Braun PL-3011 User manual

90059367/VI-21
90059367_ECLIPSE_PL3_NA.indd 190059367_ECLIPSE_PL3_NA.indd 1 07.06.21 12:2007.06.21 12:20
Stapled booklet, 148 x 210 mm, 30 pages (incl. 6 pages cover),
Cover 4/4c, Content 2/2c = Pantone Medium Purple U + black

US Helpline:
1-800-BRAUN-11 or
1-800-272-8611
Canada Helpline/
Assistance téléphonique au Canada :
1-800-387-6657
Type / Modèle 6032
Braun GmbH
Frankfurter Straße 145
61476 Kronberg/Germany/Allemagne
www.braun.com
www.service.braun.com










































90059367_ECLIPSE_PL3_NA.indd 290059367_ECLIPSE_PL3_NA.indd 2 07.06.21 12:2007.06.21 12:20

I II III IV V VI












 








Skin tone & Body hair type chart:
Tableau des teints de peau et poils corporels:
Skin tone
Teint de
peau
Hair
color
Couleur
des poils




















==

suitable /
convient à
not suitable or effective for use /
ne convient pas à/n’est pas efficace pour
Please note that the skin tones above do not relate to the Fitzpatrick scale /
Veuillez noter que les teints de la peau ci-dessus ne sont pas les mêmes que ceux de la
classification de Fitzpatrick.
8
7
6
2
1





















5
3
SensoAdapt
1
2
3
4
Silk
•
expert
Pro 3
SensoAdapt
1
2
3
10 11
12
9
90059367_ECLIPSE_PL3_NA.indd 390059367_ECLIPSE_PL3_NA.indd 3 07.06.21 12:2107.06.21 12:21

4
Table of Contents
1 Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2 How Does Silk·expert Pro3 Work? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3 Important Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3.1 Contraindications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3.2 Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3.3 Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
4 Potential Risks, Side Effects and Skin Reactions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
5 Benefits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
6 Intended Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
7 How to Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
8 Treatment Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
9 Cleaning, Maintenance and Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
10 Travelling with the device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
11 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
12 Labels and Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
13 Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
14 Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
15 Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Français. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
90059367_ECLIPSE_PL3_NA.indd 490059367_ECLIPSE_PL3_NA.indd 4 07.06.21 12:2107.06.21 12:21

5
Our products are designed to meet the highest standards of quality, functionality and design. Using
professional light technology, Braun Silk·expert Pro3 Intense Pulsed Light (IPL) is a hair removal device
that can be used comfortably at home.
1 Description
1 Treatment window
2 SensoAdapt™ skin tone sensors
3 LED Power bars
4 Sensitive mode button with indicator light
5 Treatment button
6 Handle
7 Base station with serial number
8 Mains cord
9 Glass filter
10 Standard head
11 Wide head*
12 Precision head *
* not with all models
2 How Does Silk·expert Pro3 Work?
Silk·expert Pro3 is designed to help break the cycle of hair growth. Light energy is transferred through the
skin’s surface and is absorbed by melanin present in the hair shaft. The absorbed light energy is converted
to heat energy (below the surface of the skin), which disables the hair follicle. Treated hairs naturally fall
out over the course of a few days to 1-2 weeks.
What to Expect
Immediately post treatment, you should not see any significant side effects from treatment (Refer to
section 4 for more information on side effects).
In the first few weeks following the initial treatments, you will still see some hairs growing. These are likely
to be hairs that were missed during treatment i.e. they were lying dormant and not in their growth phase
(Anagen) during treatment, when IPL is most effective.
Around 6 weeks into the 12 week treatment program you should see a reduction in hair growth. However,
many hairs may still not have been treated in their growth phase. It is important to continue the weekly
treatments.
After the 12 week program, you should see a significant reduction in hairs within the treated area. Any
remaining hairs should be finer and lighter in color. Continued monthly treatments, or treatments as
required, should maintain the reduction in unwanted hair.
3 Important Safety Information
3.1 Contraindications
DO NOT use the device if you have very dark skin. The Skin Tone sensors located near
the output window of the device will determine the tone of your skin. If the Skin Tone
sensors determine your skin is too dark for safe use, operation will be prevented.
DO NOT use the device if your skin has been artificially or naturally tanned recently
or is burned from sun overexposure. Your skin may be extra sensitive following sun
exposure and particularly susceptible to burning, blistering, discoloring or scarring
90059367_ECLIPSE_PL3_NA.indd 590059367_ECLIPSE_PL3_NA.indd 5 07.06.21 12:2107.06.21 12:21

