Braeburn Premier Series Assembly instructions

Detailed
Installer Guide
Non-Programmable Thermostats
1 Specifications 2 Installation and Wiring 3 Quick Reference
4 Installer Settings 5 System Testing
• Possible electric shock or damage to equipment can occur.
• Disconnect power before beginning installation.
Caution
This thermostat requires 24 Volt AC Power or 2 properly installed “AA” Alkaline
batteries for proper operation. When connecting 24 Volt AC Power the batteries may
be installed as a backup.
For use only as described in this manual. Any other use will void warranty.
3020 Up to 2 Heat / 1 Cool Heat Pump
1 Heat / 1 Cool Conventional
3220 Up to 3 Heat / 2 Cool Heat Pump
Up to 2 Heat / 2 Cool Conventional
Warning
For installation by experienced service technicians only.
®
This thermostat is compatible with:
• Single stage heat / cool conventional and heat pump systems
• Single stage heat pumps with auxiliary heat
• Conventional systems up to 2 stages of heating and 2 stages of cooling (3220 only)
• Heat pump systems up to 3 stages of heating and 2 stages of cooling (3220 only)
• 250 – 750 millivolt heating only systems
• 2 or 3 wire hydronic zone systems
Electrical and control specifications:
• Electrical Rating: 24 Volt AC
• 1 amp maximum load per terminal
• AC Power: 18 – 30 Volts AC
• DC Power: 3.0 Volt DC (2 “AA” Alkaline Batteries Included)
• Control Range: 45° – 90° F (7° – 32° C)
• Temperature Accuracy: +/- 1° F (+/- .5° C)
• Outdoor Temperature Display Range: -40° - 120° F (-40° - 49° C)
Terminations
• 3020: G, Rc, Rh, W1/E, O/B/V3, Y1, C, S1, S2
• 3220: G, Rc, Rh, W1/E/W3, W2, O/B/V3, Y1, Y2, C, L, S1, S2
1
Specifications
3020W-100-03
Model number is located on back of thermostat.
PREMIER
SERIES

Thermostat Location
Install the thermostat approximately 5 feet (1.5m) above the floor in an area that has a good amount of air
circulation and maintains an average room temperature.
Avoid installation in locations where the thermostat can be affected by drafts, dead air spots, hot or cold air
ducts, sunlight, appliances, concealed pipes, chimneys and outside walls.
Installer Guide 2
Install your new Braeburn thermostat in 4 basic steps:
1Install the Sub-Base
2Provide Power
3Connect Your Wires
4Attach Thermostat to Sub-Base
Install the Sub-Base:
• Remove the sub-base from the body of the thermostat.
• Mount the sub-base as shown below:
Warning
Disconnect power before beginning installation.
2
Installation and Wiring
1
UP UP
Drill 3/16” pilot holes in your
desired location. Use supplied
anchors for drywall or plaster.

3 Installer Guide
Provide Power
C
24VAC Power Terminal (C)
2
Wiring Terminations for model 3020
Terminal Function Description
Rc Input 24 Volt AC Cooling Transformer
(Dual Transformer Systems Only)
Rh Input Power Connection (24 Volt AC Heating
Transformer or Millivolt Power Source)
G Output Fan Control
W1 / E Output (W1) Conventional Heat Relay
(E) Auxiliary/Emergency Heat
O / B / V3 Output (O) Cool Active Reversing Valve
(B) Heat Active Reversing Valve
(V3) Zone Valve Power Close
Y1 Output Compressor Relay
C Input 24 Volt AC Transformer Common
S1
S2
Connect Your Wires
3
Input Optional Remote Sensor (indoor or outdoor)
+
+
• For 24 Volt AC power, you must connect the common side of the transformer to the C terminal on the thermostat sub-base. In
dual transformer installations, the transformer common must come from the cooling transformer.
• For battery power, insert the 2 supplied “AA” type alkaline batteries into the battery compartment located in the rear
housing of the thermostat. Make sure to position the Positive (+) and Negative (-) sides of the batteries correctly with
the +/- symbols in the battery compartment.
Batteries Installed as Shown

