Briteq BTX-LIGHTSTRIKE User manual

Other languages can be downloaded from:
WWW.BRITEQ-LIGHTING.COM
ENGLISH
Operation Manual
Version: 1.0
JB LOGO MET
JUISTE SPACING
(enkel voor JBS !!!)
FOTO / TEKENING
TOEVOEGEN

ENGLISH
USER MANUAL
BRITEQ®1/22 BTX-LIGHTSTRIKE
OPERATION MANUAL
Thank you for buying this Briteq®product. To take full advantage of all possibilities and for your own safety,
please read these operating instructions very carefully before you start using this unit.
FEATURES
•BTX-LIGHTSTRIKE is a very versatile hybrid LED Pixel mapping bar, excellent for many rental jobs, TV-
studios, concert stages, discotheques and many more.
•This hybrid LED bar consists of 2 complementary effects for maximum impact:
•112 extremely bright cold-white LEDs, divided into 16 zones, form a central line to create awesome
and overwhelming strobe effects.
•672 RGB LEDs on both sides of the central white strobe line, arranged in 32 powerful LED pixel zones
of 21 RGB LEDs each, provide a powerful tool for creating stunning, colorful moving images.
•Multiple operating modes allow for flexible use in any setting imaginable:
•Extended DMX modes with up to 112 channels where you can control each pixel individually via media
servers to create the most insane images and hallucinating effects.
•Limited-channel DMX modes (only 14CH) where the built-in effect macros ensure that incredibly
creative shows can be built with relatively simple DMX controllers in very little time.
•Besides the standard DMX with RDM support, there is also full support for Art-net and sACN allowing
large sets to be built up and controlled quickly and efficiently.
•Optional creative filters are available for all kinds of additional visual effects.
•The BTX-LIGHTSTRIKE is very compact and has a low weight which allows it to be quickly incorporated into
all kinds of scenery.
•For easy installation, 2 mounting options are included:
•Tilt mounting brackets: to which standard clamps can be added.
•Omega bracket bases: for use with optional omega brackets and standard clamps.
•Equipped with an inventive quick-release mechanism that allows you to quickly connect and align multiple
projectors.
•Standard equipped with 3pin XLR, RJ45 network and PowerCON compatible connector in/outputs for easy
daisy chaining.
•Very silent operation, thanks to temperature-controlled cooling fans.
•Alphanumeric OLED-display and touch keys to select the different options in the setup menu.
•Four dimmer curves: linear, square, inverse square, S-curve
BEFORE USE
•Before you start using this unit, please check if there’s no transportation damage. Should there be any, do
not use the device and consult your dealer first.
•Important: This device left our factory in perfect condition and well packaged. It is absolutely necessary for
the user to strictly follow the safety instructions and warnings in this user manual. Any damage caused by
mishandling is not subject to warranty. The dealer will not accept responsibility for any resulting defects or
problems caused by disregarding this user manual.
•Keep this booklet in a safe place for future consultation. If you sell the fixture, be sure to add this user manual.
Check the contents:
Check that the packing contains the following items:
•BTX-LIGHTSTRIKE (tilt brackets installed)
•2pcs extra omega bracket base
•English operating instructions, other languages can be downloaded from our website.
•Mains power cable

ENGLISH
USER MANUAL
BRITEQ®2/22 BTX-LIGHTSTRIKE
SAFETY INSTRUCTIONS:
•To protect the environment, please try to recycle the packing material as much as possible.
•To avoid condensation to be formed inside, allow the unit to adapt to the surrounding temperatures when bringing it into
a warm room after transport. Condense sometimes prevents the unit from working at full performance or may evencause
damages.
•Don’t place metal objects or spill liquid inside the unit. Electric shock or malfunction may result. If a foreign object enters
the unit, immediately disconnect the mains power.
•Locate the fixture in a well-ventilated spot, away from any flammable materials and/or liquids. The fixture must be fixed
at least 50cm from surrounding walls.
•Don’t cover any ventilation openings as this may result in overheating.
•Prevent use in dusty environments and clean the unit regularly.
•Keep the unit away from children.
•Inexperienced persons should not operate this device.
•Maximum safe ambient temperature is 40°C. Don’t use this unit at higher ambient temperatures.
•Make sure the area below the installation place is free from unwanted persons during rigging, de-rigging and servicing.
•Allow the device about 10 minutes to cool down before to start servicing.
•Always unplug the unit when it is not used for a longer time or before to start servicing.
•The electrical installation should be carried out by qualified personal only, according to the regulations for electrical and
mechanical safety in your country.
•Check that the available voltage is not higher than the one stated on the unit.
•The power cord should always be in perfect condition. Switch the unit immediately off when the power cord is squashed
or damaged. It must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a
hazard.
•Never let the power-cord come into contact with other cables!
•This fixture must be earthed in order to comply with safety regulations.
•Don’t connect the unit to any dimmer pack.
•Always use an appropriate and certified safety cable when installing the unit.
•In order to prevent electric shock, do not open the cover. There are no user serviceable parts inside.
•Never repair a fuse or bypass the fuse holder. Always replace a damaged fuse with a fuse of the same type and
electrical specifications!
•In the event of serious operating problems, stop using the fixture and contact your dealer immediately.
•The housing and the lenses must be replaced if they are visibly damaged.
•Please use the original packing when the device is to be transported.
•Due to safety reasons it is prohibited to make unauthorized modifications to the unit.
Important: Never look directly into the light source! Don’t use the effect in the presence of persons suffering from epilepsy.
CAUTION: To reduce the risk of electric shock, do not remove the
top cover. No user-serviceable parts inside. Refer servicing to
qualified service personnel only.
The lightning flash with arrowhead symbol within the equilateral triangle is intended to alert the use or
the presence of un-insulated “dangerous voltage” within the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock.
The exclamation point within the equilateral triangle is intended to alert the user to the presence of
important operation and maintenance (servicing) instructions in the literature accompanying this
appliance.
This Class I appliance must be earthed in order to comply with safety regulations
IP20
This appliance is protected against penetration of objects over 12mm but is not protected against dripping
water, rain or splashes/jets of water.
This symbol means: indoor use only!
This symbol means: Read instructions
This symbol determines: the minimum distance from lighted objects. The minimum distance between
light-output and the illuminated surface must be more than 1 meters
Visibly damaged lenses/housing parts should be replaced with original spare parts.
CAUTION: Do not stare at operating light source, this may be harmful to the eyes.