6
if you use the device. Wait 1 week until sunburn or tan disappears before using the
device. Treating tanned skin with IPL may result in permanent Hyper (darkening) or
Hypo (lightening) changes to the treated skin.
DO NOT expose treated areas to the sun. Wait at least 7 days after treatment before
exposing treated skin to direct sunlight. Your skin may be extra sensitive following
IPL treatment and particularly susceptible to sunburn. Apply sunscreen (SPF 15 or
greater) to the treated area or cover the treated area with suitable clothing.
DO NOT use the device directly on the nipples, genitals or around the anus. These
areas may have a darker skin color and/or greater hair density. Using the device in
these areas may cause discomfort/pain or injure (burn, discolor or scar) your skin.
DO NOT use the device if you have a history of skin cancer or pre-cancerous
lesions (e.g. nevi or a large number of moles).
DO NOT use if you are pregnant, lactating, as this device has not been tested with
these individuals.
DO NOT use on dark brown or black spots such as birthmarks, moles or warts in
the area you wish to treat. Using the device may injure your skin or make existing
conditions worse. You may experience side effects such as burns, blisters and skin
color changes or scarring.
DO NOT use if you have any skin condition in the treatment area, including psoriasis,
vitiligo, eczema, acne, herpes simplex or active infections, wounds or blisters.
DO NOT use if you are under the age of 18 as this device has not been tested on
these individuals.
DO NOT use on scars, tattoos or permanent make up in the treatment area.
DO NOT use on beard/facial hair for men.
3.2 Warnings
DO NOT use if you have a known sensitivity to sunlight (photosensitivity) or are
taking a medication that causes photosensitivity e.g., certain antibiotics such as
tetracycline, NSAIDS such as ibuprofen or retinoids such as Accutane and/or
topical retinoids such as Retin A. Always check the instructions that come with your
medical products to see if photosensitivity is listed as a side effect. Using the Silk
Expert device on photosensitive skin could result in skin damage including blisters
and swelling.
DO NOT use more than once a week on the same area. Damage of skin may occur
after prolonged or repeated treatment on one site.
It is not recommended to use this device where dermal fillers are present.
Women who are using the device on the face:
DO NOT use if you have had a skin peel treatment on the area of the face you wish
to treat. You should wait 30 days after a skin peel before treating.
90059367_ECLIPSE_PL3_NA.indd 690059367_ECLIPSE_PL3_NA.indd 6 07.06.21 12:2107.06.21 12:21

7
DO NOT use if you have had a laser skin resurfacing procedure on the area of the
face you wish to treat. You should wait 6 months following a laser skin resurfacing
procedure before treating.
EYE SAFETY
The device emits flashes of Intense Pulsed Light. Direct exposure is potentially
harmful to your eyes. Take care to follow the safety precautions below.
Possible eye injury (potentially leading to loss of vision) or skin injury if instructions
are not followed. Protect the eye from exposure. Do not use the device over the eye
lids or close to the eye.
The device can only be activated (flashed) if both Skin Tone Sensors (2) detect a
valid Skin Tone reading. However:
DO NOT look directly into the treatment window (1) when the device has electrical
power and is activated.
DO NOT attempt to activate (flash) the device towards the eye.
DO NOT treat areas around the eye (eyebrows or eyelashes).
ONLY attempt to activate (flash) the device when the treatment window is in good
contact with the area you wish to treat.
WE RECOMMEND you look away from the device when pushing the treatment button.
ELECTRICAL AND FIRE SAFETY
As with any electrical device, certain precautions must be taken in order to ensure
your safety.
DO NOT try to open the device, as this may expose you to dangerous electrical
components.
DO NOT use if the device is damaged; for example, cracked housing, cable damage
(internal wires visible), cracked or broken glass filter etc. This may result in injury.
DO NOT use near bathtubs, showers, basins or other vessels containing water.
If the device becomes wet, it should not be used.
DO NOT use if the device becomes uncomfortably hot to touch. This may indicate
that the unit is damaged.
DO NOT attempt to activate (flash) the device onto any surface other than skin.
DO NOT operate the device if the mains plug is not easily accessible. You should be
able to disconnect at any time.
DO NOT override the safety mechanism inherent to the device.
WARNING No modification of this equipment is allowed.
Do not use any other component, nor manipulate the device. This may damage the
unit and cause it to stop working.
90059367_ECLIPSE_PL3_NA.indd 790059367_ECLIPSE_PL3_NA.indd 7 07.06.21 12:2107.06.21 12:21

