Brinkmann 810-1201-S User manual

OWNER’S MANUAL / MANUAL DEL PROPIETARIO
WARNING/ADVERTENCIA
HAZARDOUS EXPLOSION MAY RESULT IF THESE WARNINGS AND INSTRUCTIONS
ARE IGNORED. READ AND FOLLOW ALL WARNINGS AND INSTRUCTIONS IN THIS
MANUAL TO AVOID PERSONAL INJURY, INCLUDING DEATH OR PROPERTY DAMAGE.
SE PUEDE PRODUCIR UNA EXPLOSIÓN PELIGROSA SI SE HACE CASO OMISO A
ESTAS ADVERTENCIAS E INSTRUCCIONES. LEA Y SIGA TODAS LAS ADVERTENCIAS
E INSTRUCCIONES EN ESTE MANUAL PARA EVITAR LESIONES PERSONALES,
INCLUSO LA MUERTE, O LOS DAÑOS MATERIALES.
ASSEMBLY AND OPERATING INSTRUCTIONS
INSTRUCCIONES DE ARMADO Y OPERACIÓN
SAVE THIS MANUAL FOR FUTURE REFERENCE
GUARDE ESTE MANUAL PARA REFERENCIA FUTURA
NOTICE TO INSTALLER:
LEAVE THESE INSTRUCTIONS
WITH THE GRILL OWNER FOR
FUTURE REFERENCE.
AVISO PARA EL
INSTALADOR:
ENTREGUE ESTAS
INSTRUCCIONES AL
PROPIETARIO DE LA PARRILLA
PARA REFERENCIA FUTURA.
Portable 2 Burner Gas Grill
Parrilla a Gas Portátil
con 2 Quemadores
Model: 810-1201-S

1
WE WANT YOU TO ASSEMBLE AND USE YOUR GRILL AS SAFELY AS POSSIBLE.
THE PURPOSE OF THIS SAFETY ALERT SYMBOL IS TO ATTRACT YOUR
ATTENTION TO POSSIBLE HAZARDS AS YOU ASSEMBLE AND USE YOUR GRILL.
WHEN YOU SEE THE SAFETY ALERT SYMBOL
PAY CLOSE ATTENTION TO THE INFORMATION WHICH FOLLOWS!
READ ALL SAFETY WARNINGS AND INSTRUCTIONS CAREFULLY
BEFORE ASSEMBLING AND OPERATING YOUR GRILL.
IF INSTRUCTIONS OR PARTS ARE MISSING CONTACT CUSTOMER SERVICE
AT 1-800-527-0717 OR
IMPORTANT SAFETY
WARNINGS
IF YOU SMELL GAS:
1. Shut off gas to the appliance.
2. Extinguish any open ame.
3. Open Lid.
4. If odor continues, keep away from the appliance and immediately call your gas
supplier or your re department.
1. Never leave this appliance unattended while in use.
2. Never operate this appliance within 10 ft (3.0 m) of any structure, combustible
material or other gas cylinder.
3. Never operate this appliance within 25 ft (7.5 m) of any ammable liquid.
4. Heated liquids remain at scalding temperatures long after the cooking process.
Never touch cooking appliance until liquids have cooled to 115 ºF (45 ºC) or less.
5. If a re should occur, keep away from the appliance and immediately call your re
department. Do not attempt to extinguish an oil or grease re with water.
Failure to follow these instructions could result in re or explosion which could
cause property damage, personal injury or death.
DANGER
DANGER
a) DO NOT store a spare LP gas cylinder under or near this appliance.
b) Never ll the cylinder beyond 80% full.
c) If the information in (a) and (b) are not followed exactly, a re causing death or
serious injury may occur.
DANGER

2
FOR COVERS, ACCESSORIES AND OTHER PRODUCTS, PLEASE VISIT US ONLINE AT:
General Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
LP Gas Cylinder (Tank) Specications and Installation. . . . . . . . . . . . . . . . 4-6
Hose & Regulator Specications and Installation . . . . . . . . . . . . . . . . . . . . 6-7
Leak Testing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-8
Pre-start Check List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Lighting Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-10
Operating the Grill . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-11
Proper Care and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-13
Transporting and Storage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Trouble Shooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-16
Grill Cooking Tips. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Assembly Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17-20
Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Back Cover
DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.
WARNING: Be alert to the possibility of serious bodily injury if the instructions are not followed. Be sure to read and
carefully follow all of the messages.
CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.
CALIFORNIA PROPOSITION 65 WARNING
This product contains chemicals, including lead in the brass of certain component parts, that are
known to the State of California to cause cancer, and birth defects or other reproductive harm.
Wash hands after handling. When used, this product emits fuel combustion chemicals that are known
to the State of California to cause cancer, and birth defects or other reproductive harm.
Follow all instructions in this manual and use only in well ventilated, outdoor area.
TABLE OF CONTENTS:

3
WARNING
GENERAL WARNINGS:
• Leak test all connections before rst use, even if grill was purchased fully assembled and after
each tank rell. Check the propane tank rubber seal for damage.
• Always check the grill and propane tank prior to each use as indicated in the “Checking for
Leaks” & “Pre-Start Check List” sections of this manual.
• Never use natural gas in a unit designed for liquid propane gas.
• Never use charcoal, lava rocks or wood briquets in a gas grill. Flavoring chips must be
contained in a metal smoking box to contain ash and prevent res.
• Ensure ames come out of all burner ports at each use. Spiders and insects like to build nests
in burner tubes. Blocked burner tubes can prevent gas ow to the burners and could result in a
burner tube re or re beneath the grill.
• Never check for leaks using a match or open ame.
• Never use or store gasoline, lighter uid, paint thinner, or other ammable vapors and liquids or
combustible materials in or near your grill.
• DO NOT block ventilation areas in sides, back or cart compartment of grill.
• DO NOT cover cooking grates or other components with aluminum foil, as this blocks ventilation
and damage to grill or personal injury may occur.
• Keep children and pets away from hot grill. DO NOT allow children to use or play near this grill.
• DO NOT leave the grill unattended while ON or in use.
• DO NOT allow the gas hose to come in contact with hot surfaces. Redirect the gas hose if
necessary.
• DO NOT allow grease or hot drippings to fall on hose and regulator assembly. If this occurs, turn
gas supply OFF at once. Empty grease tray/cup and clean the hose and regulator assembly and
inspect for damage before use.
• Never cook on the grill without the grease cup/tray in position.
• Keep any electrical supply cords away from water or heated surfaces.
• DO NOT use water on a grease re. Closing the lid to extinguish a grease re is not possible.
Use type BC dry chemical re extinguisher or smother with dirt, sand or baking soda.
• DO NOT use while under the inuence of drugs or alcohol.
• FOR OUTDOOR USE ONLY. DO NOT operate indoors or in an enclosed area such as a garage, shed
or breezeway.
• Position your grill outdoors on a non-combustible level surface in a well ventilated location, a
safe distance 10 ft. (3.1 m) from combustible materials, buildings and overhangs.
• Apartment dwellers: Check with management and follow the requirements and re codes for using
an LP gas grill in your apartment complex. Only use outside on the ground (not on a balcony,
patio, garage, etc) with a 15 foot (4.6 m) minimum clearance on all sides from any wall, structure or
combustible material.
• Maintain a minimum clearance of 36 inches (91 cm) between all sides of grill, deck railings, walls or
other combustible material. Not adhering to these clearances may prevent proper ventilation and can
increase the risk of a re and/or property damage, which could also result in personal injury. DO NOT
use grill under overhead unprotected combustible construction.
• DO NOT use or install this grill in or on a recreational vehicle and/or boat.
• DO NOT build this model grill in any built-in or slide in construction.
• If a bristle brush is used to clean any of the cooking surfaces, ensure no loose bristles remain on the
cooking surfaces prior to grilling as loose bristles may attach to food.
• This appliance is not intended for and should never be used as a heater.
• DO NOT use any other regulator assembly other than the one supplied with your grill.
Replacement regulator assembly must be part No. 155-1201-0, which can be obtained by
contacting customer service at 800-527-0717.

4
LP GAS CYLINDER (TANK) SPECIFICATIONS AND INSTALLATION:
• Grill is hot when in use. To avoid burns:
• DO NOT attempt to move the grill.
• Wear protective gloves or oven mitts.
• DO NOT touch any hot grill surfaces.
• DO NOT wear loose clothing or allow hair to come in contact with grill.
• Not for commercial use. DO NOT use this grill for anything other than its intended purpose.
USE CAUTION AND COMMON SENSE WHEN OPERATING YOUR GAS GRILL.
FAILURE TO ADHERE TO THE SAFETY WARNINGS AND GUIDELINES IN THIS MANUAL
COULD RESULT IN SEVERE BODILY INJURY OR PROPERTY DAMAGE.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
WARNING
• ONLY connect this grill to a Type 1 cylinder valve. The Type 1 valve can be identied with the
large external threads on the valve outlet.
• DO NOT connect to a propane cylinder exceeding a 20 lb. (9.1 kg) capacity.
• DO NOT connect to a cylinder that uses any other type of valve connection device.
• Inspect the propane tank valve rubber seal for cracks, wear or deterioration prior to use. A
damaged rubber seal can cause a gas leak, possibly resulting in an explosion, re or severe
bodily harm.
• Turn off the cylinder valve when your grill is not in use.
• Handle the tank with care.
• Always secure the cylinder in an upright position.
• Never connect an unregulated LP gas cylinder to your grill.
• DO NOT expose LP gas cylinders to excessive heat or ignition sources.
• DO NOT store a spare LP gas cylinder under or near your grill.
• Allow only qualied LP gas dealers to ll or repair your LP gas cylinder.
• DO NOT allow the cylinder to be lled beyond 80% capacity.
• Read and follow all warnings and instructions that are on the cylinder and that accompany this
product.
• DO NOT store a spare LP gas cylinder (full or empty) under or near your grill. This could cause
excess pressure to be expelled through the vapor relief valve resulting in re, explosion, or
severe personal injury, including death.
• Propane gas is heavier than air and will collect in low areas. Proper ventilation is extremely
important. Keep the ventilation opening(s) of the LP gas cylinder enclosure free and clear from
obstructions and debris.
• DO NOT insert any foreign objects into the cylinder valve outlet as this could damage the
rubber seal. Do not use propane tank with a damaged rubber seal. A damaged rubber seal can
cause a gas leak, possibly resulting in explosion, re, severe bodily harm, or death. Inspect
rubber seal for cracks, wear or deterioration prior to use.
• Always keep cylinder (tank) in upright position during use, transit or storage.
DANGER