ENGLISH
USER MANUAL
BRITEQ®3/22 BTX-LIGHTSTRIKE
DESCRIPTION:
1. MAINS INPUT: equipped with PowerCON®compatible connectors. Connect the supplied mains cable or
any PowerCon® extension cable here.
2. MAINS OUTPUT: used to daisy chain the power to several other projectors. Always pay attention to the
maximum load while adding projectors! Special Multi cables (PowerCON® + DMX XLR-cables are optionally
available: see our website!)
Hint: Please check our website for special cable assemblies that contain both power (3x1.5mm² with
Neutrik PowerCON®TRUE1) and balanced signal (XLR 3pin) in one cable. Different lengths are
available: 1.3m, 3m, 5m and 10m, very convenient!
3. DMX IN/OUT: 3pin in/outputs are available to daisy chain the projector with other units that will be
controlled by a DMX-controller.
4. ETHERNET IN/OUT: used to connect the projector to an Ethernet network, Art-Net / sACN protocol is
supported.
5. DISPLAY & BUTTONS: alphanumeric OLED-display and touch keys to select different options of the
setup menu:
•MENU-button: used to browse the different menu options or to exit a menu option. If the setup menu
is locked: press the button for about 2seconds to unlock and enter.
•▼-button: used to go to the next menu option or to decrease a parameter value.
•▲-button: used to go to the previous menu option or to increase a parameter value.
•ENTER-button: used to select a menu option or confirm a setting.
Note: shortcut to flip the display → press the ▲+▼ buttons together.
6. VENTILLATION HOLES + COOLING FAN: it is very important to make sure that the temperature-
controlled fan and ventilation openings always remain free to maintain optimal cooling!
7. HANGING BRACKET: with a knob to fasten the unit in the desired tilt position. You can use the hole in
the center of the bracket to fix a hook or truss clamp. There are 6 fixing holes so you can adapt the position
of the brackets if needed.
8. OMEGA BRACKET BASE: can be fixed instead of the
standard hanging brackets so you can easily fix two optional
“omega bracket small” (order code: B02677).There are 6
fixing holes so you can adapt the position of the omega bases
if needed.
9. SAFETY HOLE: used to attach (an optional) safety cable when the unit is rigged, see paragraph “overhead
rigging”.

ENGLISH
USER MANUAL
BRITEQ®4/22 BTX-LIGHTSTRIKE
10. COUPLER MECHANISM: the coupler mechanism makes it possible to quickly connect and align two or a
long line of projectors together. Please proceed as follows:
A. Pull the locking pin and turn it over 90°
so it stays unlocked.
B. Move the latch on the other projector
so that the slide comes out completely.
C. Place both projectors nicely against
each other in line so that the slide fits
nicely into the other projector.
D. When this is done, pull the locking pin
and turn it again over 90°, until the pin
fits in the hole of the slide and locks
both projectors together.
Done!
OVERHEAD RIGGING
•Important: The installation must be carried out by qualified service personal only. Improper
installation can result in serious injuries and/or damage to property. Overhead rigging requires
extensive experience! Working load limits should be respected, certified installation materials
should be used, the installed device should be inspected regularly for safety.
•Make sure the area below the installation place is free from unwanted persons during
rigging, de-rigging and servicing.
•Locate the fixture in a well-ventilated spot, far away from any flammable materials and/or
liquids. The fixture must be fixed at least 50cm from surrounding walls.
•The device should be installed out of reach of people and outside areas where persons
may walk by or be seated.
•Before rigging make sure that the installation area can hold a minimum point load of
10times the device’s weight.
•Always use a certified safety cable that can hold 12times the weight of the device when installing the unit.
This secondary safety attachment
should be installed in a way that no
part of the installation can drop
more than 20cm if the main
attachment fails.
•The device should be well fixed; a
free-swinging mounting is
dangerous and may not be
considered!
•Don’t cover any ventilation
openings as this may result in
overheating.
•The operator has to make sure
that the safety-relating and
machine-technical installations
are approved by an expert before
using them for the first time. The
installations should be inspected
every year by a skilled person to
be sure that safety is still optimal.