Installer Guide 4
Wiring Terminations for model 3220
Terminal Function Description
Rc Input 24 Volt AC Cooling Transformer
(Dual Transformer Systems Only)
Rh Input Power Connection (24 Volt AC Heating
Transformer or Millivolt Power Source)
G Output Fan Control
W1 / E / W3 Output (W1) 1st Stage Conventional Heat,
(E) Emergency Heat,
(W3) 3rd Stage Auxiliary Heat
W2 Output 2nd Stage Conventional Heat
O / B / V3 Output (O) Cool Active Reversing Valve
(B) Heat Active Reversing Valve
(V3) Zone Valve Power Close
Y1 Output 1st Stage Compressor
Y2 Output 2nd Stage Compressor
L Input System Malfunction Indicator
C Input 24 Volt AC Transformer Common
S1
S2
Connecting Your Wires (continued)
3
Input Optional Remote Sensor (indoor or outdoor)

5 Installer Guide
Typical Wiring Configurations
NOTE: The “System Type” option will be configured in the Installer Settings section. Shaded areas do not
apply to the 3020.
Conventional Systems
NOTE: Additional options are configured in the
Installer Settings section.
S1
S2
NOTES - Additional Wiring Options
[1] These terminals can be used to connect a
Braeburn
®
indoor or outdoor remote sensor.
Additional Wiring Options
Indoor or Outdoor Remote Sensor [note 1]
NOTES - Conventional Systems
[1] Optional 24 Volt AC common connection.
[2] Remove factory installed jumper for dual
transformer systems.
[3] In dual transformer systems, transformer
common must come from cooling transformer.
[4] If needed for system.
Provide disconnect and overload protection
as required.
2 HEAT / 2 COOL Single or Dual Transformer
Set System Type to 22CONV (3220 Only)
Rh 24 Volt AC Power (heating transformer) [note 2]
Rc 24 Volt AC Power (cooling transformer) [note 2]
W1 Heat Relay Stage 1
W2 Heat Relay Stage 2
Y1 Compressor Relay Stage 1
Y2 Compressor Relay Stage 2 [note 4]
G Fan Relay
C 24 Volt AC Transformer Common [note 1, 3]
Hydronic Heat Only
Set System Type to 1HD
Rh 24 Volt AC Power (heating transformer)
W1 Zone Valve Power Open
V3 Zone Valve Power Close
G Fan Relay [note 4]
C 24 Volt AC Transformer Common [note 1]
Hydronic Heat / 1 Cool
Set System Type to 11HD
Rh 24 Volt AC Power (heating transformer) [note 2]
Rc 24 Volt AC Power (cooling transformer) [note 2]
W1 Zone Valve Power Open
V3 Zone Valve Power Close
Y1 Compressor Relay
GFan Relay (cooling fan only)
C 24 Volt AC Transformer Common [note 1, 3]
Heat Only or Millivolt
Set System Type to 11CONV
Rh Power Connection
W1 Heat Relay
GFan Relay [note 4]
C24 Volt AC Transformer Common
[note 1]
1 HEAT / 1 COOL Single or Dual Transformer
Set System Type to 11CONV
Rh 24 Volt AC Power (heating transformer) [note 2]
Rc 24 Volt AC Power (cooling transformer) [note 2]
W1 Heat Relay
Y1 Compressor Relay
G Fan Relay
C 24 Volt AC Transformer Common [note 1, 3]