8
GENERAL SAFETY
The device should be kept out of the reach of children under 18 years of age.
Children should not use, play with, maintain or clean the device. There are a number
of potential risks – exposure to the light output causing burns or eye damage,
electrocution, strangulation from the cables, choking on the Removable Front.
People with reduced physical, sensory or mental capabilities or lack of experience
and knowledge may use the device if they have been given supervision or instruction
concerning the safe use of the device and understand the hazards involved.
The Glass filter (9) is a critical component that will get hot during use.
Keep the device out of reach of pets and pests which could damage it.
DO NOT touch the glass filter during or directly after use. Regularly inspect the
filter for damage.
DO NOT use the device if the filter is cracked or missing.
DO NOT use if the built-in reflector is missing or not in correct place.
3.3 Precautions
Hair removal by lasers or intense pulse light sources can cause increased hair
growth in some individuals. Based upon currently available data, the highest risk
groups for this response are females of Mediterranean, Middle Eastern, and South
Asian heritage treated on the face and neck.
DO NOT USE the device on any area where you may want hair to grow back.
The device is not recommended for use on red, grey, white or blonde hair since it is
not effective on these hair colors.
4 Potential Risks, Side Effects and Skin Reactions
The use of this device could result in side effects. The table below lists the known skin reactions that may
occur following treatment with the device.
Possible Side Effects How to assess and react
Mild pain / discomfort in the area being treated This is expected and is normal for all IPL
treatments. You can keep on using the device as
instructed, and the pain should diminish with
continued use.
Warm feeling or tingling sensations during
treatment, which typically disappear after a few
seconds to a minute and decrease with continued
use.
This is expected and is normal for all IPL
treatments. You can keep on using the device as
instructed.
Itchiness in the treatment area This is quite common for IPL treatments, and
should subside after a short period. You can keep
on using the device as instructed. Do not scratch
the area.
Skin redness during or after treatment which
disappears within minutes. This is expected and is normal for all IPL treatments. You can keep on using the device as
instructed once skin redness has disappeared.
90059367_ECLIPSE_PL3_NA.indd 890059367_ECLIPSE_PL3_NA.indd 8 07.06.21 12:2107.06.21 12:21

9
Skin redness which does not disappear within
minutes and lasts 24-48 hours. Stop using the device immediately and consult your physician before using it again.
Pain or discomfort that is intense during treatment
or persists after a treatment. Stop using the device immediately and consult your physician before using it again.
In very rare cases How to assess and react
Swelling and redness that does not disappear
within two to three days. Stop using the device immediately and consult your physician before using it again.
Temporary changes in skin color (lightening or
darkening). If your skin color changes, stop using the device immediately and consult your physician.
Blistering or burning of the skin. Stop using the device immediately and consult
your physician before using it again. Apply a cold
pack to the area. Treat with antiseptic or burn
cream.
In a clinical trial of 50 subjects, each subject received 12 weekly treatments. The recorded effects were:
• Itchiness: Four subjects experienced mild itchiness after treatment.
• Slight Redness: This was reported by 1 subject.
• Mild Stinging Sensation: Five subjects reported mild discomfort following treatment.
• In-growing Hair: One subject reported experiencing an in-growing hair following treatment.
• Follicle Redness: One subject reported a red spot at the treatment site following treatment.
In all cases, the treated skin returned to normal within 7 days.
5 Benefits
The device is indicated for the permanent reduction of unwanted hair.
A clinical trial was performed to assess both the safety and efficacy of the device. The key features of the
clinical trial were:
• All treatments were performed by non-medically trained operators at a single location using devices
identical to the one provided in this package;
• All subjects were required to complete questionnaires related to their general health and those who
could not be treated, e.g. those who had one or more of the contraindications as listed in Section 3 of
this User Manual were excluded. In addition, all subjects were required to provide Informed Consent as
per international clinical trial requirements;
• A total of 53 female subjects, aged between 19 and 45 years old, commenced the trial;
• Three subjects left the trial during the treatment period for personal reasons. No subjects left the trial
due to problems associated with the use of the device;
• Each subject received 12 weekly treatments to their chosen body location. A typical treatment consisted
of shaving the site then applying the device following the same process as outlined in Section 7, Step 3
of this user manual;
• Hair counts were used to measure the change in the amount of hair 6 months after the last treatment
and 12 months after the last treatment. The hairs in the treatment sites were counted via high resolution
photography and the difference in hair counts was calculated as a percentage change;
• When used as directed, the clinical trial participants showed on average 44% less hair 6 months after
their last treatment and 36% less hair 12 months after their last treatment when compared to hair counts
taken before treatment (see table below). Actual results did vary from person to person.
Number of subjects at 6 months post treatment 50
Hair reduction at 6 months post treatment 43.9 %
Number of subjects at 12 months post treatment 33
Hair reduction at 12 months post treatment 36.0 %
% of subjects met success (> 30% hair reduction) on all body areas at 12 months
post treatment. Subject success is defined as greater than 30 % hair reduction at
all treatment sites at 12 months.
66.7 %
• The incidence of side effects during the clinical trial was minimal (as outlined in Section 4 above) and the
majority of subjects (48 out of 50) would recommend the device to their friends.
90059367_ECLIPSE_PL3_NA.indd 990059367_ECLIPSE_PL3_NA.indd 9 07.06.21 12:2107.06.21 12:21