ENGLISH
USER MANUAL
BRITEQ®5/22 BTX-LIGHTSTRIKE
SETUP MENU:
Main Menu
1st Level
2nd Level
Remarks
Default Value
DMX Settings
DMX Address
001-506
1
Channel Mode
6CH
21CH
15CH
17CH
21CH
33CH
39CH
65CH
113CH
No DMX Status
BlackOut
Freeze
Freeze
View DMX Value
Select a channel to monitor
Connection Option
Auto
Auto
DMX
Art-Net
sACN
Network
IP Address
Subnet Mask
Art-Net Settings
Net
values: 0 → 127
0
Sub-Net
values: 0 → 15
0
Universe
values: 0 → 15
0
sACN Settings
sACN Universe
values: 0001 → 32000
1
sACN Priority
values: 0 → 200
100
Fixture Settings
Dimmer Curve
Linear
LINEAR
Square law
Inv SQ law
S Curve
Dimmer Speed
Fast
Fast
Smooth
White Balance
Red1
255
Green1
255
Blue1
255
Red2
255
Green2
255
Blue2
255
Invert PixelOrder
DISABLE
DISABLE
ENABLE
PWM Frequency
1200 Hz
4800 Hz
3600 Hz
4800 Hz
7200 Hz
12000 Hz
Display Settings
Display Invert
No/Yes
No
Temperature Unit
°C / F
(Celcius / Fahrenheit)
°C
Fixture Test
Auto Test
Fixture Information
Fixture Use Hour
LED Use Hour
Total LED Hour
LED On Hour
LED Hours Reset
needs password (= 050)
Temperature
current + max LED temp.
Fan State
xxxx
shows actual rotation speed
Firmware Version
RDM UID
xxxxxx
Error Logs
Fixture Errors
Reset Error Log
confirm with password (= 050)
Special Functions
Factory Restore
No/Yes

ENGLISH
USER MANUAL
BRITEQ®6/22 BTX-LIGHTSTRIKE
General operation of the setup menu:
•Press the MENU button to ENTER the setup menu.
•Press the ▼/▲ buttons to browse the menu until the required function shows up.
•Select the function with the ENTER button.
•Use ▼/▲ buttons to change the values.
•Press the ENTER button to confirm the selected value.
•Press the MENU button to return to a higher level in the menu or leave the setup menu.
Remark 1: press the MENU button during 2s to unlock the setup menu
Remark 2: press the ▼/▲ buttons together to flip the display.
DMX SETTINGS menu
DMX ADDRESS
Used to set the desired DMX-address.
•Press the ▼/▲ buttons to browse the menu until the required function shows up.
•Press the ENTER button: the values can be changed
•Use ▼/▲ buttons to select the desired DMX512 address. The last occupied DMX-address is also shown:
makes it easier to set the address of the next unit in the chain.
•Once the correct address shows on the display, press the ENTER button to save it.
Note: on RDM-compatible controllers this option can also be remotely set.
CHANNEL MODE
Used to set the desired channel mode.
•Press the ▼/▲ buttons to browse the menu until the required function shows up.
•Press the ENTER button: the values can be changed
•Use ▼/▲ buttons to select the desired mode:
•6CH 2 zones: z1= RGB + z2 = WHITE (no effect macros)
•15CH 2 zones: z1= RGB + z2 = WHITE + multi-zone effect macros (combined control RGB / WHITE)
•21CH 2 zones: z1= RGB + z2 = WHITE + multi-zone effect macros (separate control RGB / WHITE)
•17CH 8 zones: 4 RGB + 4 WHITE + Function channel
•33CH 16 zones: 8 RGB + 8 WHITE (only pixel control) + Function channel
•39CH 16 zones: 8 RGB + 8 WHITE + separate RGB / WHITE strobe & dim + Function channel
•65CH 32 zones: 16 RGB + 16 WHITE (only pixel control) + Function channel
•113CH 48 zones: 32 RGB + 16 WHITE (only pixel control) + Function channel
•Once the correct option shows on the display, press the ENTER button to save it.
Remark: on RDM-compatible controllers this option can also be remotely set.
NO DMX Status
Used to set how the projector reacts when the DMX-signal suddenly disappears.
•Press the ▼/▲ buttons to browse the menu until the required function shows up.
•Press the ENTER button: the values can be changed
•Use ▼/▲ buttons to select the desired mode:
•BLACKOUT: output turns black while no DMX is detected.
•FREEZE: output based on the last valid DMX-signal is kept on the projector.
•Once the correct option shows on the display, press the ENTER button to save it.
Note: as soon as the input detects a DMX-signal, blackout or freeze mode will be cancelled.
View DMX Values
Used to monitor the incoming DMX-signals, handy for fault debugging.
•Press the ▼/▲ buttons to browse the menu until the required function shows up.
•Press the ENTER button: you can monitor the incoming DMX-signal, functions and values are displayed.
•Press the ▼/▲ buttons to select the channel that you want to monitor.
Connection Option
Used to set the desired control mode.
•Press the ▼/▲ buttons to browse the menu until the required function shows up.
•Press the ENTER button: the values can be changed
•Use ▼/▲ buttons to select the desired mode:
•AUTO: checks the incoming signals and selects the first valid signal.

