Breeze DVS Series User manual

We bring better air to life
2020
USER’S MANUAL
SILENT INLINE FAN
Thank you for choosing silent inline fan. Please read and save this
user's manual for future reference. Read carefully before
attempting to assemble, install, operate or maintain the product
described. Protect yourself and others by observing all safety
information. Failure to comply with instructions could result in
personal injury and property damage.
DVS 180
DVS 300 | DVS 500
DVS 780 | DVS 960
DVS 1200 | DVS 1900 | DVS 3000
DVS Series

www.breeze.com.vn | [email protected] 01
We bring better air to life
USER’S MANUAL
DVS SERIES
1. GENERAL SAFETY INFORMATION
Ÿ Please read the user’s manual carefully prior to installing and operating the unit.
Ÿ This user’s manual is the primary operating document intended for technical, maintenance and operations staff.
Ÿ All user’s manual requirements as well as the provisions of all the applicable local and national construction, electrical and
technical norms and standards must be observed when installing and operating the unit.
Ÿ The warnings contained in the user’s manual must be considered most seriously since they contain vital personal safety
information.
Ÿ Failure to follow the rules and safety precautions noted in this user’s manual may result in an injury or unit damage.
After a careful reading of the manual, keep it for the entire service life of the unit.
Ÿ While transferring the unit control, the user’s manual must be turned over to the receiving operator.
Disconnect the unit from power mains prior to any
installation operations.
While installing the unit, follow the safety
regulations specific to the use of electric tools.
Do not lay the power cable of the unit in close
proximity to heating equipment.
Do not change the power cable length at your
own discretion. Do not bend the power cable.
Avoid damaging the power cable. Do not put any
foreign objects on the power cable.
Do not use damaged equipment or cables when
connecting the unit to power mains.
Do not operate the unit outside the temperature
range stated in the user’s manual. Do not operate
the unit in aggressive or explosive environments.
Do not touch the unit controls with wet hands. Do
not carry out the installation and maintenance
operations with wet hands.
Do not wash the unit with water. Protect the electric
parts of the unit against ingress of water.
Disconnect the unit from power mains prior to any
technical maintenance.
Do not store any explosive or highly flammable
substances in close proximity to the unit.
When the unit generates unusual sounds, odour
or emits smoke, disconnect it from power supply
and contact the Seller.
Do not direct the air flow produced by the unit
towards open flame or ignition sources.
Do not block the air duct when the unit is
switched on.
In case of continuous operation of the unit,
periodically check the security of mounting.
The product must be disposed separately at the end of its service life. Do not dispose the unit
as unsorted municipal waste.
Do not allow children to operate the unit.
The unit must be grounded!
Do not open the unit during operation.
Unpack the unit with care.
Multiple bend
Pipe diameter shrinks
at connecting part
< 0.8m
Adapter
Duct
Outlet closed to crook
UNIT INSTALLATION AND OPERATION SAFETY PRECAUTIONS
ŸBefore installing this product, ensure that the
voltage and frequency consistent with the
product nameplate.
ŸWhen connected to power supply, all-pole
power switch with more than 3mm contact
separation is necessary to be installed on the
power supply circuit. Please do the connection
according to the local electrical equipment
technical regulations.
ŸPlease set up vent and spot inspection.
ŸInstallation height should be more than 2.3m.
ŸShould be firmly installed. Gradient installation
forbidden.
ŸDo not disassemble the junction box by
yourself, if the power cord is damaged, it
should repair by qualified serviceman
ŸInstallation on window or outdoor is forbidden.
ŸPlaces with overmuch lampblack or steam
forbidden.
ŸBelow connection way of air duct is forbidden.

