series
v
FCC RADIO FREQUENCY INTERFERENCE STATEMENT
This equipment has been tested and found to comply with the limits for a
Class x computing device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment
This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instruction manual,
may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in
which the user will be required to correct the interference at his own
expense.
Any changes or modifications not expressly approved by the manufacturer
could void the user’s authority to operate the equipment.
The use of non-shielded I/O cables may not guarantee compliance with
FCC RFI limits. This digital apparatus does not exceed the Class B limits
for radio noise emission from digital apparatus set out in the Radio
Interference Regulation of the Canadian Department of Communications.
Le présent appareil numérique n’émet pas de bruits radioélectriques
dépassant les limites applicables aux appareils numériques de classe B
prescrites dans le Règlement sur le brouillage radioélectrique publié par le
ministère des Communications du Canada.
Any changes or modifications not expressly approved by the manufacturer could
void the user’s authority to operate the equipment.
The use of non-shielded I/O cables may not guarantee compliance with FCC RFI
limits. This digital apparatus does not exceed the Class A limits for radio noise
emission from digital apparatus set out in the Radio Interference Regulation of the
Canadian Department of Communications.
Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les
limites applicables aux appareils numériques de classe A prescrites dans le
Règlement sur le brouillage radioélectrique publié par le ministère des
Communications du Canada.

IMediaChassis Series
vi
Class A
This equipment has been tested and found to comply with the limits for a Class A
computing device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to
cause harmful interference in which the user will be required to correct the
interference at his/her own expense.
Any changes or modifications not expressly approved by the manufacturer could
void the user’s authority to operate the equipment.
The use of non-shielded I/O cables may not guarantee compliance with FCC RFI
limits. This digital apparatus does not exceed the Class A limits for radio noise
emission from digital apparatus set out in the Radio Interference Regulation of
the Canadian Department of Communications.
Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant
les limites applicables aux appareils numériques de classe A prescrites dans le
Règlement sur le brouillage radioélectrique publié par le ministère des
Communications du Canada.
Class B
This equipment has been tested and found to comply with the limits for a Class B
computing device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to
cause harmful interference in which the user will be required to correct the
interference at his/her own expense.
Any changes or modifications not expressly approved by the manufacturer could
void the user’s authority to operate the equipment.
The use of non-shielded I/O cables may not guarantee compliance with FCC RFI
limits. This digital apparatus does not exceed the Class B limits for radio noise
emission from digital apparatus set out in the Radio Interference Regulation of
the Canadian Department of Communications.
Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant
les limites applicables aux appareils numériques de classe B prescrites dans le
Règlement sur le brouillage radioélectrique publié par le ministère des
Communications du Canada.

IMediaChassis Series
vii
Product
Description
Version
FCC
Class A
FCC
Class B
iMediaChassis/20
Dual AC
Dual DC
iMediaChassis/6
AC
Dual AC
DC
Dual DC
iMediaChassis/3
AC
2AC
DC
2DC
ACDC

