Junior Picnic Table Assembly Instructions
PLEASE READ THESE INSTRUCTIONS CAREFULLY AND FOLLOW THE ASSEMBLY DRAWINGS.
WE WILL NOT ACCEPT ANY CLAIMS IF THIS PRODUCT IS WRONGLY ASSEMBLED.
Parts Supplied Tools Required
a) 2 × A-Frame supports
b) 10 × Seat & table slats [numbered 1 to
10]
c) 1 × Angle brace
d) 2 × Seat ties
e) 1 × Table tie
f) 44 × 90mm long screws
g) 18 × 70mm long screws
Power drill with Philips screwdriver bit
Measuring tape
Straight edge
2 Person Operation
2 × A-Frames
2 × Seat slats [1&10]
4 × 90mm screws
4 × 70mm screws
2 × Seat slats [2&9]
8 × 90mm screws
• Position seat slats 2 and 9 with a
small gap between slats.
• Square the ends with a straight edge.
• Fix with 90mm screws.
• Position outer table slats 3 and 8 with a 10mm
overhang and 160mm from horizontal support
to end of slat.
• Loosely secure outer holes with 90mm screws.
• Ensure slats are square by measuring the
diagonals. The diagonals should measure
the same.
• Tighten the outer screws once the table is
square.
• Fix inner holes with 90mm screws.
2.
3.
1.
All seat and table slat labels should face upward and be on the left-hand side when
assembled. A-Frame labels should face outwards.
2 × Table slats [3&8]
8 × 90mm screws
•StandA-Framesuprightonaatsurfacewithhorizontal
support facings on the inside.
• Position seat slats 1 and 10 as the diagram, and locate
pilot holes in the A-Frames through the predrilled outer
holes of the slats, secure loosely using 70mm screws -
but do not fully tighten. (This will give a 10mm overhang
and 160mm from horizontal support to end of slat).
• Ensure that the frames are square by measuring
across the diagonals. The diagonals should
measure the same.
• Tighten the outer screws once the table is square.
• Fix the inner holes with 90mm screws.
10mm
160mm
2
9
10
1
10mm
160mm

BRITISH RECYCLED PLASTIC Unit 8C, Top Land Country Business Park, Cragg Road, Mytholmroyd, HX7 5RW Tel: [phone] Email: [email protected] britishrecycledplastic.co.uk
Junior Picnic Table Assembly Instructions
PLEASE READ THESE INSTRUCTIONS CAREFULLY AND FOLLOW THE ASSEMBLY DRAWINGS.
WE WILL NOT ACCEPT ANY CLAIMS IF THIS PRODUCT IS WRONGLY ASSEMBLED.
• Line up the angle brace between the A-Frames in line with
the holes on the horizontal supports.
•Firstxtheanglebraceontothetabletophorizontalsupport
 with90mmscrewssothatthetopoftheanglebraceisush
with the top of the horizontal support.
• Fix the angle brace to the seat horizontal support with
90mm screws.
6.
4.
5. 4 × Table slats [4,5,6&7]
16 × 90mm screws
2 × Seat ties
1 × Table tie
14 × 70mm screws
• Position the 4 remaining slats [4,5,6&7] spaced equally.
• Square the ends with a straight edge.
• Fix with 90mm screws.
• Turn the table over on to its top.
• Fix the seat ties in the centre of the seat slats with
70mm screws (4 screws per tie).
• Fix the table tie in the centre of the table slats with
70mm screws (1 screw per slat).
1 × Angle brace
4 × 90mm screws