Silent inline fan with standard motor are suitable for ventilation of:
• Clean air
• Slightly dusty and greasy air
• Slightly aggressive gases and vapour
• Mediums up to an atmospheric density of 1.2 kg/m3
• Mediums with a temperature of -20°C up to +40°C
• Mediums up to a max. Humidity of 85%
• The ambient temperature of the motor must be between -20°C and +40°C make sure and adhere to the specifications of the
motor manufacturer.
2. PRODUCTS OVEVIEW
02
DVS series use a silent inline fan with high quality material and exceptionally super low noise design. The idea solution for medium
demand ventilation in commercial and residential systems.
Material:
Ÿ Casing: Stainless plate steel
Ÿ Impeller: Stainless steel with high energy efficiency of forward curve centrifugal impeller in favor of drastically reducing noise.
Ÿ Motor: 100% copper coil and fitted with high quality ball bearing, high efficiency, low noise, maintenance free and long service life.
Equipped with thermal overload protection.
Ÿ Standard motor range is protected to IP 44, class B insulation.
Application:
Ÿ Bathroom, bedroom, office, living room, store, toilets, hotels.
Ÿ Super low noise requirements and supply or exhaust ventilation.
1. Fan Box
2. Fan Casing
3. Double Inlet Impeller
4. Motor Support
5. Motor Frame
6. Inlet/Outlet Flange
7. Terminal Electric Box
8. Plate of Terminal Box
9. Bracket Hanger
10. Service Plate
3. PERFORMANCE CURVE
200
100
300
400
400 800 1200 1600 2000 2400
DVS 1900
Pa
3
m /h
500
200
100
300
400
500 1000 1500 2000 2500 3000
DVS 3000
Pa
3
m /h
500
200
100
300
400
200 400 600 800 1000 1200
DVS 1200
Pa
3
m /h
500
75
50
100
125
40 80 120 160 200 240
DVS 180
Pa
3
m /h
100
50
150
200
60 120 180 240 300 360
DVS 300
Pa
3
m /h
100
50
150
200
100 200 300 400 500 600
DVS 500
Pa
3
m /h
100
50
150
200
150 300 450 600 750 900
DVS 780
Pa
3
m /h
250
100
50
150
200
200 400 600 800 1000 1200
DVS 960
Pa
3
m /h
250
Construction.
The silent inline fan consists of the following main parts:
www.breeze.com.vn | [email protected]
We bring better air to life
USER’S MANUAL
DVS SERIES

03
5. DIMENSION INFORMATION
Wiring Diagram
A
B
C
D
E
Airflow
Motor
Black
Blue
Brown
Capacity
Yellow
Green
Terminals
Yellow Green
Brown
Blue
N
L
FU
Fan
L1
2
3
4
N
L
N
MCB
PE
AC ~
220-240V
50 Hz
Model
DVS 180
DVS 300
DVS 500
DVS 780
DVS 960
DVS 1200
DVS 1900
DVS 3000
A
184
206
206
270
270
330
330
330
B
286
288
288
390
390
470
470
470
C
395
407
407
548
548
650
650
650
D
288
299
299
420
420
490
490
490
E
100
150
150
200
200
250
250
250
Weight
(Kg)
4.4
4.5
4.5
11
11
18
35
38
All dimensions in mm.
PE
4. PERFORMANCE PARAMETERS
220/1/50
220/1/50
Voltage
(V/P/Hz)
0.11
1.9
Current
(A)
25
420
Power
(W)
1180
1280
Speed
(rpm/min)
110
400
Max.
Pressure
(Pa)
21
49
Noise
(at 3m)
DVS 180
DVS 3000
Model
Max.
Air Volume
3
(m /h)
180
220/1/500.2347 1140115 25
DVS 300 300
220/1/500.4598 1360190 28
DVS 500 500
220/1/500.72155 1180230 35
DVS 780 780
220/1/500.75163 1280245 37
DVS 960 960
220/1/50
0.84
185 820230 40
DVS 1200 1200
220/1/501.75385 1060380 46
DVS 1900 1900
3000
Electric Connection
6. ELECTRIC INSTALLATION
www.breeze.com.vn | [email protected]
We bring better air to life
USER’S MANUAL
DVS SERIES
• The fan is designed for 220-240V/50Hz (single-phase).
• The fan shall be connected to power supply by means of insulated, durable
and thermal-resistant cords (cables, wires).
• Electric wiring must be in accordance with technical connection regulations
and local ordinances and national electric codes as per enclosed wiring
diagram in the terminal box or on the casing.
• The recommended wire cross section is minimum 0.75 mm2.
• The actual conductor cross-section selection must be based on its type,
maximum permissible heating, insulation, length and installation method (in
the air, pipes or inside walls). Connect the cables to the terminal block
incorporated inside the terminal box located on the fan casing in compliance
with the fan wiring diagram and the terminal designation. The terminal
designations are shown on the sticker inside the fan casing.
• Check that supply is according to data on nameplate.
• Insert cable according to the instructions in the junction box and seal it
(Avoid water enter).The equipment connected ground for motor protection
according to the instructions - Unless the guarantee isn’t accepted. Connect
electric supply.
• After connecting the wiring, install the terminal cover with screws.

