1 Overview
The Brandywine Communications QFS-106 is a high performance reference
frequency standard distribution amplifier. The QFS-106 has two internal
reference oscillator options. The QFS-106 may use either a free running Oven
Controlled Crystal Oscillator (OCXO) or a free running Rubidium Oscillator. Also,
the QFS-106 has various power supply options. The QFS-106 may use either
AC or DC input power supplies. The QFS-106 provides six output channels of a
single reference frequency, typically 10 MHz. The QFS-106 has six individually
buffered low phase noise outputs. When more outputs are required, multiple
QFS-106 units may be daisy-chained to a single reference.
1.1 Part Number Reference
PART NUMBER
OSCILLATOR
POWER SUPPLY
015006001
OCXO
115/230 VAC
015006002
OCXO
09 – 18 VDC
015006003
OCXO
18 – 36 VDC
015006004
OCXO
36 – 72 VDC
015006011
Rubidium
115/230 VAC
015006012
Rubidium
09 – 18 VDC
015006013
Rubidium
18 – 36 VDC
015006014
Rubidium
36 – 72 VDC

MANUAL P/N 900000034 REV D
6
2 Specifications
2.1 I/O and Environmental (Rear Panel)
SPECIFICATION
DESCRIPTION
Internal Reference
Oscillator
OCXO Stability
1 x 10-8 at -30°to -60°C
OCXO Aging
5 x 10-8 per year
Rubidium Stability
±1 x 10-10 at 0 to 50°C
Rubidium Aging
5 x 10-11 per month
Reference Input
Label
J8
Number of Reference Inputs
1 Input
Frequency
10 MHz Standard
Level
1 Vrms into 50 ohm
Connector
BNC
Reference Output
(Buffered from
Reference Input)
Label
J7
Number of Reference Outputs
1 Output
Frequency
10 MHz Standard
Level
1 Vrms into 50 ohm
Distortion
< 33 dBc
Connector
BNC
Outputs
Label
Output 1 (J1), Output 2 (J2),
Output 3 (J3), Output 4 (J4),
Output 5 (J5), and Output 6
(J6)
Number of Frequency Outputs
6 Buffered Outputs
Frequency
10 MHz Standard
Level
1 Vrms into 50 ohm
Distortion
< 33 dBc
Connector
BNC
Phase Noise at 10
MHz
1 Hz
-90 dBc/Hz
10 Hz
-110 dBc/Hz
100 Hz
-140 dBc/Hz
1000 Hz
-150 dBc/Hz
10000 Hz
-157 dBc/Hz
Environmental
Temperature
-30 to +60°C
Humidity
95% non-condensing
Fuse
VDC Model
400 VDC and 4A
VAC Model
115/230 VAC and 250mA
Power
VDC Power Supply
09 – 18 VDC (12V Nominal)
18 – 36 VDC (28V Nominal)
36 – 72 VDC (48V Nominal)
VAC Power Supply
115/230 VAC
Power Connection
VDC Connector
DC Connector
VDC Connector 2 Pin
Pin A -> Positive
Pin B -> Negative
VAC Connector
AC Connector
Dimension
Length (Rack Mount & Chassis)
19.00” and 17.00”
Height
1.720”
Width
6.150”
Weight
Weight
Typically 3 lbs

MANUAL P/N 900000034 REV D
7
2.2 Switch and Indicator (Front Panel)
SWITCH/INDICATOR
COLOR
DESCRIPTION
POWER SWITCH
––
Used to switch the unit on and off
POWER LED
GREEN
Indicates that the unit has primary power
OUTPUT MONITOR 1 LED
GREEN
Indicates that Output 1 is present
OUTPUT MONITOR 2 LED
GREEN
Indicates that Output 2 is present
OUTPUT MONITOR 3 LED
GREEN
Indicates that Output 3 is present
OUTPUT MONITOR 4 LED
GREEN
Indicates that Output 4 is present
OUTPUT MONITOR 5 LED
GREEN
Indicates that Output 5 is present
OUTPUT MONITOR 6 LED
GREEN
Indicates that Output 6 is present
PLL LED
RED
Indicates that the unit is in power up mode or not
locked to the reference input
GREEN
Indicates that the unit is phased locked to the
reference input
RB LOCKED LED
GREEN
Indicates that the rubidium oscillator has reached
resonance lock if installed
CALIBRATE (POTENTIOMETER)
––
Used to calibrate the oscillator

MANUAL P/N 900000034 REV D
8
3 Unpacking and Installation
3.1 Unpacking
Carefully remove the QFS-106 from the shipping carton. The following items
should be included in the shipment:
•1 QFS-106
•1 user guide
•1 power cord
•1 power mating connector (DC voltage only)
Note the power connection on the rear of the QFS-106 chassis. Please take
note of the voltage displayed near this power connection.
If the AC or DC voltage setting is incorrect, use a small screw driver to remove
the fuse holder. Reverse the fuse holder and re-insert the fuse holder, making
sure that the correct AC or DC voltage is now displayed on the rear panel of the
QFS-106.
Use the supplied power mating connector for the QFS-106 unit (DC voltage
only). The user must connect the wires to the connector as shown in the table
below.
DC MODEL
DESCRIPTION
Pin A
Positive input voltage
Pin B
Negative input voltage
Mating Connector
Amphenol 97-3106A-10SL-4S
Strain Relief
Amphenol 97-3057-1004-1
3.2 Installation
The QFS-106 may be bolted directly onto a 19” rack mount enclosure.
3.3 Connections
Connect the power source to the QFS-106.Now connect the input reference
signal and output reference signals to the appropriate connectors on the rear
panel of the QFS-106.The Reference Output connector may be used when
daisy-chaining multiple QFS-106 units.

MANUAL P/N 900000034 REV D
9
When daisy-chaining multiple QFS-106 units, these units should be connected as
shown in Figure 1. This configuration ensures that all outputs are accurately
locked to a common reference with minimal injection of the phase lock loop
noise.
Power
QFS-106
QFS-106
12 3 4 5 6
REF IN REF OUT 1 2 3 4 5 6
QFS-106
REF IN REF OUT 1 2 3 4 5 6
QFS-106
REF IN REF OUT 1 2 3 4 5 6
Additional QFS-106
Units
User’s Equipment
User’s Equipment
User’s Equipment
User’s Equipment
Figure 1 Daisy-Chain Interconnection

MANUAL P/N 900000034 REV D
10
4 Operation
4.1 Powering the QFS-106
Once all the connections to the QFS-106 have been made, apply power to the
unit by switching the power switch to the on position. The power switch is
located on the rear panel of the unit. The Power LED and Output Monitor LEDs
(1 – 6) on the front panel of the unit will illuminate green.
Please note that units fitted with the quartz oscillators will take approximately five
minutes to warm up and these units will reach full accuracy after twenty-four
hours. Units fitted with the rubidium oscillators will take approximately ten
minutes to warm up.
4.2 Loss of Input Signal
The PLL LED illuminates green when an input signal is present on the Reference
Input connector on the rear panel of the unit. If the reference input fails, the front
panel PLL LED will extinguish.
4.3 Loss of Output Signal
The Output Monitor LEDs (1 – 6) illuminate green when output signals are
present on the Outputs connectors on the rear panel of the unit. If one or more
outputs fail, the front panel Output Monitor LEDs (1 – 6) will extinguish.
Please note that a short circuit on the output cable may not always trigger the
output alarm.
