English
6English
Introduction
Congratulations on your purchase and welcome to
Philips! To fully benefit from the support that Philips
offers, register your product at
www.philips.com/welcome.
Important safety information
Only use the product for its intended purpose. Read
this important information carefully before you use
the product and its batteries and accessories, and
save it for future reference. Misuse can lead to
hazards or serious injuries.
Warnings
- Charge only with Philips WAA1001, WAA2001, UL or
equivalent safety approved adapters with input
ratings (100 - 240V~; 50/60Hz; 3.5W) and output
ratings (5Vdc; 2.5W). For the list of adapters, please
see Philips.com/support
- Keep the charger away from water.
- Make sure the handle is completely dry before you
connect the USB charger.
- This appliance can be used by children and
persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if
they have been given supervision or instruction
concerning use of the appliance in a safe way and
understand the hazards involved. Cleaning and
user maintenance shall not be made by children
without supervision.
- Children shall not play with the appliance.
- Only use original Philips accessories or
consumables. Only use the USB charger provided
with the product.
- This appliance contains no user-serviceable parts.
If the appliance is damaged, stop using it and
contact the Consumer Care Center in your country
(see 'Warranty and support').
- Do not charge the product outdoors or near
heated surfaces.

7
English
- Do not clean any part of the product in the
dishwasher.
- This appliance has only been designed for cleaning
teeth, gums and tongue.
- Stop using the appliance and consult your
dentist/doctor if excessive bleeding occurs after
use, if bleeding continues to occur after 1 week of
use or if you experience discomfort or pain.
- If you have had oral or gum surgery in the previous
2 months, consult your dentist before you use this
appliance.
- If you have a pacemaker or other implanted device,
contact your doctor or the manufacturer of the
implanted device prior to use.
- If you have medical concerns, consult your doctor
before you use this appliance.
- This appliance is a personal care device and is not
intended for use on multiple patients in a dental
practice or institution.
- Stop using a brush head with crushed or bent
bristles. Replace the brush head every 3 months or
sooner if signs of wear appear.
- If your toothpaste contains peroxide, baking soda
or bicarbonate (common in whitening
toothpastes), thoroughly clean the brush head with
soap and water after each use. This prevents
possible cracking of the plastic.
- Avoid direct contact with products that contain
essential oils or coconut oil. Contact may result in
bristles dislodging.
- Charge, use and store the product at a
temperature between 0°C and 40°C.
- Keep product and batteries away from fire and do
not expose them to direct sunlight or high
temperatures.
- If the product becomes abnormally hot or smelly,
changes color or if charging takes longer than
usual, stop using and charging the product and
contact Philips.
- Do not place products and their batteries in
microwave ovens or on induction cookers.

8English
- Do not open, modify, pierce, damage or dismantle
the product or battery to prevent batteries from
heating up or releasing toxic or hazardous
substances. Do not short-circuit, overcharge or
reverse charge batteries.
- If batteries are damaged or leaking, avoid contact
with the skin or eyes. If this occurs, immediately
rinse well with water and seek medical care.
Electromagnetic fields (EMF)
This Philips appliance complies with all applicable
standards and regulations regarding exposure to
electromagnetic fields.
Intended use
1000 and 2000 Series power toothbrushes are
intended to remove adherent plaque and food debris
from the teeth to reduce tooth decay and improve
and maintain oral health. 1000 and 2000 series power
toothbrushes are intended for consumer home use.
Use by children should be with adult supervision.
Your Philips Sonicare toothbrush
1 Hygienic travel cap
2 Brush head
3 Handle
4 Power on/off button
5 Battery level indicator
6 USB charger (wall adapter not included)
Note: Wall adapter not included. Only use 5V IPX4
adapter (Type A).

