IPC-613 User's Manual 1
Chapter 1 General Information
1.1 Introduction
The IPC-613 is a 2U high, rack-mount e-Server chassis for high-density internet services. Engineered
for service providers and enterprises, the IPC-613's rack-mount 2U form factor is best for stacking
servers as services grow. The IPC-613 is designed to accommodate ATX motherboards. With various
configuration possibilities, the IPC-613 provides the flexibility and high performance at the same time.
1.2 Specifications
•Construction: Heavy-duty steel
•Disk drive capacity: Four optional hot-swap 3.5" hard disk drive space, one 5.25" CD-ROM drive
and one 3.5" floppy disk drive
•Expansion slots: Two PCI expansion slots on the PCI riser card
•Indicators: LEDs for power, fan, and temperature
•Controls: Momentary power switch and alarm reset switch on front panel
•Cooling fan: Three 38.6 CFM cooling fans, 115.8 CFM in total
•Weight: 10 kg (22 lbs)
•Dimensions (W x D x H): 482 x 595 x 88 mm (19" x 23.4" x 3.5")
•Interior paint color: Black 4C 2X; brushed finish, Ni
Power supply
•Output rating: 300 W
•Input rating: 100/200 VAC
•Output voltage: +3.3 V @ 16 A, +5 V @ 26 A, +12 V @ 10 A, -5 V @ 0.25 A, -12 V @ 1 A, +5
VSB @ 1.5 A
•Minimum load: +5 V @ 1 A, +12 V @ 0.5 A
•MTBF: 50,000 @ 50° C
•Safety: CE / UL / CUL
Environmental specifications
•Operating temperature: 0 ~ 45° C (32 ~ 113° F)
•Relative humidity: 10 ~ 95% @ 40° C, non-condensing
•Safety: UL / CE approved
•CE compliant

2 IPC-613 User's Manual
1.3 Dimensions
Unit: mm (inches)
Figure 1-1: IPC-613 dimensions

IPC-613 User's Manual 3
Chapter 2 System Setup
The following procedures are provided to assist you in installing drives and plug-in cards into the
IPC-613.
2.1 Removing the Cover
1. Unscrew the screws at the rear side of the chassis.
2. Slide the upper cover backwards.
3. Lift up the upper cover to open the chassis.
Figure 2-1: Upper cover removing

4 IPC-613 User's Manual
2.2 Drive Bay
The IPC-613 supports four hard disk drives, one CD-ROM drive and one floppy disk drive. There are
two types of the IPC-613 available: IPC-613 and IPC-613-SCA. The IPC-613-SCA provides a SCA-2
backplanes and therefore support four hot-swap hard disk drives.
Please notice that the IPC-613 support two 3.5", 1" height SCSI hard disk drives with 80-pin SCA-2
connecotrs and two 3.5" 1.6" height SCSI hard disk drives with 80-pin SCA-2 connectors.
In order to install the hard disk drives in the chassis, please follow the following procedures.
1. Unscrew the screws on the hard disk trays and pull them out.
2. Put hard disk drives in the hard disk racks and fasten them with screws.
3. Slide the hard disk racks into the drive bay.
Figure 2-2: Hot-swap hard disk drive bay

IPC-613 User's Manual 5
2.3 Installing A Motherboard
The IPC-613 support ATX motherboards. Please contact Advantech for recommended motherboard
solutions.
Figure 2-3: IPC-613 with server motherboard

6 IPC-613 User's Manual
2.4 Installing the Riser Card
One riser card is shipped with the IPC-613. This riser card can support two PCI expansion slots.
Please refer to Figure 2-4 to install the riser card.
Figure 2-4: Riser card on the motherboard

IPC-613 User's Manual 7
2.5 Temperature Setting
If the chassis interior temperature exceeds 65o C (149o F) (default setting), the LED changes color from
green to red. There will be audio alarm as well. The LED remains red until the temperature goes below
63o C.
Temperature also can be selected (SW1) on the alarm board inside the chassis:
SW1
1 2 TEMP
OFF OFF 65o C
OFF ON 55o C
ON OFF 70o C
ON ON 75o C
Figure 2-5: Temperature Setting
Figure 2-6: System monitoring alarm board

8 IPC-613 User's Manual

IPC-613 User's Manual 9
Appendix A Riser Card
Two PCI expansion slots at 32-bit, 33 MHz
Part Number: 9686613000
Unit: mm (inches)

10 IPC-613 User's Manual

IPC-613 User's Manual 11
Appendix B Safety Instructions
B.1 English
1. Read these safety instructions carefully.
2. Keep this user's manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Do not use liquid or spray deter-
gents for cleaning. Use a damp cloth.
4. For pluggable equipment, the power outlet must be installed near the equipment and be easily
accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Dropping it or letting it fall could
cause damage.
7. The openings on the enclosure are for air convection. Protect the equipment from overheating.
DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before connecting the equipment to the
power outlet.
9. Position the power cord so that people cannot step on it. Do not place anything over the power
cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the power source to avoid
damage by transient overvoltage.
12. Never pour any liquid into an opening. This could cause fire or electrical shock.
13. Never open the equipment. For safety reasons, the equipment should be opened only by qualified
service personnel.
14. If any of the following situations arises, get the equipment checked by service personnel:
a. The power cord or plug is damaged.
b. Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.
d. The equipment does not work well, or you cannot get it to work according to the installation
reference guide.
e. The equipment has been dropped and damaged.
f. The equipment has obvious signs of breakage.
15. DO NOT LEAVE THIS EQUIPMENT IN AN UNCONTROLLED ENVIRONMENT WHERE
THE STORAGE TEMPERATURE IS BELOW -20° C (-4° F) OR ABOVE 60° C (140° F).
THIS MAY DAMAGE THE EQUIPMENT.
The sound pressure level at the operator's position according to IEC 704-1:1982 is equal to or less than
70 dB(A).
DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all
responsibility for the accuracy of any statements contained herein.