IMediaChassis Series
viii
WARRANTY
Effective for products of B+B SmartWorx shipped on or after May 1, 2013, B+B SmartWorx
warrants that each such product shall be free from defects in material and workmanship for
its lifetime. This limited lifetime warranty is applicable solely to the original user and is not
transferable.
This warranty is expressly conditioned upon proper storage, installation, connection,
operation and maintenance of products in accordance with their written specifications.
Pursuant to the warranty, within the warranty period, B+B SmartWorx, at its option will:
1. Replace the product with a functional equivalent;
2. Repair the product; or
3. Provide a partial refund of purchase price based on a depreciated value.
Products of other manufacturers sold by B+B SmartWorx are not subject to any warranty or
indemnity offered by B+B SmartWorx, but may be subject to the warranties of the other
manufacturers.
Notwithstanding the foregoing, under no circumstances shall B+B SmartWorx have any warranty
obligations or any other liability for: (i) any defects resulting from wear and tear, accident, improper
use by the buyer or use by any third party except in accordance with the written instructions or advice
of the B+B SmartWorx or the manufacturer of the products, including without limitation surge and
overvoltage conditions that exceed specified ratings, (ii) any products which have been adjusted,
modified or repaired by any party other than B+B SmartWorx or (iii) any descriptions, illustrations,
figures as to performance, drawings and particulars of weights and dimensions contained in the B+B
SmartWorx’ catalogs, price lists, marketing materials or elsewhere since they are merely intended to
represent a general idea of the products and do not form part of this price quote and do not constitute
a warranty of any kind, whether express or implied, as to any of the B+B SmartWorx’ products.
THE REPAIR OR REPLACEMENT OF THE DEFECTIVE ITEMS IN ACCORDANCE WITH THE
EXPRESS WARRANTY SET FORTH ABOVE IS B+B SMARTWORX’ SOLE OBLIGATION UNDER
THIS WARRANTY. THE WARRANTY CONTAINED IN THIS SECTION SHALL EXTEND TO THE
ORIGINAL USER ONLY, IS IN LIEU OF ANY AND ALL OTHER WARRANTIES, EXPRESS OR
IMPLIED, AND ALL SUCH WARRANTIES AND INDEMNITIES ARE EXPRESSLY DISCLAIMED,
INCLUDING WITHOUT LIMITATION (I) THE IMPLIED WARRANTIES OF FITNESS FOR A
PARTICULAR PURPOSE AND OF MERCHANTABILITY AND (II) ANY WARRANTY THAT THE
PRODUCTS ARE DO NOT INFRINGE OR VIOLATE THE INTELLECTUAL PROPERTY RIGHTS OF
ANY THIRD PARTY. IN NO EVENT SHALL B+B SMARTWORX BE LIABLE FOR LOSS OF
BUSINESS, LOSS OF USE OR OF DATA INTERRUPTION OF BUSINESS, LOST PROFITS OR
GOODWILL OR OTHER SPECIAL, INCIDENTAL, EXEMPLARY OR CONSEQUENTIAL DAMAGES.
B&B ELECTRONIC SHALL DISREGARD AND NOT BE BOUND BY ANY REPRESENTATIONS,
WARRANTIES OR INDEMNITIES MADE BY ANY OTHER PERSON, INCLUDING WITHOUT
LIMITATION EMPLOYEES, DISTRIBUTORS, RESELLERS OR DEALERS OF B+B SMARTWORX
WHICH ARE INCONSISTENT WITH THE WARRANTY, SET FORTH ABOVE.

IMediaChassis Series
1
ABOUT THE IMEDIACHASSIS/20
The iMediaChassis series is a modular chassis platform designed for use with
B&B Electronics’ Simple Network Management Protocol (SNMP) manageable
series of modules. The iMediaChassis/20 is a 3U high, rack mountable chassis
that features 20 slots for installing application series modules plus an additional
slot for installing an SNMP Management Module. Power supply modules are
user-replaceable and hot-swappable.
The iMediaChassis/20 line offers models available in dual AC, dual DC and
ACDC versions.
It offers features such as end-user replaceable power
supply modules, temperature monitoring, Last Gasp and an Alarm Reset
Button.
HARDWARE FEATURES
ALARM RESET, LAST GASP AND TEMPERATURE GAUGE
The iMediaChassis/20 series supports power supply modules, so that worn parts
can be replaced without having to send an entire unit in for repair.

IMediaChassis Series
2
User-Replaceable
Power Supply Modules
Figure 1: iMediaChassis/20, all models
ALARM RESET BUTTON
When one power supply module malfunctions, an audible alarm sounds
indicating the loss of the power module. The alarm can be silenced by pressing
the Alarm Reset Button, located next to the power connector on the power supply
module. If this occurs, remove and replace the power supply module
immediately. (LEDs on the Management Module and the power supply module
itself also indicate power supply module failures.)
LAST GASP ALARM
The iMediaChassis series includes the Last Gasp trap feature, “Remote Chassis
Down”, which sends a Trap when the following occurs:
• Both power supply modules malfunction.
• Both power supply modules are powered down.
• When the AC line fails.

