Br ewer

Document # 100452 RevK 2 Printed in USA © 2012
Service
If you require assistance with the installation or operation
of your Brewer table, call the Brewer Customer Service
Department at (1-888-Brewer1). Our trained staff will
attempt to assist you in correcting the problem directly
over the phone. If service is required, a factory authorized
technician will be sent to your location.
Please ll in the following information for use when calling
the Brewer Company or your distributor with questions
regarding your unit. See Figure 1 for model and serial
number location.
Date of Purchase
Serial Number
Model Number
Authorized
Dealer Name
Dealer
Phone Number
Dealer Address
IMPORTANT INFORMATION
General
The Brewer Access High-Low Exam Table Model 6000
Series is designed to provide positioning and support of
patients during general examinations conducted by quali-
ed medical professionals. Read and understand all op-
erating instructions, safety information, and maintenance
requirements contained in this manual prior to operating
the table. Become familiar with all of the table functions
before using it with a patient.
The Brewer Access High-Low Exam Table is primarily
used in examination rooms for general examinations and
minor procedures. The wide variety of positions provided
by one or two powered motions, slideout leg support,
slideout leg extension, stirrups and treatment pan, create
a safe and convenient patient positioning table for most
examinations and procedures performed in the doctor’s
ofce.
The table is easily adjusted to a wide variety of positions
using the convenient foot control provided with the table.
The table height can be adjusted from 18” to 37”. The
table seating surface on models 6001 and 6501 can be
moved from the normal horizontal position to an angle of
5°. The backrest can be adjusted from a at lying down
position, to an 80° angle for seating.
In addition to the electronically controlled positions noted
above, several manual adjustments are available:
• The leg support can be extended 14” for the patient
prone position. If more length is needed, the leg ex-
tension can be pulled out to provide an additional 6”.
• Stirrups may be manually extended through innite
positions and four lateral positions.
• A removable treatment pan is built-in underneath the
leg extension for use during examinations.
• Grab bars attached to each side of the table may
be rotated out of position for improved access to the
patient.
• A pass through work surface, stored under the seat,
may be pulled out from either side of the table.
• Storage drawers at the front and side of the table may
be used for supplies. The pass through side drawers
may be pulled out from either side of the table.
• A storage cover at the rear of the table can be lifted to
store paper rolls.
The table is designed to accommodate a maximum
patient weight of 450 lbs.
Figure 1. Model and Serial Number Location
Model Number
Serial Number

Document # 100452 RevK 3 Printed in USA © 2012
Br ewer
Failure to follow instructions with this symbol
could result in serious personal injury and/or damage
to the unit.
DANGER indicates an imminently hazardous
situation which, if not avoided, will result in death or
serious injury.
WARNING indicates a potentially hazardous
situation which, if not avoided, could result in death
or serious injury.
CAUTION indicates an imminently or poten-
tial hazardous situation which, if not avoided, may
result in serious injury and/or equipment damage.
Safety Information
The primary concern of The Brewer Company is that the
equipment is operated and maintained with the safety of
the patient and healthcare staff in mind. To ensure safe
and reliable operation:
•Read and understand all instructions in this manual
before attempting to install or operate the unit.
•Ensure that appropriate personnel are informed on
the manual contents. This is the responsibility of the
purchaser.
•Ensure that this manual is located near the table, or if
possible permanently afxed to the table.
SAFETY INFORMATION
COMPONENT IDENTIFICATION
Figure 2. Component Overview
Paper Roll Holder
Safety On/Off Switch
(located on back of cabinet)
Pass Through
Drawers
Stirrups
Grab Bar
Drawer Warmer Switch
(Models 6001 & 6501 only)
Front Drawer
Paper Storage
Compartment Lid
- Slideout Leg Support
- Slideout Leg Extension
Treatment Pan
(located under Leg Support Pad)
Foot Controls
Pass Through
Work Surface
Model
6000/6001
Model
6500/6501
Back Release Handle
(Models 6000/6001)
STOP RETURN
TOCHAIR
Pelvic Tilt Bar