5
• Allow only qualied licensed LP gas dealers to properly ll or repair your LP gas cylinder.
• New tanks should be purged prior to lling; inform LP gas dealer if you are using a new tank.
• DO NOT allow the cylinder to be lled beyond 80% capacity. Over-lled tanks can create a
dangerous condition. Over-lled tanks can build-up pressure and cause the relief valve to expel
propane gas vapors. The vapor is combustible and if it comes in contact with a spark source or
ame an explosion causing severe burns, bodily harm, or death could occur.
• Always use a protective cylinder cap when grill is not connected to cylinder.
• If you exchange a cylinder with a qualied exchange program, the new cylinder must have
a Type 1 valve and an over-lling prevention device (OPD).
• Inspect the propane tank valve rubber seal for cracks, wear or deterioration prior to use. A
damaged rubber seal can cause a gas leak, possibly resulting in an explosion, re or severe
bodily harm.
FILLING THE LP GAS CYLINDER (TANK):
WARNING
LP GAS CYLINDER (TANK) SPECIFICATIONS:
LP gas cylinder (not supplied with this grill)
The LP (Liquid Propane) gas cylinder specically designed to be used with this grill must be 12” (30.5 cm)
diameter x 18” (45.7 cm) tall and have a 20 lb. (9.1 kg) capacity incorporating a Type 1 cylinder valve and
an over-lling protection device (OPD).
This grill is designed to t Worthington, Manchester or SMPC brand 20 lb. (9.1 kg) cylinders. Other brand
DOT cylinders may t this grill if the cylinder has similar dimensions of the top and bottom rings.
The installation of this appliance must be in accordance with:
All applicable local codes, or in the absence of local codes, either:
• National Fuel Gas Code ANSI Z223.1 NFPA 54
• Natural Gas and Propane Installation Code: CAN/CGA B149.1
• Natural Gas Installation Code: CAN/CGA B149.1 (Canada)
• Propane Installation Code: CAN/CGA B149.2 (Canada)
To check your local codes, see your local LP gas dealer or natural gas company. This grill was not
intended to be connected to a natural gas supply line. If an external electrical source is utilized, it must be
electrically grounded in accordance with local codes, or in the absence of local codes, with the National
Electrical Code, ANSI/NFPA 70, or the Canadian Electrical Code, CSA 22.1.
When purchasing or exchanging a cylinder for your gas grill, it must be constructed and marked in
accordance with the specications for LP gas cylinders of the U.S. Department of Transportation (DOT)
or the National Standard of Canada, CAN/CSA-B339 Cylinders, Spheres and Tubes for Transportation of
Dangerous Goods; and Commission, as applicable; and provided with a listed over-lling prevention device
(OPD), and provided with a cylinder connection device compatible with the connection for outdoor cooking
appliances.
The cylinder must also be equipped with:
• A shut-off valve terminating in a Type 1 gas cylinder valve outlet.
• A Type 1 valve that prevents gas ow until a positive seal is obtained.
• An arrangement for vapor withdrawal.
• A collar to protect the cylinder shut-off valve.
• A safety relief device having direct communication with the vapor space of the cylinder.
• A listed over-lling prevention device (OPD).

6
LP GAS CYLINDER (TANK) PLACEMENT:
• The
grill should be installed with the hose regulator
assembly extended at full length of hose directly
(24” [61cm] minimum) away from the burner. When
so congured, placement results in maximum
tank to grill distance. When the grill is operated,
the hose / regulator and gas tank should be on a
line perpendicular to wind direction. Placing tank
closer than 24” (61cm) to the grill can overheat the
tank and cause release of propane through relief
openings and can result in tank re or explosion.
WARNING: The hose to tank attachment can result in a
potential trip hazard and tank tipping hazard -
use caution.
• Inspect the propane tank valve rubber seal for cracks,
wear or deterioration prior to use. A damaged rubber
seal can cause a gas leak, possibly resulting in an
explosion, re or severe bodily harm.
• Inspection should be done each time the propane tank
is connected to the grill, has been relled, exchanged or
has not been used for more than 60 days.
• Do not use a propane tank with a damaged rubber seal.
Exchange the tank or have the rubber seal replaced at a
qualied propane lling station.
LP GAS CYLINDER (TANK) RUBBER SEAL INSPECTION:
Good
Rubber Seal Damaged
Rubber Seal
HOSE & REGULATOR SPECIFICATIONS AND INSTALLATION:
• DO NOT attempt to connect grill, as purchased for LP (propane) gas, to any other fuel supply
source such as a natural gas line. For dual fuel grills that can be converted to natural gas, a
Brinkmann conversion kit must be purchased and installed for use with natural gas. Please
contact Brinkmann Customer Service at 800-527-0717 to see if your grill can be converted.
• DO NOT use any other pressure regulator/hose assembly other than the one supplied with your grill.
Replacement pressure regulator/hose assembly must be part No 155-1201-0, which can be obtained
by contacting customer service at 800-527-0717.
• DO NOT attempt to adjust or repair a regulator. The regulator is designed to operate at a
maximum output pressure of 11 inches of water column (2.74 kPa).
• Ensure the tank valve is CLOSED prior to connecting the LP gas cylinder to your grill. Turn the
valve knob clockwise to properly close the valve. Read and follow all instructions and warnings
on the supply hose safety tags. Read and follow all warnings in this manual concerning the safe
use of LP gas cylinders and the hose and regulator before connecting cylinder to grill. Read and
follow all warnings on the LP cylinder.
WARNING
24” min
(610mm)
WIND

