Briteq BT-AKKUZOOM User manual

1 PRODUCT SPECIFICATIONS
1.1 TECHNICAL SPECIFICATIONS
LED MODULE
Dimensions
LED MODULE:
Voltage
Power
Weight
270x160x160mm
4.5Kg
24VDC
40W
Operation Temperature 0℃~35℃(operating)
0℃~35℃(startup)
IP 44
IP Rating
1.2 DIMENSIONS
4pcsx10W（RGBW 4 in 1 LED）
Zoom Range
7~60º
Type of bettery Lithium Battery
PAGE: 01
BT-AKKUZOOM

1.3 SAFETY WARNING
IMPORTANT
【ALWAYS READ THE USER MANUAL BEFORE OPERATION. 】
【PLEASE CONFIRM THAT THE POWER SUPPLY STATED ON THE PRODUCT IS THE
SAME AS THE MAINS POWER SUPPLY IN YOUR AREA.】
● This product must be installed by a qualified professional.
● Always operate the equipment as described in the user manual.
●A minimum distance of 0.5m must be maintained between the equipment and combustible surface.
● The product must always be placed in a well ventilated area.
● Always make sure that the equipment is installed securely.
● Do not stand close to the equipment and stare directly into the LED light source.
● Always disconnect the power supply before attempting maintenance.
●Always make sure that the supporting structure is solid and can support the combined weight of the
products.
● The earth wire must always be connected to the ground.
● Do not touch the power cables if your hands are wet.
ATTENTION
● Do not operate in a sealed enclosure with insufficient air flow
● Do not operate in an environment with temperatures in excess of 45deg. C.
● Do not operate store in close proximity to source of fire.
● Always charge with supplied charger
● Do not charge for more than 24 hours
● Always turn off battery storage switch when storing for longer than 7 days
● Always store with full load
● Always charge with flightcase open
● Always carry out one full discharge and charge cycle every 3 months
● Always store in a dry environment away from direct sunlight
2.1 OPERATING POSITION
2GETTING STARTED
● This lighting fixture is powered using a Lithium Battery which requires that the
correct product orientation is always maintained for operation.
PAGE: 02
BT-AKKUZOOM

ZOOM RANGE (7~60º)
2.2 BATTERY CHARGING INPUT
12
Charger +ve
Charger -ve
Battery charging input
BATTERY CHARGING INPUT
● Do not connect DMX
● Only for specified charger(in flight case or single charger)
● Do not connect any other data cables
Zoom Range 60º Zoom Range 7º
PAGE: 03
BT-AKKUZOOM

2.3 GENERAL OPERATION
Power Status
2.3.1 POWER STATUS
● During operation, the Power Status indicator will indicate the amount of battery power that is remaining.
The battery should be recharged when RED is shown.
● During charging, the Power Status indicator will indicate the amount of battery power that has been
charged to the battery. When the battery is fully charged the GREEN LED will immediately switch off.
● In the event that the battery storage switch is OFF, it is not possible to charge the battery. In this case, when
the mains power is connected to the fixture, the Power Status indicator will show GREEN for 30 seconds and
then fade out. This shows that electrical contact has been made between the lighting fixture and the battery
charging system. The Battery Storage Switch must be ON in order to charge the battery.
● In order to check the current status of the battery, the battery charging system should be turned OFF. The
fixture can then be turned ON using the EVENT ON/OFF button and the Power Status can be checked.
GREEN: >70%
YELLOW: >20%
RED: EMPTY
2.3.2 ON/OFF SWITCH
2.4 OTHER OPERATIONS
● Press the SWITCH ON/OFF button for 3 seconds to turn on/off lighting fixture (when BATTERY SWITCH is ON)
● SWITCH ON/OFF button indicator LED when showing constant RED indicates lighting fixture is power ON
(when slowly flashing indicates that DMX data is successfully received)
1
2
3
BATTERY CHARGER INPUT
DISPLAY
2.4.1 ANTENNA RELEASE
● When releasing support antenna with hand
2.4.2 BATTERY SWITCH
● ON for operation/charging
OFF for storage (>7 days)●
OFF for maintenance●
● Always use the Battery Switch when storing for more than 7 days
● Battery Switch must be ON for operation and charging
BATTERY SWITCH
ON/OFF Switch
Zoom Knob
IR Receiver
PAGE: 04
BT-AKKUZOOM

