BRAVILOR BONAMAT HW10 User manual

Operating instructions GB
HOT WATER BOILER

2
1
3
4
5

1
Operating instructions (English)
To operate this appliance properly and safely1 read the following instructions carefully.
1.1 Introduction
This appliance, model HW 10, is a simple
water boiler. The cold water is poured
into the kettle by hand.
When you push the on/off switch the
water will heat. The signal-lamp in the
switch will light up.
Figure 1 shows the main components
and controls.
FIGURE 1:
1. Water supply inlet with funnel
2. On/off switch
3. Tap
4. Temperature setting
5. Electrical connection
Figure 2 shows the appliance's
dimensions.
THE APPLIANCE IS SUPPLIED WITH THE
FOLLOWING ACCESSORIES:
−Drip-tray
−Water boiler lid
−Screwdriver
−1 sachet RENEGITE (descaler)
TECHNICAL DATA
Model........................................ : HW 10-001
Water reservoir capacity ........... : 4.5 litre
Capacity.................................... : 21 l/h
Discharge capacity.................... : 2 I/h
Cord length ............................... : ca. 150 cm
Supply voltage .......................... : 230 V~
Rating ....................................... : 2080 W
Protection.................................. : 15 A

2
1.2 Warning!
For safe operation of the water boiler, pay
close attention to the following points:
1. When the appliance Is In operation,
some components will get very hot.
2. If the appliance is unused for a long
period of time, it is advisable to dis-
connect the electrical supply.
3. Under normal circumstances, a small
quantity of water always remains in
the appliance: please keep this in
mind if it is to be exposed to
temperatures below 0 °C.
4. Stay with the appliance during main-
tenance operations (such as desca-
ling).
5. When working with strong cleaning or
descaling agents, it is most advisable
to wear safety goggles (face
protector) and gloves.
6. After working with strong cleaning or
descaling agents, be sure to wash
your hands.
7. Never immerse the appliance in
water.
8. Make sure that all repairs are carried
out by qualified technicians.
9. When the appliance has to be
opened for repairs or maintenance,
be sure to disconnect the electricity.
10. The appliance must always be
connected to the mains in such a way
that it can be easily disconnected.
11. The appliance must be earthed.
12. Be sure to observe local regulations
and standards when installing the
appliance.
13. Prevent spillage of the descaler solu-
tion on to the outside of the machine,
this can cause permanent damage to
the exterior surface of the machine
housing. In the event of a spillage,
wipe area affected dry, whilst
observing the safety regulations as
given in the Users Instructions.
1.3 Installation and initial operating procedure
INSTALLATION
When installing the appliance, keep the
instructions given above (points 10
through 12) in mind. Position the
appliance on a solid level base where it
can be easily connected to the electrical
mains.
(230V 1 phase with plug connection)
Fig. 3
Please take note of the following in
regard to figure 3:
−If equipped with a fuse plug, the appli-
ance must be protected with a 13 A
fuse. If another plug is installed, the
appliance must be protected with a
15 A fuse.
−If the plug supplied with the appliance
does not fit into your socket, it should
be cut off and replaced with a new
plug. The old plug should then be dis-
posed of, as it can be dangerous if in-
serted into a socket.

3
Keep the following instructions in mind
when installing a new plug:
−The yellow-green core (earth) must be
connected to the terminal marked with
the letter E or the earth symbol ( ) or
coloured green or yellow-green.
−The blue core (neutral) must be con-
nected to the terminal marked with the
letter N or coloured black.
The remaining brown core (live) must be
connected to the terminal marked with
the letter L or coloured red.
IMPORTANT !
The triple-core supply cord in fig. 3 is
colour-coded as follows:
Green and yellow - earth
Blue - neutral
Brown - live
INITIAL OPERATING PROCEDURE
The following procedure is to be carried
out when operating a new appliance for
the first time:
1. Remove the funnel.
2. Clean the inside of the kettle as
thoroughly as possible either with a
damp cloth or by rinsing with hot
water.
3. Replace the funnel.
4. Pour ca. 4.5 litres water into the
funnel.
5. When the water is hot, draw off as
much of it as possible via the tap and
dispose of it.
6. Then refill the funnel with cold water
to ca. 3 cm under the brim.
The appliance is now ready for normal
use.
ADJUSTMENT
The temperature of the water in the
reservoir can be adjusted. The
temperature can be set on the right side
of the machine (fig. 4) by means of the
screwdriver supplied.
−Turn the screwdriver tot the right to
increase the temperature.
−Turn the screwdriver tot the left to
decrease the temperature.
WARNINGS FOR THE ADJUSTING!
When adjusting our machines the
following rules must be observed:
1. When adjusting the water
temperature ensure that the water
within the machine does not reach
boiling.
2. The supplier is not liable for any
negative effect caused by a changed
adjustment of the machine.
1.4 Operation
Set switch 3 (fig. 1) in the on position, the
switch light will go on. The element will
now heat the water to ca. 95 °C. via the
tap and the water can be drawn off via
the tap.
When no more hot water can then be
drawn off via the tap, the kettle should be
topped up again to ca. 3 cm under the
brim of the funnel.
Fig. 4

4
1.5 Maintenance
WARNING!
Always stay with the appliance during
maintenance tasks (such as descaling or
cleaning) and keep the instructions given
in the Introduction (points 4 through 9 and
13) in mind.
CLEANING
The water boiler can be cleaned with a
damp cloth. The drip tray, etc., can be
washed in the usual way.
DESCALING
Under normal operating circumstances,
calcium deposits will appear in the appli-
ance. The appliance must be regularly
descaled in order to function properly, at
least once every 6 months. We advise for
this purpose RENEGITE, a descaling
agent which we have tested ourselves.
The following instructions are based on
the use of 100 gr. of RENEGITE (read
the instructions on the packet as well.)
The descaling procedure is as follows:
1. If the appliance is on it must be
switched off and as much hot water
as possible drawn off via the tap.
Cool the appliance by refilling it with
cold water.
2. Remove the plug from the socket.
3. When the appliance has cooled
down, remove the funnel from the
kettle.
4. Empty the kettle of water by tilting the
appliance.
5. Dissolve 100 gr. descaler in ca. 2
litres lukewarm water.
6. Pour the solution carefully into the hot
water kettle. (Do not replace the
funnel)
7. Now replace the plug in the socket,
switch on the appliance and wait ca.
10 minutes.
8. Then replace the funnel in the kettle
and fill up to ca. 3 cm from the brim.
9. Draw off a cup of descaler solution
three or four times a minute via the
hot water tap and pour it into the
funnel again. (Thus giving this a
good descaling too.)
10. Then switch the appliance off again
and remove the plug from the socket.
11. Now draw off as much solution as
possible via the tap and cool the
kettle by refilling it with cold water.
12. Draw off as much solution as
possible via the tap.
13. Remove the funnel again and pour
the remaining descaler solution out of
the kettle. CAUTION Wear good
protective gloves.
14. Now pour ca. 5 litres water into the
reservoir (do not allow it to overflow).
15. Draw off as much water as possible
via the normal hot water tap and
dispose of it.
16. Pour the rest of the water out of the
kettle.
17. Repeat operations 14, 15 and 16 at
least twice.
18. Rinse the funnel well a few times with
hot water before replacing it in the
kettle.
19. Now fill the appliance again with cold
water up to ca. 3 cm from the funnel
brim. The appliance is now ready for
normal use.
(SUBJECT TO MODIFICATION)

205
61E
31
140
432
49
224
134
358
E

COFFEE BREWING MACHINES
© 02-1999
700.403.117 E