04
7. INSTALLATION METHOD
Install the boom, flat washers,
nuts (customer need purchase
by yourself, you must use the
M8-M10 specifications).
If you need prevent vibration,
please use the shockproof rubber
(customer need purchase by
yourself), its strength must be
able to carry this product’s weight.
The product of hanging ceiling
structure and suspension
components must be able to
carry more than five times
intensity.
Airflow
Airflow
Airflow
Airflow
Install firmly bolts and nuts when
it hanging down.
Install the bolt
Nut
Flat washer
Size A bolt is 2-3
helicoidal than the Nut
Casing to be installed
horizontally Leading to the outdoor air duct
must remain slight slope.
Put the bags or canvas connect together
Airlow
Before starting the unit, check the following:
• Confirm that building supply voltage matches the voltage for which the unit is wired.
• Check all piping and wiring penetrations
• Made by contractors for water tightness. All penetrations must be made watertight to prevent water damage to the unit and
building.
• Rotate the fan impeller manually to be sure that it is free to operate. Remove any dirt or debris that may have accumulated
during installation.
• Inspect all fasteners to ensure that none have loosened during shipment.
• Check all electrical connections for proper attachment.
• Check casing and ductwork, if accessible, for obstructions and foreign material that may damage the fan impeller.
Check
• The equipment type and arrangement should be verified as ordered at once when it arrives at the jobsite. When a discrepancy
is found, the local Breeze Sales Representative must be notified immediately so that corrective action may be investigated, also
verify electrical conformance to specifications. Unauthorized alterations and unauthorized backcharges will not be recognized by
Breeze Fan.
• After the unit has been assembled, installed and all utilities have been hooked up, the unit is now ready for operation.
8. OPERATION INSTRUCTION
Visual Inspection of Equipment
• The fan is designed direct connection to air duct.
•Take care of direction of air flow shown by arrow stickers.
• Check impeller rotation by hand for soft running. for external mounting weather
protection should be used. This should be designed to suit the installation and is
supplied by others.
•Apply the markings for mounting of the fixing brackets onto the mounting surface.
•Drill the holes and fasten the fan on the brackets by using appropriate fasteners.
• Install the fan with bolts and nut to the building construction (refer to the right
picture).
www.breeze.com.vn | [email protected]
We bring better air to life
USER’S MANUAL
DVS SERIES

