Briggs & Stratton 76000 Setup guide

Home Generator Systems
Liquid-Cooled
Home Generator System
Model / Modelo / Modèle
076000
Illustrated Parts List
Les Parties Illustrées Enumèrent
Las Partes Ilustradas Listan
Manual No. 205051A Rev. - (03/14/2008)

UNIT EXPLODED VIEW
Copyright © 2008 Briggs & Stratton Power Products Group, LLC. All rights reserved. No part of this material may be
reproduced or transmitted in any form by any means without the express written permission of Briggs & Stratton Power
Products Group, LLC.
2BRIGGSandSTRATTON.COM

UNIT PARTS LIST
Item Part # Description
1 AA204477GS BASE
2 205623GS TRAY, Battery
3 206119GS ASSY, Heater, Tank
4 204892GS KIT, Exhaust
5 204654GS SILENCER, Muffler
6 205398GS DECAL, Burn Hazard
7 * HHCS, 5/16 - 18 x 1
8 * WASHER, 5/16 - M8, Lock
9 * WASHER, 5/16 - M8, Flat
10 205396GS DECAL, Warning Hot Coolant
11 205399GS DECAL, Warning Moving Parts
12 205226GS KIT, Bottle Overflow
13 204868GS CLAMP, Air Cleaner
14 204274GS ASSY, Air Cleaner
207026GS Cartridge, Air Filter
15 204343GS ASSY, Alternator
207019GS Assy, Rectifier
207020GS Regulator, Voltage
16 206120GS ASSY, Fuel Valve
17 AA204802GS COUPLER, Fuel System
18 206626GS VALVE, Ball 1/4"
19 206455GS ASSY, Hose, Fuel
20 205012GS ELBOW, Rubber
21 204841GS TUBE, Inlet, Air
22 204869GS ELBOW, Rubber
23 200409GS DECAL, Warning, Hot
24 186649GS DECAL, Oil Drain
25 205401GS DECAL, Explosion Hazard
900 § ENGINE
Parts Not Illustrated
204347GS KIT, Manual
205051GS MANUAL, Operator’s
205052GS MANUAL, Install
206992GS MANUAL, Engine, PSI
841281 SWITCH, Oil Pressure
204751GS SWITCH, Temperature
198866GS ASSY, Wall Plate
205206GS HOSE, Flex
206943GS ASSY, Oil Drain Hose
198573GS FUSE, ATO Type 15amp
203374GS PAINT, Touch-Up 1/2oz, Continuum
Charcoal
198811GS PAINT, Touch-Up 1/2oz, Metallic
Silver
205622GS KIT, Hold Down Battery
207025GS KIT, Decals, Service
Optional Accessories
199475GS PAINT, Touchup, 12oz Spray, Silver
203417GS PAINT, Touchup, 12oz Spray,
Continuum Charcoal
203374GS PAINT, Touch-Up, Continuum
Charcoal
198811GS PAINT, Touch-Up, Metallic Silver
* - Items without part numbers are common fasteners and
are available at your local hardware store.
§ - Contact Engine Manufacturer
3

Item Part # Description
1 AA204477GS BASE
2 186643GS DECAL, Fuel Inlet
3 B4986GS DECAL, Ground
4 205849GS ASSY, Roof
5 205368BGS SEAL TAPE, Vinyl
6 205368CGS SEAL TAPE, Vinyl
7 205368AGS SEAL TAPE, Vinyl
8 T204451GS COVER, Radiator
9 T204443GS HINGE, Plate
10 T204443GS HINGE, Plate Cover
12 205855GS ASSY, Bulkhead, Alt.
13 205853GS ASSY, Support Rail, Top
14 205850GS ASSY, Bulkhead, Engine
15 205854GS ASSY, Door
Item Part # Description
16 207030GS ASSY, Support Rail, Bottom
17 205851GS ASSY, Corner, Exhaust
18 207024GS ASSY, Baffle Exhaust
19 186049GS HANDLE, Door
20 207031GS ASSY., Support Rail
21 207032GS ASSY, Weldment Door
22 AA204460GS BRACKET
23 194828GS KEY, Door Latch
24 195998GS KIT, Door Latch
25 205126GS DECAL, Requirements
Parts Not Illustrated
205358GS SEAL, Hollow, 200 Ft Roll (Cut to Fit)
205357GS SEAL, Tape, Vinyl, 50 Ft Roll (Cut to
Fit)
ENCLOSURE EXPLODED VIEW & PARTS LIST
4BRIGGSandSTRATTON.COM

Item Part # Description
1 204008GS PANEL, Control
2 198516GS CONNECTOR, Terminal, 10-Pin
3 21217GS MOUNT, Vibration
4 201307GS PLUG, Relay
5 205028GS BLOCK, Terminal
6 205026GS RELAY
7 198549GS DECAL, Terminal Block
8 205029GS BLOCK, Terminal
9 190841GS TERMINAL, Neutral
10 204519GS INSULATOR
11 204178GS CIRCUIT BREAKER
12 186173GS BUSHING, Snap
13 192151GS FUSE HOLDER
14 205110GS FUSE
15 198550GS DECAL, Ground Neutral
16 204530GS KIT, Load Lug Conversion
17 B4986GS DECAL, Ground
Item Part # Description
18 203015GS BUSHING, Snap
19 B5082AGS DECAL, Danger High Voltage
20 205392GS DECAL, Warning, Auto Start
21 205394GS DECAL, Warning, Electrical Shock
22 193297GS DECAL, Caution
23 205395GS DECAL, Warning, Electrical Shock
24 205393GS DECAL, Warning, Outdoor Install
25 AA205058GS COVER, 10 Pin Connector
26 205030GS JUMPER, Screw
27 AA206191GS PLATE, Bottom Access
28 205588GS DIODE
Parts Not Illustrated
205031GS WIRE HARNESS
198573GS FUSE, ATO Type, 15amp
205115GS DECAL, Fuse
192597GS DECAL, Utility 240 VAC
CONTROL PANEL EXPLODED VIEW & PARTS LIST
5
