Brightwin Technology BRT2010 User manual

Temperature Calibrator
Users Manual
Model No.: BRT 2010
Shenzhen Brightwin Technology Co., Ltd.

Contents
1 Basic Introduction........................................................................................................ 1
1.1 Function............................................................................................................. 1
1.2 Summary of Source and Measure Functions...............................................1
1.3 Terminal Description.........................................................................................2
1.4 Key Description.................................................................................................3
1.5 Display Screen..................................................................................................4
2 Basic Operation............................................................................................................5
2.1 Measure and Source........................................................................................5
2.2 Shutdown Mode................................................................................................7
2.3 Backlight Brightness Adjustment....................................................................8
3 Function Usage............................................................................................................ 9
3.1 DC V Measurement..........................................................................................9
3.2 DC mV Measurement.................................................................................... 10
3.3 Resistance Measurement............................................................................. 10
3.4 DC mV Output.................................................................................................11
3.5 Resistance Output..........................................................................................12
4 Temperature Measurement......................................................................................13
4.1 Using Thermocouple (TC).............................................................................13
4.2 Using Resistance Thermometer Detector (RTD)...................................... 15
5 Simulation of temperature sensor........................................................................... 18
5.1 Simulating Thermocouples........................................................................... 18
5.2 Application of Resistance Temperature Detector (RTD).......................... 19
6 Advanced Application................................................................................................20
6.1 Setting 0 % and 100 % output parameters................................................ 20
6.2 Auto Ramping the Output..............................................................................21
6.3 Factory Reset..................................................................................................21
7 Power...........................................................................................................................22
7.1 Charge............................................................................................................. 22
8 Specifications............................................................................................................. 23
8.1 DC Voltage Measurement.............................................................................23

8.2 DC Voltage Source.........................................................................................23
8.3 Resistance Measurement............................................................................. 24
8.4 Resistance Output..........................................................................................24
8.5 Temperature, TC.............................................................................................25
8.6 Temperature, RTD..........................................................................................26
9 Product Accessories..................................................................................................27
9.1 Standard Accessories....................................................................................27
9.2 Optional accessories..................................................................................... 27
10 Warning.....................................................................................................................28

BRIGHTWIN BRT 2010 TEMPERATURE CALIBRATOR
www.brightwinelectronics.com [e-mail] 1
1 Basic Introduction
1.1 Function
It allows you to measure DC V, DC mV, resistance ,TC and RTD.
Outputs resistance, simulation of TC and RTD.
Thermocouple (TC) measurement provides cold-junction compensation.
Manual stepping, automatic stepping, 0 ～100% phase step and ramp
output.
Super-strong protection: The waterproof grade is IP67. Automatic
protection against the signal terminals connect to the 220V.
Support for PC communication
1.2 Summary of Source and Measure
Functions
Function
Measure
Source
DC V
0～30V
Not available
DC mV
0～120mV
0mV～100mV
Resistance
0～3200Ω
0～3200Ω
RTD
Pt100, Pt1000, Cu50,
Cu100
Pt100, Pt1000, Cu50, Cu100
TC
E,J,K,T,B,R,S,N
E,J,K,T,B,R,S,N
Others
Stepping output, ramp, phase step output, user-defined range

BRIGHTWIN BRT 2010 TEMPERATURE CALIBRATOR
www.brightwinelectronics.com [e-mail] 2
1.3 Terminal Description
Figure 1.3-1
No.
Name
Description
①
Communication and
charging connector
Connect power adaptor to charge batteries or connect
the calibrator to the computer.
②
3W and 4W terminal
3-wire and 4-wire electric and thermal resistance
measurement terminal.
③
COM Public terminal
terminal
All measurement and output public terminal.
④
V, mV, Ω,TC and RTD
terminal
Voltage and DC mV, 2-wire resistance,
thermal-electric and resistance measurement as well
as DC mV, resistance, thermocouple and
thermal-resistance output terminal.
⑤
4W+ terminal
Resistance and thermal resistance 4-wire
measurement terminal.

BRIGHTWIN BRT 2010 TEMPERATURE CALIBRATOR
www.brightwinelectronics.com [e-mail] 3
1.4 Key Description
Figure 1.4-1
No.
Description
①
Turns the power on or off
②
Selects the measurement mode
③
Selects output and analog transmitter mode.
④
Enables backlight switch display during start, enters backlight
brightness control mode.
⑤
Selects thermal resistance mode
⑥
Sets and saves calibrator parameters setting

BRIGHTWIN BRT 2010 TEMPERATURE CALIBRATOR
www.brightwinelectronics.com [e-mail] 4
⑦
Recovers factory default setting
⑧
Sets manual output
⑨
Cycles through:
slow repeating 0%-100%-0% ramp
Fast repeating 0 % - 100 % - 0 % ramp
Repeating 0 % - 100 % - 0 % ramp in 25 % steps
⑩
Set output by 0% of span, Press and hold to store the source
value as the 0 % value
⑾
Decrements output by 25% of span.
⑿
Increments output by 25% of span.
⒀
Sets output by 100% of span, Press and hold to store the
source value as the 100 % value.
⒁
Sets voltage, DC mV and resistance mode
⒂
Selects thermo-couple mode
1.5 Display Screen
Figure 1.5-1