7
HOSE AND REGULATOR:
Your grill is equipped with a Type 1 connection device with the following features:
1. The system will not allow gas ow from the cylinder until a positive connection to the valve has been made.
Note: The cylinder valve and all grill burner knobs must be turned OFF before any connection is made or
removed.
2. A regulator ow limiting device, when activated, restricts the ow of gas to 10 cubic feet per hour. If the
ow limiting device is activated, perform Regulator Resetting Procedure.
Note: If your grill will not get hot enough to cook, the ow limiting device may have been activated.
CONNECTING HOSE AND REGULATOR:
1. Inspect the propane tank valve rubber seal for cracks, wear or
deterioration prior to use. A damaged rubber seal can cause a gas
leak, possibly resulting in an explosion, re or severe bodily harm. Do
not use a propane tank with a damaged rubber seal.
2. Attach or detach regulator to the LP gas cylinder only when cylinder is
at rest in tank holder.
3. Check that the cylinder valve is closed by turning the knob clockwise.
4. Check that the grill’s burner control knobs are in the “OFF” positions.
5. Visually inspect the hose assembly prior to each use for evidence of damage, excess wear, or
deterioration. If found, replace the assembly before using your grill. Only the manufacturer’s supplied
replacement should be used.
6. Remove the protective plastic cap from the cylinder valve.
7. Check that the hose does not contain kinks, does not contact sharp edges, and does not contact
surfaces that may become hot during use.
8. Hold regulator and insert the brass nipple into the LP cylinder valve outlet. Ensure that the device is
centered properly.
9. Turn the large coupling nut clockwise by hand and tighten to a full stop. Take care not to cross thread
the coupling nut onto the cylinder valve. Do not use tools to tighten connection.
Note: If you are unable to make the connection, repeat Steps 7 and 8.
10. Leak check all ttings before lighting your grill. See section on “Leak Testing” in this manual.
REGULATOR RESETTING PROCEDURE:
If your grill will not get hot enough to cook, the ow limiting device may have been activated.
Mini Reset:
Turn ALL burner control knobs to “OFF”, turn off the cylinder valve. Wait one minute. Slowly turn
cylinder valve ON and relight grill. If burner ame is higher and grill heats up properly – proceed with
cooking.
Full Reset:
Turn ALL burner control knobs to “OFF”, turn off the cylinder valve. Disconnect hose and regulator from
cylinder. Wait two minutes, reattach hose and regulator and perform leak test.
WARNING
• Never use your grill without leak testing all gas connections, hoses and propane tank. Follow
the section on “Leak Testing” in this manual for proper procedures.
LEAK TESTING:
Inspect Rubber Seal (see page 6)

8
WHEN TO PERFORM A LEAK TEST:
• After assembling your grill and before lighting for the rst time, even if purchased fully assembled.
• Every time the LP gas cylinder is relled, exchanged or if any of the gas components are disconnected or
replaced.
• Any time your grill has been moved.
• At least once per year or if your grill has not been used for more than 60 days.
CHECKING FOR LEAKS:
CAUTION: Strong odors, colds, sinus congestion, etc. may prevent the detection of propane by smell.
Use caution and common sense when testing for leaks.
Note: The leak test must be performed in an area that has adequate lighting in order to see if bubbles are
developing and not in a windy or noisy area so larger leaks can be detected by smell or sound.
1. Create a mixture of 50% water and 50% liquid dishwashing soap.
2. Open the lid.
3. Ensure all control knobs are set to the “OFF” position.
4. Turn on the gas at the cylinder valve. Turn the cylinder valve knob counter-
clockwise to full open. If you hear a rushing sound or smell gas, turn the gas
off. Tighten any leaking connections. If leak is detected at connection nut and
tightening does not stop leak, reinspect propane tank rubber seal.
5. Apply the soapy water mixture to the following:
Supply tank (cylinder) welds.
Connection nut to tank valve.
Back side of connection nut to brass nipple.
Brass nipple connection into regulator.
Regulator connections to gas supply hoses.
Hose connection to gas manifold.
The full length of gas supply hose.
Tank valve to cylinder.
6. Check each place listed (A–H) for growing bubbles, which indicates a leak. Large
leaks may not be detected by bubbles but should produce
a rushing sound or gas smell.
7. Turn off gas supply at cylinder valve.
8. Turn on control knobs to release gas pressure in hose.
9. Turn control knobs to “OFF” position.
10. Tighten any leaking connections. If leak is detected at connection nut and
tightening does not stop leak, reinspect propane tank rubber seal. (see page 6)
11. Repeat soapy water test until no leaks are detected.
12. Turn off gas supply at cylinder valve until you are ready to use your grill.
13. Wash off soapy residue with cold water and towel dry.
14. Wait 5 minutes to allow all gas to evacuate the area before lighting grill.
WARNING: DO NOT use the grill if leaks cannot be stopped. Contact a qualied gas appliance repair service.
To prevent re or explosion hazard:
• DO NOT smoke or permit ignition sources in the area while conducting a leak test.
• Perform test OUTDOORS in a well ventilated area that is protected from the wind.
• Never perform a leak test with a match or open ame.
• Never perform a leak test while the grill is in use or while grill is still hot.
A
B
C
D
E
F
G
H
Watch For Bubbles
DANGER
A
B
C
D
E
F
G
H