Installer Guide 6
Typical Wiring Configurations
NOTE: The “System Type” option will be configured in the Installer Settings section. Shaded areas do not
apply to the 3020.
Heat Pump Systems
NOTE: Additional options are configured in the
Installer Settings section.
S1
S2
NOTES - Additional Wiring Options
[1] These terminals can be used to connect a
Braeburn
®
indoor or outdoor remote sensor.
Additional Wiring Options
Indoor or Outdoor Remote Sensor [note 1]
1 HEAT / 1 COOL - No Auxiliary Heat
Set System Type to 11HP
Rh 24 Volt AC Power
Rc Connected to Rh with supplied Jumper Wire
O/B Changeover Valve [note 2]
Y1 Compressor Relay
GFan Relay
C24 Volt AC Transformer Common [note 1]
3 HEAT / 2 COOL – Including Auxiliary Heat
Set System Type to 32HP (3220 Only)
Rh 24 Volt AC Power
Rc Connected to Rh with supplied Jumper Wire
O/B Changeover Valve [note 2]
Y1 Compressor 1 Relay (1st stage heating/cooling)
Y2 Compressor 2 Relay (2nd stage heating/cooling)
E/W3 Auxiliary Heat Relay (3rd stage heating) [note 5]
GFan Relay
C24 Volt AC Transformer Common [note 1]
LOptional System Fault Monitor [note 4]
2 HEAT / 1 COOL - Including Auxiliary Heat
Set System Type to 22HP (3220 Only)
Rh 24 Volt AC Power
Rc Connected to Rh with supplied Jumper Wire
O/B Changeover Valve [note 2]
Y1 Compressor Relay (1st stage heating/cooling)
W2 Auxiliary Heat Relay (2nd stage heating) [note 3]
E Emergency Heat Relay [note 3]
G Fan Relay
C 24 Volt AC Transformer Common [note 1]
L Optional System Fault Monitor [note 4]
2 HEAT / 2 COOL - No Auxiliary Heat
Set System Type to 32HP (3220 Only)
Rh 24 Volt AC Power
Rc Connected to Rh with supplied Jumper Wire
O/B Changeover Valve [note 2]
Y1 Compressor 1 Relay (1st stage heating/cooling)
Y2 Compressor 2 Relay (2nd stage heating/cooling)
GFan Relay
C24 Volt AC Transformer Common [note 1]
LOptional System Fault Monitor [note 4]
NOTES - Heat Pump Systems
[1] Optional 24 Volt AC common connection.
[2] O (cool active) or B (heat active) is selected in
the Installer Settings menu.
[3] Install a field supplied jumper between the
W2 and W1/E/W3 terminals if there is
no separate emergency heat relay installed.
[4] If the L terminal is used, the 24 Volt AC common
must be connected (C terminal).
[5] If a separate emergency heat relay is installed, the
W1/E/W3 terminal should have both the auxiliary
heat 1 relay and emergency heat relay connected.
[6] If a separate emergency heat relay is installed, the
W1/E terminal should have both the auxiliary
heat 1 relay and emergency heat relay connected.
2 HEAT / 1 COOL - Including Auxiliary Heat
Set System Type to 21HP (3020 Only)
Rh 24 Volt AC Power
Rc Connected to Rh with supplied Jumper Wire
O/B Changeover Valve [note 2]
Y1 Compressor Relay (1st stage heating/cooling)
E Auxiliary/Emergency Heat Relay [note 6]
G Fan Relay
C 24 Volt AC Transformer Common [note 1]
Provide disconnect and overload protection as required.

INSTRUCTIONS
7 Installer Guide
NOTE: This thermostat ships configured as a 1H/1C conventional
thermostat. Confirm installer settings. See page 9.
UP UP
4
Attach Thermostat to Sub-Base
3) Insert Quick Reference Card into slot
on top of thermostat.
1) Line up the thermostat body with the sub-base.
2) Carefully push the thermostat body against the
sub-base until it snaps in place.

Installer Guide 8
INSTRUCTIONS
Room Temperature ...................... Displays the current room temperature
Set Temperature .......................... Displays the current set point temperature
Reset Button ............................... Resets current time, program and user settings
SYSTEM Button ............................ Selects the system you want to control
BACK Button.................................Moves back in installer/user setup modes
NEXT Button................................. Moves forward in installer/user setup modes
RETURN Button ............................ Returns to normal mode from installer/user setup modes
Service Indicators ...................... Displays various service/maintenance information
FAN Button ................................... Selects the system fan mode
Quick Reference Instructions...... Stored in slot located at top of thermostat
Low Battery Indicator.................. Indicates when the batteries need to be replaced
Fan Indicator................................ Indicates when the system fan is running
System Status Indicator ............. Displays information about the status of the system
Lock Mode Indicator ................... Indicates if the thermostat is locked
SpeedBar®................................... Increases or decreases settings (time, temperature, etc.)
Outdoor Temperature Indicator.... Displays along with the outdoor temperature reading (see note below)
Battery Compartment ................. Located in the back of thermostat
3
Quick Reference
1
2
3
5
15
7
14
16
13
12
11
10
1
2
3
4
5
6
7
8
9
10
11
Thermostat and Display
12
13
14
68 4 9
15
16
NOTE: If a Braeburn®outdoor sensor was connected you can view the outdoor temperature by
pressing the BACK and NEXT buttons at the same time.

