BRIGHTLIGHT NEON CLASSIC User manual
LIGHT DIRECTION
16.5
11.5
29
MINIMUM
BEND RADIUS
60mm
COLOUR CODE
WARM WHITE
2700K +/- 145K BL-LS-4580-27
WARM WHITE
3000K +/- 175K BL-LS-4580-30
NATURAL WHITE
4000K +/- 275K BL-LS-4580-40
COOL WHITE
5700K +/- 300K BL-LS-4580-57
2500 - 5000K
TUNEABLE BL-LS-4900
RED
615–625nm BL-LS-4530-R
GREEN
520–530nm BL-LS-4500-G
BLUE
465–475nm BL-LS-4500-B
YELLOW
580nm BL-LS-4530-Y
RGB BL-LS-4600-RGB
RGBW BL-LS-4650-RGBW
RGB CHASING BL-LS-4700-RGBC
RGBW CHASING BL-LS-4700-RGBWC
ELECTRICAL & OPTICAL DATA VARIANCE +/- 10%
SOLD BY THE METRE
IES FILES AVAILABLE
HORIZONTAL BENDING
Actual product characteristics may vary. Bright Light reserves the right to improve, modify or update the product designs without prior notice.
INSTALLATION GUIDE
NEON CLASSIC | ELECTRICAL AND PHYSICAL INSTALLATION GUIDE
DO NOT TWIST THE LIGHT OR BEND
AGAINST THE LIGHT SURFACE
NEON CLASSIC CAN BE CURVED
AS SHOWN BELOW
LIGHT SURFACE
– Avoid bending LED Neon within the rst unit (units are
clearly marked with dashed lines on the sides of the product)
– LED Neon can be bent up to the dened
“minimum bend radius” (60mm for Neon Classic)
BENDING PARAMETERS
60mm
0800 952 000 | www.brightlight.co.nz | BRIGHTLIGHT
Actual product characteristics may vary. Bright Light reserves the right to improve, modify or update the product designs without prior notice.
INSTALLATION GUIDE
NEON CLASSIC | ELECTRICAL AND PHYSICAL INSTALLATION GUIDE
– LED Neon must always be used in conjunction with a
certied Bright Light 24V DC power supply.
– Check the polarity of the connector before inserting the front
connector and switching on the mains power.
– To minimise voltage drop and ensure consistent light output,
position the power supply near to the power feed end of the
LED Neon, and keep the line as short as possible
– Ensure your maximum run per power feed adheres to the
guidelines; see specication sheet.
– Ensure to add 20% buer when selecting a power supply
– Before making any cuts, installation, maintenance, or
connection, be sure the mains power is disconnected.
– If essential; cut and connect LED Neon correctly. Any
incorrect operation can cause damage.
– All connector joints must be connected correctly to
achieve connector IP rating.
WHITE / SINGLE COLOUR
WIRING DIAGRAMS
RGBW
RGB
POWER SUPPLY RGB CONTROL
green wire: “G” terminal (-)
blue wire: “B” terminal (-)
yellow wire: +
red wire: “R” terminal (-)
24V DC
TUNEABLE WHITE
POWER SUPPLY 2-CHANNEL
CONTROL
black wire: Cool White connection (-)
red wire: +
yellow wire: Warm White connection (-)
24V DC
POWER SUPPLY RGBW CONTROL
green wire: “G” terminal (-)
blue wire: “B” terminal (-)
white wire: “W” terminal (-)
yellow wire: +
red wire: “R” terminal (-)
24V DC
DYNAMIC RGB ‘CHASING’ / RGBW ‘CHASING’
POWER SUPPLY DIMMER
optional black wire: -
red wire: +
24V DC
DMX OPTION AVAILABLE
black wire: “GND”, Cathode (-) terminal
red wire: “VCC”, Anode (+) terminal
yellow wire: “Signal” terminal
POWER SUPPLY INDEPENDENT
SPI CONTROL
24V DC
0800 952 000 | www.brightlight.co.nz | BRIGHTLIGHT
PROFILE INSTALLATION REQUIREMENTS
PROFILE MOUNTING: Install the screw ensuring head is ush or lower than the prole groove and into surface straight
SIDE
TOP
Put screws in any hole along the curve stainless steel
prole to create the desired curve shape.
