bright showers BSB2700 User manual

BSB2700

Thank you for choosing and using our products.
Aer opening the product package, please check the accessories according to the following table and the following figure(s).
If there is a shortage, Please contact us immediately at: info@premierbathfixtures.com or [phone]
Warning: Please read the enre contents of this installaon manual carefully before installaon!
Tools Required:
• Phillips Screwdriver
• Adjustable Wrench
• Tape Measure/Ruler
• Pencil
• Electric Drill
-1-
NOTE
14 and 16 are for
Optional Mounting
5
8
6
9
4
3
2122
21
20
19
18
17
12
13
14
15
16 10
11
7
18
min.10"
MOUNTING
DIAGRAM
Serial
numbe
r
name quant
y
1 Shower Arm 1
2 PTFE Thread Sealant Tape 1
3 Hexagonal Wrench 1
4 Hexagon socket screw set 1
5 Ball Joint 1
6 Gland Nut 1
7 top tee 1
8 Shower Rod 1
9 Hand Shower Holder 1
10 Diverter Body 1
11 Extension B（75mm） 1
12 C ring 1
13 Lock Nut 1
14 Lower Mount screw 1
15 Lower Mount 1
16 Wall Anchor 1
17 Extension A（45mm） 1
18 Rubber Washer 2
19 Stainless steel Hose 1
20 Hand Shower 1
21 Rain Shower Head 1
22 Rubber Washer 1

5) Connect the shower am (1) with the top tee(7) and adjust the
posion, then ghten the nut(4) with Hexagonal Wrench(3)
6) Loose the gland nut(6) and top tee(7) counterclockwise, screw the
ball joint(5) clockwise by hand, then ghten the ball joint(5) with
adjustable wrench.
7) Tighten the gland nut(6) and top tee(7) with the hexagonal wrench,
adjust the shower set to be parallel to the wall, adjust the extension
B(11) to make the shower rod (8) to be parallel to the wall and mark
the posion of lower mount(15) on the wall then ghten the lock
nut(13) with adjustable wrench.
4) O-ring on the top tee (7) is coated with silicone oil
2) Use the aached template to measure the length of shower arm and
choose the suitable extension A or extension B.
3) This set is preassembled with extension B(11), the longer one. Please
change to shorter extension A(17) if required, steps as below.
Loose the lock nut (13) counterclockwise from the diverter body (10),
and loose the extension B (11) clockwise from lower mount (15) , then
take down the extension B(11). Assemble the Extension A (17) on the
contrary way .
Assembly
1) Use a wrench to remove the old shower head from the arm, clean the
threads on the shower arm and wrap it clockwise with PTFE Thread
Sealant Tape.
-2-
4 /
15
16
3
2
3 /
2 /
2
3
3
2
2 /
3 /
2
3
16
15
4 /
Templae Left Templae Right
"
"
"
"
"
"
Templae Right
Templae Left
4 /
15
16
3
2
3 /
2 /
2
33
2
2 /
3 /
2
3
16
15
4 /
"
"
"
"
"
"
B
A
1. 2. 3.
13
10
13
11
15
11
13 12
17
15
Grease
V
3
41
7
66
7
5
6
7
11
15
pencil
13
15
A

8) Wall surface must be cleaned completely dry. Remove covering of
two-face tape of the lower mount (15) and install the lower
mount(15) on the wall. Apply pressure to mount for 30 seconds by
pushing firmly against the lower mount(15).
Note: to ensure proper adhesion, allow one hour before using your
showerspa and keep area around the mount as dry as possible for
the first 24 hours. Tape will be fully cured aer 24 hours.
10) Install the rubber washer(22) into the rain shower head(21),and
then connect to the shower arm.
The handle of diverter has default posion for water flow. When it
towards upside, the rain shower head works ; when you turn the
handle counterclockwise 180°, the hand shower works.
Hold and buon side of shower holder and turn it 45° to slid up and
down, turn it back for fixing.
There are 3 funcons of hand shower, turn the back dial of it for
funcon change
Turning the shower head like a wheel for 2 funcon change.
To clean the shower column, wash with a wet, non-abrasive soapy
cloth.
Do not use any abrasive chemicals, corrosive powders or any other
strong cleaners/disinfectants on the products as they may be
harmful to the finish.
If you have any quesons or concerns about this product, please
don’t hesitate to contact us. We will be more than happy to provide
you assistance either over the phone or via e-mail. Thank you for
choosing us as your Premier Bath Fixtures!
Email: info@premierbathfixtures.com
Phone: [phone]
9) Insert the rubber washers(18) into the two ends of stainless steel
hose(19). Connect the hexagonal nut end to the diverter body(10),
connect the tapered end of the shower hose to the hand shower(20).
Insert the handheld shower(20) into hand shower holder(9).
-3-
18 19
18
20
9
10
1
22
21
Cleaning and maintenance
Usage
Assembly
11 15
13
B1 B2
35mm
φ6mm
B3
13 15
B5
2.
1.
B6
13
B4