INSTRUCTIONS
The Installer Settings must be properly configured in order for this thermostat to operate correctly. The Installer
Settings are menu driven. The portion of these settings that do not apply to your setup will be skipped. These
settings are indicated below with comments. More detail on each setting follows this table.
1. Press and hold down the RETURN and
buttons for 3 seconds.
2. Release both buttons and the first installer
setting will be displayed.
3. Change settings as required using the
or portion of the SpeedBar®.
4. Press NEXT or BACK to move to the next
or previous setting, press RETURN to exit.
No. Installer Setting Factory Setting Comments
(Notes follow this table) Default Options (More information follows this table)
1 Temperature Scale F DEG F DEG Select for Fahrenheit display
C DEG Select for Celsius display
2 Auto Changeover oF AUTO oF AUTO Disables Auto Changeover mode
ON AUTO Enables Auto Changeover mode
11CONV Select for 1H/1C Conventional system
22CONV Select for 2H/2C Conventional system
3 System Type 11CONV 11HP Select for 1H/1C Heat Pump system
21HP Select for 2H/1C Heat Pump system (3020 only)
22HP Select for 2H/2C Heat Pump system
32HP Select for 3H/2C Heat Pump system
1HD Select for Heat Only Hydronic system
11HD Select for Hydronic Heat/1C system
4 1st Stage Differential 0.5 DIF1 0.5, 1.0 or Select a 1st stage temperature differential of .5°,
2.0 DIF1 1° or 2° F (0.2°, 0.5° or 1° C)
5 2nd Stage Differential 2.0 DIF2 1.0, 2.0, 3.0, Select a 2nd stage temperature differential of 1°,
[note 1] 4.0, 5.0 or 2°, 3°, 4°, 5° or 6° F (0.5°, 1°, 1.5°, 2°, 2.5° or 3° C)
6.0 DIF2
6 3rd Stage Differential 2.0 DIF3 1.0, 2.0, 3.0, Select a 3rd stage temperature differential of 1°, 2°,
[note 1] 4.0, 5.0 or
3°, 4°, 5° or 6° F (0.5°, 1°, 1.5°, 2°, 2.5° or 3° C)
6.0 DIF3
7 1st Stage Fan Control HG FAN 1 HG FAN 1 Select for 1st stage Gas heating
[note 2] HE FAN 1 Select for 1st stage Electric heating
8 Emergency Heat] HE EMER HE EMER Select for Electric Emergency Heat
Fan Control [note 3] HG EMER Select for Gas Emergency Heat
9 Reversing Valve REVO REVO Select for cool active Reversing Valve (O terminal)
(O/B Terminal) [note 4] REVB Select for heat active Reversing Valve (B terminal)
10 Fossil Fuel AE AUX AE AUX Select for Electric Auxiliary heat (with compressor)
Backup Heat [note 3] AG AUX Select for Gas Auxiliary heat (without compressor)
4
Installer Settings
9 Installer Guide
NOTE: Shaded areas below do not apply to the 3020.

