Bradford White Includes Hydrojet DS User manual

RESIDENTIAL GAS REPLACEMENT PARTS LIST
Direct Vent Energy Saver (DS) Models
Includes Hydrojet
®
Total Performance System
Effective: July 31, 2008
ECO 7291-2
NOTE: BOTH MODEL AND SERIAL
NUMBERS ARE REQUIRED FOR
ORDERING REPLACEMENT PARTS
Dimensions and specifications
subject to change without notice.
Parts Book #238-42504-00b

Page 2

Item Description Model Model
DS140S*(BN,EN,CX) DS150S*(BN,EN,CX)
1 Standard Brown Vent Package (Includes Items 2 Thru 8) 239-41097-00 239-41097-00
White Vent Package (Includes Items 2 Thru 8) 239-45481-00 239-45481-00
2 Direct Vent-Air Intake Terminal (Standard Brown) 239-41425-00 239-41425-00
Direct Vent-Air Intake Terminal (White) 239-45482-00 239-45482-00
3 Outer Wall Mounting Plate (Standard Brown) 239-41431-00 239-41431-00
Outer Wall Mounting Plate (White) 239-45483-00 239-45483-00
4 Backing Plate 239-41433-00 239-41433-00
5 Outer Telescopic Tube 239-41006-00 239-41006-00
6 Inner Telescopic Tube 239-41005-00 239-41005-00
7 Outer Elbow 239-41007-00 239-41007-00
8 Inner Elbow 239-41008-00 239-41008-00
9 Plenum 239-41010-00 239-41010-00
10 Flue Reducer 239-41009-00 239-41009-00
11 Plenum Gasket 239-41070-01 239-41070-01
12 Air Intake Tube 239-41012-01 239-41012-02
13 Flue Baffle 243-44648-00 243-44648-00
14 Heat Trap Insert (Inlet) 239-45073-00 239-45073-00
15 Cold Water Inlet Dip Tube Polysulfone ŸŸ 229-39628-04 229-39628-06
16 Hot Water Outlet Anode Magnesium Ÿ224-32731-81 224-32731-82
Hot Water Outlet Anode Aluminum Ÿ224-32999-31 224-32999-06
Hot Water Outlet Anode A420 Aluminum Ÿ224-45147-04 224-45147-03
17 Heat Trap Insert (Outlet) 239-45167-00 239-45167-00
18 T&P Relief Valve 230-32920-01 230-32920-01
19 Wire Tie 239-44328-00 239-44328-00
20 Air Intake Boot Escutcheon 243-46922-00 243-46922-00
21 Air Intake Boot 239-46755-01 239-46755-01
22 Air Intake Boot Gasket 223-41067-00 223-41067-00
23 Piezo Igniter 239-43448-00 239-43448-00
24 Outer Door 243-43962-00 243-43962-00
25 Right Side Inner Door (Sight Glass) 239-45415-00 239-45415-00
26 Left Side Inner Door 239-45416-00 239-45416-00
27 Brass Drain Valve 265-42351-02 265-42351-02
28 Gas Valve Natural Gas 265-46181-01 265-46181-01
Gas Valve LP Gas 265-46182-01 265-46182-01
29 Heat Trap Insert Kit 265-45420-00 265-45420-00
30 ASSE Approved Mixing Valve (Optional) 239-43740-01 239-43740-01
31 Inner Door Gasket Kit 239-45909-00 239-45909-00
32 Direct Vent-Air Intake Terminal Guard (Optional) 239-41453-00 239-41453-00
*Applies to all warranties **Inner door gasket kit recommended
***Ordering a complete burner assembly may increase delivery time. Please order the specific component required for the quickest delivery.
ŸOrder with item 17 ŸŸOrder with item 14
Page 3

