American Hometec AHQ-B03X User manual

Electric Tankless Hot Water Heater
Installation and Operation Manual
Model: AHQ-B03X
American Hometec, Inc.
3411 Silverside Road
Hanby Building, Suite 105
Wilmington, DE 19810
Sección 2 Español
Section 3 Français
www.AmericanHometec.com
[e-mail]
800-295-8039

2
Contents
INTRODUCTION 3
PACKING LIST 3
IMPORTANTSAFETYINSTRUCTIONS 4
TYPICAL INSTALLATION 5
MOUNTING 6
CONNECT ELECTRICAL 7
CONNECT WATER 9
START UP 10
OPERATION 11
MAINTENANCE 13
SPARE PARTS 13
SYSTEM SPECIFICATIONS 13
TROUBLESHOOTING 14
LIFETIME LIMITED WARRANTY 14
IMPORTANT: KEEP THIS MANUAL FOR FUTURE REFERENCE

3
Introduction
Thank you for purchasing the American Hometec
®
Electric Tankless Water Heater.
In order to ensure proper installation, safe operation, and long life, please carefully
read the instructions. Installation should only be completed by licensed
professionals. The use of electrical and plumbing professionals ensures the
installation is in full compliance with all required building, plumbing and electrical
codes.
KEEP THIS MANUAL for future reference. This booklet includes useful information
about the product, maintenance requirements and the details of your product
warranty.
Packing List
The following contents are included. If any items are missing contact American
Hometec’s toll free support line: 1-800-295-8039.
Item Item# Quantity
Water Heater A 1
Wall mounting bracket B 1
Pressure relief valve C 1
Inlet water filter D 1
Low Flow Aerator (not included with all units) 1
Mounting template (not pictured) 1
Screws (not pictured) 8
A: Water Heater
B: Wall Mounting
Bracket
C: Pressure relief valve
D: Inlet Water Filter

4
IMPORTANT SAFETY INSTRUCTIONS
When using this electrical equipment, basic precautions should always be
followed, including the following:
(a) READ AND FOLLOW ALL INSTRUCTIONS.
(b) CANADA: A green terminal (or a wire connector
marked "G", "GR", "GROUND", or "GROUNDING") is
provided with the control box. To reduce the risk of
electric shock, connect this terminal or connector to
the grounding terminal of the electric service or supply
panel with a continuous copper wire in accordance
with the Canadian Electrical Code, Part I.
(c) This product shall be protected by a Class A
ground fault circuit interrupter.
(d) SAVE THESE INSTRUCTIONS
FAILURE TO FOLLOW INSTALLATION, OPERATING OR
MAINTENANCE INSTRUCTIONS IN THIS MANUAL COULD RESULT
IN PERSONAL INJURY OR DEATH.
USE ONLY LICENSED PROFESSIONAL CONTRACTORS FOR THE
INSTALLATION OF THIS PRODUCT. FOLLOW ALL APPLICABLE
CODES.

5
TYPICAL INSTALLATION
Figure 1: Typical Installation
Figure 2: Dimensions and Clearance

6
Mounting
1. Choose location
1) Orientation : Only install unit vertically with inlet and outlet connections
on the bottom. DO NOT install horizontally or upside down.
2) Install indoors. Product not designed for outdoor installation.
3) Caution: DO NOT INSTALL IN A BATH ENCLOSURE OR SHOWER STALL.
For Canada Only (required standard language that does not apply to this
Coilless Technology® tankless water heater): DO NOT CONNECT TO A SALT-
REGENERATED WATER SOFTENER OR A WATERSUPPLY OF SALT WATER
4) Do not install the water heater in cold location, below the freezing point of
water (32oF / 0oC).
5) Clearance required: 2” above, 5” below, 1” to each side.
2. Prepair for Mounting the Unit
1) Use the mounting template and a pencil to mark the location of the
holes. The template will ensure clearance requirements are maintained.
2) Attach the wall mounting bracket (B) to wall using the screws provided.
3) Lift the water heater and slide the tab of the mounting bracket on the back
of the water heater (A) over and into the opening on the wall mounting
bracket (B) as shown in Figure 3. Do not Mount the unit at this time simply
check for clearances and measurements of electrical cables and piping.
4) The actual Mounting of the unit will take place during the Connect
Electrical section to follow.
5) Note: Only licensed professionals should open the cover panel of unit.