Curve stainless steel prole is exible and can stretch or condense as the design requires.
REFER TO
MOUNTING ACCESSORIES PDF
FOR PROFILE DETAILS
& DIMENSIONS
ACCESSORY
BL-LS-4003
SELF-LOCKING ALUMINIUM V2 PROFILE 2m
BL-LS-4004
SELF-LOCKING ALUMINIUM V2 MOUNTING CLIP 35mm
BL-LS-4005
PLASTIC PROFILE 2m
BL-LS-4006
PLASTIC PROFILE 1m
ACCESSORY
BL-LS-4028
CURVE STAINLESS STEEL PROFILE 900MM
MULTIPLE FIXING LOCATIONS
CURVED PROFILE MOUNTING:
Install the screw ensuring head is ush or lower than
the prole groove and into surface straight
NEON IN PROFILE.
Designed to leave space
at the bottom for screw.
NEON IN PROFILE.
Designed to leave
space at the bottom
for screw.
Actual product characteristics may vary. Bright Light reserves the right to improve, modify or update the product designs without prior notice.
INSTALLATION GUIDE
NEON CLASSIC | ELECTRICAL AND PHYSICAL INSTALLATION GUIDE
0800 952 000 | www.brightlight.co.nz | BRIGHTLIGHT
PROFILE INSTALLATION REQUIREMENTS
>> FOR SLEEVE / SNAP / DUAL INJECTION MOULDING CONNECTORS
– Ensure the supply cord is not subject to mechanical stress
– Keep 10–20mm distance between the end of the prole and the end mounting piece
– The bend angle should be less than 15 degrees when installing LED Neon into the prole by hand
– Avoid placing mechanical stress on the front connector cable
– Do not curl or bend the front connector cable with excessive force
– Avoid installing the prole less than 10mm from the end mounting piece
– Install the LED Neon into the prole in one direction, don’t let it bow in the middle
-10mm
10-20 10-20
10-20 10-20
PULL
Actual product characteristics may vary. Bright Light reserves the right to improve, modify or update the product designs without prior notice.
INSTALLATION GUIDE
NEON CLASSIC | ELECTRICAL AND PHYSICAL INSTALLATION GUIDE
0800 952 000 | www.brightlight.co.nz | BRIGHTLIGHT
TOP END FEED
END CAP
END CAP
BOTTOM FEED / SIDE FEED
MIDDLE FEED
– Top End Feed (Slimline injection moulding only) & end cap are both tted within the prole
– Bottom feed / side feed are keep outside the prole with 10-20mm space
End cap is
within the
prole
End cap is within the prole
Top end feed is within prole
– End cap is within the prole
10-20 10-20
Keep 10–20mm distance
between the end of the prole
and the botton or side feed
PROFILE INSTALLATION REQUIREMENTS
>> FOR SLIMLINE INJECTION MOULDING CONNECTOR
End cap is
within the
prole
Keep 10–20mm distance
between both ends of the
prole and the middle feed
10-20
10-20
PULL
PULL
End cap is within the prole
End cap is within the prole
END CAP
– Avoid placing mechanical stress on the connector cable
– Do not curl or bend the connector cable with excessive force
Do not use prole closer than 10mm from connector to
avoid bending Neon and damaging LEDs.
Actual product characteristics may vary. Bright Light reserves the right to improve, modify or update the product designs without prior notice.
INSTALLATION GUIDE
NEON CLASSIC | ELECTRICAL AND PHYSICAL INSTALLATION GUIDE
0800 952 000 | www.brightlight.co.nz | BRIGHTLIGHT