Document # 100452 RevK 4 Printed in USA © 2012
WARNING
When performing a cauterization or similar treat-
ment, the patient must be insulated from the metal
portions of the table by nonconductive material.
Failure to do so may result in electrical shock or
burns to the patient.
WARNING
Use 115 VAC, 60 Hz as noted on the rating label.
Failure to do so may result in electrical shock to
personnel and will result in damage to the table.
WARNING
Do not use this table in an explosive or oxygen-en-
riched atmosphere. Failure to do so may result in
serious personnel injury or death.
CAUTION
Do not use any power supply other than that
listed on the rating label (Figure 1). Failure to do
so may result in serious injury and/or equipment
damage.
SPECIFICATIONS
Duty Cycle (10%)
.................... 2 minutes on / 18 minutes off (motor run time)
Power Cord............... Extends 70 in. (Minimum) from table.
120V Models: 18 AWG / 3 conductor, SJT grey jacketed
junior hard service with hospital plug or detachable
power cord.
Type of protection
against electrical shock
Model 6000, 6500........................ Class 2 Double Insulated
Models 6001, 6501................................. Class 1 Grounded
Type of protection
against electrical shock ............................... B applied parts
Type of protection against ingress of water……. Ordinary
Can accept paper rolls of 18 in. x 3.0 in.
.................................................................. or 21 in. x 3.0 in.
Certications* .............................. UL60601-1; IEC60601-1;
..................................................CAN-CSA C22.2 No. 601.1
Operating Conditions:
Temperature Range...........................................65° to 85°F
Relative Humidity..............................................10% to 90%
Transportation and Storage
Temperature .................................................-20°F to 150°F
Humidity............................................................10% to 90%
* UL classied in the United States and Canada
per the following standards.
Weight of Table...................................................... 395 lbs.
Load Rating (maximum):
- Seat/Back............................................................ 450 lbs.
- Leg Support........................................................... 50 lbs.
- Leg Extension ....................................................... 50 lbs.
- Pass Through Work Surface ................................. 15 lbs.
- Grab Handle........................................................ 100 lbs.
Back Section Range.................0° (horizontal) to +80° ± 5°
Table Top Height Range .............18 ± 0.5 in. to 37 ± 1.0 in.
Pelvic Tilt Range
(Models 6001/6501 Only) .............0° (horizontal) to 5° (up)
Upholstery Dimensions:
Upholstered Top ........................ 28.0 in. wide x 58 in. long
Upholstered Leg Support……15.25 in. long x 18.5 in. wide
Upholstered Leg Extension…....6.0 in. long x 15.5 in. wide
Overall Length ................................................... 58 in. long
With Leg Support Extended............................... 72 in. long
With Leg Extension Extended ........................... 78 in. long
Electrical Requirement
6000/6500 - 115 VAC nominal, 60 HZ, 5.8 amps max.
6001/6501 - 115 VAC nominal, 60 HZ, 6.3 amps max.
6001/6501 W/Outlet- 115 VAC nominal, 60 HZ, 9.3 amps
max.
Fuse Rating:
Control Box Fuse Rating, 120V Models .......... 250V/2.5AL
Option/Heater Fuse Rating................................ 250V/1.0A
Option/Heater & Outlet Fuse Rating.................. 250V/3.0A
ELECTRICAL REQUIREMENTS
CAUTION
This product has been evaluated with respect to
electrical shock, re, and mechanical hazards only
in accordance with UL60601-1; IEC60601-1;
CAN/CSA C22.2 No. 601.1
Electromagnetic Interference
This product is designed and built to minimize electromag-
netic interference with other devices; however, if interfer-
ence is noticed between another device and this product,
remove the interfering device from the room or plug this
product into an isolated circuit.

