5 6 7
takes 12 hours and enables at least 2 weeks of regular brushing
(twice a day, 2 minutes).
Note: At a very low charge level, the lights might not flash
immediately; it can take up to 30 minutes.
• If the battery is running low, a red light is flashing on the charge
level display and the motor is reducing its speed. Once the
battery is empty, the motor will stop; it will need at least a
30-minute charge for one usage.
• You can always store the handle on the plugged-in charging unit
to maintain it at full power; a battery overcharge is prevented by
device.
Note: Store handle at room temperature for optimal battery
maintenance.
Caution: Do not expose handle to temperatures higher than 50 °C.
Using your toothbrush
Brushing technique
Wet brush head and apply any kind of toothpaste. To avoid
splashing, guide the brush head to your teeth before switching on
the handle (picture ➁). When brushing your teeth with one of the
Oral-B oscillating-rotating brush heads guide the brush head
slowly from tooth to tooth, spending a few seconds on each tooth
surface (picture ➂). When using the Oral-B «Deep Sweep» brush
head place the toothbrush bristles against the teeth at a slight
angle towards the gum-line. Apply light pressure and start brushing
in back and forth motions, just like you would do with a manual
toothbrush.
With any brush head start brushing the outsides, then the insides
and finally the chewing surfaces. Brush all four quadrants of your
mouth equally. You may also consult your dentist or dental hygienist
about the right technique for you.
In the first days of using any electric toothbrush, your gums may
bleed slightly. In general, bleeding should stop after a few days.
Should it persist after 2 weeks, please consult your dentist or dental
hygienist. If you have sensitive teeth and/or gums, Oral-B
recommends using the «Sensitive» mode (optional in combination
with an Oral-B «Sensitive» brush head).
Smart Ring features
Your toothbrush is equipped with a Smart Ring (2) that has various
functionalities indicated via different colors of light:
White (default) = Operating and visual timer light (choose individual
color via Oral-BTM App settings)
Red = Pressure sensor light
Blue = Bluetooth® pairing indicator
Timer
You can choose between «Professional» or «2-Minute» timer.
The «2-Minute» timer signals with a long stuttering sound and a
flashing light of the Smart Ring (2) that the professionally
recommended 2-minute brushing time has been reached.
The «Professional» timer signals with a short stuttering sound and a
flashing light of the Smart Ring at 30-seconds intervals to move
to
the next quadrant of your mouth (picture ➂).
A long stuttering sound
and a flashing light indicate the end of the professionally
recommended 2-minute brushing time.
The timer memorizes the elapsed brushing time, even when the
handle is briefly switched off during brushing. The timer resets if
pausing longer than 30 seconds, briefly pressing the mode button
(4) during pause or placing the handle on the plugged-in charger.
Note: During the use of special Oral-BTM App features, the visual
timer light may be deactivated.
Timer setup:
Your toothbrush comes with the «Professional» timer activated. To
change this, press and hold the mode button (4) for 2 seconds.
Toggle between timer selection by pressing the on/off button (3).
Confirm selection by pressing the mode button.
• 2 LED’s illuminated indicate «2-Minute» timer
• 4 LED’s illuminated indicate «Professional» timer
Note: You can also set/advance the timer functionality via Oral-BTM App.
Pressure sensor
If too much pressure is applied, the Smart Ring (2) will light up in
red, reminding you to reduce pressure. In addition the pulsation of
the brush head will stop and the oscillation movement of the brush
head will be reduced (during «Daily Clean», «Pro Clean» and
«Sensitive» mode) (picture ➂).
Periodically check the operation of the pressure sensor by pressing
moderately on the brush head during use.
Brushing modes (depending on model)
Your toothbrush offers different brushing modes:
«Daily Clean» – Standard mode for daily mouth cleaning
«Pro Clean» – For an extraordinary clean feeling (operated
with a higher frequency)
«Sensitive» – Gentle, yet thorough cleaning for sensitive
areas
«3D White» – Polishing for occasional or everyday use
«Gum Care» – Gentle massage of gums
Your toothbrush automatically starts in the mode selected last. To
switch to another mode, successively press the mode button during
use (picture ➃). To return from any mode back to «Daily Clean»
mode, press and hold the mode button (4).