10
6 Intended Use
USE
The device is intended for the permanent reduction in unwanted, visible hair for a single user.
BODY AREAS
Women: Legs, arms, underarms, bikini area and face (below the cheek bones)
CAUTION: Do not use the device near the eyes, along the forehead, on the lips or
nostrils. Do not use it in the genital area.
Men: Shoulders and below (chest, back, arms, stomach, legs)
CAUTION: Do not use on the face, neck or genital area.
The device is intended to be used on body hair below the neck, including arms,
underarms, bikini line, stomach and legs.
SKIN COLOR
The device is intended for use on light, medium and dark skin tones up to and including skin tone V (see
Skin tone chart on page 3). The device incorporates two Skin Tone Sensors that measure the color of your
skin and will prevent use if your skin tone is too dark.
HAIR COLOR
The device is intended for use on naturally black or brown hair. It may not be as effective on white, grey,
blonde or red hair.
7 How To Use
WARNING: Follow each step in the treatment process ensuring you complete all aspects of each step
before progressing to the next.
Step 1: Preparing the treatment area
Remove all visible hair on the skin before using the device. You may use your preferred hair removal
method. Remove any cosmetics, lotions and cream from the area you wish to treat. Cleanse the treatment
area and pat dry. To keep the treatment window clean and intact and prevent hair burns, make sure there is
no more hair remaining on the skin surface.
Step 2: Doing a Test Patch
Before your first treatment on each new body area, we RECOMMEND you test your skin (in that area) for
reactions.
The patch test area should be approximately 3 cm x 2 cm in size (equivalent to 2 flashes applied to the skin
side by side). Follow Step 3 to treat the area.
Wait 24 hours following the patch test, to ensure your skin is suitable for treatment and there is no adverse
reaction to the light energy. If there is no reaction after 24 hours, you may treat the area around the test
patch. The ‘patch tested area’ should not be re-treated for at least one week.
Step 3: Treating with Silk·expert Pro
a) Use the mains cord (8) to connect the base station to an electrical outlet. Press any button to activate
the device. The LED power bars (3) will light up once and a fan will start running. This means the device
is in READY mode. During operation, the device will heat up slightly.
b) Press the treatment window (1) firmly against the area to be treated ensuring both skin tone sensors (2)
are in contact with skin. The device will not operate if only one skin tone sensor is in contact with skin.
Once both skin tone sensors measure a valid skin tone, the pre-set output power is displayed on the
LED Power Bars (3) located on both sides of the device.
Silk·expert Pro uses skin tone sensors that continuously measure the color (tone) of your skin and
automatically set the correct level of output power needed based on the measured skin tone. This is not
related to the Fitzpatrick skin tone classification. If your skin is too dark for treatment with Silk·expert
Pro, the skin tone sensors will detect this and prevent the unit from operating.
RED lights will be shown in the Power Bar if your skin is too dark.
If a valid skin tone is detected, the Power Bars will illuminate WHITE.
90059367_ECLIPSE_PL3_NA.indd 1090059367_ECLIPSE_PL3_NA.indd 10 07.06.21 12:2107.06.21 12:21

11
light skin tone Uhigh power setting
dark skin tone Ulow power setting
no lights no skin contact Udevice cannot be activated
red light invalid skin tone Udevice cannot be activated
Thanks to the built-in, intelligent SensoAdaptTM, which automatically measures the skin color, there is no
need for the user to make any manual adjustment for skin tone. The skin tone chart on page 3 is displayed
also on the sales box as a guidance to potential purchasers to determine if the device will work on their
skin colouration. This does not relate to the Fitzpatrick scale, it is simply a color guide.
Number of Power bar lights illuminated 321
Max. energy (J/cm²) 4.21 3.99 3.77
c) Press the treatment button (5). The device will flash and a warm sensation should be felt.
If you find the treatment uncomfortable, you can reduce the light intensity using the sensitive mode
button (4). The sensitive mode indicator lights up when it is activated. To deactivate it, press the
sensitive mode button again.
The power bars flash to confirm a change in the light intensity setting.
When holding the sensitive mode button (4) longer than 3 seconds, the device is deactivated.
After 10 minutes without use, the device is automatically deactivated. To re-activate, press
any button.
d) Move the treatment window to the next area to be treated and repeat. The device needs to recharge
between flashes. This will take less than a second.
e) Ensure that the entire area receives treatment, but DO NOT treat an area twice (overlapping flashes).
If the device is used in high ambient temperatures for extended treatment sessions, short pauses in
treatment may be seen to allow cooling. This is normal and operation will resume once the device is
cooled.
8 Treatment Modes
The area to be treated has to be hair-free, clean and dry. Before pressing the treatment button, look away
from the device to avoid the bright light. In seldom cases, a user may find the flash too bright, however
there is no safety risk associated with this. For increased comfort, we recommend treating in a well-lit
room to help reduce the perceived brightness.
GLIDING
for fast and efficient
treatment of large areas
(e.g. legs).
STAMPING
for treating small,
hard-to reach areas
(e.g. face for females,
bikini line, underarms,
knee, chin, ankles)
1. Place the treatment window (1) firmly on your skin, ensuring both skin sensors (2) have skin contact.
Power bars (3) show white LEDs.
2. Press and hold the treatment button (5).
The device will begin to flash. 2. Press and instantly release the treatment button (5). The device will emit a flash.
90059367_ECLIPSE_PL3_NA.indd 1190059367_ECLIPSE_PL3_NA.indd 11 07.06.21 12:2107.06.21 12:21