9
English
Getting started
Attaching the brush head
1Align the brush head so the bristles point in the
same direction as the front of the handle.
2Firmly press the brush head down onto the metal
shaft until it stops.
Note: It is normal to see a slight gap between the
brush head and the handle. This allows the brush
head to vibrate properly.
Charging your Philips Sonicare
1Plug the USB charging cord into a wall adapter that
is connected to a electrical outlet.
2Place the handle on the charger.
- The light of the battery level indicator
illuminates and the handle beeps twice. This
indicates that the toothbrush is charging.
Note: It can take up to 24 hours to fully charge the
battery, but you can use the Philips Sonicare
toothbrush before it is fully charged.
Using your Philips Sonicare toothbrush
If you are using your Sonicare toothbrush for the first
time, it is normal to feel more vibration than when
using a non-electric toothbrush. It is common for first
time users to apply too much pressure. Only apply
gentle pressure and let the toothbrush do the
brushing for you. Please follow brushing instructions
below for the best experience. To help you transition
to your new Sonicare power toothbrush, it comes with
the EasyStart feature turned on. This feature gently
increases the power over the first 14 brushings to help

10 English
you adapt to brushing with a Philips Sonicare
toothbrush.
Brushing instructions
1Wet the bristles and apply a small amount of
toothpaste.
2Place the toothbrush bristles against the teeth at a
slight angle (45 degrees), pressing gently to make
the bristles reach the gumline or slightly beneath
the gumline.
Note: Keep the center of the brush in contact with
the teeth at all times.
3Press the power on/off button to turn on the
Philips Sonicare.
4Gently keep the bristles placed on the teeth and in
the gumline. Brush your teeth with small back and
forth motion so the bristles reach between the
teeth. Continue this motion throughout your
brushing cycle.
Note: The bristles should slightly flare. It is not
recommended to scrub as you would with a
manual toothbrush.
5To clean the inside surfaces of the front teeth, tilt
the brush handle semi-upright and make several
vertical overlapping brushing strokes on each
tooth.
Note: To make sure you brush evenly throughout
the mouth, divide your mouth into 4 sections using
the Quadpacer feature (see chapter ‘Features’).
2
4
3
1
6Begin brushing in section 1 (outside upper teeth)
and brush for 30 seconds before you move to
section 2 (inside upper teeth). Continue brushing in
section 3 (outside lower teeth) and brush for 30
seconds before you move to section 4 (inside
lower teeth).

11
English
7After you have completed the brushing cycle, you
can spend additional time brushing the chewing
surfaces of your teeth and areas where staining
occurs. You can also brush your tongue, with the
toothbrush turned on or off, as you prefer.
Your Philips Sonicare toothbrush should be safe to
use on braced (brush heads wear out sooner when
used on braces) and dental restorations (fillings,
crowns, veneers) if they are properly adhered and
not compromised. If a problem occurs, please
follow up with a dental professional.
Note: When the Philips Sonicare toothbrush is used in
clinical studies, the handle should be fully charged
and the EasyStart feature deactivated.
Charging and battery status
1Attach the USB charging cord to a wall adapter,
plug the wall adapter into an electrical wall outlet.
2Place the handle on the charger.
Note: The handle will emit 2 short beeps to confirm
that the handle is placed properly on the charger and
is charging.
Note: This Philips Sonicare toothbrush is designed to
provide at least 28 brushing sessions, each session
lasting 2 minutes (14 days if used twice per day). The
battery level indicator shows the battery status when
you complete the 2-minute brushing session, when
you pause the handle, or while it is charging.
Battery status (when handle is on a working charger)
Battery status Battery indicator
Full Solid green (turns off after 30
seconds)
Charging Flashing green