BRIGHTWIN BRT 2010 TEMPERATURE CALIBRATOR
www.brightwinelectronics.com [e-mail] 5
2 Basic Operation
2.1 Measure and Source
This section acquaints you with some basic operations of BRT-2010/
BRT-1810.
Proceed as follows:
1. The connection of the calibrator as shown in Figure 2.1-1.
Figure 2.1-1
2. Press more than 2 seconds to turn on the calibrator. The calibrator
checks itself, including check on internal circuit and LCD, during which,
LCD displays all contents for 1s as shown in Figure 2.1-2:

BRIGHTWIN BRT 2010 TEMPERATURE CALIBRATOR
www.brightwinelectronics.com [e-mail] 6
Figure 2.1-2
3. Then the product model（2010）and automatic shutdown time（30 min）
will be displayed for 2 seconds as shown in Figure 2.1-3.
Figure 2.1-3
4. Then the default interface of boot will be displayed as shown in Figure
2.1-4:
Figure 2.1-4
5. Press , switch to the voltage mode. Switching is not required for this
series after starting-up.
6. Press to enter into output mode selection
7. Press to enter into DC mV output mode as shown in Figure 2.1-5.

BRIGHTWIN BRT 2010 TEMPERATURE CALIBRATOR
www.brightwinelectronics.com [e-mail] 7
Figure 2.1-5
8. Press and to increase or decrease 1 of the horizontal line
position (the number will be based on automatic stepping without change
of horizontal line position); press or to change the position of
horizontal line.
9. Press until the buzzer works and to enter 0mV as 0% value.
10. Likewise, press to increase output value to be 100mV, and then
press until the buzzer works and enter 100mV as 100% value.
11. Press or to make output increase or decrease within the
span of 0% to 100% based on 25% advance amplitude. The screen will
display as shown in Figure 2.1-6.
Figure 2.1-6
2.2 Shutdown Mode
The calibrator comes with the shutdown mode enabled for a time duration set to
30 minutes (displayed for about 2 seconds when the calibrator is initially turned
on). When the shutdown mode is enabled, the calibrator will automatically

BRIGHTWIN BRT 2010 TEMPERATURE CALIBRATOR
www.brightwinelectronics.com [e-mail] 8
shutdown after the time duration has elapsed from the time the last key was
pressed. To disable the shutdown mode, press and simultaneously. To
enable the mode, press and simultaneously. To adjust the time duration,
press and simultaneously, the screen will display as shown in Figure
2.2-1,then press and/or to adjust the time between 1 and 30 minutes
and then press to store the new time duration (Without pressing any key
for 5 seconds, the calibrator will quit from the adjustment automatically).
Figure 2.2-1
2.3 Backlight Brightness Adjustment
To adjust the brightness of backlight, proceed as follows:
1. Please press and simultaneously until the buzzer work, then the
screen will display as shown in Figure 2.3-1:
Figure 2.3-1
2. Press and to adjust the brightness of backlight.
3. Press to save brightness level, will appear and then the
calibrator will enter into the work mode(Without pressing key for 5 seconds,
the calibrator will exit from the adjustment automatically).

BRIGHTWIN BRT 2010 TEMPERATURE CALIBRATOR
www.brightwinelectronics.com [e-mail] 9
3 Function Usage
3.1 DC V Measurement
The default function after turn on is DC V measurement. If it is required, press
to re-select the voltage measurement (the display unit is V).Please
connect the lines after all functions are selected. The connection mode and
interface are shown in Figure 3.1-1:
Figure 3.1-1

BRIGHTWIN BRT 2010 TEMPERATURE CALIBRATOR
www.brightwinelectronics.com [e-mail] 10
3.2 DC mV Measurement
Press to re-select the DC mV function (the display unit is DC mV), the
connection mode is same to that of voltage measurement. The screen will
display as shown in Figure 3.2-1.
Figure 3.2-1
3.3 Resistance Measurement
Press to reselect the DC mV measurement function (Display unit is Ω)
Figure 3.3-1
The Over Span Under Open Circuit
Resistance measurement supports the connection type of two-wire system,
three-wire system and four-wire system. The calibrator can be switched to
three-wire system or four-wire system according to actual connecting type. The
respective connecting types are listed in Figure 3.3-2: Press and to
select the connection mode forcibly.