12
3. Move the device slowly and continuously from the
bottom to the top of the treatment area to avoid
missing areas. Make sure to always keep full skin
contact so that the device flashes continuously.
3. Lift off the device and place it onto the next
adjacent spot to be treated. Wait for the
power bars to show white LEDs. Then press and
release the treatment button.
Once you have completed your first gliding stroke, lift
the device off the treatment area. Repeat steps 1 to
3 to treat the next adjacent area in a parallel stroke.
Continue treatment spot by spot until you have
completed the entire area you wish to treat.
Make sure to avoid missed areas by placing the treatment window directly next to the previously
treated spot without leaving any space between treated areas.
If you feel intense pain, stop treatment immediately and consult your physician before using the device again.
Treatment head(s)
The standard head (10) can be used on all areas.
The wide head (11)* is for large body areas.
The precision head (12)* has been specifically designed for small, curvy, hard to
reach areas.
* not with all models
Step 4: Your Treatment Schedule
For optimal results, Silk·expert should be used once a week for 12 weeks to ensure all hair follicles are
treated. After the initial treatment phase (12 treatments), we recommend the device is used once a month,
or as required, to maintain results.
Step 5: Switching Off the Device
When the treatment is finished, unplug the device. Refer to section 9 for details of how best to look after
your device.
9 Cleaning, Maintenance and Storage
After treatment, always unplug the device.
After use, the handset, the skin tone sensors (2) and the treatment window (1) should be inspected for
damage and wiped down with a dry, lint free cloth. If any marks or black spots are seen, then it is best to
clean them off straight away after treatment.
NEVER use water or other cleaning fluids, as these can damage the device leading to a potential safety hazard.
WARNING: The glass filter (9) can get hot during use. DO NOT touch or clean the filter for at least 5 minutes
after use to allow it to cool down.
To ensure maximum performance, keep the heads (10, 11, 12) with their built-in reflectors free from dirt,
hair or other debris. Do not clean them in water, but use a dry cloth for cleaning them carefully.
Store the device in a cool, dry place. Make sure that the treatment window and skin tone sensors are
protected from damage.
Regularly check the device (including cords) for visible signs of damage. In case of damage or cracks,
stop using the device.
 Travelling with the Device
The device will work with all commonly encountered mains supplies. Providing you have a suitable adaptor
for the mains power cable plug, the device will operate as normal.
90059367_ECLIPSE_PL3_NA.indd 1290059367_ECLIPSE_PL3_NA.indd 12 07.06.21 12:2107.06.21 12:21

13
  Troubleshooting
Problem Solution
Power bars do not light up when treatment window
is placed on the skin. Make sure the device is connected to an electrical outlet. Press any button to activate it.
Ensure both skin tone sensors are in full contact
with the skin. If needed, move the device in a way
that both skin tone sensors get skin contact.
The device doesn’t work on small areas. Use the precision head (if available) on small,
hard-to-reach areas. Make sure both skin tone
sensors are in contact with the skin.
With the precision head attached, the flashing
sequence is slower. This is normal.
On the power bar, only the first LED illuminates
red. Invalid skin tone reading. Your skin is too dark. For safety reasons, the device will not flash.
Sensitive mode light is flashing. Device is deactivated. Press any button to
re-activate it.
First LED on power bars flashes red. Head 10, 11 or 12 has been taken off. Re-attach it.
The power bars show an unfamiliar pattern of one
red LED shining along with individual white LEDs. Device error. Device will not operate. Unplug and re-connect.
If error persists, contact a Braun Service Center.
All white LEDs flash. End of product lifetime. Maximum number of
flashes (300,000) has been reached.
The device is broken, cracked or appears
defective. DO NOT USE if the handle, the base station or the mains cord is damaged.
90059367_ECLIPSE_PL3_NA.indd 1390059367_ECLIPSE_PL3_NA.indd 13 07.06.21 12:2107.06.21 12:21

14
 Labels and Symbols
The base station is marked with the following symbols:
Type BF Applied Part
Class II equipment
Note: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of
the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.
Follow instructions for use
WEEE waste disposal mark of the European Union
Conformity mark of the European Union
Keep Dry
Optical radiation
Not suitable for use in a bathtub or shower
MET
usCNRTL Certification marking
Other symbols shown on the base station refer to requirements for other regions.
 Technical specifications
Braun Silk·expert Pro3 is a filtered broadband Intense Pulsed Light system with the following technical
specifications:
Repetition rate: every 0.6 - 0.67 seconds (depending on treatment setting),
continuous operation
Max optical output: 4.21 J/cm2
Pulse length 2.6 msec FWHM
Wave length: 510 - 2000 nm
Power line input: 00 - 240V~, 50-60Hz, 1.7 - 0.91A
90059367_ECLIPSE_PL3_NA.indd 1490059367_ECLIPSE_PL3_NA.indd 14 07.06.21 12:2107.06.21 12:21