Page 4

Item Description Model Model
DS140S*(BN,EN,CX) DS150S*(BN,EN,CX)
Natual Gas (BN) Burner Assembl
y
(Replacement for Natural Gas (EN) Burner)
33 Nat. Gas (BN) Burner Assembly Complete*** 265-47439-11-33 265-47439-11-32
34 Nat. Gas (BN) Burner** 228-42506-00 228-42506-00
35 Nat. Gas (BN) Main Burner Orifice** 234-41034-33 234-41034-32
Nat. Gas (BN) High Altitude 2001 Ft. to 5000 Ft.** 234-41034-36 234-41034-36
Nat. Gas (BN) High Altitude 5001 Ft. to 8000 Ft.** 234-41034-36 234-41034-38
Nat. Gas (BN) High Altitude Over 8000 Ft.** 234-41034-40 234-41034-38
36 Nat. Gas Pilot Assembly** 233-46277-04 233-46277-04
37 Thermocouple** 233-46501-24 233-46501-24
38 Nat. Gas Pilot Orifice** 234-46502-05 234-46502-05
LP Gas (SX) Titanium Stainless Steel Burner Assembly (Replacement for LP Gas (CX) Cast Iron Burner)
39 LP Gas (SX) Burner Assembly Complete*** 265-47440-20-50 265-47440-20-49
40 LP Gas (SX) Burner** 228-46964-00 228-46964-00
41 LP Gas (SX) Main Burner Orifice** 234-47604-50 234-47604-49
LP Gas (SX) High Altitude 2001 Ft. to 5000 Ft.** 234-47604-51 234-47064-51
LP Gas (SX) High Altitude 5001 Ft. to 8000 Ft.** 234-47604-52 234-47064-52
LP Gas (SX) High Altitude Over 8000 Ft.** 234-47064-53 234-47064-52
42 LP Gas Pilot Assembly** 233-46278-03 233-46278-03
43 Thermocouple** 233-46501-24 233-46501-24
44 LP Gas Pilot Orifice** 234-46502-02 234-46502-02
- LP to Natural Gas Conversion Kit (Norm Alt.) 265-45912-01 265-45912-02
- LP to Natural Gas Conversion Kit (High Alt.) 265-45912-06 265-45912-07
*Applies to all warranties **Inner door gasket kit recommended
***Ordering a complete burner assembly may increase delivery time. Please order the specific component required for the quickest delivery.
ŸOrder with item 17 ŸŸOrder with item 14
Page 5

Page 6

V
ENT KITS
13 1/4
14 3/16
15
17 11/16
22 1/4
32 3/16
36
55 7/8
58 5/16
104 5/16
10 order kit A
239-41260-00
order kit B
239-41331-00
no add'l kit
req'd
order kit C
239-41029-00
order kit D
239-41424-00
14 3/4
15 11/16
order kit A *(2)
239-41260-00
order kit A & B
239-41260-00 239-41331-00
order kit A
239-41260-00
order kit A & C
239-41260-00
239-41029-00
order kit A & D
239-41260-00
239-41424-00
16 1/2
19 3/16
order kit A & B
239-41260-00 239-41331-00
order kit B *(2)
239-41331-00
order kit B
239-41331-00
order kit B & C
239-41331-00
239-41029-00
order kit B & D
239-41331-00
239-41424-00
23 3/4
33 11/16
order kit A
239-41260-00
order kit B
239-41331-00
order kit C
239-41029-00
order kit C *(2)
239-41029-00
order kit D
239-41424-00
37 1/2 57 3/8
order kit A & C
239-41260-00 239-41029-00
order kit B & C
239-41331-00 239-41029-00
order kit C *(2)
239-41029-00
order kit C *(3)
239-41029-00
order kit C & D
239-41029-00
239-41424-00
59 13/16
105 13/16
order kit A & D
239-41260-00 239-41424-00
order kit B & D
239-41331-00 239-41424-00
order kit D
239-41424-00
order kit C & D
239-41029-00
239-41424-00
order kit D *(2)
239-41424-00
*(2) = Order two kits
*(3) = Order three kits
Horizontal "X"
Vertical "Y"
Page 7
