1
1Introduction
This specification details the feature set of the Intel®LB440GX 2U rack server chassis, an ATX-form
factor server chassis designed for the Intel®L440GX+ server board.
IntelLB440GX features include:
•2U rack mount chassis (3.46” H x 16.75”W x 28” L)
•One floppy drive
•Two 32-bit/33 MHz PCI slots on the included PCI Riser Card
•Four hot-swap hard drive bays capable of supporting two 1”and two 1.6”LVD SCSI hard drives
•Two system fans
•One 300-Watt PFC PS/2* power supply
2Chassis
The chassis is 3.46 inches high, 16.75 inches wide, and 28 inches long. The rear I/O panel conforms
to the ATX Specification version 2.03, supporting two expansion cards.
2.1 Chassis Color
The primary exterior chassis color will match Intel Color Standard 513505 (dusty beige).
2.2 Front Panel Features
The front panel is pressed SECC with four removable SCSI drive bays, two 1.6” and two 1”. The front
panel also allows for a floppy drive and full-size CD-ROM. The front panel contains a power button
power indicator LED, and hard drive activity LED’s.
2.3 Security
At the chassis level, no security option is provided (no chassis intrusion).
2.4 I/O panel
All input/output connectors are accessible on the rear of the chassis and an ATX 2.03-compatible
cutout is provided for I/O shield installation. A metal I/O shield with appropriate Electromagnetic
Interference (EMI) gasket is installed in the cutout in order to maintain EMI-compliance levels. The
I/O cutout dimensions (measured in inches) are shown in Figure 1 below.
Figure 1. ATX 2.03 I/O Aperture
I/O Aperture Baseboard Datum 0,0
5.196 ± 0.0106.250 ± 0.008
1.750 ± 0.008
(0.650)
(0.150)
0.100 Min keepout around opening
R 0.039 MAX, TYP

Intel©LB440GX 2U Rack Server Chassis TPS Rev 1.0
2
2.5 Chassis Views
Figure 2. Front and Rear Chassis Views
Two 1” Hot-swap Drive
Bays
Two 1.6” Hot-swap Drive
Bays
Floppy Drive
CD-ROM Drive Bay
Power Switch and
Drive LEDs
Exhaust Grill
I/O Panel: Keyboard, Mouse, Parallel
Port, 2 Serial Ports, LAN, 2 USB Ports,
and Video
Two PCI Bays

Intel©LB440GX 2U Rack Server Chassis TPS Rev 1.0
3
Figure 3. Isometric View without Top Cover
2.6 Chassis Dimensions
Height 2U (80 mm)
Width 16.75” (480
mm)
Depth 28” (711 mm)
Table 1. Chassis Dimensions

Intel©LB440GX 2U Rack Server Chassis TPS Rev 1.0
4
3Chassis Power Subsystem
This chassis uses a single standard PS/2 form factor power supply. Variations may be chosen for
future board sets to satisfy the chassis power, power distribution, thermal performance, acoustic
noise and cost requirements.
The form factor was chosen to optimize the overall chassis dimensions. The typical PS/2 form factor
power supply with a remote enable feature can be used. The remote enable feature permits the
chassis power to be activated from a variety of sources, allowing the implementation of “Wake On
LAN*” (WOL) or other remote management features. The 300-watt PFC (Power Factor Correction)
power supply features a 24-pin main power connector and a 6-pin Auxiliary ATX power connector.
The following table is a brief overview:
ATX 300W Non-PFC 719680-
002 P/S Rating, Maximum Continuous Current
+5 VDC Output26 Amp Max
+12 VDC Output 10 Amp Max
-12 VDC Output 0.5 Amp Max
-5 VDC Output 0.25 Amp Max
+3.3 VDC Output 16 Amp Max
+5 VDC Standby 800mA Max
Output balancing Total combined output power of +3.3V
and +5V shall not exceed 167 W.
AC Line Voltage Autorange
AC Line Frequency 50/60 Hz
AC Input Current 4.6 Amp at 115 VAC 2.3 Amp at 220 VAC
Table 2. Power Supply Output Summary
3.1 Mechanical Outline
The mechanical outline and dimensions of the power supply adhere to the standard PS/2 Form factor.
The approximate dimensions are: 140mm high x 86mm wide x 150mm deep.
3.2 Fan Requirements
The power supply incorporates an 80mm low-acoustic-noise fan to exhaust air. The sound pressure
level is measured at a distance of 0.1 meter from each side of the power supply in a free field. The
worst-case peak value of the measurements shall not exceed 38 dBA at 23°C ±2°C.
Due to the increased output requirements of the 5V standby circuit, power supply thermal margins
are difficult to maintain while the system is in the “off” state. For this reason, the power supply fan
will run at a reduced RPM when the system is off.
3.3 AC Power Line
The power supply is specified to operate from 100-120VAC, 200-240VAC, at 50 or 60Hz and is auto-
ranging. The power supply is tested to meet these voltages, and has been tested (but not specified)
in a configured system at ±10% of the voltage ranges, and similarly ±3Hz on the line input
frequency.
The power supply, in a configured system, is specified to operate without error at full power supply