15
Operating temperature: 5°C - 40°C / 41°F - 104°F
Optimum operating temperature: 5°C - 30°C / 59°F - 86°F
Operating humidity: up to 93% R.H. non-condensing
Operating pressures: 700 hPa to 1060 hPa
Treatment area (spot size): 3 cm² (Wide head: 4 cm², Precision head: 1.5 cm²)
Transport Conditions:
Temperature range: – 25°C to 70°C / –13°F to 158°F
Humidity: up to 93% R.H. non-condensing
Pressures: 500 hPa to 1060 hPa
The device includes 300,000 flashes and is intended for a single user. Expected service life: 5 years
This device complies with the standards IEC 60601-1:2005/A2:2012, CAN/CSA-C22.2 No. 60601-1:2014,
ANSI/AAMI ES60601-1:2005 / A1:2012, IEC 60601-1-11:2015, IEC 60601-2-57:2011, EN 55014-1:2017,
EN 55014-2:2015, EN 61000-3-2:2014, EN 61000-3-3:2013.
 Support
US Helpline: 1-800-BRAUN-11 or 1-800-272-8611
Canada Helpline: 1-800-387-6657
If you are unable to call our Helpline during working hours, we provide online support via our web page
(www.braun.com) or Facebook.
Manufacturer:
CyDen Ltd., Block A, Bay Studios Business Park, Fabian Way, Swansea SA1 8QB, UK
 Warranty
For the US only: 1 year limited warranty
Braun warrants this device to be free of defects in material and workmanship for a period of one year from
the date of original purchase.
If the device exhibits such a defect, Braun will, at its option, either repair or replace it for the consumer
without charge.
Please call 1-800-Braun 11 (800-272-8611) to be referred to the authorized Braun Service Center closest
to you.
This warranty does not cover damage resulting from accident, misuse, abuse, dirt, water, tampering,
unreasonable use, servicing performed or attempted by unauthorized service agencies or failure to
provide reasonable and necessary maintenance.
ALL IMPLIED WARRANTIES INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS
FOR ANY PARTICULAR PURPOSE ARE LIMITED IN DURATION TO 1 YEAR FROM DATE OF ORIGINAL
PURCHASE. IN NO EVENT WILL BRAUN INC. BE RESPONSIBLE FOR CONSEQUENTIAL DAMAGES
RESULTING FROM THE USE OF THIS PRODUCT.
Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above
limitation or exclusion may not apply to you.
This warranty gives you specific legal rights, and you may also have other legal rights which vary from state
to state.
For Canada only:
In the event the device fails to function within 1 year from date of purchase, because of defects in material
or workmanship, and the consumer returns the unit to an authorized service center, Braun will, at its
option, either repair or replace the unit without additional charge to the consumer.
Please call 1-800-387-6657 or visit www.service.braun.com to be referred to the authorized Service
Center closest to you. This guarantee does not cover any product, which has been damaged by dropping,
tampering, wrong current, servicing performed or attempted by unauthorized service agencies, misuse
or abuse.
90059367_ECLIPSE_PL3_NA.indd 1590059367_ECLIPSE_PL3_NA.indd 15 07.06.21 12:2107.06.21 12:21

16
Exclusion of Warranties: The foregoing warranty is the sole warranty offered by Braun hereby disclaims
any implied warranty or merchantability or fitness for any particular purpose. In no event will Braun be
responsible for consequential damages resulting from the use of this product.
100 days money back satisfaction guarantee
Braun Silk·expert Intense Pulsed Light (IPL) is a hair removal device that can be used comfortably at home.
After 6 to 12 weeks of treatment, a reduction in hair regrowth will be visible.
We are willing to guarantee your full satisfaction, or your money back.
Try the Silk·expert for 10 to 12 weeks. If you are not fully satisfied after that time, please call 1-800 Braun
11 (800-272-8611) in the US or 1-800-387-6657 in Canada.
Please note: No refunds will be made for any device damaged by accident, neglect or unreasonable use.
Your device must be shipped in its original packaging, with your original sales slip indicating the date of
purchase.
Please include the following information when you return your device:
Name ................................................................................................................................................
Street ................................................................................................................................................
City ...................................................................................................................................................
State Zip code ....................................................................................................................................
Telephone number ............................................................................................................................. .
Please allow 6-8 weeks for handling.
90059367_ECLIPSE_PL3_NA.indd 1690059367_ECLIPSE_PL3_NA.indd 16 07.06.21 12:2107.06.21 12:21