RUN DMX
SLAV
AT.01
AT.10
AUTO
PR.01
PR.10
D.(001~512)
ADDR
TOUR
ARC.1
AR1.D
ARC.2
MENU
RED
GREN
BLUE
R.(0~255)
G.(0~255)
B.(0~255)
STRB
S.(0~20)
STAT
PERS
AR2.D
SET
UPLD
REST
RGBW
COLOR
DIM1
DIM3
DIM2
DIM4
DIM
UC
OFF
OF F
AR2.S
PASS
PASS
SEND END
REST END
PR.01
PR.10
SC.01
SC.30
RED
GREN
BLUE
STRB
TIME
FADE
EDIT
KEY ON
OFF
R.(0~255)
G.(0~255)
B.(0~255)
S.(0~20)
T.(0~255)
F.(0~255)
NORM
LIFE LONG
3.1 BASIC
3 USING THE MENU
The LED fixture is mounted with a LCD display
And 4 control buttons.
enter the currently selected menu or confirm the current function value
scroll 'UP' through the menu list or increase the value of the current function
scroll 'DOWN' through the menu list or decrease the value of the current function
scroll through the main menu or return to the main menu
MENU
ENTER
3.2 MENU
ENTER UP DOWN
MENU
Tr16
HSV
WHITE W.(0~255)
WHITE
B.(0~255)
Cv1
Cv3
Cv2
OFF
CURV
OF F
BLAK
SAVE
DERR
OF F
ON
OFF
SLCK
OF F
CLAS
SPEC
STRB
PAGE: 05
BT-AKKUZOOM

3.3 EDIT STATIC COLOUR
【STATIC COLOUR】
● Combine 【Red】, 【Green】,【Blue】and【White】 to create an infinite
range of colors (0-255)
● Set the value of the 【Strobe】 (0-20Hz)
MENU Red
Green
Blue
(0~255)
(0~255)
(0~255)
White (0~255)
STAT
3.4 ACTIVATING AUTO PROGRAMS
【AUTO】
● Select the target【AUTO】 program and press【ENTER】.
● Programs【AT.01】to【AT.10】are fully pre-programmed and will not be
altered by changes in【EDIT 】mode.
● Programs 【PR.01】to【PR.10】are fully pre-programmed and can be edited
in 【EDIT 】mode.
AT.01
AT.10
AUTO
PR.01
PR.10
MENU
3.5 DMX512 SETTINGS
【DMX】
● Enter the【DMX】mode to set the DMX ADDRESS.
D(001~512)
DMX
MENU
【RUN 】
● Enter the【RUN 】mode to set working mode.
● 【DMX】 mode is for using the DMX512 controller to control the fixtures.
● 【SLAV】 mode is for Master -- Slave operation.
3.6 RUN MODE
RUN DMX
SLAV
MENU
Strob (0~20)
WH.01
WH.11
RED
GREN
BLUE
R.(0~255)
G.(0~255)
B.(0~255)
CAL1
RGB.W RED
GREN
BLUE
R.(0~255)
G.(0~255)
B.(0~255)
CAL2
ACTI ON
OFF
WDMX
REST NO
YES
****
CAL
OK
ACTI ON
OFF
WDMX
REST NO
YES OK
PAGE: 06
BT-AKKUZOOM