Document # 100452 RevK 5 Printed in USA © 2012
Overview
Perform the following sequence in order when setting up
the table:
- Uncrating
- Leveling the Base
- Installing Grab Bars
Uncrating
NOTE: Inspect all boxes and contents for damage. Re-
port any damage to the carrier immediately.
CAUTION
To avoid damaging the table’s upholstery or paint-
ed surfaces, DO NOT use a knife or other sharp
object to open the packaging. Also, to avoid dam-
aging the table lift only at points indicated in Figure
3. Do not lift at other points as indicated by the
note in Figure 4.
CAUTION
Do not plug power into table prior to removal of all
packaging materials.
1. Remove stretch wrap surrounding table.
2. Cut and remove banding and protective foam tube
attaching table to pallet.
3. Remove the 6 steel brackets securing the table to the
pallet, one at each of the four corners and one at the
middle on each side of the table. The brackets engage with
the table levelers to hold the table securely to the pallet.
Remove the 2 bolts from each bracket using a 7/16” socket
or wrench. Take care not to scratch the unit when turning
the wrench.
4. Remove the 2 screws attaching the spacers on either side
of the wooden U-shaped brace located under the front
corners of the cabinet. Remove the 2 screws attaching the
U-shaped brace tho the pallet.
5. Remove the foot control from the rear drawer. Insert the
foot control cord into the receptacle at the bottom of the
rear panel. Secure with locking ring.
6. Remove the gray power cord from the rear drawer. Plug the
power cord into the socket at the bottom of the rear panel.
Plug the power cord into a 120 Volt grounded receptacle.
7. Make sure the black On/Off Switch at the back of the table
is on.
8. Depress the switch on the foot control for lifting the seat
section until all the weight is removed from the wooden
U-shaped brace. Remove the brace and spacers.
9. Unplug the power cord from the table and the receptacle.
Remove the foot control from the table table. Slide the
table forward off the pallet.
• Caution: Do not lift table by stirrups. Lift front of table by leg
support. Pull leg support (not leg extension) out approximately
6”. Lift rear of table by pushing top rear pass-through drawer
to one side and using opening as a hand hold.
INSTALLATION
Figure 3. Table Lift Points
Lift table at these points only
Slide drawer and
lift here
Pull Leg Support out
slightly and lift here. Do not
lift by the Leg Extension.
See Figure 4.
WARNING
The table weighs approximately 395 lbs. Two or
more people should assist in removing the table
from the shipping skid. Also, use proper lifting
techniques when lifting. Failure to do so could
result in serious injury.
CAUTION
Do not use the stirrups to lift or move the table.
The Leg Support may be used to lift the table. Do
not pull on the Leg Support to slide the table.
8. The electrical rating for this unit is 115 VAC, 60 Hz,
5.8 amp maximum. The three-pronged grounding
plug on the table power cord must be plugged into
a matching three-pronged, grounded, non-isolated,
correctly polarized 115 VAC receptacle.
Figure 4. Stirrups & Treatment Pan
NOTE: DO NOT
LIFT HERE
Leg
Support
Do Not Use
Leg Extension
to Lift

Document # 100452 RevK 6 Printed in USA © 2012
Note :
Some models may
not have a detachable
power cord.
Figure 7. Power Cord and Foot Control
Foot Control Power Cord
Leveling the Table
A leveling screw pad (Figure 6) is located in six places
under the table’s base and rear cabinet. Adjust the six
leveling pads to achieve a solid, level installation.
Installing the Power Cord
(Models 6001, 6500 & 6501)
1. Remove the power cord from the shipping bag.
2. Insert the female plug end of the power cord into the
receptacle on the table (Figure 7). Make sure the tabs
are aligned and the plug is fully seated.
Note: The power cord is installed at the factory on model
6000.
Installing the Foot Control
1. Insert the male plug of the foot control cord into the
receptacle on the table (Figure 7). Make sure the pins
are properly orientated and the plug is fully seated.
2. Turn the locking ring clockwise to secure the plug to
the table.
Figure 6. Leveling Screw Pad (located under table)
INSTALLATION (continued)
Installing Grab Bars
1. Remove from drawer.
2. Grab bars t on either side.
3. Align pin on grab bar shaft with mating slot on side of
table. See Figure 5.
4. Push grab bar all the way down and rotate to front of
table.
5. Push grab bar down until it engages to prevent left or
right movement.
Grab Bar
Mounting Support
Figure 5.