BRIGHTWIN BRT 2010 TEMPERATURE CALIBRATOR
www.brightwinelectronics.com [e-mail] 11
Figure 3.3-2
Press or to force the calibrator to adopt two-wire system, three-wire
system or four-wire system. Afterwards, the calibrator will not detect connecting
type automatically unless you quit the mode of resistance measurement and
re-enter.
3.4 DC mV Output
Press and to select DC mV output function, the connection mode
is same to that of voltage measurement. The screen will display as shown in
Figure 3.4-1.
Figure 3.4-1

BRIGHTWIN BRT 2010 TEMPERATURE CALIBRATOR
www.brightwinelectronics.com [e-mail] 12
3.5 Resistance Output
Press and to select the resistance output function, the connection
mode is same to that of voltage measurement.
Figure 3.5-1
indicates the undersize of exciting current,
meanwhile, the main value flashes
Press to select resistance output at 3200Ω level.
Figure 3.5-2
indicates the oversize of exciting current,
meanwhile, the main value flashes

BRIGHTWIN BRT 2010 TEMPERATURE CALIBRATOR
www.brightwinelectronics.com [e-mail] 13
4 Temperature Measurement
4.1 Using Thermocouple (TC)
The calibrator supports eleven standard thermocouples, including J, K, T, E, R,
S, B, L, U and N. Lower table summarizes the ranges and characteristics of the
supported thermocouples
Graduation
Positive lead
material
Positive wire (H)
color
Negative lead
material
Specified
span℃
ANSI*
IEC**
E
Chrome-nick
el
Mauve
Purple
Constantan
-200～950
N
Nickel-chrom
e-silicon
Orange
Pink
Nickel-silicon-magn
esium
-200～1300
J
Iron
White
Black
Constantan
-200～1200
K
Chrome-nick
el
Yellow
Green
Alumel
-200～1370
T
Copper
Blue
Brown
Constantan
-200～400
B
Platinum
(30%
rhodium)
Grey
Platinum (6%
rhodium)
600～1800
R
Platinum
(13%
rhodium)
Black
Orang
e
Platinum
-20～1750
S
Platinum
(10%
rhodium)
Black
Orang
e
Platinum
-20～1750
* Negative conductor (L) regulated as American National Standard (ANSI) is always red.
*Negative conductor (L) regulated as International Electro-technical Commission (L) is always
white.
To measure temperature using thermocouple, the following steps shall be
followed:
1. Connect the thermocouple to the calibrator as shown in Figure 4.1-1:

BRIGHTWIN BRT 2010 TEMPERATURE CALIBRATOR
www.brightwinelectronics.com [e-mail] 14
Figure 4.1-1
Attention:
Under different calibrator-thermocouple temperature environment, you
shall wait for one minute to stabilize the plug temperature after
connecting TC to input & output wiring.
2. Press to select measurement mode.
3. Press to display thermocouple reading as shown in Figure 4.1-2. If
necessary, pressing continuously to select appropriate
thermocouple type.
Figure 4.1-2
4. Press to display the DC mV value reading as shown in Figure 4.1-3.
The DC mV value continue to display for 3s and then automatically return
to the original display .
Process temperature

BRIGHTWIN BRT 2010 TEMPERATURE CALIBRATOR
www.brightwinelectronics.com [e-mail] 15
Figure 4.1-3
There are two kinds of cold end temperature compensation for thermocouple
measurement, automatic compensation directly using machine internal cold
end temperature compensation and manual compensation through the key to
set the cold end temperature compensation by the user.
4.1.1 Automatic compensation
First entered the thermocouple measurement mode, the default of the cold end
temperature compensation is automatic compensation reading as shown in
Figure 4.1.1-1.The sign represents that the current cold end
temperature compensation is automatic compensation. If you need further view
current automatic cold end temperature compensation value,you have to
operation key. Reading as shown in Figure 4.1.1-1,after press
key, the sign is replaced for current automatic cold end temperature
compensation value as . The value continue to display for 2s and
then automatically return to the sign.
Figure 4.1.1-1

BRIGHTWIN BRT 2010 TEMPERATURE CALIBRATOR
www.brightwinelectronics.com [e-mail] 16
4.1.2 Manual compensation
Manual compensation through the key to set the cold end temperature
compensation by the user, the following steps shall be followed:
1. Press key to enter the set mode, reading as shown in Figure
4.1.2-1, the appear of sign shows that entering the setup mode,
the assistant value means the value of manual compensation.
Figure 4.1.2-1
2. If you need to adjust the manual compensation value, press
keys to adjust.
3. Press key to save the value of manual compensation and exit from
the setup mode at the same time, reading as shown in Figure 4.1.2-2.
Figure 4.1.2-2
4. If necessary, press key return to automatic compensation.

BRIGHTWIN BRT 2010 TEMPERATURE CALIBRATOR
www.brightwinelectronics.com [e-mail] 17
4.2 Using Resistance Thermometer
Detector (RTD)
The calibrator accepts Pt100, Pt1000, Cu50 and Cu100, etc. The calibrator
accepts RTD measurements inputs in two-, three-, or four-wire connections,
with the three-wire connection the most common. A four-wire configuration
provides the highest measurement precision, and two-wire provides the lowest
measurement precision.
To measure temperature using an RTD input, proceed as follows:
1. Press to select mode.
2. Press for the RTD display. Then the screen will display as shown in
Figure 4.2-1. If desired, continue pressing this key to select the desired
RTD type.
3. Connect RTD to the corresponding port according to the connecting type
of ‘resistance measurement’.
Figure 4.2-1
