Brivis Touch User manual

Brivis Touch
Owner’s Manual

i
Congratulations on purchasing a Brivis Touch Comfort Controller. This
intelligent Controller can be used with a range of Brivis heating and
cooling products.
The Brivis Touch allows you to maximize the performance of your
heating and cooling system with customized comfort control.
The Brivis Touch Controller can operate in many configurations, for
example:
•a single Touch Controller with a single Brivis comfort system
•a single Touch Controller with multiple Brivis comfort systems
•a single Touch Controller with single or multiple room temperature
sensors
•multiple Touch Controllers
The Brivis Touch Controller also facilitates either Single Temperature
Set Point (STSP) or Multi Temperature Set Point (MTSP) control of
zoned systems.
Your Brivis designer / installer will advise you on the appropriate
configuration and operation of your system. Please also refer to any
Owner’s Manuals accompanying each of your Brivis products.
Follow the step-by-step instructions in this guide to begin enjoying the
benefits of your Brivis climate system.
Specifications subject to change without notice.
Pictures for illustration purposes only.
© Brivis Climate Systems Pty Ltd 2016.

ii
Table of Contents
1.0 Quick Reference Guide................................................................. 1
2.0 Quick Start Guide.......................................................................... 3
3.0 Fan Operation............................................................................... 3
4.0 Heating – Manual Operation ......................................................... 4
4.1 Heating – Program Schedule Operation........................................ 4
5.0 Cooling – Manual Operation.......................................................... 5
5.1 Cooling – Program Schedule Operation ........................................ 5
6.0 Evaporative Cooling – Manual Operation ...................................... 6
6.1 Evaporative Cooling – Pump Only Operation ................................ 7
6.2 Evaporative Cooling – Fan Only Operation ................................... 7
6.3 Evaporative Cooling– Auto Operation ........................................... 7
6.4 Evaporative Cooling – Timer Operation......................................... 7
6.5 Evap Timer ON – Manual / Auto.................................................... 8
6.6 Evap Timer OFF – Manual / Auto.................................................. 9
6.7 Evap Timer Cancel or Change .................................................... 10
7.0 Zoning (where installed).............................................................. 10
7.1 Single Temperature Set Point Zoning (STSP)............................. 10
7.2 Multi Temperature Set Point Zoning (MTSP)............................... 10
8.0 Menu .......................................................................................... 11
9.0 User Preferences........................................................................ 11
9.1 System Lockout Control.............................................................. 12
9.2 General Settings ......................................................................... 12
9.3 System Settings .......................................................................... 13
9.4 Set Zone Names ......................................................................... 14
10.0 Clean Screen ............................................................................ 14
11.0 Schedule................................................................................... 15
12.0 Set Day/Time ............................................................................ 16
13.0 Service Notification Message .................................................... 16
14.0 Outdoor Temperature Sensor (Optional) ................................... 17
15.0 Error Messages......................................................................... 17
16.0 Power Outages ......................................................................... 17
17.0 Glossary.................................................................................... 18

1
1.0 Quick Reference Guide
Diagram
1
: Heating screen in Manual Operation
Room temperature sensor active
System Mode/Run indicator
Zones (Where Fitted)
Mode Selector
ON/OFF
Digital Clock
Manual or Schedule
M – Master Controller
Day
Fan Only mode
Display Options or Settings
Fan Status Indicator
Current System Mode
Room / Zone Temperature
Zone ID (where fitted)

2
Diagr
am
3
: Refrigerated Cooling Screen
Diagram
2
: Evaporative Cooling Screen
Pump OnFan On
Timer OnTimerManual / Auto

3
2.0 Quick Start Guide
The quick start procedure, as outlined below, allows you to begin using
your system before you learn all the details of system operation.
1. Activate the Brivis Touch Controller by touching anywhere
on the LCD screen.
2. Select the required mode by pressing the “MODE” button
(where more than one option is available – i.e. HEAT, COOL
or EVAP).
3. Turn on the system by pressing the “ON/OFF” button.
4. Select the desired temperature / comfort level by using the
“UP/DOWN” buttons.
5. System will run at desired comfort level until turned OFF by
pressing the “ON/OFF” button.
You may access User Preferences and other advanced options by
pressing the “MENU” button.
3.0 Fan Operation
FAN ONLY
With the system OFF (standby) push the “FAN” button in the top right
hand corner to turn the fan ON.
If in ‘HEAT’ or ‘COOL’ mode the heater fan will turn on.
If in ‘EVAP’ mode the evaporative cooler fan will turn on.
CIRCULATION FAN
When enabled by the installer, the circulation fan will be on
continuously between Heating and Refrigerated Cooling cycles.
CIRC FAN will be indicated below the FAN icon.