Document # 100452 RevK 7 Printed in USA © 2012
WARNING
Keep personnel and equipment clear of table be-
fore initiating movement to avoid personal injury
or damage to the equipment.
Model Power Back PneuMatic Manual Back Pelvic tilt drawer warMer return tochair
6000 x
6001 x x x
6500 x x
6501 x x x x
NOTE: The control system is protected by a fuse to
prevent excessive current draw which could damage
the system. If operation does not resume after a cooling
period of one hour, contact your dealer or an authorized
service center for repair.
General
DANGER
Do not use this table in an explosive or oxygen-
rich atmosphere. To do so will result in an explo-
sion or re.
WARNING
If the table malfunctions, immediately remove your
foot from the controls, unplug the power cord from
the electrical receptacle, and assist the patient
from the table. If table continues to malfunction,
call for service. Do not attempt to repair table your-
self.
WARNING
Before initiating power, keep personnel and equip-
ment clear of the table movement to avoid person-
al injury or equipment damage.
OPERATION
CAUTION
The foot control is moisture resistant and runs on
low voltage, eliminating shock hazards. However,
to avoid temporary or permanent damage to the
foot control, do not immerse in water or liquids.
CAUTION
Keep foreign objects away from foot control. To
avoid accidental operation, be sure the foot con-
trol is NOT positioned below the front of the table.
Failure to do so could result in unwanted motion
and possible damage to the table.
NOTE: For optimum table performance, allow the table to
reach room temperature before operating.
NOTE: The table is not designed for continuous opera-
tion. The control system includes a thermal overload
safety switch to protect from overheating. If the table is
operated continuously causing the control to exceed its
allowable operating temperature, the thermal overload
safety switch will shut off. If normal operation ceases,do
not attempt to operate the table. Allow the table to cool
for 10-15 minutes before attempting to use again. The
thermal overload switch will automatically reset when it
has reached a safe operating temperature.
Model Congurations
NOTE: Each control function will automatically stop
moving when either the UP or DOWN travel limit is
reached. If the foot pedal is pressed with travel at its
limit, the actuator will not operate. Sensors prevent the
actuator motor from operating when travel limit has
been reached, preventing wear of the actuator.

Document # 100452 RevK 8 Printed in USA © 2012
Models 6000 & 6001
Models 6000 & 6001 are equipped with a single foot
pedal that controls the raising/lowering of the table.
Models 6500 & 6501
Models 6500 & 6001 are equipped with a dual foot pedal
that controls the raising/lowering of the table and raising/
lowering of the seat back. In addition, the control features
the following:
Return to Chair: When pressed, the table automatically
returns to the low chair position. The seat back will rise
to the full up position and the table will lower to the full
down position and stop. If the Emergency Stop or either
pedal is pressed while the table is in motion, the system
will return to manual mode and all motion will stop.
Emergency Stop: When pressed, stops the motion of all
functions.
Green Light (Models 6500 & 6501 only): Indicates that
there is power to the foot control (Safety On/Off switch at
back of table is ON).
Safety Switch for
Seat Back
Function
Safety Switches for Table
Bottom Raising/Lowering Function
Figure 9. Safety Switches
Safety Switches
all Models
All models are equipped with safety switches located
on the bottom and seat back of the chair assembly that
automatically stops the lowering function if an obstruction
is encountered.
Figure 8. Foot Controls
TABLE UP
(Raises the entire
table upward)
TABLE DOWN
(Lowers the entire
table downward)
MODELS 6000 & 6001 MODELS 6500 & 6501
TABLE UP
(Raises the entire
table upward)
TABLE DOWN
(Lowers the entire
table downward)
BACK DOWN
(Lowers the back)
BACK UP
(Raises the back)
EMERGENCY STOP (RED)
(Stops all
functions
when pressed)
RETURN TO CHAIR
(BLUE)
(Returns table
to chair position
when pressed)
OPERATION (continued)
GREEN LIGHT
(Lights when power
to the foot control is ON)
CAUTION
Do not leave patient unattended when using the
Return To Chair feature.
Safety On/Off Switch
all Models
The On/Off switch (located on the back of the rear cabi-
net) can be set to the OFF position to disable all move-
ment of the table. Power to the drawer warmer (if so
equipped) and other portions of the table will remain on.
STOP RETURN
TO CHAIR