9. ROUTINE MAINTENANCE
• Regular maintenance is needed each year. The impeller blades require thorough cleaning once in 6 months.
• Before any maintenance work is undertaken:
o Stop fan in accordance to regulations and disconnect all poles from mains supply.
o Wait until impeller is stationary.
o Make sure that a restart is not possible
• Use only original spare parts tested and approved by the manufacturer.
• The following safety notes must be observed when maintaining the machine.
• Replace the ball bearings of the motor whenever the grease utilization period has elapsed in accordance with the maintenance
instructions of the manufacturer.
• The technical maintenance includes periodic cleaning of the surfaces from accumulated dust and dirt.
• Use a soft dry brush or a vacuum cleaner to remove dust.
• Only use usual commercial cleaning material paying attention to the prescribed safety measures and do not use any abrasive
tools (surface protection will be destroyed)..
• Check that the mechanical assembly has been carried out properly
• Remove foreign bodies located in the suction and outflow areas and in the fan space
• Check that the electrical installation has been completed in accordance with regulations
• Does the mains voltage match the motor voltage specified on the rating plate?
• Is the motor protection system set correctly with regard to the motor's nominal current? The setting must be carried out in
accordance with the corresponding details contained on the motor output plate.
• Has the motor been connected correctly in accordance with the wiring diagram? The connection schematic supplied by the
motor suppliers applies for the connection of the motor.
Checks after initial start-up
Check the mechanical connections after initial start-up, especially the joints at the fan.
Checks prior to initial start-up
Proceed with the fan's initial start-up in the following sequence:
Starting up the fan for the first time.
Only put the fan into operation after it has been assembled in accordance with the regulations:
• Put the fan into operation.
• Monitor its correct function (quiet running, vibration, imbalance, power consumption, controllability)
Once the unit has been put into operation, a routine maintenance schedule should be set up to accomplish the following:
• Lubrication of bearings and motor.
• Impeller, casing, bolts and set screws on the entire fan should be checked for tightness.
• Any dirt accumulation on the impeller or in the casing should be removed to prevent unbalance and possible damage.
• Inspect fan impeller and casing looking for fatigue, corrosion or wear.
General Check:
• Too much bearing play?
• Lubricant leaking from the bearings?
• Surface protective coating damaged?
• Attention: Conveyed medium too aggressive?
• Unusual noises during operation?
• Fan output still sufficient for possibly extended or shortened ducting system?
Prior to all servicing work:
• Bring the fan to a halt in the prescribed manner and completely isolate the fan from the mains supply.
• Wait until the rotor has come to a halt.
• Ensure that the machine cannot be switched on again
• Clean the fan
• Clean the suction apertures
• Clean the rotor (if necessary dismantle the protective anti-intrusion fitting)
• Do not overload the motor
• Do not bend the rotor or vanes
• Assemble the protective anti-intrusion fitting.
• Control whether installation is correct:
o Impeller must rotate free
o Annular gap between impeller and casing must be regular.
o Checking direction of rotation is correct.
05
www.breeze.com.vn | [email protected]
We bring better air to life
USER’S MANUAL
DVS SERIES

Clean fan:
• Unscrews terminal plate and service plate of fan box
• Clean casing, inlet and outlet flanges.
• Clean impeller.
o Do not flood motor.
o Do not bend impeller, blades.
• Assembly fan.
•Control whether installation is correct:
o Motor impeller must rotate free
o The gap between impeller and casing must be regular.
o Checking direction of rotation is correct.
•Install the fan into air duct.
•Push into operation after clean.
•Connect electric supply of motor.
06
10. TROUBLESHOOTING TABLE
PROBLEM POSSIBLE REASONS TROUBLESHOOTING
ŸWhen switching on the
unit the fan does not
start.
ŸCircuit breaker
tripping during the fan
start.
ŸLow air flow.
ŸThe automatic circuit breaker is
triggered by an abnormally high current
consumption due to a short circuit.
ŸClogging of air ducts or other ventilation
system elements. Impeller clogging.
Damaged air ducts. Air damper closure.
ŸDisconnect the fan from power mains and
contact the Breeze Seller.
ŸDo not turn on the fan again.
ŸClean the air ducts and other ventilation system
elements as well as the impeller.
ŸCheck the air ducts for damage.
ŸMake sure the air dampers and louver shutters
are open.
ŸPoor foundation ŸExcessive noise
ŸExcessive vibration
ŸReinforce the foundation
ŸFault installation ŸExcessive noise
Excessive vibration
ŸRe-adjust the installation
ŸLow voltage ŸInsufficient air flow ŸCheck power source
ŸContact between rotary
and stationary parts
ŸMotor too hot
ŸExcessive noise
ŸExcessive vibration
ŸInspect and adjust
ŸSucked in objects /
Adhere dust
ŸMotor too hot
ŸExcessive noise
ŸExcessive vibration
ŸInspect and clean
ŸFaulty ducting ŸExcessive noise
ŸExcessive vibration
ŸInsufficient air flow
ŸInspect and adjust
ŸIncorrect wiring ŸRun abnormally ŸChange wiring
ŸNo power supply.
ŸMotor jamming.
ŸCheck the electrical connections and the power
switch status.
ŸTurn off the fan.
ŸTroubleshoot the impeller jamming.
ŸRestart the fan.
www.breeze.com.vn | [email protected]
We bring better air to life
USER’S MANUAL
DVS SERIES
Fig 1 Fig 2
Fig 5
Fig 4
Fig 3