12 English
Battery status (When handle is not placed on charger)
Battery status Battery indicator Sound
Full Solid green -
Partially full Flashing green -
Low Flashing orange 3 beeps
Empty Flashing orange 2 sets of 5 beeps
Note: To save energy, the battery light will turn off
when not in use.
Note: When the battery is completely empty, the
Philips Sonicare toothbrush turns off. Place the Philips
Sonicare toothbrush on the charger to charge it.
Note: To keep the battery fully charged at all times,
you may keep your Philips Sonicare toothbrush on the
charger when not in use.
Features
QuadPacer
2
4
3
1
The QuadPacer is an interval timer that has a short
beep and pause to remind you to brush the 4 sections
of your mouth evenly and thoroughly. This Philips
Sonicare toothbrush comes with the QuadPacer
feature activated.
SmarTimer
The SmarTimer indicates that your brushing cycle is
complete by automatically turning off the toothbrush
at the end of the brushing cycle.
Dental professionals recommend brushing no less
than 2 minutes twice a day.
Note: If you press the power on/off button after you
started the brushing cycle, the toothbrush will pause.
After a pause of 30 seconds, the SmarTimer resets.

13
English
EasyStart
This Philips Sonicare model comes with the EasyStart
feature activated. The EasyStart feature gently
increases the power over the first 14 brushings to help
you get used to the brushing with the Philips Sonicare.
Activating or Deactivating EasyStart
1Place the handle on the plugged-in charger.
2Press and hold the power on/off button while the
handle remains on the charger.
3Keep the power on/off button pressed until you
hear a single short beep (after 3 seconds).
4Release the power on/off button.
5After you release the power on/off button, you’ll
hear three tones.
- Triple tone of low-med-high means the EasyStart
feature has been activated.
- Triple tone of high-med-low means the EasyStart
feature has been deactivated.
Cleaning
You should clean your Philips Sonicare toothbrush
regularly to remove toothpaste and other residue.
Failure to clean your Philips Sonicare toothbrush may
result in an unhygienic product and damage to it may
occur.
Warning: Do not clean product or accessories
with sharp objects or in dishwasher, microwave,
with chemicals or in boiling hot water
Toothbrush handle
1Remove the brush head and rinse the metal shaft
area with warm water. Make sure you remove any
residual toothpaste.
Caution: Do not push on the rubber seal on the metal
shaft with sharp objects, as this may cause damage.
2Wipe the entire surface of the handle with a damp
cloth.
Note: Do not tap the handle on the sink to remove
excess water.

14 English
Brush head
1Rinse the brush head and bristles after each use.
2Remove the brush head from the handle and rinse
the brush head connection with warm water at
least once a week. Rinse the travel cap as often as
needed.
Charger
1Unplug the charger before you clean it.
2Wipe the surface of the charger with a damp cloth.
Storage
If you are not going to use the product for a long time,
unplug it, clean it (see chapter 'Cleaning') and store it
in a cool and dry place away from direct sunlight.
Replacement
Brush head
Replace Philips Sonicare brush heads every 3 months
to achieve optimal results. Use only Philips Sonicare
replacement brush heads.
Locating the model number
Look on the bottom of the Philips Sonicare
toothbrush handle for the model number (HX36XX).
Warranty and support
If you need information or support, please visit
www.philips.com/support or read the international
warranty leaflet.
Warranty restrictions
The terms of the international warranty do not cover
the following:
- Brush heads.
- Damage caused by use of unauthorized
replacement parts.
- Damage caused by misuse, abuse, neglect,
alterations or unauthorized repair.

15
English
- Normal wear and tear, including chips, scratches,
abrasions, discoloration or fading.
Recycling
- This symbol means that electrical products and
batteries shall not be disposed of with normal
household waste.
- Follow your country’s rules for the separate
collection of electrical products and batteries.
Removal of built-in rechargeable battery
The built-in rechargeable battery must only be
removed by a qualified professional when the
appliance is discarded. Before removing the battery,
make sure that the battery is completely empty.
Take any necessary safety precautions when you
handle tools to open the appliance and when you
dispose of the rechargeable battery. Be sure to
protect your eyes, hands, fingers, and the surface
on which you work.
When you handle batteries, make sure that your
hands, the product and the batteries are dry.
To avoid accidental short-circuiting of batteries
after removal, do not let battery terminals come
into contact with metal objects (e.g. coins,
hairpins, rings). Do not wrap batteries in
aluminum foil. Tape battery terminals or put
batteries in a plastic bag before you discard
them.
Removing the rechargeable battery
Before removing the battery, make sure that the
battery is completely empty.
To remove the rechargeable battery, you need a towel
or cloth, a hammer and a flat-head (standard)
screwdriver.