Document # 100452 RevK 9 Printed in USA © 2012
Powered Backrest (Models 6500 & 6501)
Models 6500 & 6501 are equipped with safety switches
on the rear of the seat back which automatically stops the
lowering function of the seat and back if an obstruction is
encountered.
Depress the BACK UP pedal and remove the obstruction.
PneuMatic Manual Backrest (Models 6000 & 6001)
The safety switches automatically stop the lowering func-
tion of the seat if an obstruction is encountered.
Grab Bars
In the forward (normal use) position the grab bars lock
into place preventing left or right rotation.
The grab bars can be rotated to the side of the table for
improved access to the patient. Pull up on the grab bar
and rotate to the desired position. The grab bar locks in
the front and rear position.
NOTE: The grab bar can be removed from the table by
pullling up on the grab bar, rotating it to the 90° position,
and then lifting it out of it’s holder.
Leg Support
The leg support is located under the seat cushion. (Figure
11), It can be extended 14” for the patient prone position.
If more length is needed, the leg extension can be pulled
out to provide an additional 6”.
Treatment Pan
A removable treatment pan is built-in underneath the
leg support pad for use during examination. Pull the leg
support fully out and remove the leg support pad or slide
it back under the seat to access the pan (Figure 12).
Remove the treatment pan for cleaning.
Figure 10. Grab Bar Adjustment
Pull up to rotate
Push down to
lock in place
Figure 11. Leg Extention
Figure 12. Treatment Pan
Leg Support
Treatment Pan
Leg Support Pad
Leg
Support
Leg
Extension

Document # 100452 RevK 10 Printed in USA © 2012
OPERATION (continued)
Front Drawer
A storage drawer for supplies is located at the front of the
table. Models 6001 & 6501 are equipped with a drawer
warmer that is turned on by a switch located above the
drawer (Figure 13).
Pass Through Side Drawers
Two storage drawers are built into the table cabinet for
supplies (Figure 15). The drawers may be pulled out from
either side of the table.
Installing Drawer Stops
The Brewer Access High-Low Exam Tables are supplied
with two drawer stops for the side pass through drawers.
If you wish to restrict the drawers to opening only on one
side, simply install one drawer stop per drawer on the op-
posite side the drawer is to be opened (See Figure 14.)
To install drawer stops:
1. Pull drawers out on the side of desired use.
1. Screw in one drawer stop, one for each drawer on
opposite side of cabinet. (Figure 14).
Figure 14.
Brewer
Figure 13. Front Drawer
Drawer Warmer
On/Off Switch
(Models 6001
and 6501 only)
Front Drawer

Document # 100452 RevK 11 Printed in USA © 2012
Paper Storage
Figure 15. Side Drawers & Paper Storage
Pass Through Work Surface
A pass through work surface, stored under the seat (Fig-
ure 17), may be pulled out from either side of the table.
Grasp the edge of the work surface and pull until it is fully
extended. Push it fully in to stow after use.
CAUTION
The work surface is intended to support a maxi-
mum of 15 lbs.
Figure 16. Paper Roll Installation
Paper Storage
With the seat back in the upright position, lift the lid
on the paper storage compartment to access stored
paper rolls (Figure 15).
Paper Roll Holder
To change a paper roll, place the paper into the
holder located on the rear of the seat back (Figure
16). Pull the end of the roll over the top of the seat
back and position in the desired position.
Removing the Work Surface for Cleaning
1. Push work surface in, to reveal a white plastic screw.
2. Remove the white plastic screw. (Figure 18.)
3. Pull the work surface toward you and remove it.
CAUTION
Do not use paper roll with a diameter greater than
3” or back rest safety switch will not operate.
Pass Through Side Drawers
Figure 17. Pass Through Work Surface

Document # 100452 RevK 12 Printed in USA © 2012
OPERATION (continued)
CAUTION
Do not use any part of the stirrup for attachment of
any device. Warranty will be voided. Use support
adapters to attach clamps, then attach knee crutch-
es to clamps. If adapters are not currently installed,
order PN 100550 (See page 22 for accessories).
Figure 18. Removing the Work Surface
Figure 19. Stirrups
storing the stirruPs
1. To store the stirrups in the table, grasp end of stirrup
and pull straight out to its full extension.
2. Fold stirrup down against bar, then rotate it to the
inner most lateral position and slide it back into the
stowed position.
Plastic Screw
WARNING
Failure to engage the lateral locking mechanism
could allow patient to lose balance resulting in
personal injury to patient.
Adjustable Stirrups
oPerating the stirruPs (Figure 19)
1. To operate the stirrups, grasp end of stirrup and pull
straight out of the table. Lift up slightly while sliding
the stirrup out.
NOTE: Do not apply any downward pressure when pull-
ing stirrup from table or it may be difcult to move. This
is normal and is part of the stirrup friction locking mecha-
nism
2. Unfold stirrup upward to the fully open position.
3. Adjust the stirrup to the desired length by sliding it in
or out.
stirruP lateral adjustMent
1. Lift end of stirrup and then rotate outward to
desired position.
2. When the desired position is achieved, lower the stir-
rup to engage the lateral locking mechanism.
3. Check that lateral locking mechanism is engaged by
attempting to rotate stirrup assembly without lifting on
the stirrup end.