ENGLISH
USER MANUAL
BRITEQ®7/22 BTX-LIGHTSTRIKE
•DMX: standard DMX / RDM input is used for control
•Art-Net: Art-Net™ protocol is used
•sACN: sACN protocol is used.
Network
Used to set the network parameters.
•Press the ▼/▲ buttons to browse the menu until the required function shows up.
•IP-address
•Subnet Mask
•Press the ENTER button: the values can be changed
•Use combination of ▼/▲ and ENTER buttons to set the desired values.
Art-Net Settings
Used to set the specific Art-Net parameters.
•Press the ▼/▲ buttons to browse the menu until the required function shows up.
•Net (0 → 127)
•Sub-Net (0 → 15)
•Universe (0 → 15)
•Press the ENTER button: the values can be changed
•Use combination of ▼/▲ and ENTER buttons to set the desired values.
sACN Settings
Used to set the specific sACN parameters.
•Press the ▼/▲ buttons to browse the menu until the required function shows up.
•sACN universe (1 → 32’000)
•sACN priority (0 → 200)
•Press the ENTER button: the values can be changed
•Use combination of ▼/▲ and ENTER buttons to set the desired values.
FIXTURE SETTINGS menu
DIMMER CURVE
Used to set the dimmer curve of the master dimmer.
•Press the ▼/▲ buttons to browse the menu until the required function shows up.
•Press the ENTER button: the values can be changed
•Use ▼/▲ buttons to selected the desired curve:
•Once you have the desired curve, press the ENTER button to save it.
DIMMER SPEED
Used to set the speed (smoothness) of the dimmer continuously.
•Press the ▼/▲ buttons to browse the menu until the required function shows up.
•Press the ENTER button: the values can be changed
•Use ▲/▼ buttons to select the desired speed:
•Fast: quick and snappy response, can small steps can be noticed while dimming very slowly.
•Smooth: smoother dimming without visual steps but slower reaction time for fast changes.
•Once the desired value shows on the display, press the ENTER button to confirm.
WHITE BALANCE
Used to set the white balance.
The projector contains 2 PCBs with LEDs: when 1 PCB needs to be replaced, the white balance helps to match
the colors of the new PCB with those of the already present PCB. We recommend to use this option only when
it is really necessary.
•Connect the projector to a DMX controller in the 6CH DMX-mode and choose the color you want to match.

ENGLISH
USER MANUAL
BRITEQ®8/22 BTX-LIGHTSTRIKE
•Press the ▼/▲ buttons to browse the menu until the required function shows up.
•Press the ENTER button: the display shows the 3 LED colors of PCB 1 & 2 (change with ▼/▲ buttons)
•Press the ENTER button: the display shows the value (125-255) for the selected color / led.
•Use ▼/▲ buttons to adapt the value between 125 and 255 and confirm with ENTER
•Repeat these steps until you have the desired values. The settings will be automatically saved.
Invert PixelOrder
To keep uniformity, you can flip the pixel order when some projectors are mounted normally and others
upside-down (suspended).
•Press the ▼/▲ buttons to browse the menu until the required function shows up.
•Press the ENTER button: the values can be changed
•Use ▼/▲ buttons to select the desired mode:
•Once the correct option shows on the display, press the ENTER button to save it.
PWM Frequency
Used to set the PWM refresh frequency of the LED dimming to avoid undesired effects on video
recordings.
•Press the ▲/▼ buttons until the desired function is showing on the display.
•Press the ENTER button: the values can be changed
•Use ▲/▼ buttons to select the desired speed:
•1200 Hz : slowest PWM frequency.
…
•12000 Hz: highest possible PWM frequency,
•Once the desired value shows on the display, press the ENTER button to confirm.
Remark 1: please note that the dimmer behavior changes when the PWM frequency is changed so always
use the same PWM frequency on all units.
Remark 2: The default value (4800 Hz) gives excellent results.
DISPLAY SETTINGS menu
Display Invert
Used to flip the display (turn it 180°).
•Press the ▼/▲ buttons to browse the menu until the required function shows up.
•Press the ENTER button: the values can be changed
•Use ▼/▲ buttons to select the desired mode:
•No: normal display
•Yes: flipped display.
•Once the correct option shows on the display, press the ENTER button to save it.
Remark: a faster shortcut is to press the ▼/▲ buttons together for about 2 seconds.
Temperature Units
Used to select if the LED-temperature is shown in degrees Celsius °C or Fahrenheit F.
•Press the ▼/▲ buttons to browse the menu until the required function shows up.
•Press the ENTER button: the values can be changed
•Use ▼/▲ buttons to select the desired mode:
•°C: temperature shown in degrees Celsius.
•F: temperature shown in Fahrenheit.
•Once the correct option shows on the display, press the ENTER button to save it.