4
4.0 Heating – Manual Operation
To operate your heating system with full manual control, activate the
Controller by touching the LCD screen, select HEAT using the MODE
button, turn system on using the ON/OFF button, and set the desired
temperature. The system will operate to maintain the desired
temperature level until turned OFF.
4.1 Heating – Program Schedule Operation
The Brivis Touch Controller uses default ‘energy saver’ HEAT settings
that helps reduce your heating expenses.
To operate your Heating system with the Schedule, activate the
Controller by touching the LCD screen, select HEAT using the MODE
button, turn system on using the ON/OFF button, and press the
“Schedule” button. The system will operate automatically to maintain
the desired temperatures as programmed in the program Schedule.
Advance to next Period
If you leave or arrive home early, you may skip to the next schedule
period by pressing the current period displayed, e.g. .
The program schedule will automatically resume once one of the
following occurs:
•The next time period begins.
•The “Cancel” button is pressed.
•The Temporary period is pressed.
Note:
Time period “
Pre
-
Sleep
” can be enabled in the “User
Preferences” > ”System Settings” > ”Pre-Sleep Option”. To
customise your “Schedule” settings to suit your lifestyle, please
see section “User Preferences” > “System Settings” > ”Schedule
Settings”.
Diagram
4
: Heating ON – Schedule home screen
Diagram
5
: Heating Advance Period

5
Temporary Temperature Override
To temporarily adjust the temperature, simply adjust the temperature
level with the UP/DOWN arrows. The program Schedule will
automatically resume once one of the following occurs:
•The next time period begins.
•The “Cancel” button is pressed.
The word “Temporary” will flash on the screen.
5.0 Cooling – Manual Operation
To operate your Refrigerated Cooling system with full manual control,
activate the Controller by touching the LCD screen, select COOL using
the MODE button, turn system on using the ON/OFF button, and set
the desired temperature. The system will operate to maintain the
desired temperature level until turned OFF.
5.1 Cooling – Program Schedule Operation
The Brivis Touch Controller uses default ‘energy saver’ COOL settings
that helps reduce your refrigerated cooling expenses.
To operate your Refrigerated Cooling system with the program
schedule, activate the Controller by touching the LCD screen, select
COOL using the MODE button, turn system on using the ON/OFF
button, and press the SCHEDULE button. The word COOL will appear
on the screen. The system will operate automatically to maintain the
temperatures as programmed in the Schedule.
Note:
Time period “
Pre
-
Sleep
” can be enabled in the “User
Preferences” > ”System Settings” > ”Pre-Sleep Option”. To
customise your “Schedule” settings to suit your lifestyle, please
see section “User Preferences” > “System Settings” > ”Schedule
Settings”.
Diagram
6
: Heating Temperature Override

6
Advance to next Period
If you leave or arrive home early, you may skip to the next schedule
period by pressing the current period displayed, e.g. .
The program schedule will automatically resume once one of the
following occurs:
•The next time period begins.
•The “Cancel” button is pressed.
•The Temporary period is pressed.
Temporary Temperature Override
To temporarily adjust the temperature, simply adjust the temperature
level with the UP/DOWN arrows. The program Schedule will
automatically resume once one of the following occurs:
•The next time period begins.
•The “Cancel” button is pressed.
The word “Temporary” will flash on the screen.
Diagram
7
: Cooling ON – Schedule home screen
Diagram
9
: Cooling Temperature Override
Diagram
8
: Cooling Advance Period