Document # 100452 RevK 13 Printed in USA © 2012
TABLE ADJUSTMENTS
Figure 21. Adjusting Seat Back
Figure 20. Table Height Positioning
Table Height
The table can be adjusted to any height between 18” to
37” (Figure 20).
1. To raise the table, depress and hold the Table Up
pedal until the desired height is achieved, then re-
lease the pedal. (See Figure 8.)
2. To lower the table, raise the backrest to the upright
position, then depress and hold the Table Down pedal
until the desired height is achieved, then release the
pedal. (See Figure 8.)
Seat Back
The back can be adjusted to any angle between horizon-
tal and 80°.
NOTE: The table must be raised to a height of at least
28” before the backrest can be adjusted to the horizontal
position. (See Figure 21.)
PneuMatic Manual Backrest (Models 6000 & 6001)
1. Raise the table to a minimum of 28”
2. To lower the seat back, push down on the seat back
while pulling the release handle upward (See Figure
2).
3. To adjust the back from a horizontal position to a
chair position, press the release handle (located on
either side of the seat cushion) and lift upward. The
seat back will lock in the desired position when the
handle is released.
Powered Backrest (Models 6500 & 6501)
1. Raise the table to a minimum of 28”
2. To adjust the back from an upright (chair) position
to a horizontal position, depress and hold the
Back Down pedal until the desired angle is achieved,
then release the pedal.
3. To adjust the backrest from a horizontal position to
a chair (upright) position, depress and hold the
Back Up pedal until the desired angle is achieved,
then release the pedal.
NOTE: The back is positioned by an actuator that raises
the back when activated. When lowered, the actuator
retracts and gravity causes the back to lower.
28“

Document # 100452 RevK 14 Printed in USA © 2012
TABLE ADJUSTMENTS (continued)
Manual Pelvic Tilt
(Models 6001 & 6501)
The manual pelvic tilt feature sets the seat angle at 0°
(horizontal) or 5° (up) position.
Pull up on the front of the seat and the pelvic tilt auto-
matically travels to the locked tilt position (Figure 22). Lift
the adjustment lever and lower the seat to the horizontal
position.
CAUTION
Patient must be removed from table prior to lower-
ing the seat.
Figure 22. Pelvic Tilt Adjustment
Pelvic Tilt Adjustment Bar
Front Drawer Warmer
(Models 6001 & 6501)
Models 6001 & 6501 are equipped with a drawer warmer
that is turned on by a switch located above the drawer
(Figure 23).
Drawer Warmer
On/Off Switch
(Models 6001 &
6501 only)
Figure 23. Front Drawer Warmer Switch