ENGLISH
USER MANUAL
BRITEQ®9/22 BTX-LIGHTSTRIKE
FIXTURE TEST menu
AUTO TEST
Used to quickly check if all LEDs are working well without the need for a DMX-console.
•Press the ▼/▲ buttons to browse the menu until the required function shows up.
•Press the ENTER button:
•The display starts flashing while showing ”Testing……”
•The different LED colors are lit one by one so you can see if they are all working well.
•Press the MENU button to stop the “AUTO TEST” function.
FIXTURE INFORMATION menu
FIXTURE Use Hours
Shows the Total time the projector was switched on, starting from the 1st day it was used.
•Press the ▼/▲ buttons to browse the menu until the required function shows up.
•Press the ENTER button: the TOTAL usage time is shown, this value cannot be reset.
LED Use Hours
Shows the time information of the LEDs in the projector.
•Press the ▼/▲ buttons to browse the menu until the required function shows up.
•Press the ENTER button → 3 options are shown:
•Total LED Hour: shows the number of operating hours of the LEDs since the first use
•LED On Hour: shows the number of operating hours of the LEDs since the last reset.
•LED Hours reset: resets the “LED On Hour” counter.
Temperature
Shows the current + Max LED Temperature.
•Press the ▼/▲ buttons to browse the menu until the required function shows up.
•Press the ENTER button (use ▼/▲ buttons to choose the LEDs on PCB1 or PCB2):
•The current LED temperature is shown.
•The MAXIMUM LED temperature is shown, since the projector was switched on.
Fan State
Shows the actual rotation speed of the cooling fan.
•Press the ▼/▲ buttons to browse the menu until the required function shows up.
•Press the ENTER button: the current rotation speed is shown (in RPM)
Firmware Version
Shows actual firmware version information.
•Press the ▼/▲ buttons to browse the menu until the required function shows up.
•Press the ENTER button: the current firmware version of the different processors is shown.
Note: The firmware of this unit can be upgraded using our special “Firmware Updater” (separately available
from Briteq). More information about this can be found in the user manual of the firmware updater or our
website: https://briteq-lighting.com/firmware-updater
RDM UID
Shows actual unique RDM ID of the projector.
•Press the ▼/▲ buttons to browse the menu until the required function shows up.
•Press the ENTER button: the unique RDM ID of the projector is shown.
•This RDM-UID has 2 parts:
•Fixed part (same for all BTX-LIGHTSTRIKE units): 21220047
•Random part (unique 4-digit for each unit, ranging from 0000 to FFFF)
ERROR Messages
Shows eventual ERROR messages if they exist.
•Press the ▼/▲ buttons to browse the menu until the required function shows up.
•Press the ENTER button: under normal conditions the display should be empty.
Remark: when a FAN ERROR occurs, the output is reduced to 50% to prevent overheating of the unit.

ENGLISH
USER MANUAL
BRITEQ®10/22 BTX-LIGHTSTRIKE
SPECIAL FUNCTIONS menu
FACTORY RESTORE →
This is your emergency exit if you really messed up the settings: just return to factory settings.
•Press the ▼/▲ buttons to browse the menu until the required function shows up.
•Press the ENTER button: the values can be changed
•Use ▼/▲ buttons to selected the desired option:
•No (nothing happens)
•Yes (factory defaults are loaded)
Remark: the default values are shown in the last column of the SETUP MENU table, see earlier in this manual.
ELECTRICAL INSTALLATION
Important: The electrical installation should be carried out by qualified personal only,
according to the regulations for electrical and mechanical safety in your country.
Mains power is the same for all units but there are different possibilities to connect the data cabling:
ELECTRICAL INSTALLATION FOR TWO OR MORE UNITS IN WIRED DMX-MODE:
Use this function when you want to control the projectors by any DMX controller.
•Connect the projectors as shown in the drawing below.
•First put the projectors in the desired DMX-mode: see the different DMX-charts and choose the one that
suits you best.
•Give all projectors a start address: each projector shows its start + end address, make sure that the
addresses do not overlap!
Some general information on DMX:
•The DMX-protocol is a widely used high speed signal to control intelligent light equipment. You need to
“daisy chain” your DMX controller and all the connected units with a balanced cable of good quality.
•Both XLR-3pin and XLR-5pin connectors are used, however XLR-3pin is more popular because these
cables are compatible with balanced audio cables.
•Pin layout XLR-3pin: Pin1 = GND ~ Pin2 = Negative signal (-) ~ Pin3 = Positive signal (+)
•Pin layout XLR-5pin: Pin1 = GND ~ Pin2 = Negative signal (-) ~ Pin3 = Positive signal (+) ~ Pins4+5
not used.
•To prevent strange behavior of the light effects, due to interferences, you must use a
90Ω to 120Ω terminator at the end of the chain. Never use Y-splitter cables, this
simply won’t work!
•Make sure that all units are connected to the mains.
•Each light effect in the chain needs to have its proper starting address so it knows which commands from
the controller it has to decode.
ELECTRICAL INSTALLATION VIA WIRED ETHERNET IN/OUT:
Art-Net is nothing more than a protocol for transmitting DMX512 over an Ethernet network, developed by
Artistic Licence Engineering (UK) Ltd. Thanks to the much bigger bandwidth it is possible to send more than
256 DMX-universes in one time.
This projector can be connected in such Ethernet network using routers, switches etc. The network topology
is exactly the same as for a normal PC-network. However, IP-addresses cannot be obtained via DHCP: see