16 English
1To deplete the rechargeable battery of any charge,
remove the handle from the charger, turn on the
Philips Sonicare and let it run until it stops. Repeat
this step until you can no longer turn on the Philips
Sonicare.
2Remove and discard the brush head. Cover the
entire handle with a towel or cloth.
1
2
3Hold the top of the handle with one hand and
strike the handle housing 0.5 inch above the
bottom end. Strike firmly with a hammer on all 4
sides to eject the end cap.
Note: You may have to hit on the end several times
to break the internal snap connections.
4Remove the end cap from the toothbrush handle.
If the end cap does not release easily from the
housing, repeat step 3 until the end cap is
released.
5Holding the handle upside down, press the shaft
down on a hard surface. If the internal components
do not easily release from the housing, repeat step
3 until the internal components are released.
6Wedge the screwdriver between the battery and
the white frame at the bottom of the internal
components. Then pry the screwdriver away from
the battery to break the bottom of the white frame.

17
English
7Insert the screwdriver between the bottom of the
battery and the white frame to break the metal tab
connecting the battery to the green printed circuit
board. This will release the bottom end of the
battery from the frame.
8Grab the battery and pull it away from the internal
components to break the second metal battery
tab.
Caution: Be aware of the sharp edges of the
battery tabs so as to avoid injury to your fingers.
9Cover the battery contacts with tape to prevent
any electrical short from residual battery charge.
The rechargeable battery can now be recycled and
the rest of the product discarded appropriately.

Bahasa Melayu
18 Bahasa Melayu
Pengenalan
Tahniah atas pembelian anda dan selamat
menggunakan Philips! Untuk memanfaatkan
sepenuhnya sokongan yang ditawarkan oleh Philips,
daftar produk anda di www.philips.com/welcome.
Maklumat keselamatan penting
Hanya gunakan produk untuk tujuan penggunaan
produk ini. Baca maklumat penting ini dengan teliti
sebelum anda menggunakan produk dan bateri serta
aksesorinya, dan simpan untuk rujukan pada masa
hadapan. Penyalahgunaan boleh menyebabkan
bahaya atau kecederaan serius.
Amaran
- Hanya mengecas dengan penyesuai Philips
WAA1001, WAA2001, UL atau penyesuai yang
diperakui selamat yang setara dengan pengadaran
input (100 - 240V ~; 50 / 60Hz; 3.5W) dan
pengadaran output (5Vdc; 2.5W). Untuk senarai
penyesuai, sila lihat Philips.com/support
- Pastikan pengecas berada jauh dari air.
- Pastikan pemegang kering sepenuhnya sebelum
anda menyambungkan pengecas USB.
- Perkakas ini boleh digunakan oleh kanak-kanak
dan orang yang kurang upaya dari segi fizikal, deria
atau mental, atau kurang berpengalaman dan
pengetahuan jika mereka diberi pengawasan dan
arahan berkenaan penggunaan perkakas secara
selamat dan memahami bahaya yang mungkin
berlaku. Pembersihan dan penyelenggaraan oleh
pengguna tidak harus dilakukan oleh kanak-kanak
tanpa pengawasan.
- Kanak-kanak tidak sepatutnya bermain dengan
perkakas ini.
- Hanya gunakan aksesori atau barangan pakai
habis Philips yang tulen. Hanya gunakan pengecas
USB yang dibekalkan bersama produk.