17
Table des matières
1 Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
2 Comment Silk·expert Pro3 fonctionne-t-il? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
3 Informations importantes relatives à la sécurité . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
3.1 Contre-indications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
3.2 Avertissements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3.3 Précautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
4 Risques potentiels, effets secondaires et réactions cutanées . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
5 Avantages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
6 Utilisation conforme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
7 Comment utiliser l’appareil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
8 Méthodes de traitement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
9 Nettoyage, entretien et entreposage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
10 Voyager avec l’appareil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
11 Dépannage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
12 Étiquettes et symboles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
13 Caractéristiques techniques . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
14 Soutien . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
15 Garantie . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
90059367_ECLIPSE_PL3_NA.indd 1790059367_ECLIPSE_PL3_NA.indd 17 07.06.21 12:2107.06.21 12:21

18
Nos produits sont conçus pour satisfaire aux plus hautes exigences en matière de qualité, fonctionnalité et
design. Grâce à la technologie de lumière pulsée professionnelle, le Braun Silk·expert Pro3 à Lumière
intense pulsée (Intense Pulsed Light, ou IPL) est un appareil que vous pouvez utiliser dans le confort de
votre foyer.
1 Description
1 Fente d’émission
2 Détecteurs de teint SensoAdapt™
3 Indicateur de pile DEL
4 Bouton de mode sensible avec voyant lumineux
5 Bouton de traitement
6 Manche
7 Station de base avec numéro de série
8 Câble secteur
9 Filtre en verre
10 Tête standard
11 Tête large*
12 Tête de précision*
* pas sur tous les modèles
2 Comment Silk·expert Pro3 fonctionne-t-il?
Silk·expert Pro3 est conçu pour aider à arrêter la repousse des poils. La lumière est transmise à travers la
surface de la peau puis absorbée par la mélanine de la tige capillaire. La lumière ainsi absorbée est
convertie en chaleur (sous la surface de la peau), ce qui neutralise le follicule pileux. Les poils ainsi traités
tombent par eux-mêmes après quelques jours, au plus tard en 2 semaines.
À quoi s’attendre
Immédiatement après le traitement, vous ne devriez ressentir aucun effet secondaire (lire la section 4 pour
plus d’informations relatives aux effets secondaires).
Au cours des premières semaines suivant le premier traitement, les repousses continueront à apparaître.
Ces repousses sont probablement des poils qui ont échappé au traitement, c’est-à-dire qui n’étaient pas
en phase de croissance (anagène) lors du traitement, au moment où la lumière intense pulsée est la plus
efficace.
Environ à la 6esemaine du traitement de 12 semaines, vous devriez constater une réduction des
repousses. Cela dit, plusieurs poils n’auront toujours pas été traités lors de leur phase de croissance.
Il est important de poursuivre les traitements hebdomadaires.
Une fois le traitement de 12 semaines terminé, vous devriez constater une réduction importante du
nombre de poils dans la surface traitée. Les poils restants devraient être plus minces et plus pâles.
Poursuivre les traitements mensuels, ou lorsque nécessaire, devrait maintenir la réduction des poils
indésirables.
3 Informations importantes relatives à la sécurité
3.1 Contre-indications
NE PAS utiliser l’appareil si votre peau est très foncée. Les détecteurs de teint
situés près de la surface d’émission de l’appareil analyseront le teint de votre peau.
Si les détecteurs de teint déterminent que votre teint est trop foncé pour une
utilisation sécuritaire, l’appareil ne fonctionnera pas.
NE PAS utiliser l’appareil si votre peau a été bronzée de façon artificielle ou
naturelle, ou si vous souffrez d’une surexposition au soleil. Votre peau, suite à une
90059367_ECLIPSE_PL3_NA.indd 1890059367_ECLIPSE_PL3_NA.indd 18 07.06.21 12:2107.06.21 12:21