ENGLISH
USER MANUAL
BRITEQ®11/22 BTX-LIGHTSTRIKE
the explanations in the chapter “setup menu” on how to manually setup the IP-address, Net Mask and choose
the desired DMX-universe. Also the sACN protocol is supported.
IMPORTANT NOTE: this projector has both Ethernet input and output so you can daisy chain several units.
However, the number of units in one chain should be limited to ±10 units to avoid unwanted signal delays. In
bigger installations you should use the “STAR-topology” using Ethernet switches (or a combination of both).
This reduces the delays between unit and also improves reliability of the installation.
•Internally the selected DMX-universe is treated as a normal DMX-signal so further setup of the DMX-
address, channel mode etc. should be done as usual.
DMX CHARTS
There are several DMX-modes for maximum compatibility under different conditions:
DMX CHART for BASIC USE
Simple mode, without pixels control or pixel macros
6 CH
VALUE
FUNCTION
REMARKS
1
000-255
RED
pixel 1
2
000-255
GREEN
pixel 1
3
000-255
BLUE
pixel 1
4
000-255
WHITE
pixel 2
5
000-255
MASTER DIMMER (coarse) 0 → 100%
6
000-255
MASTER DIMMER (fine) 0 → 100%

ENGLISH
USER MANUAL
BRITEQ®12/22 BTX-LIGHTSTRIKE
DMX CHARTS with pre-programmed PIXEL MACROS
Easy mode, with pixel macros: the perfect choice to make nice shows on controllers with a limited number of
DMX channels or when there is not enough time to write complicated pixel mapping programs.
15CH LAYOUT
15 CH
VALUE
FUNCTION
REMARKS
1
000-255
RED
pixel 1
2
000-255
GREEN
pixel 1
3
000-255
BLUE
pixel 1
4
000-255
WHITE
pixel 2
5
MACRO COLOR PRESETS
000-009
Macros OFF
010-017
Color1
018-024
Color2
025-032
Color3
033-039
Color4
040-047
Color5
048-054
Color6
055-061
Color7
062-069
Color8
070-076
Color9
077-084
Color10
085-091
Color11
092-099
Color12
100-106
Color13
107-113
Color14
114-121
Color15
122-128
Color16
129-136
Color17
137-143
Color18
144-151
Color19
152-158
Color20
159-165
Color21
166-173
Color22
174-180
Color23
181-188
Color24
189-195
Color25
196-203
Color26
204-210
Color27
211-217
Color28
218-225
Color29
226-232
Color30
233-240
Color31
241-247
Color32
248-255
Color33
6
000-255
MASTER DIMMER (coarse) 0 → 100%
combined for all pixels
7
000-255
MASTER DIMMER (fine) 0 → 100%
16 bit mode
8
000-255
STROBE DURATION
combined for all pixels
9
STROBE SPEED
000-006
No strobe
combined for all pixels
007-255
SPEED (slow → fast)
combined for all pixels
10
STROBE EFFECTS
000-005
No effect
combined for all pixels
006-050
Ramp up
combined for all pixels
051-100
Ramp down
combined for all pixels
101-150
Ramp up-down
combined for all pixels
151-200
Lightning
combined for all pixels
201-255
Random
combined for all pixels

ENGLISH
USER MANUAL
BRITEQ®13/22 BTX-LIGHTSTRIKE
11
RGB EFFECT MACROS
RGB macros use 32pixels
000-039
No function
040-047
RGB Macro 1
048-055
RGB Macro 2
056-063
RGB Macro 3
064-071
RGB Macro 4
072-079
RGB Macro 5
080-087
RGB Macro 6
088-095
RGB Macro 7
096-103
RGB Macro 8
104-111
RGB Macro 9
112-119
RGB Macro 10
120-127
RGB Macro 11
128-135
RGB Macro 12
136-143
RGB Macro 13
144-151
RGB Macro 14
152-159
RGB Macro 15
160-167
RGB Macro 16
168-175
RGB Macro 17
176-183
RGB Macro 18
184-191
RGB Macro 19
192-199
RGB Macro 20
200-207
RGB Macro 21
208-215
RGB Macro 22
216-223
RGB Macro 23
224-231
RGB Macro 24
232-239
RGB Macro 25
240-247
RGB Macro 26
248-255
RGB Macro 27
12
EFFECT MACROS - WHITE CENTRAL LINE
WHITE macros use 16pixels
000-090
No function
091-105
WHITE Macro 1
106-120
WHITE Macro 2
121-135
WHITE Macro 3
136-150
WHITE Macro 4
151-165
WHITE Macro 5
166-180
WHITE Macro 6
181-195
WHITE Macro 7
196-210
WHITE Macro 8
211-225
WHITE Macro 9
226-240
WHITE Macro 10
241-255
WHITE Macro 11
13
MACRO SPEED (COMBINED FOR CH11 + CH12)
000-004
STOP (waiting at first step)
005-127
SPEED L→R: SLOW to FAST
128-132
STOP (waiting at last step)
133-255
SPEED R→L: SLOW to FAST
14
000-255
FADE EFFECT (zero → max)
15
FUNCTION CHANNEL
000-005
No function
006-010
DIMMER CURVE: LINEAR
3 seconds delay
011-015
DIMMER CURVE: SQUARE
3 seconds delay
016-020
DIMMER CURVE: INV. SQUARE
3 seconds delay
021-025
DIMMER CURVE: S-CURVE
3 seconds delay
026-030
No function
031-035
DIMMER SPEED: FAST
3 seconds delay
036-040
DIMMER SPEED: SLOW
3 seconds delay
041-045
No function
046-050
PIXEL ORDER: NORMAL
3 seconds delay
051-055
PIXEL ORDER: INVERSED
3 seconds delay
056-060
No function
061-065
LED PWM Frequency: 1200Hz
3 seconds delay