7
Figure 3: Mounting Diagram
Connect Electrical
Note: Only licensed professionals should open the cover panel of unit.
1. Determine the power capacity setting for the application (2.4 kW or 3.4
kW).
Model AHQ-B03X Electric Tankless Heater
Application
One sink with low
flow rate faucets
One sink with low
flow rate faucets
Power setting
selection
Setting 1
Setting 2
Power setting
3.4 kW
2.4 kW
Rated voltage
120 V 60 Hz
Current load
7 –28.5 A
7 –20 A
Breaker
required
30 A
20A
Wire size
required
10 AWG
12 AWG
2. The unit requires a power cord be installed. The power cord selected will
be rated to handle up to 300 Volts and be of the wire size specified in the
chart above. To install the power cord, please follow these steps:
a) Open the front panel of the unit by removing six small screws from the
back of the cover and then lift the front cover out.
b) Unscrew and remove the cable clamp.
c) Feed the 10 or 12 AWG electrical cable (not provided) into unit through

8
cable aperture on the side of unit. Connect the wires to the terminal
block.
d) Reinstall the cable clamp to secure the wire.
e) Reinstall the front cover.
3. Position the unit on the wall as in the Mounting section above. Now fasten
the unit to the mounting bracket with the supplied screws. Note: Do not
connect the water at this time this will happen in the Connect Water section
of this manual, connecting water at this point would cause electric damage
to the unit and potentially your property.
Figure 4: Power Capacity Setting
4. The units can be connected to a plug and plugged into the corresponding
receptacle (refer to Figure 5) or it can be hardwired in a junction box to a
correctly sized breaker and AWG wire size. Check with your local electric
codes if the hardwire option is to be selected. The NEMA and HBL prefixed
number under each plug configuration refers to the NEMA and Hubbell
Incorporated model of this plug. The L, N, G refers to Load, Neutral and
Ground respectively.
a. CAUTION: CONNECT ONLY TO A CIRCUIT PROTECTED BY A
CLASS A GROUND FAULT CIRCUIT INTERRUPTER.
b. USE COPPER CONDUCTORS ONLY.
c. CANADA: USE BONDING CONDUCTOR IN ACCORDANCE WITH THE
CANADIAN ELECTRICAL CODE, PART I. A green terminal (or a wire
connector marked "G", "GR", "GROUND", or "GROUNDING") is
provided with the control box. To reduce the risk of electric shock,
connect this terminal or connector to the grounding terminal of the
electric service or supply panel with a continuous copper wire in
accordance with the Canadian Electrical Code, Part I.
Holding the ON/OFF button down for 5 seconds to
switch between 3.4KW and 2.4KW. 3 LED lights
flashing indicate 2.4kw. 4 LED lights flashing
indicate 3.4kw.

9
5. Turn power on. Set power capacity by holding down the On/Off button for
5 seconds to switch between 3.4KW and 2.4KW. If 3 lights blinking for 3
times, it is set to 2.4kw. If 4 lights blinking for 3 times, it is set to 3.4kw.
Once set turn off power once more.
G
G
G
N
NL
L
HBL2311
HBL2611
120 volt 30 amp
10AWG
120 volt 20 amp
12AWG
N
L
G
NL
HBL5366C
HBL9309
CAUTION: Do not switch on power. This will be done during start up steps.
Connect Water
1. Notes
Arrows on the unit near the connections indicate cold water inlet ( ↑ ) and hot
water outlet ( ↓ ).
Use a PTFE based pipe sealant or tape to ensure leak free connections.
Do not sweat fittings or weld pipe to unit.
Isolation valves are recommended.
Hard connections or flexible braided tubing connections are bothacceptable.
However, flexible braided tubing is preferred.
CAUTION : DO NOT OVERTIGHTEN, MAY BREAK THE PIPE CONNECTION ATHEATING
ELEMENT.
2. This unit does not require a pressure relief valve. However if local codes require,
install the supplied pressure relief valve (C) .
Figure 5: Internal Diagram & Plugs
Cable Aperture
Cable Clamp

