Braemar DL700 User manual

Braemar, Inc.
DL700
DL700DL700
DL700
Operator Manual
Caution: U.S. Federal law restricts this device to sale by
or on the order of a physician.

i
Braemar Limited Warranty
Braemar products are warranted to be free from manufacturing and material
defects for a period of one (1) year from the date of shipment from Braemar to
the original purchaser.
Excluded from this warranty are expendable supply items including, but not
limited to, electrodes, leadwires, patient cables and batteries. This warranty does
not apply to any product that Braemar determines has been modified or damaged
by the customer.
Except for the express warranties stated above, Braemar disclaims all
warranties including implied warranties of merchantability and fitness.
The stated express warranties are in lieu of all obligations of liabilities on
the part of Braemar for damages, including but not limited to, special
indirect or consequential, arising out of or in connection with the use or
performance of Braemar products.
Any action for breach of warranty shall be commenced within one (1) year of
said breach or be forever barred. Any repairs made to the product that are not
covered by the warranty shall be billed to the customer.
Document Number: 600-0573-00
Revision: G
Date: March 2006
ii

iii
Table of Contents
Product Overview .............................................................................................. 1
1. Description................................................................................................... 2
2. Specifications............................................................................................... 5
Product Operation ............................................................................................. 7
3. Recorder Preparation ................................................................................... 8
3.1 Battery Installation ................................................................................ 8
3.2 Setting the Clock .................................................................................... 8
4. Electrode Application ................................................................................ 10
4.1 Materials Needed ................................................................................. 10
4.2 Recommended Steps............................................................................. 10
5. Operation .................................................................................................. 12
5.1 Materials Needed ................................................................................. 12
5.2 To Start Recording............................................................................... 12
5.3 To Stop Recording ............................................................................... 14
5.4 Analyzing the ECG Data...................................................................... 14
Service And Maintenance................................................................................ 15
6. Maintenance............................................................................................... 16
6.1 Replacing the Clock Battery ................................................................ 16
7. Troubleshooting Guide .............................................................................. 18
7.1 Problem Description and Recommended Solution .............................. 18
8. Service Items.............................................................................................. 20
Appendix A ....................................................................................................... 21
9. Electrode Placement (7 Lead) .................................................................... 22
10. Electrode Placement (5 Lead) .................................................................. 24
iv

DL700 Holter Monitor
1
Product Overview
DL700 Holter Monitor
2
1. Description
The DL700 Holter Recorder is a battery operated solid state recorder
designed for 24 hour continuous recording of ambulatory ECG data. It is an
AAMI Type I device, which is part of a conventional AECG monitoring
system where the ECG is recorded on a removable Flash memory card in the
DL700. After the ECG data has been recorded, the memory card is removed
from the DL700 and inserted in a Flash Card Reader which is part of the
Computer Analysis System on which the ECG will finally be analyzed. The
Flash memory card used in the DL700 is the same as some PCMCIA
memory cards used in laptop computers.
Batteries and Receptacle
The DL700 provides a battery compartment with secure receptacles for
inserting two standard AA alkaline batteries. A polarity guard feature is
built in to prevent damage in case the batteries are installed incorrectly.
Cover Labeling
The label on the outside of the cover provides information about the
company supplying the recorder while the label on the inside of the cover
provides Patient Hook-up and Recording Start/Stop instructional
information.
Digital Clock
A digital LCD clock is mounted into the front panel to provide both time
and date for patient convenience.
Clock Battery
The digital clock is powered by a Duracell silver oxide 392B, 1.5V battery
or its equivalent. For instructions on battery replacement, refer to the
Maintenance Section.
Clock Set Controls
The clock set controls are used to set the date and time. Time can be set in
hours and minutes.

DL700 Holter Monitor
3
Patient Event Button
Patients should be instructed to use this Event Button anytime they feel
symptoms similar to those which they have been instructed by their
physician to note in their Patient Log along with date and time information.
Figure 1
DL700 Holter Recorder
Patient Input Connector
The patient input connector provides a snug and reliable connection for the
patient electrode leads along with complete color-coding for each lead.
Test Jacks
Three test jacks are provided to verify that a good, reliable signal is being
obtained on each ECG channel immediately after connecting the electrodes
to the patient. This test should be done prior to allowing the patient to leave
the clinic.
DL700 Holter Monitor
4
Gain Switch
A gain switch is provided to allow the medical technician to adjust signal
amplitude. Three positions are provided: 1/2X, 1X, and 2X. Position
indications are on the label above the switch.
Operating LED
This is the green LED just to the right of the gain switch (Fig 1). It provides
current status information on the recorder (See Operation Section).
Equipment Symbols
Symbol Description
Type B equipment.
Consult manual.
0086
Complies with the Medical Device Directive of
the European Union.
Waste Electrical and Electronic Equipment
(WEEE) It is the responsibility of the end user
to dispose of this equipment at a designated
collection point for recycling.
Year of Manufacture
SN Serial Number
REF Not shown - DL700 is the catalogue number.
European Representative:
CEpartner4U BV
Esdoornlaan 13
3951 DB Maarn.
The Netherlands
Tel: [phone]