Note: You can also set/advance the mode functionality via Oral-BTM
App.
Brush heads
Oral-B offers you a variety of different Oral-B brush heads that fit
your Oral-B toothbrush handle.
Our oscillating-rotating brush heads can be used for tooth-by-
tooth precision cleaning.
Oral-B CrossAction brush head
features perfectly angled bristles to remove plaque,
even in hard-to-reach areas.
Oral-B FlossAction brush head
features micropulse bristles that allow for an
outstanding plaque removal in the interdental areas.
Oral-B 3D White brush head
features a special polishing cup to naturally whiten
your teeth. Please note that children under 12 years
old should not use the Oral-B «3D White» brush
head.
Oral-B Gum Care brush head
features a combination of regular and ultra-thin
bristles for advanced cleaning and gum protection.
Most Oral-B brush heads feature INDICATOR® bristles to help you
monitor brush head replacement need. With thorough brushing,
twice a day for two minutes, the color will fade halfway
approximately within 3 months, indicating the need to exchange
your brush head. If the bristles splay before the color recedes, you
may be exerting too much pressure on teeth and gums.
We do not recommend using the Oral-B «FlossAction» or Oral-B «3D
White» brush head with braces. You may use the Oral-B «Ortho»
brush head, specifically designed to clean around braces and wires.
Connecting your toothbrush
to your Smartphone
The Oral-BTM App is available for mobile devices running iOS or
Android operating systems. It can be downloaded for free from App
Store(SM) or Google PlayTM.
The Oral-BTM App gives you the opportunity to chart your brushing
progress and customize your toothbrush settings (for many more
benefits see the Oral-BTM App instructions).
• Start the Oral-BTM App. It will guide you through the entire
Bluetooth pairing procedure.
Note: Oral-BTM App functionality is limited if Bluetooth wireless
technology is deactivated on your smartphone (for directions
please refer to your smartphone’s user manual).
• Any app instructions will be displayed on your smartphone.
• If Bluetooth wireless technology is activated on your handle, the
Bluetooth symbol on the radio transmission display (6)
illuminates. Once the handle is paired, the Smart Ring (2) flashes
briefly.
• Keep your smartphone in close proximity (within 5 m distance)
when using it with the handle. Make sure the smartphone is
safely positioned in a dry place.
• The smartphone holder stand (11) (depending on model) can
hold your smartphone while using. Before use, make sure your
phone fits the stand and keeps stable.
Note: Your smartphone must support Bluetooth 4.0 (or higher)/
Bluetooth Smart in order to pair your handle.
Compatible smartphones are listed in App Store(SM) or Google PlayTM.
Caution: Follow your smartphone’s user manual to ensure your
phone/charger is designed for use in a bathroom environment.
Cleaning
recommendations
After brushing, rinse your brush head under running water with the
handle switched on. Switch off and remove the brush head. Clean
handle and brush head separately; wipe them dry before reassembling.
Unplug the charger before cleaning. Brush head holder (9), brush head
compartment and protective cover (10) and smartphone holder stand
(11) are dishwasher-safe. Beauty bag (12) should be hand washed only
with lukewarm water (86°F - 104°F / 30°C - 40°C).
To be cleaned with a damp cloth only: charger (8), charger pouch
(14), travel case (13) (picture ➄).
Accessories
(depending on model)
Beauty Bag/Charger Pouch/Travel Case
Store the clean and dry toothbrush/brush heads in the travel case
(13) and place it inside the beauty bag (12).
Store the charger in the charger pouch (14).
Clean stains on surfaces immediately. The beauty bag should be
hand washed only with lukewarm water (86°F - 104°F / 30°C - 40°C).
Charger pouch and travel case should be cleaned with a damp
cloth only (picture ➄). Store in clean and dry place.
Subject to change without notice.
Environmental Notice
Product contains batteries and/or recyclable electric
waste. For environment protection do not dispose in
household waste, but for recycling take to electric
waste collection points provided in your local region.
Battery removal at the
end of the product’s
useful life
Do not disassemble the product except when disposing of the
battery. Run down battery before removing. When taking out the
battery for disposal, use protective clothing (gloves, safety glasses,
etc.) to avoid direct skin contact with batteries that may be subject
to leakage. Insulate terminals (e.g. with tape) and put the battery in
a plastic bag for disposal.