3.7 PERSONALITY
【PERSONALITY】
● Enter the【PERSONALITY】mode to select DMX mode:【TOUR】,【TR16】,
【ARC.1】,【AR1.D】,【ARC.2】,【AR2.D】,【AR2.S】or【HSV】
TOUR
ARC.1
AR1.D
PERS
HSV
BLOC
MENU
3.8 SPECIAL SETTINGS
【SETTING】
【KEY】
● Enter the【KEY】mode to select whether the access password is on or off.
● When the fixture is set as PASS 【ON】, after 30 seconds or turn on the fixture
next time, the fixture will need an access password to enter the display menu
control.
Note: The factory access password is【UP】+【DOWN】+【UP】+【DOWN】,
then press 【ENTER】to confirm the access.
● Select【UPLD】to upload the custom programs from the current MASTER unit to
the SLAVE units.
● In order to activate the upload function the password must be entered.
● Password is the same as the main access password.
● When uploading the MASTER and SLAVE units will display YELLOW.
● If an error occurs when uploading the MASTER and/or SLAVE units will display RED.
● On successful uploading of the custom programs the MASTER and SLAVE units
will display GREEN.
● In order to reset custom modes to default values select 【REST】.
● 【COLOR】 is for activate/unactivate the color calibration functions.
When 【RGBW】is selected, on RGBW = 255,255,255, 255 the color is displayed as calibrated
in CAL2 -- RGBW. When【COLOR】 is set 【OFF】, on RGBW = 255,255,255,255 the RGBW
values are not adjusted and the output is most powerful.
When [UC] is selected, the RGB output are adjusted to a standard preset universal color
which balances fixtures from different generations..
● 【LIFE】BATTERY LIFE ; LONG for extended battery operation (approx. 10hrs), NORM
for standard battery operation (approx. 8hrs).
SET
UPLD
REST
RGBW
COLOR
DIM1
DIM3
DIM2
DIM4
DIM
UC
OFF
OF F
PASS
PASS
SEND END
REST END
KEY ON
OFF
NORM
LIFE LONG
Cv1
Cv3
Cv2
OFF
CURV
OF F
BLAK
SAVE
DERR
OF F
ON
OFF
SLCK
OF F
CLAS
SPEC
STRB
PAGE: 07
BT-AKKUZOOM

【CAL2】
● Enter the 【CAL2】to adjust the RGB parameter to make different whites.
● When the new setting is activated, the DMX controller choose
RGB = 255,255,255, the white color will be made by the actual RGB values on
the .【CAL2】
RGBW Red
Green
Blue
(0~255)
(0~255)
(0~255)
CAL2
ACTI ON
OFF
WDMX
REST NO
YES
MENU
WDMX【 】
The BT-AKKUZOOM is compatible with the W-DMX G4-protocol from “Wireless Solution
Sweden“ and with the „WT-DMXG4" Wireless DMX Transmitter from Briteq.
●Enter 【WDMX】menu to change WDMX settings
● Enter the 【ACTI】 menu to turn ON/OFF WDMX functionality
● Enter the【REST】 menu to reset the WDMX pairing (note that only when
the WDMX receiver card is reset can it be paired with a new WDMX transmitter card)
3.12 WDMX SETTINGS
WT01
WT02
WT11
Red
Green
Blue
(0~255)
(0~255)
(0~255)
CAL1
MENU
【CAL1】
● Enter the 【CAL1】to select white color of different color temperature.
● There are 11 pre-programmed White colors can be edited by using 【Red】,
【Green】&【Blue】.
3.10 WHITES CALIBRATION
CAL
OK
3.9 EDITING CUSTOM PROGRAMS
PR.01
PR.10
SC.01
SC.30
Red
Green
Blue
Strobe
Time
Fade
(0~255)
(0~255)
(0~255)
(0~20)
(0~255)
(0~255)
EDIT
MENU
【EDIT CUSTOM】
● Enter the【EDIT 】mode to edit the custom programs【PR.01】to 【PR.10】.
● Each custom program has 30 steps that can be edited.
● Each step allows the creation of a scene using RED 【Red】, GREEN 【Green】,
BLUE 【Blue】, STROBE 【Strobe】, TIME【Time】 & FADE
【Fade】.
White (0~255)
PAGE: 08
BT-AKKUZOOM

