BRCK BRCK User manual
QUICK START GUIDE
®
SETUP YOUR BRCK IN 6SIMPLE STEPS
accessories
AUX
USB ETHERNET
SIM
POWER
USB
CELL
SMA
CELL
SMA
PORT
POWER
USB
PORT
AUX
USB
POWER
BUTTON
GPIO CONNECTION
( General Purpose Input/Output )
STATUS LIGHT
ETHERNET
PORT
BOTTOM
CELL
SMA
appendix
Status light colour codes
Battery Status
THE BRCK
Warranty : 6 month warranty against defects in materials and workmanship.
For more information see http://www.brck.com/warranty
°BRCK <NAME >: The default name of your BRCK, where <NAME >is a randomly generated code for setup
°Browser : A software application for presenting resources on the World Wide Web.
The major web browsers are Google Chrome, Mozilla Firefox, Internet Explorer, Opera, Safari & Lynx
°Status Light : The top guide light on your BRCK (fig A - 1)
°AUX USB : USB slot to connect external devices eg: phone, tablets etc - 500mA Max (fig A - 3)
°Ethernet Port : Ethernet slot used to connect an Ethernet cable (RJ45 cable) to another router (fig A - 4)
°SIM Slot : SIM card slot used to Insert a standard data enabled SIM card (fig A - 5)
(for nano & micro SIMs, you will require a SIM adapter)
°Power Micro-USB Port : Micro-USB slot used to charge the BRCK using the provided USB cable (fig A - 5)
°Cell RP-SMA : Antenna expansion port (attach antenna for better cellular coverage) (fig A - 6)
°GPIO connection : The bottom port used to connect external devices (fig A - 7)
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference
2. This device must accept any interference received, including interference that may cause undesired operation.
28
A
1
MICRO USB CABLE
B
4 5
FULLSIZE
SIM CARD
SLOT
673
BRCK.com © All rights reserved
Inner box
Signal Status
Outer box
Blue - 3G / 2G / EDGE
Green - WiFi
Purple - Ethernet
White - BRCK-Net
Yellow - Booting Up
SPINNING - Seeking Connection
Fully Charged (95-100%) - Blue
Ok Power (41-94%) - Green
Low Power (11-40%) - Yellow
Very Low Power(0-10%) - Red
CHARGING - PULSING
Plug in your Brck to power go to http://my.brck.com on a
browser ( Chrome, Firefox, Safari, Internet Explorer )
Connect the USB power cable to
your BRCK’s MICRO-USB port and the other
end to a power plug or USB device
Connect your devices with your BRCK’s WiFi signal
(maximum 20)
Setup to a new account or login to an already
existing profile
Yay! You are connected
Having trouble connecting?
Visit : https://my.brck.com/help
You can also visit http://forums.brck.com/
to meet other BRCK users
Note : The power button is the disconnecting device, and will disconnect all networks from the BRCK
Setting up your first BRCK should take you about 10 minutes to get started, following these 6steps below
14
Signup or login
6
5
Ethernet WiFi SIM BRCK Net
http://my.brck.com
INTERNET
http://my.brck.com
AUX
USB ETHERNET
SIM
POWER
USB
CELL
SMA
SIGN UP
.........
Connect to WiFi signal
On your computer, smartphone or tablet search for
the BRCK WiFi signal and connect to it.
3BRCK
name
Turn on your BRCK
On the side of the BRCK press the
power button to turn on your BRCK
TOP STATUS LIGHT
2
NOTE : PULSING of the inner box means your BRCK is connected to power.
Now, press the power button to turn it ON
NOTE : After switching on your BRCK, it will take
about 1Minute for the WiFi signal to be available
Not connected? Do one of the following:
• Plug in an ethernet cable
• Look for another WiFi signal
• Insert a SIM card
NOTE : Your WiFi Network is not secure.
Once you get onto your dashboard rename your
WiFi Network and Password.
If this in your first BRCK, Setup and new account.
If you have an account already, then login to your
excisting profile.
Once that is done, ensure you are
connected to your BRCK WiFi, then enter
the URL http://192.168.69.1