ENGLISH
USER MANUAL
BRITEQ®14/22 BTX-LIGHTSTRIKE
066-070
LED PWM Frequency: 3600Hz
3 seconds delay
071-075
LED PWM Frequency: 4800Hz
3 seconds delay
076-080
LED PWM Frequency: 7200Hz
3 seconds delay
081-085
LED PWM Frequency: 12000Hz
3 seconds delay
086-255
No function
21CH LAYOUT
21 CH
VALUE
FUNCTION
REMARKS
CONTROLS FOR RGB ZONES
1
000-255
RED
pixel 1
2
000-255
GREEN
pixel 1
3
000-255
BLUE
pixel 1
4
MACRO COLOR PRESETS
000-009
Macros OFF
010-017
Color1
018-024
Color2
025-032
Color3
033-039
Color4
040-047
Color5
048-054
Color6
055-061
Color7
062-069
Color8
070-076
Color9
077-084
Color10
085-091
Color11
092-099
Color12
100-106
Color13
107-113
Color14
114-121
Color15
122-128
Color16
129-136
Color17
137-143
Color18
144-151
Color19
152-158
Color20
159-165
Color21
166-173
Color22
174-180
Color23
181-188
Color24
189-195
Color25
196-203
Color26
204-210
Color27
211-217
Color28
218-225
Color29
226-232
Color30
233-240
Color31
241-247
Color32
248-255
Color33
5
000-255
MASTER DIMMER (coarse) 0 → 100%
6
000-255
MASTER DIMMER (fine) 0 → 100%
7
000-255
STROBE DURATION
8
STROBE SPEED
000-006
No strobe
007-255
SPEED (slow → fast)
pixel 1
9
STROBE EFFECTS
000-005
No effect
006-050
Ramp up
051-100
Ramp down

ENGLISH
USER MANUAL
BRITEQ®15/22 BTX-LIGHTSTRIKE
101-150
Ramp up-down
151-200
Lightning
201-255
Random
10
EFFECT MACROS
RGB macros use 32pixels
000-039
No function
040-047
RGB Macro 1
048-055
RGB Macro 2
056-063
RGB Macro 3
064-071
RGB Macro 4
072-079
RGB Macro 5
080-087
RGB Macro 6
088-095
RGB Macro 7
096-103
RGB Macro 8
104-111
RGB Macro 9
112-119
RGB Macro 10
120-127
RGB Macro 11
128-135
RGB Macro 12
136-143
RGB Macro 13
144-151
RGB Macro 14
152-159
RGB Macro 15
160-167
RGB Macro 16
168-175
RGB Macro 17
176-183
RGB Macro 18
184-191
RGB Macro 19
192-199
RGB Macro 20
200-207
RGB Macro 21
208-215
RGB Macro 22
216-223
RGB Macro 23
224-231
RGB Macro 24
232-239
RGB Macro 25
240-247
RGB Macro 26
248-255
RGB Macro 27
11
MACRO SPEED
000-004
STOP (waiting at first step)
005-127
SPEED L→R: SLOW to FAST
128-132
STOP (waiting at last step)
133-255
SPEED R→L: SLOW to FAST
12
000-255
FADE EFFECT (zero → max)
CONTROLS FOR WHITE ZONE
13
000-255
MASTER DIMMER (coarse) 0 → 100%
14
000-255
MASTER DIMMER (fine) 0 → 100%
15
000-255
STROBE DURATION
16
STROBE SPEED
000-006
No strobe
007-255
SPEED (slow → fast)
pixel 2
17
STROBE EFFECTS
000-005
No effect
006-050
Ramp up
051-100
Ramp down
101-150
Ramp up-down
151-200
Lightning
201-255
Random
18
EFFECT MACROS
WHITE macros use 16pixels
000-090
No function
091-105
WHITE Macro 1
106-120
WHITE Macro 2
121-135
WHITE Macro 3
136-150
WHITE Macro 4
151-165
WHITE Macro 5
166-180
WHITE Macro 6
181-195
WHITE Macro 7
196-210
WHITE Macro 8
211-225
WHITE Macro 9