No. Installer Setting Factory Setting Comments
(Notes follow this table) Default Options (More information follows this table)
11 C ompressor Power Outage oF CPOP oF CPOP Disables Power Outage Lockout Delay
Protection [notes 3, 5] on CPOP Enables Power Outage Lockout Delay
12 AC Power Interrupt AC oF MONR AC oF MONR Disables AC Power Interrupt Warning
Warning [note 5] AC on MONR Enables AC Power Interrupt Warning
13 Compressor Short 5 CSCP 5, 4, 3, 2 or Select a compressor short cycle protection delay
Cycle Protection [note 6] 0 CSCP of 5, 4, 3, 2 or 0 minutes
14 Residual Cooling 60 FAN 90, 60, 30 Select a Residual Cooling Fan Delay of 90, 60,
Fan Delay [note 6] or 0 FAN 30 or 0 seconds.
15 Circulating Fan Lock oF CIRC oF CIRC Disables Circulating Fan Lock mode
on CIRC Enables Circulating Fan Lock mode
16 Indoor Remote Sensor I SENS I SENS Temperature is sensed from thermostat only.
Control* [note 7] E SENS Temperature is sensed from remote sensor only.
A SENS Temperature is combined with the thermostat
and the remote sensor.
17 Lockout Security Level 2 LOCK 2 LOCK If locked – Complete lockout is enabled
1 LOCK If locked – Partial lockout is enabled (SpeedBar
®
is still functional)
18 Auto Changeover 3 BAND 2, 3, 4 or 5Select a Dead Band of 2°, 3°, 4° or 5˚ F
Dead Band [note 8] BAND
(1.0°, 2.0° or 3.0° C) for Auto Changeover mode.
19 Compressor Balance NO BALC NO BALC Disables Balance Points
Point [notes 3, 9] 15-50 BALC Select a Compressor Balance Point of 15°- 50°F
(-9°-10° C)
20 Auxiliary Heat Balance NO BALA NO BALA Disables Balance Points
Point [notes 3, 9] 70-40 BALA Select a Auxiliary Heat Balance Point of 70°- 40° F
(21°- 4.0° C)
21
Heat Set Point Upper Limit 90LIM 90-60 LIM Select a Heat Set Point Upper Limit of 90°-60° F
(32°-10° C)
22 Cool Set Point Lower Limit 45LIM 45-80 LIM Select a Cool Set Point Lower Limit of 45°-80° F
[note 6] (7.0°-27° C)
*When a Braeburn
®
outdoor sensor is connected, the thermostat automatically recognizes it. Press BACK and NEXT at the same
time to display outdoor temperature.
NOTE: Additional options such as Service Monitors, Setting the lock code, etc. are located in the User Settings –
See User manual for information on setting these options.
NOTES - Installer Settings
1Only available if a 2 or 3 stage system type was selected in option 3.
2Only available if a Conventional system was selected in option 3.
3Only available if a 2 or 3 stage Heat Pump system was selected in option 3.
4Only available if a Heat Pump system was selected in option 3.
5Only available if the 24 Volt AC common wire is connected to the C terminal.
6Not available if a Heat Only Hydronic system is selected in option 3.
7Only available if a Braeburn®indoor remote sensor was connected.
8Only available if auto changeover was enabled in option 2.
9Only available if a Braeburn outdoor sensor was connected.
Detailed Explanation of Installer Settings (also see NOTES above):
1Temperature Scale – Selects a temperature scale of either °F or °C.
2Auto Changeover – Selects auto changeover on or off. When auto changeover mode is enabled and
selected, the system automatically switches between heating and cooling modes. There is a 5 minute delay
when switching from heating to cooling or cooling to heating in auto changeover mode.
NOTE: Also see “Auto Changeover Dead Band” in option 18.
Installer Guide 10

3System Type – Selects the system type for your installation. NOTE: Changes made to this option will reset
options 4 through 11 back to their default values dependant on the system type.
41st Stage Differential – Selects a 1st stage temperature differential.
52nd Stage Differential [note 1] – Selects a 2nd stage temperature differential.
63rd Stage Differential [note 1] – Selects a 3rd stage temperature differential.
71st Stage Fan Control [note 2] – Selects a 1st stage fan control of either gas or electric heat.
8Emergency Heat Fan Control [note 3] – Selects emergency heat fan control of either gas or electric heat.
9Reversing Valve [note 4] – Selects the output state of the O/B terminal. Select O for this terminal to be
active in the cool mode or select B for this terminal to be active in the heat mode.
10 Auxiliary Fossil Fuel Heat Pump Control [note 3] – When set to electric (AE AUX), both the compressor
(1st stage) and auxiliary stage(s) will run when a call for auxiliary heat is made. When set to gas (AG AUX),
the compressor stage(s) will be locked out one minute after a call for auxiliary heat. NOTE: This option can
be overridden if setting an auxiliary heat balance point in Option 20.
11 Compressor Power Outage Protection [notes 3, 5] – Selects power outage protection on or off. When
enabled, this thermostat will provide cold weather compressor protection by locking out the compressor
stage(s) of heating for a period of time after a power outage greater than 60 minutes.
12 AC Power Interrupt Warning [note 5] – When enabled, the thermostat will display an outage warning
when AC power to the thermostat is lost.
13 Short Cycle Protection [note 6] – Selects the number of minutes the cooling compressor will be locked
out after turning off. This short cycle protection is also active in the heat mode if a heat pump system was
selected in Option 3.
14 Residual Cooling Fan Delay [note 6] – Selects a delay for the system fan after the cooling compressor
has turned off. This delay will help remove the remaining cool air out of the ductwork providing additional
efficiency.
15 Circulating Fan Lock – When enabled, the only user fan options available are ON and CIRC (Circulation).
The AUTO option is not available with this option enabled.
16 Indoor Remote Sensor Control [note 7] – If a Braeburn®indoor remote sensor is connected during
installation, the thermostat will automatically detect the sensor. When an indoor sensor is detected, you may
select between thermostat only (I SENS), remote sensor only (E SENS) or combining the thermostat and the
remote sensor (A SENS). NOTE: This option does not apply to a Braeburn outdoor sensor. When an outdoor
sensor is connected the thermostat automatically recognizes it and no further configuration is necessary.
17 Lockout Security Level – Selects the level of keypad lockout when the thermostat is locked. Level 2 locks
the entire thermostat (including the front reset button). Level 1 locks everything except the SpeedBar®
allowing for up and down temperature adjustment. NOTE: The lock code is set in the User Settings mode
(see User Manual).
18 Auto Changeover Dead Band [note 8] – When auto changeover mode is enabled in option 2 and
selected, the system automatically switches between heating and cooling when the room temperature
meets the normal criteria for either a heating or cooling call. There is a forced separation (dead band)
between the heating and cooling set points so that the systems do not work against each other. This
option selects the amount of this dead band in degrees with the default being 3° F.
19 Compressor Balance Point [notes 3, 9] – Locks out the use of the compressor heat stage when the
outside air temperature is less than the selected setting of 15° F to 50° F (-9° C to 10° C).
20 Auxiliary Heat Balance Point [notes 3, 9] – Locks out the use of the auxiliary heat stage when the
outside air temperature exceeds the selected setting of 70° F to 40° F (21° C to 4° C). NOTE: This balance
point overrides the fossil fuel compressor lockout in option 10. If this option is set to gas and the outdoor
temperature is over the auxiliary balance point, the compressor will remain on during a call for auxiliary heat.
11 Installer Guide