Open the handle as shown, remove the battery and dispose of it according to
local environmental regulations.
Caution! Opening the handle will destroy the appliance and
invalidate the warranty.
Information
Bluetooth® radio module
Although all indicated functions on the Bluetooth device are
supported, Oral-B does not ensure 100% reliability in connection,
and feature operation consistency.
Operation performance and connection reliability are direct
consequences of each individual Bluetooth device, software
version, as well as the operating system of those Bluetooth devices
and company security regulations implemented on the device.
Oral-B adheres to and strictly implements the Bluetooth standard
by which Bluetooth devices can communicate and function in
Oral-B toothbrushes.
However, if device manufacturers fail to implement this standard,
Bluetooth compatibility and features will be further compromised
and the user may experience functional and feature-related issues.
Please note that the software on the Bluetooth device can
significantly affect compatibility and operation.
1) Warranty – Exclusions and Limitations
This limited warranty applies only to the new products manufactured
by or for The Procter & Gamble Company, its Affiliates or
Subsidiaries («P&G») that can be identified by the Braun / Oral-B
trademark, trade name, or logo affixed thereto. This limited warranty
does not apply to any non-P&G product including hardware and
software. P&G is not liable for any damage to or loss of any
programs, data, or other information stored on any media contained
within the product, or any non-P&G product or part not covered by
this limited warranty. Recovery or reinstallation of programs, data or
other information is not covered under this limited warranty.
This limited warranty does not apply to (i) damage caused by
accident, abuse, misuse, neglect, misapplication, or non-P&G
product; (ii) damage caused by service performed by anyone other
than Braun or authorized Braun service location; (iii) a product or
part that has been modified without the written permission of P&G,
and (iv) damage arising out of the use of or inability to use the
Oral-B Smartphone stand/puck, Smartphone mirror holder, or
charging travel case («Accessories»).
2) Using your smartphone holder
The Oral-B Accessories included in the package has been designed
to provide you with a convenient way to position your smartphone
while you are using the Oral-B app. Try multiple orientations of your
smartphone in the Oral-B smartphone holder prior to use to
determine the best positioning of your smartphone in the holder.
Be sure to try this in a manner which will not harm your smartphone
if it falls out of the stand. Do not use in automobiles.
LIMITATION OF LIABILITY
TO THE EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT
SHALL P&G ITS DISTRIBUTORS OR SUPPLIERS BE LIABLE TO
YOU OR ANY THIRD PARTY FOR ANY DIRECT, INDIRECT,
INCIDENTAL, CONSEQUENTIAL, SPECIAL, EXEMPLARY OR
PUNITIVE DAMAGES, OF ANY NATURE WHATSOEVER, ARISING
OUT OF THE USE OF OR INABILITY TO USE THE ORAL-B
ACCESSORIES, INCLUDING, WITHOUT LIMITATION, INJURY TO
PERSONS, PROPERTY DAMAGE, LOSS OF VALUE OF ANY THIRD
PARTY PRODUCTS THAT ARE USED IN OR WITH THE ORAL-B
ACCESSORIES, OR LOSS OF USE OF THE ORAL-B
ACCESSORIES OR ANY THIRD PARTY PRODUCTS THAT ARE
USED IN OR WITH THE ORAL-B ACCESSORIES, EVEN IF P&G
HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
WITHOUT LIMITING THE FOREGOING, YOU UNDERSTAND AND
AGREE THAT P&G HAS NO LIABILITY FOR ANY DAMAGE OR
DESTRUCTION TO CONSUMER ELECTRONICS DEVICES OR
OTHER PERSONAL PROPERTY THAT ARE CONTAINED ON OR
EXTERIOR TO THE ORAL-B ACCESSORIES, OR ANY LOSS OF
DATA CONTAINED IN THE FOREGOING DEVICES. IN NO EVENT
SHALL ANY RECOVERY AGAINST ORAL-B EXCEED THE ACTUAL
PRICE PAID FOR THE PURCHASE OF THE PRODUCT.
Warranty replacement brush heads
Oral-B warranty will be voided if electric rechargeable handle
damage is found to be attributed to the use of non-Oral-B
replacement brush heads.
Oral-B does not recommend the use of non-Oral-B replacement
brush heads.