19
Bahasa Melayu
- Perkakas ini tidak mengandungi bahagian yang
boleh diservis pengguna. Jika perkakas tersebut
rosak, berhenti menggunakan perkakas itu dan
hubungi Pusat Khidmat Pengguna di negara (lihat
'Jaminan dan sokongan') anda.
- Jangan cas produk ini di luar atau berdekatan
permukaan panas.
- Jangan bersihkan mana-mana bahagian produk ini
di dalam mesin basuh pinggan mangkuk.
- Perkakas ini hanya direka bentuk untuk
membersihkan gigi, gusi dan lidah.
- Berhenti menggunakan perkakas ini dan berjumpa
dengan doktor gigi/doktor anda sekiranya
pendarahan berlebihan berlaku selepas
penggunaan, jika pendarahan terus berlaku
setelah 1 minggu penggunaan atau jika anda
mengalami ketidakselesaan atau kesakitan.
- Jika anda pernah melalui pembedahan gigi atau
gusi dalam tempoh 2 bulan sebelum ini, hubungi
doktor gigi anda sebelum anda menggunakan
perkakas ini.
- Jika anda mempunyai perentak jantung atau
peranti lain yang diimplan, hubungi doktor anda
atau pengilang peranti yang diimplan sebelum
menggunakan peranti tersebut.
- Jika anda mempunyai keraguan dari segi
perubatan, temui doktor anda sebelum anda
menggunakan perkakas ini.
- Perkakas ini ialah alat pembersihan peribadi dan
tidak dimaksudkan untuk digunakan oleh lebih dari
seorang pesakit di klinik atau institusi gigi.
- Berhenti menggunakan kepala berus dengan bulu
kejur yang renyuk atau bengkok. Gantikan kepala
berus setiap 3 bulan sekali atau lebih awal jika
tanda-tanda haus kelihatan.
- Jika ubat gigi anda mengandung peroksida, baking
soda atau bikarbonat (biasa di dalam ubat gigi
pemutihan), bersihkan kepala berus dengan teliti
menggunakan sabut dan air selepas setiap kali
digunakan. Ini mencegah kemungkinan rekahan
pada plastiknya.

20 Bahasa Melayu
- Elakkan sentuhan langsung dengan produk yang
mengandungi minyak pati atau minyak kelapa.
Sentuhan mungkin menyebabkan bulu berus
tertanggal.
- Cas, gunakan dan simpan produk pada suhu
antara xx°C hingga xx°C.
- Jauhkan produk dan bateri daripada api dan
jangan dedahkan kepada cahaya matahari
langsung atau suhu tinggi.
- Jika produk menjadi panas secara luar biasa atau
mengeluarkan bau, berubah warna atau jika
pengecasan memakan masa yang lebih lama
daripada biasa, berhenti menggunakan serta
mengecas produk dan hubungi pengedar Philips
tempatan anda.
- Jangan letakkan produk dan baterinya dalam
ketuhar gelombang mikro atau pada dapur induksi.
- Jangan buka, ubah suai, tebuk, rosakkan atau
merungkas produk atau bateri untuk mengelak
bateri daripada memanas atau melepaskan bahan
toksik atau berbahaya. Jangan pintaskan litar,
terlebih cas atau melakukan pengecasan berbalik
pada bateri.
- Jika bateri rosak atau bocor, elakkan daripada
tersentuh kulit atau mata. Jika ini berlaku, bilas
segera dengan air dan dapatkan rawatan
perubatan.
Medan elektromagnet (EMF)
Perkakas Philips ini mematuhi semua piawaian dan
peraturan yang berkaitan dengan pendedahan
kepada medan elektromagnet.
Tujuan penggunaan
Berus gigi berkuasa 1000 dan 2000 Series bertujuan
untuk menanggalkan plak dan sisa makanan yang
melekat daripada gigi untuk mengurangkan kerosakan
gigi dan menambah baik serta menjaga kesihatan oral.
Berus gigi berkuasa 1000 dan 2000 series bertujuan
untuk penggunaan pengguna di rumah. Penggunaan