12 Installer Guide
21 Heat Set Point Upper Limit – Selects the heating set point upper adjustment limit.
22 Cool Set Point Lower Limit [note 6] – Selects the cooling set point lower adjustment limit.
Warning
Read Before Testing
• Do not short (or jumper) across terminals on the gas valve or at the heating or cooling system control board
to test the thermostat installation. This could damage the thermostat and void the warranty.
• Do not select the COOL mode of operation if the outside temperature is below 50º F (10º C). This could
possibly damage the controlled cooling system and may cause personal injury.
• This thermostat includes an automatic compressor protection feature to avoid potential damage to the
compressor from short cycling. When testing the system, make sure to take this delay into account.
NOTE: The compressor delay can be bypassed by pressing the reset button on the front of the thermostat.
All user settings will be returned to factory default, however all Installer settings will remain as originally
programmed in section 4.
1Press the SYSTEM button until the thermostat is in HEAT mode.
2Using the SpeedBar®raise the set temperature a minimum of 3 degrees above the current room
temperature. The system should start within a few seconds. With a gas heating system, the fan may
not start right away.
3Press SYSTEM until the thermostat is in the OFF mode. Allow the heating system to fully shut down.
4Press SYSTEM until the thermostat is in the COOL mode.
5Using the SpeedBar lower the set temperature a minimum of 3 degrees below the current room
temperature. The system should start within a few seconds (unless compressor short cycle protection
is active – See note above).
6Press SYSTEM until the thermostat is in the OFF mode. Allow the cooling system to fully shut down.
7Press FAN until the thermostat is in FAN ON mode. The system fan should start within a few seconds.
8Press FAN until the thermostat is in FAN AUTO mode. Allow the system fan to turn off.
5
System Testing

®
Store this manual for future reference.
Limited Warranty
When installed by a professional contractor, this product is backed by a 5 year limited
warranty. Limitations apply. For limitations, terms and conditions, you may obtain a full
copy of this warranty:
• Visit us online: www.braeburnonline.com/warranty
• Phone us: 866.268.5599
• Write us: Braeburn Systems LLC
2215 Cornell Avenue
Montgomery, IL 60538
5
YEAR
WARRANTY
LIMITED
Braeburn Systems LLC
2215 Cornell Avenue • Montgomery, IL 60538
Technical Assistance: www.braeburnonline.com
Call us toll-free: 866-268-5599 (U.S.)
630-844-1968 (Outside the U.S.)
©2020 Braeburn Systems LLC • All Rights Reserved.
®
3020W-100-03