1
2
0 2 5 5
3
4
0 2 5 5
0 2 5 5
0 2 5 5
5 0 2 5 5
7 1 9 0 RED 0%/GREEN DOWN/BLUE 100%
0 5
1 1
3 0
3 1 5 0
5 1 7 0
NO FUNCTION
RED100%/GREEN UP/BLUE0%
RED DOWN/GREEN 100%/BLUE0%
RED 0%/GREEN 100%/BLUE UP
6
WHITE1：3200K
WHITE2：3400K
WHITE3：4200K
WHITE4：4900K
1 7 1 2 0 0
2 0 1 2 0 5
2 0 6 2 1 0
2 1 1 2 1 5
2 1 6 2 2 0
RED100%/GREEN 100%P/BLUE100%
9 1 1 1 0
1 1 1 1 3 0
1 3 1 1 5 0
RED UP/GREEN 0%/BLUE100%
RED100%/GREEN 0%/BLU EDOWN
RED100%/GREEN UP/BLUE UP
1 5 1 1 7 0 RED DOWN/GREEN DOWN/BLUE 100%
TOUR
4.2 CHANNEL ASSIGNMENT
● Note:This product has six DMX512 channel configurations:【TOUR】，【TR16】,
【.】， 【.D】，【ARC 】，【 】,【 】 【 】.ARC 1 AR1 .2 AR2.D AR2.S and HVS
CHANNEL FUNCTIONVALUE
MASTER DIMMER
BLUE
GREEN
RED
WHITE
4.1 BASIC ADDRESSING
● Set the DMX512 address in the【DMX】menu.
● It is possible to have the same DMX address or independent addresses for each
fixture.
4 USING A DMX512 CONTROLLER
(or STEP TIME when CUS.01-CUS.10 in CH10 is activated)
(or FADE TIME when CUS.01-CUS.10 in CH10 is activated)
PAGE: 09
BT-AKKUZOOM

WHITE7：6500K
WHITE8：7200K
23 1 2 3 5
23 6 2 4 0
WHITE9：8000K
WHITE10：8500K
WHITE11：10000K
24 1 2 4 5
24 6 2 5 0
25 1 2 5 5
7 0 1 0
1 1 2 5 5
0 4 0
4 1 5 0 AUTO 1
6
WHITE5：5600K
WHITE6：5900K
22 1 2 2 5
22 6 2 3 0
8 1 4 1 1 5 0
1 5 1 1 6 0
1 6 1 1 7 0
1 7 1 1 8 0
1 8 1 1 9 0
1 9 1 2 0 0
2 0 1 2 1 0
2 1 1 2 2 0
2 2 1 2 3 0
PR.01
2 3 1 2 5 5
9 1 1 0 0
1 0 1
1 1 0
1 1 1 1 2 0
1 2 1 1 3 0
AUTO 6
AUTO 7
AUTO 8
AUTO 9
1 3 1 1 4 0 AUTO 10
5 1 6 0
6 1 7 0
7 1 8 0
8 1 9 0
AUTO 2
AUTO 3
AUTO 4
AUTO 5
0 2 5 5
9
PR.02
PR.03
PR.04
PR.05
PR.06
PR.07
PR.08
PR.09
PR.10
0 9
3 0 69
7 0 1 2 9
1 3 0 1 8 9
1 9 0 2 5 5
1 0
1 0 2 9
NO FUNCTION
1~20Hz
NO FUNCTION
When using CH10,AUTO01-AUTO10, this function activated
DIMMER SPEED
LINEAR DIMMER
NON LINEAR DIMMER 1（fastest）
NON LINEAR DIMMER 2
NON LINEAR DIMMER 3
NON LINEAR DIMMER 4（slowest）
PRESET DIMMER SPEED FROM DISPLAY MENU
CHANNEL FUNCTION
VALUE
WHITE7：6500K
WHITE8：7200K
23 1 2 3 5
23 6 2 4 0
WHITE9：8000K
WHITE10：8500K
WHITE11：10000K
24 1 2 4 5
24 6 2 5 0
25 1 2 5 5
7 0 1 0
1 1 2 5 5
0 4 0
4 1 5 0 AUTO 1
6
WHITE5：5600K
WHITE6：5900K
22 1 2 2 5
22 6 2 3 0
8 1 4 1 1 5 0
1 5 1 1 6 0
1 6 1 1 7 0
1 7 1 1 8 0
1 8 1 1 9 0
1 9 1 2 0 0
2 0 1 2 1 0
2 1 1 2 2 0
2 2 1 2 3 0
PR.01
2 3 1 2 5 5
9 1 1 0 0
1 0 1
1 1 0
1 1 1 1 2 0
1 2 1 1 3 0
AUTO 6
AUTO 7
AUTO 8
AUTO 9
1 3 1 1 4 0 AUTO 10
5 1 6 0
6 1 7 0
7 1 8 0
8 1 9 0
AUTO 2
AUTO 3
AUTO 4
AUTO 5
0 2 5 5
9
PR.02
PR.03
PR.04
PR.05
PR.06
PR.07
PR.08
PR.09
PR.10
0 9
3 0 69
7 0 1 2 9
1 3 0 1 8 9
1 9 0 2 5 5
1 0
1 0 2 9
NO FUNCTION
STROBE
1~20Hz
AUTO
NO FUNCTION
AUTO SPEED ADJUSTMENT
When using CH10,AUTO01-AUTO10, this function activated
DIMMER SPEED
LINEAR DIMMER
NON LINEAR DIMMER 1（fastest）
NON LINEAR DIMMER 2
NON LINEAR DIMMER 3
NON LINEAR DIMMER 4（slowest）
PRESET DIMMER SPEED FROM DISPLAY MENU
CHANNEL FUNCTION
VALUE
PAGE: 10
BT-AKKUZOOM