7
6.0 Evaporative Cooling – Manual Operation
To operate your Evaporative Cooling system with full manual control,
activate the Controller by touching the LCD screen, select EVAP using
the MODE button, turn system on using the ON/OFF button. When the
Evaporative Cooler turns on for the first time the PUMP and FAN will
be on, indicated by the light blue colour buttons. Set the desired FAN
SPEED level with the UP/DOWN arrows. The system will operate until
turned OFF.
6.1 Evaporative Cooling – Pump Only Operation
While in Manual Operation, press the FAN icon to disable the fan.
The PUMP icon will remain illuminated, the FAN icon will not. Only the
pump will be running in this mode and no air will be circulating.
6.2 Evaporative Cooling – Fan Only Operation
While in Manual Operation, press the PUMP icon to disable the
pump. The FAN icon will remain illuminated, the PUMP icon will not.
Only the fan will be running in this mode.
6.3 Evaporative Cooling– Auto Operation
To operate your Evaporative Cooling system so that it automatically
maintains your desired comfort level, activate the Controller by
touching the LCD screen, select EVAP using the MODE button, turn
system ON using the ON/OFF button, press the “AUTO” button, set the
desired comfort level using the UP/DOWN arrows. The system will
automatically regulate the pump and fan speed to maintain your
desired comfort level.
The darker bars represents a cooler comfort level requirement, refer
Diagram 11.
6.4 Evaporative Cooling – Timer Operation
The “Timer” option allows access to the evaporative cooler program to
turn the system ON or OFF for Manual or Auto operation. The timer
can be set within the next 24 hour period by selecting the time of day
for it to activate.
Diagram
10
: Evaporative Cooling Manual Operation
Diagram
11
: Evaporative Cooling Auto Operation

8
6.5 Evap Timer ON – Manual / Auto
With the system in “EVAP” mode and OFF, press the “Timer” button,
refer Diagram 12.
To set the ON Timer firstly select mode of operation, either MANUAL
or AUTO.
For ON Timer in MANUAL mode the below configuration options
become available to change:
•Fan Speed (Low to High)
•Pump ON or OFF (Press the “PUMP” button to change)
•Set On Time (within next 24 hours)
To save settings and return to the home OFF screen press “Done”. To
cancel Timer setting press “BACK”.
For ON Timer in AUTO mode the below configuration options become
available to change:
•Comfort Level (Dark blue is cooler)
•Set On Time (within next 24 hours)
Diagram
12
: EVAP mode in OFF state
Diagram
13
: Manual – Set On Timer

9
To save settings and return to the home OFF screen press “Done”. To
cancel Timer setting press “BACK”.
The EVAP home OFF screen will display with a clock symbol adjacent
to the “Timer” button to confirm TIMER ON has been set, refer
Diagram 15.
6.6 Evap Timer OFF – Manual / Auto
With the system ON in either MANUAL or AUTO mode, press the
“Timer” button, refer Diagrams 10 & 11.
For OFF Timer the below configuration option becomes available to
change:
•Set Off Time (within next 24 hours)
To save settings and return to the ON screen press “Done”. To cancel
Timer setting press “BACK”.
Diagram
15
: EVAP OFF with ON Timer Set
Diagram
16
: Set OFF Timer
Diagram
14
: Auto – Set On Timer

10
6.7 Evap Timer Cancel or Change
If TIMER ON or TIMER OFF has been set, as indicated by the clock
adjacent to the TIMER button, this may be cancelled or changed.
To cancel the timer press the “Timer” button to enter the timer settings
then press “BACK”. The clock adjacent to the “Timer” button will
disappear.
To change the timer press the “Timer” button to enter the timer
settings, change the time then press “Done”. The clock adjacent to the
“Timer” button will remain.
7.0 Zoning (where installed)
IMPORTANT NOTE:
Your specialist Brivis Dealer may have divided your home into a
maximum of four controlled zones that can be operated and controlled
separately. The exact configuration of your system will determine the
programming features that are enabled, as well as the number of
zones that can be heated (or cooled) simultaneously. Your system
may be operated manually, or you can program your comfort schedule
and let the system automatically do the rest. Multiple Brivis Touch
Controllers or Temperature Sensors may be fitted.
The following information applies to HEATING or REFRIGERATED
COOLING systems only (i.e. not Evaporative Systems).
Please ensure your dealer has provided you with details on zone
identification, the capabilities of your heating and cooling system, and
the maximum or minimum number of zones that can be operated
simultaneously for heating or cooling design conditions.
7.1 Single Temperature Set Point Zoning (STSP)
The zone temperature set point is the same across all Touchscreens
and/or Temperature Sensors.
Pressing the “ZONES” button on the Home Screen will bring up the
ZONE SELECTION: OPERATING screen, refer Diagram 17.
•A blue light indicates the zone’s status (ON or OFF)
•Press to select “On” or “Off” as required
•A flashing blue “On” status indicates the zone is at the set point
7.2 Multi Temperature Set Point Zoning (MTSP)
The zone temperature set point can be set independently across all
Touchscreens and/or Temperature Sensors.
Pressing the “ZONES” button on the Home Screen will scroll between
the available zones, indicated by the Zone ID, refer Diagram 18.
•The Home Screen indicates the Zone Temperature and Set Point
of each Zone
Diagram
17
: STSP Zone Selection: Operation