Intel©LB440GX 2U Rack Server Chassis TPS Rev 1.0
5
output load, nominal input voltage, with line source interruptions not to exceed one period of the AC
input power frequency (i.e. 20 milliseconds at 50Hz).
The power supply is not damaged by AC surge ring wave up to 3.0kV/500A. This ring wave is a
100kHz damped oscillatory wave with a specified rise-time for the linear portion of the initial half-
cycle of 0.5µsec. Additionally, the chassis will not be damaged by a unidirectional surge waveform of
up to 1.5kV/3000A, with a 1.2µsec rise time and 50µsec duration. Further details on these
waveforms can be obtained in ANSI/IEEE STD C62.45-1992.
3.4 Power Supply Connector Pin Assignments
3.4.1 P1 Main Power Connector
Housing: 24-pin Molex* 39-01-2240, Contact: Molex 39-00-0038
Pin Signal 18 AWG
Color Pin Signal 18 AWG Color
1+3.3VDC Orange 13 +3.3VDC Orange
2** +3.3VDC
+3.3V remote sense
Orange
Orange
14 -12VDC Blue
3** COM
3.3V remote sense RTN Black
Black
15 COM Black
4+5VDC Red 16 PS_ON_L Green
5COM Black 17 COM Black
6+5VDC Red 18 COM Black
7COM Black 19 COM Black
8PWR OK Gray 20 -5V White
95VSB Purple 21 +5VDC Red
10 +12VDC Yellow 22 +5VDC Red
11 +12VDC Yellow 23 +5VDC Red
12 +3.3VDC Orange 24 COM Black
Table 3. 20+4-pin “Modified ATX” Power Supply Connector
§Note**: The 3.3V power and 3.3V remote sense are double crimped into a single contact at
pin 2. The 3.3V remote sense return and COM are double crimped into a single contact at
pin 3.
§The “Modified ATX” main power connector is configured as the standard ATX 20 (2x10) pin
connector plus a 2x2 (4) pinout designed to supply additional +5VDC to the board. For
connecting this into the IntelL440GX+ server board, use the 24-pin power connector on the
board.

Intel©LB440GX 2U Rack Server Chassis TPS Rev 1.0
6
3.4.2 P10 ATX Aux Power Connector
Housing: 6-pin Molex 90331-0010, Contact: Molex 09-50-0277
Pin Signal 18 AWG
Color Pin Signal 18 AWG Color
1COM Black 4+3.3VDC Orange
2COM Black 5+3.3VDC Orange
3COM Black 6+5VDC Red
Table 4. Aux ATX Power Connector
3.4.3 P2-P8, P11, P12 Peripheral Power Connector
Housing: Amp 1-480424-0, Contact: Amp 61314-1
Pin Signal 18 AWG
Color
1+12VDC Yellow
2COM Black
3COM Black
4+5VDC Red
Table 5. Peripheral Power Connector
3.4.4 P9 Floppy Drive Power Connector
Housing: Amp 171822-4
Pin Signal 18 AWG
Color
1+5VDC Red
2COM Black
3COM Black
4+12VDC Yellow
Table 6. Floppy Drive Power Connector
3.5 Power Supply/Chassis Configuration
The IntelLB440GX 2U rack server platform can only be configured with a single power supply. For
a more detailed specification on the power supply, see document 719680, the specification for the
300-Watt power supply with PFC.