10
3. Install the inlet water filter (D) in the cold water inlet. Install the filter such that it
is easily removable for inspection and cleaning.
4. Test water connections for leaks. Turn on water and purge water through the
water heater and system. Flow for 1 - 2 minutes. Ensure all air is eliminated.
Start Up
Open water inlet and outlet. Turn on water and let water flow through unit forone to
two minutes and double check to ensure there are no leaks. CAUTION: DO NOT
OPERATE UNIT DRY.
1. If no leaks are found, turn on the power to unit at breaker.
3. Turn on the water heater power switch located on the control panel on
the frontof the unit.
FOR REFERENCE: Temperature for bathroom sink is typically set to 98
o
F / 37
o
C and for
kitchen istypically set to 110
o
F / 43
o
C. Adjust temperature to meet your comfort needs.
However,temperature should not exceed 125oF / 52 oC due to possibility of
scalding.
4. Adjust water flow to a normal setting.
5. Set temperature to display Celsius or Farenheit.

11
6. Adjust the desired water temperature by pressing power level “UP” or
“DOWN”on the control panel. Increasing the power level will increase
the watertemperature. Decreasing the power setting will result in
cooler water. Note:incoming water supply temperature may change
seasonally. For optimal energysavings, an adjustment may be required in
the winter or in the summer. Thepower setting can be adjusted as
follows:
Power Adjustment Range
Power setting selection (Fig 5)
Setting 1
Setting 2
Power setting
3.4 kW
2.4 kW
Adjustment range (power
levels)
Low: 1- High: 4
Low: 1- High: 3
7. Register the unit for warranty purposes at www.americanhometec.com
Operation
Power indicator light
Power level indicator lights. 4 lights are available
for power level 1 to 4 when unit is installed at
3.4kw. 3 lights are available for power level 1 to 3
when installed at 2.4kw.
UP and DOWN buttons for adjusting power levels
ON/OFF POWER button for turning heater on or off.
When heater is powered on, unit is on standby until
there is a hot waterdemand. Unit will heat water
whenever hot water faucet is turned on and
incoming water temperature is lower than 125
o
F. If
the heater will not be in use for a long time (such as
during vacation), this POWER button is recommended
to beturned off. Pressing ON/OFF button for 5
seconds, if 3 lights blinking for 3 times, it is set to
2.4kw. If 4 lights blinking for 3 times, it is set to
3.4kw. Wire accordingly for installation.

12
The heater supplies a constant amount of energy to heat the water based
on the power setting and power level selected. If water flow rate is
reduced, the water temperature will increase. If water flow is increased,
the temperature will decrease
Please allow hot water to run approximately 5-10 seconds for water
temperature to be regulated before hand contact
During colder seasons the ground water temperature will be lower. This
results in a lower hot water temperature. Press UP on front panel or
reduce water flow at faucet toincrease the power setting which will
result in warmer hot water
Do not block the discharge of the pressure relief valve (if installed)
This unit is designed with safety features to protect against scalding. The
following required information is provided to the consumer:
WARNING! Hot water can produce 3
rd
degree burns in 6 seconds at
140
o
F / 60
o
C and in 30 seconds at 130
o
F / 54
o
C
The unit is designed to withstand freezing temperatures during standby,
but the unit and piping must be thawed prior to operation. Attempting to
operate the unit while frozen will cause irreversible damage.
A flow rate of > 0.4 gpm is required to enable the unit. Continuous
operating at very low flows can result in damage to the heating
mechanism.
The hottest water temperature from the unit is 125oF (52oC). An internal
temperature switch automatically disables the heating if the temperature
exceeds 125oF (52oC)
Figure 6: Sequence of Operation (Scalding Prevention)