1
2
0 2 5 5
3
4
0 2 5 5
0 2 5 5
0 2 5 5
5 0 2 5 5
7 1 9 0 RED 0%/GREEN DOWN/BLUE 100%
0 1 0
1 1
3 0
3 1 5 0
5 1 7 0
NO FUNCTION
RED100%/GREEN UP/BLUE0%
RED DOWN/GREEN 100%/BLUE0%
RED 0%/GREEN 100%/BLUE UP
11
WHITE1：3200K
WHITE2：3400K
WHITE3：4200K
WHITE4：4900K
1 7 1 2 0 0
2 0 1 2 0 5
2 0 6 2 1 0
2 1 1 2 1 5
2 1 6 2 2 0
RED100%/GREEN 100%P/BLUE100%
9 1 1 1 0
1 1 1 1 3 0
1 3 1 1 5 0
RED UP/GREEN 0%/BLUE100%
RED100%/GREEN 0%/BLU EDOWN
RED100%/GREEN UP/BLUE UP
1 5 1 1 7 0 RED DOWN/GREEN DOWN/BLUE 100%
TR16
CHANNEL FUNCTIONVALUE
MASTER DIMMER
GREEN
RED
MASTER DIMMER FINE
RED FINE
6 0 2 5 5 GREEN FINE
7 0 2 5 5 BLUE
8 0 2 5 5 BLUE FINE
9 0 2 5 5 WHITE
10 0 2 5 5 WHITE FINE
COLOR MACRO&WHITE
PAGE: 11
BT-AKKUZOOM