11
•A flashing Zone ID indicates you are viewing a Zone other than the
Zone being controlled by the Controller
•Any Zone can be viewed or adjusted from any Touch Controller
•The System Run Indicator (e.g. Flame) identifies if the Zone is
active
8.0 Menu
The configuration MENU screen is accessed whenever the “MENU”
button is pressed on all Brivis Touch Controllers installed. It provides
access to various settings that control how the Brivis Touch Controller
appears and for the homeowner these are:
1. User Preferences
2. Clean Screen
3. Schedule
4. Set Day/Time
Refer Diagram 19.
Note: Once you access the MENU Screen and select a configuration
option, if no button is pressed for 60 seconds, the Touch will exit the
configuration mode and return to normal operation; this applies to all
options other than SCHEDULE.
9.0 User Preferences
When the “User Preferences” button is pressed on the Master Brivis
Touch controller user settings are accessed, refer Diagram 20.
Diagram
20
: User Preferences
Diagram
1
9
: MENU options
Diagram
18
: MTSP Zone Selection
Note:
A flashing “ZONE” button on the Home Screen indicates all
Zones are satisfied and system is in standby.

12
9.1 System Lockout Control
From the Master Brivis Touch Controller, “System Lockout Control”
allows the system to be locked or unlocked in any state, and the user
PIN codes to be set or reset, refer Diagram 21.
To lock the system press “Lockout System” and enter the User PIN,
the default PIN is “1111” until modified. When locked a padlock icon
will flash at the bottom of the touch screen.
If the system is locked the “System Lockout Control” button
(Diagram 18) appears as “Unlock System”. When this button is
pressed the display reverts to showing a numeric keypad which is
used to enter the PIN code to unlock the system.
To modify the User PIN, press either “PIN Number 1” or “PIN Number
2”. Pressing either one of these will allow the PIN to be modified and a
key pad will appear as shown in Diagram 22. Once the new PIN has
been entered press “OK” to accept.
9.2 General Settings
When the “General Settings” button is pressed on any Brivis Touch
controller the general settings can be viewed and altered. These
settings are specific to the Brivis Touch controller being accessed.
The three settings currently available are:
Note:
All Brivis Touch Controllers are able to lock and unlock the
system – only the Master Controller allows you to change the PIN.
Diagram 2
3
: Active backlight intensity
Diagram
22
: Key Pad for PIN entry
Diagram
2
1
: System Lockout Control

13
9.3 System Settings
When the “System Settings” button is pressed on the Master Brivis
Touch Controller the system settings can be defined, refer Diagram 26.
The “Schedule Day Grouping” option allows the customisation of
days when programming the AUTO schedule.
For “Schedule Day Grouping” (Heat/Cool) the options are:
•Weekdays / Weekends
•Same for all days
•Set days individually
The “Schedule Pre-Sleep Option” allows this period to be ON or OFF
when programming the AUTO schedule.
The “Temperature Display Scale” allows the temperature scale
displayed on the home screen to be either Celsius or Fahrenheit. .
Diagram
26
: System Settings
Diagram 2
4
: Active backlight delay
Diagram 2
5
: Dimmed backlight delay