13

14
Maintenance
Particles in the inlet water will be removed by the inlet filter (D) .This filter
should be inspected and cleaned on a regular basis. If the filter is clogged,
the unit canfunction improperly or it may even be damaged or destroyed.
System Specifications
Model AHQ-B03X Electric Tankless Heater
Power setting selection
Setting 1
Setting 2
Power setting
3.4 kW
2.4 kW
Rated voltage
120 V 60 Hz
Current load
30 A
20A
Breaker required
30 A
20A
Wire size required
10 AWG
12 AWG
Water flow minimum
0.4 gpm (1.5 l/min)
Water temperature
1250F (520C) maximum
Water proof rating
IPX 4
Water supply pressure
3 –190 psig (0.02 –1.31 MPa)
Weight
6 lb
Spare Parts
The following spare parts are available for purchase and maybe replaced by a
licensed professional. Please contact American Hometec, Inc.’s toll free support
line at 1-800-295-8039.
Item
Part Number
Pressure Relief Valve
B03XPRV
Control panel
B03XCP
Inlet water filter
B03XF
Wall mounting kit (wall mounting bracket and screws)
B03XWM
PCB circuit board
B03XPCB
Temperature sensor
B03XTS
Magnetic floater
B03XMF
Flow switch
B03XFS1
Transformer
B03XTFM

15
Troubleshooting
Trouble
Possible Cause
Remedy
No water
Valves are closed
Filter clogged
Open valves
Remove and clean water inlet filter (D)
Water cold
No power
Insufficient power
Check electric breaker
Check power switch on unit
Increase power level –press “UP” button
Increase power setting (licensed
professional required!)
Water too hot
Water flow is low Power
level is too high
Valves partially closed
Clean water inlet filter (D)
Lower power level –press “DOWN”
button
Water temperature
fluctuating
Water pressure
fluctuating
Water flow fluctuating
Install water pressure regulator
No hot water. Unit
shows a diagnostic
code.
Internal problem or
unit went through an
automatic safety
shutdown.
Unit will automatically reset otherwise call
our service number or a licensed
contractor for assistance.
If you need further assistance, call American Hometec, Inc. toll free service
and support line at 1-800-295-8039. Please have product information including
serial number, date of purchase and error code shown on the control panel, if any,
ready when you call.
Lifetime Limited Warranty
Register unit at www.AmericanHometec.com
General
Themanufacturerwarrantsthiswaterheaterand itscomponents to be freefromdefectsinmaterial
and workmanship accordingto the termsherein.
The heating mechanism within this product is warranted against manufacturer defects for the
lifetimeoftheproductupto15yearsforresidentialwaterheatingapplicationsorupto5yearsfor
commercialandindustrialapplications.Theremainingcomponentsoftheunitarewarranted against
manufacturer defects for a period of 12 months. The warranty is to the original owner of the
equipment at original installed location and is transferable only with original receipt showing date