07
Transport
• Our products are packed at the factory to suit the respectively agreed mode of transportation. Transport the fan in its original
packaging.
• Fans are protected against damage during shipment. If the unit cannot be installed and operated immediately, precautions need
to be taken to prevent deterioration of the unit during storage. The user assumes responsibility of the fan and accessories while
in storage. The manufacturer will not be responsible for damage during storage. These suggestions are provided solely as a
convenience to the user.
• Only use suitable means of transport, such as pallet trucks or fork-lift trucks or hoist machine.
• If the fan is to be transported by hand, ensure that supporting and carrying loads are kept within reasonable limits for the
personnel involved.
• The fans must not be dropped or thrown. Avoid scratches or rough handling during loading and unloading.
• Parts which have been stacked too high can collapse.
• Avoid a distortion of casing or blades or other damage.
• Danger ! Do not step under hanging loads.
12. TRANSPORT AND STORAGE
Storage
• Store the unit in the manufacturer’s original packaging box in a dry closed ventilated premise with temperature range from +5˚С
up to +40˚С and relative humidity up to 85%.
•Store the fan in a dry, weather-protected location in its original packaging or protect it from the effects of dirt and the weather
until final assembly. Storage environment must not contain aggressive vapours and chemical mixtures provoking corrosion,
insulation and sealing deformation.
•Rotate fan impeller monthly and purge bearings once every three months.
•If storage of fan is in a humid, dusty or corrosive atmosphere, rotate the fan and purge the bearings once a month. Improper
storage which results in damage to the fan will void the warranty.
•Avoid lengthy storage periods (a maximum of one year is recommended) and check that the motor bearing assembly is in good
functional order prior to fitting. With storage times of more than 1 year, please check the bearings on soft running before
installation (turn by hand).
Change of motor impeller:
• Disconnect electrical supply in function box.
• Unscrew motor mounting and pull out of the casing complete with motor, impeller.
• Install a new motor impeller complete with motor mounting in casing.
• Assembly fan.
•Control whether installation is correct:
o Motor and impeller must rotate freely
direction of rotation is correct. o Control whether
o Install maintenance cover if have.
o The gap between impeller and casing must be regular.
•Install the fan into air duct.
•Push into operation after repaired.
•Connect electric supply of motor.
Thank you for your cooperations!
www.breeze.com.vn | [email protected]
We bring better air to life
USER’S MANUAL
DVS SERIES
11. REPAIR
Before any repairs are undertaken please:
• Stop fan in accordance to regulations and disconnect all poles from mains supply.
• Wait until impeller is stationary.
• Make sure that a restart is not possible.
• Only use original spare parts manufactured and supplied by Breeze Fan.

Applied standard:
BREEZE INDUSTRIAL VENTILATION JOINT STOCK COMPANY
Vietnam
Head Office:
215D8 Nguyen Van Huong Street, Thao Dien Ward,
District 2, Ho Chi Minh City, Vietnam.
Tel: [phone] | Hotline: [phone]
Factory:
12 Road No. 570, Xom Moi Hamlet, Trung Lap Ha
Commune, Cu Chi District, Ho Chi Minh City, Vietnam.
Tel: [phone]
Ha Noi Office:
55, Alley No. 14, Vu Huu Street, Thanh Xuan Bac Ward,
Thanh Xuan District, Ha Noi City, Vietnam.
Tel: [phone] | Hotline: [phone].
Website: www.breeze.com.vn
Email: [email protected]
Singapore
Office:
No 15, Yishun Industrial Street
1, #03-29, WIN5 Singapore
S768091.
Tel: [phone]
Myanmar
Office:
No.13/B, Kan Yeik Thar
Street, Thingangyun
Township, Yangon, Myanmar.