W H I T E 7：6500K
W H I T E 8：7200K
2 3 1 2 3 5
2 3 6 2 4 0
W H I T E 9：8000K
WHITE10：8 5 0 0 K
WHITE11：1 0 0 0 0 K
2 4 1 2 4 5
2 4 6 2 5 0
2 5 1 2 5 5
12 0 1 0
1 1 2 5 5
0 4 0
4 1 5 0 A U T O 1
11
W H I T E 5：5 6 0 0 K
W H I T E 6：5 9 0 0 K
2 2 1 2 2 5
2 2 6 2 3 0
13 1 4 1 1 5 0
1 5 1 1 6 0
1 6 1 1 7 0
1 7 1 1 8 0
1 8 1 1 9 0
1 9 1 2 0 0
2 0 1 2 1 0
2 1 1 2 2 0
2 2 1 2 3 0
P R . 0 1
2 3 1 2 5 5
9 1 1 0 0
1 0 1
1 1 0
1 1 1 1 2 0
1 2 1 1 3 0
A U T O 6
A U T O 7
A U T O 8
A U T O 9
1 3 1 1 4 0 A U T O 1 0
5 1 6 0
6 1 7 0
7 1 8 0
8 1 9 0
A U T O 2
A U T O 3
A U T O 4
A U T O 5
0 2 5 5
14
P R . 0 2
P R . 0 3
P R . 0 4
P R . 0 5
P R . 0 6
P R . 0 7
P R . 0 8
P R . 0 9
P R . 1 0
0 9
3 0 69
7 0 1 2 9
1 3 0 1 8 9
1 9 0 2 5 5
15
1 0 2 9
NO FUNCTION
STROBE
1~20Hz
AUTO
NO FUNCTION
AUTO SPEED ADJUSTMENT
When using CH10,AUTO01-AUTO10, this function activated
DIMMER SPEED
LINEAR DIMMER
NON LINEAR DIMMER 1（fastest）
NON LINEAR DIMMER 2
NON LINEAR DIMMER 3
NON LINEAR DIMMER 4（slowest）
PRESET DIMMER SPEED FROM DISPLAY MENU
CHANNEL FUNCTION
VALUE
2 3 1 2 3 5
2 3 6 2 4 0
2 4 1 2 4 5
2 4 6 2 5 0
2 5 1 2 5 5
0 1 0
1 1 2 5 5
0 4 0
4 1 5 0
2 2 1 2 2 5
2 2 6 2 3 0
1 4 1 1 5 0
1 5 1 1 6 0
1 6 1 1 7 0
1 7 1 1 8 0
1 8 1 1 9 0
1 9 1 2 0 0
2 0 1 2 1 0
2 1 1 2 2 0
2 2 1 2 3 0
2 3 1 2 5 5
9 1 1 0 0
1 0 1
1 1 0
1 1 1 1 2 0
1 2 1 1 3 0
1 3 1 1 4 0
5 1 6 0
6 1 7 0
7 1 8 0
8 1 9 0
0 2 5 5
0 9
3 0 69
7 0 1 2 9
1 3 0 1 8 9
1 9 0 2 5 5
1 0 2 9
CHANNEL FUNCTION
VALUE
PAGE: 12
BT-AKKUZOOM

1
2
0 2 5 5
3
0 2 5 5
0 2 5 5
AR2.D
1
2
0 2 5 5
3
4
0 2 5 5
0 2 5 5
0 2 5 5
ARC2
1
2
0 255
3
0 255
0 255
ARC.1
LEdC.
CHANNEL FUNCTIONVALUE
RED
GREEN
BLUE
CHANNEL FUNCTION
VALUE
RED
GREEN
BLUE
GREEN
RED
DIMMER
CHANNEL FUNCTION
VALUE
WHITE
4 0 2 5 5 BLUE
5 0 2 5 5 WHITE
PAGE: 13
BT-AKKUZOOM
IJĖ I Į Ĝ FUNCTION VALUE FUNCTION VALUE FUNCTION VALUE FUNCTION
ﻮ يي 100% 255 100% 255 100% 248-255 OUTPUT = 100%
247 STROBE 15Hz
slow to fast speed
201 STROBE 0,5Hz
191-200 OUTPUT = 100%
190 DIM 100%
8 DIM 0%
0 0% 0 0% 0 0% 000-007 OFF
Ĉ Ǽ Ī ĜG Č Ǽ ĠĪ ĜĜÍ Ċ Ǽ ĘI Į Ĝ Ç  Ì ĖĬ İ ĜĪ GHÌ

5.2 Select DMX from the <RUN> menu.
5.3 Select ACTI from the <WDMX> menu and proceed to turn ON the WDMX.
If the WDMX receiver card is already paired with a WDMX transmitter then
the fixture is ready for receiving DMX signal. If the WDMX receiver card needs
to be paired with a new WDMX transmitter, select YES from the <WDMX >/<REST>
menu. The green signal indicator LED will not show which confirms that WDMX receiver
card is unpaired and ready for new pairing.。
5.1 When using this lighting fixture with W-DMX receiver installed inside,
the fixture may be placed at a range of 300m from W-DMX transmitter
WIRELESS RECEIVING ANTENNA
5OPERATION WITH WIRELESS DMX
W-DMX TRANSMITTER
1
2
0 2 5 5
3
0 2 5 5
0 2 5 5
HSV
1
2 0 2 5 5
3
4
0 2 5 5
0 2 5 5
0 2 5 5
RED
GREEN
BLUE
VALUE
SATURATION
HUE
CHANNEL FUNCTION
VALUE
WHITE
CHANNEL FUNCTION
VALUE
AR2.S
0 2 5 5 DIMMER
6 0 2 5 5 STROBE
5
PAGE: 14
BT-AKKUZOOM