9
LIGHTING THE MAIN BURNERS:
1. Open lid before lighting burner.
2. Make sure all control knobs are in the “OFF” position.
3. Push and hold down the IGNITION BURNER control knob and
turn SLOWLY (2 to 3 seconds) to “HIGH”. You should hear the
igniter click.
Note: Step 3 may need to be repeated 2-3 times to light grill.
4. If ignition does NOT occur in 5 seconds, turn control knob to “OFF”, wait 5 minutes to allow gas to
dissipate and repeat lighting procedure.
WARNING
DANGER
Property damage, bodily harm, severe burns, and death could result from failure to follow these
safety steps. These steps should be performed after the grill has been assembled and prior to
each use. DO NOT operate this grill until you have read and understand ALL of the warnings and
instructions in this manual.
• Ensure that the grill is properly assembled.
• Inspect the gas supply hose for burns, chaffing, kinks, and proper routing before each use. If it is
evident there is excessive abrasion or wear, or the hose is cut, it must be replaced prior to the grill
being used. Replace with hose and regulator Model No. 155-1200-0, which can be obtained by
contacting customer service at 800-527-0717.
• Leak check all gas connections, hose and propane tank. See section on “Leak Testing”.
• Ensure that all electrical supply cords are properly grounded. Keep any electrical supply cord and the
fuel supply hose away from any heated surfaces. Hose should be at least 3 inches from hot surfaces.
• Position your grill on a non-combustible level surface in a well ventilated location, a safe distance
10 ft. (3.1 m) from combustible materials, buildings and overhangs.
• Properly place the empty grease cup under the grease drain hole in the bottom of the grill to catch
grease during use.
• DO NOT block ventilation areas in sides, back or cart compartment of grill.
PRE-START CHECK LIST:
LIGHTING INSTRUCTIONS:
Read, understand and follow all warnings and instructions contained in this manual. DO NOT skip any
of the warnings and instructions contained in the preceding sections of this manual.
Follow the instructions exactly.
1. OPEN THE GRILL LID before attempting to light a burner so that fumes do not accumulate inside
the grill. An explosion could occur if grill lid is down.
2. Check that all burner control knobs and the cylinder valve are turned to the “OFF” position.
3. Turn on the fuel supply by slowly rotating the cylinder valve knob counter-clockwise to full open.
4. DO NOT stand with head, body, or arms over the grill when lighting.

10
5. To light other burners, push and turn control knobs to “HIGH”. Follow Step 4.
6. If burner does not ignite using the igniter, wait 5 minutes, see “Match Lighting the Main Burners” section.
7. To turn off, turn each control knob clockwise until it locks in the “OFF” position. This does not turn off the
gas ow from the cylinder.
Note: If burner does not light or ame is too low, See “Trouble Shooting” section of the owners manual.
MATCH LIGHTING THE MAIN BURNERS:
1. Open lid before lighting burner.
2. Make sure all control knobs are in the “OFF” position.
3. Place a paper match in the end of the matchlighter. Strike the match and
place through lighting hole in the left hand side of the grill to approximately
1/2” (1 to 2 cm) from the burner.
4. Turn on the FAR LEFT burner control knob to the “HIGH” position.
The burner should light within 5 seconds.
5. If the burner does not light, turn the control knob to “OFF” and wait
5 minutes for gas to evacuate the grill. Repeat Steps 1 through 5 until
the burner ignites.
6. To light other burners, push and turn control knobs to “HIGH”
in sequence from left to right. Follow Step 5.
7. If the burner does not light within the rst few attempts of match lighting, there is a problem with the gas
supply. Turn off the gas at the burner and cylinder. DO NOT attempt to operate the grill until the problem
is found and corrected. See “Trouble Shooting” section of this manual.
Note: If burner does not light or ame is too low, See “Trouble Shooting”
section of the owners manual.
Note: Observe ame height when lit: Flame should be a Blue/Yellow
color between 1”–2” when burner is on “HIGH”.
See section in manual on burner adjustment to adjust ame.
Lighting Hole
Matchlighter
• Read and follow all warnings and instructions contained in the preceding sections of this
manual.
• Never use charcoal, lava rocks or wood briquets in a gas grill. Flavoring chips must be
contained in a metal smoking box to contain ash and prevent res.
• DO NOT cover cooking grates or other components with aluminum foil, as this blocks
ventilation and damage to grill or personal injury may occur.
• DO NOT leave your grill unattended while “ON” or in use.
• DO NOT move grill when in use.
• DO NOT use water on a grease re. Closing the lid to extinguish a grease re is not possible.
Use type BC dry chemical re extinguisher or smother with dirt, sand or baking soda.
• Never cook on the grill without the grease cup/tray in place.
WARNING
OPERATING THE GRILL:

11
TURNING OFF THE GRILL:
1. Turn off the cylinder valve.
2. Turn all burner control knobs to the “OFF” position.
Note: Turn off LP cylinder rst to prevent gas from being left in the system under pressure.
CAUTION:
• The cylinder valve should always be in the off,
or closed, position when the grill is not in use.
To turn off the cylinder valve,
turn knob clockwise until it stops.
BREAKING IN YOUR GRILL:
• In manufacturing and preserving the components of your grill, oil residue may be present on the
burners and cooking surfaces of your grill.
• Before cooking on your grill for the rst time you should preheat it for 15 minutes on “HIGH” to burn off
these residual oils.
PREHEATING THE GRILL:
• Prior to each use, it is recommended that you preheat your grill. This ensures that the grilling surfaces
are at the desired temperatures to sear the food sugars when cooking. After lighting your grill, set the
main burner control knobs to the “HIGH” position for 5 to 10 minutes. Close the lid during the preheat
period.
CONTROLLING FLARE-UPS/GREASE FIRES:
• Flare-ups are a part of cooking meats on a gas grill. This adds to the unique avor of cooking on a gas
grill. Use caution when opening the lid as sudden are-ups may occur. Excessive are-ups can over-
cook your food and cause a dangerous situation for you and your grill. Excessive are-ups result from
the build-up of grease in your grill. If this should occur, DO NOT pour water onto the ames. This can
cause the grease to splatter and could result in serious burns or bodily harm.
• If grease re occurs while lid is open, leave lid open, turn burner knobs to “OFF”, turn off LP cylinder
valve. If possible, relocate food to a different section of cooking grate and allow grease to burn out or
smother the ames with baking soda.
• If grease re occurs while lid is closed, leave lid closed, as a sudden burst of air may increase ames.
Turn burner knobs to “OFF”, turn off LP cylinder valve. Allow grease to burn out.
• Never pour water on a grease re as grease may splatter/spread and could result in bodily injury or
property damage.
• If grease re does not quickly burn out or the re is growing/spreading, use type BC dry chemical re
extinguisher or smother with dirt, sand or baking soda. Closing the lid to extinguish a grease re is not
possible.
TO MINIMIZE FLARE-UPS:
• Trim excess fat from meats prior to cooking.
• Cook meats with high fat contents (chicken or pork) on Low settings or indirectly.
• Ensure that your grill is on level ground and the grease is allowed to evacuate the grill through the
drain hole in the bottom and into grease cup/tray.
• Clean grill frequently to minimize grease buildup.
INDIRECT COOKING:
• Indirect cooking is the process of cooking your food without the heat source being directly under your
food. You can sear meats over a high ame on one side of the grill while slow cooking a roast on the
other (unlit) side of the grill.

12
WARNING: If a bristle brush is used to clean any of the cooking surfaces, ensure no loose bristles remain
on the cooking surfaces prior to grilling as loose bristles may attach to food.
CLEANING INTERIOR OF GRILL:
• We recommend cleaning off food residue immediately after cooking by gently scrubbing grates with wire bristle
brush and then turning burners to “HIGH” for approximately 5 minutes.
WARNING: DO NOT leave grill unattended when grill is on. Wear oven mitts to protect from burns.
• The heat from the burners will burn off most food/grease residue from grates & heat tents and turn it to an ash like
substance which will fall to the bottom of the rebox or grease tray. After the grill cools (approximately 30 minutes)
remove grates and heat tents and brush the ash and any grease out of the rebox. Clean and replace grease cup.
Inspect the heat tents for damage or deterioration before reinstalling in the grill. (Replacements can be ordered by
calling 800-527-0717.)
• Wash the grates and heat tents with a mild detergent and rinse with hot water periodically if desired.
CAUTION: DO NOT allow ash residue to remain on the grease tray or rebox as it could block proper grease
drainage of the grill.
INTERIOR OF GRILL LID:
• Smoke will accumulate inside grill lid and may ake onto your food. Clean the inside of the grill lid with scrub brush
and baking soda/water solution. Dry thoroughly. Do not mistake this for paint. The interior of gas grill lids are not
painted.
MAINTAINING EXTERIOR OF GRILL:
• To protect your grill from excessive rust, the unit must be kept clean and covered at all times when not in use.
• Painted surfaces. Wash with mild detergent or non-abrasive cleaner and warm soapy water.
• Stainless steel surfaces. To maintain your grill’s appearance, wash with mild detergent and warm soapy water and
wipe dry with a soft cloth after each use. Baked-on grease deposits may require the use of an abrasive plastic
cleaning pad. Use only in direction of brushed nish to avoid damage. Do not use abrasive pad on areas with
graphics. Car wax may help protect the exterior nish of your grill.
• Porcelain surfaces. Because of glass-like composition, most residue can be wiped away with a solution of baking
soda and water or specially formulated cleaner. Use non-abrasive scouring powder such as baking soda for
stubborn stains.
• Plastic and rubber parts. Wash with warm soapy water and wipe dry. Do not use citrisol, abrasive cleaners,
degreasers or a concentrated grill cleaner on plastic parts. Damage to and failure of parts can result.
RUST:
• Discoloration, rust and rust pits can occur as a result of high cooking temperatures, acidic marinades, grease res
and exposure to coastal climates or other natural elements.
• Rust spots on the interior surface can be buffed, cleaned, then lightly coated with vegetable oil or vegetable oil spray
to minimize rusting.
• Never use cleaners containing chlorine or store swimming pool supplies or chemicals in cart compartment as
chlorine promotes rust.
PROPER CARE & MAINTENANCE:
BURNER CLEANING AND MAINTENANCE:
• Keep the appliance free and clear of combustible materials, gasoline and other ammable vapors and liquids.
• Keep the ventilation openings of the cylinder enclosure free and clear of debris.
• Visually check burner ames for proper operation (see pictorial in “Burner Assembly/Maintenance” under Proper Care
and Maintenance). Spiders or other insects can nest in the burner causing gas blockage.
• For safe grilling and peak performance of your grill, perform these checks at least twice per year or after extended
periods of storage.
• Be sure to tighten up all hardware (nuts, bolts, screws, etc.) at least twice per year.
CAUTION: Some parts may contain sharp edges. Wear protective gloves if necessary.
• Remove the cooking grills, heat distribution plates, and burners from inside your grill. Use a brush with hot water
and detergent to remove excess residue. NEVER use a commercial oven cleaner. Rinse completely with water.
Towel dry and replace all components as described in the assembly instructions.