Intel©LB440GX 2U Rack Server Chassis TPS Rev 1.0
7
4Chassis Cooling
Two system fans and the power supply fan provide cooling for the processor(s), hard drives, and
add-in cards. Two 80mm system fans are mounted in the middle of the chassis.All chassis fans
provide a single tachometer output for RPM detection that the server board can make available for
server management monitoring and alert functions. Removal of the top cover gives access to the
fans, which then can be easily changed with the system powered down.
Figure 4. 80mm System Fan
AIR FLOW
ROTATION
80
±
.5
71.5 ±.3
25. ±.5
4.0X 2
4.- Φ4.5 DIA
230 ±30 LABEL SIDE
3 2 1
CONNECTOR PIN OUT
1
2
3
GROUND BLACK
+12V RED
SIGNAL AND WIRE COLOR
All measurements are in millimeters
TACHOMETER

Intel©LB440GX 2U Rack Server Chassis TPS Rev 1.0
8
5Chassis Peripheral Bays
5.1 3.5" Floppy Drive Bay
The chassis provides for the installation of a 3.5“ floppy drive above the 5.25” CD-ROM drive bay.
Removal of the top cover provides access for replacement of the floppy drive.
5.2 5.25" Drive Bay
The chassis supports one half-height (1.6” high) removable media peripheral devices (typically CD-
ROM). As a guideline based on cooling capabilities, the maximum recommended power per device is
17W. Thermal performance of specific devices must be verified to ensure compliance to the drive
manufacturer’s specifications.
The 5.25" peripherals are removable from the front of the chassis after removal of the top cover.
5.3 LVD SCSI Hot-Swap Drive Bays
The LB440GX 2U rack server chassis supports up to four (two 1” high and two 1.6” high)3.5" LVD
Ultra-2 SCSI hard drives which are accessible from the front of the chassis. Four low-cost SECC
carriers are provided with the chassis to be installed on the hard drives.
Thermal performance of specific hard drives must be verified to ensure compliance to the drive
manufacturer’s specifications. Peripherals must be specified to operate at a maximum ambient
temperature of 50°C.

Intel©LB440GX 2U Rack Server Chassis TPS Rev 1.0
9
6Front Panel
The front panel board includes the Power On/Off button, a green Power On LED, four green hard
drive activity LED’s (not drive failures), which are visible through the front inlay.
A four-pin connector is provided on the front panel board for connection to the hot-swap backplane
for drive activity of drives number 1 and 2.
A four-pin connector is provided on the front panel board for connection to the hot-swap backplane
for drive activity of drives number 3 and 4.
A four-pin connector is provided on the front panel board for connection to the baseboard for power
LED.
A two-pin connector is provided on the front panel board for connection to the baseboard for the
power switch.
Figure 5. Front Panel and Functions
Power LED Hard Drive Activity LEDs
Power Switch

Intel©LB440GX 2U Rack Server Chassis TPS Rev 1.0
10
7Hot-Swap SCSI Subsystem
The IntelLB440GX 2U rack server chassis has two independent, identical hot-swap backplanes.
Each backplane supports two Ultra2 SCSI hot-swappable drives. Two configurable switches on the
back of each backplane (see Figure 11) determine the identification of each drive. The backplanes
are then daisy chained with a standard 68-pin Ultra-2 SCSI cable. The hot-swap SCSI subsystem
supports the following features:
§Hot-swapping of Ultra-2 SCSI drives, that allows connection of SCSI devices while the power
is on.
§Full dual mode LVD operation, compliant with Fast, Ultra and Ultra-2 SCSI bus operation.
7.1 Subsystem Purpose
The IntelLB440GX 2U rack server chassis hot-swap SCSI backplane performs the tasks associated
with hot-swappable SCSI drives. The backplane design allows for:
§Four high density 68 pin connectors for four LVD Ultra-2 compatible SCSI drives
§Active termination on SCSI bus
§Per-drive power control, including automatic slot power down upon drive removal
7.2 Abstract
The IntelLB440GX hot-swap SCSI backplane is made up of the following functional blocks:
§SCSI Bus with Ultra-2 high density LVD 68 pin drive connectors, and active terminators
§SCSI drive power control
§Configuration jumpers