14
9.4 Set Zone Names
All installed zones can be given a descriptive name up to sixteen
characters long. When the “Set Zone Names” button is pressed on the
Master Brivis Touch Controller all installed zones appear and when
selected can be changed accordingly, refer Diagram 27.
By pressing a zone, a keypad appears to enable the zone name
change, refer Diagram 28.
Press the “Done” button once complete and the zone name will be
changed, refer Diagram 29.
10.0 Clean Screen
The screen displayed after pressing the “Clean Screen” button allows
no user input, reverting back to the configuration menu screen after 30
seconds. This allows the Brivis Touch Controller screen to be cleaned
without affecting any operation, refer Diagram 30.
Diagram
27
: Naming of Zones
Diagram
30
: Clean Screen for 30 seconds
Diagram
29
: Keypad for renaming of zones
Diagram
28
: Keypad for Naming of Zones

15
11.0 Schedule
The default time and temperature values for each period are set as
shown in Diagram 31 and Diagram 32 for Heating and Cooling
respectively.
To access the Heating Schedule the system must be in HEAT mode
and access is through “MENU” > “Schedule”.
To access the Cooling Schedule the system must be in COOL mode
and access is through “MENU” > “Schedule”.
To modify the time, select the time for the relevant period, e.g. Wake
6:00AM and press the UP/DOWN arrows to change.
To modify the temperature, select the temperature for the relevant
period, e.g. Wake 20°and press the UP/DOWN arrows to change. To
set a period to OFF, reduce the temperature for that period DOWN to
the minimum setting.
Repeat this for all day grouping options, Weekdays / Weekends shown
in Diagrams 29 & 30 if installed. Once complete press “BACK” to save
and exit back to the MENU screen.
Only the zones installed for the heating/cooling system are displayed
and can be enabled or disabled for each period by pressing the
relevant zone button. Light blue indicates the zone is enabled.
Note:
For STSP systems, there is one Heating/Cooling Schedule for all
zones
For MTSP systems, there is one Heating/Cooling Schedule for
each controlled zone.
Note:
For STSP systems default times and temperatures
apply to all zones, and their default is ‘ON’.
Diagram
31
: Heating Default Schedule – Weekdays shown
Diagram
32
: Cooling Default Schedule – Weekdays shown

16
12.0 Set Day/Time
When the “Set Day/Time” button is pressed on the Master Brivis
Touch Controller this allows the day, time and time period to be
changed, refer Diagram 33.
To set the Day and Time press the adjacent UP/DOWN arrows.
Pressing the “Done” button saves the changes and returns you to the
configuration menu screen. Pressing the “BACK” button does not save
the changes and returns to the configuration menu screen.
13.0 Service Notification Message
When the operating hours logged for an appliance exceeds the
predetermined period, the Brivis Touch Controller displays the
following:
Diagram
3
3
: Set Day/Time
The “
S
panner
” icon appears
flashing at one second intervals.
The “ ” Alert icon is displayed with the “Alert” text
flashing at one second intervals.
Diagram
3
4
: System Alert
Note:
Changing the system DAY/TIME can only be done on the
Brivis Master Touch Controller.

17
Pressing the “ ” icon will result in the following message being
displayed for either HEAT/COOL or EVAP fan run hours above the
preset limit. The system will continue to run with this message
displayed. You may book a service call or clear the Spanner and Alert
icon by pressing the “Clear”button, refer Diagram 35.
14.0 Outdoor Temperature Sensor (Optional)
If you installed this option, the outdoor (ambient) temperature will be
displayed as indicated in Diagram 36. If “OD” does not appear next to
the day display on your screen, this feature is not enabled.
15.0 Error Messages
When your system is operating, the Brivis Touch Controller monitors and
controls every aspect of the system's performance. On-board diagnostics
help determine the source of any faults. If a lockout fault is detected, the
yellow “Alert” will flash, refer Diagram 36. Press the “Alert” icon to display
details of the fault, refer Diagram 37.
If the system turns off completely you may reset the system by pressing the
“Reset” button, refer Diagram 37.
If normal operation does not resume, please call Brivis Service for
assistance. Inform them of the nature of your problem, the relevant error
code, model and type of appliance so your issue can be remedied.
16.0 Power Outages
If power is restored within 10 minutes of a power outage, the Brivis Touch
will resume normal operation with the mode and settings immediately
before the outage.
When powered OFF, the Controller will retain its Day and Time setting for
up to 5 days.
Diagram
35
: Fan run hour limit
D
iagram
3
6
: Alert on the home screen
Diagram
3
6
: Outdoor Temperature Display