Document # 100452 RevK 15 Printed in USA © 2012
Preventative Maintenance
CAUTION
Failure to perform periodic inspections of the
table could result in personal injury or equipment
damage.
• Periodically inspect the electrical cord to ensure it is
free of cuts or damage.
• Inspect the mechanical functions to ensure satisfac-
tory operation. Complete the operating test.
• Check fasteners to make sure they are present and
tightened securely.
• Lubricate moving parts (such as back and storage
cover hinges) with a food grade silicon lubricant.
• Have a qualied technician inspect your table every 6
months.
Control Box Fuse Replacement
WARNING
Disconnect power by removing plug from the
power outlet before changing fuses.
1. Manually raise table and prop in raised position.
2. Remove shroud below seat to expose actuators and
control box. (See Figure 24.)
3. Locate fuse cover on control box. (See Figure 25.)
4. Pull out fuse cover with pliers.
5. Replace fuses using spare fuses in fuse cover. Fuse
type is 250V/2.5AT for 115 VAC and 250V/1.25AT for
230 VAC models.
6. Reassemble.
Heater Fuse Replacement
(Models 6001 & 6501)
1. Remove two fuse covers from back of table near the
power cord.
2. Replace both fuses. Fuse type is 5 x 20mm,
250V/1.0A.
3. Replace fuse covers.
* Models 6001 & 6501 with Heater & Outlet have a single
fuse. Fuse type is 5 x 20mm, 250V/3.0A
MAINTENANCE
CAUTION
The upholstery material is resistant to most medici-
nal type stains, but may be damaged by solvents
and dyes. Remove any spilled uids from the up-
holstery immediately.
Clean the table weekly, wiping the painted metal and
plastic surfaces with a clean, soft cloth. If desired, mild
cleaners may be used.
Clean the work surface and rear paper storage cover im-
mediately after contact with any uids or gels. Use a mild
soap and rinse with clear water. Avoid the use of harsh
chemicals as they can permanently damage the nish.
Table Care
Upholstery Removal
1. Remove the two screws under the seat securing the
pelvic tilt lever to the the seat frame (models equipped
with pelvic tilt only, all other models skip to step 2).
2. Lift the seat and remove the three screws securing the
hinge to the seat frame.
3. Remove one screw in the paper holder securing the
seat back to the back frame.
4. Remove the upholstery from the table.
5. To remove the leg extension upholstery, pull up on pad
to release the plastic clips.
Remove Two Screws
Remove Cover
Remove Fuse Cover
and Replace Fuses
Figure 24.
Figure 25.

Document # 100452 RevK 16 Printed in USA © 2012
TROUBLESHOOTING
Operating Test
It is possible to verify normal operation of the
series 6000 tables by performing the following
series of tests.
ALL MODELS
Lift test
1. Insure ON/OFF switch is in ON position.
2. Press and hold the TABLE UP pedal. The
table should rise to the full up position
(about 37”) and stop. There must be no
continuing motor hum after the table stops.
3. Release the TABLE UP pedal.
4. Press the TABLE DOWN pedal. While
the table is going down pressing on each
corner of the back of the seat must cause
the table to momentarily stop.
5. The table should go to the full down posi-
tion. Release the TABLE DOWN
pedal.
6. Reach under the front section bottom plate
and lift up momentarily on each corner of
the plate. This should activate the lift caus-
ing the table to rise while the plate is lifted.
7. Turn the ON/OFF switch, located on the
back of the rear cabinet, to the OFF posi-
tion. Verify that pressing any of the foot
pedals does not cause motion. Turn the
ON/Off switch to the ON position.
MODELS 6500 & 6501 ONLY
Powered Back test
1. Press the TABLE UP pedal to raise the table
above 28” so the back may be lowered without
contacting the back cabinet.
2. Press the BACK DOWN pedal. The back
should go to the full recline position, which is
level.
3. Press the BACK UP pedal. The back should
go to the full up position.
4. Press the BACK DOWN pedal. While the
back is going down pressing on any corner of
the back of the seat must cause the back to
momentarily stop.
5. Press the blue RETURN TO CHAIR button on
the foot control. While the chair is in motion
momentarily press the red STOP button. The
chair must stop and remain stopped.
6. Press the blue RETURN TO CHAIR button on
the foot control. While the chair is in motion
momentarily press the BACK UP pedal. The
chair must stop and remain stopped.
7. Press the blue RETURN TO CHAIR button on
the foot control. While the chair is in motion
momentarily press the BACK DOWN pedal.
The chair must stop and remain stopped.
8. Press the blue RETURN TO CHAIR button
on the foot control. While the chair is in mo-
tion momentarily press the TABLE UP pedal.
The chair must stop and remain stopped.
9. Press the blue RETURN TO CHAIR button on
the foot control. While the chair is in motion
momentarily press the TABLE DOWN pedal.
The chair must stop and remain stopped.
10. Raise the table to the full up position, and then
lower the back so the table is in the high table
position. Press the blue RETURN TO CHAIR
button. The table should rst raise the back
then lower to the chair low position.