Intel©LB440GX 2U Rack Server Chassis TPS Rev 1.0
11
7.3 Hot-Swap Backplane Board Layout
The backplanes reside in the hot-swap drive bay of the IntelLB440GX 2U rack server chassis. Note
this is a passive backplane, which means there is no firmware associated with it (no SAF-TE ASIC).
As a result, server management will not be able to determine the status of each drive.
The following diagram shows the layout of components and connectors on the hot-swap SCSI
backplane printed circuit board.
68Pin SCSI CON
NECTOR
SCSI ID SW
SW2 SW1 DISK1 DISK0
OFF OFF 1 0
OFF ON 3 2
ON OFF 5 4
ON ON 9 8
SE/LVD SCSI
TERMINATOR
TERMINATOR
ENABLE : SHORT
DIABLE : OPEN
DISK POWER
CONNECTOR
Figure 6. Functional Diagram of the Hot-Swap SCSI Backplane
7.3.1 Configuration Options
The following table lists all possible SCSI ID switch configurations of the IntelLB440GX hot-swap
SCSI backplane and the resulting SCSI ID for the position of each switch.
SW
2SW 1ID of Disk 1ID of Disk 0
OFF OFF 10
OFF ON 32
ON OFF 54
ON ON 98
Table 7. HSBP Configuration Jumpers

Intel©LB440GX 2U Rack Server Chassis TPS Rev 1.0
12
7.4 Functional Description
This section defines the architecture of the IntelLB440GX Hot-swap SCSI Backplane, including
descriptions of functional blocks and how they operate. The following figure shows the functional
blocks of the Hot-swap SCSI Backplane. An overview of each block follows.
SCA-2 Connector 1
(Lower Slot)
68P SCSI
Connector
Terminator
Enable Jumper(JP2)
Short : Enable
Open : Disable
SCA-2 Connector 0
(Upper Slot)
LVD/SE Multimode
TERMINATOR
Drive Power
Control
ID Config
EPLD
ID SELECT SW
DIP2 DIP1 SLOT0 SLOT1
OFF OFF 1 0
OFF ON 3 2
ON OFF 5 4
ON ON 9 8
Presence
Presence
Figure 7. Hot Swap SCSI Backplane Block Diagram
7.4.1 68 pin LVD high density Hot-Swap Connectors
The IntelLB440GX contains two hot swap backplane boards with two high-density LVD connectors
on each backplane. The connectors provide power and SCSI signals using a single connector. Each
SCSI drive attaches to the backplane using one of these connectors.
7.4.2 SCSI Interface
The SCSI interface on the IntelLB440GX Hot-swap SCSI Backplane provides the required circuitry
between the SCSI bus and the Adaptec controller, which contains the intelligence for the backplane.
The interface consists of an Altera EPLD. After powering on, the Altera EPLD detects the presence of
disks in the slots and powers them on. The SCSI ID configuration of the disks is configured on the
backplanes by using two DIP-switches located on the boards. See section 7.3.1 for the SCSI ID
configuration options.