ENGLISH
USER MANUAL
BRITEQ®16/22 BTX-LIGHTSTRIKE
226-240
WHITE Macro 10
241-255
WHITE Macro 11
19
MACRO SPEED
000-004
STOP (waiting at first step)
005-127
SPEED L→R: SLOW to FAST
128-132
STOP (waiting at last step)
133-255
SPEED R→L: SLOW to FAST
20
000-255
FADE EFFECT (zero → max)
21
FUNCTION CHANNEL
000-005
No function
006-010
DIMMER CURVE: LINEAR
3 seconds delay
011-015
DIMMER CURVE: SQUARE
3 seconds delay
016-020
DIMMER CURVE: INV. SQUARE
3 seconds delay
021-025
DIMMER CURVE: S-CURVE
3 seconds delay
026-030
No function
031-035
DIMMER SPEED: FAST
3 seconds delay
036-040
DIMMER SPEED: SLOW
3 seconds delay
041-045
No function
046-050
PIXEL ORDER: NORMAL
3 seconds delay
051-055
PIXEL ORDER: INVERSED
3 seconds delay
056-060
No function
061-065
LED PWM Frequency: 1200Hz
3 seconds delay
066-070
LED PWM Frequency: 3600Hz
3 seconds delay
071-075
LED PWM Frequency: 4800Hz
3 seconds delay
076-080
LED PWM Frequency: 7200Hz
3 seconds delay
081-085
LED PWM Frequency: 12000Hz
3 seconds delay
086-255
No function
39CH LAYOUT
39 CH
VALUE
FUNCTION
REMARKS
CONTROLS FOR RGB ZONES
1
000-255
RED1
2
000-255
GREEN1
3
000-255
BLUE1
4
000-255
RED2
5
000-255
GREEN2
6
000-255
BLUE2
7
000-255
RED3
8
000-255
GREEN3
9
000-255
BLUE3
10
000-255
RED4
11
000-255
GREEN4
12
000-255
BLUE4
13
000-255
RED5
14
000-255
GREEN5
15
000-255
BLUE5
16
000-255
RED6
17
000-255
GREEN6
18
000-255
BLUE6
19
000-255
RED7
20
000-255
GREEN7
21
000-255
BLUE7
22
000-255
RED8
23
000-255
GREEN8
24
000-255
BLUE8

ENGLISH
USER MANUAL
BRITEQ®17/22 BTX-LIGHTSTRIKE
25
000-255
MASTER DIMMER (coarse) 0 → 100%
26
000-255
MASTER DIMMER (fine) 0 → 100%
27
000-255
STROBE DURATION
28
STROBE SPEED
000-006
No strobe
007-255
SPEED (slow → fast)
29
STROBE EFFECTS
000-005
No effect
006-050
Ramp up
051-100
Ramp down
101-150
Ramp up-down
151-200
Lightning
201-255
Random
WHITE ZONE
30
000-255
WHITE 1
31
000-255
WHITE 2
32
000-255
WHITE 3
33
000-255
WHITE 4
34
000-255
MASTER DIMMER (coarse) 0 → 100%
35
000-255
MASTER DIMMER (fine) 0 → 100%
36
000-255
STROBE DURATION
37
STROBE SPEED
000-006
No strobe
007-255
SPEED (slow → fast)
38
STROBE EFFECTS
000-005
No effect
006-050
Ramp up
051-100
Ramp down
101-150
Ramp up-down
151-200
Lightning
201-255
Random
39
FUNCTION CHANNEL
000-005
No function
006-010
DIMMER CURVE: LINEAR
3 seconds delay
011-015
DIMMER CURVE: SQUARE
3 seconds delay
016-020
DIMMER CURVE: INV. SQUARE
3 seconds delay
021-025
DIMMER CURVE: S-CURVE
3 seconds delay
026-030
No function
031-035
DIMMER SPEED: FAST
3 seconds delay
036-040
DIMMER SPEED: SLOW
3 seconds delay
041-045
No function
046-050
PIXEL ORDER: NORMAL
3 seconds delay
051-055
PIXEL ORDER: INVERSED
3 seconds delay
056-060
No function
061-065
LED PWM Frequency: 1200Hz
3 seconds delay
066-070
LED PWM Frequency: 3600Hz
3 seconds delay
071-075
LED PWM Frequency: 4800Hz
3 seconds delay
076-080
LED PWM Frequency: 7200Hz
3 seconds delay
081-085
LED PWM Frequency: 12000Hz
3 seconds delay
086-255
No function

ENGLISH
USER MANUAL
BRITEQ®18/22 BTX-LIGHTSTRIKE
DMX CHARTS for pure PIXEL MAPPING
Several extended DMX modes: the perfect choice while used with media servers and consoles with pixel
mapping possibilities.
17CH LAYOUT
33CH LAYOUT
65CH LAYOUT
113CH LAYOUT
17CH
33CH
65CH
113CH
–
FUNCTION
REMARKS
1
1
1
1
000-255
RED1
2
2
2
2
000-255
GREEN1
3
3
3
3
000-255
BLUE1
4
4
4
4
000-255
RED2
5
5
5
5
000-255
GREEN2
6
6
6
6
000-255
BLUE2
7
7
7
7
000-255
RED3
8
8
8
8
000-255
GREEN3
9
9
9
9
000-255
BLUE3
10
10
10
10
000-255
RED4
11
11
11
11
000-255
GREEN4
12
12
12
12
000-255
BLUE4
13
13
13
000-255
RED5
14
14
14
000-255
GREEN5
15
15
15
000-255
BLUE5
16
16
16
000-255
RED6
17
17
17
000-255
GREEN6
18
18
18
000-255
BLUE6
19
19
19
000-255
RED7
20
20
20
000-255
GREEN7
21
21
21
000-255
BLUE7
22
22
22
000-255
RED8
23
23
23
000-255
GREEN8
24
24
24
000-255
BLUE8
25
25
000-255
RED9
26
26
000-255
GREEN9
27
27
000-255
BLUE9
28
28
000-255
RED10
29
29
000-255
GREEN10
30
30
000-255
BLUE10
31
31
000-255
RED11
32
32
000-255
GREEN11
33
33
000-255
BLUE11