19
exposition au soleil, pourrait être très sensible. L’utilisation de l’appareil pourrait
entraîner des brûlures cutanées, de la décoloration, de la scarification et des
boursouflures. Veuillez attendre 1 semaine après un coup de soleil ou une séance
de bronzage avant d’utiliser l’appareil. Le traitement par lumière intense pulsée
d’une peau bronzée peut entraîner de l’hyperpigmentation (assombrissement) ou
de l’hypopigmentation (éclaircissement).
NE PAS exposer au soleil les surfaces traitées. Attendez au moins 7 jours après le
traitement avant d’exposer la peau traitée au soleil. Il se peut que votre peau, suite
à un traitement à lumière intense pulsée, soit très sensible et sujette aux coups de
soleil. Appliquez un écran solaire (FPS 15 ou plus) sur la surface traitée, ou
couvrez-la à l’aide de vêtements appropriés.
NE PAS utiliser l’appareil sur les mamelons, les parties génitales ou autour de
l’anus. Ces surfaces ont potentiellement un teint de peau plus foncé et/ou une
pilosité accrue. L’utilisation de l’appareil à ces endroits pourrait causer de
l’inconfort/de la douleur ou des blessures (brûlures, décoloration ou cicatrices) sur
votre peau.
NE PAS utiliser l’appareil si vous avez des antécédents de cancer de la peau ou de
lésions précancéreuses (des nævi ou de nombreux grains de beauté).
NE PAS utiliser l’appareil si vous êtes enceinte ou en lactation. Il n’a pas été
éprouvé auprès de ces personnes.
NE PAS utiliser l’appareil sur des taches brun foncé ou noires telles les taches de
naissance, les grains de beauté ou les verrues situés sur les surfaces que vous
désirez traiter. Utiliser l’appareil pourrait entraîner des blessures cutanées ou empirer
les conditions préexistantes. Vous pourriez éprouver des effets secondaires tels des
brûlures, des cloques, des cicatrices ou des changements de teint.
NE PAS utiliser l’appareil si vous souffrez de problèmes cutanés dans la surface
traitée tels le psoriasis, le vitiligo, l’eczéma, l’acné, l’herpès ou toute blessure ou
infection active.
NE PAS utiliser l’appareil si vous êtes âgé de moins de 18 ans. Cet appareil n’a pas
été éprouvé auprès de ces personnes.
NE PAS
utiliser l’appareil sur les cicatrices, les tatouages ou le maquillage permanent.
NE PAS utiliser l’appareil sur la barbe, dans le cas des hommes.
3.2 Avertissements
NE PAS UTILISER cet appareil si vous êtes sensible à la lumière du soleil (photo-
sensibilité) ou si vous prenez des médicaments qui causent la photosensibilité (p. ex.,
certains antibiotiques comme la tétracycline, des AINS comme de l’ibuprofène ou
des rétinoïdes comme Accutane ou des rétinoïdes topiques comme Retin A).
Toujours vérifier si les directives de vos produits médicaux mentionnent la photo-
sensibilité parmi les effets secondaires. Le fait d’utiliser un appareil SilkExpert sur
une peau photosensible peut endommager cette dernière et causer des cloques
ou de l’enflure.
90059367_ECLIPSE_PL3_NA.indd 1990059367_ECLIPSE_PL3_NA.indd 19 07.06.21 12:2107.06.21 12:21

20
NE PAS UTILISER sur une même zone plus d’une fois par semaine. La peau
pourrait être endommagée en cas de traitement prolongé et répété sur un côté.
Il est déconseillé d’utiliser cet appareil sur des zones où des comblements
dermiques sont injectés.
Pour les femmes traitant leur visage avec le Silk·expert Pro :
NE PAS utiliser l’appareil si vous avez subi un traitement d’exfoliation sur la surface
du visage que vous désirez traiter. Vous devriez attendre 30 jours après l’exfoliation
avant d’entamer le traitement.
NE PAS utiliser l’appareil si vous avez subi une restructuration au laser sur la surface
du visage que vous désirez traiter. Vous devriez attendre 6 mois après une
restructuration au laser avant d’entamer le traitement.
SÉCURITÉ DES YEUX
L’appareil émet des clignotements de lumière intense pulsée. Une exposition
directe pourrait être nocive pour vos yeux. Veuillez suivre attentivement les
précautions de sécurité ci-dessous.
Des lésions oculaires (pouvant potentiellement entraîner une perte de la vue) ou
cutanées pourraient survenir si les directives ne sont pas suivies. Protéger les yeux
de l’exposition. Ne pas appliquer l’appareil sur les paupières ou près des yeux.
L’appareil ne peut être activé (clignotement) que si les 2 détecteurs de teint
détectent un teint de peau valide. Cependant :
NE PAS regarder directement à l’intérieur de la fente d’émission (1) lorsque
l’appareil est alimenté et en marche.
NE PAS essayer d’activer (clignotement) l’appareil lorsqu’il est orienté vers votre œil.
NE PAS traiter la surface autour des yeux (incluant les cils et les sourcils).
Essayez d’activer (clignotement) l’appareil UNIQUEMENT lorsque la fente
d‘émission est en contact direct avec la surface que vous désirez traiter.
NOUS VOUS RECOMMANDONS de détourner le regard au moment d’appuyer
sur le bouton de traitement.
SÉCURITÉ ÉLECTRIQUE ET INCENDIE
Comme avec tout appareil électrique, certaines précautions doivent être prises
pour assurer votre sécurité.
NE PAS essayer d’ouvrir l’appareil. Vous pourriez vous exposer à des pièces
électriques dangereuses.
NE PAS utiliser l’appareil s’il est endommagé; par exemple, si le boîtier est fissuré,
si le câble est endommagé (vous apercevez les fils à l’intérieur), si le filtre de verre
est cassé, etc. Cela pourrait entraîner des blessures.
NE PAS utiliser l’appareil près de baignoires, de douches, de lavabos ou d’autres
contenants remplis d’eau. Si l’appareil est mouillé, il ne devrait pas être utilisé.
90059367_ECLIPSE_PL3_NA.indd 2090059367_ECLIPSE_PL3_NA.indd 20 07.06.21 12:2107.06.21 12:21