Intel©LB440GX 2U Rack Server Chassis TPS Rev 1.0
13
8Dual-Slot PCI Riser
The IntelLB440GX employs a dual-slot PCI riser, which provides two full-length 32-bit/33Mhz PCI.
The riser is an active riser due to the extra PCI Bus Bridge on the card. The riser resides in PCI slot
number 5 of the IntelL440GX+ server board.
TI PCI
Bridge
PCI2031
32Bits/33MHz
Slot 0 (Lower Slot)
Slot 1 (Upper Slot)
Primary PCI Secondary PCI
IDSEL 21
IDSEL 20
P_INT_A <- INT_A
P_INT_B <- INT_B
P_INT_C <- INT_C
P_INT_D <- INT_D
P_INT_B <- INT_A
P_INT_C <- INT_B
P_INT_D <- INT_C
P_INT_A <- INT_D
PCI Slot5
IDSEL 20
Figure 8. Active PCI Riser Block Diagram
Note: The IntelL440GX+ baseboard provided in the IntelLB440GX system contains 6 PCI slots
and 1 ISA slot. PCI Slot 5 contains the PCI Riser Card. The other slots are inactive and should not be
used. Any (up to two) PCI cards in the system should be inserted in the slots on the PCI Riser card.
9Chassis Interconnection
9.1 Chassis Internal Cables
Front panel board to hot-swap backplanes
§A four-pin connector connect the front panel board to the second hot-swap backplane to
transfer drive activities to the LED indicators of drives 3 and 4.
§A four-pin connector connects the front panel board to the first hot-swap backplane to
transfer drive activities to the LED indicators of drives 1 and 2.
Front panel board to server board
§A two-pin connector cable provides Power On/Off function.
§A four-pin connector cable connects the server board to the front panel board to provide
server board power status.

Intel©LB440GX 2U Rack Server Chassis TPS Rev 1.0
14
Server board to hot-swap backplanes
§An Ultra-2 SCSI cable (68-pin) is provided to interface from the installed server board to
the two hot-swap backplanes.
§Two high-density 68-pin connectors in each backplane provide interface between the hot-
swap SCSI backplane and hot-swap SCSI devices.
9.2 Connector Interfaces
Each pin is classified by type, as shown in the following table.
Type
Description
PWR Power connection (power or
ground)
I/O Bi-directional signal
OOutput signal
IInput signal
O/C Open-collector output signal
O/D Open-drain output signal
Table 8. Pin Types
9.2.1 Hot-Swap Backplane and Peripheral Power Connectors
The hot-swap backplane power connector and peripheral power connectors are a standard four-
pin shrouded plastic PC power connectors with mechanical keying. Connector pinout is shown
below.
Figure 9. Peripheral power connector
Name Pin Description
+12V 1+12 Volt power supply (yellow
wire)
GND 20V Electrical ground (black wire)
GND 30V Electrical ground (black wire)
+5V 4+5 Volt power supply (red wire)
Table 9. Peripheral power connectors

Intel©LB440GX 2U Rack Server Chassis TPS Rev 1.0
15
10 Supported Intel Server Boards
The following is a summary of the feature sets for Intel server boards supported by the Intel
LB440GX 2U rack server chassis. Please refer to the appropriate server board Technical Product
Specification for greater detail.
10.1 Intel L440GX+ DP Server Board
§Support for Single or Dual Pentium®II processors of identical speed and stepping, current
revision
§Designed around the Intel®440GX AGPSet, PIIX4e, I/O APIC devices for full MPS 1.4 compliance.
§100MHz System Bus (Front Side Bus)
§Support for up to 2 GB 100MHz “PC/100” compliant registered or 1GB of unbuffered ECC or Non-
ECC SDRAM DIMMs (4 sites)
§Dual Peer PCI buses providing 6 PCI slots.
§Adaptec* AIC-7896 Dual function PCI SCSI controller providing Ultra2 (LVDS) wide and Ultra
wide SCSI channels. Support for Adaptec ARO-1130U2 RAIDPort* “zero channel” RAID
controller.
§Intel®82559 PCI 10/100Mbit Ethernet controller with integrated physical layer. Onboard RJ-45
Network connector.
§Cirrus Logic* GD5480 PCI SVGA graphics controller, 2MB of Synchronous Graphics memory
(SGRAM)
§PCI IDE controller (in PIIX4E) providing dual independent Ultra DMA/33 IDE interfaces, each able
to support 2 IDE drives.
§Compatibility I/O device integrating floppy, dual serial and parallel ports, all connectors provided.
§Universal Serial Bus (USB) support with two USB connectors.
§Integration of server management features, including thermal, voltage, fan, and chassis
monitoring into one controller. Emergency Management Port (EMP) feature. Introducing Platform
Event Paging (PEP) Feature enabling remote notification of significant server management
events.
§Flash BIOS support for all of the above.