IMediaChassis Series
3
TEMPERATURE GAUGE
The iMediaChassis/20 includes a temperature monitoring gauge with a heat
sensor on the backplane of the chassis. Users define a threshold for chassis
temperature via SNMP. If the chassis’ temperature rises above the specified
level, the SNMP agent sends a trap (configured in iView²) to the administrator.
There is also an LED indicator on the SNMP Management Module for chassis
temperature.
SNMP WRITE LOCK
There is an SNMP Write Lock switch located below slot #3 on the front of the
iMediaChassis/20. The SNMP Write Lock switch prevents a new management
board from re-configuring the application
module settings (e.g., the status of features
such as LinkLoss, FiberAlert, Force mode,
etc.) made via SNMP on any previous
Management Modules.
Figure 2: SNMP Write Lock Switch
NOTE
Leave this switch in the
NORMAL
position during day-to-day operation; the
LOCKED
position should only be used when changing the SNMP management board.
The SNMP Management Module can be removed and replaced as necessary.
Refer to the SNMP Management Module manual for complete instructions about
configuration and operation. If an SNMP Management Module is installed, refer
to the LED panel below for indicators of Link, Temperature, Power supply
modules and other functions.

IMediaChassis Series
4
SNMP MANAGEMENT MODULE LEDS
The SNMP Management Module features several LEDs. The LED functions are:
LNK/ACT
FDX/COL
TEMP
PS
FAN A / FAN B
Glows green when a link is established on
port. Blinks green when data activity occurs.
Glows yellow when port is in Full-duplex
mode. Blinks yellow when port is operating in
Half-duplex mode and collisions occur.
Glows yellow when temperature of unit
surpasses a user-defined level.
Glows yellow when one module malfunctions.
Glows yellow when a fan malfunctions.
Installing the iMediaChassis/20
Install the chassis first before installing any modules into an iMediaChassis.
When installing the chassis, be sure to observe the following precautions to
prevent electrical or mechanical damage:
1. Protect the chassis from exposure to sunlight and electrical or magnetic
fields.
2. Ensure that the equipment rack remains stable, even with the addition of the
chassis and its associated cabling.
To install 20 -slot Rackmount chassis:
1. Have four #10 screws and four clip nuts available (hardware may vary
depending on rack type). The rest of the hardware is supplied with the unit.
2. Locate a suitable location in the rack for installation and secure the clip-nuts
onto the mounting rails. Use screws to attach the chassis to the rack.
3. Plug the chassis into a reliable, filtered power source.
4. Elevated Operating Ambient - If installed in a closed or multi-unit rack
assembly, the operating ambient temperature of the rack environment may

IMediaChassis Series
5
be greater than room ambient. Therefore, consideration should be given to
installing the equipment in an environment compatible with the maximum
ambient temperature (Tma) specified by the B+B SmartWorx.
5. Reduced Air Flow - Installation of the equipment in a rack should be such
that the amount of air flow required for safe operation of the equipment is not
compromised.
6. Mechanical Loading - Mounting of the equipment in the rack should be such
that a hazardous condition is not achieved due to uneven mechanical
loading.
7. Circuit Overloading - Consideration should be given to the connection of the
equipment to the supply circuit and the effect that overloading of the circuits
might have on over current protection and supply wiring.
8. Reliable Grounding - Reliable grounding of rack-mounted equipment should
be maintained. Particular attention should be given to supply connections
other than direct connections to the branch circuit (e.g., use of power strips).
9. All AC and DC versions are intended for use in a Restricted Access Location
(RAL).
DC POWER SUPPLY MODULE WIRING INSTRUCTIONS
The following diagram shows the wiring configuration for a -48 VDC
power supply module for the iMediaChassis/20-2DC and
iMediaChassis/20-ACDC.
Figure 3: DC Wiring Scheme
NOTE
The chassis is protected against incorrect wiring configurations. When wired incorrectly, the
chassis will not function, but no damage will occur.