1
2
6
5
4
3
1
2
6
5
4
3
PAGE: 15
BT-AKKUZOOM
STATIC PLAY
(press 2s to 3s to take effect)
COLOR KEY BUTTONS
(first set colors in the setup menu:
[EDIT]>[CKY1] ... [CKY6] )
COLOR KEY BUTTONS
first load the desired
effect in the setup menu:
* [EDIT]>[EKY1] ... [EKY6]
load:
* [AT01] ... [AT10] (factory effects)
* [PR01] ... [PR10] (user effect presets)
WHITE + BLUE +
ON / OFF
(press 4s to 5s to take effect)
WHITE - BLUE -
RED +
RED -
GREEN +
GREEN -
ADJUST

6 BATTERY CHARGING
6.1 BATTERY SPECIFICATIONS:
Type of bettery:Lithium Battery
Voltage: 24V
Storage Capacity: 8800mA
Charge Time: 8 hrs
Discharge Time: 8hrs (in fixture at full output)
Weight: 1.2Kg
Dimensions:135X65X76mm
6.2 SPECIAL CONSIDERATIONS:
Charging
lDo not charge for more than 24 hours
lAlways charge with flightcase open
lIt is recommended to charge at a temperature between 0℃ to 35℃
lAlways recharge within 3 days of use
lAlways charge with supplied charger
Operation
lRecommended ambient temperature is between 0℃ to 35℃
lAlways use fixture in a vertical or near-vertical position (<30deg. from vertical)
lDo not operate in a sealed enclosure with insufficient air flow
Storage
lAlways store at a temperature below 35℃ (below 25℃ is best)
lAlways store in a vertical position
lAlways store fully charged
lIt is important to carry out one full discharge and charge cycle every 3 months
lAlways use the battery switch when storing for longer than 7 days
lStore in a dry environment away from direct sunlight
Maintenance
lAlways switch off the battery switch when carrying out maintenance
lDo not allow battery contacts come into contact with fixture housing
lDo not link the positive and negative terminals in any way
Red
Black
Battery
PAGE: 16
BT-AKKUZOOM

1、Charger +ve
2、Charger -ve
6.3 CHARGER SPECIFICATIONS
Voltage: AC100-240V, 50/60Hz
Output: DC24V, 3A
6.4 FLIGHTCASE SPECIFICATIONS
Voltage: AC100-240V, 50,60Hz
Rated Power: 300W
Weight: 21KG
Dimensions: 730 x 400 x 520mm
6.5 IMPORTANT FACTS:
HOW TO CARE FOR YOUR BATTERY!
STORING
STORE WITH FULL LOAD
l
TURN OFF AT BASE WHEN STORING FOR MORE THAN 7 DAYS
l
STORE IN AN UPRIGHT POSITION
l
CHARGING
DO NOT CHARGE FOR MORE THAN 24HRS
l
RECHARGE WITHIN 3DAYS OF USE
l
CHARGE WITH FLIGHTCASE OPEN
l
21
PAGE: 17
BT-AKKUZOOM

7 APPENDIX
7.1 MAINTENANCE
No. Item Name
1
2
3
4
5
6
Hanger
Wireless Receiver
Top cover
Lens.
Fix board of wireless Receiver.
7
Plastic cover 1 for fixing lens.
Plastic cover 2 for fixing lens.
Fixed board for zoom
Connecting bracket for zoom.
Zooming supporter
light barrier.
Body cover A
Foam pad.
Wireless receiver board.
Zooming pillar
Light Guid Bart
Arm
Lithium battery
Lithium battery holder.
Driver board
.
Display board.
Recharge socket A.
Bearer for recharge socket A
PCB holder.
Button of display board
Full-featured control panel.
Foot.
Power switch.
Body cover B.
Cooling aluminum.
Led board.
Zooming nut.
Zooming screw.
Connector for lens
Fixed board for LED charge indicator.
LED charge indicato.
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
27
26
28
29
30
31
32
33
34
35
36
PAGE: 18
BT-AKKUZOOM