16
of purchase. The warranty applies to heaters installed within theUS and Canada by licensed
professionals in accordance with the manufacturer’s installation and operating instructions and all
applicablecodes. The warranty covers parts for the repair or replacement of the defective portions
of the unit and labor for a period of 12 months for residential applicaitons. The effective date of
the warranty is the verified date of purchase (original receipt) or the date of manufacture plus
ninety days.
Exclusion
THISLIMITEDWARRANTYSHALLBETHEEXCLUSIVEWARRANTYMADEBYTHE
MANUFACTURERANDISMADEINLIEUOFALLOTHERWARRANTIES,EXPRESSED
ORIMPLIED(WHETHERWRITTENORORAL),INCLUDING,BUTNOTLIMITEDTO,
WARRANTIESOFMERCHANTABILITYANDFITNESSFORAPARTICULARPURPOSE.
THEREMEDIESSETFORTHHEREINARETHEONLYREMEDIESAVAILABLETOTHE
OWNERORANY PERSON.Thecompanydoesnotauthorize anypersonorcompanytoassume
any obligation orliability in connectionwith the repair or replacement. Manufacturer shall not be
liable for anyincidental, consequential, special or contingent damagesor expenses arising,
directly orindirectly, from any defectin thewater heater or the use of thewater heater.
Manufacturer shall not be liableforanywaterdamagearising,directlyorindirectly,fromanydefect
inthewaterheatercomponent part(s)or from its use.
Manufacturershallnotbeliableunderthiswarrantyifthewaterheaterissubjectedtoanyofthe
following conditions.
Misuse, alteration, unauthorized repair, neglect, accident
Hasnotbeeninstalledinaccordancewiththeapplicablelocalplumbingand/orbuilding
code(s) and/or regulation(s)
Is not continuously supplied with potable water
Has been operated while frozen
Is exposed to inlet temperatures above 125
o
F (52
o
C)
Exposed to water pressures above pressure rating of 190 psig (1.31 MPa)
Used for service in a spa, pool, boat or water craft
If heating element box was opened
SOMESTATESDONOTALLOWTHEEXCLUSIONORLIMITATIONOFINCIDENTALOR
CONSEQUENTIALDAMAGES,SOTHEABOVELIMITATIONOREXCLUSIONMAYNOT
APPLYTO YOU. THISWARRANTY GIVESYOUSPECIFICLEGALRIGHTSANDYOU
MAYALSOHAVEOTHERRIGHTSWHICHMAYVARYFROMSTATETOSTATE.
Making a Claim
OwnershouldsubmitthewarrantyclaimdirectlytoAmericanHometec,Inc.bycontactingusat
thephone number shown below. If you are advised to return the unit, you must obtain a
Returned Materials Authorization (RMA) over thephone BEFORE RETURNING THE
UNIT. When contacting the company please have the unit’s serial number and original receipt on
handtoprovidepurchase date andothernecessary information.Packagethe heater wellto
prevent damage, tag the heater with the RMA number and ship the water heaterprepaid to
American Hometec, Inc. as instructed.Unauthorized returns may be rejected at the
company’s discretion.

17
American Hometec, Inc.
www.AmericanHometec.com
1 - 800 - 295 - 8039
©2009/2010 American Hometec, Inc. AHQ-B03X_v03a-07210

Calentador de Agua Eléctrico Sin Tanque
Manual de instalación y operación
Modelo: AHQ-B03X
American Hometec, Inc.
3411 Silverside Road
Hanby Building
Wilmington, DE 19810
www.AmericanHometec.com
[e-mail]
1-800-295-8039

2
Contenid
o
INTRODUCCIÓN 3
LISTA DE EMPAQUE 3
INSTRUCCIONES IMPORTANTES DE SEGURIDAD 4
INSTALACIÓN TÍPICA 5
MONTAJE 6
CONECTE LA ELECTRICIDAD 7
CONECTE EL AGUA 9
ARRANQUE 10
OPERACIÓN 11
MANTENIMIENTO 13
PIEZAS DE REPUESTO 13
ESPECIFICACIONES DEL SISTEMA 13
BÚSQUEDA DE FALLAS 14
GARANTÍA LIMITADA DE POR VIDA 14
IMPORTANTE: CONSERVE ESTE MANUAL PARA
REFERENCIA
FUTURA

3
Introducción
Gracias por adquirir el calentador de agua eléctrico sin tanque, de la marca American
Hometec®. Por favor leacuidadosamente estas instrucciones, para garantizar una
instalación apropiada, una operación segura y una larga vida útil. La instalación
deberá realizarse sólo por técnicos profesionales. Una instalación realizada por
plomeros competentes garantiza que dicha instalacióncumpla cabalmente con los
códigos de construcción, plomería y eléctricos.
CONSERVE ESTE MANUAL para referencia futura. Este manual incluye información
útil acerca delproducto, requisitos de mantenimiento, así como detalles de la garantía
de su producto.
Lista de empaque
Se incluyen los siguientes artículos. Si faltara cualquiera de los artículos, comuníquese
sin costo a la línea de ayuda de American Hometec: 1-800-295-80391.
Artículo Letra Cantidad
Calentador de agua A 1
Soporte de montaje en pared B 1
Válvula de alivio de presión C 1
Filtro de entrada de agua D 1
Aireador de Flujo Bajo (no se incluye en todas las unidades) 1
Plantilla de montaje (no se muestra) 1
Tornillos (no se muestran) 8
A: Calentador de agua
B: Soporte de Montaje en Pared
B:
C: Válvula de alivio de presión
D: Filtro de entrada de agua