IMediaChassis Series
6
Installing SNMP Management and Application (iMcV-) Modules
To install a module:
1. Remove the blank bracket (if present) covering the slot where the module
will be installed. B+B SmartWorx recommends installing blank brackets in
unused module slots.
2. Slide the module into the chassis using the card guides.
3. Secure the module to the chassis by tightening the captive screw. (Refer to
the documentation shipped with the module for configuration information.)
4. When installing modules observe ESD precautions, refer to the Electrostatic
Discharge Precautions section.
In order to manage an iMediaChassis series, the SNMP Management Module
needs to be installed in the appropriate slot of the chassis.
Install the iMediaChassis/20 SNMP Management Module into the first slot of the
chassis.
NOTE
This slot is ONLY for the Management Module; do not install Application Modules
such as media conversion and mode conversion modules in this slot.

IMediaChassis Series
7
REPLACING POWER SUPPLY MODULES
USER REPLACEABLE POWER SUPPLIES
The iMediaChassis power supply modules are redundant *, failed power supply
modules should promptly be replaced to maintain network integrity and prevent
data loss.
To replace a power supply module:
1. Disconnect the power source from the power supply module.
2. Remove the screws of the retainer plate (on some AC modules).
3. Move the Power Supply Release switch toward the right or unscrew captive
release screw.
4. Before grasping the power supply module by the silver handle, press the
release screw and then slide out of the chassis (Power supply modules are
hot-swappable).
5. Install new power supply module. If module is equipped with an ON/OFF
switch install the module with the switch in the OFF position.
DUAL AC, PART NUMBER 850-10960-2AC
Figure 4: 850-10960-2AC PS

IMediaChassis Series
8
DUAL DC, PART NUMBER 850-10960-2DC
Figure 5: 850-10960-2DC PS
Both the 850-10960-2AC and 850-10960-2DC were put on End-of-Life
“EOL” in June 2015; support is still available for existing chassis
deployed. Power supplies are limited to a six year warranty.

IMediaChassis Series
9
DUAL AC, PART NUMBER 605-10144-2AC
Figure 6: 605-10144-2AC PS
DUAL DC, PART NUMBER 605-10145-2DC
Figure 7: 605-10144-2DC PS

IMediaChassis Series
10
iMediaChassis/20 Specifications
Input Specifications
Dual AC 100 to 240V AC, 50/60Hz, 3.5/1.5A
Dual DC -48V DC, 5A
ACDC 100 to 240V AC, 50/60HZ, 2A
-48V DC, 4.4A
Operating Temperature
0° C to 50° C (32° F to 122° F)
Storage Temperature
Dual AC & ACDC -20° C to 80° C (-4° F to 176° F)
Dual DC -20° C to 60° C (-4° F to 140° F)
Humidity
20 to 90% (non-condensing at 40° C)
Shipping Weight
11.3 kg (25 lbs)
Dimensions
13.21 x 48.26 x 35.0 5cm (5.2 x 19.0 x 13.8 inches)

IMediaChassis Series
11
ABOUT THE IMEDIACHASSIS/6
The iMediaChassis series is a modular chassis platform designed for use with
B+B SmartWorx Simple Network Management Protocol (SNMP) manageable
series of modules. The iMediaChassis/6 is 1U high, can be installed on a rack
mount shelf, and supports optional redundant power supply modules, as well as
an SNMP Management Module.
The iMediaChassis/6 series offers a line of models including single AC, single
DC, dual AC and dual DC. It offers features such as end-user replaceable power
supply modules, temperature monitoring, Last Gasp and an Alarm Reset Button.
Figure 8:iMediaChassis/6 PS
This manual suits for next models
2
Table of contents
Popular Chassis manuals by other brands

Hewlett Packard Enterprise
Hewlett Packard Enterprise Apollo DX2000 Gen10 Maintenance and service guide

Akasa
Akasa ITX48-M2B user manual

NEC
NEC FlexATX Chassis Disassembly manual

Würth
Würth 1952 008 220 Translation of the original operating instructions

JetStor
JetStor SAS 724HS 10G Series Quick installation guide

Netstor
Netstor NR340A-IP2 Quick installation guide