13
BURNER ASSEMBLY/MAINTENANCE:
• Although your burners are constructed of stainless steel,
they may corrode as a result of the extreme heat and acids
from cooking foods. Regularly inspect the burners for cracks,
abnormal holes, and other signs of corrosion damage. If found,
replace the burner.
• DO NOT block ventilation areas in sides, back or cart
compartment of grill. Burner tubes can become blocked by
spiders and other insects building their nests. Blocked burner
tubes can prevent gas ow to the burners and could result in
a burner tube re or re beneath the grill. To clean the Burner
Assembly follow these instructions to clean and/or replace parts
of burner assembly or if you have trouble igniting the grill.
1. Turn gas off at control knobs and LP cylinder tank valve.
2. Remove cooking grills and heat distribution plates.
3. Remove cotter pin from each burner post and remove post.
4. Remove screws connecting crossover channel and burners.
5. Carefully lift each burner up and away from valve openings.
6. Use a narrow bottle brush or a stiff wire bent into a small hook
to run through each burner tube or use compressed air to blow
into burner tube and out the ame ports. Check each port to
make sure air comes out each hole.
CAUTION: Wear eye protection when using compressed air.
7. Use a wire brush to clean the entire outer surface of burner to
remove food residue and dirt.
8. Check burner for damage, if any cracks or holes are
found replace burner.
9. Install burner in grill and carefully align crossover channel
between burners and orient burners CORRECTLY.
IMPORTANT: Burner opening must slide over valve nozzle.
10. Replace cotter pins to each burner and reconnect crossover
channel.
Note: Follow the “Gas Leak Testing” section
of this manual. Relight burners to verify
proper operation.
11. Replace heat distribution plates and cooking grills.
PROPER VALVE TO BURNER ALIGNMENT
Valve Nozzle
Burner Opening
Debris
Crossover
Channel
Post
Screw
Cotter
Pin

BEFORE STORING YOUR GRILL:
• Ensure that the cylinder valve is fully closed.
• Clean all surfaces. Lightly coat the burners with cooking oil to prevent excess rusting.
• If storing the grill indoors, disconnect the LP tank and leave the LP tank OUTDOORS.
• Place dust cap on cylinder valve outlet whenever the cylinder is not in use. Only install the type of dust cap on the
cylinder valve outlet that is provided with the cylinder valve. Other types of caps or plugs may result in leakage of
propane.
• Check and clean burner prior to use after storing, at the beginning of grilling season or after a period of not being
used. Spiders and insects like to build nests in burner tubes (especially during colder months). Blocked burner
tubes can prevent gas ow to the burners and could result in a burner tube re or re beneath the grill. See “Burner
Assembly/Maintenance” under “Proper Care and Maintenance”.
• If storing the grill outdoors, cover the grill with a grill cover for protection from the weather.
• Never move a grill when hot or in use.
• Make sure that cylinder valve is closed and burner knobs are in the off position.
• DO NOT store a spare LP gas cylinder (lled or empty) under or near the grill.
• Never store ammable liquids or spray canisters under or near the grill.
• If the outdoor cooking gas appliance is not in use, the gas must be turned off at the LP gas
supply cylinder.
• Storage of an outdoor cooking gas appliance indoors is permissible only if the cylinder is
disconnected and removed from the outdoor cooking gas appliance.
• Cylinders must not be stored in a building or enclosure, including garages and sheds.
• Cylinders must be kept out of reach of children.
WARNING
TRANSPORTING AND STORAGE:
14

15
TROUBLE SHOOTING:
Problem Possible Cause Prevention/Cure
Burner will not light LP gas tank valve is closed Make sure regulator is securely attached to the LP gas tank, turn LP
gas tank valve to “OPEN”
LP gas tank is low or empty Check if LP gas tank is empty. If empty, replace or rell.
LP gas leak 1. Turn LP gas tank valve to “CLOSED”
2. Wait 5 minutes for gas to clear
3. Follow “Leak Testing” in the owner’s manual
Coupling nut and regulator not fully connected See section on “Connecting Hose and Regulator”
Obstruction of gas ow 1. Clean burner assembly
2. Check for bent or kinked hose
Burner may not be properly seated Reseat burner and valve. Refer to “Burner Assembly/Maintenance”
instructions
Spider webs or insect nest in venturi Clean venturi and burner assembly
Burner ports clogged or blocked Clean burner ports
Battery needs to be changed Replace the battery (follow assembly step for inserting battery)
Wires or electrode covered with cooking residue Clean wire and/or electrode with rubbing alcohol
Electrode and burners are wet Wipe dry with cloth
Electrode cracked or broken - sparks at crack Replace electrode
Wire loose or disconnected Reconnect wire or replace electrode/wire assembly
Wire is shorting (sparking) between ignitor and
electrode
Replace ignitor wire/electrode assembly
Bad ignitor Replace ignitor
Grill does not get hot
enough
Out of gas Replace or rell LP gas tank
Flow limiting device may have been activated 1. Mini Reset:
a.Turn control knobs and LP gas tank valve to “OFF”
b. Wait one minute and relight grill per “Lighting Instructions”
2. If ames are still too low, perform a Full Reset
Full Reset:
a.Turn control knobs and LP gas tank valve to “OFF”
b. Disconnect regulator from propane tank
c. Inspect LP cylinder rubber seal
d. Wait 1 minute
e. Reconnect regulator and perform “Leak Testing” on all
connections.
f. Light grill per “Lighting Instructions”
Irregular ame pattern.
Flame does not run full
length of burner
Burner ports are clogged or blocked
Air shutter on burner needs adjustment
Clean burner ports
See section on “Burner Adjustment”
Flame is yellow or orange New burner may have residual manufacturing
oils
Burn grill for 15 minutes on “HIGH” with the lid closed
Spider webs or insect nest in venturi Clean venturi and burner assembly
Food residue, grease, etc. Clean burner assembly
Poor alignment of valve to burner venturi
Air shutter on burner needs adjustment
Make sure burner venturi is properly engaged with valve
See section on “Burner Adjustment”
To see trouble shooting or assembly videos, visit us at:

16
Problem Possible Cause Prevention/Cure
Flame blows out High or gusting winds Do not use grill in high winds
Low on LP gas Replace or rell LP gas tank
Burner holes may be obstructed Refer to “Burner Assembly/Maintenance” instructions
Flow limiting device tripped Refer to “Regulator Resetting Procedure”
Flare-up Grease buildup Clean all grill parts per “Proper Care and Maintenance” instructions
Excess fat in meat Trim fat from meat before grilling
Excessive cooking temperature Adjust (lower) cooking temperature
Grease re Grease trapped by food buildup around burner
system
1. Turn control knobs and LP gas tank valve to “OFF”
2. Leave lid in open or closed position and let re burn out. Use BC
type re extinguisher or baking soda, sand or dirt to smother re,
if necessary.
3. After grill cools, remove and clean all parts per “Proper Care and
Maintenance” instructions
Flashback (re in burner
tubes) / knobs melting
Burner and/or burner tubes are blocked Clean burners and/or burner assembly
Inside of lid is peeling
(like paint peeling)
Baked on grease buildup has turned into carbon
and is aking off
Clean thoroughly per “Proper Care and Maintenance” instructions
GRILL COOKING TIPS:
CLEANLINESS:
• Always wash hands thoroughly with soap and hot water prior to handling food and after handling raw
meat, uncooked poultry or seafood.
• When using a platter to carry raw meat, uncooked poultry or seafood to the grill, make sure to wash
the platter thoroughly with soap and hot water before placing cooked foods back on the platter or use
different platters for raw and cooked foods.
• Never use the same utensils when handling raw meat, uncooked poultry or seafood unless you wash
the utensils thoroughly with soap and hot water.
• Never re-use marinade from raw meat or uncooked poultry on foods that have been cooked and are
ready to be served.
GRILLING TO PROPER TEMPERATURE:
• Use a meat thermometer to be sure food has reached a safe internal temperature.
• The USDA recommends the minimum temperature be reached for the following food items:
HELPFUL HINTS:
• If you pre-cook meat or poultry, do so immediately before grilling.
• Never defrost meat at room temperature or on a countertop.
• Refrigerate leftovers within 2 hours of taking food off the grill.
• For additional information, please phone the USDA’s toll free Meat & Poultry Hotline at 800-535-4555.
Chops . . . . . . . . . . . . . . . . . . . 145° F (62.8° C)
Ground Meat . . . . . . . . . . . . . . 160° F (71° C)
Pork . . . . . . . . . . . . . . . . . . . . . 145° F (62.8° C)
Poultry . . . . . . . . . . . . . . . . . . . 165° F (73.9° C)
Roasts . . . . . . . . . . . . . . . . . . . 145° F (62.8° C)
Seafood . . . . . . . . . . . . . . . . . . 145° F (62.8° C)
Vegetables. . . . . . . . . . . . . . . . 145° F (62.8° C)

17
PARTS LIST:
1 Grill Body Assembly
2 Heat Distribution Plates
2 Knobs
1 Large Cooking Grate
1 Small Cooking Grate
1 Griddle
1 Grease Tray
1 Hook
1
2
3
4
5
6
READ ALL SAFETY WARNINGS & ASSEMBLY INSTRUCTIONS CAREFULLY
BEFORE ASSEMBLING OR OPERATING YOUR GRILL.
WE RECOMMEND TWO PEOPLE WORK TOGETHER WHEN ASSEMBLING THIS UNIT.
To see trouble shooting or assembly videos, visit us at:
FOR COVERS, ACCESSORIES AND OTHER PRODUCTS, PLEASE VISIT US ONLINE AT:
Inspect contents of the box to ensure all parts are included and undamaged.
1
2
45
6
7
7
8
3
8
ASSEMBLY INSTRUCTIONS:

18
Choose a good, cleared assembly area
and get a friend to help you put your
grill together. Lay cardboard down to
protect grill nish and assembly area.
CAUTION: Some parts may contain
sharp edges. Wear
protective gloves if
necessary.
Step 1
Unfold legs into place. Insert burner
control knobs onto valve stems.
Step 2
Release hood latch and open hood.
Step 3
Insert heat distribution plates on
brackets over burners.

19
Step 4
Place cooking grates directly above
heat distribution plates.
Note: When using griddle, griddle will
replace small cooking grate.
Do not overheat or use metal
utensils that will scratch the
griddle’s coating.
Step 5
Insert grease tray on tracks
underneath the grill