Document # 100452 RevK 17 Printed in USA © 2012
Step #
1
2
3
4
5
6
7
* No relay clicking in control box. Table then functions after about 30 minutes.
Front cabinet switches; 1 or more
of 6 is not closing when pressed.
Press each one and listen for click
when pressed and again when
released. Replace as necessary.
Start Here
Complete the operational test
Test fails Test passes Test Complete
No movement
Some
movement
Go to step 2.1
Go to step 2.2
Does the drawer warmer heat
properly? Does outlet work?
Yes or N/A
No
Call 1 888-Brewer1 for technical
assistance.
Call 1 888-Brewer1 for technical
assistance.
Fixed
Still bad
Seat back switches; 1 or more of 4
is not opening when pressed.
Press each one and listen for click
when pressed and again when
released. Replace as necessary.
Fixed
Yes
No
Return to step 1
Control box is over temperature.
Allow 30 minute cool down.
Control box resets automatically.
Yes
No
No
Yes
Is there excessive noise or other
problems which are not yet
identified?
Go to step 5.1 for Heater
Go to step 6.1 for Outlet
Go to step 7.1
Table stops after period of heavy
use. *see below
Still bad
Do all powered functions work?
Yes
No
Do the 6 front limit switches
work properly?
Yes
No
Do the 4 seat back limit switches
work properly?
6000 SERIES TABLE TROUBLESHOOTING CHART

Document # 100452 RevK 18 Printed in USA © 2012
2.1
a
b
c
d
e
f
g
Return to step 1
Step 2.1 continue here
Call 1 888-Brewer1 for technical
assistance.
Front cabinet switch (one of 6) is
stuck on. (closed) Unplug table
power. Isolate faulty switch or wire
using a continuity tester. Replace
or repair.
Is green light on at back side of
control box?
No Yes
Is the table stuck in the up
position?
No
Still bad Fixed
No heater or No
Table does not go down. Control
box relay clicks in down direction.
When front bottom switch plate is
lifted there is no relay click.
No Yes
Call 1 888-Brewer1 for technical
assistance.
Return to step 1
Return to step 1
Check for loose wire connections
at terminal block.
Return to step 1
Return to step 1
If table has a heater, is the switch
illuminated when turned on?
Yes
Still bad
Fixed
Press foot control pedal. Does
relay in control box click?
Yes
Replace 2 control box fuses.
Still bad
Is on/off switch on back of cabinet
turned on?
Yes
No
Check for loose plug in wall outlet
or back of table. Check for power
at outlet.
Yes
No
Fixed
Replace control box.
Still bad
Fixed
Ok
Turn on switch, then return to step 1
Fixed

Document # 100452 RevK 19 Printed in USA © 2012
2.2
a
b
c
d
e
f
Yes
No
No
Yes
No backrest movement. Motor
hums in the up direction but there
is no movement.
No
Yes
Are there other problems not yet
identified?
No
Yes
Table does not go all the way
down. After table stops in the down
direction, continue pressing the
down pedal. One actuator
continues to hum for a few seconds
while there is no movement.
Backrest safety switch, 1 or more
of 4 is not closing when pressed.
Press each one and listen for click
when pressed and again when
released. Replace as necessary.
Replace back actuator.
No
Yes
One lift actuator has failed.
Replace both lift actuators. Return
to step 1.
Table raises slightly slower than
normal while the up pedal is held.
One actuator continues to hum.
Retun to step 1.
Step 2.2 continue here
Call 1 888-Brewer1 for technical
assistance.
No problem found, test complete.
Table is low and does not rise, but
motors hum when up pedal is
pressed.
Return to step 1
Still bad
Fixed
Backrest or table lift stuck in full up
position. No motor hum. Control
box relay clicks in both up and
down direction.
No
Yes

Document # 100452 RevK 20 Printed in USA © 2012
5.1
a
b
c
6.1
a
b
c
Does outlet work now?
Yes
No
Call 1 888-Brewer1 for technical
assistance.
Replace heater / outlet fuse.
Yes or N/A
Replace transformer.
No
Replace table outlet.
Does outlet work now?
Yes
No
Return to step 1
No
Does outlet work now now?
Yes
Yes
No
Return to step 1
Outlet Option
Step 6.1 continue here
Device works when plugged in to
table outlet.
Heater gets warm when on. Call 1 888-Brewer1 for technical
assistance.
Yes
No
Replace heater.
Does heater get warm now?
Yes
No
Replace heater switch.
Does switch illuminate now?
Yes No
Drawer warmer
Step 5.1
continue here
Heater switch illuminates when on.
Replace heater fuse(s).
Yes
No
Does switch illuminate now?
